Support for you Access our support website directly in your device or visit support.sonymobile.com from any supported browser. Support options include User guides, downloads, troubleshooting tips and contact information. Even if you don ́t have a network connection, you can access support contact numbers or email addresses in your device. Depending on the country or region where you purchased your device, you can find this information directly in the Support application, or by searching your contacts for Xperia™ Care. To access the Support application 1 From your Home screen, tap . 2 Find and tap . For best support available, we recommend connecting to the Internet when using the Support application. Overview 5 1 2 3 4 6 1Charging/Notification light 2Power key/Fingerprint sensor 3Volume/Zoom key 4Camera key 5Charger/USB cable port 6Nano SIM/Memory card slot cover To insert a memory card 1 Open the nano SIM/Memory card slot cover. 2 Insert the memory card into the memory card slot, then close the cover. Make sure you insert the memory card in the correct orientation. To insert the nano SIM cards If you insert the nano SIM card while the device is powered on, the device restarts automatically. 1 Open the nano SIM/Memory card slot cover. 2 Using a fingernail or other similar object, drag out the nano SIM card holder. 3 Place the nano SIM card (or cards) in the relevant nano SIM card slot (or slots) in the holder, then re-insert the holder. 4 Close the cover. Make sure you re-insert the nano SIM card holder in the correct orientation. When you drag out the holder to insert the nano SIM card, do not turn the holder upside down. To turn on the device 1 Make sure your device is charged for at least 30 minutes before you turn it on for the first time. 2 Press and hold down the power key until the device vibrates. 3 Wait a while for the device to start. To activate the screen • Briefly press the power key . Dust and water protection Your device is waterproof and protected against dust: all ports and attached covers should be firmly closed. You should not put the device completely under water or expose it to sea water; salt water; chlorinated water; or liquids such as drinks. Improper use will invalidate the warranty. Your device has the Ingress Protection ratings IP65 and IP68. To understand what these ratings mean and how they affect your usage, visit www.sonymobile.com/waterproof. Your capless USB port must be completely dry before a cable can be connected. If your USB port gets wet, wipe dry with a microfibre cloth and shake it several times with the USB port facing downwards. Repeat until no moisture is visible in the USB port. Important Information Before you use your device, please read the Important information provided under Settings > About phone > Legal information in your device. From here, you can find legal information as well as warranty, safety and SAR information. Transferring contacts and other content If you need help to find and transfer contacts, messages, photos and other data from an old device to your new device, we recommend that you use the Xperia™ Transfer application. Visit www.sonymobile.com/xperiatransfer for more information. Frequency bands and model info Below is the model number and supported frequency bands for your device. You can find your model number under Settings > About phone. E6633 UMTS HSPA Band 1 2 4 5 8 GSM GPRS/EDGE 850/900/1800/1900 LTE Band 1 2 3 4 5 7 8 12 17 20 E6683 UMTS HSPA Band 1 2 4 5 8 GSM GPRS/EDGE 850/900/1800/1900 FDD LTE Band 1 2 3 4 5 7 8 12 17 20 TDD LTE Band 38 39 40 41 Some frequency bands might be turned off in certain markets or by certain operators. To view the CE mark 1 Open the nano SIM/Memory card slot cover. 2 Place a fingernail under the right or left edge of the label tray, then drag the tray outwards. The CE mark and FCC ID are displayed on the tray. To view the regulatory compliance mark • Open the phone dialer, then enter *#07#. Legal information Sony E6633/E6683 Publication number: 1284-9581.2 This Startup guide is published by Sony Mobile Communications Inc. or its local affiliated company, without any warranty. Improvements and changes to this Startup guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Mobile Communications Inc. at any time and without notice. Such changes will, however, be incorporated into new editions of this Startup guide. All illustrations are for illustration only and may not accurately depict the actual device. All product and company names mentioned herein are the trademarks or registered trademarks of their respective owners. Any rights not expressly granted herein are reserved. Visit www.sonymobile.com/global- en/legal/ for more information. Product compliance: This product has been manufactured by or on behalf of Sony Mobile Communications Inc., 1-8-15 Konan, Minato-ku, Tokyo 108-0075, Japan. Inquiries related to product compliance based on national legislation shall be addressed to Sony Mobile Quality Office, Sony Mobile Communications Inc., 1-8-15 Konan, Minato-ku, Tokyo 108-0075, Japan. Should your device need warranty service, please return it to the dealer from whom it was purchased or visit support.sonymobile.com/contact to contact your local Sony Mobile repair partner (national rates may apply). © 2015 Sony Mobile Communications Inc. All rights reserved. Startup guide Xperia ™ XX E6633/E6683 Sony Mobile Communications Inc. 1-8-15 Konan, Minato-ku, Tokyo 108-0075, Japan 1284-9581.2

Sony Mobile Communications Confidential LETTER 1(2) Document number Revision 21/0061-22/FCP 119 1516 Uen A Prepared by Date SEM/CGQKACD CAROL LI 2015-09-15 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQKACD (YUSHENG WU) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 FCC ID: PY7-PM0907 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. - Schematic Diagram - Block Diagram - Theory of Operation - Antenna Specification - Parts List - Tune up Information Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments for 180days from date of the Grant of Equipment Authorization. - External Photos - Internal Photos - Test Setup Photos - User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential Confidential LETTER 2(2) Document number Revision 21/0061-22/FCP 119 1516 Uen A documents and those information will be available for public review once the grant of equipment authorization is issued. Yours sincerely Yusheng Wu Manager Global Type Approval China Sony Mobile Communications (China) Co., Ltd

Sony Mobile Communications Confidential LETTER 1(1) Document number Revision 70/0061-LXE 108 828 Uen PA1 Prepared by Date SEM/CGQKACD CAROL LI 2015-09-21 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Sony Mobile Communications Inc., hereby declares the device, FCC ID: PY7-PM0907, as a variant of the device, FCC ID: PY7-PM0908. The differences between FCC ID: PY7-PM0907 and FCC ID: PY7-PM0908 are as follows: FCC ID: PY7-PM0907 doesn’t support TDD-LTE compared to FCC ID: PY7-PM0908. FCC ID: PY7-PM0907 & FCC ID: PY7-PM0908 both utilise the same main PWB. Product form factor and all antennas (BT/BLE/WLAN/Ant+/RFID/GPS/AGPS) between the two versions remain identical in type and construction. Antenna Gain is identical between the two versions. Based on this, the FCC part 15C test data for BT/BLE/WLAN/Ant+/ RF ID/HAC issued for FCC ID: PY7-PM0908 also apply for FCC ID: PY7-PM0907. In addition, the FCC part 22/24/27 conducted test data and RSE test data issued for FCC ID: PY7-PM0908 also applies for FCC ID: PY7-PM0907. Only ERP/EIRP was carried out and update test data in the report of FCC ID: PY7-PM0907. Yours Sincerely Yusheng Wu (武予生) Manager Global Type Approval China Sony Mobile Communications (China) Co., Ltd

Sony Mobile Communications Company Internal INTRODUCTION 1(1) Document number Revision 15/0341-FEA 202 8219 Uen PA2 Prepared by Date SEM/CGQKACD DAO KANG 2015-09-10 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. FCC ID: PY7-PM0907 External Photos Front Rear Side view: Top/Bottom view: Top Bottom

Label and Label Location FCC ID: PY7-PM0907 Sony M obile Communications Confi denti al WORK DESCRIPTION 1(1 ) Document number Revision A Prepared by Date YOSHINORI FUSE (22714209) 2015-05-26- Conte nts responsible if oth er t han preparer Remarks This d ocument is managed i n meta Doc. Approved by FCC ID: PY7-PM0907 Front side of the EUT

Sony Mobile Communications Company Internal INTRODUCTION 1(3) Document number Revision 13/0341-FEA 202 8219 Uen PA3 Prepared by Date SEM/CGQKACD DAO KANG 2015-09-10 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. FCC ID: PY7-PM0907 Internal Photos Without Rear Panel Rear Panel With PWB Without PWB Company Internal INTRODUCTION 2(3) Document number Revision 13/0341-FEA 202 8219 Uen PA3 Internal PWB with/without Shield cases–Front (LCD)– side: Internal PWB with Shield cases (Front - side) Internal PWB without Shield cases (Front - side) Internal PWB with/without Shield cases–Rear–side Internal PWB with Shield cases (Rear-side) Internal PWB without Shield cases (Rear-side) Company Internal INTRODUCTION 3(3) Document number Revision 13/0341-FEA 202 8219 Uen PA3 Battery
