PWX-AL21Triband GSM Mobile Phone

Table of Contest1 right page (1) of AL21 PELICAN FCC us-en (27.02.2006, 13:26) Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711 © BenQ Mobile GmbH & Co OHG 2004, \\Itl.eu\c ottbus\Projekte_30\BenQ_M obile\AL21_PELICAN\out- Legal notices ...................................... 2 Safety precautions ............................. 4 Antenna care ................................... 5 Phone operation .............................. 5 Electronic devices ............................ 6 Overview of the phone ...................... 9 Getting started ................................. 10 Open/close slider .............................. 11 Security ............................................ 11 Codes ............................................ 11 Calling .............................................. 11 Text entry ......................................... 12 Addressbook ..................................... 13 <New entry> .................................. 13 Change entry ................................. 13 Voice dialling ................................. 13 SMS ................................................... 13 MMS ................................................. 14 Ring tones ........................................ 14 Surf & fun ......................................... 15 Internet ......................................... 15 Games & more ............................... 15 Organizer ......................................... 16 Alarm clock ................................... 16 Calendar ....................................... 16 Appointments ............................... 16 Notes ............................................ 16 Time zones .................................... 16 Calendar setup .............................. 16 Customer Care ................................. 17 Care and maintenance ..................... 18 Product data ..................................... 19 SAR ................................................. 20 U.S. FDA ........................................... 21 FCC/Industry Canada Notice ............ 25 Intellectual property ........................ 26 Ten Driving Safety Tips .................... 27 End user license agreement ............ 29 Index ................................................ 32 Table of Contest Legal notices2 © BenQ Mobile GmbH & Co. OHG 2004, \\Itl.eu\co ttbus\Projekte_30\BenQ_Mobile\AL21_PELICAN\out- left page (2) of AL21 PELICAN FCC us-en, (27.02.2006, 13:02) Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711 Legal notices The mobile phone described in this guide is approved for use on the GSM and GPRS net- works operating on the GSM 900, 1800 (DCS/PCN) and 1900 (PCS) bands. It is approved for use in the country where it was originally sold and may be approved for use in other countries. © 2005 Siemens Communications Inc. All rights reserved. Siemens and the AL21 model phone are trademarks or registered trademarks of Siemens and/or its affiliates in the United States and/or other countries. T9® is a registered trademark of America Online, Inc. in the United States. Java and all Java-based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S and other countries. The names of actual companies and products mentioned herein may be the trademarks of their respective owners. Disclaimer The information contained in the User Guide is written for the AL21 phone. Siemens reserves the right to make chang- es and improvements to the products and any of the features of the products de- scribed in this document without prior no- tice. The contents of the user guide are pro- vided "AS IS". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of mer- chantability and fitness for a particular pur- pose, are made in relation to the accuracy, reliability or contents of this document. Siemens reserves the right to revise the user guide or withdraw it at any time with- out prior notice. Under no circumstances shall Siemens be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howso- ever caused. Export Information The mobile phone may be subject to export regulation of the United States and other countries. Diversion contrary to law is pro- hibited. You must comply with all applica- ble export laws, restrictions and regulations of the United States foreign agencies or au- thorities, and may not export, or transfer for the purpose of re-export, the mobile phone or any part of the phone in violation of any applicable restrictions, laws or regu- lations, or without all necessary approvals. Network Services A number of features included in this guide are called Network Services. They are special services provided by wireless service providers. In order to use any of these Network Services, you must sub- scribe to these service(s) from your ser- vice provider and obtain instructions for their use. Some of these Network Servic- es may not be available when roaming on a network other than your home network. 3Legal notices right page (3) of AL21 PELICAN FCC us-en (27.02.2006, 13:02) © BenQ Mobile GmbH & Co OHG 2004, \\Itl.eu\c ottbus\Projekte_30\BenQ_M obile\AL21_PELICAN\out- Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711 Standby and Talk Time Information The mobile phone incorporates features that are new to the mobile phone world. These may include color displays and lighting, graphic games, music reproduc- tion and browsing the Internet. The way you use the display and the features will affect the performance of the battery and how long it lasts between charge cycles. The quoted standby times and talk times show the minimum and maximum per- formance that can be expected from the battery under normal network conditions and with the default settings as set by the factory. However, playing games (particu- larly with the backlig…

Text truncated - open the document above for the full version.

Mobile AL21 External Pictures BENQ Page:1 of 6 AL21 Front View (Slider Closed) Mobile AL21 External Pictures BENQ Page:2 of 6 AL21 Back View (Slider Closed) Mobile AL21 External Pictures BENQ Page:3 of 6 AL21 Side View (Slider Closed) Mobile AL21 External Pictures BENQ Page:4 of 6 AL21 Front View (Slider open) Mobile AL21 External Pictures BENQ Page:5 of 6 AL21 Back View (Slider open) Mobile AL21 External Pictures BENQ Page:6 of 6 AL21 Side View (Slider open)

BENQ Mobile AL21 IMEI Label Mobile Page:1 of 2 BENQ Mobile AL21 IMEI Label Mobile Page:2 of 2

Mobile AL21 Internal Pictures BENQ Page:1 of 10 AL21 Open Battery Cover (Final label: See extra exhibit) Mobile AL21 Internal Pictures BENQ Page:2 of 10 AL21 Disassembly Step 1 Mobile AL21 Internal Pictures BENQ Page:3 of 10 Mobile AL21 Internal Pictures BENQ Page:4 of 10 AL21 Disassembly Step 2 Mobile AL21 Internal Pictures BENQ Page:5 of 10 AL21 Disassembly Step 3 Mobile AL21 Internal Pictures BENQ Page:6 of 10 AL21 Disassembly Step 4 Mobile AL21 Internal Pictures BENQ Page:7 of 10 AL21 Disassembly Step 5 Mobile AL21 Internal Pictures BENQ Page:8 of 10 AL21 Back view BB (rep. Lid) Mobile AL21 Internal Pictures BENQ Page:9 of 10 AL21 Front view RF Mobile AL21 Internal Pictures BENQ Page:10 of 10 AL21 Antenna

DAT-P-152/98-01 SAR Report, BenQ_6620_575_FCC_1900_AL21 Page 1 of 40 Report Dosimetric Assessment of the Portable Device BenQ AL21 (FCC ID: PWX-AL21) According to the FCC Requirements February 09, 2006 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer BenQ Denmark a/s Siemens Kaj 1 DK-9400 Norresundby The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. dasy_report_fcc_1900_4.4.doc/14.09.2005/ABo SAR Report, BenQ_6620_575_FCC_1900_AL21 Page 2 of 40 dasy_report_fcc_1900_4.4.doc/14.09.2005/ABo Executive Summary The AL21 is a mobile phone (Portable Device) from BenQ operating in the 900 MHz, 1800 MHz and 1900 MHz frequency range. The device has an integrated antenna and the system concepts used are the GSM 900, GSM 1800 and PCS 1900 standards including GPRS Class 8. The objective of the measurements done by IMST was the dosimetric assessment of one device in the PCS 1900 standard with slider up and slider down. The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the Supplement C to OET Bulletin 65 of the Federal Communications Commission (FCC) Guidelines [OET 65] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions. All measurements have been performed in accordance to the recommendations given by SPEAG. The BenQ AL21 mobile phone (FCC ID: PWX-AL21) is in compliance with the Federal Communications Commission (FCC) Guidelines [OET 65] for uncontrolled exposure. The phone was tested in addition to the head positions in the following configurations: Body worn with the following accessories: • GSM with and without headset (15 mm distance) • GPRS (Class 8) with data cable (15 mm distance) prepared by: ........................................... reviewed by: ..................................... Alexander Rahn André van den Bosch test engineer quality assurance engineer IMST GmbH Carl-Friedrich-Gauß-Straße 2 D-47475 Kamp-Lintfort Tel. +49- 2842-981 378 Fax +49- 2842-981 399 email: [email protected] SAR Report, BenQ_6620_575_FCC_1900_AL21 Page 3 of 40 dasy_report_fcc_1900_4.4.doc/14.09.2005/ABo Table of Contents 1 SUBJECT OF INVESTIGATION.................................................................................................................... 4 2 THE IEEE STANDARD C95.1 AND THE FCC EXPOSURE CRITERIA................................................. 4 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES........... 4 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS....................................... 4 2.3 SAR LIMIT.................................................................................................................................................. 5 3 THE FCC MEASUREMENT PROCEDURE................................................................................................. 6 3.1 GENERAL REQUIREMENTS......................................................................................................................... 6 3.2 DEVICE OPERATING NEXT TO A PERSON’S EAR....................................................................................... 6 4 BODY-WORN CONFIGURATIONS.............................................................................................................. 9 4.1 POC (PTT) POSITION...............................................................................................................................9 4.2 PHANTOM REQUIREMENTS...................................................................................................................... 10 4.3 TEST TO BE PERFORMED......................................................................................................................... 10 5 THE MEASUREMENT SYSTEM................................................................................................................. 10 5.1 PHANTOM................................................................................................................................................. 12 5.2 PROBE...................................................................................................................................................... 12 5.3 MEASUREMENT PROCEDURE.................................................................................................................. 13 5.4 UNCERTAINTY ASSESSMENT................................................................................................................... 14 6 SAR RESULTS............................................................................................................................................... 15 7 EVALUATION................................................................................................................................................. 18 8 APPENDIX....................................................................................................................................................... 20 8.1 ADMINISTRATIVE DATA............................................................................................................................ 20 8.2 DEVICE UNDER TEST AND TEST CONDITIONS......................................................................................... 20 8.3 TISSUE RECIPES...................................................................................................................................... 21 8.4 MATERIAL PARAMETERS......................................................................................................................... 21 8.5 SIMPLIFIED PERFORMANCE CHECKING................................................................................................... 22 8.6 ENVIRONMENT..................................................................................…

Text truncated - open the document above for the full version.

DAT-P-152/98-01 SAR_Report_BenQ_6620_575_Cal Data_AL21 dasy_report_fcc_1900_cal_data_2.0.doc/08.01.2005/CH Appendix for the Report Dosimetric Assessment of the Portable Device BenQ AL21 (FCC ID: PWX-AL21) According to the FCC Requirements Calibration Data February 15, 2006 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer BenQ Denmark a/s Siemens Kaj 1 DK-9400 Norresundby This report shall not be reproduced except in full without the written approval of the testing laboratory.

DAT-P-152/98-01 SAR Report, BenQ_6620_575_FCC_1900_SAR Plots_AL21 Page 1 of 18 Appendix for the Report Dosimetric Assessment of the BenQ AL21 (FCC ID: PWX-AL21) According to the FCC Requirements SAR Distribution Plots February 14, 2006 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer BenQ Denmark a/s Siemens Kaj 1 DK-9400 Norresundby The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH SAR Report, BenQ_6620_575_FCC_1900_SAR Plots_AL21 Page 2 of 18 dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH Table of Contents 1 SAR DISTRIBUTION PLOTS, PCS 1900 HEAD........................................................................................ 3 2 SAR DISTRIBUTION PLOTS, PCS 1900 BODY, WITHOUT ACCESSORY, GSM MODE............... 11 3 SAR DISTRIBUTION PLOTS, PCS 1900 BODY, WITH HEADSET, GSM MODE............................. 13 4 SAR DISTRIBUTION PLOTS, PCS 1900 BODY, WITH DATA CABLE, GPRS CLASS 8 MODE.. 15 5 SAR Z-AXIS SCANS (VALIDATION)......................................................................................................... 17 6 SAR Z-AXIS SCANS (MEASUREMENTS)................................................................................................ 18 SAR Report, BenQ_6620_575_FCC_1900_SAR Plots_AL21 Page 3 of 18 dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH 1 SAR Distribution Plots, PCS 1900 Head Test Laboratory: Imst GmbH; File Name: 460yplm_1_su.da4 DUT: BenQ; Type: AL21; Serial: 004400016916460 Program Name: Cheek Left Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.43 mho/m; ε r = 40.9; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(8.25, 8.25, 8.25); Calibrated: 23.09.2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 17.03.2005 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.6 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 159 Cheek Left/Area Scan (6x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.234 mW/g Cheek Left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 10.4 V/m; Power Drift = 0.013 dB Peak SAR (extrapolated) = 0.338 W/kg SAR(1 g) = 0.238 mW/g; SAR(10 g) = 0.147 mW/g Maximum value of SAR (measured) = 0.259 mW/g Fig. 1: SAR distribution for PCS 1900, channel 661, cheek position, left side of head, slider up, February 08, 2006; Ambient Temperature: 21.7∞ C; Liquid Temperature : 20.9∞ C). SAR Report, BenQ_6620_575_FCC_1900_SAR Plots_AL21 Page 4 of 18 dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH Test Laboratory: Imst GmbH; File Name: 460yplm_2_su.da4 DUT: BenQ; Type: AL21; Serial: 004400016916460 Program Name: Tilted Left Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.43 mho/m; ε r = 40.9; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(8.25, 8.25, 8.25); Calibrated: 23.09.2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 17.03.2005 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.6 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 159 Tilted Left/Area Scan (6x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.207 mW/g Tilted Left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 11.6 V/m; Power Drift = 0.055 dB Peak SAR (extrapolated) = 0.321 W/kg SAR(1 g) = 0.204 mW/g; SAR(10 g) = 0.123 mW/g Maximum value of SAR (measured) = 0.222 mW/g Fig. 2: SAR distribution for PCS 1900, channel 661, tilted position, left side of head (February 08, 2006; Ambient Temperature: 21.7∞ C; Liquid Temperature : 20.9∞ C). SAR Report, BenQ_6620_575_FCC_1900_SAR Plots_AL21 Page 5 of 18 dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH Test Laboratory: Imst GmbH; File Name: 460yprm_1_su.da4 DUT: BenQ; Type: AL21; Serial: 004400016916460 Program Name: Cheek Right Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.43 mho/m; ε r = 40.9; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(8.25, 8.25, 8.25); Calibrated: 23.09.2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 17.03.2005 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.6 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 159 Cheek Right/Area Scan (6x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.218 mW/g Cheek Right/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 10.0 V/m; Power Drift = 0.098 dB Peak SAR (extrapolated) = 0.347 W/kg SAR(1 g) = 0.210 mW/g; SAR(10 g) = 0.135 mW/g Maximum value of SAR (measured) = 0.227 mW/g Cheek Right/Zoom Scan (7x7x7)/Cube 1: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 10.0 V/m; Power Drift = 0.098 dB Peak SAR (extrapolated) = 0.427 W/kg SAR(1 g) = 0.193 mW/g; SAR(10 g) = 0.098 mW/g Maximum value of SAR (measured) = 0.209 mW/g Fig. 3: SAR distribution for PCS 1900, channel 661, cheek position, right side of head, slider up (February 08, 2006; Ambient Temperature: 21.7∞ C; Liquid Temperature : 20.9∞ C). SAR Report, BenQ_6620_575_FCC_1900_SAR Plots_AL21 Page 6 of 18 dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH Test Laboratory: Imst GmbH; File Name: 460yprm_2_su.da4 DUT: BenQ; Type: AL21; Serial: 004400016916460 Program Name: Tilted Right Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.43 mho/m; ε r = 40.9; ρ = 1000 kg/m 3 Phantom secti…

Text truncated - open the document above for the full version.

TTI-P-G 081/94-A0 Accredited according to ISO/IEC 17025 Bluetooth Qualification Test Facility (BQTF) FCC listed # 101450 IC recognized # 3925 CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2113686 Board of Directors: Dr. Harald Ansorge, Dr. Klaus Matkey, Hans Peter May © Copyright by CETECOM FCC Test Report FCC Part 24 / RSS 133 . FOR: TRI-BAND GSM MOBILE PHONE MODEL #: AL21 BenQ Mobile GmbH & Co OHG Haidenauplatz 181667 München GERMANY FCC ID: PWX-AL21 IC ID: 6175C-AL21 TEST REPORT #: BENQ0_007_06001_AL21_FCC24 DATE: March 22, 2006 Test Report #: BENQ0_007_06001_AL21_FCC24 Date of Report: 03/22/2006 Page 2 of 60 This report shall not be reproduced except in full without the written approval of: CETECOM, Inc. Table of Contents 1 ASSESSMENT ....................................................................................................................................3 2 ADMINISTRATIVE DATA............................................................................................................... 4 2.1 IDENTIFICATION OF THE TESTING LABORATORY ISSUING THE EMC TEST REPORT.........................4 2.2 IDENTIFICATION OF THE CLIENT...................................................................................................4 2.3 IDENTIFICATION OF THE MANUFACTURER....................................................................................4 3 EQUIPMENT UNDER TEST (EUT) ................................................................................................5 3.1 IDENTIFICATION OF THE EQUIPMENT UNDER TEST.......................................................................5 4 SUBJECT OF INVESTIGATION.....................................................................................................6 5 MEASUREMENTS.............................................................................................................................7 5.1 RF POWER OUTPUT.......................................................................................................................7 5.1.1 FCC 2.1046 Measurements required: RF power output.......................................................7 5.1.2 Limits: ...................................................................................................................................7 5.1.2.1 FCC 24.232 (b)(c) Power limits. .......................................................................................7 5.1.3 Conducted Output Power Measurement procedure:.............................................................7 5.1.4 Results 1900 MHz band(conducted): ....................................................................................8 5.1.5 Radiated Output Power Measurement procedure:................................................................9 5.1.6 EIRP Results 1900 MHz band:............................................................................................10 5.2 OCCUPIED BANDWIDTH/EMISSION BANDWIDTH........................................................................14 5.2.1 FCC 2.1049 Measurements required: Occupied bandwidth...............................................14 5.2.2 Occupied / emission bandwidth measurement procedure:..................................................14 5.2.3 Occupied / Emission bandwidth results 1900 MHz band: ..................................................15 5.3 FREQUENCY STABILITY...............................................................................................................22 5.3.1 Limit ....................................................................................................................................22 5.3.2 FREQUENCY STABILITY (PCS-1900) ..............................................................................23 5.4 SPURIOUS EMISSIONS CONDUCTED.............................................................................................24 5.4.1 FCC 2.1051 Measurements required: Spurious emissions at antenna terminals. ..............24 5.4.2 Limits: .................................................................................................................................24 5.4.2.1 FCC 24.238 Emission limitations for Broadband PCS equipment. ...............................24 5.4.3 Conducted out of band emissions measurement procedure: ...............................................24 5.4.4 Bandedge Results PCS-1900 ...............................................................................................26 5.4.5 Conducted Spurious Results PCS-1900 ..............................................................................28 5.5 SPURIOUS EMISSIONS RADIATED................................................................................................32 5.5.1 FCC 2.1053 Measurements required: Field strength of spurious radiation.......................32 5.5.2 Limits: .................................................................................................................................32 5.5.2.1 FCC 24.238 Emission limitations for Broadband PCS equipment. ...............................32 5.5.3 Radiated out of band measurement procedure: ..................................................................33 5.6 RECEIVER RADIATED EMISSIONS § 2.1053 / RSS-133 ....................................................50 5.6.1 Receiver Spurious on EUT ..................................................................................................51 5.7 AC POWERLINE CONDUCTED EMISSIONS § 15.107/207 .................................................56 5.7.1 Results EUT.........................................................................................................................57 6 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS ................................................59 7 REFERENCES ..........................…

Text truncated - open the document above for the full version.

Mobile Test Report Conducted Output Power PCS1900 Siemens AL21 Report No: Pelican AL21_Conducted_Power.doc Issue date: Feb. 2, 2006 Test Sites: EA BEJ Phone: +86 10 64748800-7865 Peter Loeber EMC/Antenna Engineer, EA A21 - Conducted Output Power Page 2 / 6 Contents 1 Objective and Method............................................................................... 3 2 Device under test....................................................................................... 3 3 Measurement Set-up................................................................................. 3 4 Test Result ................................................................................................. 5 Annex 1 Calibration Certificate..................................................................... 7 A21 - Conducted Output Power Page 3 / 6 1 Objective and Method FCC approval for mobile phone requires reporting output power at RF output terminal pursuant to title 47 CFR part 2.1046. BenQ devices use special test fixtures with 50 Ohm connection suitable for such measurements. Using a special adapter and connecting the phone to an appropriate load in terms of the input port of the measurement equipment used, we hereby report the values for highest power setting. 2 Device under test Mobile Phone: Siemens AL21 (GSM900/GSM1800/PCS1900) Frequency Range PCS 1900: 1850 – 1990 MHz There are 6 devices has been tested listed in “Chapter 4 Test Result”. 3 Measurement Set-up Figure 1: Block Diagram of set-up for conducted power measurement Base Station Simulator CMU 200 Serial Number 105851 Software Version Base 3.81 / GSM 3.80 Calibration Certification Annex 1 Test Voltage: 4.0 V Temperature: Room Temperature Base Station Simulator DUT Special Adapter A21 - Conducted Output Power Page 4 / 6 Figure 2: Set-up for conducted power measurement A21 - Conducted Output Power Page 5 / 6 4 Test Result Conducted Output Power (PCS1900 Band) EUTs Average Power during burst at phone connector (dBm) A21 IMEI Ch. 512 1850.2 MHz Ch. 661 1880.0 MHz Ch. 810 1909.8 MHz SAR approval Sample #1 004400016916460 29.1 29.1 29.2 SAR approval Sample #2 004400016912360 29.0 29.0 29.1 FCC Emission Sample #3 004400016912634 29.0 29.0 29.1 FCC Emission Sample #4 004400016912006 29.1 29,1 29,2 FCC Emission Sample #5 004400016917039 29.0 29.1 29.2 FCC Emission Sample #6 004400016916544 29.1 29.1 29.2 A21 - Conducted Output Power Page 6 / 6 Annex 1 Calibration Certificate

BENQ DENMARK APS BML TESTING LABORATORY (NO. 1) for Electro-Magnetic Compatibility BenQ Denmark ApS Lindholm Brygge 35 Switchboard CVR No. 03.03.06 /bmlpkn DK-9400 Nr.Sundby +45 7219 5000 27963706 Revision: 1.0, Page 1 of 30 Denmark AL21 - CISPR 22 (FCC 15) EMI 03-03-2006 TEST REPORT NO.: BML – FC 002.2006 Test specification: CFR47 part 15 Radio Frequency Devices. Sub standard: FCC 15 subpart B/C Unintentional/Intentional Radiators. Ordered by: AL21 Polaris project team – Peter Loeber Address: Lindholm Brygge 35, 9400 Nr.Sundby Denmark Subject: Siemens AL21 Verification: Travel Charger – Delta type – A5BHTN00 164532, TADP-3XB CB (Lead free) Desktop Stand – EDS-600 – L360880-N6881-A100 Headset Basic – HHS-500 – L36880-N5601-A107 Headset – HHS-510 – L36880-N5601-A108 Headset Purestyle - HHS-610 – L36880-N7101-A500 Car Kit Portable – HKP-500 – L36880-N5601-A109 Car Charger – ECC-500 – L36880-N5601-A106 Car Charger Plus – ECC-600 – L36880-N7101-A109 Data Cable – DCA-500 (RS232) – L36880-N5601-A110 Spare battery – V30145-K1310-X386-1-SO – 3.7V/600 mAh Spare battery – V30145-K1310-X386-VA – 3.7V/570 mAh Serial numbers: Sample #134, IMEI: 004400016916544 HW revision: B2 SW revision: 00.1592, 18012006 Manufacturer: Manufacturer BenQ SHA Mobile Street Address Chuan Qiao Rd. 777, Pudong City/Zip Code Shanghai 201206 Country China BENQ DENMARK APS BML TESTING LABORATORY (NO. 1) for Electro-Magnetic Compatibility BenQ Denmark ApS Lindholm Brygge 35 Switchboard CVR No. 03.03.06 /bmlpkn DK-9400 Nr.Sundby +45 7219 5000 27963706 Revision: 1.0, Page 2 of 30 Denmark AL21 - CISPR 22 (FCC 15) EMI 03-03-2006 Internal Order No.: PKN – 13.02.2006.002 Date(s) of test: 13.02.2006 -> 28.02.2006 Technical responsibility Per K. Nielsen Date: 03.03.2006 Test performed b…

Text truncated - open the document above for the full version.
