Company Internal Specification 1(4) Document number Revision 6 Prepared by Date HW PM Torbjörn Samuelsson 2013-08-15 Contents responsible if other than preparer Remarks This document is handled in SPACE Approved by HW PM Torbjörn Samuelsson  Type number: RD-0070  FCC id: PY7-RD0070  IC id: 4170B-RD0070 Specification Core Unit Marking Contents 1 Printing information............................................................................ 2 2 Contents and positioning of laser etch printing .................................. 2 2.1 Contents ............................................................................................ 2 2.2 Positioning of printing ........................................................................ 4 3 REVISION INFORMATION ............................................................... 4 Abstract This document describes the label printing for Ellis (Smartwear) 1278-8125 Company Internal Specification 2(4) Document number Revision 6 1 Printing information The printing is laser etched in a grey color. The printing shall be sharp and well readable and shall withstand wearing. Material can be found in SPACE under 12............ 2 Contents and positioning of laser etch printing 2.1 Contents The label shall have the following content, Position and alignment may vary: RTL type Position Text Align Note Model: SWR10 3,5pt 1278-8125 3 3,5pt Type: RD-0070 3,5pt FCC ID: PY7-RD0070 3,5pt IC: 4170B-RD0070 3,5pt NFC icon height: 3.0mm Isolation zone: 1.5mm Made in China 3,5pt yyWww 3,5pt yy = production year ww = production week BDA: XXXXXXXXXXXX 3,5pt actual unique BT address S/N: YYWWSSPCXXXXXXC 3,5pt Note 1 height:1.045mm width:10.457 mm Japanese Lithium Ion battery statement Size: 1.0x9.5mm , Symbol size: 3.0mm text 3,5pt Japanese TA number and logo Symbol size: 3mm, text 1mm height Company Internal Specification 3(4) Document number Revision 6 height: 5.0mm height: 1.0mm for numbers CE-mark, symbol height 5.0mm N12878 C-tick height: 3.0mm Text height:3,5pt C-tick icon with N12878 number Australian EMC requirement. Ref. doc 1001-5788 C-tick mark height 3.0mm and text height 1.0mm Z354 height:0.9 width:2,26 New Zealand EMC-requirement. Shall be put together with C-tick height:5.0 width:4.5 Recycling WEEE icon ref.doc. 1003-0743 Min size: 5mm height of cross Note1: Serial No according to 4/159 35-LXE 108 179 YYWWSSPCXXXXXXC YY = Year WW = Week of production SS = Supplier/site PC = Production Line/Product Code XXXXXX = Serial value C = Checksum (in two positions) Company Internal Specification 4(4) Document number Revision 6 2.2 Positioning of printing The logotype, text and safety approval symbols mentioned under content shall be placed on the top surface on the module. 3 REVISION INFORMATION Version Date Note 1 2013-12-05 Development revision

No. 2013TAR754 Page49 of 52 ©Copyright. All rights reserved by TMC Beijing. BT Wrist Notifier Disassembly BT Wrist Notifier Disassembly No. 2013TAR754 Page50 of 52 ©Copyright. All rights reserved by TMC Beijing. BT Wrist Notifier Disassembly BT Wrist Notifier Disassembly

No.2013TAR824 Page 1 of 6 ©Copyright. All rights reserved by TMC Beijing. RF Exposure REPORT No. 2013TAR824 for Sony Mobile Communications AB BT Wrist Notifier Type: RD-0070 Model : SWR10 FCC ID: PY7-RD0070 IC ID: 4170B-RD0070 with Hardware Version: AP Software Version: V3.4 Issued Date: 2013-12-23 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No.18A, Kangding Street, Beijing Economical Development Area, Beijing, China 100176 Tel:+86(0)10-67857376, Fax:+86(0)10-67857376 Email:[email protected]. www.emcite.com. No.2013TAR824 Page 2 of 6 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT ..................................................................................... 5 3.3. INTERNAL IDENTIFICATION O F AE ........................................................................................ 5 4. REFERENCE DOCUMENTS ............................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 6 5. RF EXPOSURE LIMIT ....................................................................................................................... 6 No.2013TAR824 Page 3 of 6 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing,P.R.China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304793 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Project Leader: Xue Zhen Testing Start Date: 2013-11-05 Testing End Date: 2013-11-28 1.4. Signature Xue Zhen (Prepared this test report) Song Chongwen (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2013TAR824 Page 4 of 6 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: Sony Mobile Communications AB Address /Post: Mobilvägen, 22188 Lund, Sweden City: Lund Postal Code: 22188 Country: Sweden Contact Person: Nilsson, Mikael Telephone: +46 703 227503 Fax: +46 706 127385 2.2. Manufacturer Information Company Name: Sony Mobile Communications AB Address /Post: Mobilvägen, 22188 Lund, Sweden City: Lund Postal Code: 22188 Country: Sweden Contact Person: Nilsson, Mikael Telephone: +46 703 227503 Fax: +46 706 127385 No.2013TAR824 Page 5 of 6 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description BT Wrist Notifier Type RD-0070 Model SWR10 FCC ID PY7-RD0070 IC ID 4170B-RD0070 Frequency Range ISM 2400MHz~2483.5MHz Type of Modulation GFSK Number of Channels 40 Antenna Integrated Antenna MAX Radiated Power 5.24dBm EIRP MAX Conducted Power 4.79dBm Power Supply 3.7VDC Note1: Photographs of EUT are shown in ANNEX A of this test report. 3.2. Internal Identification of EUT EUT ID* HW Version SW Version N19 AP V0.6 N28 AP V3.4 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE AE ID* Description SN AE1 USB Cable --- *AE ID: is used to identify the test sample in the lab internally. No.2013TAR824 Page 6 of 6 ©Copyright. All rights reserved by TMC Beijing. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version RSS-102 Radio Frequency Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) Issue 4 KDB447498 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies v05r01 5. RF Exposure compliance According to RSS-102 Issue 2, section 2.5 and FCC KDB447498, and the maximum output power listed below, the device is exempt from the routine evaluation and is fulfill RF exposure compliance with FCC and IC requirement. The output power and operating frequency of the device are: Frequency Maximum Output Power Conducted Radiated 2402 ~ 2480MHz 4.79dBm 5.24dBm ***END OF REPORT***

No. 2013TAR754 Page1 of 52 ©Copyright. All rights reserved by TMC Beijing. FCC PART 15C TEST REPORT No. 2013TAR754 for Sony Mobile Communications AB BT Wrist Notifier Type: RD-0070 Model : SWR10 FCC ID: PY7-RD0070 IC ID: 4170B-RD0070 with Hardware Version: AP Software Version: V3.4 Issued Date: 2013-12-24 DAR accreditation (DIN EN ISO/IEC 17025): No. D-PL-12123-01-01 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629B Note:The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No.18A，Kangding Street，Beijing Economical Development Area， Beijing，China 100176 Tel:+86(0)10-67857376, Fax:+86(0)10-67857376 Email:[email protected]. www.emcite.com. No. 2013TAR754 Page2 of 52 ©Copyright. All rights reserved by TMC Beijing. CONTENTS CONTENTS .................................................................................................................................................. 2 1. TEST LABORATORY ......................................................................................................................... 4 1.1. T ESTING LOCATION ......................................................................................................................... 4 1.2. T ESTING ENVIRONMENT .................................................................................................................. 4 1.3. P ROJEC T D ATA ................................................................................................................................. 4 1.4. S IGNATURE ...................................................................................................................................... 4 2. CLIENT INFORMATION ................................................................................................................... 5 2.1. A PPLICANT INFORMATION ............................................................................................................... 5 2.2. M ANUFACTURER INFORMATION ...................................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 6 3.1. A BOUT EUT .................................................................................................................................... 6 3.2. I NTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................... 6 3.3. I NTERNAL IDENTIFICATION OF AE USED DURING THE TEST ............................................................. 6 3.4. G ENERAL DESCRIPTION ................................................................................................................... 7 4. REFERENCE DOCUMENTS ............................................................................................................. 8 4.1. D OCUMENTS SUPPLIED BY APPLICANT ............................................................................................ 8 4.2. R EFERENCE DOCUMENTS FOR TESTING ........................................................................................... 8 5. LABORATORY ENVIRONMENT ..................................................................................................... 9 6. SUMMARY OF TEST RESULT S ..................................................................................................... 10 6.1. S UMMARY OF TEST RESULTS ......................................................................................................... 10 6.2. S TATEMENTS ...................................................................................................................................11 6.3. T EST CONDITIONS ..........................................................................................................................11 7. TEST EQUIPMENTS UTILIZED .................................................................................................... 12 ANNEX A: MEASUREMENT RESULTS ................................................................................................ 13 A.1. MEASUREMENT METHOD .................................................................................................................. 13 A.2. PEAK OUTPUT POWER ....................................................................................................................... 14 A.2.1 Antenna gain ............................................................................................................................... 14 A.2.2 Conducted Output Power ............................................................................................................ 14 A.2.3 Radiated Output Power ............................................................................................................... 14 A.3. FREQUENCY BAND EDGES ................................................................................................................. 15 A.4. CONDUCTED EMISSION ...................................................................................................................... 17 A.5. RADIATED EMISSION .......................................................................................................................... 26 A.6. 6DB BANDWIDTH............................................................................................................................... 34 A.7. MAXIMUM POWER SPECTRAL DENSITY LEVEL ................................................................................. 36 A.8. 20DB BANDWIDTH............................................................................................................................. 38 A.9. AC POWERLINE CONDUCTED EMISSION ............................................................................................…

Text truncated - open the document above for the full version.

No. 2013TAR754 Page45 of 52 ©Copyright. All rights reserved by TMC Beijing. ANNEX B: Photographs of the Test Set-up Photo 1: Photo 2: No. 2013TAR754 Page46 of 52 ©Copyright. All rights reserved by TMC Beijing. Photo 3:
