PMJTR02Transmitter for Wireless Headphones

Document Number 102115 Rev A Rosen Aviation Digital Wireless Headphone System Document Number: 102115 Revision: B Date: TBD Template: 4.2.3-6-FM; Revision A; 16 May, 2005 Page 2 of 10 Technical Manual, Digital Wireless Headphone System © 2008 by Rosen Aviation, LLC All Rights Reserved The information contained herein is proprietary to Rosen Aviation, LLC. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written authorization from Rosen Aviation, LLC, except as allowed under copyright laws. Disclaimer of Liability The information contained in this document is subject to change without notice. Because we are continually improving and adding features to our products, Rosen Aviation, LLC reserves the right to change specifications without prior notice. Rosen Aviation, LLC shall not be liable for technical or editorial errors or omissions contained herein. Rosen Aviation, LLC 1020 Owen Loop South Eugene, OR 97402 541.342.3802 888.668.4955 Fax: 541.342.4912 www.rosenaviation.com Rosen Aviation Digital Wireless Headphone System Document Number: 102115 Revision: B Date: TBD Template: 4.2.3-6-FM; Revision A; 16 May, 2005 Page 3 of 10 Contents 1. INTRODUCTION .................................................................................................................4 1.1. Unpacking .....................................................................................................................4 2. CONNECTING THE TRANSMITTER .................................................................................4 3. WIRELESS TRANMITTER CONNECTOR .........................................................................5 4. PLACING THE TRANSMITTER .........................................................................................6 5. INSERTING THE BATTERIES INTO THE HEADPHONES ...............................................7 6. OPERATING THE HEADPHONES .....................................................................................8 7. TECHNICAL REFERENCES AND SUPPORT ...................................................................8 7.1. Troubleshooting ............................................................................................................8 7.2. DO-160E Qualifications ................................................................................................9 8. SPECIFICATIONS ..............................................................................................................9 9. REVISION HISTORY ........................................................................................................ 10 Rosen Aviation Digital Wireless Headphone System Document Number: 102115 Revision: B Date: TBD Template: 4.2.3-6-FM; Revision A; 16 May, 2005 Page 4 of 10 1. INTRODUCTION The Digital Wireless Headphone System consists of a 5.8 GHz transmitter and 5.8 GHz headphones. The transmitter features three audio inputs and a pilot microphone input. The pilot microphone input will override the other inputs when active. The unit is designed to integrate into any entertainment system with analog audio capability. This guide describes general configuration information for the Rosen Wireless Headphone Transmitter with any audio source equipment to supplement the Outline & Installation Drawing (P/N 0700-009-CD). Note: Only trained and qualified personnel should perform installation and service. 1.1. Unpacking The parts shipped with the 5.8 GHz Digital Wireless Transmitter include:  One 5.8 GHz digital audio transmitter (P/N 0700-009)  One connector kit (P/N 0300-043)  Transmitter Outline & Installation Drawing (P/N 0700-009-CD) The parts shipped with the 5.8 GHz Digital Wireless Headphones include:  One set of 5.8 GHz Digital Wireless Headphones (P/N 0500-100)  Two AA batteries (P/N BAT-AA)  One User’s Guide (P/N 102302) The Outline & Installation drawing is also available at www.rosenaviation.com. From the Rosen Aviation home page, select Support Drawings and Pinouts, and then look under A/V Distribution for the Wireless Transmitter. 2. CONNECTING THE TRANSMITTER The transmitter provides interfaces to connect three audio sources and the pilot microphone. Use the pinout descriptions on page 2 of the Outline & Installation drawing to assist in the wiring process. Pay close attention to the pinout information while completing wiring connections. Note: The wireless transmitter & headphones are for entertainment purposes only; connect the transmitter to the non-critical power bus. Rosen Aviation Digital Wireless Headphone System Document Number: 102115 Revision: B Date: TBD Template: 4.2.3-6-FM; Revision A; 16 May, 2005 Page 5 of 10 3. WIRELESS TRANMITTER CONNECTOR Table 1 Wireless Transmitter J1 Connector Pin # Signal Comment 1 28 Volts Power 2 Audio #1 Left Signal Input 3 Audio #1 Right Signal Input 4 Audio #2 Left Signal Input 5 Audio #2 Right Signal Input 6 Audio #3 Left Signal Input 7 Audio #3 Right Signal Input 8 Microphone Signal Input 9 PA Override Momentary or Constant Ground 10 28 Volt Return GND 11 Audio #1 Left Return Input 12 Audio #1 Right Return Input 13 Audio #2 Left Return Input 14 Audio #2 Right Return Input 15 Audio #3 Left Return Input 16 Audio #3 Right Return Input 17 Microphone Return Input 18 Reserved Reserved 19 Reserved Reserved 20 Reserved Reserved 21 Reserved Reserved 22 Reserved Reserved 23 Reserved Reserved 24 Reserved Reserved 25 Reserved Reserved 26 Reserved Reserved Rosen Aviation Digital Wireless Headphone System Document Number: 102115 Revision: B Date: TBD Template: 4.2.3-6-FM; Revision A; 16 May, 2005 Page 6 of 10 4. PLACING THE TRANSMITTER The wall-mounted transmitter must be mounted with the J1 connector pointing toward the ceiling of the aircraft cabin. It can be placed behind a bulkhead or other wall, as long as the bulkhead or wall is made of composite or wood material. Figure 1 Digital wireless headpho…

Text truncated - open the document above for the full version.

Request for Confidentiality PHOENIX TESTLAB GmbH Date: November 20, 2009 Product Certification Königswinkel 10 D 32825 Blomberg RE: Certification Application FCC ID: PMJTRO2 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rule, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: • Schematics • Block Diagram • Technical Description "Comments to Schematics" • Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure od this application and all accompanying documentation will not be made before the date of the GRANT for this application ́. Thank you for your attention in this matter. Applicant’s Company : TÜV SÜD SENTON GmbH address : Auessere Fruehlingstrasse 45, D-94315 Straubing Signature : Johann Roidt Job Title and Dept. : Technical Director

FCC ID PMJTRO2 FCC ID PMJTRO2 FCC ID PMJTRO2 FCC ID PMJTRO2 FCC ID PMJTRO2 FCC ID PMJTRO2

FCC ID PMJTRO FCC ID PMJTRO FCC ID PMJTRO FCC ID PMJTRO FCC ID PMJTRO FCC ID PMJTRO

Prüfbericht / Test Report Nr. / No. 69555-00838-1 (Edition 1) Applicant: Amphony (Deutschland) GmbH Type of equipment: Transmitter for Wireless Headphones Type designation: 5.8 GHz Digital Wireless Headphones-Transmitter Order No.: Test standards: FCC Code of Federal Regulations, CFR 47, Part 15, Sections 15.205, 15.207, 15.215 and 15.249 Industry Canada Radio Standards Specifications RSS-Gen Issue 2, Section 7.2.2 and RSS-210 Issue 7, Sections 2.2, A2.9 (Category I Equipment) November 10, 2009 TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69555-00838-1 (Edition 1) Page 2 of 57 Page(s) Table of Contents 1 Description of the Equipment Under Test (EUT)............................................................ 3 2 Administrative Data ........................................................................................................ 4 3 Identification of the Test Laboratory............................................................................... 5 4 Summary........................................................................................................................6 5 Operation Mode and Configuration of EUT .................................................................... 7 6 Measurement Procedures .............................................................................................. 8 6.1 Bandwidth Measurements ....................................................................................... 8 6.2 Radiated Emission Measurement 9 kHz to 30 MHz................................................. 9 6.3 Radiated Emission in Fully or Semi Anechoic Room ............................................. 11 6.4 Radiated Emission at Open Field Test Site ........................................................... 13 7 Photographs Taken During Testing.............................................................................. 15 8 Test Results ................................................................................................................. 20 8.1 Occupied Bandwidth .............................................................................................. 22 8.2 Bandwidth of the Emission..................................................................................... 26 8.3 Designation of Emissions....................................................................................... 28 8.4 Restricted Bands of Operation............................................................................... 29 8.5 Radiated Emission Measurement 9 kHz to 30 MHz.............................................. 31 8.6 Radiated Emission Measurement 30 MHz to 40 GHz........................................... 32 8.7 Exposure of Humans to RF Fields ......................................................................... 34 9 Referenced Regulations............................................................................................... 36 10 Revision History ........................................................................................................... 38 11 Charts taken during testing .......................................................................................... 39 TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69555-00838-1 (Edition 1) Page 3 of 57 Page(s) 1 Description of the Equipment Under Test (EUT) General data of EUT Type designation 1 : 5.8 GHz Digital Wireless Headphones-Transmitter Parts 2 : Serial number(s): 0001 Manufacturer: Amphony (Deutschland) GmbH Type of equipment: Transmitter for Wireless Headphones Version: As received FCC ID: Additional parts/accessories: Technical data of EUT Application frequency range: 5725 - 5875 MHz Frequency range: 5800 MHz Operating frequency: 5800 MHz Type of modulation: ASK Pulse train: Not applicable Pulse width: Not applicable Number of RF-channels: 1 Channel spacing: Not applicable Designation of emissions 3 : 47M0A9D Type of antenna: Integrated Size/length of antenna: 2.5 x 1.7 cm Connection of antenna: detachable not detachable Type of power supply: DC supply Specifications for power supply: nominal voltage: 28 V 1 Type designation of the system if EUT consists of more than one part. 2 Type designations of the parts of the system, if applicable. 3 Also known as "Class of Emission". TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69555-00838-1 (Edition 1) Page 4 of 57 Page(s) 2 Administrative Data Application details Applicant (full address): Amphony (Deutschland) GmbH Annenstraße 26 D-10179 Berlin Contact person: Mr. Jens Kurrat Order number: Receipt of EUT: October 19, 2009 Date(s) of test: October - November 2009 Note(s): Report details Report number: 69555-00838-1 Edition: 1 Issue date: November 10, 2009 TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69555-00838-1 (Edition 1) Page 5 of 57 Page(s) 3 Identification of the Test Laboratory Details of the Test Laboratory Company name: TÜV SÜD SENTON GmbH Address: Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Laboratory accreditation: DAR-Registration No. DAT-PL-171/94-03 FCC test site registration number 90926 Industry Canada test site registration: 3050A-1 Contact person: Mr. Johann Roidt Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69555-00838-1 (Edition 1) Page 6 of 57 Page(s) 4 Summary Summ…

Text truncated - open the document above for the full version.

Test Equipment List with Calibration Data Seite 1 von 2 Test report number(s): Date of test: 69555-00838-1 11/2009 Date of Calibration Type Inv.-No. Type Designation Serial Number Manufacturer Calibration Organization Last Next Test receiver 1028 ESHS10 860043/016 Rohde & Schwarz Rohde & Schwarz 02/2009 08/2010 EMI Test receiver 1569 ESMI 839379/013 Rohde & Schwarz Rohde & Schwarz 10/2009 01/2012 EMI test receiver 1711 ESPI7 836914/0002 Rohde & Schwarz Rohde & Schwarz 09/2009 03/2011 EMI test receiver 1863 ESCI 1166.5950K03 100008 Rohde & Schwarz Rohde & Schwarz 06/2008 12/2009 EMI test receiver 2010 ESPI7 101018 Rohde & Schwarz Rohde & Schwarz 11/2009 05/2011 Test receiver 2031 ESVP 891846/003 Rohde & Schwarz Rohde & Schwarz 10/2008 04/2010 Spectrum analyser 1666 FSP30 100063 Rohde & Schwarz Rohde & Schwarz 10/2007 01/2010 Preamplifier 1142 R14601 13120026 Advantest TÜV SÜD SENTON 04/2008 04/2010 Preamplifier 1484 ACO/180-3530 32641 CTT TÜV SÜD SENTON 05/2008 11/2009 Preamplifier 1651 CPA9231A 3393 Schaffner Electrotest TÜV SÜD SENTON 05/2008 11/2009 Preamplifier 1684 AFS3-00100800-32-LN 847743 MITEQ TÜV SÜD SENTON 05/2008 11/2009 V-network 1059 ESH3-Z5 894785/005 Rohde & Schwarz Rohde & Schwarz 05/2009 05/2012 V-network 1060 ESH3-Z5 862770/021 Rohde & Schwarz Rohde & Schwarz 01/2007 01/2010 V-network 1218 ESH3-Z5 830952/025 Rohde & Schwarz Rohde & Schwarz 07/2008 07/2011 Loop antenna 1016 HFH2-Z2 882964/0001 Rohde & Schwarz Rohde & Schwarz 09/2009 03/2011 Double ridged waveguide horn antenna 1516 3115 9508-4553 EMCO Elektronik ARC 05/2008 05/2011 Biconical Antenna 1518 HK116 842204/01 Rohde & Schwarz Rohde & Schwarz 06/2008 12/2009 Logarithmic-periodic antenna 1519 HL223 841516/23 Rohde & Schwarz Rohde & Schwarz 06/2008 12/2009 TRILOG broadband antenna 1722 VULB 9163 9163-188 Schwarzbeck Schwarzbeck 04/2008 0 1 /2010 Note 1: Date of next calibration contains maximum tolerance if applicable. Note 2: According to manufacturer's specifications no calibration is required but mechanical check only. This check is perform ed before every test sequence. Test Equipment List with Calibration Data Seite 2 von 2 Test report number(s): Date of test: 69555-00838-1 11/2009 Date of Calibration Type Inv.-No. Type Designation Serial Number Manufacturer Calibration Organization Last Next Multimeter 1653 21 III 76530546 Fluke ZMK 05/2008 02/2011 Multimeter 1654 21 III 76381229 Fluke ZMK 03/2008 12/2010 Multimeter 1975 Fluke 77 III 92370108 Fluke ZMK 09/2008 06/2011 Multimeter 1976 Fluke 77 IV 93090238 Fluke ZMK 09/2008 06/2011 Digital multimeter 2025 Fluke 177 96720024 Fluke ZMK 09/2008 06/2011 Digital multimeter 2026 Fluke 177 96720025 Fluke ZMK 09/2008 06/2011 External mixer 1576 WM782A 845881/005 Tektronix Rohde & Schwarz 09/2009 09/2012 Harmonic mixer 1577 FS-Z30 843389/007 Rohde & Schwarz Rohde & Schwarz 09/2009 09/2012 Horn antenna 3160-03 9112-1003 EMCO Elektronik Note 2 Horn antenna 3160-04 9112-1001 EMCO Elektronik Note 2 Horn antenna 1012 3160-05 9112-1001 EMCO Elektronik Note 2 Horn antenna 1013 3160-06 9112-1001 EMCO Elektronik Note 2 Horn antenna 1014 3160-07 9112-1008 EMCO Elektronik Note 2 Horn antenna 3160-08 9112-1002 EMCO Elektronik Note 2 Horn antenna 3160-09 9403-1025 EMCO Elektronik Note 2 Horn antenna 3160-10 399185 EMCO Elektronik Note 2 Note 1: Date of next calibration contains maximum tolerance if applicable. Note 2: According to manufacturer's specifications no calibration is required but mechanical check only. This check is perform ed before every test sequence.

TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69555-00838-1 (Edition 1) Page 16 of 57 Page(s) Test setup for radiated emission measurement 9 kHz – 30 MHz TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69555-00838-1 (Edition 1) Page 17 of 57 Page(s) Test setup for radiated emission measurement (fully anechoic room) TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69555-00838-1 (Edition 1) Page 18 of 57 Page(s) Test setup for radiated emission measurement (open field test site) TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69555-00838-1 (Edition 1) Page 19 of 57 Page(s) Test setup for radiated emission measurement (open field test site) - continued -
