PPIRM-813GSM/WCDMA cellular phone w/BT and WLAN

Microsoft Corporation

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Nov 20, 2011
Application Purpose: Original Equipment
Date of Application: Nov 20, 2011
Equipment Note: GSM/WCDMA cellular phone w/BT and WLAN
Frequency Range: 2402.00000000 - 2480.00000000
Company: Microsoft Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Nokia 302 User Guide 5555555 Issue 1 CyanCyanMagentaMagentaYellowYellowBlackBlack Contents Safety5 Get started7 Keys and parts7 Write with the keyboard9 Messaging key11 Insert a SIM card and battery11 Insert a memory card13 Charge the battery14 Switch the phone on or off16 Antenna locations17 Attach a strap17 Basic use18 Access codes18 Lock the keys20 Indicators21 Copy content from your old phone22 Change the volume of a call, song, or video23 Use your phone without a SIM card23 Calls24 Make a call24 Call the last dialled number24 View your missed calls 24 Contacts25 Save a name and phone number25 Use speed dial26 Write text27 Write using the keyboard27 Predictive text input28 Messaging29 Send a message29 Listen to voice messages31 2www.nokia.com/support CyanCyanMagentaMagentaYellowYellowBlackBlack Personalise your phone31 About the home screen 31 Personalise the home screen32 Personalise your phone tones33 Time management34 Change the time and date34 Alarm clock34 Add an appointment35 Connectivity 36 Bluetooth36 USB data cable38 Connect to a WLAN39 Music and audio42 FM radio42 Media player44 Camera46 Take a picture46 Record a video47 Send a picture or video 47 Web48 About the web browser 48 Browse the web49 Clear your browsing history50 Keep in touch with your online friends51 About Communities51 Mail and chat52 About Mail52 Send a mail52 Read and reply to mail 53 About Chat53 Chat with your friends53 Nokia Services54 Availability and costs of Nokia Services54 Access Nokia Services55 Phone management55 www.nokia.com/support3 CyanCyanMagentaMagentaYellowYellowBlackBlack Update phone software using your phone55 Update phone software using your PC57 Restore original settings57 Back up your pictures and other content to a memory card58 Protect the environment58 Save energy58 Recycle59 Product and safety information59 Index71 4www.nokia.com/support CyanCyanMagentaMagentaYellowYellowBlackBlack Safety Read these simple guidelines. Not following them may be dangerous or illegal. For further information, read the complete user guide. SWITCH OFF IN RESTRICTED AREAS Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas. ROAD SAFETY COMES FIRST Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety. INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance. Safety5 CyanCyanMagentaMagentaYellowYellowBlackBlack QUALIFIED SERVICE Only qualified personnel may install or repair this product. KEEP YOUR DEVICE DRY Your device is not water-resistant. Keep it dry. PROTECT YOUR HEARING Listen to a headset at a moderate level, and do not hold the device near your ear when the loudspeaker is in use. 6Safety CyanCyanMagentaMagentaYellowYellowBlackBlack Get started Keys and parts 1Charger connector 2Headset connector/Nokia AV connector (3.5 mm) 3Micro-USB connector Get started7 CyanCyanMagentaMagentaYellowYellowBlackBlack 4Earpiece 5Screen 6Selection key 7Social key 8Call key 9Bluetooth key. Press and hold to access the Bluetooth settings. 10WLAN key. Press and hold to access the WLAN settings. 11Navi™ key (scroll key) 12Selection key 13Messaging key 14End/Power key 15Keyboard 1 2 3 4 5 8Get started CyanCyanMagentaMagentaYellowYellowBlackBlack 1Camera lens. Before using the camera, remove the protective tape from the lens. 2Wrist strap hole 3Loudspeaker 4Memory card slot 5Back cover release latch Write with the keyboard Your phone has a full keyboard. 1 Function key. To insert special characters printed at the top of keys, press the function key, and then press the corresponding key. To enter several special Get started9 CyanCyanMagentaMagentaYellowYellowBlackBlack characters in a row, press the function key twice. To return to normal mode, press the function key. 2 Shift key. To switch between the upper and lower case modes, press the shift key twice. To enter a single upper case letter in lower case mode, or a single lower case letter in upper case mode, press the shift key, and then press the desired alphabet key. 3 Sym key. To insert special characters not shown on the keyboard, press the sym key, and select the desired character. 4 Backspace key. To delete a character, press the backspace key. To delete several characters, press and hold the backspace key. 5 Enter key. To move the cursor to the next row or text input field, press the enter key. Additional functions are based on the current context. 6 Ctrl key. To copy, cut, or paste text, while pressing and holding the ctrl key, press C, X, or V. To select all, while pressing and holding the ctrl key, press A. Insert a variation of a letter You can insert, for example, letters with accents. To insert á, press and hold the sym key, and then press A repeatedly, until the desired letter is displayed. The order and availability of letters depends on the selected writing language. 10Get started CyanCyanMagentaMagentaYellowYellowBlackBlack Messaging key To quickly write a mail or message, view your inbox, or start chatting, on the home screen, press the messaging key . Set what happens when you press the key Select Menu > Settings and My shortcuts > Messaging key, and select an option. Insert a SIM card and battery Important: This device is designed to be used with a standard SIM card (see figure) only. Use of incompatible SIM cards may damage the card or the device, and may corrupt data stored on the card. Please consult your mobile operator for the use of a SIM card that has a mini-UICC cutout. This phone is intended for use with a BL-5J battery. Always use original Nokia batteries. 1Pull the back cover release latch toward the bottom of the phone, and remove the cover. Get started11 CyanCyanMagentaMagentaYellowYellowBlackBlack 2If the b…

Text truncated - open the document above for the full version.

Cover Letter(s)

NOKIA GmbH Joensuunkatu 7 FIN-24100 SALO FINLAND Tel. +358 7180 08000 Fax. +358 7180 45220 November 18, 2011 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: PPIRM-813 and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA GmbH Tero Lehtinen Product Certification Officer DQD/DCo, Salo

Cover Letter(s)

NOKIA GmbH Joensuunkatu 7 FIN-24100 SALO FINLAND Tel. +358 7180 08000 Fax. +358 7180 45220 November 18, 2011 Attention: Equipment Authorization Branch REQUEST FOR SHORT TERM CONFIDENTIALITY Pursuant to Section 0.459 of the Commission’s Rules and Public Notice DA 04-1705 of June 15, 2004, the Applicant hereby requests for 90 days short term confidential treatment of some of the information accompanying this application of FCC ID: PPIRM-813 and as outlined below: - Exhibit 3: External photos - Exhibit 7: Test setup photos - Exhibit 8: User's manual - Exhibit 9: Internal photos These materials contain proprietary information not yet released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. NOKIA GmbH Tero Lehtinen Product Certification Officer DQD/DCo, Salo

External Photos

08 November 2011 External photographs FCC ID: PPIRM-813 Exhibit 3 IC: 661U-RM813 Applicant: Nokia Corporation Copyright © 2011 Nokia. All rights reserved. 1. EXTERNAL PHOTOGRAPHS 1.1 Front and back 08 November 2011 External photographs FCC ID: PPIRM-813 Exhibit 3 IC: 661U-RM813 Applicant: Nokia Corporation Copyright © 2011 Nokia. All rights reserved. 1.1 Disassembled 08 November 2011 External photographs FCC ID: PPIRM-813 Exhibit 3 IC: 661U-RM813 Applicant: Nokia Corporation Copyright © 2011 Nokia. All rights reserved. 1.2 External interfaces

ID Label/Location Info

Internal Photos

09 November 2011 Internal photographs FCC ID: PPIRM-813 Exhibit 9 IC: 661U-RM813 Applicant: Nokia Corporation Copyright © 2011 Nokia. All rights reserved. 1. INTERNAL PHOTOGRAPHS 1.1 Pwb back 09 November 2011 Internal photographs FCC ID: PPIRM-813 Exhibit 9 IC: 661U-RM813 Applicant: Nokia Corporation Copyright © 2011 Nokia. All rights reserved. 1.2 Pwb front

Test Report

FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CBT_RM-813_02.docx Copyright © TCC Nokia 1 (23) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC Part 15C Compliance Test Report Test Report no.: FCC15CBT_RM-813_02.docx Date of Report: 01-Nov-2011 Number of pages: 23 Customer’s Contact person: Ramelli Bruno Testing laboratory: TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 Customer: Nokia Corporation Lise Meitner Strasse 10 89081 ULM GERMANY Tel. +49 731 1754 0 Fax. +49 731 1754 6800 FCC listing no.: IC recognition no.: 94436 661AK-1 Tested devices/ accessories: Phone RM-813 / Battery BL-5J / AC charger AC-11E / Headset WH-102 FCC ID: PPIRM-813 IC: 661U-RM813 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), Public Notice DA 00-705, DTS procedures KDB 558074, IC standards. Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Hannu Söderholm, Senior Engineer, EMC FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CBT_RM-813_02.docx Copyright © TCC Nokia 2 (23) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 1. Summary for FCC Part 15C Compliance Test Report Date of receipt 03-Oct-2011 Testing completed 20-Oct-2011 The customer's contact person Ramelli Bruno Test Plan referred to T:\Projects\RM-813\TestPlan\RS_testplan_RM-813.xls Notes - Document name T:\Projects\RM-813\EMC\FCC15CBT_RM-813_02.docx 1.1. EUT and Accessory Information The EUT is a 8-band mobile phone: GSM850/900/1800/1900/GPRS/EGPRS/Monopole without GND reflector (GSM/WCDMA) WCDMA I/II(1900)/V(850)/VIII/HSDPA/HSUPA/Monopole without GND reflector (GSM/WCDMA) WLAN/Bluetooth The EUT is tested with maximum rated TX power, modulated with pseudo random bit sequence (PRBS9). Product Type SN HW MV SW DUT Phone RM-813 004402136622101 0150 - jc13.32 42686 Battery BL-5J 4175351253D10101414;0670573 - - - 42688 AC charger AC-11E 4090491212970501626;0675479 - - - 42689 Headset WH-102 06943231163V4121358 - - - 42690 1.2. Summary of Test Results Bluetooth: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8(0.4(2)) Conducted peak output power NP 15.247(d) A8(0.5) Band edge compliance of RF emissions PASSED 15.247(d) A8(0.5) Spurious RF conducted emissions NP 15.247(d), 15.209 A8(0.5) Spurious radiated emissions PASSED 15.207 7.2.2 AC powerline conducted emissions PASSED 15.247(a)(1) A8(0.1(1)) 20dB(bandwidth) NP 15.247(a)(1) A8(0.1(2)) Carrier frequency separation NP 15.247(a)(1)(iii) A8(0.1(4)) Number of hopping frequencies NP 15.247(a)(1)(iii) A8(0.1(4)) Time of occupancy NP PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CBT_RM-813_02.docx Copyright © TCC Nokia 3 (23) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 CONTENTS 1. Summary for FCC Part 15C Compliance Test Report .............................................. 2 1.1. EUT and Accessory Information ........................................................................................... 2 1.2. Summary of Test Results ..................................................................................................... 2 2. Band edge compliance of RF emissions (FCC §15.247(d), RSS-210 A8.5) ....................................................................................... 4 2.2. Test method and limit ........................................................................................................... 4 2.3. Bluetooth Test results ........................................................................................................... 5 3. AC powerline conducted emissions (FCC §15.207, RSS-GEN 7.2.2) .................... 15 3.1. Test method and limit ......................................................................................................... 15 3.2. Bluetooth Test results ......................................................................................................... 16 4. Spurious radiated emissions (FCC §15.247(d), §15.209, RSS-210 A8.5) ....................................................................... 17 4.2. Test method and limit ......................................................................................................... 18 4.3. Bluetooth Test results ......................................................................................................... 19 5. Test Equipment ......................................................................................................... 22 5.1. Conducted measurements ................................................................................................. 22 5.2. Radiated measurements .................................................................................................... 23 FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CBT_RM-813_02.docx Copyright © TCC Nokia 4 (23) TCC Nokia Tampere Laboratory P.O. Box 6…

Text truncated - open the document above for the full version.

Test Report

FCC Part 15C Compliance Test Report / Template Version 12.0 FCC15C_RM-813_07.docx Copyright © TCC Nokia 1 (27) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC Part 15C Compliance Test Report Test Report no.: FCC15C_RM-813_07.docx Date of Report: 07-Oct-2011 Number of pages: 27 Customer’s Contact person: Bruno Ramelli Testing laboratory: TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 Customer: Nokia Corporation Lise Meitner Strasse 10 89081 ULM GERMANY Tel. +49 731 1754 0 Fax. +49 731 1754 6800 FCC listing no.: IC recognition no.: 94436 661AK-1 Tested devices/ accessories: PHONE RM-813 / Battery BL-5J / Charger AC-11E / Headset WH-102 FCC ID: PPIRM-813 IC: 661U-RM813 Supplement reports: Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), Public Notice DA 00-705, DTS procedures KDB 558074, IC standards RSS-GEN (Issue 2, June 2007) and RSS-210 (Issue 7, June 2007). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document. Date and signature for the contents: Hannu Söderholm, Senior Engineer, EMC FCC Part 15C Compliance Test Report / Template Version 12.0 FCC15C_RM-813_07.docx Copyright © TCC Nokia 2 (27) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 1. Summary for FCC Part 15C Compliance Test Report Date of receipt 03-Oct-2011 Testing completed 07-Oct-2011 The customer's contact person Bruno Ramelli Test Plan referred to T:\Projects\RM-813\TestPlan\RS_testplan_RM-813.xls Notes - Document name FCC15C_RM-813_07.docx 1.1. EUT and Accessory Information The EUT is a 8-band (GSM850/900/1800/1900 and WCDMA Band I/II(1900)/V(850)/VIII) mobile phone with GPRS, EGPRS, Bluetooth and WLAN. Bluetooth and WLAN are tested with maximum rated TX power. Product Type SN HW MV SW DUT Phone RM-813 004402136622077 0150 - Jc13.32 42687 Battery BL-5J - - - - 42688 Charger AC-11E - - - - 42689 Headset WH-102 - - - - 42691 1.2. Summary of Test Results Bluetooth: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8.4 (2) Conducted peak output power PASSED 15.247(d) A8.5 Band edge compliance of RF emissions - 15.247(d) A8.5 Spurious RF conducted emissions PASSED 15.247(d), 15.209 A8.5 Spurious radiated emissions - 15.207 7.2.2 AC powerline conducted emissions - 15.247(a)(1) A8.1 (a) 20 dB bandwidth PASSED 15.247(a)(1) A8.1 (b) Carrier frequency separation PASSED 15.247(a)(1)(iii) A8.1 (d) Number of hopping frequencies PASSED 15.247(a)(1)(iii) A8.1 (d) Time of occupancy PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Tampere Laboratory. FCC Part 15C Compliance Test Report / Template Version 12.0 FCC15C_RM-813_07.docx Copyright © TCC Nokia 3 (27) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 CONTENTS 1. Summary for FCC Part 15C Compliance Test Report .............................................. 2 1.1. EUT and Accessory Information ........................................................................................... 2 1.2. Summary of Test Results ..................................................................................................... 2 2. Test setups .................................................................................................................. 4 2.1. Conducted RF test setup ...................................................................................................... 4 2.2. AC powerline conducted emissions test setup ...................................................................... 4 2.3. Radiated test setup .............................................................................................................. 4 3. Conducted peak output power (FCC §15.247(b)(1), RSS-210 A8.4 (2)) ................... 5 3.1. Test method and limit ........................................................................................................... 5 3.2. Bluetooth Test results ........................................................................................................... 6 4. Spurious RF conducted emissions (FCC §15.247(d), RSS-A8.5) ............................ 9 4.1. Test method and limit ........................................................................................................... 9 4.2. Bluetooth Test results ......................................................................................................... 10 6. 20 dB bandwidth (FCC §15.247(a)(1), RSS-210 A8.1 (a)) ........................................ 13 6.1. Test method and limit ......................................................................................................... 13 6.2. Bluetooth Test results ......................................................................................................... 14 7. Carrier frequency separation (FCC §15.247(a)(1), RSS-210 A8.1 (b)) ................... 17 7.1. Test method and limit ......................................................................................................... 17 7.2. Bluetooth Test results ...............................…

Text truncated - open the document above for the full version.

Test Setup Photos

EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-813_19.docx Copyright © TCC Nokia 1 (3) RM-813 Test Setups Picture 1. FCC Part 15C Radiated emissions Picture 2. FCC Part 15B Radiated emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-813_19.docx Copyright © TCC Nokia 2 (3) Picture 3. FCC Part 15C AC powerline conducted emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-813_19.docx Copyright © TCC Nokia 3 (3) Picture 4. FCC Part 15B AC powerline conducted emissions from PC Charger Picture 5. FCC Part 15B AC powerline conducted emissions from Mobile Charger

Contact Information

Applicant

Hasnain Syed(Director, EMC, SI, and RF Compliance)

[email protected]425-707-1039Fax: 425-706-7329

Test Firm

TCC Microsoft SaloKalle Hannila

[email protected]358718008000Fax: 45-3329-2001

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	6.80 mW

Confidentiality

Long Term

Grant Notes

Power Output listed is conducted. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device contains WLAN and GSM/WCDMA transmitters.
