POD-ANA2Analog Transceiver

TYT ELECTRONICS CO., LTD

Click to zoom

Application Details

Equipment Class: TNF - Licensed Non-Broadcast Transmitter Held to Face
Date of Grant: Dec 28, 2020
Application Purpose: Original Equipment
Date of Application: Dec 28, 2020
Equipment Note: Analog Transceiver
Frequency Range: 406.10000000 - 470.00000000
Company: TYT ELECTRONICS CO., LTD
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Do not use the radio with a damaged antenna. Use only the supplied or an approved antenna(max gain 1.5dBi). Unauthorized antennas, modifications, or attachments could impair call quality, damage the radio, or result in violation of FCC regulations. Occupational/Controlled Use The radio transmitter is used in situations in which persons are exposed as consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Attention: This radio complieswith IEEE and ICNIRP exposure limits for occupational/controlled RF exposure emvironment at operating duty factors of up to 50% and is authorized by the FCC for occupational use only. An appropriate warning lable is affixed to all units. In order to comply with RF exposure requirements, a minimum distance of 2.5cm must be maintained when held-to-face, and body-worn operations are restricted to the approved original acessories (belt clip)a minimum distance of 0 cm. Do not use this device when antenna shows obvious damages. This product is compliance to FCC RF Exposure requirements and refers to FCC website https://apps.fcc.gov/oetcf/eas/reports/GenericSearch.cfm search for Model FCC ID: POD-ANA2W or Model TC- FCC ID:POD-ANA2 to gain further information include SAR Values. Our TYT two way radio generators RF electromagnetic energy during transmit mode.This radio is designed for and classified as“Occupational Use Only”,meaning it must be used only during the course of employment by individuals aware of the hazards,and the ways To Minimize Such hazards. This radio is NOT intended for use by the“General Population” in an uncontrolled environment. This radio has been tested and complies with the FCC RF exposure limits for“Occupational Use Only”.Inaddition, our TYT two way radio complies with the following Standards and Guidelines with regard to RF energy and electromagnetic energy levels and evaluation of such levels for exposure to humans: ---IEEE Std. 1528:2013 and KDB447498, Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields. ---American National Standards Institute (C95.1-1992), IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. ---American National Standards Institute (C95.3-1992), IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields-RF and Microwave. The information listed above provides the user with the information needed to make him or her aware of RF exposure, and what to do to as-sure that this radio operates with the FCC RF exposure limits of this radio. Electromagnetic Interference/Compatibility During transmissions,TYT two way radio generates RF energy that can possibly cause interference with other devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals, aircraft,and blasting sites. TC-666 666A

Cover Letter(s)

TYT ELECTRONICS CO., LTD Dec. 09, 2020 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID : POD-ANA2 Model Number: TC-666A, TC-666C, TC-666F, TC-666G To Whom It May Concern: We, The TYT ELECTRONICS CO., LTD hereby declare that the model : TC-666C, TC- 666F, TC-666G is identical with the model : TC-666A except the model name, plastic shell line and battery shell Except for the different above, no other modification is performed. Sincerely, Signature: TYT ELECTRONICS CO., LTD Contact person: Jiamao Lin

Cover Letter(s)

TYT ELECTRONICS CO., LTD Agent Authorization Company: TYT ELECTRONICS CO., LTD Address: Block 39-1, Optoelectronics-information industry base, Nan'an, Quanzhou, Fujian, China. Product Name: Analog Transceiver Model Number(s): TC-666A, TC-666C, TC-666F, TC-666G Product Description: Analog Transceiver We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-12-09 Name: Jiamao Lin Company: TYT ELECTRONICS CO., LTD

Cover Letter(s)

TYT ELECTRONICS CO., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020-12-09 Subject; Request for Confidentiality FCC ID: POD-ANA2 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely TYT ELECTRONICS CO., LTD Contact person: Jiamao Lin

Cover Letter(s)

TYT ELECTRONICS CO., LTD Dec. 08, 2020 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division Subject: Extended Frequencies Justification for Certification of Transmitter with FCC ID: POD-ANA2 Dear Sir/Madam, This transmitter was designed to operate in following frequency ranges: 400-470MHz To aid equipment authorization in other countries which accept the United States FCC Grant for Certification, TYT ELECTRONICS CO., LTD is requesting that the FCC lists the frequencies 400-470MHz, under FCC Rule Parts 90 on the FCC Grant. TYT ELECTRONICS CO., LTD attests that the Is two way radio will not be marketed to USA users with the frequency band which is not allowed by the rule part 90. Per the FCC’s KDB634817 guidance, as an alternative to listing the exact frequencies, we acknowledge that it’s a violation of the FCC Rules if this device operates on unauthorized frequencies. Also, equipment programming is the responsibility of Authorized Service Personnel, the Is two way radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Please contact me if you require any additional information. Sincerely Yours, Signature: ___________________ Jiamao Lin TYT ELECTRONICS CO., LTD Frequency Range (MHz） FCC Rule Part 400-406 For Federal 406.1-450 FCC Part90 450-454 FCC Part90 455-460 FCC Part90 460-462.5375 FCC Part90 462.7375-467.5375 FCC Part90 467.7375-470 FCC Part90

Cover Letter(s)

TYT ELECTRONICS CO., LTD ___________________________________________________________________________________________ Date: 2020-12-08 FCC Part90 Letter FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: FCC ID: POD-ANA2 Dear Sir/Madam, This equipment meets the requirements of the FCC Rules, Parts 90.203(e) and (g), as applicable. Programming software of this products could ONLY program the Call ID, PTT ID,encryption, 2-Tone,5-Tone , Scrambler ,contacts these kinds of function that will not influence on transmit and power. We are requesting certification under Part(s) of the Commission’s Rules listed above to allow operation of this equipment. The transmitter is intended for work related occupational use only under Part 90 of the FCC rules. The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls The product belongs to single analog modulation without data transmission. Sincerely Yours, Signature: ___________________ Jiamao Lin TYT ELECTRONICS CO., LTD

External Photos

External Photos ALL VIEW OF SERIAL MODEL ALL VIEW OF EUT Antenna TC-666F TC-666G TC-666C TC-666A TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

ID Label/Location Info

FCC ID Label Location FCC ID: POD-ANA2

Internal Photos

Internal Photos OPEN VIEW-1 OF EUT OPEN VIEW-2 OF EUT OPEN VIEW-3 OF EUT INTERNAL VIEW-1 OF EUT INTERNAL VIEW-2 OF EUT INTERNAL VIEW-3 OF EUT

RF Exposure Info

Ref : ACR.262.3.20.MVGB.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK,No.190, CHONGQING ROAD, FUYONG STREET, BAO’ AN DISTRICT, SHENZHEN,GUANGDONGCHINA MVG COMOSAR REFERENCE DIPOLE FREQUENCY: 450 MHZ SERIAL NO.: SN 30/14 DIP0G450-330 07/14/2020 Summary: This document presents the method and results from an accredited SAR reference dipole calibration performed in MVG. using the CALIPROBE test bench. for use with a MVG COMOSAR system only. The test results covered by accreditation are traceable to the International System of Units(SI). SAR Reference Dipole Calibration Report Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise - 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibretion date: 07/14/2020 Page: 1/11 SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.3.20.MVGB.A Name Function Date Signature Prepared by : Jérôme LUC Technical Manager 7/28/2020 Checked by : Jérôme LUC Technical Manager 7/28/2020 Approved by : Yann Toutain Laboratory Director 7/28/2020 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 7/28/2020Initial release Page: 2/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Jérôme LUC SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.3.20.MVGB.A TABLE OF CONTENTS 1 Introduction ................................................................................................................ 4 2 Device Under Test ..................................................................................................... 4 3 Product Description ................................................................................................... 4 3.1 General Information _______________________________________________________ 4 4 Measurement Method ................................................................................................ 5 4.1 Return Loss Requirements __________________________________________________ 5 4.2 Mechanical Requirements ___________________________________________________ 5 5 Measurement Uncertainty .......................................................................................... 5 5.1 Return Loss ______________________________________________________________ 5 5.2 Dimension Measurement ___________________________________________________ 5 5.3 Validation Measurement ____________________________________________________ 5 6 Calibration Measurement Results .............................................................................. 6 6.1 Return Loss and Impedance In Head Liquid ____________________________________ 6 6.2 Return Loss and Impedance In Body Liquid ____________________________________ 6 6.3 Mechanical Dimensions ____________________________________________________ 6 7 Validation measurement ............................................................................................ 7 7.1 Head Liquid Measurement __________________________________________________ 7 7.2 SAR Measurement Result With Head Liquid ____________________________________ 8 7.3 Body Liquid Measurement __________________________________________________ 9 7.4 SAR Measurement Result With Body Liquid __________________________________ 10 8 List of Equipment .................................................................................................... 11 Page: 2/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH T his document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Page: 3/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.3.20.MVGB.A 1 INTRODUCTION This document contains a summary of the requirements set forth by the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards for reference dipoles used for SAR measurement system validations and the measurements that were performed to verify that the product complies with the fore mentioned standards. 2 DEVICE UNDER TEST Device Under Test Device Type COMOSAR 450 MHz REFERENCE DIPOLE Manufacturer MVG Model SID450 Serial Number SN 30/14 DIP0G450-330 Product Condition (new / used) New A yearly calibration interval is recommended. 3 PRODUCT DESCRIPTION 3.1 GENERAL INFORMATION MVG’s COMOSAR Validation Dipoles are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. The product is designed for use with the COMOSAR test bench only. Figure 1 – MVG COMOSAR Validation Dipole Page: 4/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.3.20.MVGB.A 4 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards provide requirements for reference dipoles used for system validation measurements. The following measurements were performed to verify that the product complies with the fore mentioned standards. 4.1 RETURN LOSS REQUIREMENTS The dipole used for SAR system validation measurements and checks must have a return loss of -20 dB or better. Th…

Text truncated - open the document above for the full version.

RF Exposure Info

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No.: STS2011160H01 Issued for TYT ELECTRONICS CO., LTD Block 39-1, Optoelectronics-information industry base, Nan’an, Quanzhou, Fujian, China. Product Name: Analog Transceiver Brand Name: TYT Model Name: TC-666A Series Model: TC-666C, TC-666F, TC-666G FCC ID: POD-ANA2 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. Report SAR (1g): Face up : 0.848 W/kg Back side: 3.958 W/kg S T L A B S Page 2 of 33 Report No.: STS2011160H01 Test Report Certification Applicant’s name ................. : TYT ELECTRONICS CO., LTD Address ................................. : Block 39-1, Optoelectronics-information industry base, Nan’an, Quanzhou, Fujian, China. Manufacture's Name ............ : TYT ELECTRONICS CO., LTD Address ................................. : Block 39-1, Optoelectronics-information industry base, Nan’an, Quanzhou, Fujian, China. Product description Product name ........................ : Analog Transceiver Brand Name ........................... : TYT Model name ......................... : TC-666A Series Model .......................... : TC-666C, TC-666F, TC-666G Standards ............................. : ANSI/IEEE Std. C95.1 IEEE 1528:2013 FCC 47 CFR Part 2 ( 2.1093) The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 24 Nov. 2020 Date of Issue .......................................... : 25 Nov. 2020 Test Result .............................................. : Pass Testing Engineer : (Lemon Li) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 33 Report No.: STS2011160H01 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 6 1.3 Test Factory 6 2. Test Standards and Limits 7 3. SAR Measurement System 8 3.1 Definition of Specific Absorption Rate (SAR) 8 3.2 SAR System 8 4. Tissue Simulating Liquids 11 4.1 Simulating Liquids Parameter Check 11 5. SAR System Validation 13 5.1 Validation System 13 5.2 Validation Result 13 6. SAR Evaluation Procedures 14 7. EUT Test Position 15 8. Uncertainty 16 8.1 Measurement Uncertainty 16 8.2 System validation Uncertainty 17 9. Conducted Power Measurement 18 10. EUT And Test Setup Photo 19 10.1 EUT Photo 19 10.2 Setup Photo 22 11. SAR Result Summary 24 12. Equipment List 26 Appendix A. System Validation Plots 27 Appendix B. SAR Test Plots 29 Appendix C. Probe Calibration and Dipole Calibration Report 33 Page 4 of 33 Report No.: STS2011160H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 25 Nov. 2020 STS2011160H01 ALL Initial Issue Note: Format version of the report -V01 Page 5 of 33 Report No.: STS2011160H01 1. General Information 1.1 EUT Description Equipment Analog Transceiver Brand Name TYT Model name TC-666A Series Model TC-666C, TC-666F, TC-666G Model Difference The same PCB board and specifications, only the plastic shell line, battery shell, and model are different Device Category Portable Product stage Production unit RF Exposure Environment Occupational/Controlled Hardware Version KA2U-1903-V1.0 Software Version v1.37 Frequency Range 400-470MHz Channel Spacing 12.5KHz Max. Reported SAR(1g): With 50% duty cycle Mode Frequency(MHz) Face up (W/kg) Back Side (W/kg) 2W 400.025 0.801 3.675 435.025 0.820 3.751 469.975 0.845 3.958 1W 400.025 0.344 0.700 435.025 0.357 0.716 469.975 0.399 0.750 Modulation Type: FM Antenna Specification: Detachable Antenna Note: 1. The EUT battery must be fully charged and checked periodically during the test to ascertain uniform power Page 6 of 33 Report No.: STS2011160H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC Registration No.: 625569 A2LA Certificate No.: 4338.01 IC Registration No.: 12108A Page 7 of 33 Report No.: STS2011160H01 2. Test Standards and Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v06 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r04 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D02 v01r02 RF Exposure Reporting 7 FCC KDB 643646 D001 SAR Test Reduction Considerations for Occupational PTT Radios (A). Limits for Occupational/Controlled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankles 0.4 8.0 20.0 (B). Limits for General Population/Uncontrolled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankles 0.08 1.6 4.0 NOTE: Whole-Body SAR is averaged over the entire body, part…

Text truncated - open the document above for the full version.

Test Report

Test Setup Photos RADIATED EMISSION BELOW 1G TEST SETUP RADIATED EMISSION ABOVE 1G TEST SETUP CONDUCTED TEST SETUP

Test Report

Page 1 of 71 Report No.: AGC02931200801FE10 FCC ID : POD-ANA2 PRODUCT DESIGNATION : Analog Transceiver BRAND NAME : TYT MODEL NAME : TC-666A, TC-666C, TC-666F, TC-666G APPLICANT : TYT ELECTRONICS CO., LTD DATE OF ISSUE : Nov. 05, 2020 STANDARD(S) : FCC Part 90 Rules REPORT VERSION : V 1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd FCC Part 90 Rules Test Report Report No.:AGC06326201001FE10 Page 2 of 71 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Nov. 05, 2020 Valid Initial Release Report No.:AGC02931200801FE10 Page 3 of 71 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE ....................................................................................... 5 2. GENERAL INFORMATION .................................................................................................... 6 2.1PRODUCT DESCRIPTION ........................................................................................................................ 6 2.2RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................... 9 2.3 TEST METHODOLOGY ........................................................................................................................... 9 2.4 ADDRESS OF THE TEST LABORATORY ............................................................................................... 9 2.5 TEST FACILITY ........................................................................................................................................ 9 2.6 SPECIAL ACCESSORIES ...................................................................................................................... 10 2.7 EQUIPMENT MODIFICATIONS ............................................................................................................. 10 3. SYSTEM TEST CONFIGURATION ...................................................................................... 11 3.1EUT CONFIGURATION ............................................................................................................................ 11 3.2 EUT EXERCISE ...................................................................................................................................... 11 3.3 GENERAL TECHNICAL REQUIREMENTS ............................................................................................. 11 3.4 CONFIGURATION OF TESTED SYSTEM ............................................................................................. 12 4. SUMMARY OF TEST RESULTS ......................................................................................... 13 5. DESCRIPTION OF TEST MODES ...................................................................................... 16 6. FREQUENCY TOLERANCE ............................................................................................... 17 6.1 PROVISIONS APPLICABLE ................................................................................................................... 17 6.2 MEASUREMENT PROCEDURE ............................................................................................................ 17 6.3 TEST SETUP BLOCK DIAGRAM ........................................................................................................... 18 6.4 TEST RESULTS ..................................................................................................................................... 19 7. EMISSION BANDWIDTH ....................................................................................................... 21 7.1 PROVISIONS APPLICABLE ................................................................................................................... 21 7.2 MEASUREMENT PROCEDURE ............................................................................................................ 21 7.3 TEST SETUP BLOCK DIAGRAM ........................................................................................................... 21 7.4 MEASUREMENT RESULT ..................................................................................................................... 23 8．UNWANTED RADIATION .................................................................................................... 29 8.1 PROVISIONS APPLICABLE ................................................................................................................... 29 8.2 MEASUREMENT PROCEDURE ............................................................................................................ 29 8.3 TEST SETUP BLOCK DIAGRAM ........................................................................................................... 30 8.4 MEASUREMENT RESULTS: .................................................................................................................. 32 8.5 EMISSION MASK PLOT ......................................................................................................................... 41 9.MODULATION CHARACTERISTICS ..................................................................................... 46 9.1 PROVISIONS APPLICABLE ................................................................................................................... 46 Report No.:AGC02931200801FE10 Page 4 of 71 9.2 MEASUREMENT METHOD ................................................................................................................... 46 9.3 MEASUREMENT RESULT ...................................................................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jiamao Lin

[email protected]0595-86766928Fax: 0595-86767928

Technical Contact

TYT ELECTRONICS CO., LTD

[email protected]

China

Test Firm

Attestation of Global Compliance (Shenzhen) Co., LDoris Li

[email protected]+86-755-25234088

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	90	406.1 MHz - 470 MHz	2 W	11K0F3E	1.0910000000 ppm

Confidentiality

Long Term

Grant Notes

Power output listed is rated conducted. The maximum conducted power is 1.95W. This device must be restricted to work-related operations only in an Occupational/Controlled RF exposure environment and must operate with a duty factor not exceeding 50%. All qualified end-users of this device must have the knowledge to control their exposure conditions and/or duration to comply with Occupational /Controlled Exposure limit and requirements. A label, as described in this filing, must be displayed on the device to direct users to specific training information for meeting Occupational Exposure Requirements. Body-worn SAR compliance is limited to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide a minimum of 2.5cm between the device, including its antenna, and the user's body. The highest reported SAR values for Face held and Body-worn accessory are: 0.85 W/Kg and 3.96 W/Kg respectively when operating at 50% duty cycle.
