PVBEMDA001RGBluetooth Speaker

One Foundation Digital Audio System Product Name: Bluetooth Speaker Model: EM-DA001-RG Welcome to the House of Marley We are honored you have selected One Foundation to become part of your music experience. The One Foundation is a two-way, stereo sound system which works with Bluetooth® devices connected wirelessly and hundreds of other devices via the auxiliary, digital, or analog inputs. One Foundation fuses striking aesthetics with a powerful audio engine and brings realism and detail to your music collection. High-definition, long-throw, wood-fiber impregnated, 5.25-inch woofers in a tuned, bass-reflex enclosure, Danish designed 1-inch tweeters and over 200 watts come together in this beautifully engineered work of sonic beauty. Everything You Need One Foundation comes with the following items: • Sound System [Ill. 1] • Remote [Ill. 2] • Power Cord for Wall Outlet [Ill. 3] • 3.5mm Stereo Cable [Ill. 4] Powering One Foundation Your One Foundation uses a built-in, 100-120 VAC 50/60Hz or 220-240 VAC 50/60Hz 200W (depending on the country where the product was purchased) power supply and is powered by a standard wall outlet. 1. Insert the AC power cord into One Foundation. [Ill. 5] 2. Insert wall plug into an appropriate wall outlet. [Ill. 6] Inputs/Output One Foundation uses automatic signal detection and will only access the inputs from devices that are plugged into the audio system. One Foundation will automatically revert to the last used input when powered “On”. [ILLUSTRATION OF REAR INPUT PANEL – Ill. 7] - [WHITE CIRCLE] RCA Analog Input: For use with analog sources. - Pre-Out: Recommended for use with active subwoofer (not included). See Fig. # for using One Foundation with a subwoofer. - [RED CIRCLE] Digital Audio (Optical) Input: Recommended for use with digital peripherals. Peripheral must be connected and turned on in order to cycle to this input. - [BLUE CIRCLE] Bluetooth Pairing Button: This mode can also be initiated by pressing and holding the [INPUT] button on the remote. [ILLUSTRATION OF SIDE PANEL] - [GREEN] 3.5mm Auxiliary Input: This input will be triggered automatically when a 3.5mm auxiliary cable (included) is plugged into One Foundation. - USB-A Port: 2.1A Charging Port Easy To Use [ILLUSTRATION OF ROTARY DIAL – Ill. 8] One Foundation uses one convenient control dial to operate power, volume, and input selection. - Press the control dial once to turn One Foundation on - Press the control dial again while One Foundation is on to cycle through active inputs - Turn the control dial to adjust volume - Press and hold the rotary dial to turn One Foundation off Remote [ILLUSTRATION OF REMOTE – Ill. 2] - Input: Cycle through connected inputs or press and hold to engage Bluetooth Pairing Mode. - Power: On/Off - FF: Press for next track, press and hold for fast forward - RW: Press for previous track, press and hold for rewind - Play/Pause: Play/Pause track Connecting Your Device via Bluetooth® Pairing Mode (Blinking Blue LED) One Foundation automatically goes into Bluetooth Reconnect Mode for 10 seconds as soon as you turn it on (fast flashing BLUE led). It then switches to Pairing Mode (slow flashing BLUE led). You can pair a new device to One Foundation when in Pairing Mode. Note: Holding the [INPUT BUTTON] on the One Foundation remote for 3 seconds will disconnect the device currently connected and go into Pairing Mode. Pairing mode can also be engaged by disconnecting a connected device or by pressing the [BT PAIR] on the back of One Foundation. Connected Mode (Solid Blue LED) Use your Bluetooth-enabled device to pair to One Foundation. One Foundation does not require a pairing password. Once paired, the LED will glow solid blue. Note: One Foundation will automatically pair with the last device connected to it when turned ON (when the device is available). Connecting other devices The various inputs on the back of One Foundation allow you to connect other devices to the system. For connecting analog devices, use the RCA input on the back or the auxiliary input on the side. For connecting digital devices we recommend using the digital audio (optical) input for the highest sound quality. USB Charging Port Use this port for charging up your iPod®, smartphone, or tablet. The port is always active when One Foundation is plugged into a wall outlet. Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plug, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the art/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or m…

Text truncated - open the document above for the full version.

RF_160, Issue 03 Declaration of Authorization We Name: The House of Marley.LLC Address: 3000 Pontiac Trail Commerce Township City: Oaklang Country: United States Declare that: Name Representative of agent: Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification of the following product(s), including the signing of the related documents such as 731 forms: Product description: Bluetooth Speaker Type designation: EM-DA001-RG Trademark: Marley on our behalf. Date: 2013-12-24 City: Oaklang Name: Vladislav Grodzinskiy Function: manager Signature:

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: The House of Marley.LLC Address: 3000 Pontiac Trail Commerce Township City: Oaklang Country: United States To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: PVBEMDA001RG Reference number: ####### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2013-12-24 Name and signature of applicant: Vladislav Grodzinskiy Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Neutron Engineering Inc. Project No.: 1311C001 Page 2 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 3 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 4 of 18

PC Sheet(细砂纹),T=0.3mm,单面背胶(3M 7533胶) Label: Pantone Black 7C, Type: Pantone Cool Gray 2C DVR NO. Necole Necole 注記： 1、所有零部件都需经超声工程师确定后才可生产. 2、有 標記的尺寸為重要管制(IQC必檢)尺寸. 3、有◆標記的尺寸為客戶重要管制(IQC必檢)尺寸. 4、未標示的尺寸請參照 3D CAD. 5、產品材質應符合RoHS. 6、拔模斜度最大为1,除另行通知外. 7、图中未标注的半径应为0.2mm。 8、材質: 9、表面处理: 10、請使用超聲工程提供的美工稿直接制板. 11、禁止更改客戶的美工稿(不可在客戶的美工稿上作任何修改動作,超聲工程部有書面通知除外). 12、未標注公差的尺寸參照IT15. F176-0705C 2013.08.13 One Foundation BT Power Label （重量: 體積： mm ） 2 0.3g IVHA15042-0001 IVHA15042-X001 106.8mm+/-0.2 31.8mm+/-0.2

Neutron Engineering Inc. Project No.: 1311C001 Page 5 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 6 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 7 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 8 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 9 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 10 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 11 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 12 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 13 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 14 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 15 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 16 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 17 of 18 Neutron Engineering Inc. Project No.: 1311C001 Page 18 of 18

Neutron Engineering Inc. Im FCC RF EXPOSURE REPORT FCC ID: PVBEMDA001RG Project No. : 1311C001 Equipment : Bluetooth Speaker Model Name : EM-DA001-RG Applicant : The House of Marley, LLC Address : 3000 Pontiac Trail Commerce Township MI-48390, USA According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Ant. Manufacturer Model Name Antenna Type Connector Gain (dBi) 1 C4080-510003-A(S SR-1200342) PCB N/A 2 Note: The EUT is considered two different ANT types (one PCB antenna and one Printed antenna), Only used the PCB antenna, the Printed antenna is not used. Maximum measured transmitter power: Output Power (dBm) Out Power (mW) Limit (mW) 4.17 2.6 10 According to FCC KDB447498 V05, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The maximum measured output power of this EUT is 4.17dBm (2.6mW), less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Neutron Engineering Inc. Report No.: NEI-FICP-1-1311C001 Page 1 of 94 FCC&IC Radio Test Report FCC ID: PVBEMDA001RG IC: 10613A-EMDA001RG This report concerns (check one): Original Grant Class II Change Issued Date : Dec. 26, 2013 Project No. : 1311C001 Equipment : Bluetooth Speaker Model Name : EM-DA001-RG Applicant : The House of Marley, LLC Address : 3000 Pontiac Trail Commerce Township MI-48390, USA Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Nov. 29, 2013 Date of Test: Nov. 29, 2013~ Dec. 25, 2013 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL: 0769-8318-3000 FAX: 0769-8319-6000 Neutron Engineering Inc. Report No.: NEI-FICP-1-1311C001 Page 2 of 94 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-1-1311C001 Page 3 of 94 Table of Contents Page 1 . CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 TEST PROCEDURE 15 4.1.3 DEVIATION FROM TEST STANDARD 15 4.1.4 TEST SETUP 16 4.1.5 EUT OPERATING CONDITIONS 16 4.1.6 EUT TEST CONDITIONS 16 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 19 4.2.1 RADIATED EMISSION LIMITS 19 4.2.2 TEST PROCEDURE 20 4.2.3 DEVIATION FROM TEST STANDARD 20 4.2.4 TEST SETUP 21 4.2.5 EUT OPERATING CONDITIONS 22 4.2.6 EUT TEST CONDITIONS 22 4.2.7 TEST RESULTS (BELOW 30MHZ) 23 4.2.8 TEST RESULTS: 30MHZ - 1000MHZ 24 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 31 5 . NUMBER OF HOPPING CHANNEL 46 5.1 APPLIED PROCEDURES 46 5.1.1 TEST PROCEDURE 46 5.1.2 DEVIATION FROM STANDARD 46 5.1.3 TEST SETUP 46 5.1.4 EUT OPERATION CONDITIONS 46 5.1.5 EUT TEST CONDITIONS 46 5.1.6 TEST RESULTS 47 Neutron Engineering Inc. Report No.: NEI-FICP-1-1311C001 Page 4 of 94 Table of Contents Page 6 . AVERAGE TIME OF OCCUPANCY 48 6.1 APPLIED PROCEDURES / LIMIT 48 6.1.1 TEST PROCEDURE 48 6.1.2 DEVIATION FROM STANDARD 48 6.1.3 TEST SETUP 48 6.1.4 EUT OPERATION CONDITIONS 49 6.1.5 EUT TEST CONDITIONS 49 6.1.6 TEST RESULTS 50 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 62 7.1 APPLIED PROCEDURES / LIMIT 62 7.1.1 TEST PROCEDURE 62 7.1.2 DEVIATION FROM STANDARD 62 7.1.3 TEST SETUP 62 7.1.4 EUT TEST CONDITIONS 62 7.1.5 TEST RESULTS 63 8 . BANDWIDTH TEST 67 8.1 APPLIED PROCEDURES 67 8.1.1 TEST PROCEDURE 67 8.1.2 DEVIATION FROM STANDARD 67 8.1.3 TEST SETUP 67 8.1.4 EUT OPERATION CONDITIONS 67 8.1.5 EUT TEST CONDITIONS 67 8.1.6 TEST RESULTS 68 9 . PEAK OUTPUT POWER TEST 72 9.1 APPLIED PROCEDURES / LIMIT 72 9.1.1 TEST PROCEDURE 72 9.1.2 DEVIATION FROM STANDARD 72 9.1.3 TEST SETUP 72 9.1.4 EUT OPERATION CONDITIONS 72 9.1.5 EUT TEST CONDITIONS 72 9.1.6 TEST RESULTS 73 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 77 10.1 APPLIED PROCEDURES / LIMIT 77 10.1.1 TEST PROCEDURE 77 10.1.2 DEVIATION FROM STANDARD 77 10.1.3 TEST SETUP 78 10.1.4 EUT OPERATION CONDITIONS 78 10.1.5 EUT TEST CONDITIONS 78 10.1.6 TEST RESULTS 79 11 . MEASUREMENT INSTRUMENTS LIST AND SETTING 89 Neutron Engineering Inc. Report No.: NEI-FICP-1-1311C001 Page 5 of 94 Table of Contents Page 12 . EUT TEST PHOTO 91 Neutron Engineering Inc. Report No.: NEI-FICP-1-1311C001 Page 6 of 94 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FICP-1-1311C001 Original Issue. Dec. 26, 2013 Neutron Engineering Inc. Report No.: NEI-FICP-1-1311C001 Page 7 of 94 1. CERTIFICATION Equipment : Bluetooth Speaker Brand Name : Marley Model Name : EM-DA001-RG Applicant : The House of Marley, LLC. Manufacturer : The House of Marley, LLC Address : 3000 Pontiac Trail Commerce Township MI-48390, USA Factory : Premium Loudspeakers (Huizhou) Co., Ltd Address : Tymphany Industrial Area Xinlian Village, Xinxu Town, Huizhou City, Guangdong, P.R. China Date of Test : Nov. 29, 2013~ Dec. 25, 2013 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C : 2012 (15.247) / ANSI C63.4 : 2009 / FCC Public Notice DA 00-705, March 30, 2000. Canada RSS-210:2010 RSS-GEN Issue 3, Dec 2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FICP-1-1311C001 Page 91 of 94 12. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FICP-1-1311C001 Page 92 of 94 Radiated Measurement Photos 9K~30MHz Neutron Engineering Inc. Report No.: NEI-FICP-1-1311C001 Page 93 of 94 Radiated Measurement Photos 30~1000MHz Neutron Engineering Inc. Report No.: NEI-FICP-1-1311C001 Page 94 of 94 Radiated Measurement Photos Above 1000MHz
