PNZ4XXRemote Control Transmitter

4 DISCLAIMER The information contained here is considered accurate. However, Xilor makes no warranty or guarantee whether expressed or implied regarding the accuracy of the data, the results to be obtained from the use thereof, or that any such use will not infringe upon a patent. User shall determine the suitability of the product for the intended application and assume all risk and liability whatsoever in connection therewith. Under no circumstances shall Xilor be liable for incidental, consequential or other damages arising out of the use or handling of this product or the failure of the device to operate in a specific application. Xilor Inc make no representation, guarantee, or warranty regarding the suitability of use. Our wireless control devices should not be used in applications where safety risks or possible loss of life may occur. The sole liability of Xilor for any claims arising out of the manufacture, use or sale of its products shall be to refund the buyer’s purchase price provided such products have been demonstrated, in Xilor’s sole opinion to justify such refund. © Xilor ™ Inc. 1400 Liberty Street Knoxville, TN 37909 www.rfmicrolink.com www.xilor.com Tel: (865) 546-9863 Fax: (865) 546-8324 1 μLink ® seriesseries rev.8/01 ® Xilor ™ Inc. Wireless Keyfob Transmitter 2 OVERVIEW μLink ® series remote control is designed for industrial, home, or automotive applications. The series include 2, 4 and 8 channel units.They have been precertified for FCC Part 15 compliance and are available in 418MHz or 433MHz with the former being our standard. The remote is powered with a 3V lithium cell battery and its typical transmission range is 100 feet. Signals can be decoded using our decoder IC’s or our RF receiver subassemblies. CODE SYSTEM A unique sequential serial number is factory programmed during manufacturing and therefore there is no need to manually set each transmitter address. CHANNEL ASSIGNMENT *Numbers are for document labeling purposes only. They do not come on stock units. CONTENTION ISSUES Only one transmitter at a time of a certain carrier frequency can be operated without contention. Two signals of the same frequency can not share the same carrier within the operating range of the other. This results in signal “jamming” . BATTERY Battery is already factory installed. To replace battery use CR2032 Lithium cell for remote units. Observe polarity when replacing bat- tery. Battery cell holder has a plus on it indicating which way to install battery. To remove battery use non-metallic object to push battery out of cell holder . 2 3 FCC INFO. FCC ID:PNZ4XX This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference that may cause unde- sired operation. _____________________________________________________ This equipment has been tested and found to comply with the limits for a Class-B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televi- sion reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) Reorient or relocate the receiving antenna 2) Increase the separation between the equipment and receiver. 3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4) Consult the dealer or an experienced radio/TV technician for help. _____________________________________________________ This equipment has been certified to comply with the limits for a Class-B computing device, pursuant to FCC Rules. In order to main- tain compliance with FCC regulation s, shielded cables must be used with this equipment. Operation with non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. Changes and modifications by the user to the equipment without the approval of the manufacture could void the users authority to oper- ate this equipment.

50Ω Planar Antenna System Matching Network Low Pass Filter Encoder Buttons SAW Stabilized RF Oscillator Block Diagram. Same for 418MHz and 433MHz units

FCC ID: PNZ4XX 0.26" 6.6mm 0.80" 20.3mm Metalized sticker-FCC ID label sample. Due to limited space full FCC statement is located in user's manual.

2.33" 59.2mm 1.75" 44.3mm μLink ® FCC ID: PNZ4XX 0.26" 6.6mm 0.80" 20.3mm FCC Label Location Notes: 1) Due to limited space full FCC statement is located in user's manual. 2) Label is for 418MHz and 433.9MHz Models.

DESCRIPTION /OVERVIEW μLink ® series RF remote control is designed for industrial, home, or automotive control applications. The series include 2, 4 and 8 channel enclosures for the same circuit board. These units have been pre-certified for FCC Part 15 compliance and are available in 418MHz or 433MHz with the former being our standard. The remote is powered with a 3V lithium cell battery and its typical transmission range is 100 feet. Signals can be decoded using our decoder IC’s or our RF receiver subassemblies. CODE SYSTEM A unique sequential serial number is factory programmed during manufacturing and therefore there is no need to manually set each transmitter address removing the need to dip switch blocks, or code trace cut areas which take up valuable circuit board space. CONTENTION ISSUES Only one transmitter at a time of a certain carrier frequency can be operated without contention. Two signals of the same frequency can not share the same carrier within the operating range of the other. This results in signal “jamming” . BATTERY Battery is already factory installed. To replace battery use CR2032 Lithium cell for remote units. Observe polarity when replacing battery. Battery cell holder has a plus on it indicating which way to install battery. To remove battery use non-metallic object to push

1234 A B C D 4321 D C B A 1 Xilor Inc 1400 Liberty St Knoxville TN 37909 1 Remote Control Keyfob Schematic Title Size:Number: Date: Revision: Sheetof A Feb. 2 1998 uLink(tm) Series Remote Control All Rights Reserved COPYRIGHT XILOR INC DATA 19 BC 20 SCAN 1 NC 2 CH3 7 CH4 8 CH5 9 CH6 10 CH7 11 CH8 12 CH1 13 CH2 14 SCAN 4 OSC 18 GND 3 NC 17 U1 E1548AR 1 3 2 4 SW1 SWSO 1 3 2 4 SW2 SWSO 1 3 2 4 SW3 SWSO 1 3 2 4 SW4 SWSO 1 3 2 4 SW5 SWSO 1 3 2 4 SW6 SWSO 1 3 2 4 SW7 SWSO 1 3 2 4 SW8 SWSO 12 GND50 OHM RF IN ANT1 PLANAR SPIRAL ANTENNA Q2 1 2 34 RES1 SAW RESONATOR C5 C7 C6 C2 8.2pF R3 5.11K R4 18K R5 150 C1 8.2pF C4 0.1uF C8 22pF L1 L2 GNDGND GND GND GND VCC VCC R1 47 C3 10000pF GND GND VCC GND R6 10K R2 68K VCC GND GND 2 1 B1 CR2032 3V Battery GND VCC C9 1000pF Model RFTXX-B-418 1234 A B C D 4321 D C B A 1 Xilor Inc 1400 Liberty St Knoxville TN 37909 1 Remote Control Keyfob Schematic Title Size:Number: Date: Revision: Sheetof A Feb. 2 1998 uLink(tm) Series Remote Control All Rights Reserved COPYRIGHT XILOR INC DATA 19 BC 20 SCAN 1 NC 2 CH3 7 CH4 8 CH5 9 CH6 10 CH7 11 CH8 12 CH1 13 CH2 14 SCAN 4 OSC 18 GND 3 NC 17 U1 E1548AR 1 3 2 4 SW1 SWSO 1 3 2 4 SW2 SWSO 1 3 2 4 SW3 SWSO 1 3 2 4 SW4 SWSO 1 3 2 4 SW5 SWSO 1 3 2 4 SW6 SWSO 1 3 2 4 SW7 SWSO 1 3 2 4 SW8 SWSO 12 GND50 OHM RF IN ANT1 PLANAR SPIRAL ANTENNA Q2 1 2 34 RES1 SAW RESONATOR C5 C7 C6 C2 8.2pF R3 5.11K R4 18K R5 150 C1 8.2pF C4 0.1uF C8 22pF L1 L2 GNDGND GND GND GND VCC VCC R1 47 C3 10000pF GND GND VCC GND R6 10K R2 68K VCC GND GND 2 1 B1 CR2032 3V Battery GND VCC C9 1000pF Model RFTXX-B-433

FCC PART 15, SUBPART C TEST METHOD: ANSI C63.4-1992 TEST REPORT for KEYFOB TRANSMITTERS P/N(s): RFTXX-B-418 and RFTXX-B-433 OEM Manufacture: Xilor Inc 1400 Liberty St. Knoxville, TN 37909 (865) 546-9863 DATE: 8-24-2001 Table of Contents: Page Purpose and Report Summary3 Test Equipment settings and measurements 418MHz device flat4 418MHz device end 5 418MHz device side 6 433.9MHz device flat7 433.9MHz device end8 433.9MHz device side9 418MHz correction factors10 418MHz scope photo of pulse widths11 418MHz occupied bandwidth plot12 433.9MHz correction factors13 433.9MHz scope photo of pulse widths 14 433.9MHz occupied bandwidth plot15 Encoder Data Format16 Test Equipment/Antenna/Calibration List17 REPORT SUMMARY This is an electromagnetic emission test report. The test report is based on testing performed by Philips Testing Lab. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test are within the specification limits defined by CFR Title 47, Part 15, Subpart C, sections 15.205, 15.209, and 15.231(a) (1). Test Lab: Philips Testing 3029 Gov. John Sevier Hwy. Knoxville TN 37914 FCC Reg.# 90875 (exp. 1/28/03) NVLAP# 200409-0 exp. (6/30/02) (DBA Philips Consumer Electronics) Device(s) Tested: Keyfob Transmitters P/N(s): RFTXX-B-418 (418MHz unit), RFTXX-B-433 (433.9MHz unit) Modifications: The EUT was not modified during the testing. Manufacturer: Xilor Inc 1400 Liberty St. Knoxville TN 37909 Test Date: 6-27-2001 Test Specifications: EMI requirements CFR Title 47, Part 15 Subpart C, Sections 15.205, 15.209, and 15.231 Test Procedure: ANSI C63.4: 1992 Test Deviation: The test procedure was not deviated from during testing. SUMMARY OF TEST RESULTS Conducted RF Emissions This test was not performed because the EUT runs off a 3-volt lithium coin cell only and cannot be powered by any device that runs off of the AC public mains. Radiated RF Emissions Complies with the limits of CFR Title 47, Part 15, Subpart C, sections 15.205, 15.209, and 15.231 (a) (1) END OF SUMMARY Radiated Emissions FCC Section 15.205 and 15.231 (a) (1) Report # 11782-2 Test Distance 3 meters Date 6/27/01 Test Conditions Unit Flat EUT Remote Control Transmitter (DSC) Model 418 MHz Transmitter Mfg. Xilor FCC ID PNZ4XX Frequency (MHz) Horiz dBuV Vert dBuV Antenna Factor dBuV Duty Cycle Correction factor Horiz dBuV Vert dBuV Limit dBuV Horiz dBuV Vert dBuV 41860.244.920.9-7.4373.6758.3780.3-6.63-21.93 8362516.528-7.4345.5737.0760.3-14.73-23.23 125412.116.132.8-7.4337.4741.4760.3-22.83-18.83 1672 10.6 11.7 36.6 -7.43 39.77 40.87 54.0 -14.23 -13.13 Test Equipment Setup/Comments RBW & VBW= 100 kHz (30 - 1000 MHz) RBW & VBW= 1MHz (1 - 5 GHz) MEASUREMENTS WERE TAKEN FROM 30 MHz UP TO THE 10TH HARMONIC The above reading are Peak readings with the duty cycle correction factor applied. 5 Radiated Emissions FCC Section 15.205 and 15.231 (a) (1) Report # 11782-2 Test Distance 3 meters Date 6/27/01 Test Conditions Unit on End EUT Remote Control Transmitter (DSC) Model 418 MHz Transmitter Mfg. Xilor FCC ID PNZ4XX Frequency (MHz) Horiz dBuV Vert dBuV Antenna Factor dBuV Duty Cycle Correction factor Horiz dBuV Vert dBuV Limit dBuV Horiz dBuV Vert dBuV 41851.25920.9-7.4364.6772.4780.3-15.63-7.83 83621.522.328-7.4342.0742.8760.3-18.23-17.43 125414.315.932.8-7.4339.6741.2760.3-20.63-19.03 1672 10.3 7.7 36.6 -7.43 39.47 36.87 54.0 -14.53 -17.13 Test Equipment Setup/Comments RBW & VBW= 100 kHz (30 - 1000 MHz) RBW & VBW= 1MHz (1 - 5 GHz) MEASUREMENTS WERE TAKEN FROM 30 MHz UP TO THE 10TH HARMONIC The above reading are Peak readings with the duty cycle correction factor applied. 6 Radiated Emissions FCC Section 15.205 and 15.231 (a) (1) Report # 11782-2 Test Distance 3 meters Date 6/27/01 Test Conditions Unit on Side EUT Remote Control Transmitter (DSC) Model 418 MHz Transmitter Mfg. Xilor FCC ID PNZ4XX Frequency (MHz) Horiz dBuV Vert dBuV Antenna Factor dBuV Duty Cycle Correction factor Horiz dBuV Vert dBuV Limit dBuV Horiz dBuV Vert dBuV 41859.149.520.9-7.4372.5762.9780.3-7.73-17.33 83620.724.428-7.4341.2744.9760.3-19.03-15.33 125414.312.232.8-7.4339.6737.5760.3-20.63-22.73 1672 12.1 11.7 36.6 -7.43 41.27 40.87 54.0 -12.73 -13.13 Test Equipment Setup/Comments RBW & VBW= 100 kHz (30 - 1000 MHz) RBW & VBW= 1MHz (1 - 5 GHz) MEASUREMENTS WERE TAKEN FROM 30 MHz UP TO THE 10TH HARMONIC The above reading are Peak readings with the duty cycle correction factor applied. 7 Radiated Emissions FCC Section 15.205 and 15.231 (a) (1) Report # 11782-2 Test Distance 3 meters Date 6/27/01 Test Conditions Unit Flat EUT Remote Control Transmitter (DSC) Model 433.9 MHz Transmitter Mfg. Xilor FCC ID PNZ4XX Frequency (MHz) Horiz dBuV Vert dBuV Antenna Factor dBuV Duty Cycle Correction factor Horiz dBuV Vert dBuV Limit dBuV Horiz dBuV Vert dBuV 433.959.146.721.3-6.0574.3561.9580.83-6.48-18.88 867.821.312.928.6-6.0543.8535.4560.83-16.98-25.38 1301.7 8.9 0 33.6 -6.05 36.45 27.55 54.0 -17.55 -26.45 1735.6 24 22.1 37.4 -6.05 55.35 53.45 60.83 -5.48 -7.38 Test Equipment Setup/Comments RBW & VBW= 100 kHz (30 - 1000 MHz) RBW & VBW= 1MHz (1 - 5 GHz) MEASUREMENTS WERE TAKEN FROM 30 MHz UP TO THE 10TH HARMONIC The above reading are Peak readings with the duty cycle correction factor applied. 8 Radiated Emissions FCC Section 15.205 and 15.231 (a) (1) Report # 11782-2 Test Distance 3 meters Date 6/27/01 Test Conditions Unit on End EUT Remote Control Transmitter (DSC) Model 433.9 MHz Transmitter Mfg. Xilor FCC ID PNZ4XX Frequency (MHz) Horiz dBuV Vert dBuV Antenna Factor dBuV Duty Cycle Correction factor Horiz dBuV Vert dBuV Limit dBuV Horiz dBuV Vert dBuV 433.949.258.8521.3-6.0564.4574.180.83-16.38-6.73 867.818.12028.6-6.0540.6542.5560.83-20.18-18.28 1301.7 8.7 9.2 33.6 -6.05 36.25 36.75 54.0 -17.75 -17.25 1735.616.515.237.4-6.0547.8546.5560.83-12.98-14.28 Test Equipment Setup/Comments RBW & VBW= 100 kHz (30 - 1000 MHz) RBW & VBW= 1MHz (1 - 5 GHz) MEASUREMENTS WERE TAKEN FROM 30 MHz UP TO THE 10TH HARMONIC The above reading a…

Text truncated - open the document above for the full version.

Table of Contents: Click Thumbnail for larger image OATS setup.........................Page 2 OATS device on table............Page 3 Pre-Scan setup ....................Page 4 Pre-Scan device on table .......Page 5 Occupied Bandwidth .............Page 6 notes: Pictures are same for both 418MHz and 433.9MHz devices
