PX8MU-6100ComFlex 600 Series DAS

Comba Telecom Network Systems Limited

Click to zoom

Application Details

Equipment Class: B2I - Part 20 Industrial Booster (CMRS)
Date of Grant: Jan 21, 2014
Application Purpose: Original Equipment
Date of Application: Jan 20, 2014
Equipment Note: ComFlex 600 Series DAS
Frequency Range: 1850.00000000 - 1915.00000000
Company: Comba Telecom Network Systems Limited
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

USER MANUAL FOR COMFLEX 6100 1W D D I I S S T T R R I I B B U U T T E E D D A A N N T T E E N N N N A A S S Y Y S S T T E E M M USER MANUAL ComFlex 6100 1W QE: 1-0-0 Comba Telecom Ltd. ComFlex 600 Series USER MANUAL FOR COMFLEX 6100 1W The information contained herein is the responsibility of and is approved by the following, to whom all enquiries should be directed in the first instance: This is an unpublished work the copyright in which vests in Comba International ("Comba"). All rights reserved. The information contained herein is confidential and the property of Comba and is supplied without liability for errors or omissions. No part may be reproduced, disclosed or used except as authorised by contract or other written permission. The copyright and the foregoing restriction on reproduction and use extend to all media in which the information may be embodied. USER MANUAL FOR COMFLEX 6100 1W ENU STATUS : 1-0-0 Copyright - refer to title page Page 3 0.1 CONTENTS Section Page 0.1 CONTENTS ....................................................................................................................................................... 3 0.2 INDEX TO FIGURES AND TABLES ...................................................................................................................... 4 0.3 HISTORY ........................................................................................................................................................... 6 0.4 GLOSSARY OF TERMS ....................................................................................................................................... 7 0.5 SAFETY NOTICES AND ADMONISHMENTS ....................................................................................................... 8 1 GENERAL INFORMATION .............................................................................................................................. 9 2 EQUIPMENT DESCRIPTION .......................................................................................................................... 11 2.1 SYSTEM DIAGRAM ......................................................................................................................................... 11 2.2 TYPICAL APPLICATION ................................................................................................................................... 11 2.3 EQUIPMENT CONSTITUTION ......................................................................................................................... 12 2.4 KIT OF PART ................................................................................................................................................... 13 3 INSTALLATION ............................................................................................................................................ 15 3.1 WARNINGS AND ALERTS ................................................................................................................................ 15 3.2 SITE PLANNING CONSIDERATIONS ................................................................................................................ 16 3.3 INSTALLATION PROCEDURES ......................................................................................................................... 18 3.4 EQUIPMENT CONNECTORS ........................................................................................................................... 26 3.5 EQUIPMENT CONNECTION ............................................................................................................................. 29 4 COMMISSIONING ....................................................................................................................................... 34 4.1 PRE-COMMISSIONING TASKS ........................................................................................................................ 34 4.2 LED INDICATORS ............................................................................................................................................ 34 4.3 DIGITAL DISPLAY INDICATORS ....................................................................................................................... 35 4.3.1 DIGITAL DISPLAY ON RFU .......................................................................................................................... 35 4.3.2 DIGITAL DISPLAY ON FOU.......................................................................................................................... 35 5 WEB GUI ..................................................................................................................................................... 37 5.1 WEB GUI CONNECTION ............................................................................................................................... 37 5.2 WEB GUI INTRODUCTION ........................................................................................................................... 38 5.2.1 [DEVICES] ............................................................................................................................................... 38 5.2.2 [COMMISSIONING] ................................................................................................................................ 42 5.2.3 [FIRMWARE] .......................................................................................................................................... 43 5.2.4 [MANAGEMENT] .................................................................................................................................... 44 5.3 COMMISSIONING PROCEDURE ................................................................................................................... 50 6 ALARMS AND TROUBLESHOOTING ............................................................................................................. 58 6.1 ALARMS .....................…

Text truncated - open the document above for the full version.

Cover Letter(s)

PX8100 FCC ID:PX8MU-6100

Cover Letter(s)

FCC ID: PX8ComFlex-6100 FCC ID:PX8MU-6100 180

Internal Photos

1 MU-6100 (1) MU01‐RACK‐E01 (2) MAU01‐FOU‐SABFOP6ED4 (3) MAU-PSU-A92W300 (4) MAU01-RFU-2000B45D (5) MAU01-RFU-1900B65D (6) MAU01-RFU-0850B25D (7) MAU01-RFU-0700B181D (8) MAU01-RFU-0700B11D (9) MU Combiner (10) MU Connection Board (11) MU Distribution Board (12) MU MCU

RF Exposure Info

FCC§1.1307(b)(1) &§2.1091-RF EXPOSURE 1. Applicable Standard According to FCC§part 1.1310 and §Part 2.1091 (Mobile Devices)RF exposure is calculated. Frequency Range(MHz) Electric Field Stength(V/m) Magnetic Field Stength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f²) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f=frequency in MHz *=Plane-wave equivalent power density 2.Prediction of MPE limit at given distance, equations from OET Bulletin 65, Edition 97‐01: S = (1.64 * P * G) / (4 * π * R²) (where PG = ERP) S = (P * G) / (4 * π * R²) (where PG = EIRP) Where: S = power density P= power input to antenna G= numeric gain of the antenna R= distance to the center of radiation of the antenna a 700MHz Lower ABC Band (Uplink 698~716MHz): Maximum peak output power at antenna input terminal (dBm): -23.15 Maximum peak output power at antenna input terminal (mW): 0.0048 Prediction frequency (MHz): 698.7 Maximum antenna gain (dBi): 12.5 Maximum antenna gain (dBd): 10.35 Maximum antenna gain (numeric): 10.84 Maximum RF output power (ERP, mW): 0.052 MPE limit for uncontrolled exposure at predication frequency (mW/ cm²): 0.466 Prediction distance (cm) R= 14.3*4* **64.1 S GP : 0.12 b 700MHz UpperC Band (Uplink 776~787MHz): Maximum peak output power at antenna input terminal (dBm): -23.49 Maximum peak output power at antenna input terminal (mW): 0.0045 Prediction frequency (MHz): 781.5 Maximum antenna gain (dBi): 12.5 Maximum antenna gain (dBd): 10.35 Maximum antenna gain (numeric): 10.84 Maximum RF output power (ERP, mW): 0.049 MPE limit for uncontrolled exposure at predication frequency (mW/ cm²): 0.521 Prediction distance (cm) R= 14.3*4* **64.1 S GP : 0.11 c 850MHz Band (824~849MHz): Maximum peak output power at antenna input terminal (dBm): -23.31 Maximum peak output power at antenna input terminal (mW): 0.0047 Prediction frequency (MHz): 836.5 Maximum antenna gain (dBi): 12.5 Maximum antenna gain (dBd): 10.35 Maximum antenna gain (numeric): 10.84 Maximum RF output power (ERP, mW): 0.051 MPE limit for uncontrolled exposure at predication frequency (mW/ cm²): 0.567 Prediction distance (cm) R= 14.3*4* **64.1 S GP : 0.11 d 1900MHz Broadband PCS (1850~1910MHz): Maximum peak output power at antenna input terminal (dBm): -22.90 Maximum peak output power at antenna input terminal (mW): 0.0051 Prediction frequency (MHz): 1910 Maximum antenna gain (dBi): 12.5 Maximum antenna gain (dBd): 10.35 Maximum antenna gain (numeric): 10.84 Maximum RF output power (ERP, mW): 0.055 MPE limit for uncontrolled exposure at predication frequency (mW/ cm²): 1 Prediction distance (cm) R= 14.3*4* **64.1 S GP : 0.084 e AWS-1 Band (1710~1755MHz) Maximum peak output power at antenna input terminal (dBm): -23.58 Maximum peak output power at antenna input terminal (mW): 0.0044 Prediction frequency (MHz): 1732.5 Maximum antenna gain (dBi): 12.5 Maximum antenna gain (dBd): 10.35 Maximum antenna gain (numeric): 10.84 Maximum RF output power (ERP, mW): 0.048 MPE limit for uncontrolled exposure at predication frequency (mW/ cm²): 1 Prediction distance (cm) R= 14.3*4* **64.1 S GP : 0.08 3. Test Results The above all ,when the Maximum antenna gain is 12.5dBi and the shortest distance from the human specific is 0.12cm , ,the device is compliant with the requirement MPE limit for uncontrolled exposure.

Test Report

Page 1 of 351 TEST REPORT Report No.: EM201300924 Application No.: ZJ00035225 Client: Comba Telecom Ltd. Address: 611 East Wing, No. 8 Science Park West Avenue, Hong Kong Science Park Tai Po, Hong Kong Sample Description: ComFlex 600 Series DAS Model number: MU-6100 Test Location: EMC Laboratory of Guangzhou GRG Metrology and Test Co., Ltd. Test Specification: FCC PART 27, FCC PART 22, FCC PART 24, FCC PART 2 Test Date: 2013-10-15 to 2013-12-29 Issue Date: 2013-12-29 Test Result: Pass. Prepared By: Reviewed By: Approved By: Jacky Zhang / Test Engineer Jane Cao / Technical Support Gavin Wu / Manager Date:2013-12-29 Date:2013-12-29 Date:2013-12-29 Other Aspects: None Abbreviations: ok / P = passed; fail / F = failed; n.a. / N = not applicable The test result in this test report refers exclusively to the presented test sample. This report shall not be reproduced except in full, without the written approval of GRGT. GRG Metrology and Test Co., Ltd. Address: 163, Pingyun Road, West of Huangpu Avenue, Guangzhou, Guangdong, P.R. China Tel:+86-20-38699960 Fax:+86-20-38695185 Email: [email protected] http://www.grgtest.com Ver.:2011.1.1 Report No.:EM201300924 Application No.: ZJ00035225 Page 2 of 351 FCC ID: PX8MU-6100 DIRECTIONS OF TEST 1. This station carries out test task according to the national regulation of verifications which can be traced to National Primary Standards and BIPM. 2. The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. 3. If there is any objection concerning the test, the client should inform the laboratory within 15 days from the date of receiving the test report. Report No.:EM201300924 Application No.: ZJ00035225 Page 3 of 351 FCC ID: PX8MU-6100 TABLE OF CONTENTS 1．TEST SUMMARY .................................................................................................................................................... 4 2．GENERAL INFORMATION .................................................................................................................................. 7 2.1 CLIENT INFORMATION ....................................................................................................................................... 7 2.2 MANUFACTURER AND FACTORY ....................................................................................................................... 7 2.3 BASIC DESCRIPTION OF EUT ............................................................................................................................. 7 2.4 SIGNAL CONTROL PROCESS ............................................................................................................................... 8 2.5 STANDARDS APPLICABLE FOR TESTING ............................................................................................................. 8 3. LABORATORY AND ACCREDITATIONS ........................................................................................................... 9 3.1 TEST LOCATION ....................................................................................................................................................... 9 3.2 ACCREDITATION ...................................................................................................................................................... 9 3.3 OTHER INFORMATION REQUESTED BY THE CUSTOMER ............................................................................................ 9 4 EQUIPMENTS USED DURING TEST ................................................................................................................... 10 5 TEST RESULTS .................................................................................................................................................. 11 5.1 EUT OPERATION .............................................................................................................................................. 11 5.2 TEST PROCEDURE & MEASUREMENT DATA ................................................................................................... 14 5.2.1 RF Output Power .................................................................................................................................... 14 5.3.2 Conducted Spurious Emissions .............................................................................................................. 28 5.3.3 Band Edge ............................................................................................................................................. 134 5.3.5 Frequency Stability ............................................................................................................................... 224 5.3.6 Occupied Bandwidth ............................................................................................................................ 232 5.3.7 Out of Band Rejection .......................................................................................................................... 340 5.3.8 Radiated Spurious Emissions ............................................................................................................... 345 Report No.:EM201300924 Application No.: ZJ00035225 Page 4 of 351 FCC ID: PX8MU-6100 1．Test summary Test Item Frequency Band Test Requirement Test Method Result Output Power 700MHz Lower ABC Band FCC part 27.50 FCC part 2. 1046& 935210 D02 Signal Boosters Certification v01r01 PASS 700MHz Upper C Band FCC part 27.50 PASS 850MHz Band FCC part 22.913 PASS 1900MHz Broadband PCS FCC part 24.232 PASS AWS-1 Band FCC part 27.50 PASS Conducted Spurious Emission 700MHz Lower ABC Band FCC part 27.53 FCC part 2. 1051& 935210 D02 Signal Boosters Certification v01r01 PASS 700MHz Upper C Band FCC part 27.53 PASS 850MHz Band FCC part 22.917 PASS 1900MHz Broadband PCS FCC part 24.238 PASS AWS-1 Band FCC part 27.53 PASS Band Edge 700MHz Lower ABC Band FCC par…

Text truncated - open the document above for the full version.

Test Report

Report No.:EM201300924 Application No.: ZJ00035225 Page 51 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 52 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 53 of 351 FCC ID: PX8MU-6100 5.3.2.1.2 700MHz Upper C 1) Test for LTE 1.4MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 54 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 55 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 56 of 351 FCC ID: PX8MU-6100 2) Test for LTE 5MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 57 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 58 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 59 of 351 FCC ID: PX8MU-6100 3) Test for LTE 10MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 60 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 61 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 62 of 351 FCC ID: PX8MU-6100 5.3.2.1.3 850MHz Band 1) LTE modulation 1.1) Test for LTE 1.4MHz (a) Lowest frequency: 9 kHz to 1 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 63 of 351 FCC ID: PX8MU-6100 (b) Lowest frequency: 1 GHz to 12.75 GHz (c) Middle frequency: 9 kHz to 1 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 64 of 351 FCC ID: PX8MU-6100 (d) Middle frequency: 1 GHz to 12.75 GHz (e) Highest frequency: 9 kHz to 1 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 65 of 351 FCC ID: PX8MU-6100 (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 66 of 351 FCC ID: PX8MU-6100 1.2) Test for LTE 5MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 67 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 68 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 69 of 351 FCC ID: PX8MU-6100 1.3) Test for LTE 10MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 70 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 12.75 GHz

Test Report

Report No.:EM201300924 Application No.: ZJ00035225 Page 71 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 72 of 351 FCC ID: PX8MU-6100 1.4) Test for LTE 20MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 73 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 74 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 75 of 351 FCC ID: PX8MU-6100 2) GSM modulation (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 76 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 77 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 78 of 351 FCC ID: PX8MU-6100 3) CDMA modulation (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 79 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 80 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 81 of 351 FCC ID: PX8MU-6100 4) WCDMA modulation (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 82 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 83 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 84 of 351 FCC ID: PX8MU-6100 5) 1x EV-DO modulation (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 85 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 86 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 12.75 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 87 of 351 FCC ID: PX8MU-6100 5.3.2.1.4 1900MHz Broadband PCS 1) 1900MHz LTE modulation 1.1) Test for LTE 1.4MHz (a) Lowest frequency: 9 kHz to 1 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 88 of 351 FCC ID: PX8MU-6100 (b) Lowest frequency: 1 GHz to 26.5 GHz (c) Middle frequency: 9 kHz to 1 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 89 of 351 FCC ID: PX8MU-6100 (d) Middle frequency: 1 GHz to 26.5 GHz (e) Highest frequency: 9 kHz to 1 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 90 of 351 FCC ID: PX8MU-6100 (f) Highest frequency: 1 GHz to 26.5 GHz

Test Report

Report No.:EM201300924 Application No.: ZJ00035225 Page 91 of 351 FCC ID: PX8MU-6100 1.2) Test for LTE 5MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 92 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 93 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 94 of 351 FCC ID: PX8MU-6100 1.3) Test for LTE 10MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 95 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 96 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 97 of 351 FCC ID: PX8MU-6100 1.4) Test for LTE 20MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 98 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 99 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 100 of 351 FCC ID: PX8MU-6100 2) GSM modulation (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 101 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 102 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 103 of 351 FCC ID: PX8MU-6100 3) CDMA modulation (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 104 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 105 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 106 of 351 FCC ID: PX8MU-6100 4) WCDMA modulation (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 107 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 108 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 109 of 351 FCC ID: PX8MU-6100 5) 1x EV-DO modulation (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 110 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz

Test Report

Report No.:EM201300924 Application No.: ZJ00035225 Page 111 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 112 of 351 FCC ID: PX8MU-6100 5.3.2.1.5 AWS-1 Band 1) LTE modulation 1.1) Test for LTE 1.4MHz (a) Lowest frequency: 9 kHz to 1 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 113 of 351 FCC ID: PX8MU-6100 (b) Lowest frequency: 1 GHz to 26.5 GHz (c) Middle frequency: 9 kHz to 1 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 114 of 351 FCC ID: PX8MU-6100 (d) Middle frequency: 1 GHz to 26.5 GHz (e) Highest frequency: 9 kHz to 1 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 115 of 351 FCC ID: PX8MU-6100 (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 116 of 351 FCC ID: PX8MU-6100 1.2) Test for LTE 5MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 117 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 118 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 119 of 351 FCC ID: PX8MU-6100 1.3) Test for LTE 10MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 120 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 121 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 122 of 351 FCC ID: PX8MU-6100 1.4) Test for LTE 20MHz (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 123 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 124 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 125 of 351 FCC ID: PX8MU-6100 2) CDMA modulation (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 126 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 127 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 128 of 351 FCC ID: PX8MU-6100 3) WCDMA modulation (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 129 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 130 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz

Test Report

Report No.:EM201300924 Application No.: ZJ00035225 Page 131 of 351 FCC ID: PX8MU-6100 4) 1x EV-DO modulation (a) Lowest frequency: 9 kHz to 1 GHz (b) Lowest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 132 of 351 FCC ID: PX8MU-6100 (c) Middle frequency: 9 kHz to 1 GHz (d) Middle frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 133 of 351 FCC ID: PX8MU-6100 (e) Highest frequency: 9 kHz to 1 GHz (f) Highest frequency: 1 GHz to 26.5 GHz Report No.:EM201300924 Application No.: ZJ00035225 Page 134 of 351 FCC ID: PX8MU-6100 5.3.3 Band Edge Test Date: 27 Dec, 2013 to 27 Dec, 2…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Ronin Gong(Director)

[email protected]+86 2028390000Fax: +86 20 28396600

Technical Contact

GUANGZHOU GRG METROLOGY&TEST CO.,LTDJane Cao

[email protected]86-20-39699960

163 Ping Yun Rd,West of HuangPu Ave · Guangzhou · China

Non-Technical Contact

GUANGZHOU GRG METROLOGY&TEST CO.,LTD.Cherry Li

[email protected]86-20-66664985

Test Firm

Guangzhou GRG Metrology And Test Technology LTD.Gavin Wu

[email protected]862038699960Fax: 86 20 38695

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
12	24E	1.85 GHz - 1.92 GHz	4.00 mW	F8W	0.01 ppm

Confidentiality

Long Term

Grant Notes

Power output listed is per carrier at the antenna terminal (uplink) of an host unit device. Emission Designator F9W covers both CDMA and WCDMA. This transmitter operates as a host unit as part of a system along with remote unit components as described in this filing, and excluding any other devices connected to the (uplink) output terminal of the remote unit. This application covers only the system configuration with host unit connected to a base station in the uplink path via antenna or amplifier. Antennas installed for each host unit must provide a minimum 20cm separation distance from all persons as described in this filing. The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC bureau(s), including antenna co-location requirements of § 1.1307(b)(3). This grant is subject to the conditions of the limited waiver issued by FCC Wireless Telecommunications Bureau, as shown in this filing. Part of booster system used with FCC ID: PX8LRU-6100. For operation within 1710-1755 MHz, system installation must be limited to a max 1 W EIRP as required by 27.50(d)(4). Fixed stations are also limited to an ABSOLUTE max 10 m antenna height above earth.
