PVB-EMDE045Aura ANC

Aur ANC Quick Start Guide Guide De Démarrage Rapide Guí De Inicio Rápido Guid Di Riferimento Rapido Kurzanleitung Snelstartgids 盠ഠֵአ藯ก ꠕꌭ겑녆閵넩麑 More than 30%: LED off Low battery: flashing once/5S Aura ANC 6 1 4 2 5 3 L R 2x3x 1x 1.5s 2x 1.5s 1x 3x R L 2x 2x 3s Mono Mode Re-Pairing Mode Mono / Modo monoaural / Modalità Mono / Mono-Modus / Mono-modus / 㻌肨螇秇ୗ / ꑝ鬭ꩡ끞 Réappariement / Reemparejar / Riparazione / Neu koppeln / Opnieuw koppelen / /᯿碝蟴੒녡뵍꽩ꍶ LR 2x 3s 2x 3x 2x 1x 2x 3s 2x 2x 1x 3x 2s White LED on earbuds blinks twice when press case button for 2s (case open) La LED blanche des écouteurs clignote deux fois lorsque vous appuyez sur le bouton du étui pendant 2 secondes (étui ouvert) El LED blanco de los auriculares parpadea dos veces al presionar el botón del estuche durante 2 segundos (estuche abierto) Il LED bianco degli auricolari lampeggia due volte quando si preme il pulsante del case per 2 secondi (case aperto) Die weiße LED an den Kopfhörern blinkt zweimal, wenn die Taste am Case 2 Sekunden gedrückt wird (Case geöffnet) De witte LED op de oordopjes knippert twee keer wanneer u de knop op de case 2 seconden ingedrukt houdt (case open) ಑୏獅ኪፋ෸牧ೲ֘ፋӤೲᰵ ᑁ牧肊๢ጮᜋ/('ᳬᅮӷ稞 뢵넩걙꘹뱱냹뚽閹鮹ꌩꐩ 넩꽩꘹麑넍섥ꩾ/('閵鸅꘽ 頑ꠖ넺鱽鲙 뢵넩걙꾩ꍱꩶ몑 Reset Réinitialisation / Restablecer / Ripristino / Zurücksetzen / Resetten / /᯿ᗝ뚽韥쀉 5s White LED on earbuds blinks three times when press case button for 5s (case open) La LED blanche des écouteurs clignote trois fois quand on appuie sur le bouton du boîtier pendant 5 secondes (boîtier ouvert) El LED blanco de los auriculares parpadea tres veces al presionar el botón del estuche durante 5 segundos (estuche abierto). Il LED bianco degli auricolari lampeggia tre volte quando si preme il pulsante del case per 5 secondi (case aperto). Die weiße LED an den Kopfhörern blinkt dreimal, wenn die Taste am Case 5 Sekunden gedrückt wird (Case geöffnet). De witte LED op de oordopjes knippert drie keer als u de knop van de case 5 seconden ingedrukt houdt (case open). ಑୏شኪፋ෸牧ೲ֘ፋӤೲᰵ ꕾ牧肊๢ጮᜋ/('ᳬᅮӣེ 뢵넩걙꘹뱱냹뚽閹鮹ꌩꐩ 넩꽩꘹麑넍섥ꩾ/('閵ꫭ꘽ 頑ꠖ넺鱽鲙 뢵넩걙꾩ꍱꩶ몑 No Case On/Off 8s 3s L R Pas de boîtier activé/désactivé / Sin funda (activada/desactivada) / Nessuna custodia attivabile/disattivabile / Kein Gehäuse Ein/Aus / Geen hoesje aan/uit / /෫賯୏ى뢵넩걙꽻넁룑뎅顱뎅 1. Initial Set Up & Pairing: • Open Case. • Remove earbuds and remove paper film from the bottom. • Place earbuds back into charging case and leave closed for 15 minutes before first pair. • Remove earbuds from the charging case and they will automatically go into pairing mode indicated by the flashing white LED on one of the earbuds. • Select “Aura ANC” from your device’s Bluetooth ® menu. • Once paired, simply removing earbuds from the case will automatically pair to your device 2. Re-pairing: Open the case, put earbuds into case, then press button on case for 2s, white LED on earbuds blinks twice, then start to charge. Take earbuds out from case, it’s pairing mode. 3. Reset: Open the case, put earbuds into case, then press button on case for 5s, white LED on earbuds blinks for 3 times, reset successfully. ___________________________________ 1. Installation initiale et appairage: • Ouvrez l’étui. • Retirez les écouteurs et ôtez le film papier au fond de l’étui. • Retirez les écouteurs de l’étui de chargement et ils passeront automatiquement en mode appairage, indiqué par la LED blanche clignotante sur l’un des écouteurs. • Retirez les écouteurs de l’étui de charge; ils passent alors automatiquement en mode d’appairage, comme l’indiqué par la LED blanche clignotante sur l’un des écouteurs. • Sélectionnez « Aura ANC » dans le menu Bluetooth® de votre appareil. • Une fois l’appairage initial effectué, il suffit de sortir les écouteurs de l’étui pour qu’ils soient automatiquement appairés à votre appareil. 2. Réappariement : Ouvrez l’étui, placez les écouteurs dans l’étui, puis appuyez sur le bouton de l’étui pendant 2 secondes. Le LED blanc des écouteurs clignote deux fois, puis commence à charger. Sortez les écouteurs de l’étui, ils sont en mode d’appariement. 3. Réinitialisation : Ouvrez l’étui, placez les écouteurs dans l’étui, puis appuyez sur le bouton de l’étui pendant 5 secondes. Le LED blanc des écouteurs clignote trois fois, la réinitialisation est réussie. ___________________________________ 1. Configuración inicial y acoplamiento: • Abra el estuche. • Saque los audífonos y retire la tira de papel del fondo. • Vuelva a colocar los audífonos en el estuche de carga y déjelo cerrado durante 15 minutos antes del primer acoplamiento. • Retire los auriculares del estuche de carga y entrarán automáticamente en modo de emparejamiento, lo que se indica mediante el LED blanco intermitente en uno de los auriculares. • Seleccione “Aura ANC” en el menú Bluetooth ® de su dispositivo. • Una vez acoplados, con solo sacar los audífonos del estuche, éstos se acoplarán a su dispositivo 2. Reemparejar: Abre el estuche, coloca los auriculares dentro, luego presiona el botón del estuche durante 2 segundos. El LED blanco de los auriculares parpadea dos veces y comienza a cargar. Saca los auriculares del estuche, estarán en modo de emparejamiento. 3. Restablecer: Abre el estuche, coloca los auriculares dentro, luego presiona el botón del estuche durante 5 segundos. El LED blanco de los auriculares parpadea tres veces, el restablecimiento se ha completado con éxito. ___________________________________ 1. Impostazione iniziale e collegamento: • Aprire la scatola. • Estrarre gli auricolari e rimuovere la pellicola di carta dal fondo. • Rimettere gli auricolari nella scatola di carica e lasciarla chiusa per 15 minuti prima del collegamento iniziale. • Estrarre gli auricolari dalla custodia di ricarica: entreranno automaticamente in modalità di abbinamento, indicata dal LED bianco lampeggiante su uno degli auricolari. • Selezionare “Aura ANC” dal menu Bluetooth® del dispositivo. • Una volta completato l’accoppiamento, basta estrarre gli auric…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 1 of 11 Appendix External Photos for GZCR2601000228AT Test Model No.: EM-DE045 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 2 of 11 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 3 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 4 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 5 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 6 of 11 Left earbud SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 7 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 8 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 9 of 11 Right earbud SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 10 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 11 of 11 - End of the Appendix -

14.5mm Designed by House of Marley Madein China Model:EM-DE045 Input:5V 500mA Aura ANC Battery:500mAh 0.185Wh FCCID:PVB-EMDE045 Tonbridge TN11 OGP, UK 29 Earlsfort Terrace, Dublin D02AY28, Ireland IC:10613A-EMD045 0626 Model:EM-DE045 Input:5V 500mA Aura ANC Battery:500mAh 0.185Wh FCCID:PVB-EMDE045 Tonbridge TN11 OGP, UK 29 Earlsfort Terrace, Dublin D02AY28, Ireland IC:10613A-EMD045 Designed by House of Marley Madein China 0626 14.5x8.9mm 15.6x11mm

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 1 of 8 Appendix Internal Photos for GZCR2601000228AT Test Model No.: EM-DE045 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 2 of 8 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 3 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 4 of 8 Left earbud SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 5 of 8 BT ANT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 6 of 8 Right earbud SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 7 of 8 BT ANT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 8 of 8 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR260100022804 Page: 1 of 8 FCC ID: PVB-EMDE045 RF EXPOSURE EVALUATION REPORT Application No.: GZCR2601000228AT Applicant:The House of Marley.LLC Address of Applicant:3000 Pontiac Trail, Commerce Township, Michigan 48390 United States Manufacturer:The House of Marley.LLC Address of Manufacturer:3000 Pontiac Trail, Commerce Township, Michigan 48390 United States Factory:Huizhou Gotek Electronics Co., Ltd Address of Factory:1701, Building 1, Xunyang Technology Park 2nd Phase, Chayuan Village, Qiuchang Street, Huiyang District, Huizhou, Guangdong Sheng, China Product Name:Aura ANC Model No.: EM-DE045 Trade Mark:MARLEY Standard(s) : KDB 447498 D01 V06 Date of Receipt: 2026-01-26 Date of Evaluation: 2026-03-16 to 2026-03-16 Date of Issue: 2026-03-19 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR260100022804 Page: 2 of 8 Revision Record VersionReport No.DateRemark 01GZCR2601000228042026-03-19Original Authorized for issue by: Pank Feng/Project Engineer Approved By Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR260100022804 Page: 3 of 8 2Evaluation Summary ItemStandardMethodRequirementResult RF Exposure KDB 447498 D01 V06 KDB 447498 D01 V06KDB 447498 D01 V06Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR260100022804 Page: 4 of 8 3Contents Page 1Cover Page...............................................................................................................................................1 2Evaluation Summary................................................................................................................................3 3Contents....................................................................................................................................................4 4General Information.................................................................................................................................5 4.1Details of E.U.T.................................................................................................................................5 4.2Evaluating Location...........................................................................................................................5 4.3Facility...............................................................................................................................................6 4.4Deviation from Standards..................................................................................................................6 4.5Abnormalities from Standard Conditions...........................................................................................6 5Technical Requirements Specification..................................................................................................7 5.1General Description of Applied Standards........................................................................................7 5.2RF Exposure Evaluation....................................................................................................................7 5.2.1Limit & Test Method......................................................................................................................7 5.2.2Conclusion....................................................................................................................................7 6EUT Constructional Details (EUT Photos).............................................................................................9 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR260100022804 Page: 5 of 8 4General Information 4.1Details of E.U.T. Power supply:Powered by built-in battery as below and charged by charging case for earbuds: Model: 1040 Rate: DC 3.85V, 35mAh, 0.135Wh Powered by built-in battery as below for charging case without any RF function: Model: 851634 Rate: DC 3.7V, 500mAh, 1.85Wh DC 5V for charging Cable(s):USB cable: about 0.4 unshielded Minimum Internal Source: 32MHz RF Parameter: Please refer to test report GZCR260100022802 for BT details Please refer to test report GZCR260100022803 for BLE details Remark: The information in this section is provided by the applicant or manufacturer, SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. 4.2Evaluating Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Guangzhou Branch EMC Laboratory, No.198, Kezhu Road, Science City, Economic & Technological Development Area, Guangzhou, Guangdong, China 510663 Tel: +86 20 82155555 No tests were sub-contracted. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR260100022804 Page: 6 of 8 4.3Facility The facility is recognized, certified, or accredited by the following organizations: ● ACMA SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory can also perform testing for the Australian/New Zealand Regulatory Compliance Mark (RCM). ● SGS UK(Certificate No.: 32), SGS-TUV SAARLAND and SGS-FIMKO Have approved SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory as a supplier of EMC TESTING SERVICES and SAFETY TESTING SERVICES. ● FCC Recognized Accredited Test Firm(Registration No.: 486818) SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory has been accredited and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter fr…

Text truncated - open the document above for the full version.

2.4GHz2012ChipAntenna:RANT2012F245C07 Dimension(mm) L2.05+-0.10 W1.20+-0.10 T0.65+-0.10 No.TerminalName 1Feeding/GNG 2GND Application: WLAN,802.11b/g,Bluetooth,WLAN,etc... Features SMD,highreliability,ultraImpact,Omni-directional... PartnumberInformation RANT2012F245C07 (A)(B)(C)(D)(E)(F) (A)ProductTypeChipAntenna (B)SizeCode2.0x1.2mm(+-0.2mm) (C)MaterialHighKmaterial (D)Frequency2.4~2.5GHz (E)FeedingmodePIFA&SingleFeeding (F)AntennatypeType=07 ElectricalSpecification WorkingFrequencyRange2400~2484MHz Bandwidth84(Min.) PeakGain1.7dBi(Typ.) Impedance50Ohm Returnloss10dB(Min) PolarizationLinear AzimuthBeamwidthOmni-directional OperationTemperature( °C )-40~85 °C ResistancetoSolderingHeats 10sec.(@280°C) TerminationNi/Au(Leadless) ThespecificationisdefinedonEVB. DimensionandTerminalConfiguration 咏成國際科技有限公司電話:13530576606 RAINInternationalTechnologyCo.,Ltd. 7/F,BuildingF,ZhichuangPark,Tong'an,Gushu,Shenzhen 2.4GHz2012ChipAntenna:RANT2012F245C07 EvaluationBoardReference PCBDimensionAntennaLayoutReferenceUnit:mm ElectricalCharacteristics ReturnLoss ReturnLoss&Radiation 1 Frequency(MHz) S11(dB) 2400-10.77 2450-24.81 2484-10.243 Radiation Z Y X 2400MHz2450MHz2500MHz Efficiency70.56%75.25%71.01% 2.4GHz2012ChipAntenna:RANT2012F245C07 TapingSpecifications ReelandTapingSpecification ReelSpecification TYPESIZEABCD 20127”5K/Reel 9.0±0.5 60±213.5±0.5178±2 TappingSpecification PackagingTypeABWEFGHTDP PaperType2012 1.50±0.202.30±0.208.0±0.201.75±0.103.5±0.054.0±0.102.0±0.050.75±0.101.57±0.104.0±0.1 2.4GHz2012ChipAntenna:RANT2012F245C07 ReliabilityTable TestItemProcedure Requirements CeramicType Remark (Reference) Electrical Characterization Fulfilltheelectrical specification UserSpec. Thermal Shock 1.Preconditioning: 50±10°C/1hr,thenkeepfor24±1hrsatroomtemp. 2.Initialmeasure:Spec:referInitialspec. 3.Rapidchangeoftemperaturetest: -30°Cto+85°C;100cycles; 15minutesatLowercategorytemperature; 15minutesatUppercategorytemperature. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 107 Temperature Cycling 1.Initialmeasure:Spec:referInitialspec. 2.100Cycles(-30°Cto+85°C),SoakMode=1(2Cycle/hours). 3.Measurementat24±2Hoursaftertestcondition. NoVisibleDamage. Fulfilltheelectrical specification. JESD22 JA104 HighTemperature Exposure 1.Initialmeasure:Spec:referInitialspec. 2.Unpowered;500hours@T=+85°C. 3.Measurementat24±2hoursaftertest. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 108 LowTemperature Storage 1.Initialmeasure:Spec:referInitialspec. 2.Unpowered:500hours@T=-30°C. 3.Measurementat24±2hoursaftertest. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 108 Solderability (SMDBottomSide) Dippingmethod: a.Temperature:235±5°C b.Dippingtime:3±0.5s Thesoldershouldcover over95%ofthecritical areaofbottomside. IEC60384-21/22 4.10 SolderingHeat Resistance (RSH) Preheatingtemperature:150±10°C. Preheatingtime:1~2min. Soldertemperature:260±5°C. Dippingtime:5±0.5s NoVisibleDamage.IEC60384-21/22 4.10 Vibration5g'sfor20min.,12cycleseachof3orientations Note:Use8"X5"PCB.031"thick7securepointson,onelong sideand2securepointsatcornersofoppositesides.Parts mountedwithin2"fromanysecurepoint.Testfrom10-2000 Hz. NoVisibleDamage.MIL-STD-202 Method204 Mechanical Shock Threeshocksineachdirectionshallbeappliedalongthethree mutuallyperpendicularaxesofthetestspecimen(18shocks) Peakvalue:1,500g’s Duration:0.5ms Velocitychange:15.4ft/s Waveform:Half-sine NoVisibleDamage.MIL-STD-202 Method213 Humidity Bias 1.Humidity:85%R.H.,Temperature:85±2°C. 2.Time:500±24hours. 3.Measurementat24±2hrsaftertestcondition. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 Method106 2.4GHz2012ChipAntenna:RANT2012F245C07 2.4GHz2012ChipAntenna:RANT2012F245C07 _ Board Flex (SMD) 1.Mountingmethod: IR-Reflow.PCBSize(L:100×W:40×T:1.6mm) 2.Applytheloadindirectionofthearrowuntilbendingreaches 2mm. NoVisibleDamage.AEC-Q200 005 AdhesionForceof1.8Kgfor60seconds.NoVisibleDamage Magnificationof20Xor greatermaybeemployed forinspectionofthe mechanicalintegrityofthe devicebodyterminalsand body/terminaljunction. AEC-Q200 006 Physical Dimension Anyapplicablemethodusingx10magnification,micrometers, calipers,gauges,contourprojectors,orothermeasuring equipment,capableofdeterminingtheactualspecimen dimensions. Inaccordancewith specification. JESD22 JB100 RevisionHistory RevisionDateContent 12020/10/15NewDatasheet

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.: GZCR260100022802 Page: 1 of 87 FCC ID: PVB-EMDE045 TEST REPORT Application No.: GZCR2601000228AT Applicant: The House of Marley.LLC Address of Applicant: 3000 Pontiac Trail, Commerce Township, Michigan 48390 United States Manufacturer: The House of Marley.LLC Address of Manufacturer: 3000 Pontiac Trail, Commerce Township, Michigan 48390 United States Factory: Huizhou Gotek Electronics Co., Ltd Address of Factory: 1701, Building 1, Xunyang Technology Park 2nd Phase, Chayuan Village, Qiuchang Street, Huiyang District, Huizhou, Guangdong Sheng, China Product Name: Aura ANC Model No.: EM-DE045 Trade Mark: MARLEY Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2026-01-26 Date of Test: 2026-02-25 to 2026-03-16 Date of Issue: 2026-06-09 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.: GZCR260100022802 Page: 2 of 87 Revision Record Version Report No. Date Remark 01 GZCR260100022802 2026-06-09 Original Authorized for issue by: Pank Feng/Project Engineer Approved By Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.: GZCR260100022802 Page: 3 of 87 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence N/A 47 CFR Part 15, Subpart C 15.247(a)(1),(g),(h) Pass N/A: Not applicable Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2020) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2020) Section 6.10.5 & 7.8.8 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2020) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2020) Section 6.6 & 7.8.8 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Maximum Conducted Output Power ANSI C63.10 (2020) Section 7.8.5 47 CFR Part 15, Subpart C 15.247(b)(1) Pass 20dB Bandwidth ANSI C63.10 (2020) Section 6.9.2 47 CFR Part 15, Subpart C 15.247(a)(1) Pass Carrier Frequencies Separation ANSI C63.10 (2020) Section 7.8.2 47 CFR Part 15, Subpart C 15.247a(1) Pass Hopping Channel Number ANSI C63.10 (2020) Section 7.8.3 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Dwell Time ANSI C63.10 (2020) Section 7.8.4 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Conducted Band Edges Measurement ANSI C63.10 (2020) Section 7.8.7.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2020) Section 7.8.7 47 CFR Part 15, Subpart C 15.247(d) Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.: GZCR260100022802 Page: 4 of 87 3 Contents Page 1 Cover Page ................................................................................................................................................. 1 2 Test Summary ............................................................................................................................................ 3 3 Contents ..................................................................................................................................................... 4 4 General Information ................................................................................................................................... 6 4.1 Details of E.U.T. .................................................................................................................................. 6 4.2 Description of Support Units ............................................................................................................... 6 4.3 Measurement Uncertainty ................................................................................................................... 7 4.4 Test Location ....................................................................................................................................... 7 4.5 Test Facility ......................................................................................................................................... 8 4.6 Deviation from Standards .................................................................................................................... 8 4.7 Abnormalities from Standard Conditions ............................................................................................ 8 5 Equipment List ........................................................................................................................................... 9 6 Radio Spectrum Technical Requirement .............................................................................................. 12 6.1 Antenna Requirement ....................................................................................................................... 12 6.1.1 Test Requirement: ........................................................................................................................ 12 6.1.2 Conclusion .................................................................................................................................... 12 6.2 Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence................. 13 6.2.1 Test Requirement: ..................................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 1 of 3 Appendix Test Setup Photo for GZCR260100022802 & GZCR260100022803 Test Model No.: EM-DE045 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 3 of 3 Radiated Emissions which fall in the restricted bands & Radiated Spurious Emissions Above 1GHz Radiated Spurious Emissions Below 1GHz - End of the Appendix -
