PWX-AX75GSM 900/1800/1900 Mobile Phone

right page (1) of AX75_Pegasus, fcc, us-en (31.05.2005, 08:47) © Siemens AG 2004, C:\Siemens\DTP-Satz\Produkte\AX75_Pegas us_1\output\SUG\AX75_fcc_approval_050519_te\S_PegasusIVZ.fm Contents 1 VAR Language: am; VAR issue date: 050309 Legal notices ...................................... 2 Safety precautions ............................. 4 Antenna care ................................... 5 Phone operation .............................. 5 Electronic devices ............................ 6 Overview of the phone ...................... 9 Display symbols ................................ 10 Getting started ................................. 11 Switch on/off, PIN ............................. 12 Emergency number (SOS) .............. 12 General instructions ......................... 12 Security ............................................ 13 Codes ............................................ 13 Calling .............................................. 14 Text entry ......................................... 14 Default book ..................................... 16 Phonebook ....................................... 16 <New entry> .................................. 16 Call (search for an entry) ................ 16 Address book .................................... 16 <New entry> .................................. 16 Change entry ................................. 17 Voice dialing .................................. 17 Records ............................................. 17 Duration/charges .............................. 17 Voice message/ mailbox .................. 17 SMS ................................................... 18 MMS ................................................. 19 Message setup ................................. 20 Ring tones ........................................ 20 Surf & fun ......................................... 20 Internet browser ............................ 20 Games & more ............................... 21 Setup ................................................ 21 Organizer ......................................... 24 Alarm clock ................................... 24 Calendar ....................................... 24 Appointments ............................... 24 Notes ............................................ 24 Missed alarms ............................... 25 Time zones .................................... 25 Calend. setup ................................ 25 Extras ............................................... 25 SIM services (optional) .................. 25 Calculator ...................................... 25 Currency conv ............................... 25 Stopwatch ..................................... 25 Countdown ................................... 25 Voice command ............................ 25 Fast access key ................................. 26 Own stuff ......................................... 26 Customer Care ................................. 27 Care and maintenance ..................... 28 Product data ..................................... 29 Accessories ...................................... 30 SAR (AX75) ....................................... 31 U.S. FDA ........................................... 33 FCC/Industry Canada Notice ............ 37 Ten Driving Safety Tips .................... 38 Intellectual property ........................ 40 End user license agreement ............ 41 Contents © Siemens AG 2004, C:\Siemens\DTP -Satz\Produkte\AX75_Pegasus_1\out- left page (2) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47) Legal notices 2 VAR Language: am; VAR issue date: 050309 Legal notices The mobile phone described in this guide is approved for use on the GSM and GPRS net- works operating on the GSM 900, 1800 (DCS/PCN) and 1900 (PCS) bands. It is approved for use in the country where it was originally sold and may be approved for use in other countries. © 2005 Siemens Information and Communication Mobile, LLC. All rights reserved. Siemens and the AX75 model phone are trademarks or registered trademarks of Siemens AG and/or its affiliates in the United States and/or other countries. T9® is a registered trademark of America Online, Inc. in the United States. Java and all Java-based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S and other countries. The names of actual companies and products mentioned herein may be the trademarks of their respective owners. Disclaimer The information contained in the User Guide is written for the AX75 phone. Siemens reserves the right to make changes and improvements to the products and any of the features of the products described in this document without prior notice. The contents of the user guide are provided "AS IS". Except as required by applicable law, no warranties of any kind, either express or im- plied, including, but not limited to, the im- plied warranties of merchantability and fit- ness for a particular purpose, are made in relation to the accuracy, reliability or con- tents of this document. Siemens reserves the right to revise the user guide or with- draw it at any time without prior notice. Un- der no circumstances shall Siemens be re- sponsible for any loss of data or income or any special, incidental, consequential or in- direct damages howsoever caused. Export Information The mobile phone may be subject to export regulation of the United States and other countries. Diversion contrary to law is pro- hibited. You must comply with all applica- ble export laws, restrictions and regulations of the United States foreign agencies or au- thorities, and may not export, or transfer for the purpose of re-export, the mobile phone or any part of the phone in violation of any applicable restrictions, laws or regu- lations, or without all necessary approvals. Network Services A number of features included in this guide are called Network Services. They are special services provided by wireless service providers. In order to use any of these Network Services, you must su…

Text truncated - open the document above for the full version.

Siemens Communications, Inc. Siemens Communications, Inc. 16745 West Bernardo Drive Suite 120 San Diego, CA 92127 Tel. 858-521-3200 June 6, 2005 Letter of Authorization Re: Application for Siemens mobile device AX75 To whom it may concern, We the undersigned, hereby authorize CETECOM Inc. (411 Dixon Landing Road, Milpitas, CA 95035, Tel.408 586 6214) to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CETECOM Inc., on our behalf shall have the same effect as acts of our own. The authorization from Siemens Communications is valid 365 days from the date of this letter. Sincerely, Kevin Wolentarski Regulatory Engineer

Siemens Communications, Inc. Siemens Communications, Inc. 16745 West Bernardo Drive Suite 120 San Diego, CA 92127 Tel. 858-521-3200 Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 June 6, 2005 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Siemens Communications, Inc requests confidentiality for the following products: FCC ID Number Product Title/Model PWX – AX75 Tri -Band/AX75 For the product stated above, we request that the following information be held confidential: 1) Electrical Schematics of the Circuitry 2) Block Diagram 3) Parts List 4) Technical Description Required for section 2.1003 (c) • Operational Description 5) Tune-up Procedure No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain Siemens Communications, Inc trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our mobile handset. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Kevin Wolentarski Regulatory Engineer

Sieme n s Communication s, Inc. AX75 Front View Sieme n s Communication s, Inc. AX75 Back View Sieme n s Communication s, Inc. AX75 Side View Sieme n s Communication s, Inc. AX75 Side View

Date 12.11.2004 Approval label Name Li Gang AX75/IMEI-Label/Standard MP PD LPD Z30880-Z9999-Z27-* 1 12.11.04 Li_G LETTERING PLAN Version Date Token SIEMENS AG DIS 91798 Page 1 From 1 A24850-V1-A4-2 VORSTD.DOC White label with black lettering SIEMENS AX75 S30880-SXXXX-XXXX-1 YY XXXXXXXX SSSSSS C 0682 Typ-Approval Code: TAC Made xx Xxxxxxx Barcode: Typ 128, table C and B Characteristic: IMEI-No. has 15 digits Digit 1-14 is generated as Barcode with table C . Digit 15 is printed with table B. 1)2) 4) 5) 6) 7) 8) Current serial number (6 digits) Assigned by PICS Final-Assembly Code: FAC 15. digit CHECK DIGIT 10) 10) 10) 11) 12) FCC ID: PWX-AX75 IC:267E-AX75 13) Ink ribbon: TTR-Band Ricoh 110-A Font: Title blocks concentric 1) Corporate logo: 1.5 SN 66324 2) Product name: Internal font D, size 4 4) Code of date: Internal font D, size 4 e.g. F3  March └─1995 5) Code number: Internal font D, size 4 6) CE- identification: Height: 5 mm 7) Barcode IMEI-No.: Code: 128 Size: 2 Ratio: 3.0 Height: 3 mm 8) IMEI-No. (plain writing): Internal font D, size 4, space between TAC, FAC, serial no. and 15.digit 10) Document for IMEI-No. allocation: DIS 93162 Valid is the highest level in the system 11) Code number: Corresponding to the number of the transceiver unit part list 12) “Made in Germany“ For production in Germany “Made in Xxxxxxx“ For production out of Germany – for details please see lettering plan of retail box label 13) Canada IC and US FCC font: B3 Figure 1 Placement of IMEI label on AX75

Sieme n s Communication s, Inc. AX75 Open Battery Cover (Final label: See extra exhibit) Sieme n s Communication s, Inc. AX75 Disassembly Step 1 Sieme n s Communication s, Inc. AX75 Disassembly Step 2 Sieme n s Communication s, Inc. AX75 Disassembly Step 3 Sieme n s Communication s, Inc. AX75 Back view shields removed Sieme n s Communication s, Inc. AX75 Back view repair lid installed Sieme n s Communication s, Inc. AX75 Tri-Band Antenna

DAT-P-152/98-01 SAR Report, Siemens_6620_495_FCC_1900_Caldata_AX75 Appendix for the Report Dosimetric Assessment of the Siemens AX75 (FCC ID: PWX-AX75) According to the FCC Requirements Calibration Data May 23, 2005 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Siemens Information & Communication Mobile LLC 16475 West Bernado Dirve, Suite 400 CA 92127 San Diego The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory.

DAT-P-152/98-01 SAR Report, Siemens_6620_479_FCC_1900_SAR Plots_AX75 Page 1 of 15 Appendix for the Report Dosimetric Assessment of the Siemens AX75 (FCC ID: PWX-AX75) According to the FCC Requirements SAR Distribution Plots May 20, 2005 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Siemens Information & Communication Mobile LLC 16475 West Bernado Drive, Suite 400 CA 92127 San Diego The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. dasy_report_fcc_1900_plots_1.0.doc/05.01.2005/ABo SAR Report, Siemens_6620_479_FCC_1900_SAR Plots_AX75 Page 2 of 15 dasy_report_fcc_1900_plots_1.0.doc/05.01.2005/ABo Table of Contents 1 SAR DISTRIBUTION PLOTS, PCS 1900 HEAD, WITHOUT CAMERA................................................. 3 2 SAR DISTRIBUTION PLOTS, PCS 1900 HEAD, WITH CAMERA......................................................... 7 3 SAR DISTRIBUTION PLOTS, PCS 1900 BODY WORN (GAP = 15 MM)........................................... 11 4 SAR Z-AXIS SCANS (VALIDATION)......................................................................................................... 14 5 SAR Z-AXIS SCANS (MEASUREMENTS)................................................................................................ 15 SAR Report, Siemens_6620_479_FCC_1900_SAR Plots_AX75 Page 3 of 15 dasy_report_fcc_1900_plots_1.0.doc/05.01.2005/ABo 1 SAR Distribution Plots, PCS 1900 head, without camera Test Laboratory: IMST GmbH, DASY Yellow (II); File Name: 090yplm_1.da4 DUT: Siemens; Type: AX75 ; Serial: 004400009038090 Program Name: Cheek Left Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.4 mho/m; ε r = 40.5; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(8.19, 8.19, 8.19); Calibrated: 27.08.2004 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn631; Calibrated: 23.07.2004 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek Left/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.342 mW/g Cheek Left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm;Reference Value = 15.5 V/m; Power Drift = 0.198 dB Peak SAR (extrapolated) = 0.504 W/kg SAR(1 g) = 0.326 mW/g; SAR(10 g) = 0.194 mW/g Maximum value of SAR (measured) = 0.369 mW/g Cheek Left/Zoom Scan (7x7x7)/Cube 1: Measurement grid: dx=5mm, dy=5mm, dz=5mm;Reference Value = 15.5 V/m; Power Drift = 0.198 dB Peak SAR (extrapolated) = 0.239 W/kg SAR(1 g) = 0.203 mW/g; SAR(10 g) = 0.136 mW/g Maximum value of SAR (measured) = 0.220 mW/g Cheek Left/Zoom Scan (7x7x7)/Cube 2: Measurement grid: dx=5mm, dy=5mm, dz=5mm;Reference Value = 15.5 V/m; Power Drift = 0.198 dB Peak SAR (extrapolated) = 0.426 W/kg SAR(1 g) = 0.288 mW/g; SAR(10 g) = 0.168 mW/g Maximum value of SAR (measured) = 0.322 mW/g Fig. 1: SAR distribution for PCS 1900, channel 661, cheek position, left side of head (05.13.2005; Ambient Temperature: 21.1° C; Liquid Temperature: 20.6° C). SAR Report, Siemens_6620_479_FCC_1900_SAR Plots_AX75 Page 4 of 15 dasy_report_fcc_1900_plots_1.0.doc/05.01.2005/ABo Test Laboratory: IMST GmbH, DASY Yellow (II); File Name: 090yplm_2.da4 DUT: Siemens; Type: AX75 ; Serial: 004400009038090 Program Name: Tilted Left Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.4 mho/m; ε r = 40.5; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(8.19, 8.19, 8.19); Calibrated: 27.08.2004 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn631; Calibrated: 23.07.2004 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Tilted Left/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.444 mW/g Tilted Left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 17.1 V/m; Power Drift = 0.011 dB Peak SAR (extrapolated) = 0.588 W/kg SAR(1 g) = 0.415 mW/g; SAR(10 g) = 0.234 mW/g Maximum value of SAR (measured) = 0.467 mW/g Fig. 2: SAR distribution for PCS 1900, channel 661, tilted position, left side of head (05.13.2005; Ambient Temperature: 21.1° C; Liquid Temperature: 20.6° C). SAR Report, Siemens_6620_479_FCC_1900_SAR Plots_AX75 Page 5 of 15 dasy_report_fcc_1900_plots_1.0.doc/05.01.2005/ABo Test Laboratory: IMST GmbH, DASY Yellow (II); File Name: 090yprm_1.da4 DUT: Siemens; Type: AX75 ; Serial: 004400009038090 Program Name: Cheek Right Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.4 mho/m; ε r = 40.5; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(8.19, 8.19, 8.19); Calibrated: 27.08.2004 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn631; Calibrated: 23.07.2004 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek Right/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.267 mW/g Cheek Right/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 13.5 V/m; Power Drift = 0.067 dB Peak SAR (extrapolated) = 0.404 W/kg SAR(1 g) = 0.261 mW/g; SAR(10 g) = 0.175 mW/g Maximum value of SAR (measured) = 0.286 mW/g Cheek Right/Zoom Scan (7x7x7)/Cube 1: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 13.5 V/m; Power Drift = 0.067 dB Peak SAR (extrapolated) = 0.376 W/kg SAR(1 g) = 0.242 mW/g; SAR(10 g) = 0.147 mW/g Maximum value of SAR (measured) = 0.272 mW/g Fig. 3: SAR distribution for P…

Text truncated - open the document above for the full version.

DAT-P-152/98-01 SAR Report, Siemens_6620_479_FCC_1900_AX75 Page 1 of 35 Report Dosimetric Assessment of the Portable Device Siemens AX75 (FCC ID: PWX-AX75) According to the FCC Requirements May 20, 2005 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer dasy_report_fcc_ 1900_4.1.doc/07 . 01..2005/C H Siemens Information & Communication Mobile LLC 16475 West bernado Drive, Suite 400 CA 92127 San Diego The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. SAR Report, Siemens_6620_479_FCC_1900_AX75 Page 2 of 35 dasy_report_fcc_ 1900_4.1.doc/07 . 01..2005/C H Executive Summary The AX75 is a mobile phone (Portable Device) from Siemens operating in the 900 MHz, 1800 MHz and 1900 MHz frequency range. The device has an integrated antenna and the system concepts used are the GSM 900, GSM 1800 and PCS 1900 standards including GPRS Class 8. The objective of the measurements done by IMST was the dosimetric assessment of one device in the PCS 1900 standard. The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the Supplement C to OET Bulletin 65 of the Federal Communications Commission (FCC) Guidelines [OET 65] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions. All measurements have been performed in accordance to the recommendations given by SPEAG. The Siemens AX75 mobile phone (FCC ID: PWX-AX75) is in compliance with the Federal Communications Commission (FCC) Guidelines [OET 65] for uncontrolled exposure. The phone was tested in addition to the head positions in the following configurations: • Body worn with the following accessories and 15 mm distance: GSM without accessory GSM with headset GPRS (Class 8) with data cable prepared by: ........................................... reviewed by: ..................................... Alexander Rahn Dipl.- Ing. Christoph Hennes test engineer quality assurance engineer IMST GmbH Carl-Friedrich-Gauß-Straße 2 D-47475 Kamp-Lintfort Tel. +49- 2842-981 373 Fax +49- 2842-981 399 email: [email protected] SAR Report, Siemens_6620_479_FCC_1900_AX75 Page 3 of 35 dasy_report_fcc_1900_4.1.doc/07.01..2005/CH Table of Contents 1 SUBJECT OF INVESTIGATION.................................................................................................................... 4 2 THE IEEE STANDARD C95.1 AND THE FCC EXPOSURE CRITERIA................................................. 4 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES........... 4 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS....................................... 5 2.3 SAR LIMIT.................................................................................................................................................. 5 3 THE FCC MEASUREMENT PROCEDURE................................................................................................. 6 3.1 GENERAL REQUIREMENTS......................................................................................................................... 6 3.2 DEVICE OPERATING NEXT TO A PERSON’S EAR....................................................................................... 6 4 BODY-WORN CONFIGURATIONS.............................................................................................................. 9 4.1 POC (PTT) POSITION...............................................................................................................................9 4.2 PHANTOM REQUIREMENTS...................................................................................................................... 10 4.3 TEST TO BE PERFORMED......................................................................................................................... 10 5 THE MEASUREMENT SYSTEM................................................................................................................. 10 5.1 PHANTOM................................................................................................................................................. 12 5.2 PROBE...................................................................................................................................................... 12 5.3 MEASUREMENT PROCEDURE.................................................................................................................. 13 5.4 UNCERTAINTY ASSESSMENT................................................................................................................... 14 6 SAR RESULTS............................................................................................................................................... 15 7 EVALUATION................................................................................................................................................. 17 8 APPENDIX....................................................................................................................................................... 19 8.1 ADMINISTRATIVE DATA............................................................................................................................ 19 8.2 DEVICE UNDER TEST AND TEST CONDITIONS......................................................................................... 19 8.3 TISSUE RECIPES...................................................................................................................................... 20 8.4 MATERIAL PARAMETERS......................................................................................................................... 20 8.5 SIMPLIFIED PERFORMANCE CHECKING................................................................................................... 21 8.6 ENVIRONMENT............................................…

Text truncated - open the document above for the full version.

Siemens A/S Mobile Phones Development Project: AX75 Siemens Kaj 1 Date: 19-05-2005 DK-9400 Noerresundby Test case: Conducted pow. Denmark Page: 1 of 5 ________________________________________________________________________________ - 1 - Report No: AX75_Conducted _Report_FCC.doc Test Report Conducted Output power GSM 1900 Report No: EMC_AX75_B6E Issue date: May 19, 2005 Test Site: Siemens A/S Mobile Phones Development ICM MP PD HW 1 AAL 1 DK-9400 Noerresundby Denmark Tel.: +45 72 19 50 00 Fax.: +45 72 19 50 02 Arne Bisgaard Kristensen Part Project Leader EMC & Antenna Morten Christensen Line Group Manager EMC & Antenna Siemens A/S Mobile Phones Development Project: AX75 Siemens Kaj 1 Date: 19-05-2005 DK-9400 Noerresundby Test case: Conducted pow. Denmark Page: 2 of 5 ________________________________________________________________________________ - 2 - Report No: AX75_Conducted _Report_FCC.doc Contents 1 Objective and Method ..............................................................................3 2 Results.......................................................................................................3 2.1 GSM 1900 .................................................................................................................3 3 Minutes of Test .........................................................................................3 3.1 Description of device under test................................................................................3 3.2 Measurement Set-up ................................................................................................4 4 Calibration Certificate ..............................................................................5 Siemens A/S Mobile Phones Development Project: AX75 Siemens Kaj 1 Date: 19-05-2005 DK-9400 Noerresundby Test case: Conducted pow. Denmark Page: 3 of 5 ________________________________________________________________________________ - 3 - Report No: AX75_Conducted _Report_FCC.doc 1 Objective and Method FCC approval for mobile phones requires reporting output power at RF output terminal pursuant to title 47 CFR part 2.1046. SIEMENS devices feature a special 50 Ohm RF connector suitable for such measurements. Using a special adapter and connecting the phone to an appropriate load in terms of the input port of the measurement equipment used, we hereby report the values for highest power setting. 2 Results 2.1 GSM 1900 Average Power during burst at connector Device Ch. 512 1850.2 MHz Ch. 661 1880.0 MHz Ch. 810 1909.8 MHz Siemens AX75, ”FCC Sample B2_7” IMEI: 004400009037662 + 29.3 dBm + 29.2 dBm + 29.3 dBm Siemens AX75, ”FCC Sample FCC 8” IMEI: 004400009038439 + 29.3 dBm + 29.1 dBm + 29.2 dBm Siemens AX75, ”FCC Sample B2_13” IMEI: 004400009038090 + 29.3 dBm + 29.2 dBm + 29.3 dBm Siemens AX75, ”FCC Sample B2_14” IMEI: 004400009037670 + 29.3 dBm + 29.2 dBm + 29.3 dBm Table 2: Results of power measurements at connector in the GSM 1900 Band 3 Minutes of Test 3.1 Description of device under test Mobile phone: Siemens AX75 Frequency range GSM 1900: 1850 – 1990 MHz Siemens Part number: L36880-N2850-xxxx FCC ID: PWX-AX75 IC ID: 267E-AX75 Siemens A/S Mobile Phones Development Project: AX75 Siemens Kaj 1 Date: 19-05-2005 DK-9400 Noerresundby Test case: Conducted pow. Denmark Page: 4 of 5 ________________________________________________________________________________ - 4 - Report No: AX75_Conducted _Report_FCC.doc 3.2 Measurement Set-up Figure 1: Block Diagram of set-up for conducted power measurement Figure 2: Set-up for conducted power measurement Base Station Simulator DUT Special Adapter Siemens A/S Mobile Phones Development Project: AX75 Siemens Kaj 1 Date: 19-05-2005 DK-9400 Noerresundby Test case: Conducted pow. Denmark Page: 5 of 5 ________________________________________________________________________________ - 5 - Report No: AX75_Conducted _Report_FCC.doc 4 Calibration Certificate

TTI-P-G 081/94-A0 Accredited according to ISO/IEC 17025 Bluetooth Qualification Test Facility (BQTF) FCC listed # 101450 IC recognized # 3925 CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2113686 Board of Directors: Dr. Harald Ansorge, Dr. Klaus Matkey, Hans Peter May V1.1 2003-03-01 The BLUETOOTH trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to CETECOM Inc. © Copyright by CETECOM FCC Test report Test report no.: EMC_943FCC-24_2005_AX75 FCC Part 24 / RSS 133 FCC ID: PWX-AX75 IC ID: 267E-AX75 CETECOM Inc. Test report no.: EMC_943FCC-24_2005_AX75 Issue date: 2005-06-13 Page 2 (51) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test report 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM Inc. does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM Inc. TEST REPORT PREPARED BY: EMC Engineer: Harpreet Sidhu 1.2 Testing laboratory CETECOM Inc. 411 Dixon Landing Road, Milpitas, CA-95035, USA Phone: +1 408 586 6200 Fax: +1 408 586 6299 E-mail: [email protected] Internet: www.cetecom.com CETECOM Inc. Test report no.: EMC_943FCC-24_2005_AX75 Issue date: 2005-06-13 Page 3 (51) 1.3 Details of applicant Name : SIEMENS ICM Street : 16745 West Bernardo Drive City / Zip Code : San Diego CA 92127 Country : U.S.A Contact : Kevin Wolentarski Telephone : +1 858-521-3352 Tele-fax : +1 858-521-3105 e-mail : [email protected] 1.4 Application details Date of receipt test item : 2005-05-31 Date of test : 2005-05-31, 2005-06-06/09 1.5 Test item Manufacturer : SIEMENS Street Address : Suedstr. 9 City / Zip Code : 47475 Kamp-Lintfort Country : Germany Marketing Name : AX75 Model No. : AX75 Description : GSM 1900 Mobile Phone FCC-ID : PWX-AX75 IC ID : 267E-AX75 Additional information Test Sample for GSM : IMEI: 00-4400-903766-2 Frequency : 1850.2MHz – 1909.8MHz for PCS 1900 Type of modulation : GMSK Number of channels : 299 for PCS 1900 Antenna : Patch Antenna Power supply : Battery or Charger (AC Adaptor) Output power : 30.22dBm (1.05W) max. EIRP measured for PCS 1900 Extreme vol. Limits : 3.6VDC to 4.5VDC (nominal: 3.7VDC) Extreme temp. Tolerance : -30°C to +50°C 1.6 Test standards FCC Part 24 / RSS133 r1 CETECOM Inc. Test report no.: EMC_943FCC-24_2005_AX75 Issue date: 2005-06-13 Page 4 (51) 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course of the tests Performed Final Verdict: (only “passed” if all single measurements are “passed”) Passed Technical respon…
