PN2-BZT1Hallie Sensor (for Breztri Aerosphere) is a device to log medication use of a metered dose inhaler

Product Manual For use only with Breztri Aerosphere ™       Intended Use The Breztri+ ™ sensor is intended for single patient use in the home environment as an electronic data capture accessory for recording actuations of prescribed Inhaler medication. This may be used in the following applications: •In self-management, where patients need to track their medication use as part of their management plan. •In clinical practice, where specialists, general practitioners, nurses, and educators need to know if a patient has actuated their prescribed Inhaler medication. •In clinical trials, where researchers need to know when a patient has actuated their trial Inhaler medication. The Breztri+ ™ sensor is compatible only with Breztri Aerosphere ™ Inhaler. The Breztri+ ™ sensor is not intended to indicate remaining quantity of medication in an Inhaler and does not include a dose counting function. Important User Information Warnings identify actions or situations that could lead to personal injury. Take note of all warnings before using the Breztri+ ™ sensor. Precautions identify actions or situations that could damage the Breztri+ ™ sensor or other equipment, or affect the accuracy or availability of recorded actuation data. Notes contain advisory information about some aspect of the Breztri+ ™ sensor or its use. Warnings and Precautions To ensure your Inhaler functions correctly, do not use the Breztri+ ™ sensor with any other Inhaler or medication than that indicated on the Breztri+ ™ sensor label. Refer to the labelling provided with the Inhaler for instructions on use. Carry out all steps required to use your Inhaler according to the instructions. The Breztri+ ™ sensor is intended to track medication usage. It is not intended to diagnose your condition or to replace the diagnosis of a licensed physician. The Breztri+ ™ sensor does not contain a dose counter. Do not use data collected by the Breztri+ ™ sensor to determine the number of doses remaining in a medication canister. This manual does not provide information on how to use prescription medication, and is not intended to replace the advice provided by a health professional. Directions for using prescription medication should be obtained from a health professional and followed accordingly. Any questions related to prescription medication should be referred to a health professional. If your prescribed Inhaler changes, do not use it with this Breztri+ ™ sensor. Only use a Breztri+ ™ sensor that is labeled as compatible with your prescribed Inhaler. The Breztri+ ™ sensor is a battery- powered electronic device. Do not immerse the Breztri+ ™ sensor in water. Do not use the Breztri+ ™ sensor if it is not in good condition. Take care to not spill liquids on the Breztri+ ™ sensor or immerse it in water. Do not expose the Breztri+ ™ sensor to excessive perspiration during exercise. For hygiene and data integrity reasons, do not use the Breztri+ ™ sensor with more than one patient. Remove the Breztri+ ™ sensor from the Inhaler before cleaning the Inhaler. What is the Breztri+ ™ Sensor? The Breztri+ ™ sensor is a companion tool that tracks your prescribed medication use. The Breztri+ ™ sensor is a small battery- powered electronic data logger that attaches to an Inhaler. The Breztri+ ™ sensor contains an electronic clock and calendar that is used to log the date and time of Inhaler actuation. Usage data can be uploaded via a wireless Bluetooth ® connection. Keep the Breztri+ ™ sensor outside MRI scanner rooms. Breztri+ ™ Sensor Components       1.Door Latch 2.Light Emitting Diode (LED) 3.Status Button for pairing, battery check and manual upload Compatible Inhalers The Breztri+ ™ sensor is designed to work only with the Breztri Aerosphere ™ Inhaler as indicated on the Breztri+ ™ sensor label. The Breztri+ ™ sensor intended population is identical to the intended population of the compatible Inhaler. Preparation for First Use Setting Up Bluetooth ® Communications The Breztri+ ™ sensor must be paired with a compatible Bluetooth ® phone or tablet computer in order to sync stored usage data. Download a compatible mobile app to communicate with your sensor. Ensure Bluetooth ® is enabled on your phone or tablet computer. Open the compatible mobile app and follow the prompts to initiate the pairing process.       Hold the Breztri+ ™ sensor in an upright position.       Press and hold the Status Button for 1 second.       The Breztri+ ™ sensor will wake up and the LED will flash green.       After 5 seconds the Breztri+ ™ sensor will automatically enter Bluetooth ® pairing mode and the LED will flash blue for 60 seconds.  Follow the pairing prompts on the mobile app to complete pairing. If the LED is not flashing blue following wake up or the time limit is reached, press the Status Button 3 times to enter pairing mode again. The LED will flash blue when the Breztri+ ™ sensor is in pairing mode. The LED will flash green to indicate successful pairing. If pairing is not successful within 60 seconds the LED will flash red. The pairing process can be repeated if necessary. The Breztri+ ™ sensor can only be paired with a single phone or tablet computer at one time. Successful pairing with a new phone or tablet computer will remove the current pairing. If pairing on the new phone or tablet computer fails, the existing pairing will be retained. Installing and Removing an Inhaler Installation     To install the Inhaler hold the Breztri+ ™ sensor in an upright position.     Open the door of the Breztri+ ™ sensor by pulling the Door Latch.     Push the Inhaler into the Breztri+ ™ sensor.     Close the door so it clicks into place. Removal 1.To remove the Inhaler hold the Breztri+ ™ sensor in an upright position. 2.Pull the Door Latch to open the door of the Breztri+ ™ sensor. 3. Pull the Inhaler to remove it from the Breztri+ ™ sensor. 4. Close the door so it clicks into place. Delivering a Dose of Medication Ref…

Text truncated - open the document above for the full version.

Adherium (NZ) Limited Level 11, 16 Kingston Street, Auckland 1010, New Zealand PO Box 106-612, Auckland 1143, New Zealand Phone +64 9 307 2771 [email protected] www.adherium.com 15 July 2020 AUTHORITY TO ACT AS AGENT TO THE FEDERAL COMMUNICATIONS COMMISSION I appoint Robert Middleton of EMC Technologies Pty Ltd to act as agent in the preparation of this application for equipment authorization, on our behalf to the Federal Communications Commission. I certify that the exhibits submitted properly describe the device or system for which equipment authorization is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Commission's regulations, will have affixed to it a label identical to that submitted for approval with this application. Regards Chris Mander Head of Regulatory & Quality Adherium (NZ) Ltd Auckland, New Zealand

Adherium (NZ) Limited Level 11, 16 Kingston Street, Auckland 1010, New Zealand PO Box 106-612, Auckland 1143, New Zealand Phone +64 9 307 2771 [email protected] www.adherium.com 15 July 2020 Federal Communications Commission ‐ Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: PN2‐BZT1 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below and to withhold this information from public disclosure indefinitely: Exhibit Type File Name Operational Description PN2‐BZT1_Operational Description Block Diagram PN2‐BZT1_Block Diagram Schematics PN2‐BZT1_Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Pursuant to DA04‐1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name External Photos PN2‐BZT1_External Photos Test Setup Photos PN2‐BZT1_Test Setup Photos Internal Photos PN2‐BZT1_Internal Photos User Manual PN2‐BZT1_User Manual As the above information contains proprietary information which would be benefit to our competitors, we request that these exhibits be held from public view for 180 days from the issue date of the Grant for this application. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Chris Mander Head of Regulatory & Quality Adherium (NZ) Ltd

Page 1 of 6 EMC Technologies Pty. Ltd. ABN 82 057 105 549 Melbourne 176 Harrick Road Keilor Park, Vic 3042 Tel: +61 3 9365 1000 Sydney Unit 3/87 Station Road Seven Hills, NSW 2147 Tel: +61 2 9624 2777 Email: [email protected] Web: www.emctech.com.au Melbourne 176 Harrick Road Keilor Park, Vic 3042 Tel: +61 3 9365 1000 Sydney Unit 3/87 Station Road Seven Hills NSW 2147 Tel: +61 2 9624 2777 Auckland (NZ) 47 MacKelvie Street Grey Lynn Auckland Tel: +64 9 360 0862 APPENDIX B OF TEST REPORT S190733-2 IDENTIFICATION PHOTOGRAPHS OF TEST SAMPLE (EXTERNAL) FCC ID: PN2-BZT1 Manufacturer: Adherium (NZ) Ltd Test Sample: Hallie Sensor (for Breztri Aerosphere) Model Number: NF0103 Serial Numbers: 000001, 000002, 000003 and 000005 Date: 8 th July 2020 FCC ID: PN2-BZT1 Report No. S190733-2 Appendix B – External Identification Photographs Page 2 of 6 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX B1 EXTERNAL IDENTIFICATION PHOTOGRAPHS FCC ID: PN2-BZT1 Report No. S190733-2 Appendix B – External Identification Photographs Page 3 of 6 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX B2 EXTERNAL IDENTIFICATION PHOTOGRAPHS FCC ID: PN2-BZT1 Report No. S190733-2 Appendix B – External Identification Photographs Page 4 of 6 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX B3 EXTERNAL IDENTIFICATION PHOTOGRAPHS FCC ID: PN2-BZT1 Report No. S190733-2 Appendix B – External Identification Photographs Page 5 of 6 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX B4 EXTERNAL IDENTIFICATION PHOTOGRAPHS FCC ID: PN2-BZT1 Report No. S190733-2 Appendix B – External Identification Photographs Page 6 of 6 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX B5 EXTERNAL IDENTIFICATION PHOTOGRAPHS

NF0103 Hailie™ / Breztri+™ Sensor FCC ID: PN2‐BZT1 Label Details Label materials are polycarbonate and polyethylene affixed to device with permanent adhesive.

Page 1 of 15 EMC Technologies Pty. Ltd. ABN 82 057 105 549 Melbourne 176 Harrick Road Keilor Park, Vic 3042 Tel: +61 3 9365 1000 Sydney Unit 3/87 Station Road Seven Hills, NSW 2147 Tel: +61 2 9624 2777 Email: [email protected] Web: www.emctech.com.au Melbourne 176 Harrick Road Keilor Park, Vic 3042 Tel: +61 3 9365 1000 Sydney Unit 3/87 Station Road Seven Hills NSW 2147 Tel: +61 2 9624 2777 Auckland (NZ) 47 MacKelvie Street Grey Lynn Auckland Tel: +64 9 360 0862 APPENDIX C OF TEST REPORT S190733-2 IDENTIFICATION PHOTOGRAPHS OF TEST SAMPLE (INTERNAL) FCC ID: PN2-BZT1 Manufacturer: Adherium (NZ) Ltd Test Sample: Hallie Sensor (for Breztri Aerosphere) Model Number: NF0103 Serial Number: 000001, 000002, 000003 and 000005 Date: 8 th July 2020 FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 2 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C1 INTERNAL IDENTIFICATION PHOTOGRAPHS EUT FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 3 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C2 INTERNAL IDENTIFICATION PHOTOGRAPHS EUT FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 4 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C3 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 5 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C4 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 6 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C5 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 7 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C6 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 8 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C7 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 9 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C8 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 10 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C9 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 11 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C10 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 12 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C11 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 13 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C12 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 14 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C13 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB FCC ID: PN2-BZT1 Report No. S190733-2 Appendix C – Internal Identification Photographs Page 15 of 15 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 APPENDIX C14 INTERNAL IDENTIFICATION PHOTOGRAPHS PCB

Page 1 of 48 EMC Technologies Pty. Ltd. ABN 82 057 105 549 Melbourne 176 Harrick Road Keilor Park, Vic 3042 Tel: +61 3 9365 1000 Sydney Unit 3/87 Station Road Seven Hills, NSW 2147 Tel: +61 2 9624 2777 Email: [email protected] Web: www.emctech.com.au Accredited for compliance with ISO/IEC 17025. The results of the test, calibrations and/or measurement included in this document are traceable to Australian/national standards. NATA is a signatory to the ILAC Mutual Recognition Arrangement for the mutual recognition of the equivalence of testing, calibration and inspection reports. Except for the certificate of page 4 this document may only be reproduced in full. RADIO REPORT FOR CERTIFICATION to 47 CFR Part 15 Subpart C (Section 15.247) Test Report Number: S190733-2 v3 FCC ID: PN2-BZT1 Report Number: S190733-2 v3 Tested For: Adherium (NZ) Ltd Device under Test : Hailie Sensor (for Breztri Aersphere) Model Number : NF0103 Serial Numbers: 000001, 000002, 000003 and 000005 Issue Date: 16 th July 2020 EMC Technologies Pty Ltd reports apply only to the specific samples tested under stated test conditions. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. EMC Technologies Pty Ltd shall have no liability for any deductions, inferences or generalisations drawn by the client or others from EMC Technologies Pty Ltd issued reports. This report shall not be used to claim, constitute or imply product endorsement by EMC Technologies Pty Ltd. FCC ID: PN2-BZT1 EMC Technologies Pty Ltd Report No. S190733-2 v3 Page 2 of 48 This document must not be copied or reproduced, except in full, with the exception of the Certificate of Compliance on Page 4 www.emctech.com.au 5292 REVISION TABLE Version Sec/Para Changed Change Made Date 1 Initial issue of document 26/09/2019 2 All Inclusion of FCC ID: PN2-BZT1 08/07/2020 1.1 KDB Reference version updated 2.5 Equipment Table updated Page 4 Update address 3 3 Updated Contents Page 16/07/2020 All Amend to version 3 and update of Issue Date of Report 16/07/2020 FCC ID: PN2-BZT1 EMC Technologies Pty Ltd Report No. S190733-2 v3 Page 3 of 48 This document must not be copied or reproduced, except in full, with the exception of the Certificate of Compliance on Page 4 www.emctech.com.au 5292 RADIO REPORT FOR CERTIFICATION 47 CFR Part 15 Subpart C (Section 15.247) CONTENTS 1.0 INTRODUCTION 2.0 GENERAL INFORMATION 3.0 TEST RESULTS 3.1 §15.203 Antenna Requirement 3.2 §15.204 Antenna Information 3.3 §15.207 Disturbance Voltage on AC Mains 3.4 §15.247(a)(2) 6 dB Bandwidth 3.5 §15.247(e) 3kHz Peak Power Density 3.6 §15.247(b) Peak Output Power 3.7 §15.247(d) Restricted Bands of Operation 3.8 §15.247(d) Spurious Radiated Emission 3.9 §15.247(d) Out of Band Emissions 3.10 §15.247(i) Maximum Permissible Exposure 3.11 §2.1049 99% Occupied Bandwidth 4.0 COMPLIANCE STATEMENT 5.0 MEASUREMENT UNCERTAINTY APPENDIX A TEST SETUP PHOTOGRAPHS APPENDIX B EXTERNAL IDENTIFICATION PHOTOGRAPHS APPENDIX C INTERNAL IDENTIFICATION PHOTOGRAPHS FCC ID: PN2-BZT1 EMC Technologies Pty Ltd Report No. S190733-2 v3 Page 4 of 48 This document must not be copied or reproduced, except in full, with the exception of the Certificate of Compliance on Page 4 www.emctech.com.au 5292 RADIO REPORT FOR CERTIFICATION Issued by: EMC Technologies Pty. Ltd., Unit 3, 87 Station Road, Seven Hills, NSW, 2147, Australia. Phone: +61 2 9624 2777 E-mail: [email protected] Web: www.emctech.com.au Test Report No: S190733-2 v3 Product : Hailie Sensor (for Breztri Aerosphere) Model Number: NF0103 Serial Numbers: 000001, 000002, 000003 and 000005 Manufacturer: Adherium (NZ) Ltd Tested for: Adherium (NZ) Ltd Address: Level 11, 16 Kingston Street, Auckland, 1010, New Zealand Phone: +64 9 307 2771 Contact: Mr Chris Mander FCC ID: PN2-BZT1 Standards: 47 CFR Part 15 – Radio Frequency Devices Subpart C – Intentional Radiators Section 15.247 – Operation within the bands 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz Test Dates: 15 th August 2019 to 12 th September 2019 Issue Date: 16 th July 2020 Attestation: I hereby certify that the device(s) described herein were tested as described in this report and that the data included is that which was obtained during such testing. Test Engineer: Dong Feng Quinn Wu Authorised Signatory: Robert Middleton Sydney Branch Manager EMC Technologies Pty Ltd. FCC ID: PN2-BZT1 EMC Technologies Pty Ltd Report No. S190733-2 v3 Page 5 of 48 This document must not be copied or reproduced, except in full, with the exception of the Certificate of Compliance on Page 4 www.emctech.com.au 5292 RADIO REPORT FOR CERTIFICATION to 47 CFR Part 15 Subpart C (section 15.247) 1.0 INTRODUCTION Radio tests were performed on Hailie Sensor (for Breztri Aerosphere) with Model Number: NF0103, in accordance with the applicable requirements of 47 CFR, Part 15 Subpart C – Section 15.247 operating within the band: 2400 MHz to 2483.5 MHz. 1.1 Test Procedure Radio measurements were performed in accordance with the appropriate procedures of ANSI C63.10: 2013 and KDB 558074 v05r02 - Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247. The measurement instrumentation conformed to the requirements of ANSI C63.2: 2016. 1.2 Summary of 47 CFR Part 15 Subpart C Results FCC Part 15 Subpart C Test Performed Results 15.203 Antenna requirement Complied 15.204 Antenna information Complied 15.205 Restricted bands of operation Complied 15.207 Disturbance voltage on AC Mains Not Applicable EUT is DC powered 15.247(c) Spurious radiated emission 15.209 limit applied Complied 15.247 (a2) 6 dB Bandwidth Complied 15.247 (e) 3 kHz Peak Power Density Complied 15.247 (b) Peak Output Power Complied 15.247 (c) Antenna Gain > 6 dBi Not Applicable 15.247 (d) Out of Band Emissions Complied 15.247 (f) Hybrid Systems Not Applicable 15.247 (i) 99% Occupied bandwidth Complied 1.3 Modi…
