PP203036IV2.4GHz Nano Receiver

Shenzhen Rapoo Technology Co.,Ltd. Jacalyn Liu Page 1 of 4 5/16/2011 Quick Start Guide Of 2.4GHz Wireless Notebook Touch Mouse Rev: 1.00 2.4GHz Nano Receiver FCC ID:PP203036IV Shenzhen Rapoo Technology Co.,Ltd. Jacalyn Liu Page 2 of 4 5/16/2011 Installation 1. Plug the Nano receiver into a USB port of your computer. 2. Push the mouse power switch on. 3. Click the button to connect. Mouse Functions Left Click It’s a point-and-click mouse, and you can click anywhere on its multi-touch surface with a finger or two fingers. Click in the left click area to realize left button function. (Left click area is anywhere except right click area.) Right Click Click in the right click area to realize right button function with a finger. Scroll and Tilt Single finger swipes on the surface of the mouse like the blue cross showed in the picture. If you swipe in horizon direction, it equals the Tilt function. And if you swipe in vertical direction, it equals the scroll wheel function of a normal mouse. Note: 1.Scroll is to zoom in/out in Windows Picture and Fax Viewer and Windows Photo Viewer (Win7). 2. Tilt is only available in Windows Vista and Windows 7 without driver. Left Click Right Click Scroll + Tilt Screen Zoom Shenzhen Rapoo Technology Co.,Ltd. Jacalyn Liu Page 3 of 4 5/16/2011 Screen Zoom Function Hold down the Control key on your keyboard and scroll with one finger on the Mouse to enlarge items on your screen. Back and Forward Using two fingers, swipe left and right along the Multi-Touch surface to advance through pages in internet explorer or browse photos in picture manager. It equals the back and forward function of a normal mouse. Trouble Shooting 1. Check Nano receiver connection; try to inserting Nano Receiver to another USB port on your computer. 2. Connection between the mouse and the Nano Receiver. Re-insert the Nano Receiver. Take out the battery and reinstall it. Note This device complies with Part 15 of the FCC rules. Operation subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Caution! The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment. Back and Forward Shenzhen Rapoo Technology Co.,Ltd. Jacalyn Liu Page 4 of 4 5/16/2011 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices).

Neutron Engineering Inc. Project No.: 1105C072 Page 2 of 4 1105C0721105C072 1105C0721105C072 Neutron Engineering Inc. Project No.: 1105C072 Page 2 of 4 1105C0721105C072 1105C0721105C072

Label Size： Label location

Neutron Engineering Inc. Project No.: 1105C072 Page 3 of 4 1105C072 1105C072 Neutron Engineering Inc. Project No.: 1105C072 Page 3 of 4 1105C072 1105C072 Neutron Engineering Inc. Project No.: 1105C072 Page 4 of 4 1105C072 1105C072 Neutron Engineering Inc. Project No.: 1105C072 Page 4 of 4 1105C072 1105C072

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 2 of 51 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutronshall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 3 of 51 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.4 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 MEASUREMENT INSTRUMENTS LIST 13 4.1.3 TEST PROCEDURE 14 4.1.4 DEVIATION FROM TEST STANDARD 14 4.1.5 TEST SETUP 14 4.1.6 EUT OPERATING CONDITIONS 14 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 MEASUREMENT INSTRUMENTS LIST 18 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BELOW 30MHZ) 23 4.2.8 TEST RESULTS (BETWEEN 30 – 1000 MHz) 24 4.2.9 TEST RESULTS (ABOVE 1000 MHz) 26 4.2.10 TEST RESULTS (2400 – 2483.5 MHz) 38 5 . BANDWIDTH TEST 39 5.1 MEASUREMENT INSTRUMENTS LIST 39 5.2 TEST PROCEDURE 39 5.3 DEVIATION FROM STANDARD 39 5.4 TEST SETUP 39 5.5 EUT OPERATION CONDITIONS 39 5.6 TEST RESULTS 40 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 4 of 51 Table of Contents Page 6 . ANTENNA CONDUCTED SPURIOUS EMISSION 42 6.1 APPLIED PROCEDURES / LIMIT 42 6.1.1 MEASUREMENT INSTRUMENTS LIST 42 6.1.2 TEST PROCEDURE 42 6.1.3 DEVIATION FROM STANDARD 42 6.1.4 TEST SETUP 42 6.1.5 EUT OPERATION CONDITIONS 42 6.1.6 TEST RESULTS 43 7 . EUT TEST PHOTO 48 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 5 of 51 1. CERTIFICATION E q u i p m e n t : 2.4GHz Nano Receiver Brand Name : RAPOO Model Name : 03036; 03036-T1 A p p l i c a n t : ShenZhen Rapoo Technology Co., Ltd. F a c t o r y : ShenZhen Rapoo Technology Co., Ltd. A d d r e s s : Block A1,B1,B2,1st second stage, 1st Industrial Park, 3rd Industrial Zone, Fenghuang Fuyong, BaoAn, Shenzhen, P.R.CHINA Date of Test : May. 06, 2011 ~ May. 12, 2011 T e s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.249)/ ANSI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1105C072) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 6 of 51 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.209 Radiated Emission PASS 15.249 Radiated Spurious Emission PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 7 of 51 2.1 TEST FACILITY The test facilities used to collect the test data in this report is DG-C02/DG-CB03at the location of No.3,Jinshagang 1st Road, ShiXia, Dalang Town,Dong Guan, China.523792 Neutron's test firm number is 319330 2.2 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 A. Conducted Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE DG-C02 CISPR 150 KHz ~ 30MHz 1.94 B. Radiated Measurement : Test Site Method Measurement Frequency Range Ant. H / V U，(dB) NOTE 30MHz ~ 200MHz V 2.48 30MHz ~ 200MHz H 2.16 200MHz ~ 1,000MHz V 2.50 DG-CB03 CISPR 200MHz ~ 1,000MHz H 2.66 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 8 of 51 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT Equipment 2.4GHz Nano Receiver Brand Name RAPOO Model Name. 03036; 03036-T1 OEM Brand/Model Name N/A Model Difference Only difference is model name. Product Description The EUT is a 2.4GHz Nano Receiver. Product Type Low Power Communication Device Operation Frequency: 2408~2474 MHz Modulation Type:…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 48 of 51 7. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 48 of 51 7. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 49 of 51 Radiated Measurement Photos 9K~30MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 49 of 51 Radiated Measurement Photos 9K~30MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 50 of 51 Radiated Measurement Photos 30M~1000MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 50 of 51 Radiated Measurement Photos 30M~1000MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 51 of 51 Radiated Measurement Photos Above 1000MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1105C072 Page 51 of 51 Radiated Measurement Photos Above 1000MHz
