PY7-PM0874PDA Phone

Sony Corporation

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jul 21, 2015
Application Purpose: Original Equipment
Date of Application: Jul 09, 2015
Equipment Note: PDA Phone
Frequency Range: 2510.00000000 - 2560.00000000
Company: Sony Corporation
Country: Japan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Support for you Help is never far away. You can access our support website and a range of help options directly in your device using the Support application. Or you can visit support.sonymobile.com from any supported browser. The support options on our website include downloads, troubleshooting tips, User guides, support numbers, and chat and email support. You can access support contact information for your country or region using the Contact us links. If you don’t have a network connection, you can still access support contact information such as phone numbers and email addresses in your device. Just open the Support application and select the Contact us option near the top of the screen. To access the Support application 1 From your Home screen, tap . 2 Find and tap . Overview 2 3 4 1 5 6 1Charging/Notification light 2Power key 3Volume/Zoom key 4Camera key 5Charger/USB cable port 6Nano SIM/Memory card slot cover To insert a memory card 1 Insert a fingernail into the gap between the top of the memory card slot cover and the device, then open the cover. 2 Press the button next to the memory card slot (as illustrated) using the tip of a paper clip or other similar object with a long, fine tip, then drag out the memory card holder that pops out. 3 Place the memory card in the holder, then re-insert the holder. 4 Close the cover. Make sure you insert the memory card in the correct orientation. To insert the nano SIM card Your device only supports nano SIM cards. Make sure you use the nano SIM card holder and don’t confuse the nano SIM card slot with the memory card slot. 1 Insert a fingernail into the gap between the top of the nano SIM card slot cover and the device, then open the cover. 2 Press the button next to the nano SIM card slot (as illustrated) using the tip of a paper clip or other similar object with a long, fine tip, then drag out the nano SIM card holder that pops out. 3 Place the nano SIM card in the holder, then re-insert the holder. 4 Close the cover. If you insert a nano SIM card while the device is powered on, the device restarts automatically. To turn on the device 1 Make sure your device is charged for at least 30 minutes before you turn it on for the first time. 2 Press and hold down the power key until the device vibrates. 3 Wait a while for the device to start. To activate the screen • Briefly press the power key . Starting up The first time you start your device, a Setup guide opens to help you configure basic settings, personalise your device and sign in to some accounts, for example, your Google™ account. The Setup guide can also be accessed later from the Settings menu. Important Information Before you use your device, please read the Important information provided in the Setup guide in your device. From here, you can find legal information as well as warranty, safety and SAR information. Transferring contacts and other content If you need help to find and transfer contacts, messages, photos and other data from an old device to your new device, we recommend that you use the Xperia™ Transfer application. Visit www.sonymobile.com/xperiatransfer for more information. Dust and water protection Your device is waterproof and protected against dust as long as you follow a few simple instructions: make sure all ports and attached covers are firmly closed; don ́t take the device deeper than 1.5m in water and for longer than 30 minutes; and only use it in fresh water. Casual use in chlorinated pools is permitted provided the device is rinsed in fresh water afterwards. Do not expose it to seawater or saltwater pools. Abuse and improper use of the device will invalidate the warranty. Your device has an Ingress Protection rating of IP65 and IP68. To see what this means and for more information, visit www.sonymobile.com/durability. After using your device in water, it’s important that the USB port is completely dry before a USB cable is inserted into it. To remove moisture from the USB port, shake your device several times with the USB port facing downwards and then use a micro-fibre cloth to wipe the device dry. If moisture is still visible in the USB port, repeat the shaking and drying procedure. Learn more You are now ready to start using your new device. To learn more about your device and its full functionality, access our support website directly in your device using the Support application or by visiting support.sonymobile.com. Frequency bands and model info Below is the model number and supported frequency bands for your device. You can find your model number under Settings > About phone. E5303 UMTS HSPA Band 1 2 5 8 GSM GPRS/EDGE 850/900/1800/1900 LTE Band 1 3 5 7 8 20 E5606 UMTS HSPA Band 1 2 4 5 8 GSM GPRS/EDGE 850/900/1800/1900 LTE Band 2 4 5 7 12 13 17 28 E5653 UMTS HSPA Band 1 2 5 8 GSM GPRS/EDGE 850/900/1800/1900 FDD LTE Band 1 3 5 7 8 20 28 TDD LTE Band 40 Some frequency bands might be turned off in certain markets or by certain operators. Legal information Sony E5303/E5606/E5653 Publication number: 1284-9581.2 This Startup guide is published by Sony Mobile Communications Inc. or its local affiliated company, without any warranty. Improvements and changes to this Startup guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Mobile Communications Inc. at any time and without notice. Such changes will, however, be incorporated into new editions of this Startup guide. All illustrations are for illustration only and may not accurately depict the actual device. See regulatory information such as the device CE mark in the relevant label tray in the device. All product and company names mentioned herein are the trademarks or registered trademarks of their respective owners. Any rights not expressly granted herein are reserved. Visit www.sonymobile.com/global- en/legal/ for more information. Product compliance: This product has been manufactured by or on behalf of Sony Mobile …

Text truncated - open the document above for the full version.

Users Manual

SAR Information FCC Statement Declaration of Conformity Sony E5653 UMTS HSPA Band 1 2 5 8 GSM GPRS/EDGE 850/900/1800/1900 FDD LTE Band 1 3 5 7 8 28 TDD LTE Band 40 Important Information United States & Canada THIS PHONE MODEL HAS BEEN CERTIFIED IN COMPLIANCE WITH THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. The E5653 Series mobile phones have been designed to comply with applicable safety requirements for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed to not exceed the limits of exposure to radio frequency (RF) energy set by governmental authorities. These limits establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by international scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a safety margin designed to assure the safety of all individuals, regardless of age and health. The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate (SAR). Tests for SAR are conducted using standardized methods with the phone transmitting at its highest certified power level in all used frequency bands. While there may be differences between the SAR levels of various phone models, they are all designed to meet the relevant guidelines for exposure to radio waves. The highest SAR value as reported to the authorities for this phone model when tested for use by the ear is 0.321 W/kg, and when worn on the body is 1.394 W/kg. For body-worn operation, the phone has been tested when positioned a minimum of 15 mm from the body without any metal parts in the vicinity of the phone or when properly used with an appropriate accessory and worn on the body. For devices which include “WiFi hotspot” functionality, SAR measurements for the device operating in WiFi hotspot mode were taken using a separation distance of 10 mm. Use of third-party 2 accessories may result in different SAR levels than those reported. Before a phone model is available for sale to the public in the US, it must be tested and certified by the Federal Communications Commission (FCC) that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (i.e., by the ear and worn on the body) as required by the FCC for each model. The FCC has granted an Equipment Authorization for this phone model with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR levels of various phones, all mobile phones granted an FCC equipment authorization meet the government requirement for safe exposure. SAR information on this phone model is on file at the FCC and can be found under the Display Grant section of http://transition.fcc.gov/oet/ea/fccid after searching on FCC ID PY7-PM0874. Additional information on SAR can be found on the Mobile Manufacturers Forum EMF website at http://www.emfexplained.info/. In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard incorporates a margin of safety to give additional protection for the public and to account for any variations in measurements. 3 Renseignements importants États-Unis et Canada CE MODÈLE DE TÉLÉPHONE A ÉTÉ CERTIFIÉ CONFORME AUX EXIGENCES GOUVERNEMENTALES RELATIVES À L'EXPOSITION AUX ONDES RADIOÉLECTRIQUES. Les télépho nes mobiles de la E5653 ont été conçus pour répondre aux normes de sécurité en vigueur en matière d'exposition aux ondes radioélectriques. Votre téléphone sans fil est un émetteur et un récepteur radio. Il est conçu de manière à ne pas dépasser les limites d'exposition à l'énergie des fréquences radio (RF) établies par les autorités gouvernementales. Ces limites fixent les niveaux maximaux d'énergie RF auxquels peut être soumis le grand public. Ces lignes directrices sont basées sur des normes qui ont été élaborées par des organisations scientifiques internationales par le biais d'évaluations périodiques et approfondies des études scientifiques. Ces normes prévoient une marge de sécurité visant à assurer la protection de tous les individus, peu importe leur âge et leur état de santé. Les lignes directrices relatives à l'exposition aux ondes radioélectriques utilisent une unité de mesure appelée « Taux d'absorption spécifique » (TAS). Les tests de TAS sont effectués selon des méthodes standardisées dans lesquelles le téléphone émet dans toutes les bandes de fréquences utilisées, à la plus forte puissance pour laquelle il a été homologué. Bien que le TAS puisse être différent d'un modèle de téléphone à un autre, tous les appareils sont conçus pour respecter les lignes directrices relatives aux ondes radioélectriques. Le DAS le plus élevé relevé par les autorités pour ce modèle de téléphone est de 0.321 W/kg lorsqu'il est testé en utilisation près de l'oreille, et de 1.394 W/kg lorsqu'il est porté sur le corps. En mode d’utilisation porté sur le corps, le téléphone a été testé lorsqu’il est à au moins 15 mm du corps et à l’écart de toute pièce en métal, ou lorsqu’il est utilisé de façon adéquate avec un accessoire et porté sur le corps. Pour les appareils munis de la fonctionnalité « point d'accès WiFi », les mesures du DAS de l'appareil en mode WiFi ont été prises à une distance de sécurité de 10 mm. L'utilisation d'accessoires tiers peut produire des niveaux de DAS différents de ceux relevés. Avant qu'un modèle de téléphone ne soit mis en vente auprès du public aux États-Unis, la Commission fédérale des communications (CFC) doit le tester et certifier qu'il respecte les limites fixées dans les exigences gouvernementales d'exposition sans danger*. Pour chaque modèle, les tests sont effectués en position et aux endroits d'usage (c.-à-d. près de l'oreille et porté sur le corps), tel que requis par la…

Text truncated - open the document above for the full version.

Cover Letter(s)

THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD Authority to Act as Agent Date: June 22, 2015 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: _____ SGS Taiwan Ltd ______ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: _____ June 22, 2015 ~ June 22, 2016_____ By: __________________________ ______Willis Chen______________ (Signature 1 ) (Print name) Title: _______ Technical Manager ___ On behalf of: _______ SGS Taiwna Ltd_ ____ (Company Name) Telephone: ______+886-2-22993279_____ 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Cover Letter(s)

THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD Request for Confidentiality Date: June 22, 2015 Subject: Confidentiality Request for: PY7-PM0874 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 6.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* 3 User’s Manual ______ Sony Mobile Communications AB ______ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___180 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: __________________________ ________ Willis Chen__ ____ (Signature/Title 2 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section V regarding EXCEPTIONAL CIRCUMSTANCES. As of the October 2014 version of this document, TCB’s can not authorize these requests. The applicant should petition the FCC by submitting an inquiry as directed. A copy of this inquiry and the FCC’s response must be provided with the application. 2 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Cover Letter(s)

Attestation Letter Date: June 22, 2015 I, the undersigned, declare that the radio device of given application is firmware‐locked to leave end‐user not capable to control the operating parameters of frequency range, modulation type, maximum output power, and any mean to violate the condition of all parameters while unlicensed transmitter is being certified via the mean of software configuration control. The applicant: Sony Mobile Communications AB Product Name: PDA Phone FCC ID : PY7-PM0870, PY7-PM-0871, PY7-PM0872, PY7-PM0873, PY7-PM0874, PY7-PM0875 Willis Chen / Technical Manager SGS Taiwan Ltd

Cover Letter(s)

Evaluation Sheet – The Data of Measurement Re-using Jun. 25, 2015 Federal Communication Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mill Rd. Columbia MD 21046 Subject of Request: Permission and evaluation to re-use WLAN a/b/g/n, Bluetooth and NFC test data of model PM-0874-BV in application of PM-0873-BV Effective ID: PY7-PM0873/ PY7-PM0874 Dear Sirs, We, the undersigned, request to re-use the test data from ID: PY7-PM0873 in application of ID: PY7-PM0874 ID: PY7-PM0873 and PY7-PM0874 contain the same PCB, layout, display, I/O digital IC, and battery spec, and confines in the same enclosure. These two ID employs the equivalently identical chipset, circuit layout, antenna of WLAN a/b/g/n, Bluetooth and NFC, with the same default setting of transmitted output power level, and same software/firmware controlling radio parameters. The difference between PY7-PM0873 / PY7-PM0874 is PY7-PM0873 support with dual SIM and PY7-PM0874 supports with single SIM only hardware difference is the SIM socket, others are all the same. In PCS test report demonstrates the result of spot- check on Radiated Spurious Emission in order to reveal of the evidence of compliance record proving the implementation of single SIM built causes no degradation as compared to build, PY7-PM0873. Hence, the given PCS/DSS/DTS/NII/DXX test report contains the identical test results, which inherent from PY7-PM873 are: Description Of Test Case (PCS/DSS / DTS / NII) Result AC Power Line Conducted Emission Inherent from PY7-PM0873 Peak Output Power Inherent from PY7-PM0873 6dB Bandwidth Inherent from PY7-PM0873 Sincerely, _________________________________ Willis Chen / RF Manager SGS Taiwan Ltd. 134, Wu Kung Road, New Taipei Industrial Park, Wu Ku District, New Taipei City, 24803, Taiwan 20dB Bandwidth Inherent from PY7-PM0873 100 KHz Bandwidth Of Frequency Band Edges Inherent from PY7-PM0873 Spurious Emission Inherent from PY7-PM0873 Peak Power Density Inherent from PY7-PM0873 Antenna Requirement Inherent from PY7-PM0873 Frequency Separation Inherent from PY7-PM0873 Number of hopping frequency Inherent from PY7-PM0873 Time of Occupancy Inherent from PY7-PM0873 Transmission in case of Absence of Information Inherent from PY7-PM0873 Frequency Stability Inherent from PY7-PM0873 ERP / EIRP measurement Inherent from PY7-PM0873 Occupied Bandwidth Inherent from PY7-PM0873 Peak to Average Ratio Inherent from PY7-PM0873

Cover Letter(s)

Letter of Authority One behalf of Sony Mobile Communications Inc, I, Yusheng Wu, manager hereby give: Name Representative of agent: Willis Chen Agent Company name: SGS Taiwan Ltd Address: 134, Wu Kung Road, Wuku Industrial Zone Wuku Area City: New Taipei City Country: Taiwan Authority to apply for NB opinion and FCC certification only in respect of product identified below, Type Number FCC ID IC ID PM-0870-BV PY7-PM0870 N/A PM-0871-BV PY7-PM0871 N/A PM-0872-BV PY7-PM0872 4170B-PM0872 PM-0873-BV PY7-PM0873 N/A PM-0874-BV PY7-PM0874 N/A PM-0875-BV PY7-PM0875 N/A This authorization will be only effective to filing, answering inquiring from Notify Body “ CETECOM ( Germany ) “or TCB reviewer “ American Certification Body ( USA )” , any associative matter involving application of this NB opinion and FCC certification, and it will not be extended beyond the aforementioned scope. Regards ______________ Yusheng Wu Manager, No.16, Guangshun South street, Chaoyang District Beijing, China, 100102

External Photos

Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/新北市五股區新北產業園區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group EXTERNAL PHOTOGRAPHS OF EUT All View of EUT Front View of EUT Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/新北市五股區新北產業園區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group Back View of EUT Side View of EUT – 1 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/新北市五股區新北產業園區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group Side View of EUT – 2 Side View of EUT – 3 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewT…

Text truncated - open the document above for the full version.

ID Label/Location Info

1(1) Note: Any hard copy of this document is for reference only. Due to template and application dependencies the header and footer may fail to display correct data. It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Label Location 1. Open Micro‐SD door 2. Pull out the Label Open the Micro SD door and pull out the label, the label trays are visible to the users Front Side Label Location

ID Label/Location Info

00000000-000000-0 TYPE: PM-0874-BV EFF FCC ID: PY7-PM0874 Made in China 00W01 SI: XXXX-XXXX

Internal Photos

Text truncated - open the document above for the full version.

Contact Information

Applicant

Mika Kaneko(Chief Regulatory Compliance Manager)

[email protected]+81367103225Fax: +815038096297

Technical Contact

SGS Taiwan LtdWillis Chen

[email protected]886 2 2299 3279

134, Wu Kung Road, Wuku Industrial Zone · Wuku Area New Taipei City · Taiwan

Test Firm

SGS Taiwan Ltd.Jason Lin

[email protected]886-2-2299-3279Fax: 886 2 2298 2248

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
14	27	2.51 GHz - 2.56 GHz	713.00 mW	18M0D7W	2.5 ppm

Confidentiality

Long Term

Grant Notes

Power output is ERP for Part 22 and EIRP for Part 24 and Part 27. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: 0.29 W/kg; Body-worn 0.60 W/kg; Product Specific (Wireless Router): 1.40 W/kg; Simultaneous Transmission SAR: 1.46 W/kg. This device contains GSM/WCDMA/LTE functions that are not operational in U.S. Territories. This filing is only applicable for 850 MHz Cell, 1900 MHz PCS and 2500 MHz BRS operations. This device contains Bluetooth, BLE, NFC and WLAN transmitters. This device has 1.4 MHz, 3 MHz, 5 MHz and 10 MHz bandwidth modes for LTE Band 5; and 5 MHz, 10 MHz, 15 MHz and 20 MHz bandwidth modes for LTE Band 7.
