PP2M605HG2.4GHz Wireless Remote Control Mouse

MLK Industries (ShenZhen) Limited Rev:1.00 2009.5.10 1/3 P/N 266-81830-2009 Installation 1. Plug the Nano receiver into a USB port of your computer. 2. Push battery cover back first,and then pull it down to open the battery door. 1. 3. Insert 2 AAA batteries. Place back the battery cover. 4. Install the driver (required for programable button). 5. Open software from the start menu. Please click “HELP” if you have any questions. Mouse Functions Interchangeable Top-Cover Press the eject button to take away the top-cover L,and then you can put another top-cover M on the mouse. Flip 3D Press this button to switch from different windows.It’s the same function with “Alt+Tab” in keyboard. Green LED Quick Start Guide of 2.4GHz Wireless Remote Control Mouse 2. MLK Industries (ShenZhen) Limited Rev:1.00 2009.5.10 2/3 P/N 266-81830-2009 When switch the power ON, this LED will flash for 5 seconds. And If the power is low, this LED will flash too Speed Control Press the DPI button and you can toggle the DPI between 800 DPI and 1600 DPI. Universal Back / Forward Use the back button to access previous page and use the forward button to access next page. On/Off the mouse Switch on or shut off the mouse by using the On/Off switch at the bottom of the mouse. Trouble Shooting 1. Check Nano receiver connection; try to inserting Nano Receiver to another USB port on your computer. 2. Connection between the mouse and the Nano Receiver. Re-insert the Nano receiver. Take out the battery and reinstall it. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). MLK Industries (ShenZhen) Limited Rev:1.00 2009.5.10 3/3 P/N 266-81830-2009 Note This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Caution! The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment.
