PRDRX11Wireless Receiver

WARNING WARNING USER GUIDE For product assistance & missing or replacement parts: WE CAN HELP THIS GUIDE CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. 1-888-516-2630 7 DAYS/WEEK 7:00am - 9:00pm CST Find more at Walmart.com HOGRY36017802_EN_October 18, 2025_V1 Wireless Silent 5-Button Mouse 2. INSTALLING RECEIVER AA Take out USB nano receiver. Insert it into available USB-A port. 8 Warranty Contact Manufacturer for Additional Information YEAR LIMITED WARRANTY COVERING DEFECTIVE PARTS 1 Specifications Dimensions 4.16 x 2.45 x 1.52 inch 10.5 x 6.2 x 3.8 cm Operating System Windows® 7/8/10/11 or later, MacOS 10.5 or later, Chrome OS Buttons 5 1011 ProblemCauseSolution/Prevention Mouse is not working The USB nano receiver is not plugged in tightly Battery placed in the wrong direction The USB port on computer may have an issue Try a dierent USB port. If the device is connected through a USB hub or extender, try plugging directly into the USB port of your laptop/PC. Ensure the USB nano receiver is pushed in all the way. Match + and - signs on battery to signs in battery compartment. Troubleshooting 4 Overview x 1 x 1 BATTERY COVER CONNECT SCROLL WHEEL MIDDLE BUTTON BACK FORWARD BUTTON RIGHT BUTTON LEFT BUTTON USB NANO RECEIVER ON/OFF SWITCH LED INDICATOR PULL TAB Operation, Setting Up Mouse x 1 x 1 x 1 x 1 AA 1. ACTIVATING BATTERY 2. Remove insulating pull tab. 1. Remove battery cover. Note: Replace batteries when low battery LED indicator blinks. 3. Insert 1 x AA battery. AA 7 2 Contents & Information CONTENTS & INFORMATION . . . . . . . . . . . . . . . . . . . . . 23 OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . .56 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Setting Up Mouse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-9 WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 HOGRY36017802 3 FEATURES • 5 Silent Clickable buttons, scroll wheel, and on/o switch • 1600 DPI sensitivity • 2.4GHz Wireless connection with USB nano receiver (stores in battery compartment when not in use) • Windows, MacOS, and ChromeOS compatible • USB Plug-and-play SCAN HERE FOR MORE PRODUCT INFORMATION AND LEAVE US A REVIEW! 5 FCC compliance statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. Safety Precautions - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Radiation Exposure Statement: The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. 6 AA 3. POWER ON Turn on power. Press Connect if device has lost connection. 9 For product assistance & missing or replacement parts: WE CAN HELP THIS GUIDE CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. 1-888-516-2630 7 DAYS/WEEK 7:00am - 9:00pm CST Find more at Walmart.com HOVAN36017802_EN_October 18, 2025_V1 Wireless Silent 5-Button Mouse 2. INSTALLING RECEIVER AA Take out USB nano receiver. Insert it into available USB-A port. 8 Warranty Contact Manufacturer for Additional Information YEAR LIMITED WARRANTY COVERING DEFECTIVE PARTS 1 Specifications Dimensions 4.16 x 2.45 x 1.52 inch 10.5 x 6.2 x 3.8 cm Operating System Windows® 7/8/10/11 or later, MacOS 10.5 or later, Chrome OS Buttons 5 1011 ProblemCauseSolution/Prevention Mouse is not working The USB nano receiver is not plugged in tightly Battery placed in the wrong direction The USB port on computer may have an issue Try a dierent USB port. If the device is connected through a USB hub or extender, try plugging directly into the USB port of your laptop/PC. Ensure the USB nano receiver is pushed in all the way. Match + and - signs on battery to signs in battery compartment. Troubleshooting 4 Overview x 1 x 1 BATTERY COVER CONNECT SCROLL WHEEL MIDDLE BUTTON BACK FORWARD BUTTON RIGHT BUTTON LEFT BUTTON USB NANO RECEIVER ON/OFF SWITCH LED INDICATOR PULL TAB Operation, Setting Up Mouse x 1 x 1 x 1 x 1 AA 1. ACTIVATING BATTERY 2. Remove insulating pull tab. 1. Remove battery cover. Note: Replace batteries when lo…

Text truncated - open the document above for the full version.

Acrox Technologies Co., Ltd. Covered Equipment Certification Attestation Letter 4/1/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: PRDRX11 Acrox Technologies Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Acrox Technologies Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Acrox Technologies Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Gavin Hsieh Title: Product Manager Company Name: Acrox Technologies Co., Ltd. Date: 4/1/2026

Acrox Technologies Co., Ltd. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 4/1/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: PRDRX11 FRN of applicant: 0018333633 Per section 2.911(d)(7) of the FCC rules, Acrox Technologies Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: 1PerfectChoice, Inc. FCC Registration Number (FRN): 0033429309 Physical U.S. Company Address: 21908 Valley Blvd., Walnut, CA 91789 Contact Person: Choon Kek Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different from Applicant): Signed: Signed: Printed name: Gavin Hsieh Printed name: Choon Kek Title: Product Manager Title: Chief Operating Officer Company Name: Acrox Technologies Co., Ltd. Company Name: 1PerfectChoice, Inc. Date: 4/1/2026 Date: 4/1/2026

DATE : 4/1/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint EST Technology Co., Ltd. Address:Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Acrox Technologies Co., Ltd. Address:4F., No.89, Minshan St., Neihu Dist., Taipei City 114, Taiwan <Signature> Name：Gavin Hsieh Title：Product Manager Applicant Company：Acrox Technologies Co., Ltd.

DATE : 4/1/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name：Gavin Hsieh Title：Product Manager Company：Acrox Technologies Co., Ltd.

DATE : 4/1/2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: PRDRX11 Product Name: Wireless Receiver Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name：Gavin Hsieh Title：Product Manager Company：Acrox Technologies Co., Ltd.

External Photos M/N: MXI External Photos M/N: MXI External Photos M/N: MXI

Internal Photos M/N: MXI Internal Photos M/N: MXI PCB Antenna

Page 1 of 3 Report No. ESTE-R2603291 FCC RF EXPOSURE REPORT Acrox Technologies Co., Ltd. Wireless Receiver Model Number: MXI FCC ID: PRDRX11 Applicant: Acrox Technologies Co., Ltd. Address: 4F., No.89, Minshan St., Neihu Dist., Taipei City 114, Taiwan Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2603291 Date of Test: Mar. 05, 2026 to Mar. 13, 2026 Date of Report: Mar. 23, 2026 Page 2 of 3 Report No. ESTE-R2603291 1. Applicable Standards FCC Part 2(Section 2.1093) FCC KDB 447498 D04 Interim General RF Exposure Guidance v01 2. Exposure Evaluation of Portable or Mobile Devices Human exposure to RF emissions from portable devices (47 CFR §2.1093), as defined by the FCC, must be evaluated with respect to the FCC-adopted limits for SAR. Evaluation of mobile devices, as defined by the FCC, may also be performed with respect to SAR limits, but in such cases it is usually simpler and more cost-effective to evaluate compliance with respect to field strength or power density limits. For certain devices that are designed to be used in both mobile and portable configurations similar to those described in 47 CFR §2.1091(d)(4), such as certain desktop phones and wireless modem modules, compliance for mobile configurations is also satisfied when the same device is evaluated for SAR compliance in portable configurations. The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 300 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Page 3 of 3 Report No. ESTE-R2603291 3. Evaluation Results For 2.4G SRD Field strength =71.86dBuV/m@3m P={ [10 (71.86/20) /10 6 *3] 2 /30 }*1000mW =0.0046mW< 2.72mW 1. Limited= 3060*(0.5/20)^(- (where f is in GHz); 2. We choose 2.480GHz to calculate limit as lower frequency will have higher limits. End of Test Report

Page 1 of 52 Report No.ESTE-R2603290 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of Acrox Technologies Co., Ltd. Wireless Receiver Model Number: MXI FCC ID: PRDRX11 Applicant: Acrox Technologies Co., Ltd. Address: 4F., No.89, Minshan St., Neihu Dist., Taipei City 114, Taiwan Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2603290 Date of Test: Mar. 05, 2026 to Mar. 13, 2026 Date of Report: Mar. 23, 2026 Page 2 of 52 Report No.ESTE-R2603290 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION .......................................................................................................... 3 1. GENERAL INFORMATION ................................................................................................................ 5 1.1. Description of Device (EUT) ......................................................................................................... 5 1.2. Antenna Information ...................................................................................................................... 5 1.3. Information of RF Cable ................................................................................................................ 5 2. SUMMARY OF TEST ........................................................................................................................ 6 2.1. Summary of test result .................................................................................................................. 6 2.2. Test Facilities .................................................................................................................................. 7 2.3. Measurement uncertainty ............................................................................................................. 8 2.4. Assistant equipment used for test ............................................................................................... 8 2.5. Block Diagram ................................................................................................................................ 8 2.6. Test Mode ....................................................................................................................................... 9 2.7. Power Setting of Test Software ................................................................................................... 9 2.8. Channel List .................................................................................................................................... 9 2.9. Test Equipment List ..................................................................................................................... 10 3. FIELD STRENGTH OF FUNDAMENTAL .......................................................................................... 12 3.1. Limit ................................................................................................................................................ 12 3.2. Test Setup ..................................................................................................................................... 12 3.3. Spectrum Analyzer Setting ......................................................................................................... 12 3.4. Test Procedure ............................................................................................................................. 13 3.5. Test Result .................................................................................................................................... 14 4. RADIATED SPURIOUS EMISSIONS AND BAND EDGE ................................................................... 21 4.1. Limit ................................................................................................................................................ 21 4.2. Test Setup ..................................................................................................................................... 23 4.3. Spectrum Analyzer Setting ......................................................................................................... 24 4.4. Test Procedure ............................................................................................................................. 25 4.5. Test Result .................................................................................................................................... 26 5. 20DB BANDWIDTH ....................................................................................................................... 38 5.1. Limit ................................................................................................................................................ 38 5.2. Test Setup ..................................................................................................................................... 38 5.3. Spectrum Analyzer Setting ......................................................................................................... 38 5.4. Test Procedure ............................................................................................................................. 38 5.5. Test Condition .............................................................................................................................. 39 5.6. Test Result .................................................................................................................................... 39 6. AC POWER LINE CONDUCTED EMISSIONS ................................................................................. 41 6.1. Limit ................................................................................................................................................ 41 6.2. Test Setup ..................................................................................................................................... 41 6.3. Spectrum An…

Text truncated - open the document above for the full version.

Dongle Antenna Specification Antenna overview 1. Antenna Type and Model: Type: PCB Antenna Model: PIFA Antenna 2．Gain: about 3.36dBi (peak) 3. Antenna Directivity Coefficient: about -1 @2450MHz 4. Antenna Polarization characteristic: elliptical polarization 5. Inside or outside: Inside 6. Name of Manufacturer: Shenzhen Bailihe Technology Co., LTD(深圳市百里和科技有限公司) 7. Name of Laboratory: Shenzhen Bailihe Technology Co., LTD (深圳市百里和科技有限公司) Dongle PIFA Antenna The Dongle antenna adopts the ultra-small PIFA antenna, and because of the limited area of PCB, the gain of antenna will be smaller than that of the other antennas. The communication distance can reach about 15 ~ 20 meters. The size of the Dongle Module PCB antenna is 8.8 * 3.0mm, and the thickness of PCB is 1mm.The specific size of the antenna is shown in figure 1, the physical object is shown in figure 2. Figure 1 :Dongle Antenna Figure 2 :Dongle Antenna The antenna's S11 test data is shown in figure 3, covering the entire 2.4 G frequency band. Figure 3 Dongle Antenna S11 Figure 4 Dongle Antenna S11 The gain simulation data of the antenna is shown in figure 4 Number Brand Valu e R2 Yageo 0.5pF C3 NC C4 NC Channel List-2.4G(MHz) 2402 2404 2406 2408 2410 2412 2414 2416 2418 2420 2422 2424 2426 2428 2430 2432 2434 2436 2438 2440 2442 2444 2446 2448 2450 2452 2454 2456 2458 2460 2462 2464 2466 2468 2470 2472 2474 2476 2478 2480 ANNEX A TEST RESULTS A.1 Gain and Efficiency Frequency Gain (dBi) Efficiency (%) 2400MHz 3.22 57 2410MHz 3.14 58 2420MHz 3.08 57 2430MHz 3.27 56 2440MHz 3.29 56 2450MHz 3.36 56 2460MHz 3.10 54 2470MHz 2.87 53 2480MHz 2.96 54 2490MHz 2.89 53 2500MHz 2.45 52 1D Radiation Pattern PHI=0 PHI=90 THETA=90 ANNEX B RADIATION PATTERN B.1 3D Pattern B1.1 3D Pattern for 2400MHz B1.2 3D Pattern for 2450MHz B1.3 3D Pattern for 2500MHz

Conducted Emissions Test Radiated Test (30-1000 MHz) Radiated Test (Above 1GHz)
