PODTH-9000DVVHF Mobile Radio

Thank you very much for using two-way radios. This product has a newly developed function menu and humanism operation design, making it easy to use. It will meet your requirement by the compact size and reasonable price. To customers User Manual TYT Electronics Co.,Ltd. TH-9000D TH-9000DU (Only IC UHF Version) Please contact the local authorized dealer if you have any questions.We are not responsible for any typographical errors that may be in this manual. Standard accessories may change without notice, getting your understanding for any inconveniences. Thank you for choosing TYT mobile transceiver, TYT always provides high quality products, and this transceiver is no exception. As you learn how to use this transceiver, you will find that TYT is pursuing "user friendliness". For example, each time you change the menu no. in Menu mode, you will see a text message on the display lets you know what you are configuring. Though friendly design for user, this transceiver is technically complicated and some features may be new to you. Consider this manual to be a personal tutorial from the designers,allow the manual to guide you through the learning process now, then act as a reference in the coming years. Precautions Please observe the following precautions to prevent fire, personal injury, or transceiver damage: Do not attempt to configure your transceiver while driving,it is dangerous. This transceiver is designed for a 13.8V DC power supply. Don't use a 24V battery to power on the transceiver. Do not place the transceiver in excessively dusty, humid or wet areas, nor unstable surfaces. Please keep it away from interferential devices (such as TV, generator etc.) Do not expose the transceiver to long periods of direct sunlight nor place it close to heating appliances. If an abnormal odor or smoke is detected coming from the transceiver, turn OFF the power immediately. Contact local service station or your dealer. Do not transmit with high output power for extended periods; the transceiver may overheat. P 3 P 4 P 5 P 1 P 2 DATA PWR TX New and Innovative Features Supplied Accessories/Optional Accessories Supplied Accessories Optional Accessories Initial Installation Mobile Installation DC Power Cable Connection Power Supply Voltage Display Antenna Connection Accessories Connections Getting Acquainted Front panel Rear panel Display Microphone Display Mode Basic Operations Switching the Power On/Off Adjusting the Volume 01 02-03 02 03 04-13 04-05 05-09 09-10 10-11 11-13 14-18 14-15 16 16-17 18 19-20 21-24 21 21 CONTENTS Channel mode Adjusting Channel Through Selector Knob Receiving Transmitting Transmitting Tone-Pulse Transmitting Optional Signaling Channel Edit Channel Delete Shortcut Operations Squelch Off Squelch Level Setup Frequency/Channel Scan Channel Scan CTCSS/DCS Encode and Decode Setup CTCSS Scan DCS Scan Voice Compander Offset Direction and Offset Frequency Setup Keypad Lockout 21 21-22 22 22-23 23 23 23 24 24-29 24 24 24-25 25 25-26 26 26 27 27-28 28 Current Voltage Enquiry Auto-Dialer Setup Transmitting Edited DTMF Tones in the Auto-dialer Memory General Setting Frequency Channel Step Setup DTMF, DTMF ANI, 2Tone or 5Tone Signaling Sending 2-Tone Call Sending 5-Tone Call Sending DTMF call Signaling Combination Setup Band-width Selection TX OFF Setup Busy Channel Lockout Editing Channel Name Reverse TX/RX Talk Around Voice Compander Scrambler Setup (Encryption) Radio's DTMF SELF ID ENQUIRY Radio's 5TONE SELF ID ENQUIRY 28 29 29 30-45 30 30-31 31-32 32 32-33 33-34 34 34-35 35-36 36 36 37 37 38 38 38 Voice Prompt TOT (Time-out timer) APO (Auto power off) DTMF Transmitting Time Squelch Level Setup Scan Stop Time Setup LCD Backlight Background Light Color Pilot Frequency Display Mode Setup Power on password Setup Address List Factory Default Microphone Operation Microphone Keypad lockout Sending DTMF By Keypad Function Setup By Microphone Keypad Switches between VFO and channel mode Short Calling Squelch Level Optional Signaling 39 39-40 40 40-41 41 41-42 42 42 42-43 43 44 44 45 46-52 46 46 47 47 47 47 47-48 Scan Skip Frequency/Channel Scan Busy Channel Lockout Reverse TX/RX TOT (Time-out timer) CTCSS/DCS Encode and Decode Talk Around Voice Prompt LCD Backlight Long-distance Anti-theft Alarm Cable Clone Programmin Software Installing and Starting (in windows XP system) Maintenance Default Setting after Resetting(VHF) Default Setting after Resetting(UHF) Trouble Shooting Specifications Attached Chart 50 groups CTCSS Tone Frequency(Hz) 1024 groups DCS Code 48 48 49 49-50 50 50-51 51 51-52 52 53-54 54-55 56-57 58-59 58 58 59 60-61 62-66 62 63-66 New and Innovative Features The mobile radio has nice housing, stoutness & stability, advanced and reliable functions, perfect & valuable. This mobile radio especially designs for drivers and Display on a large LCD with adjustable brightness, convenient for nighttime use. Distribute buttons reasonably, convenient for operation. Adopt superior quality material, better technology and high quality radiator to ensure stable and durable operation. 200 programmable memorized channels, identified by editing name. Programming different CTCSS, DCS, 2Tone, 5Tone in per channel, rejecting extra calling from other radios. Various scan functions including CTCSS/DCS Scan function. Using 5Tone to send Message, Emergency alarm, Call all, ANI, Remotely kill, Remotely Waken, etc. Automatic calling ldentification function by DTMF--ANI or 5Tone--ANI. Scramble function (Optional). Compander function for decrease the background noise and enhance audio clarity, it can set compander ON/OFF per channel. Different band width per channel, 25K for wide band, or 12.5K for narrow band. Theft alarm provides extra safety. 1024 groups of DCS code improves the abiliting of rejecting extra calling. 01 it pursues company philosophy of innovation and practicality. More functions as follows: 9000DU 02 Supplied Accessories/Optional Accessories Supplied Accessories Black screws (M4X8mm) [T…

Text truncated - open the document above for the full version.

TYT ELECTRONICS CO., LTD Block 39-1, Optoelectronics-information industry base, Nan'an, Quanzhou, Fujian, China. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jul. 15, 2020 FCC ID: PODTH-9000DV Subject: Declaration of compliance to the requirements of §15.121 We declare that, this scanning receiver is incapable of operating (tuning), or readily being altered by the users to operate, within the frequency bands allocated to the Cellular Radiotelephone Service in part 22 of this chapter (cellular telephone bands). This device will not be able to receive transmissions in the cellular telephone bands by means of clipping the leads of, or installing, a simple component such as a diode, resistor or jumper wire; replacing a plug-in semiconductor chip; or programming a semiconductor chip using special access codes or an external device, such as a personal computer. This device is also incapable of converting digital cellular communication transmissions to analog voice audio. This device is designed so that the tuning, control and filtering circuitry is inaccessible. Any attempts to modify the equipment to receive transmissions from the Cellular Radiotelephone Service will render the receiver inoperable. This scanning receiver rejects any signals from the Cellular Radiotelephone Service frequency bands that are 38 dB or lower based upon a 12 dB SINAD measurement. We are aware that the modification of this device to receive transmissions from Cellular Radiotelephone Service frequency bands will be considered to constitute manufacture of such equipment. This includes any individual, individuals, entity or organization that modifies one or more scanners. Any modification to receive transmissions from the Cellular Radiotelephone Service frequency bands voids the certification of the scanning receiver, regardless of the date of manufacture of the original unit. If you have any questions, please feel free to contact me. Thank you. Sincerely, Signatory Name: Peter Wang Title: General Manager

TYT ELECTRONICS CO., LTD Block 39-1, Optoelectronics-information industry base, Nan'an, Quanzhou, Fujian, China Agent Authorization Company: TYT ELECTRONICS CO., LTD Address: Block 39-1, Optoelectronics-information industry base, Nan'an, Quanzhou, Fujian, China Product Name: Mobile Radio Model Number(s): TH-9000D Product Description: VHF Mobile Radio We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Jul. 15, 2020 Name: Jiamao Lin Title: General Manager Company: TYT ELECTRONICS CO., LTD

TYT ELECTRONICS CO., LTD Block 39-1, Optoelectronics-information industry base, Nan'an, Quanzhou, Fujian, China Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jul. 15, 2020 Subject; Request for Confidentiality FCC ID: PODTH-9000DV To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jiamao Lin Title: General Manager

External Photos WHOLE VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT Hand microphone TOP VIEW OF EUT Antenna Port BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location 20mm*20mm FCC ID: PODTH-9000DV

Internal Photos OPEN VIEW OF EUT-1 OPEN VIEW OF EUT-2 OPEN VIEW OF EUT-3 INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 INTERNAL VIEW OF EUT-4 INTERNAL VIEW OF EUT-5 INTERNAL VIEW OF EUT-8 INTERNAL VIEW OF EUT-9 INTERNAL VIEW OF EUT-10 INTERNAL VIEW OF EUT-11 INTERNAL VIEW OF EUT-12 Hand microphone OPEN VIEW OF EUT-1 OPEN VIEW OF EUT-2 OPEN VIEW OF EUT-3 OPEN VIEW OF EUT-4

Test Setup Photos CONDUCTED EMISSION TEST SETUP RADIATED EMISSION TEST SETUP-BELOW 1GHZ RADIATED EMISSION TEST SETUP-ABOVE 1GHZ
