Important Information United States & Canada THIS PHONE MODEL HAS BEEN CERTIFIED IN COMPLIANCE WITH THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. The E 6603 Series mobile phones have been designed to comply with applicable safety requirem ents for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed to not exceed the limits of exposure to radio frequency (RF) energy set by governmental authorities. These limits establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by international scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a safety margin designed to assure the safety of all individuals, regardless of age and health. The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate (SAR). Tests for SAR are conducted using standardized methods with the phone transmitting at its highest certified power level in all used frequency bands. While there may be differences between the SAR levels of various phone models, they are all designed to meet the relevant guidelines for exposure to radio waves. The highest SAR value as reported to the authorities for this phone model when tested for use by the ear is 0.55 W/kg, and when worn on the body is 0.59 W/kg. For body-worn operation, the phone has been tested when positioned a minimum of 15 mm from the body without any metal parts in the vicinity of the phone or when properly used with an appropriate accessory and worn on the body. For devices which include “WiFi hotspot” functionality, SAR measurements for the device operating in WiFi hotspot mode were taken using a separation distance of 10 mm. Use of third-party 2 accessories may result in different SAR levels than those reported. Before a phone model is available for sale to the public in the US, it must be tested and certified by the Federal Communications Commission (FCC) that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (i.e., by the ear and worn on the body) as required by the FCC for each model. The FCC has granted an Equipment Authorization for this phone model with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR levels of various phones, all mobile phones granted an FCC equipment authorization meet the government requirement for safe exposure. SAR information on this phone model is on file at the FCC and can be found under the Display Grant section of http://transition.fcc.gov/oet/ea/fccid after searching on FCC ID PY7-PM0901. Additional information on SAR can be found on the Mobile Manufacturers Forum EMF website at http://www.emfexplained.info/. In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard incorporates a margin of safety to give additional protection for the public and to account for any variations in measurements. 3 FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, an d (2) This device must accept any interference received, including interference that may cause undesired operation. Any change or modification not expressly approved by Sony may void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. 17 Industry Canada Statement This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This Class B digital apparatus complies with Canadian ICES-003. The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall comply with the e.i.r.p. limit; and the maximum antenna gain permitted for devices in the band 5725-5825 MHz shall comply with the e.i.r.p. limits specified for point-to-point and non point-to-point operation as appropriate. Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. Avis d’industrie Canada Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de ré…

Text truncated - open the document above for the full version.

Support for you Access our support website directly in your device or visit support.sonymobile.com from any supported browser. Support options include User guides, downloads, troubleshooting tips and contact information. Even if you don ́t have a network connection, you can access support contact numbers or email addresses in your device. Depending on the country or region where you purchased your device, you can find this information directly in the Support application, or by searching your contacts for Xperia™ Care. To access the Support application 1 From your Home screen, tap . 2 Find and tap . For best support available, we recommend connecting to the Internet when using the Support application. Overview 5 1 2 3 4 6 1Charging/Notification light 2Power key/Fingerprint sensor 3Volume/Zoom key 4Camera key 5Charger/USB cable port 6Nano SIM/Memory card slot cover To insert a memory card 1 Open the nano SIM/memory card slot cover. 2 Using a fingernail or other similar object, drag out the holder for the nano SIM card and memory card. 3 Place the memory card in the memory card slot in the holder, then re-insert the holder. 4 Close the cover. To insert the nano SIM card Your device only supports nano SIM cards. When you drag out the holder for the nano SIM card and memory card to insert the nano SIM card, do not turn the holder upside down. Make sure you re-insert the holder in the correct orientation. 1 Open the nano SIM/memory card slot cover. 2 Using a fingernail or other similar object, drag out the holder for the nano SIM card and memory card. 3 Place the nano SIM card in the nano SIM card slot in the holder, then re-insert the holder. 4 Close the cover. If you insert a nano SIM card while the device is powered on, the device restarts automatically. To turn on the device 1 Make sure your device is charged for at least 30 minutes before you turn it on for the first time. 2 Press and hold down the power key until the device vibrates. 3 Wait a while for the device to start. To activate the screen • Briefly press the power key . Dust and water protection Your device is waterproof and protected against dust: all ports and attached covers should be firmly closed. You should not put the device completely under water or expose it to sea water; salt water; chlorinated water; or liquids such as drinks. Improper use will invalidate the warranty. Your device has the Ingress Protection ratings IP65 and IP68. To understand what these ratings mean and how they affect your usage, visit www.sonymobile.com/waterproof. Your capless USB port must be completely dry before a cable can be connected. If your USB port gets wet, wipe dry with a microfibre cloth and shake it several times with the USB port facing downwards. Repeat until no moisture is visible in the USB port. Important Information Before you use your device, please read the Important information provided under Settings > About phone > Legal information in your device. From here, you can find legal information as well as warranty, safety and SAR information. Transferring contacts and other content If you need help to find and transfer contacts, messages, photos and other data from an old device to your new device, we recommend that you use the Xperia™ Transfer application. Visit www.sonymobile.com/xperiatransfer for more information. Frequency bands and model info Below is the model number and supported frequency bands for your device. You can find your model number under Settings > About phone. E6603/E6653 UMTS HSPA Band 1 2 5 8 GSM GPRS/EDGE 850/900/1800/1900 FDD LTE Band 1 2 3 4 5 7 8 12 17 20 28 TDD LTE Band 38 40 Some frequency bands might be turned off in certain markets or by certain operators. To view the CE mark FCC ID: PY7-PM0XXX 1 Open the nano SIM/Memory card slot cover. 2 Place a fingernail under the right or left edge of the label tray, then drag the tray outwards. The CE mark and FCC ID are displayed on the tray. To view the regulatory compliance mark • Open the phone dialer, then enter *#07#. Legal information Sony E6603/E6653 Publication number: 1284-9581.2 This Startup guide is published by Sony Mobile Communications Inc. or its local affiliated company, without any warranty. Improvements and changes to this Startup guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Mobile Communications Inc. at any time and without notice. Such changes will, however, be incorporated into new editions of this Startup guide. All illustrations are for illustration only and may not accurately depict the actual device. All product and company names mentioned herein are the trademarks or registered trademarks of their respective owners. Any rights not expressly granted herein are reserved. Visit www.sonymobile.com/global- en/legal/ for more information. Product compliance: This product has been manufactured by or on behalf of Sony Mobile Communications Inc., 1-8-15 Konan, Minato-ku, Tokyo 108-0075, Japan. Inquiries related to product compliance based on national legislation shall be addressed to Sony Mobile Quality Office, Sony Mobile Communications Inc., 1-8-15 Konan, Minato-ku, Tokyo 108-0075, Japan. Should your device need warranty service, please return it to the dealer from whom it was purchased or visit support.sonymobile.com/contact to contact your local Sony Mobile repair partner (national rates may apply). © 2015 Sony Mobile Communications Inc. All rights reserved. Startup guide Xperia ™ XX E6603/E6653 Sony Mobile Communications Inc. 1-8-15 Konan, Minato-ku, Tokyo 108-0075, Japan 1284-9581.2

Sony Mobile Communications Company Internal LETTER 1(2) Document number Revision 30/0061-LXE 110 1480 Uen A Prepared by Date SEM/CGQKACC DAN 3 LI 2015-08-18 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQKACD (YUSHENG WU) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; Company Internal LETTER 2(2) Document number Revision 30/0061-LXE 110 1480 Uen A f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Yours sincerely Yusheng Wu (武予生) Manager Global Type Approval China Sony Mobile Communications (China) Co., Ltd

Sony Mobile Communications Company Internal LETTER 1(2) Document number Revision 31/0061-LXE 110 1480 Uen A Prepared by Date SEM/CGQKACC DAN 3 LI 2015-08-18 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQKACD (YUSHENG WU) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 FCC ID: PY7-PM0901 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. - Schematic Diagram - Block Diagram - Theory of Operation - Antenna Specification - Parts List - Tune up Information Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments for 180days from date of the Grant of Equipment Authorization. - External Photos - Internal Photos - Test Setup Photos - User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential Company Internal LETTER 2(2) Document number Revision 31/0061-LXE 110 1480 Uen A documents and those information will be available for public review once the grant of equipment authorization is issued. Yours sincerely Yusheng Wu Manager Global Type Approval China Sony Mobile Communications (China) Co., Ltd

Sony Mobile Communications Company Internal REPORT 1(2) Document number Revision 14/0360-1/FCP 119 1495/4 Uen PA1 Prepared by Date 2014-08-29 Contents responsible if other than preparer Remarks Approved by SEM/CGVOHCA AKINORI YAMADA PY7－PM0901: External Photos: Front: Rear: Sony Mobile Communications Company Internal REPORT 2(2) Document number Revision 14/0360-1/FCP 119 1495/4 Uen PA1 Prepared by Date 2014-08-29 Contents responsible if other than preparer Remarks Approved by SEM/CGVOHCA AKINORI YAMADA Side view: Top/Bottom view:

Label and Label Location FCC ID: PY7-PM0901 Sony M obile Communications Confi denti al WORK DESCRIPTION 1(1 ) Document number Revision A Prepared by Date YOSHINORI FUSE (22714209) 2015-05-26- Conte nts responsible if oth er t han preparer Remarks This d ocument is managed i n meta Doc. Approved by FCC ID: PY7-PM0901 Front side of the EUT

Sony Mobile Communications Confidential REPORT 1(4) Document number Revision 9/0360-1/FCP 119 1495/4 Uen PA3 Prepared by Date 2014-08-27 Contents responsible if other than preparer Remarks Approved by SEM/CGVOHCA AKINORI YAMADA PY7－PM0901: Internal Photos: Without Rear Panel Rear Panel Without Rear Panel Sony Mobile Communications Confidential REPORT 2(4) Document number Revision 9/0360-1/FCP 119 1495/4 Uen PA3 Prepared by Date 2014-08-27 Contents responsible if other than preparer Remarks Approved by SEM/CGVOHCA AKINORI YAMADA With PWB Without PWB Internal PWB with/without Shield cases – Front (LCD)-side: Internal PWB with Shield cases (Front-side) Sony Mobile Communications Confidential REPORT 3(4) Document number Revision 9/0360-1/FCP 119 1495/4 Uen PA3 Prepared by Date 2014-08-27 Contents responsible if other than preparer Remarks Approved by SEM/CGVOHCA AKINORI YAMADA Internal PWB without Shield cases (Front-side) Internal PWB with Shield cases (Rear-side) Internal PWB without Shield cases (Rear-side) Sony Mobile Communications Confidential REPORT 4(4) Document number Revision 9/0360-1/FCP 119 1495/4 Uen PA3 Prepared by Date 2014-08-27 Contents responsible if other than preparer Remarks Approved by SEM/CGVOHCA AKINORI YAMADA Battery:

SPORTON INTERNATIONAL INC. Report Template No.: BU5-FR15CANT Version 1.0 FCC TEST REPORT Report No. : FR571611E FCC RF TEST REPORT 47 CFR FCC Part 15 Subpart C § 15.249 Equipment : GSM/WCDMA/LTE Phone + Bluetooth, DTS/UNII a/b/g/n/ac, ANT+, and NFC BRAND NAME : Sony FCC ID : PY7-PM0901 We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Joseph Lin / Supervisor Approved by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan District, Tao Yuan City, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page No. : i of i TEL : 886-3-327-3456 Issued Date : Sep. 09, 2015 FAX : 886-3-328-4978 FCC ID : PY7-PM0901 FCC TEST REPORT Report No. : FR571611E Table of Contents 1. SUMMARY OF THE TEST RESULT ....................................................................................................................... 2 2. GENERAL INFORMATION ...................................................................................................................................... 3 2.1 Applicant ......................................................................................................................................................................... 3 2.2 Manufacturer ................................................................................................................................................................... 3 2.3 Product Details ................................................................................................................................................................ 3 2.4 Table for Test Modes ....................................................................................................................................................... 4 2.5 Table for Testing Locations ............................................................................................................................................. 5 2.6 Table for Supporting Units............................................................................................................................................... 5 2.7 Test Configurations ......................................................................................................................................................... 6 3. TEST RESULT ......................................................................................................................................................... 7 3.1 AC Power Line Conducted Emissions Measurement.......................................................................................................... 7 3.2 20dB and & 99% Occupied Bandwidth ............................................................................................................................ 12 3.3 Field Strength of Fundamental Emissions and Radiated Spurious Emissions ................................................................... 15 3.4 Antenna Requirements .................................................................................................................................................. 28 4. LIST OF MEASURING EQUIPMENT .................................................................................................................... 29 SPORTON INTERNATIONAL INC. Page Number : 1 of 30 TEL : 886-3-327-3456 Report Issued Date : Sep. 09, 2015 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : PY7-PM0901 Report Template No.: BU5-FR15CANT Version 1.0 FCC TEST REPORT Report No. : FR571611E REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FR571611E Rev. 01 Initial issue of report Sep. 09, 2015 SPORTON INTERNATIONAL INC. Page Number : 2 of 30 TEL : 886-3-327-3456 Report Issued Date : Sep. 09, 2015 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : PY7-PM0901 Report Template No.: BU5-FR15CANT Version 1.0 FCC TEST REPORT Report No. : FR571611E 1. SUMMARY OF THE TEST RESULT Applied Standard: Part FCC Rule Description of Test Result Under Limit 3.1 15.207 AC Power Line Conducted Emissions Complies 20.40 dB at 0.622MHz 3.2 2.1049 20dB & 99% Occupied Bandwidth Complies - 3.3 15.249(a) Field Strength of Fundamental Emissions Complies 19.43 dB at 2480.000MHz 3.3 15.249(a)(d) Radiated Spurious Emissions Complies 13.21 dB at 32.160MHz 3.4 15.203 Antenna Requirements Complies - Remark: The FR571611E report reuses test data from the FR571614E report. Uncertainty of Conducted Emission Measurement (150kHz ~ 30MHz) Measuring Uncertainty for a Level of Confidence of 95% (U = 2Uc(y)) 2.26 Uncertainty of Radiated Emission Measurement (30 MHz ~ 1000 MHz) Measuring Uncertainty for a Level of Confidence of 95% (U = 2Uc(y)) 4.90 SPORTON INTERNATIONAL INC. Page Number : 3 of 30 TEL : 886-3-327-3456 Report Issued Date : Sep. 09, 2015 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : PY7-PM0901 Report Template No.: BU5-FR15CANT Version 1.0 FCC TEST REPORT Report No. : FR571611E 2. GENERAL INFORMATION 2.1 Applicant Sony Mobile Communications Inc. Nya Vattentornet, 22188 Lund, Sweden 2.2 Manufacturer Sony Mobile Communications Inc. 1-8-15 Konan, Minato-ku, Tokyo, 108-0075, Japan 2.3 Product Details For more detailed features description, please refer to the manufacturer’s specifications or user’s manual. Items Description Modulation GFSK Channel Bandwidth (99%) 1.026MHz Max. Field Strength (Peak) 94.57dBμV/m Max. Field Strength (Average) 68.19dBμV/m ANT+ Channel Number 78 ANT+ Frequency Range 2403-2480MHz EUT Information List IMEI HW Version SW Version S/N Performed Test Item IMEI: 004402541707513 A 32.0.B.0.192 CB5A279FVJ RF conducted measurement IMEI: 004402541706515 CB5A279A2H8 Radiat…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL INC. Page Number : 1 of 3 TEL : 886-3-327-3456 Report Issued Date : Sep. 07, 2015 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : PY7-PM0901 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR571611D Setup Photographs <Conducted Emission> Remote View Rear View SPORTON INTERNATIONAL INC. Page Number : 2 of 3 TEL : 886-3-327-3456 Report Issued Date : Sep. 07, 2015 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : PY7-PM0901 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR571611D <Radiated Emission> From 9kHz~30MHz Remote View Rear View SPORTON INTERNATIONAL INC. Page Number : 3 of 3 TEL : 886-3-327-3456 Report Issued Date : Sep. 07, 2015 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : PY7-PM0901 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR571611D From 30MHz~1GHz Remote View Rear View

SPORTON INTERNATIONAL INC. Page Number : 1 of 3 TEL : 886-3-327-3456 Report Issued Date : Sep. 07, 2015 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : PY7-PM0901 Report Template No.: BU5-FR15CANT Version 1.0 FCC TEST REPORT Report No. : FR571611E Setup Photographs <Conducted Emission> Remote View Rear View SPORTON INTERNATIONAL INC. Page Number : 2 of 3 TEL : 886-3-327-3456 Report Issued Date : Sep. 07, 2015 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : PY7-PM0901 Report Template No.: BU5-FR15CANT Version 1.0 FCC TEST REPORT Report No. : FR571611E <Radiated Emission> Z Plane LF Remote View Rear View SPORTON INTERNATIONAL INC. Page Number : 3 of 3 TEL : 886-3-327-3456 Report Issued Date : Sep. 07, 2015 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : PY7-PM0901 Report Template No.: BU5-FR15CANT Version 1.0 FCC TEST REPORT Report No. : FR571611E HF Remote View Rear View
