PRTWP-D801Table Terminal

1 A3400789A Table Terminal ････WP-D801E Cradle･･･････････WP-C801E Holder Cradle･････WP-C822E Table Top Order System User's manual Rev.20150213_R2 Importer: Global Network Resources, Inc. Address: 2241 Calle de Luna, Santa Clara, CA 95054 2 Chapter 1. Terminal switch operation When the condition of the Terminal is not good, it may be improved by ON/OFF of the power switch. [Example] which needs operation of power switch. • The Terminal doesn't start working. • Pictures on the Terminal doesn't change, even if check-in/-out is operated. • Terminal doesn't accept touch operation, so can't order. (It seems like “hung-up”.) • Even if "Clear Error" is operated by MIS, Error display doesn't go off. (communication error) Note: Please do not operate power switch as much as possible, except trouble shooting. Power switch is in the hole of the diameter 2mm on the terminal left side. Please don’t use except when dealing with trouble. Please use Special Reset Pin to operate Power Switch. Power switch A3400789A Special Reset Pin 3 Chapter 2. Details of the front lower left side lamp Two LED lamp Description (Left and Right) •Left LED Blink Slow (1sec)... Charging. (Need to be placed on Cradle.) Blink Fast (0.5sec)...Detecting Charge Error. (Need to be placed on Cradle.) Unlight ............... Not Charging (Charge completed / Not placed on Cradle) •Right LED Light ......... Power On, and Placed on Cradle. Blink ......... Power On, but Not Placed on Cradle. Unlight ...... Power Off Color ......... Connection state of WLAN . Green ......... Connecting on Good Condition. Amber......... Connecting, but not so Good. Red ............ Disconnecting WLAN. Note: WLAN does not work until you select “Operational mode”. Please refer to next page for more information. A3400789A 4 Chapter 3. After start-up mode selection Cradle Cradle WP-C801E (Desktop type) Holder Cradle WP-C822E (Wall-mount type) When put on the cradle, the terminal will start charging automatically. (1) Please wait until this screen appears when you turn on the power switch. Then you can choose "Setting mode“, "Training mode" and "Operation mode". (2) When you choose "Setting mode", you can adjust “volume tune”, “brightness” or other condition of the terminal. (3) When you choose "Training mode", the menu can be operated as a stand-alone terminal demo. WLAN does not working in this mode. (4) When you choose “Operational mode”, the terminal will start working in actual system environment with WLAN. (5) Please note that the system will not work without actual WLAN system environment in “Operation mode”. These cradles were designed for safety, the output voltage from electronic pin will be supplied only when the terminal is put on it . A3400789A 5 Chapter 4. Products Specifications Table Terminal Model: WP-D801E Dimension: 267mm(W)×184mm(H)×16.5mm(D) Weight: 750g Display: 10.1 WSVGA 1024×600 (200cd/m2) Horizontal: 45°45° Vertical: 20°45° WiFi : IEEE-802.11b & g Power: DC12V, 10W or less power consumption form built-in battery Built-in battery: 6hours, (At the lowest brightness setting) Charging method: Charging by dedicated cradle, DC input from AC adapter. Touch screen: Projective Capacitive（multi-touch） OS: LINUX 2.6.32 Wireless device (Inside Table Terminal) ・Operational frequency: 2412 to 2462 MHz (5MHz step, 11 channels) ・IEEE802.11 b/g compliant Wireless LAN ・Data rate IEEE802.11b: 1, 2, 5.5 and 11 Mbps IEEE802.11g: 6, 9, 12, 18, 24, 36, 48 and 54 Mbps Cradle Model: OST Cradle (WP-C801E) and OSH Cradle(WP-C822E) Input/Output voltage: DC 12V 2A Battery Model: 6010459AY Classification of the battery: Lithium Pllymer Battery Rated voltage: 7.4V Capacity: Typical 3900mA Battery Type: 6010459AY Manufacturers: SPRINGPOWER TECHNOLOGY(SHENZHEN)LIMITED A3400789A 6 Chapter 5. Operating Considerations (§2.1077(a)(1)) Company: Worldpicom Corporation Model name: Table Terminal Model number: WP-D801E FCC ID: PRTWP-D801 (§2.1077(a)(3), §2.909) Subsidiary of the U.S. information: Global Network Resources, Inc. Address: 2241 Calle de Luna, Santa Clara, CA 95054 Phone: 408.727.1900 / Fax: 408.727.1910 (§15.21) Notice: The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. (§15.105) FCC INFORMATION The Federal Communication Commission Radio Frequency Interference Statement includes the following paragraph: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. The user should not modify or change this equipment without written approval form Worldpicom Corporation. Modification could void authority to use this equipment. This device complies with part 15 of the FCC Rules. Operation is subject…
