PY7-RD0090SmartWatch

User guide SmartWatch 3 SWR50 Contents Getting started...............................................................................4 Introduction........................................................................................4 Overview............................................................................................4 Charging............................................................................................4 Turning on and off..............................................................................5 Setting up your SmartWatch 3...........................................................5 Learning the basics........................................................................7 Using the touchscreen.......................................................................7 Dimming and waking up the screen..................................................7 Home screen......................................................................................8 Cards.................................................................................................8 Viewing status icons..........................................................................9 Basic settings...............................................................................10 Accessing settings...........................................................................10 Screen settings................................................................................10 Airplane mode..................................................................................10 Restarting and resetting...................................................................11 Using your SmartWatch 3............................................................12 Staying organised with your SmartWatch 3....................................12 Messaging........................................................................................12 Email................................................................................................12 Handling incoming calls...................................................................13 Navigation........................................................................................13 Viewing your journeys on a map......................................................14 Music...............................................................................................14 Reminders........................................................................................14 Notes................................................................................................14 Agenda.............................................................................................15 Getting quick answers.....................................................................15 Counting steps.................................................................................16 Setting an alarm...............................................................................16 Setting a timer..................................................................................17 Using the stopwatch function..........................................................17 Checking flights or hotel reservations.............................................17 Getting traffic information................................................................17 Tracking packages...........................................................................17 Using your SmartWatch 3 as a standalone device..........................17 Android Wear application.............................................................19 Android Wear on your phone or tablet............................................19 2 This is an Internet version of this publication. © Print only for private use. Selecting applications for voice actions..........................................19 Installing suggested applications.....................................................19 Connecting and reconnecting..........................................................19 Paring with another wearable device...............................................20 Adjusting settings for your SmartWatch 3.......................................20 Android Wear help...........................................................................20 Important information...................................................................21 Using your accessory in wet and dusty conditions.........................21 Legal information.............................................................................22 3 This is an Internet version of this publication. © Print only for private use. Getting started Introduction Your SmartWatch 3 accessory, which is powered by Android Wear, organises your information, suggests what you need, and shows it to you before you even ask. Use it to receive and reply to messages, view appointment notifications, and glance at weather updates – all from the convenience of your wrist. There’s no need to reach for a phone or tablet as long as a Bluetooth ® connection has been established with your SmartWatch 3. Using voice commands, you can ask questions like “When is my next meeting?” or “How do I get to the train station?” and get straight answers. You can also, for example, use the SmartWatch 3 to keep track of your fitness with daily summaries showing your step count. And you can regularly add new apps from Google Play™ to extend functionality. Useful new apps and features are being added all the time as well as updates to existing apps that you’ve installed. You get automatic notifications when such updates are available. The SmartWatch 3 works with any Android™ phone or tablet running Android™ version 4.3 or higher. To see if your Android™ device is compatible for use with Android wear, go to http://g.co/WearCheck. To achieve full functionality and performance, use the wristband together with the main unit of the SmartWatch 3. Overview 1Microp…

Text truncated - open the document above for the full version.

White paper August 2014 SmartWatch 3 SWR50 White paper | SWR50 2August 2014 This document is published by Sony Mobile Communications Inc. without any warranty*. Improvements and changes to this text necessitated by typographical errors, inaccuracies of current information or improvements to programs and/or equipment may be made by Sony Mobile Communications Inc. at any time and without notice. Such changes will, however, be incorporated into new editions of this document. Printed versions are to be regarded as temporary reference copies only. *All implied warranties, including without limitation the implied warranties of merchantability or fitness for a particular purpose, are excluded. In no event shall Sony or its licensors be liable for incidental or consequential damages of any nature, including but not limited to lost profits or commercial loss, arising out of the use of the information in this document. This White paper is published by: Sony Mobile Communications Inc., 1-8-15 Konan, Minato-ku, Tokyo108-0075, Japan www.sonymobile.com © Sony Mobile Communications Inc., 2014. All rights reserved. You are hereby granted a license to download and/or print a copy of this document. Any rights not expressly granted herein are reserved. First released version (August 2014) Publication number: 1291-4834.1 About this document This document contains technical specifications for the Sony SWR50 Smartwatch 3. Document history Sony Mobile Developer World For the latest technical news, tutorials and development tools, go to www.sonymobile.com/developer. Version August 2014First released versionVersion 1 White paper | SWR50 1August 2014 Product overview ........................................................................................................2 SmartWatch 3 SWR50 ...........................................................................................2 Facts – dimensions, weight, performance .............................................................2 Requirements on tablets and smartphones ..........................................................4 Technologies in detail .................................................................................................5 Device-to-device communications (local) .............................................................5 Bluetooth® wireless technology .........................................................................5 Trademarks and acknowledgements .......................................................................6 White paper | SWR50 2August 2014 Product overview SmartWatch 3 SWR50 The SmartWatch 3 SWR50 is both a unique standalone device as well as a companion product that interacts seamlessly with your Android phone or tablet (Android version 4.3 or later) to add new functionality and possibilities. Featuring a screen with a hardened glass surface for maximum scratch resistance and durability, a stainless steel body, and an IP rating of 68, the SmartWatch 3 is built to take whatever daily life throws at it. But behind the sleek design, there’s so much more. The SmartWatch 3 has a 1.6-inch transflective TFT LCD display, securing visibility in sunlit conditions while also offering great image quality with rich colours. A highly responsive capacitive touch system supports an easy-to-use interface. And, then, there are the apps – hundreds of applications are available for your SmartWatch 3 via the Google Play™* store, and new ones are becoming available all the time. So you can find new ways to use your device every day. * This service is not available in all markets. Facts – dimensions, weight, performance Processor 1.2 GHz, Quad-core ARM ® Cortex TM A7 Size (module)36 x 10 x 51 mm Weight Watch module38 grams Classic wristband38 grams Sport armband35.7 grams Available coloursBlack, White (classic wristband version) Pink, Lime (sport armband version) Display Colours16 bit Resolution320x320 pixels Size (diagonal)1.6 inch Type of displayTransflective TFT LCD To u c hCapacitive KeysPower key (On/Off) VibratorYes White paper | SWR50 3August 2014 * In compliance with IP68, this accessory is protected against the ingress of dust and is waterproof. Provided that all ports and covers are firmly closed, the accessory can be kept under 1.50 metres of freshwater for up to 30 minutes in compliance with IP68. Memory Flash4GB eMMC RAM512MB Sensors Ambient light sensorYes AccelerometerYes MagnetometerYes GyroYes Wi-Fi ® Wi-Fi ® enabled GPSYes Bluetooth Bluetooth specification4.0 Transfer rate< 3Mbps Power classClass 1 NFCYes, to power on the SWR50 and start the Android Wear host application USBYes, standard micro USB for charging and ADB installation Battery TypeLi-polymer Capacity420 mAh Charge time≤ 1 hour Usage time Typical usageUp to 2 days Standby timeUp to 4 days Environmental data Operating temperature range-20°C to +60°C Operating humidity range5% to 99% RH Storage temperature range-40°C to +85°C Storage humidity range20% to 95% RH Charging temperature range0°C to 45°C Water and dust classificationIP68* White paper | SWR50 4August 2014 Find out more at www.sonymobile.com/testresults Requirements on tablets and smartphones Operating system compatibility Android version 4.3 and later BluetoothVersion 4.0 White paper | SWR50 5August 2014 Technologies in detail NOTE: The information outlined below is general and levels of compliance to standards and specifications may vary between products and markets. For more information, contact Sony Mobile Developer World or your Sony contact person where applicable. Device-to-device communications (local) Bluetooth ® wireless technology More information: www.sonymobile.com/developer www.bluetooth.com Bluetooth ® profiles supported Advanced Audio Distribution Profile v1.2 Audio/Video Remote Control Profile v1.4 Core version and supported core features Version 4.0 Connectable devices Products which support at least one of the Bluetooth ® profiles listed above. White paper | SWR50 6August 2014 Tra…

Text truncated - open the document above for the full version.

May 21, 2010 17:08:55 April 1, 2010 16:06:29 ᆶ࡞ᆶ۾࿿ዊຫ௽ ג೼ᐌՓ⫼ᴵӊϟˈ៥Ӏⱘ⦃ֱՓ⫼ᳳ䰤ᰃ ᑈDŽ ᆶ۾ᆶ࡞࿿ዊईᇮ໎ 䚼ӊ ৡ鹵 䪙 (Pb) ∲ (Hg) 䬝 (Cd) Ӌ䫀݁ (Cr6+) ໮1. 㘨㣃 (PBB) ໮1. Ѡ㣃䝮 (PBDE) 䜡ӊ XOOOOO ⬉఼ܙ ˄བ䳔㽕˅ X O OOOO O: 㸼冫䆹᳝↦᳝ᆇ⠽䋼೼䚼ӊ᠔᳝ഛ䋼ᴤ᭭Ёⱘ৿䞣ഛ೼ SJ/T 11363-2006㾘ᅮⱘ䰤䞣㽕∖ҹϟDŽ X:㸼冫䆹᳝↦᳝ᆇ⠽䋼㟇ᇥ೼䆹䚼ӊⱘᶤϔഛ䋼ᴤ᭭Ё ⱘ৿䞣䍙ߎ SJ/T 11363-2006㾘ᅮⱘ䰤䞣㽕∖DŽ˄ᠧ ĀXāⱘᡔᴃॳ಴ᰃ಴ЎⳂࠡЎב≵᳝ৃ᳓ᤶᡔᴃDŽ˅ 10 www.sonymobile.com Sony Mobile Communications I nc. 1-8-15 Konan, Minato-ku, Tokyo 108-0075, Japan Declaration of Conformity for We, Sony Mobile Communications AB of Nya Vattentornet SE-221 88 Lund, Sweden declare under our sole responsibility that our product Sony type RD-0090 and in combination with our accessories, to which this declaration relates is in conformity with the appropriate standards EN 300 328:V1.8.1, EN 301 489-17:V2.2.1, EN 301 489-3:V1.6.1, EN 302 291-2:V1.1.1, EN 300 440-2:V1.4.1, EN 62209-2:2010 and EN 60 950-1:2006 +A11:2009+A1:2010+A12:2011 following the provisions of, Radio Equipment and Telecommunication Terminal Equipment directive 1999/5/EC. Lund, July 2014 Pär Thuresson, Quality Officer, SVP, Quality & Customer Services SWR50 ?? 21, 2014 09:12:28?? 1, 2014 11:40:00 1288-9855.3 ?? 11, 2014 17:03:21 FCC ID:XXX-XXXXXX XXXXXXXXXXXXX-XX-XXX:XDCC IDCFC ?? 24, 2014 15:31:38 Regulatory leaflet 1288-9855.3.pdf 1 of 2 FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Any change or modification not expressly approved by Sony may void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of th e FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can b e determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Industry Canada Statement This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Avis d’industrie Canada Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et, and (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. AVISO IMPORTANTE PARA MÉXICO La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada. Para consultar la información relacionada al número del certificado, refiérase a la etiqueta del empaque y/o del producto. Alimentación: 5,0 Vcc SWR50 기자재의명칭(모델명):특정소출력무선기기 (무선데이터통신 시스템용 무선기기)(SWR50) 제품 명칭: 이동형 통신기기 적합성 평가 받은 자의 상호: 소니코리아(주) 제조년월: 별도 표기 제조자/제조국가: Sony Mobile Communications Inc. / China 고객센터: 1588-0911 인증번호 : MSIP-CMI-SOK-SWR50 - 해당 무선설비는 운용 중 혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없음 - 이 기기는 가정용(B급) 전자파 적합기기로서 주로 가정에서 사용하는 것을 목적으로 하며, 모든 지역에서 사용 할 수 있습니다. ?? 21, 2014 09:12:28?? 1, 2014 11:40:00?? 11, 2014 17:03:21?? 24, 2014 15:31:38 Regulatory leaflet 1288-9855.3.pdf 2 of 2

SAR Information Declaration of Conformity Sony SWR50 Exposure to radio waves (SAR) When your device, the Wi-Fi hotspot functionality or the Bluetooth hands free functionality is turned on, it emits low levels of radio frequency energy (radio waves). The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate, or SAR. This device meets the international SAR limit guidelines and your device ́s SAR values are below these limits. The Specific Absorption Rate for your device is 0.86 W/kg averaged over 10g when worn on your wrist. SAR data information is provided for residents in countries that have adopted the SAR limit recommended by the International Commission of Non-Ionizing Radiation Protection (ICNIRP), which is 2 W/kg averaged over ten (10) gram of body tissue or recommended by the Institute of Electrical and Electronics Engineers (IEEE), which is 1.6 W/kg averaged over one (1) gram of body tissue. Products used on limbs has a international limit based on ICNIRP recommendations at 4 W/kg averaged over ten (10) gram of body tissue. These requirements are based on scientific guidelines that include safety margins designed to assure the safety of all persons, regardless of age and health. Tests for SAR are conducted using standardized methods with the device tra nsmitting at its highest certified power level in all used frequency bands, but because the device is designed to use the minimum power necessary to access the chosen network, the actual SAR level can be well below this value. While there may be differences between the SAR levels of various device models, they are all designed to meet the relevant guidelines for exposure to radio waves. Your device is used worn on your wrist and has been tested when positioned at 0 mm from the body without any metal parts in the vicinity of clock or when properly used with an appropriate accessory and worn on the wrist. The WHO (World Health Organization) has stated that current scientific information does not indicate the need for special precautions for the use of clocks. For more information about this topic, please refer to the WHO document (Memo No. 193, Electromagnetic Fields and Public Health, Mobile phones and their base stations), available at: http://who.int/emf . For further regional specific information about exposure to radio waves (SAR), ple ase find your region: 2 Canada, Guam, Puerto Rico, USA & Virgin Islands (C A, GU, PR, US, VI) **Before a device is available for sale to the public in the US, it must be tested and certified by the Federal Communications Commission (FCC) that it does not exceed the limit established by the government-adopted requirement for safe exposure*. The tests are performed in positions and locations (i.e., by the ear wrist and worn on the body) as required by the FCC for each model. The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR levels of various devices, all devices granted an FCC equipment authorization meet the government requirement for safe exposure. SAR information on this device is on file at the FCC and can be found under the Display Grant section of http://transition.fcc.gov/oet/ea/fccid/ after searching on the FCC ID PY7–RD0090 for your device. Additional information on SAR can be found on the Mobile Manufacturers Forum EMF website at http://emfexplained.info/. ** This paragraph is only applicable to authorities and customers in the United States. For more information about SAR and radio frequency exposure, go to: http://blogs.sonymobile.com/about-us/sustainability/health-and- safety/sar/ . Rest of the world (RoW) For more information about SAR and radio frequency exposure in China Mainland, go to: http://sonymobile.com/cn. For more information about SAR and radio frequency exposure, go to: http://blogs.sonymobile.com/about-us/sustainability/health-and- safety/sar/ . 3 Declaration of Conformity We, Sony Mob ile Communications AB of Nya Vattentornet SE-221 88 Lund, Sweden declare under our sole responsibility that our product Sony type RD-0090 and in combination with our accessories, to which this declaration relates is in conformity with the appropriate standards EN 300 328:V1.8.1, EN 301 489-17:V2.2.1, EN 301 489-3:V1.6.1, EN 302 291-2:V1.1.1, EN 300 440-2:V1.4.1, EN 62209-2:2010 and EN 60 950-1:2006 +A11:2009+A1:2010+A12:2011 following the provisions of, Radio Equipment and Telecommunication Terminal Equipment directive 1999/5/EC. Lund, July 2014 Pär Thuresson, Quality Officer, CVP, Quality & Customer Services We fulfil the requirements of the R&TTE Directive (1999/5/EC). إننا نحترم مقتضيات التوجيهات R&TTE(1999/5/EC). Biz R&TTE Təlimatlarının tələblərini yerinə yetiririk (1 9 9 9 / 5 / E C) . Ние изпълняваме изискванията на Директивата R&TTE (1999/5/EC). Mi ispunja vamo zahtjeve R&TTE Direktive (1 9 9 9 / 5 / E C) . C o m p l i m e l s requisits de la directiva R&TTE ( 1 9 9 9 / 5 / E C ). V ý r o b e k s p lňuje požadavky směrnice R&TTE (1 9 9 9 / 5 / E C) . V i o p f y l d e r kravene i R&TTE-direktivet (1 9 9 9 / 5 / E C) . D i e A n f o r d e rungen der Richtlinie für Funk- und Fernmeldegeräte ( 1 9 9 9 / 5 / E G ) w e r d e n e r füllt. Πληρούμε τις απαιτήσεις της Οδηγίας R&TTE (1999/5/ΕΚ). Cumplimos los requisitos de la Directiva R&TTE (1999/5/EC). Vastab dir ektiivi R&TTE Directive ( 1 9 9 9 / 5 / E C ) nõu e t e l e . R & T TE ( 1999/5/EC) a r t e z t a r a u a r e n b a l dintzak betetzen ditugu. ما مقررات R&TTE را به طور کامل طبق دستورالعمل )1999/5/EC( انجام داده ايم. Täytämme radio - ja telepäätelaitedirektiivin (1999/5/EY) asettamat vaatimukset. Ce produit est conforme à la directive R&TTE (1999/5/EC). Sony cumpr e cos requisitos esixidos pola directiva R&TTE ( 1 9 9 9 / 5 / E C ). M u n c i k a s haraɗin bayanin R&TTE (99/5/EC). Mi ispunjavamo zahtjeve R&TTE Direktive ( 1 9 9 9 / 5 / E C…

Text truncated - open the document above for the full version.

Sony Mobile Communications Prepared by SEM/CGQTAC RAZVAN BUJILA Contents responsible if other than preparer Approved by SEM/CGQTAC (RAZVAN BUJILA) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard Telecommunication Certification Body CETECOM GmbH Im Teelbruch 116 45219 Essen Germany Confidentiality request letter Confidentiality request letter Confidentiality request letter Confidentiality request letter Subject: Certification Application FCC ID: PY7-RD0090 It is requested that the following information is to be held confidential on behalf Communications Inc. pursuant to FCC Rules Parts 0.457 and 0.459: • Block Diagrams • Schematics • Parts List • Operation Description These items contain detailed system and equipment description and related information about the product which Sony Mobile Communications Inc. and a custom design which otherwise would not be design is a basis from which future technological products will evolv Communications Inc. also feels that this information would be of benefit to its competitors, and that the disclosure of the infor advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Yours sincerely Yusheng Wu Manager Sony Mobile Communications Tel: +86 10 80481188 x 68165 No.16, Guangshun South street, Chaoyang District, Beijing [email protected] Confidential LETTER Document number 397/0061-LXE 110 0790 Uen Date 2014-08-06 Remarks This document is managed in metaDoc. It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Telecommunication Certification Body CETECOM GmbH Im Teelbruch 116 Confidentiality request letter Confidentiality request letter Confidentiality request letter Confidentiality request letter - -- - PY7 PY7PY7 PY7 Certification Application It is requested that the following information is to be held confidential on behalf pursuant to FCC Rules Parts 0.457 and 0.459: Block Diagrams Operation Description These items contain detailed system and equipment description and related information about ch Sony Mobile Communications Inc. considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Mobile also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an advantage in the market. Please contact the undersigned if there are any further questions or additional information Sony Mobile Communications China 68165 No.16, Guangshun South street, Chaoyang District, Beijing @sonymobile.com 1(1) Revision B This document is managed in metaDoc. copy is invalid and must be removed from possible use. PY7 PY7PY7 PY7- -- -RD0090 RD0090RD0090 RD0090 It is requested that the following information is to be held confidential on behalf of Sony Mobile pursuant to FCC Rules Parts 0.457 and 0.459: These items contain detailed system and equipment description and related information about considers to be proprietary, confidential released to the general public. Since this e, Sony Mobile also feels that this information would be of benefit to its competitors, and mation in these exhibits would give our competitors an unfair Please contact the undersigned if there are any further questions or additional information

Confidential SPECIFICATION 1(7) Document number Revision 1284-6529 C Prepared by Date HW PM Daniel Flinck and Carl Fredrik Leanderson 2014-09-10 Contents responsible if other than preparer Remarks This document is handled in SPACE Approved by HW PM Carl Fredrik Leanderson Type number: RD-0090 FCC id: PY7-RD0090 IC id: 4170B-RD0090 SWR50 Product Label Specification Contents 1 Printing information............................................................................ 2 2 Cutting and Fitting information ........................................................... 2 3 Contents and positioning of laser etch printing .................................. 2 3.1 Contents ............................................................................................ 2 3.2 Positioning of printing ........................................................................ 4 4 REVISION INFORMATION ............................................................... 7 Abstract This document describes the label printing for Brooks core unit 1286-3328. Confidential SPECIFICATION 2(7) Document number Revision 1284-6529 4 1 Printing information The printing is pre-printed, with serial number and MAC address information only laser etched during production. Preferably, the text shall be gray on black background or black default label color, if possible. The contrast between the label and the font shall be less than it is today, in SP build. The printing shall be sharp and well readable and shall withstand wearing. The background (label for etching) shall mimic the plastic material surface where it is attached as close as possible. Material can be found in SOMC SPACE system, under reference nr 1284-6529. 2 Cutting and Fitting information The label shall be well attached and properly fitted to the plastic carrier of the watch and self destructing upon removal attempt, i.e., break up in parts. The label edges shall be cut in a distinct way. The label shall not be visible from beneath, e.g., through the cut in the wristband. 3 Contents and positioning of laser etch printing 3.1 Contents The label shall have the following content, Position and alignment is described in Section 3. Position Text Align Note Hidden Model: SWR50 3,5pt Product model name Hidden 1286-3328.1 3,5pt SPACE-number for the core unit Backside Type: RD-0090 3,5pt Backside FCC ID: PY7-RD0090 3,5pt Backside IC: 4170B-RD0090 3,5pt Display protective tape NFC icon height: 3.0mm Isolation zone: 1.5mm Shall be positioned where the antenna is directed Hidden Made in China 3,5pt Hidden (next to WEEE dustbin) yyWww 3,5pt yy = production year ww = production week Hidden BDA: XXXXXXXXXXXX 3,5pt actual unique BT Confidential SPECIFICATION 3(7) Document number Revision 1284-6529 4 address Hidden S/N: YYWWSSPCXXXXXXC 3,5pt *Note 2 Hidden 3,5pt Japanese Lithium Ion battery statement Size: 1.0 x 9.5mm Hidden Symbol size: 3.0mm text 3,5pt Japanese TA number and logo Hidden height: 5.0mm height: 1.0mm for numbers CE-mark, symbol height 5.0mm Hidden (next to yyWww) height:5.0 Recycling WEEE icon ref.doc. 1003-0743 Min size: 5mm height of cross Note1: Stylish Sony logo is already debossed in backside mechanics Note2: Serial No according to 4/159 35-LXE 108 179 YYWWSSPCXXXXXXC YY = Year WW = Week of production SS = Supplier/site PC = Production Line/Product Code XXXXXX = Serial value C = Checksum (in two positions) Confidential SPECIFICATION 4(7) Document number Revision 1284-6529 4 3.2 Positioning of printing All product information shall be fitted in two labels, one large and one small, in the hidden areas underneath the watchband strap. 3.2.1 Backside information Only the SONY logo shall be visible on the metal backcover. 3.2.2 Hidden areas information There are two hidden areas underneath the watchband on each side of the display on the core unit. The disposition of the text and the dimension of the l…

Text truncated - open the document above for the full version.
