PY7-PM0794GSM/WCDMA/LTE + BLUETOOTH, DTS/UNII a/b/g/n/ac, ANT+ and NFC

About the User Guide Thank-you for purchasing this product. Í Before Using This Product Í Descriptions in the User Guide Í Screenshots & Key Labels Í Other Notations Before Using This Product Read "Safety Precautions" and this guide thoroughly beforehand for proper usage. Accessible services may be limited by subscription contract conditions. Descriptions in the User Guide In the User Guide, most operation descriptions are based on handset at time of purchase. Unless noted otherwise, descriptions are for Home Screen. Some operation descriptions may be simplified. Screenshots & Key Labels Screenshots in the User Guide may differ in appearance with actual Display. Key labels in the User Guide are simplified for description purposes and differ with actual Display. Other Notations In the User Guide, the product is referred to as "handset." n microSD TM /microSDHC TM /microSDXC TM Card is referred to as "SD Card." 1 Accessing Instructions on Handset Use Guide application to learn touch operations or making settings. Í Launching Guide Í Showing Status Bar Indicator Í Launching Guide from Notifications Window Í Using Guide Launching Guide In Home Screen, (SoftBank) (Guide) Smartphone Guide top window opens. n If using Smartphone Guide for the first time, Usage notes and Auto Update confirmation appear. Follow onscreen instructions. 2 Setting Auto Update In Smartphone Guide top screen, Auto Updateon/ offBack Showing Status Bar Indicator Set to show the indicator on Status Bar to launch Smartphone Guide. In Home Screen, (SoftBank) (Guide) Smartphone Guide top window opens. n If confirmation appears, follow onscreen instructions. Indicator 3 onBack Setting is complete. 4 Launching Guide from Notifications Window Show Smartphone Guide indicator on Status Bar to check functions quickly from Notifications Window. Drag Status Bar down Notifications Window opens. Tap here for Guide 5 Smartphone Guide top window opens. Checking Operations from Notifications Window For some applications/functions, operation description appears by launching Smartphone Guide from Notifications Window while the application/function is activated. n Set to show the Guide indicator on Status Bar beforehand. n If operation does not appear, Smartphone Guide top window opens instead. 6 Using Guide Item Description Enter Keyword Search for Smartphone Guide. Open Guide Check operations for usage purpose. Voice search is also available. FAQ Check FAQ. Or access FAQ mobile web page. 7 Parts & Functions Í Handset Í Keys Í Desktop Holder Handset Part Description Second Mic Reduces noise for calling. Headphone Port Connect commercially available headphones. Earpiece Hear the other party's voice here. Notification Lamp Flashes for incoming transmissions. Lights while charging. Front Camera Capture yourself. Proximity Sensor Detects surrounding brightness to automatically adjust Display or backlight and prevent Touchscreen misoperation during a call. Display Handset uses a touchscreen-type Display. Operate with your fingers on Display. Mic/Speaker Speak here. 1 Part Description Camera Capture still images and videos. Flash/Photo Light Use as camera flash in a dark place. NFC Mark Hold mark up to reader/writer to use NFC/Osaifu-Keitai ® feature. Wi-Fi/Bluetooth ® Antenna Area Internal Antenna for Wi-Fi and Bluetooth ® . Internal Antenna/GPS Antenna Area Internal Antenna for calls, data communication, and GPS. Nameplate CE mark, FCC ID, IMEI information printed sticker is attached. Do not remove nameplate. Wi-Fi Antenna Area Internal Antenna for Wi-Fi. Internal Antenna Area Internal Antenna for call and data communication. SIM Card/SD Card Slot Insert SIM Card/SD Card. External Device Port Connect commercially available Micro USB Cable etc. Strap Hole Attach strap. 2 Keys Part Description Power Key/Screen Lock Key () Long Press for power on/off. Press for sleep mode on/off. Volume/Zoo m Up/Down Key Adjust Volume. Adjust Zoom while using Camera. Camera Key () Use as Camera shutter. Long Press to launch Camera. Desktop Holder Part Description Attachment 45A Use when charging with Desktop Holder. Terminals Contact with handset Charging Terminal for Desktop Holder. Magnet Contact Connect handset. Recess Use for removing Attachment. Charging Port Connect plug of AC Charger (optional accessory). Attachment 45B Charge 3 cover-attached handset with Desktop Holder. CE mark and FCC ID Open the slot cover, and insert a fingernail into the hook at the edge of the label tray, then pull it out straight. 4 SIM Card SIM Card is an IC card containing phone number and other customer information. Í Handling SIM Card Í Inserting SIM Card Í Removing SIM Card Handling SIM Card n Customer is responsible for any damage caused by inserting SIM Card in an IC card reader, etc. of another brand. n SoftBank Mobile Corp. is not responsible in such case. n Always keep the IC chip clean. n Avoid applying labels. May damage SIM Card. n See instructions included with SIM Card for handling. n SIM Card is the property of SoftBank Mobile Corp. n SIM is replaceable (at cost) in case of loss/damage. n Return SIM Card to SoftBank Mobile Corp. when canceling subscription. n Returned SIM Cards are recycled for environmental purposes. n Note that SIM Card specifications and performance may change without notice. n It is recommended that you keep a separate copy of information that is stored on SIM Card. SoftBank Mobile Corp. is not responsible for damages from stored information that is lost. n Always follow emergency procedures to suspend service if your SIM Card or handset (SIM Card inserted) is lost/stolen. For details, contact Customer Service. n Always power off handset before inserting/removing SIM Card. 5 IC chip Inserting SIM Card Always power off beforehand. Open Slot Cover using groove Draw Tray out using the tab 6 Set SIM Card into Tray with IC chip facing up n Check SIM Card orientation by notch. Insert Tray with SIM Card into handset n Pay attention to Tray orientation.…

Text truncated - open the document above for the full version.

©2014 Important information Sony Consumer Web site At www.sonymobile.com/support there is a support section where help and tips are only a few clicks away. Here you will find the latest computer software updates and tips on how to use your product more efficiently. Service and support You have access to a portfolio of exclusive service advantages such as: • Global and local Web sites providing support. • A global network of Contact Centers. • An extensive network of Sony service partners. • A warranty period. Learn more about the warranty conditions in the Limited Warranty section. At www.sonymobile.com/support or www.sonymobile.com/contact, you can find the latest support tools and information. For operator-specific services and features, please contact your network operator. You can also contact our Contact Centers or contact your local dealer. (Calls are charged according to national rates, including local taxes, unless it is a toll-free number.) If your product needs service, please contact the dealer from whom it was purchased, or one of our service partners. To make a claim under the limited warranty, proof of purchase is required. Guidelines for Safe and Efficient Use Please follow these guidelines. Failure to do so might entail a potential health risk or product malfunction. If in doubt as to its proper function, have the product checked by a certified service partner before charging or using it. Recommendations for care and safe use of our products • Handle with care and keep in a clean and dust-free place. • Warning! May explode if disposed of in fire. • Do not use in environments where relevant IP rating limitations, if applicable, are exceeded (including excess depths and/or pressures of liquid and/or dust) or expose to excess humidity. • For optimum performance, the product should not be operated in temperatures below -10°C(+14°F) or above +45°C(+113°F). Do not expose the battery to temperatures above +60°C(+140°F). • Do not expose to flames or lit tobacco products. • Do not drop, throw or try to bend the product. 2 This is an Internet version of this publication. © Print only for private use. • Do not paint or attempt to disassemble or modify the product. Only Sony authorised personnel should perform service. • Consult with authorised medical staff and the instructions of the medical device manufacturer before using the product near pacemakers or other medical devices or equipment. • Discontinue use of electronic devices, or disable the radio transmitting functionality of the device, where required or requested to do so. • Do not use where a potentially explosive atmosphere exists. • Do not place the product, or install wireless equipment, in the area above an air bag in a car. • Caution: Cracked or broken displays may create sharp edges or splinters that could be harmful upon contact. • Do not use a Bluetooth Headset in positions where it is uncomfortable or will be subject to pressure. Children Warning! Keep out of the reach of children. Do not allow children to play with mobile devices or accessories. They could hurt themselves or others. Products may contain small parts that could become detached and create a choking hazard. Power supply (Charger) Connect the charger to power sources as marked on the product. Do not use outdoors or in damp areas. Do not alter or subject the cord to damage or stress. Unplug the unit before cleaning it. Never alter the plug. If it does not fit into the outlet, have a proper outlet installed by an electrician. When a power supply is connected there is a small drain of power. To avoid this small energy waste, disconnect the power supply when the product is fully charged. Use of charging devices that are not Sony branded may pose increased safety risks. Battery New or idle batteries can have short-term reduced capacity. Fully charge the battery before initial use. Use for the intended purpose only. Charge the battery in temperatures between +5°C(+41°F) and +45°C(+113°F). Do not put the battery into your mouth. Do not let the battery contacts touch another metal object. Turn off the product before removing the battery. Performance depends on temperatures, signal strength, usage patterns, features selected and voice or data transmissions. Only Sony service partners should remove or replace built-in batteries. Use of batteries that are not Sony branded may pose increased safety risks. Replace the battery only with another Sony battery that has been qualified with the product per the standard IEEE-1725. Use of an unqualified battery may present a risk of fire, explosion, leakage or other hazard. 3 This is an Internet version of this publication. © Print only for private use. Personal medical devices Mobile devices / devices with radio transmitters may affect implanted medical equipment. Reduce risk of interference by keeping a minimum distance of 15 cm(6 inches) between the Sony product and the medical device. Use the Sony device at your right ear, when applicable. Do not carry the device in your breast pocket. Turn off the device if you suspect interference. For use in proximity to personal medical devices, please consult a physician and the device manufacturer. Driving In some cases, vehicle manufacturers may forbid the use of mobile devices in their vehicles unless a handsfree kit with an external antenna supports the installation. Check with the vehicle manufacturer's representative to be sure that a mobile device or Bluetooth handsfree will not affect the electronic systems in the vehicle. Full attention should be given to driving at all times and local laws and regulations restricting the use of wireless devices while driving must be observed. GPS/Location based functions Some products provide GPS/Location based functions. Location determining functionality is provided “As is” and “With all faults”. Sony does not make any representation or warranty as to the accuracy of such location information. Use of location-based information by the de…

Text truncated - open the document above for the full version.

Sony Mobile Communications Confidential LETTER 1(2) Document number Revision 7/0061-22/FCP 119 1516 Uen A Prepared by Date SEM/CGQTAGC LEI 3 CHEN 2015-04-21 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQTAGC (YUSHENG WU) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; Confidential LETTER 2(2) Document number Revision 7/0061-22/FCP 119 1516 Uen A e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Yours sincerely Yusheng Wu (武予生) Manager Global Type Approval China Sony Mobile Communications (China) Co., Ltd

Sony Mobile Communications Confidential LETTER 1(2) Document number Revision 3/0061-22/FCP 119 1516 Uen A Prepared by Date SEM/CGQTAGC LEI 3 CHEN 2015-03-09 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQTAGC (YUSHENG WU) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 FCC ID: PY7-PM0794 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. - Schematic Diagram - Block Diagram - Theory of Operation - Antenna Specification - Parts List - Tune up Information Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments for 180days from date of the Grant of Equipment Authorization. - External Photos - Internal Photos - Test Setup Photos - User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential Confidential LETTER 2(2) Document number Revision 3/0061-22/FCP 119 1516 Uen A documents and those information will be available for public review once the grant of equipment authorization is issued. Yours sincerely Yusheng Wu Manager Global Type Approval China Sony Mobile Communications (China) Co., Ltd

Sony Mobile Communications Company Internal REPORT 1(2) Document number Revision 38/0360-LXE 110 1383 Uen PA1 Prepared by Date SEM/CGVFDB KEIGO OSHIRO 2015-04-06 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. PY7-PM0794: External Photos: Front: Rear: Company Internal REPORT 2(2) Document number Revision 38/0360-LXE 110 1383 Uen PA1 Side view: Top/Bottom view:

NVLAP LAB CODE 200065-0 15J20224-S1ASAR EVALUATION REPORT FCC 47 CFR § 2.1093 IEEE Std 1528-2013 The model FCC ID: PY7-PM0792 shares the same enclosure and circuit board as model FCC ID: PY7- PM0794. The WLAN/Bluetooth circuitry and layout, including antenna, are identical between the two units. The WLAN/Bluetooth antenna and surrounding circuitry are the same between these two units, and tune up power targets are identical for WLAN and Bluetooth operations. For this reason the SAR data for the WLAN and Bluetooth operations for FCC ID: PY7-PM0792 is considered representative for FCC ID: PY7-PM0794. For GSM/W-CDMA/LTE + BLUETOOTH, DTS/UNII a/b/g/n/ac, ANT+ & NFC FCC ID: PY7-PM0794 Report Number: 15J20275-S1A Issue Date: 5/8/2015 Prepared for SONY MOBILE COMMUNICATIONS INC. NYA VATTENTORNET MOBILVAGEN 10 LUND 22188 SWEDEN Prepared by UL VERIFICATION SERVICES INC. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 Report No.: 15J20275-S1A Issue Date: 5/8/2015 Page 2 of 29 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. Revision History Rev. Date Revisions Revised By -- 4/22/2015 Initial Issue -- A 5/8/2015 Updated Leveraged WLAN Data Coltyce Sanders Report No.: 15J20275-S1A Issue Date: 5/8/2015 Page 3 of 29 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. Table of Contents 1. Attestation of Test Results ............................................................................................................ 5 2. Test Specification, Methods and Procedures .............................................................................. 6 3. Facilities and Accreditation ........................................................................................................... 6 4. SAR Measurement System & Test Equipment ............................................................................ 7 4.1. SAR Measurement System .......................................................................................................... 7 4.2. SAR Scan Procedures .................................................................................................................. 8 4.3. Test Equipment .......................................................................................................................... 10 5. Measurement Uncertainty ........................................................................................................... 10 6. Device Under Test (DUT) Information ........................................................................................ 11 6.1. DUT Description ......................................................................................................................... 11 6.2. Wireless Technologies ............................................................................................................... 11 6.3. Nominal and Maximum Output Power ........................................................................................ 12 7. RF Exposure Conditions (Test Configurations) ........................................................................ 13 8. Dielectric Property Measurements & System Check ................................................................ 14 8.1. Dielectric Property Measurements .............................................................................................. 14 8.2. System Check............................................................................................................................. 16 9. Conducted Output Power Measurements .................................................................................. 18 9.1. GSM ........................................................................................................................................... 18 9.2. W-CDMA .................................................................................................................................... 21 9.3. WLAN and BT ............................................................................................................................. 23 10. Measured and Reported (Scaled) SAR Results ......................................................................... 24 10.1. GSM850 .................................................................................................................................. 25 10.2. GSM1900 ................................................................................................................................ 25 10.3. W-CDMA Band V .................................................................................................................... 26 10.4. WLAN and Bluetooth .............................................................................................................. 26 11. SAR Measurement Variability ..................................................................................................... 27 12. Simultaneous Transmission SAR Analysis ............................................................................... 28 12.1. Sum of the SAR for WWAN & Wi-Fi & BT ............................................................................... 28 Appendixes .............................................................................................................................................. 29 A_15J20275v0 SAR Photos & Ant. Locations ....................................................................................... 29 B_15J20275v0 SAR System Check Plots ............................................................................................. 29 C_15J20275v0 SAR Highest Test Plots ................................................................................................ 29 Report No.: 15J20275-S1A Issue Date: 5/8/2015 Page 4 of 29 UL Verification Services Inc. Doc. No.: 1.0…

Text truncated - open the document above for the full version.

FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT for GSM/WCDMA/LTE + BLUETOOTH, DTS/UNII a/b/g/n/ac, ANT+ and NFC FCC ID: PY7-PM0794 REPORT NUMBER: 15J20275 –E1, Revision A ISSUE DATE: MAY 05, 2015 Prepared for SONY MOBILE COMMUNICATIONS, INC. 1-8-15 KONAN, MINATO-KU TOKYO, 108-0075 JAPAN Prepared by UL VERIFICATION SERVICES INC. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 15J20275–E1A DATE: MAY 05, 2015 FCC ID: PY7-PM0794 Page 2 of 26 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. Revision History Rev. Issue Date Revisions Revised By -- 04/25/15 Initial Issue CHOON OOI A 05/05/15 Revised Antenna Gain CHOON OOI REPORT NO: 15J20275–E1A DATE: MAY 05, 2015 FCC ID: PY7-PM0794 Page 3 of 26 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 5 2. TEST METHODOLOGY ..................................................................................................... 6 3. FACILITIES AND ACCREDITATION ................................................................................. 6 4. CALIBRATION AND UNCERTAINTY ................................................................................ 7 4.1. MEASURING INSTRUMENT CALIBRATION .............................................................. 7 4.2. SAMPLE CALCULATION ............................................................................................ 7 4.3. MEASUREMENT UNCERTAINTY ............................................................................... 7 5. EQUIPMENT UNDER TEST ............................................................................................... 8 5.1. DESCRIPTION OF EUT .............................................................................................. 8 5.2. MAXIMUM OUTPUT POWER...................................................................................... 8 5.3. DESCRIPTION OF AVAILABLE ANTENNAS .............................................................. 8 5.4. WORST-CASE CONFIGURATION AND MODE .......................................................... 9 5.5. DESCRIPTION OF TEST SETUP ...............................................................................10 6. TEST AND MEASUREMENT EQUIPMENT ......................................................................12 7. SUMMARY TABLE ...........................................................................................................13 8. ANTENNA PORT TEST RESULTS ...................................................................................14 8.1. 20 dB AND 99% BANDWIDTH ...................................................................................14 8.2. HOPPING FREQUENCY SEPARATION ....................................................................15 8.3. NUMBER OF HOPPING CHANNELS .........................................................................16 8.4. AVERAGE TIME OF OCCUPANCY............................................................................17 8.5. OUTPUT POWER.......................................................................................................18 8.6. AVERAGE POWER ....................................................................................................19 8.7. CONDUCTED SPURIOUS EMISSIONS .....................................................................20 9. RADIATED TEST RESULTS .............................................................................................21 9.1. LIMITS AND PROCEDURE ........................................................................................21 9.2. TRANSMITTER ABOVE 1 GHz ..................................................................................22 9.2.1. BASIC DATA RATE GFSK MODULATION ..........................................................22 9.2.2. ENHANCED DATA RATE 8PSK MODULATION .................................................22 9.3. WORST-CASE BELOW 1 GHz ...................................................................................23 10. AC POWER LINE CONDUCTED EMISSIONS ..............................................................24 REPORT NO: 15J20275–E1A DATE: MAY 05, 2015 FCC ID: PY7-PM0794 Page 4 of 26 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. 11. SETUP PHOTOS ...........................................................................................................25 END OF REPORT ....................................................................................................................26 REPORT NO: 15J20275–E1A DATE: MAY 05, 2015 FCC ID: PY7-PM0794 Page 5 of 26 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: SONY MOBILE COMMUNICATIONS, INC. EUT DESCRIPTION: GSM/WCDMA/LTE + BLUETOOTH, DTS/UNII a/b/g/n/ac, ANT+ and NFC SERIAL NUMBER: 159243-6 (Conducted), 153033-5 (Radiated) DATE TESTED: MARCH 9-27, 2015 APPLICABLE STANDARDS STANDARD TEST RESULTS CFR 47 Part 15 Subpart C Pass UL Verification Services Inc. tested the above equipment in accordance with the requiremen…

Text truncated - open the document above for the full version.
