PY7-87261HGSM/WCDMA/LTE phone with BT, DTS/UNII a/b/g/n/ac/ax, GPS, WPC and NFC

Sony Corporation

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Feb 27, 2020
Application Purpose: Original Equipment
Date of Application: Feb 25, 2020
Equipment Note: GSM/WCDMA/LTE phone with BT, DTS/UNII a/b/g/n/ac/ax, GPS, WPC and NFC
Frequency Range: 5745.00000000 - 5825.00000000
Company: Sony Corporation
Country: Japan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

INSTRUCTION MANUAL Introduction Thank you for your purchase of "SO-51A". For proper use of the SO-51A, read this manual carefully before and while you use the SO-51A. About manuals " (Quick Start Guide)" (Supplied accessories) Part names and functions are explained. "Instruction Manual" application (Application of the terminal) (in Japanese only) Operations and settings of each function are explained. You can search by free word, open a setting screen or launch an application from a displayed page, etc. Use the terminal more conveniently with this application. [How to use] From the Home screen, "apps folder" u "Instruction Manual" When using for the first time, download and install the application according to the onscreen instructions. You can also call up "Instruction Manual" application from "my daiz" (in Japanese only). If you uninstall "Instruction Manual" application, access Google Play from Play Store for installing it again. From the Home screen, tap [Play Store], search " (Instruction Manual)" application to select, then operate it following the onscreen instructions. "Instruction Manual" (PDF file) Operations and settings of each function are explained. It can be downloaded from NTT DOCOMO website. ❖ Note Important information for SO-51A is posted in the following website. Be sure to check before using. https://www.sonymobile.co.jp/support/ (in Japanese only) Operation descriptions In this manual, key icons (P.54) are described as , . And operations for selecting icons or items in the key operations on the screens are described as follows. "Wi-Fi" no tsukaikata "Wi-Fi" wo setsumeisho apuri de shirabemasu. DescriptionOperation Press and hold the camera key for at least 1 second. Press and hold the camera key on the side of the terminal for at least 1 second. From the Home screen, u Tap . From the Home screen, tap , and then tap on the next screen. From the Home screen, [apps folder] u [Settings] u [Display]. From the Home screen, tap [apps folder], and then tap "Settings" on the next screen and "Display" on the following screen. Touch and hold an icon. Keep touching an icon longer (1- 2 seconds). 1 ❖ Information Please note that "SO-51A" is called as "the terminal" in this manual. In this manual, the description is written based on the default state. In this manual, the easier procedure is described for the functions and settings which have multiple operating procedures. The terminal may have a software update of the operating system (OS) for the purpose of quality improvement or addition of functions. In that case, operation procedure may change. For the information about addition of functions or change of operation procedure, refer to NTT DOCOMO website And some applications that used in the previous OS version may not be available or some unintended bugs may occur. In this manual, explanations for "docomo LIVE UX" set as the home app are provided (P.72). If you set the other home app, the operations may differ from the descriptions. In this manual, screens with "Black" wallpaper are provided for explanation of "Xperia Home" home app. The contents of this manual and written URL are subject to change without prior notice. Screens and illustrations used in this manual are just images for explanations and may be different from the actual ones of the product. Reproduction or reprint of all or part of this manual without prior permission is prohibited. SO-51A (Quick Start Guide) (in Japanese only) (Notes on usage) (In Japanese only) 3.5mm Earphone jack conversion/TV Antenna cable SO01 You can check or purchase optional accessories compatible with the terminal in the DOCOMO online shop. https://onlineshop.smt.docomo.ne.jp/ options/search.html (in Japanese only) Supplied accessories Contents 2 Contents Supplied accessories. . . . . . . . . . . . . . . . . 1 Precautions . . . . . . . . . . . . . . . . . . 4 About using the terminal....................................................4 Recommended features ......................................................7 Safety Precautions (Always follow these directions) .....................................................................................8 Handling precautions......................................................... 18 Waterproofness/Dustproofness................................... 26 Before using the terminal . . . . 32 Part names and functions................................................ 32 docomo nano UIM card.................................................... 34 microSD card ........................................................................... 36 FCC ID........................................................................................... 39 Charging ..................................................................................... 39 Turning power on/off......................................................... 43 Initial settings........................................................................... 44 Security codes for the terminal .................................... 46 Basic operations . . . . . . . . . . . . 49 Basic operations ..................................................................... 49 Character entry ....................................................................... 58 Notification LED ..................................................................... 64 Screen display and the icons ......................................... 64 Task manager........................................................................... 69 Split screen................................................................................ 69 One-handed mode .............................................................. 70 Searching information in the terminal and websites ...................................................................................... 71 Home screen . . . . . . . . . . . . . . . . 72 Switching the home app ................................................. 72 docomo LIVE UX............…

Text truncated - open the document above for the full version.

Users Manual

Important Information United States THIS PHONE MODEL HAS BEEN CERTIFIED IN COMPLIANCE WITH THE GOVERNMENT'S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. The SO-51A Series mobile phones have been designed to comply with applicable safety requirements for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed to not exceed the limits* of exposure to radio frequency (RF) energy set by governmental authorities. These limits establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by international scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a safety margin designed to assure the safety of all individuals, regardless of age and health. The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate (SAR). Tests fo r SAR are con ducted using standardized methods with the phone transmitting at its highest certified power level in all used frequency bands. While there may be differences between the SAR levels of various phone models, they are all designed to meet the relevant guidelines for exposure to radio waves. The highest SAR value as reported to the auth orities for this phone model when tested for use by the ear is 0.40 W/kg*, when worn on the body is 0.21 W/kg* and when WiFi hotspot mode is 0.61 W/ kg. For body-worn operation, this phone has been tested and meets the FCC RF exposure guidelines. Please use an accessory designated for this product or an accessory which contains no metal and which positions the handset a minimum of 15 mm from the body. For devices which include “WiFi hotspot” functionality, SAR measurements for the device operating in WiFi hotspot mode were taken usin g a separation distance of 10 mm. Use of third-party accessories may result in different SAR levels than those reported. Radio Wave Exposure and Specific Absorption Rate (SAR) Information ** Before a phone model is available for sale to the public in the US, it must be tested and certified by the Federal Communications Commission (FCC) that it does not exceed the limit established by the government-adopted requirement for safe exposure*. The tests are performed in positions and locations (i.e., by the ear and worn on the body) as required by the FCC for each model. The FCC has granted an Equipment Authorization for this phone model with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR levels of various phones, all mobile phones granted an FCC equipment authorization meet the government requirement for safe exposure. SAR information on this phone model is on file at the FCC and can be found under the Display Grant section of https:// www.fcc.gov/oet/ea/fccid after searching on FCC ID PY7-87261H. Additional information on SAR can be found on the Mobile Manufacturers Forum EMF website at http://www.emfexplained.info/. *In the United States, the SAR limit for mobile phones used by the public is 1.6 watts/ kilogram (W/kg) averaged over one gram of tissue. The standard incorporates a margin of safety to give additional protection for the public and to account for any variations in measurements. **This paragraph is only applicable to authorities and customers in the United States. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: Any change or modification not expressly approved by Sony may void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Statement for the USA (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.

Cover Letter(s)

Sony Mobile Communications, Inc. 4-12-3 Higashi-shinagawa, Shinagawa-ku, Tokyo, 140-0002, Japan Remarks This document is managed in Infodoc. It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Date: February 14, 2020 SPORTON INTERNATIONAL, INC No. 52, Hwa Ya 1st Road Hwa Ya Technology Park Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan R.O.C Authorization Letter for Sporton FCC ID: PY7-87261H To Whom It May Concern: I, the undersigned, hereby authorize Sporton to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Sporton on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing Sporton as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; Sony Mobile Communications, Inc. 4-12-3 Higashi-shinagawa, Shinagawa-ku, Tokyo, 140-0002, Japan Remarks This document is managed in Infodoc. It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. Yours sincerely, ________________________________ Tomonori Nagano Head of Type Approval, Product Compliance Quality Assurance & Customer Services Sony Mobile Communications Inc.

Cover Letter(s)

External Photos

Sony Mobile Communications Confidential REPORT 1(3) Document number Revision PA1 Date 2020-02-13 Remarks This document is managed in Infodoc. It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. FCC ID: PY7-87261H External Photo Front Rear Confidential REPORT 2(3) Document number Revision PA1 Side view: Top/Bottom view: Confidential REPORT 3(3) Document number Revision PA1 SIM SLOT:

ID Label/Location Info

Sony Mobile Communications Confidential General 1(1) Document number: Revision: 000335176 4 Prepared by: Date: 12 Contents responsible if other than preparer: Remarks: Approved by: It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. E- Label and Label Location PY7-87261H 1 E-Label Location Users can access the FCC ID information within 3 step as the followings. Setting from Main Menu Settings -> About Phone -> Certificates 2 Access to the required information on the e-label (1) The user manual directs the user where to find the FCC ID E-Label. To view the regulatory compliance mark  Find and tap [Settings]->[About Phone]->[Certificates] Regulatory compliance mark such as FCC ID is displayed on the screen. Special codes or permissions are not required the above steps beyond the normal security protection to unlock the screen. (2) Products must not require special accessories or supplemental plug-ins. (3) The regulatory information is clearly legible without the aid of magnification. (4) The regulatory information is secure. The user can not access and modify the regulatory information. (5) The physical temporary label or the label on the packaging for purchasing and importation is attached in case of the device is sold in the United States. 3 FCC Statement FCC15.19(a) statement can be seen in the manual. FCC ID: PY7-87261H

Internal Photos

Sony Mobile Communications Confidential REPORT 1(5) Document number Revision PA1 Date 2020-02-17 It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. FCC ID: PY7-87261H Internal Photo Without Rear panel Rear panel Without PBA and Battery Confidential REPORT 2(5) Document number Revision PA1 Internal Main-PWB with Shield cases (Front-side) Internal Main-PWB without Shield cases (Front-side) Internal Main-PWB of Rear (Front-side) Confidential REPORT 3(5) Document number Revision PA1 Internal Main-PWB with Shield cases (Rear-side) Internal Main-PWB without Shield cases (Rear-side) Internal Main-PWB of Rear (Rear-side) Confidential REPORT 4(5) Document number Revision PA1 Internal Sub-PWB (Front-side) Internal Sub-PWB (Rear-side) Confidential REPORT 5(5) Document number Revision PA1 Battery:

RF Exposure Info

TEL : 886-3-327-3456 Page 1 of 74 FAX : 886-3-328-4978 Issued Date : Feb. 17, 2020 Form version: 181113 FCC SAR TEST REPORT Report No. : FA9O1542-02 FCC SAR TEST REPORT FCC ID : PY7-87261H Brand Name : Sony Applicant : Sony Mobile Communications Inc. 4-12-3 Higashi-Shinagawa, Shinagawa-ku, Tokyo, 140-0002, Japan Manufacturer : Sony Mobile Communications Inc. 4-12-3 Higashi-Shinagawa, Shinagawa-ku, Tokyo, 140-0002, Japan Standard : FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2013 The product was received on Dec. 12, 2019 and testing was started from Jan. 08, 2020 and completed on Jan. 16, 2020. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any agency of government. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory, the test report shall not be reproduced except in full. SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory No. 52, Huaya 1st Rd., Guishan Dist., Taoyuan City, Taiwan (R.O.C.) Approved by: Cona Huang / Deputy Manager TEL : 886-3-327-3456 Page 2 of 74 FAX : 886-3-328-4978 Issued Date : Feb. 17, 2020 Form version: 181113 FCC SAR TEST REPORT Report No. : FA9O1542-02 Table of Contents 1. Statement of Compliance ............................................................................................................................................. 4 2. Guidance Applied .......................................................................................................................................................... 5 3. Equipment Under Test (EUT) Information ................................................................................................................... 5 3.1 General Information ............................................................................................................................................... 5 3.2 Device Serial Number ............................................................................................................................................ 6 3.3 General LTE SAR Test and Reporting Considerations ........................................................................................... 6 4. RF Exposure Limits....................................................................................................................................................... 8 4.1 Uncontrolled Environment ...................................................................................................................................... 8 4.2 Controlled Environment .......................................................................................................................................... 8 5. Specific Absorption Rate (SAR) ................................................................................................................................... 9 5.1 Introduction ............................................................................................................................................................ 9 5.2 SAR Definition ........................................................................................................................................................ 9 6. System Description and Setup ...................................................................................................................................10 6.1 E-Field Probe ........................................................................................................................................................ 11 6.2 Data Acquisition Electronics (DAE) ....................................................................................................................... 11 6.3 Phantom ................................................................................................................................................................12 6.4 Device Holder........................................................................................................................................................13 7. Measurement Procedures ...........................................................................................................................................14 7.1 Spatial Peak SAR Evaluation ................................................................................................................................14 7.2 Power Reference Measurement............................................................................................................................15 7.3 Area Scan .............................................................................................................................................................15 7.4 Zoom Scan ............................................................................................................................................................16 7.5 Volume Scan Procedures ......................................................................................................................................16 7.6 Power Drift Monitoring ...........................................................................................................................................16 8. Test Equipment List .....................................................................................................................................................17 9. System Verification ......................................................................................................................................................18 9.1 Tissue Simulating Liquids ..................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2020/1/10 System Check_Head_750MHz DUT: D750V3-1107 Communication System: CW; Frequency: 750 MHz;Duty Cycle: 1:1 Medium: HSL_750_200110 Medium parameters used: f = 750 MHz; σ = 0.894 S/m; ε r = 42.421; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN3925; ConvF(10.33, 10.33, 10.33) @ 750 MHz; Calibrated: 2019/9/20 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1311; Calibrated: 2019/8/27 - Phantom: SAM_Left; Type: QD000P40CD; Serial: TP:1477 - Measurement SW: DASY52, Version 52.10 (2);SEMCAD X Version 14.6.12 (7470) Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 2.90 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 59.57 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 3.27 W/kg SAR(1 g) = 2.21 W/kg; SAR(10 g) = 1.47 W/kg Maximum value of SAR (measured) = 2.92 W/kg 0 dB = 2.92 W/kg = 4.65 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2020/1/8 System Check_Head_835MHz DUT: D835V2-4d167 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL_850_200108 Medium parameters used: f = 835 MHz; σ = 0.879 S/m; ε r = 40.816; ρ = 1000 kg/m 3 Ambient Temperature：23.7 °C; Liquid Temperature：22.7 °C DASY5 Configuration: - Probe: EX3DV4 - SN3925; ConvF(10.12, 10.12, 10.12) @ 835 MHz; Calibrated: 2019/9/20 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1311; Calibrated: 2019/8/27 - Phantom: SAM_Left; Type: QD000P40CD; Serial: TP:1477 - Measurement SW: DASY52, Version 52.10 (2);SEMCAD X Version 14.6.12 (7470) Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 3.16 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 62.62 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 3.60 W/kg SAR(1 g) = 2.37 W/kg; SAR(10 g) = 1.55 W/kg Maximum value of SAR (measured) = 3.17 W/kg 0 dB = 3.17 W/kg = 5.01 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2020/1/15 System Check_Head_1750MHz DUT: D1750V2-1112 Communication System: CW; Frequency: 1750 MHz;Duty Cycle: 1:1 Medium: HSL_1750_200115 Medium parameters used: f = 1750 MHz; σ = 1.391 S/m; ε r = 41.824; ρ = 1000 kg/m 3 Ambient Temperature：23.9 °C; Liquid Temperature：22.9 °C DASY5 Configuration: - Probe: ES3DV3 - SN3184; ConvF(5.45, 5.45, 5.45) @ 1750 MHz; Calibrated: 2019/9/25 - Sensor-Surface: 3mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1399; Calibrated: 2019/11/14 - Phantom: SAM_Left; Type: QD000P40CD; Serial: TP:1684 - Measurement SW: DASY52, Version 52.10 (2);SEMCAD X Version 14.6.12 (7470) Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 11.6 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 89.28 V/m; Power Drift = 0.15 dB Peak SAR (extrapolated) = 16.0 W/kg SAR(1 g) = 8.94 W/kg; SAR(10 g) = 4.76 W/kg Maximum value of SAR (measured) = 11.2 W/kg 0 dB = 11.2 W/kg = 10.49 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2020/1/15 System Check_Head_1900MHz DUT: D1900V2-5d041 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL_1900_200115 Medium parameters used: f = 1900 MHz; σ = 1.449 S/m; ε r = 39.269; ρ = 1000 kg/m 3 Ambient Temperature：23.9 °C; Liquid Temperature：22.9 °C DASY5 C…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Mika Kaneko(Chief Regulatory Compliance Manager)

[email protected]+81367103225Fax: +815038096297

Technical Contact

Sporton International Inc.Iris Lee

[email protected]033273456

No.52, HwaYa 1st Rd., Kwei-Shan District · Taoyuan · Taiwan

Test Firm

SPORTON International Inc.Alex Chen

[email protected]886-3-327-3456Fax: 886-3-327-0973

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
4	15E	5.75 GHz - 5.83 GHz	27.60 mW

Confidentiality

Long Term

Grant Notes

Power output listed is conducted. This device supports 2x2 MIMO operations as described in this filing. This device has 20 MHz, 40 MHz, and 80 MHz bandwidth modes. For satisfying FCC RF exposure compliance requirements, body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 15 mm separation between the device and the user's body. The highest reported SAR head, body-worn accessory, product specific (phablet-10g), and simultaneous transmission exposure conditions (1g and 10g) are 0.28 W/kg, <0.10 W/kg, 0.42 W/kg (10g), 1.05 W/kg and 0.59 W/kg (10g), respectively.
