PWX-SP65GSM 900/1800/1900 Mobile Phone with BT

© Siemens AG 2003, C:\Daten\Siemens\P rodukte\SP65_1\output\FUG\am\SP65IVZ.fm Table of Contents1 VAR Language: am; VAR issue date: 040819 See also Index at the end of this User Guide right page (1) of SP65 FUG am, A31008-H7450-A40-1-4A19 (15.02.2005, 16:10) Legal notices .............................. 3 Safety precautions ..................... 5 Antenna care ........................... 7 Phone operation ...................... 7 Electronic devices .................... 8 Overview of phone .................. 11 Display symbols ....................... 13 Getting started ......................... 15 Inserting the SIM card/battery ..................... 15 Inserting an RS MultiMediaCard™ .............. 16 Charging the battery .............. 17 Switching on/off, PIN entry ...... 19 Entering the PIN ..................... 19 Emergency number (SOS) ...... 19 General instructions ................ 20 Standby mode ....................... 20 Signal strength ...................... 20 Digital Rights Mgmt. (DRM) .... 20 Main menu ............................ 20 Standard functions .................. 22 Highlighting mode ................. 23 Menu speed dialling ............... 23 Security .................................... 24 PIN code ................................ 24 Preventing accidental activation ............................... 25 Text entry ................................. 26 Calling ...................................... 30 My items .................................. 36 Default book ............................ 37 Address book ............................ 38 New entry .............................. 38 Changing an entry .................. 40 Calling an entry ...................... 40 Groups ................................... 41 Phonebook ............................... 42 New entry .............................. 42 Calling (searching for an entry) .......... 43 Changing an entry .................. 43 <Special books> ..................... 44 Call records ............................... 45 Dur./charges ............................. 46 Main Inbox ............................... 47 SMS ........................................... 48 Writing/sending ...................... 48 Reading .................................. 50 Setting ................................... 52 MMS ......................................... 54 Creating an MMS .................... 54 Templates .............................. 56 Sending ................................. 57 Receiving ............................... 58 Reading .................................. 59 Setting ................................... 60 E-mail ........................................ 62 Writing ................................... 62 Receiving/reading ................... 63 Setting ................................... 64 Voice message/mailbox ............ 65 Table of Con- tents See also Index at the end of this User Guide © Siemens AG 2003, C:\Daten\Siemens\Pr odukte\SP65_1\output\FUG\am\SP65IVZ.fm 2Table of Contents VAR Language: am; VAR issue date: 040819 See also Index at the end of this User Guide left page (2) of SP65 FUG am, A31008-H7450-A40-1-4A19 (15.02.2005, 16:10) Chat room ................................ 66 Start menu ............................. 66 Login ..................................... 67 Contact lists ........................... 67 Starting Chat room ................. 70 Msg. history ........................... 71 Setting ................................... 71 CB services ............................... 73 Zoom in ................................. 73 Surf & fun ................................. 74 Internet ................................. 74 Bookmarks ............................. 76 Games and Applications ......... 77 Download wiz. ....................... 77 Settings .................................... 79 Profiles .................................. 79 Topics .................................... 81 Display setup ......................... 82 Ring tones ............................. 84 Call setup ............................... 86 Phone setup ........................... 88 Clock ..................................... 90 Connectivity .......................... 91 Security ................................. 97 Network ................................ 99 Accessories .......................... 101 My menu ................................ 102 Fast access ............................. 103 Speed dialling keys ............... 104 Organizer ............................... 105 Calendar .............................. 105 Appointments ...................... 106 Tasks ................................... 107 Notes ................................... 108 Missed appts. ....................... 108 Dictation mac ....................... 109 Time zones ........................... 110 Extras ...................................... 111 SIM services (optional) ......... 111 Alarm clock .......................... 111 Calc. ..................................... 112 Unit converter ...................... 113 Stopwatch ............................ 114 Countdown .......................... 114 Sound recorder ..................... 114 Remote synchronisation ....... 115 Device manag. ..................... 116 Sound recorder ....................... 117 Media player ........................... 118 My stuff .................................. 119 RS MultiMediaCard™ ............ 120 Mobile Phone Manager .......... 121 Questions & Answers ............. 123 Customer Care ........................ 126 Care and maintenance ........... 128 Product data ........................... 129 Accessories ............................. 130 SAR (SP65) .............................. 132 Quality .................................... 134 U.S. FDA .................................. 135 FCC/Industry Canada Notice ..... 141 Ten Driving Safety Tips ........... 142 Intellectual property .............. 144 End user license agreement ..... 145 Menu tree ............................... 149 Index .................…

Text truncated - open the document above for the full version.

Siemens Communications, Inc. SP65 Front View Siemens Communications, Inc. SP65 Back View Siemens Communications, Inc. SP65 Side View Siemens Communications, Inc. SP65 Side View

Siemens Communications, Inc. Page 1 2/23/2005 SP65 IMEI LABEL and LABEL LOCATION Siemens Communications, Inc. Page 2 2/23/2005 SP65 IMEI LABEL and LABEL LOCATION

Siemens Communications, Inc. SP65 Open battery cover (Final label: See extra exhibit) Siemens Communications, Inc. SP65 Disassembly step 1 Siemens Communications, Inc. SP65 Disassembly step 2 Siemens Communications, Inc. SP65 Disassembly step 3 Siemens Communications, Inc. SP65 PCB Front View Shields Removed Siemens Communications, Inc. SP65 PCB Rear View Shields Removed Siemens Communications, Inc. SP65 GSM Tri-band antenna

DAT-P-152/98-01 SAR Report, Siemens_6620_471_FCC_1900_Caldata_SP65 Appendix for the Report Dosimetric Assessment of the Siemens SP65 (FCC ID: PWX-SP65) According to the FCC Requirements Calibration Data February 08, 2005 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Siemens Information & Communication Mobile LLC 16475 West Bernado Dirve, Suite 400 CA 92127 San Diego The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory.

DAT-P-152/98-01 SAR Report, Siemens_6620_471_FCC_1900_SAR Plots_SP65 Page 1 of 12 Appendix for the Report Dosimetric Assessment of the Siemens SP65 (FCC ID: PWX-SP65) According to the FCC Requirements SAR Distribution Plots February 08, 2005 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Siemens Information & Communication Mobile LLC 16475 West Bernado Dirve, Suite 400 CA 92127 San Diego The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. dasy_report_fcc_1900_plots_1.0.doc/05.01.2005/ABo SAR Report, Siemens_6620_471_FCC_1900_SAR Plots_SP65 Page 2 of 12 dasy_report_fcc_1900_plots_1.0.doc/05.01.2005/ABo Table of Contents 1 SAR DISTRIBUTION PLOTS, PCS 1900 HEAD....................................................................................... 3 2 SAR DISTRIBUTION PLOTS, PCS 1900 BODY WITH HEADSET IN GSM MODE............................ 8 3 SAR DISTRIBUTION PLOTS, GPRS 1900 (CLASS 10)........................................................................... 9 4 SAR Z-AXIS SCANS (VALIDATION)......................................................................................................... 11 5 SAR Z-AXIS SCANS (MEASUREMENTS)................................................................................................ 12 SAR Report, Siemens_6620_471_FCC_1900_SAR Plots_SP65 Page 3 of 12 dasy_report_fcc_1900_plots_1.0.doc/05.01.2005/ABo 1 SAR Distribution Plots, PCS 1900 head Test Laboratory: IMST GmbH; File Name: 730bplm_1.da4; DUT: Siemens; Type: SP65; Serial: 353910009449730 Program Name: Cheek Left Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: σ = 1.43; mho/m, ε r = 40.5; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: ET3DV6R - SN1579; ConvF(5.28, 5.28, 5.28); Calibrated: 13.01.2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 05.08.2004 - Phantom: SAM Glycol 1176; Type: Speag; Serial: 1176 - Measurement SW: DASY4, V4.3 Build 16; Postprocessing SW: SEMCAD, V1.8 Build 127 Cheek Left/Area Scan (6x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.359 mW/g Cheek Left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 27.8 V/m; Power Drift = 0.113 dB Peak SAR (extrapolated) = 0.610 W/kg SAR(1 g) = 0.351 mW/g; SAR(10 g) = 0.200 mW/g Maximum value of SAR (measured) = 0.398 mW/g Cheek Left/Zoom Scan (7x7x7)/Cube 1: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 27.8 V/m; Power Drift = 0.113 dB Peak SAR (extrapolated) = 0.431 W/kg SAR(1 g) = 0.279 mW/g; SAR(10 g) = 0.179 mW/g Maximum value of SAR (measured) = 0.302 mW/g Fig. 1: SAR distribution for PCS 1900, channel 661, cheek position, left side of head (31.01.2005; Ambient Temperature: 21.8° C; Liquid Temperature: 20.9° C). SAR Report, Siemens_6620_471_FCC_1900_SAR Plots_SP65 Page 4 of 12 dasy_report_fcc_1900_plots_1.0.doc/05.01.2005/ABo Test Laboratory: IMST GmbH; File Name: 730bplm_2.da4 DUT: Siemens; Type: SP65; Serial: 353910009449730 Program Name: Tilted Left Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: σ = 1.43; mho/m, ε r = 40.5; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: ET3DV6R - SN1579; ConvF(5.28, 5.28, 5.28); Calibrated: 13.01.2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 05.08.2004 - Phantom: SAM Glycol 1176; Type: Speag; Serial: 1176 - Measurement SW: DASY4, V4.3 Build 16; Postprocessing SW: SEMCAD, V1.8 Build 127 Tilted Left/Area Scan (6x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.331 mW/g Tilted Left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 30.1 V/m; Power Drift = 0.035 dB Peak SAR (extrapolated) = 0.508 W/kg SAR(1 g) = 0.309 mW/g; SAR(10 g) = 0.177 mW/g Maximum value of SAR (measured) = 0.334 mW/g Fig. 2: SAR distribution for PCS 1900, channel 661, tilted position, left side of head (31.01.2005; Ambient Temperature: 21.8° C; Liquid Temperature : 20.9° C). SAR Report, Siemens_6620_471_FCC_1900_SAR Plots_SP65 Page 5 of 12 dasy_report_fcc_1900_plots_1.0.doc/05.01.2005/ABo Test Laboratory: IMST GmbH; File Name: 730bprm_1.da4 DUT: Siemens; Type: SP65; Serial: 353910009449730 Program Name: Cheek Right Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: σ = 1.43; mho/m, ε r = 40.5; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ET3DV6R - SN1579; ConvF(5.28, 5.28, 5.28); Calibrated: 13.01.2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 05.08.2004 - Phantom: SAM Glycol 1176; Type: Speag; Serial: 1176 - Measurement SW: DASY4, V4.3 Build 16; Postprocessing SW: SEMCAD, V1.8 Build 127 Cheek Right/Area Scan (6x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.366 mW/g Cheek Right/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 24.7 V/m; Power Drift = -0.105 dB Peak SAR (extrapolated) = 0.556 W/kg SAR(1 g) = 0.318 mW/g; SAR(10 g) = 0.175 mW/g Maximum value of SAR (measured) = 0.362 mW/g Cheek Right/Zoom Scan (7x7x7)/Cube 1: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 24.7 V/m; Power Drift = -0.105 dB Peak SAR (extrapolated) = 0.718 W/kg SAR(1 g) = 0.389 mW/g; SAR(10 g) = 0.184 mW/g Maximum value of SAR (measured) = 0.456 mW/g Fig. 3: SAR distribution for PCS 1900, channel 661, cheek position, right side of head (31.01.2005; Ambient Temperature: 21.9° C; Liquid Temperature : 20.9° C). SAR Report, Siemens_6620_471_FCC_1900_SAR Plots_SP65 Page 6 of 12 dasy_report_fcc_1900_plots_1.0.doc/05.01.2005/ABo Test Laboratory: IMST GmbH; File Name: 730bprm_2.da4 DUT: Siemens; Type: SP65; Serial: 353910009449730 Program Name:…

Text truncated - open the document above for the full version.

DAT-P-152/98-01 SAR Report, Siemens_6620_471_FCC_1900_SP65 Page 1 of 32 Report Dosimetric Assessment of the Portable Device Siemens SP65 (FCC ID: PWX-SP65) According to the FCC Requirements February 08, 2005 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Siemens Information & Communication Mobile LLC 16475 West Bernado Drive, Suite 400 CA 92127 San Diego The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. dasy_report_fcc_1900_4.1.doc/07.01..2005/CH SAR Report, Siemens_6620_471_FCC_1900_SP65 Page 2 of 32 dasy_report_fcc_1900_4.1.doc/07.01..2005/CH Executive Summary The SP65 is a mobile phone (Portable Device) from Siemens operating in the 900 MHz, 1800 MHz and 1900 MHz frequency range. The device has an integrated antenna and the system concepts used are the GSM 900, GSM 1800 and PCS 1900 standards including GPRS Class 10 capability. The objective of the measurements done by IMST was the dosimetric assessment of one device in the PCS 1900 standard. The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the Supplement C to OET Bulletin 65 of the Federal Communications Commission (FCC) Guidelines [OET 65] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions. All measurements have been performed in accordance to the recommendations given by SPEAG. The Siemens SP65 mobile phone (FCC ID: PWX-SP65) is in compliance with the Federal Communications Commission (FCC) Guidelines [OET 65] for uncontrolled exposure. The phone was tested in addition to the head positions in the following configurations: • Body worn with the following accessories and 22 mm distance: GSM with headset GPRS (Class 10) prepared by: ........................................... reviewed by: ..................................... André van den Bosch Dipl.- Ing. Christoph Hennes test engineer quality assurance engineer IMST GmbH Carl-Friedrich-Gauß-Straße 2 D-47475 Kamp-Lintfort Tel. +49- 2842-981 373 Fax +49- 2842-981 399 email: [email protected] SAR Report, Siemens_6620_471_FCC_1900_SP65 Page 3 of 32 dasy_report_fcc_1900_4.1.doc/07.01..2005/CH Table of Contents 1 SUBJECT OF INVESTIGATION.................................................................................................................... 4 2 THE IEEE STANDARD C95.1 AND THE FCC EXPOSURE CRITERIA................................................. 4 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES........... 4 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS....................................... 5 2.3 SAR LIMIT.................................................................................................................................................. 5 3 THE FCC MEASUREMENT PROCEDURE................................................................................................. 6 3.1 GENERAL REQUIREMENTS......................................................................................................................... 6 3.2 DEVICE OPERATING NEXT TO A PERSON’S EAR....................................................................................... 6 4 BODY-WORN CONFIGURATIONS.............................................................................................................. 9 4.1 POC (PTT) POSITION...............................................................................................................................9 4.2 PHANTOM REQUIREMENTS...................................................................................................................... 10 4.3 TEST TO BE PERFORMED......................................................................................................................... 10 5 THE MEASUREMENT SYSTEM................................................................................................................. 10 5.1 PHANTOM................................................................................................................................................. 12 5.2 PROBE...................................................................................................................................................... 12 5.3 MEASUREMENT PROCEDURE.................................................................................................................. 13 5.4 UNCERTAINTY ASSESSMENT................................................................................................................... 14 6 SAR RESULTS............................................................................................................................................... 15 7 EVALUATION................................................................................................................................................. 17 8 APPENDIX....................................................................................................................................................... 18 8.1 ADMINISTRATIVE DATA............................................................................................................................ 18 8.2 DEVICE UNDER TEST AND TEST CONDITIONS......................................................................................... 18 8.3 TISSUE RECIPES...................................................................................................................................... 19 8.4 MATERIAL PARAMETERS......................................................................................................................... 19 8.5 SIMPLIFIED PERFORMANCE CHECKING................................................................................................... 20 8.6 ENVIRONMENT...................................................................…

Text truncated - open the document above for the full version.

TTI-P-G 081/94-A0 Accredited according to ISO/IEC 17025 Bluetooth Qualification Test Facility (BQTF) FCC listed # 101450 IC recognized # 3925 CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2113686 Board of Directors: Dr. Harald Ansorge, Dr. Klaus Matkey, Hans Peter May V1.1 2003-03-01 The BLUETOOTH trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to CETECOM Inc. © Copyright by CETECOM FCC Test Report Test report no.: EMC_852FCC15.247_2005_SP65 FCC Part 15.247 for FHSS systems / CANADA RSS-210 Model: SP65 FCC ID: PWX-SP65 IC: 267E-SP65 Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 2 (64) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test report 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM Inc. USA does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM Inc USA. TEST REPORT PREPARED BY: EMC Engineer: Neelesh Raj 1.2 Testing laboratory CETECOM Inc. 411 Dixon Landing Road, Milpitas, CA-95035, USA Phone: +1 408 586 6200 Fax: +1 408 586 6299 E-mail: [email protected] Internet: www.cetecom.com Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 3 (64) 1.3 Details of applicant Name : SIEMENS Information and Communication Mobile LLC Street : 16745 West Bernardo Drive Suite 400 City / Zip Code : San Diego, CA 92127 Country : USA Contact : Kevin Wolentarski Telephone : 858-521-3352 Tele-fax : 858-521-3105 e-mail : [email protected] 1.4 Application details Date of receipt test item : 2005-02-17 Date of test : 2005-02-17 - 2005-03-15 1.5 Test item Manufacturer : SIEMENS Communications, Inc. Street Address : Sudstr. 9 City / Zip Code : D-47475 Kamp-Lintfort Country : Germany Marketing Name : SP65 Model No. : SP65 Description : GSM 1900 Mobile phone with BT FCC-ID : PWX-SP65 IC ID : 267E-SP65 Additional information Test Sample : IMEI: 35-3910-00-944930-0 Frequency : 2402MHz – 2480MHz for BT Type of modulation : GFSK Number of channels : 79 Antenna : External Power supply : Battery or Charger (AC Adaptor) Output power : -0.41dBm (0.9099mW) max. conducted peak power Extreme vol. Limits : 3.6VDC to 4.5VDC (nominal: 3.7VDC) Extreme temp. Tolerance : -30°C to +50°C 1.6 Test standards: FCC Part 15 §15.247 (DA00-705) / RSS 210 Note: All radiated measurements were made in all three orthogonal planes. The values reported are the maximum values. Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 4 (64) 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course of the tests Performed Final Verdict: (only “passed” if all single measurements are “passed”) Passed Technical responsibility for area of testing: 2005-05-15 EMC & Radio Lothar Schmidt (Manager) Date Section Name Signature Responsible for test report and project leader: 2005-05-15 EMC & Radio Neelesh Raj (EMC Engineer) Date Section Name Signature Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 5 (64) 2.2 Test report TEST REPORT Test report no.: EMC_852FCC15.247_2005_SP65 Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 6 (64) TEST REPORT REFERENCE LIST OF MEASUREMENTS PAGE CARRIER FREQUENCY SEPERATION §15.247(a) 7 NUMBER OF HOPPING CHANNELS §15.247(a) 8 TIME OF OCCUPANCY (DWELL TIME) §15.247(a) 12 SPECTRUM BANDWIDTH OF FHSS SYSTEM §15.247(a) 15 MAXIMUM PEAK OUTPUT POWER (CONDUCTED) § 15.247 (b) (1) 19 MAXIMUM PEAK OUTPUT POWER (RADIATED) § 15.247 (b) (1) 23 BAND EDGE COMPLIANCE §15.247 (c) 27 EMISSION LIMITATIONS Transmitter (Conducted) § 15.247 (c) (1) 31 EMISSION LIMITATIONS Transmitter (Radiated) § 15.247 (c) (1) 38 CO-LOCATION – (Radiated) Transmitter 49 CONDUCTED EMISSIONS § 15.107/207 54 RECEIVER SPURIOUS RADIATION § 15.209 56 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS 62 BLOCK DIAGRAMS 63 Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 7 (64) CARRIER FREQUENCY SEPERATION §15.247(a) Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 8 (64) NUMBER OF HOPPING CHANNELS §15.247(a) The number of hopping channels is 79 (see next 4 plots) The F1 line corresponds to the F2 line from the next plot. Plot 1: Total 24 Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 9 (64) Plot 2: Total 25 Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 10 (64) Plot 3: Total 20 Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 11 (64) Plot 4: Total 10 Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 12 (64) TIME OF OCCUPANCY (DWELL TIME) §15.247(a) DH1 – Packet The system makes worst case 1600 hops per second or 1 time slot has a length of 625μs with 79 channels. A DH1 Packet need 1 time slot for transmitting and 1 time slot for receiving. Then the system makes worst case 800 hops per second with 79 channels. So you have each channel 10.13 times per second and so for 31.6 seconds you have 320.108 times of appearance. Each Tx-time per appearance is 416.83μs. So we have 320.108 * 416.834μs = 133.4ms per 31.6 seconds. Test report no.: EMC_852FCC15.247_2005_SP65 Issue date: 2005-03-15 Page 13 (64) TIME OF OCCUPANCY (DWELL TIME) §15.247(a) DH3 – Packet A DH3 Packets need 3 time slots for transm…

Text truncated - open the document above for the full version.

Test setup photos SP65 Test setup – Radiated Emissions Test setup photos SP65 Test setup – Conducted measurements BT Test setup photos SP65 Test setup – Conducted measurements GSM Test setup photos SP65 Test setup – AC Line conducted measurements
