PY7-83376CGSM/WCDMA/LTE/5G Phone with BT, DTS/UNII a/b/g/n/ac/ax, GPS, WPT & NFC

Parts & Functions Handset (Front) Part Description Front Camera Use to shoot still images, videos of yourself, etc. Earpiece/Speaker Hear the other party's voice here. Proximity/Light Sensor Detects surrounding brightness to automatically adjust Display or backlight and prevent Touchscreen misoperation during a call. Display Touchscreen-type display, operate with your fingers on Display. Speaker Listen to music as well as video, etc. audio. Handset (Back/Side) Part Description Second Mic Reduces noise for calling. Headset Jack Connect commercially available headphones. This port supports tetrapolar headset that conforms to the CTIA standard. Third Mic It picks up ambient sounds evenly and reproduces clear sound. Flash/Photo Light Use as camera flash when taking photos, etc. 5G Antenna Area Internal Antenna for data communication. Try not to cover it with your hands as much as possible. It may cause communication deterioration. Also, it may get hot when used for a long time. USB Type-C™ Port Connect USB Type-C cable (commercially available), etc. Main Camera Capture still images and videos. NFC/Osaifu- Keitai ® Detection Area Hold up to a reader/writer to use NFC/Osaifu-Keitai ® . Wireless Charging Position Position wireless charger. Mic Speak here. SIM Card/SD Insert SIM Card/SD Card Slot Card. Using USB Type-C Port Connect DisplayPort-compatible USB Type-C cable (commercially available) and show handset screen on a TV or computer monitor. Also, use a USB-LAN adapter (commercially available) and connect to the Internet with a wired LAN cable. Your USB Type-C cable, USB-LAN adapter, or access point device might not work in some instances. Handset Keys Part Description Volume/Zoom Up/Down Key Adjust Volume. Adjust Zoom while using Photo Pro. Power Key/Fingerprint Sensor Power on/off. For details, see " Power On/Off." Turn Display on/off. Or, use Fingerprint authentication. Shutter Key Use as Camera shutter. Long Press to launch Photo Pro. FCC ID To view the regulatory compliance mark  Find and tap SettingsAbout phoneCertificates Regulatory compliance mark such as FCC ID is displayed on the screen. eSIM eSIM is an integrated SIM already built into handset. An eSIM-capable handset allows you to use a phoneline simply with a contract subscription and configuring handset, without the needed replacement of SIM cards. Handling eSIM For eSIM handling, see the following website. https://www.softbank.jp/mobile/support/product/sim/esim/ (Japanese) Downloading eSIM In Home Screen, (Settings)Network & internet for "SIMs"  If no SIM Card is installed, Tap SIMs. Download a SIM instead? Next Scan the QR code  Handset may not display the above step, and instead go to the next step, depending on your conditions of usage. Download Enter verification code issued at time of subscription with SoftBankContinue Close eSIM download is completed.  Tap Settings to enable eSIM. Continue by following onscreen instructions. Enabling/Disabling eSIM In Home Screen, (Settings)Network & internet SIMs  If no SIM Card is installed, go to step . Under "DOWNLOADED SIM", SoftBank Use SIM YES eSIM changes between enabled and disabled. Erasing eSIM In Home Screen, (Settings)Network & internet SIMs  If no SIM Card is installed, go to step . Under "DOWNLOADED SIM", SoftBank Erase SIM ERASE eSIM is erased. After Erasing eSIM To use an eSIM again after having erased it, the QR code for downloading an eSIM must be reissued. Erasing an eSIM does not cancel your subscription contract. SIM Card SIM Card is an IC card containing phone number and other customer information. Handling SIM Card For SIM Card handling, see following items. ① IC chip For SIM Card handling, see SoftBank Website. https://www.softbank.jp/mobile/support/protect/usim/ (Japanese)  Always keep the IC chip clean.  Wipe clean with a dry, soft cloth.  Avoid applying labels. May damage SIM Card. SIM Card Cautions Observe the following when using SIM Card.  Customer is responsible for any damage caused by inserting SIM Card in an other-brand IC card reader, etc. SoftBank Corp. is not responsible in such case.  SIM Card is the property of SoftBank Corp.  SIM is replaceable (at cost) in case of loss/damage.  Return SIM Card to SoftBank Corp. when cancelling subscription.  Returned SIM Cards are recycled for environmental purposes.  Note that SIM Card specifications and performance may change without notice.  It is recommended that you keep a separate copy of information that is stored on SIM Card. SoftBank Corp. is not responsible for damages from stored information that is lost.  Always follow emergency procedures to suspend service if your SIM Card or handset (SIM Card inserted) is lost/stolen. For details, contact Customer Service.  Always power off handset before inserting/removing SIM Card.  Some services, functions, etc. may have restrictions when an other-carrier SIM card is used. SoftBank Corp. does not guarantee operation whatsoever. Inserting SIM Card Always unmount SD Card beforehand. For details, see "Unmounting SD Card." Pull Tray out from handset  Pull SIM Card/SD Card Slot Cover out straight using fingernail in groove. Set SIM Card into Tray with IC chip (metal) facing up  Check SIM Card orientation by notch.  Make sure SIM Card is in Tray securely. Holding handset held level, press Tray in straight SIM Card is inserted.  Check Tray orientation.  Press firmly where circled ○, and make sure there is no gap between handset and SIM Card/SD Card Slot Cover. Removing SIM Card Always unmount SD Card beforehand. For details, see "Unmounting SD Card." Pull Tray out from handset  Pull SIM Card/SD Card Slot Cover out straight using fingernail in groove. Remove SIM Card from Tray Holding handset held level, press Tray in straight SIM Card is removed.  Check Tray orientation.  Press firmly where circled ○, and make sure there is no gap between handset and SIM Card/SD Card Slot Cover. Power On/Off Powering On Long Press Power Key until handset vi…

Text truncated - open the document above for the full version.

Sony Corporation CFR 47 §2.911 (d)(5) Attestation Date: March 17, 2023 FCC ID: PY7-83376C To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA 1. Sony Corporation (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Sony Corporation (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, Mika Kaneko Chief Regulatory Compliance Manager Sony Corporation

Sony Corporation CFR 47 §2.911 (d)(7) Agent Designation Attestation Date: February 10, 2023 Grantee Code: PY7 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Sony Corporation (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. U. S. Agent Information: Mr. Mark Arthurs FRN 0033408097 Sony Electronics Inc. 16535 Via Esprillo San Diego California, 92127 [email protected] Sincerely yours, Mika Kaneko Chief Regulatory Compliance Manager Sony Corporation

Sony Corporation 1-7-1 Konan Minato-ku, Tokyo, 108-0075, Japan Remarks It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Date: March 17, 2023 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA Authorization Letter for UL Verification Services Inc. FCC ID: PY7-83376C To Whom It May Concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; Sony Corporation 1-7-1 Konan Minato-ku, Tokyo, 108-0075, Japan Remarks It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. Yours sincerely, ________________________________ Mika Kaneko Chief Regulatory Compliance Manager Mobile Communications Business Group Sony Corporation

Sony Corporation 1-7-1 Konan Minato-ku, Tokyo, 108-0075, Japan Remarks It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Date: March 17, 2023 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Confidentiality Request Letter FCC ID: PY7-83376C To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. - Schematic Diagram - Block Diagram - Theory of Operation - Parts List - Tune up Information Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments for 180days from date of the Grant of Equipment Authorization. - External Photos - Internal Photos - Test Setup Photos - User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Yours sincerely, ________________________________ Mika Kaneko Chief Regulatory Compliance Manager Mobile Communications Business Group Sony Corporation

Sony Corporation 1-7-1 Konan Minato-ku, Tokyo, 108-0075, Japan Remarks It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Date: March 22, 2023 PY7-83376C Data Reuse Justification and Summary To Whom It May Concern: We are applying data reuse for FCC ID: PY7-83376C (variant) based on the parent model FCC ID: PY7- 12907W (Parent). Regarding WLAN/Bluetooth/WPT/NFC, both models share the same PCB layout, antennas, and components. The unlicensed band data for the parent model remains representative for the variant model (equipment classes DSS, DTS, NII, DCD and DXX) and test reports for the parent model plus test reports with the spot check data for the variant model have been submitted. The power to be listed on the F-731 and FCC grants for these bands are the values detailed in the parent reports as the spot check data shows all values within expected tolerances of the parent model. For SAR, WLAN, Bluetooth and NFC SAR data and WPT RF Exposure data are referenced from the parent model FCC ID: PY7-12907W and are leveraged to cover the variant FCC ID: PY7-83376C. SAR the data reuse test plan was approved via manufacturer KDB inquiry. The variant model SAR report has full tested data for the licensed bands. FCC ID Bluetooth DSS Bluetooth DTS 802.11 DTS 802.11 NII WPT DCD NFC PY7-12907W Parent R14634918-E2 R14634918-E3 R14634918-E4a R14634918-E4b R14634918-E5a R14634918-E5b R14634918-E6a R14634918-E6b R14634918-E7a R14634918-E7b R14634918-E8 R14634918-E10 PY7-83376C Variant R14639481-E4 FCC ID WPT RF Exposure SAR (WLAN/BT/NFC) PY7-12907W Parent R14634918-E9 R14634918-S1 PY7-83376C Variant R14639481-E3 R14639481-S1 Indicates full set of test data. Values in this report to be listed on the grant for these bands. Partial test data used to confirm that the parent model data is representative for the variant model. Data for these bands is for reference only Yours sincerely, ________________________________ Mika Kaneko Chief Regulatory Compliance Manager Mobile Communications Business Group Sony Corporation

Sony Corporation 1(3) Document number Revision PA1 Date 3/16/2023 Remarks It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. FCC ID: PY7-83376C External Photo Front Rear 2(3) Document number Revision PA1 Side view: Top/Bottom view: 3(3) Document number Revision PA1 SIM SLOT:

Sony Corporation 1-7-1 Konan Minato-ku, Tokyo, 108-0075, Japan E- Label and Label Location PY7-83376C 1 E-Label Location Users can access the FCC ID information within 3 step as the followings. Setting from Main Menu Settings -> About Phone -> Certificates 2 Access to the required information on the e-label (1) The user manual directs the user where to find the FCC ID E-Label. To view the regulatory compliance mark  Find and tap [Settings]->[About Phone]->[Certificates] Regulatory compliance mark such as FCC ID is displayed on the screen. Special codes or permissions are not required the above steps beyond the normal security protection to unlock the screen. (2) Products must not require special accessories or supplemental plug-ins. (3) The regulatory information is clearly legible without the aid of magnification. (4) The regulatory information is secure. The user can not access and modify the regulatory information. (5) The physical temporary label or the label on the packaging for purchasing and importation is attached in case of the device is sold in the United States. 3 FCC Statement FCC15.19(a) statement can be seen in the manual. FCC ID: PY7-83376C

Sony Corporation 1(5) Document number Revision PA1 Date 2022-7-28 It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. FCC ID: PY7-83376C Internal Photo Without Rear panel Rear panel Without PBA and Battery 2(5) Document number Revision PA1 Combined ①Front PBA and ②Rear PBA with Shield cases (Front-side) Combined ①Front PBA and ②Rear PBA without Shield cases (Front-side) 3(5) Document number Revision PA1 Combined ①Front PBA and ②Rear PBA with Shield case (Rear-side) Combined ①Front PBA and ②Rear PBA without Shield case (Rear-side) 4(5) Document number Revision PA1 Only ①Front PBA (Rear-side) Only ②Rear PBA with Shield case (Front-side) Only ②Rear PBA without Shield case (Front-side) 5(5) Document number Revision PA1 Internal Sub-PWB (Front-side) Internal Sub-PBA (Rear-side) Battery:

SAR EVALUATION REPORT IEEE Std 1528-2013 For GSM/WCDMA/LTE/5G Phone with BT, DTS/UNII a/b/g/n/ac/ax, GPS, WPT, & NFC FCC ID: PY7-83376C Report Number: R14639481-S1 v3 Issue Date: 3/27/2023 Prepared for Sony Corporation 1-7-1 Konan Minato-ku Tokyo, 108-0075, Japan Prepared by UL LLC 12 LABORATORY DR RTP, NC 27709, U.S.A. TEL: (919) 549-1400 Report No.: R14639481-S1 v3 Issue Date: 3/27/2023 Page 2 of 48 UL LLC Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL LLC Revision History Rev. Date Revisions Revised By V1 3/23/2023 Initial Issue -- V2 3/24/2023 Corrected measured power for section 10.8 Bluetooth and 5.5 GHz WLAN extremity. Updated NFC measurements to current variant PY7-83376C in Section 1, Section 10.9, and Section 12.6. Added highest NFC test plot in Appendix C. Updated Simultaneous Tx Extremity value in Section 1. Added 13MHz liquid check, system performance check, and system performance check plot in Appendix B; u pdated CLA13 dipole in Section 4.3 and in Appendix F. Lindsay Ryan V3 3/27/2023 Removed IMEIs from §6.1. Updated Tune-up for GSM DTM in §9.1. Richard Jankovics Report No.: R14639481-S1 v3 Issue Date: 3/27/2023 Page 3 of 48 UL LLC Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL LLC Table of Contents 1. Attestation of Test Results ............................................................................................................ 5 2. Test Specification, Methods and Procedures .............................................................................. 7 3. Facilities and Accreditation ........................................................................................................... 8 4. SAR Measurement System & Test Equipment ............................................................................ 9 4.1. SAR Measurement System .......................................................................................................... 9 4.2. SAR Scan Procedures ................................................................................................................ 10 4.3. Test Equipment .......................................................................................................................... 12 5. Measurement Uncertainty ........................................................................................................... 14 6. Device Under Test (DUT) Information ........................................................................................ 15 6.1. DUT Description ......................................................................................................................... 15 6.2. Wireless Technologies ............................................................................................................... 16 6.3. General LTE SAR Test and Reporting Considerations .............................................................. 17 6.4. Power Back-off Operation........................................................................................................... 18 7. RF Exposure Conditions (Test Configurations) ........................................................................ 19 8. Dielectric Property Measurements & System Check ................................................................ 20 8.1. Dielectric Property Measurements .............................................................................................. 20 8.2. System Check............................................................................................................................. 22 9. Conducted Output Power Measurements .................................................................................. 24 9.1. GSM ........................................................................................................................................... 24 9.2. W-CDMA .................................................................................................................................... 27 9.3. LTE ............................................................................................................................................. 31 9.4. WLAN 2.4GHz & WLAN 5GHz & Bluetooth ................................................................................ 39 10. Measured and Reported (Scaled) SAR Results ......................................................................... 40 10.1. GSM850 .................................................................................................................................. 42 10.2. GSM1900 ................................................................................................................................ 42 10.3. W-CDMA Band 2 .................................................................................................................... 42 10.4. W-CDMA Band 4 .................................................................................................................... 42 10.5. LTE Band 2 (20MHz Bandwidth)............................................................................................. 43 10.6. LTE Band 4 (20MHz Bandwidth)............................................................................................. 43 10.7. LTE Band 12 (10MHz Bandwidth)........................................................................................... 43 10.8. WLAN & Bluetooth & NFC Spot Check Verification ................................................................ 44 10.9. NFC ......................................................................................................................................... 44 11. SAR Measurement Variability ..................................................................................................... 45 Report No.: R14639481-S1 v3 Issue Date: 3/27/2023 Page 4 of 48 UL LLC Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL LLC 12. Simultaneous Transmission…

Text truncated - open the document above for the full version.

Plot No. 1 Test Laboratory: UL LLC SAR 1A Date/Time: 2023-02-20, 12:45 2023-02-20 System Performance Check Report D1750V2 - SN1136 Summary Dipole D1750V2 - SN1136 Frequency [MHz] 1750.0 Phantom Section | TSL Flat | HSL Dev. Peak [%] 3.8 Power [dBm] 17.0 Iso. Error [%] 0.8 Exposure Conditions Dipole Distance [mm] 10 TSL Permittivity 39.4 Conversion Factor 8.89 TSL Conductivity [S/m] 1.38 Hardware Setup Probe | Calibration Date EX3DV4 - SN7711 | 2022-03-11 Phantom Twin-SAM V8.0 (30deg probe tilt) - SN2084 DAE | Calibration Date DAE4 Sn1716 | 2022-03-08 TSL | Meas. Date HBBL600-10000V6 | 2023-Feb-20 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 40.0 x 90.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 10.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Graded Grid n/a Yes M2/M1 [%] 81.4 Dist 3dB Peak [mm] 10.9 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 1.78 1.78 psSAR10g [W/Kg] 0.956 0.948 Power Drift [dB] 0.01 0.00 Plot No. 2 Test Laboratory: UL LLC SAR 1A Date/Time: 2023-02-24, 10:22 2023-02-24 System Performance Check Report D5GHzV2 - SN1213 Summary Dipole D5GHzV2 - SN1213 Frequency [MHz] 5600.0 Phantom Section | TSL Flat | HSL Dev. Peak [%] -5.6 Power [dBm] 17.0 Iso. Error [%] 1.4 Exposure Conditions Dipole Distance [mm] 10 TSL Permittivity 35.9 Conversion Factor 5.16 TSL Conductivity [S/m] 5.10 Hardware Setup Probe | Calibration Date EX3DV4 - SN7711 | 2022-03-11 Phantom Twin-SAM V8.0 (30deg probe tilt) - SN2084 DAE | Calibration Date DAE4 Sn1716 | 2022-03-08 TSL | Meas. Date HBBL600-10000V6 | 2023-Feb-24 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 40.0 x 80.0 22.0 x 22.0 x 22.0 Grid Steps [mm] 10.0 x 10.0 4.0 x 4.0 x 1.4 Sensor Surface [mm] 3.0 1.4 Graded Grid n/a Yes M2/M1 [%] 61.8 Dist 3dB Peak [mm] 7.4 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 3.58 3.85 psSAR10g [W/Kg] 1.01 1.09 Power Drift [dB] -0.00 -0.01 Plot No. 3 Test Laboratory: UL LLC SAR 1A Date/Time: 2023-03-23, 23:32 2023-03-23 System Performance Check Report CLA-13 - SN1008 Summary Dipole CLA-13 - SN1008 Frequency [MHz] 13.0 Phantom Section | TSL Flat | HSL Dev. Peak [%] n/a Power [dBm] 16.5 Iso. Error [%] -6.0 Exposure Conditions Dipole Distance [mm] 0 TSL Permittivity 57.6 Conversion Factor 15.8 TSL Conductivity [S/m] 0.735 Hardware Setup Probe | Calibration Date EX3DV4 - SN7710 | 2023-02-03 Phantom ELI V8.0 (20deg probe tilt) - SN2081 DAE | Calibration Date DAE4 Sn1715 | 2023-01-23 TSL | Meas. Date HBBL4-250V3 | 2023-Mar-23 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 40.0 x 90.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 10.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Graded Grid n/a Yes M2/M1 [%] 75.5 Dist 3dB Peak [mm] 15.7 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 0.025 0.024 psSAR10g [W/Kg] 0.020 0.015 Power Drift [dB] 0.02 0.04 Plot No. 4 Test Laboratory: UL LLC SAR 2A Date/Time: 2023-02-20, 13:14 2023-02-20 System Performance Check Report D900V2 - SN1d180 Summary Dipole D900V2 - SN1d180 Frequency [MHz] 900.0 Phantom Section | TSL Flat | HSL Dev. Peak [%] 0.9 Power [dBm] 17.0 Iso. Error [%] 1.0 Exposure Conditions Dipole Distance [mm] 15 TSL Permittivity 43.0 Conversion Factor 10.14 TSL Conductivity [S/m] 0.957 Hardware Setup Probe | Calibration Date EX3DV4 - SN7710 | 2023-02-03 Phantom Twin-SAM V8.0 (30deg probe tilt) - SN2082 DAE | Calibration Date DAE4 Sn1715 | 2023-01-23 TSL | Meas. Date HBBL600-10000V6 | 2023-Feb-20 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 40.0 x 90.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 10.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Graded Grid n/a Yes M2/M1 [%] 85.5 Dist 3dB Peak [mm] 19.7 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 0.519 0.523 psSAR10g [W/Kg] 0.339 0.339 Power Drift [dB] 0.01 0.02 Plot No. 5 Test Laboratory: UL LLC SAR 2A Date/Time: 2023-02-20, 13:48 2023-02-20 System Performance Check Report D750V3 - SN1139 Summary Dipole D750V3 - SN1139 Frequency [MHz] 750.0 Phantom Section | TSL Flat | HSL Dev. Peak [%] 1.1 Power [dBm] 17.0 Iso. Error [%] 1.1 Exposure Conditions Dipole Distance [mm] 15 TSL Permittivity 43.4 Conversion Factor 10.65 TSL Conductivity [S/m] 0.905 Hardware Setup Probe | Calibration Date EX3DV4 - SN7710 | 2023-02-03 Phantom Twin-SAM V8.0 (30deg probe tilt) - SN2082 DAE | Calibration Date DAE4 Sn1715 | 2023-01-23 TSL | Meas. Date HBBL600-10000V6 | 2023-Feb-20 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 40.0 x 90.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 10.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Graded Grid n/a Yes M2/M1 [%] 86.6 Dist 3dB Peak [mm] 22.1 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 0.412 0.412 psSAR10g [W/Kg] 0.275 0.271 Power Drift [dB] 0.00 0.00 Plot No. 6 Test Laboratory: UL LLC SAR 2B Date/Time: 2023-02-20, 14:43 2023-02-20 System Performance Check Report D1900V2 - SN5d202 Summary Dipole D1900V2 - SN5d202 Frequency [MHz] 1900.0 Phantom Section | TSL Flat | HSL Dev. Peak [%] 1.2 Power [dBm] 17.0 Iso. Error [%] -1.7 Exposure Conditions Dipole Distance [mm] 10 TSL Permittivity 38.9 Conversion Factor 8.74 TSL Conductivity [S/m] 1.41 Hardware Setup Probe | Calibration Date EX3DV4 - SN7709 | 2022-12-12 Phantom Twin-SAM V8.0 (30deg probe tilt) - SN1742 DAE | Calibration Date DAE4 Sn1714 | 2022-11-23 TSL | Meas. Date HBBL1550-1950V3 | 2023-Feb-20 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 40.0 x 90.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 10.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Graded Grid n/a Yes M2/M1 [%] 81.4 Dist 3dB Peak [mm] 9.6 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 1.92 1.91 psSAR10g [W/Kg] 0.989 0.992 Power Drift [dB] -0.02 -0.01 Plot No. 7 Test Laboratory: UL LLC SAR 2B Date/Time: 2023-02-24, 17:34 2023-02-24 System Performance Check Report D2450V2 - SN963 Summary Dipole D2450V2 - SN963 Frequency [MHz] 2450.0 Phantom Section | TSL Flat | HSL Dev. Peak [%] -3.9 Power [dBm] 17.0 Iso. Error [%] 4.3 Exposure Conditions Dipole Distance [mm] 10 TSL Permittivity 41.1 Conversion Factor 8.6 TSL Conductivity [S/m] 1.8…

Text truncated - open the document above for the full version.

Plot No. 1 Test Laboratory: UL LLC SAR 2A Date/Time: 2023-02-20, 20:16 Measurement Report for GSM 850, CHEEK, Normal, CELL Main1 Exposure Conditions Band GSM 850 TSL Permittivity 43.2 Frequency [MHz] | Channel Number 836.6 | 190 TSL Conductivity [S/m] 0.937 Group | UID GSM | 10090-DAC Phantom Section | TSL RightHead | HSL Conversion Factor 10.14 Test Distance [mm…

Text truncated - open the document above for the full version.
