PY71130202Licensed portable

ContentsGetting started 3Make and receive the first call.Getting to know your phone 6Key functions, quick keys, entering letters.Personalizing your phone 15Choose ring signal, theme and other settings.Calling 24Use the phone book, voice control, call options.Setting up mobile Internet 43Set up WAP and e-mail.Messaging 49Chat, e-mail, text and multimedia messages.Using mobile Internet 57WAP browser, bookmarks. Transferring and exchanging information 61Bluetooth wireless technology, synchronization. More features 67Calendar, alarm clock, stopwatch, timer, games.Security 75SIM card lock, phone lock.Troubleshooting 77Why doesn’t the phone work the way I want?Additional information 79Safe and efficient use, warranty, declaration of conformity.Icons 88What do the icons mean?Index 93 Sony EricssonFirst edition (November 2001)This manual is published by Sony Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this manual.All rights reserved.© Sony Ericsson Mobile Communications AB, 2001 Publication number: EN/LZT 108 5405 R1APlease note:Some of the services in this manual are not supported by all networks. This also applies to the GSM International Emergency Number 112 . Please contact your network operator or service provider if you are in doubt whether you can use a particular service or not.Please read the Guidelines for safe and efficient use and the Limited warranty chapters before you use your mobile phone.The BLUETOOTH trademarks are owned by Bluetooth SIG, Inc.T9™ Text Input is a registered trademark of Tegic Communications.T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057, United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide. Getting started 3 Getting startedAbout this user’s guideFor ease of reference, the “Getting to know your phone” chapter gives a quick overview of the main functions of the phone, shortcuts and general information.Available servicesSome services and functions described in this user’s guide are network- or subscription-dependent. Because of this, all menus may not be available in your phone. This symbol indicates that a service or function is network- or subscription-dependent. Please consult your network operator for more information about your subscription.The SIM cardWhen you register as a subscriber with a network operator, you get a SIM (Subscriber Identity Module) card. The SIM card contains a computer chip that keeps track of your phone number, the services included in your subscription, and your phone book information, among other things. AssemblyBefore you can use your phone you need to: • insert the SIM card.• attach and charge the battery. See “SIM card and battery information” on page 4.Note: Always turn off the phone and detach the charger before you insert or remove a SIM card. 4 Getting started SIM card and battery informationIt may take up to 30 minutes before an icon appears in the display when charging. 1. Insert the SIM card. Make sure the SIM card is placed under the silvery holders. 2. Place the battery on the back of the phone and push until you hear a click. 3. Connect the charger to the phone at the flash symbol. The flash symbol on the charger plug must face upwards. 4. It may take up to 30 minutes before the battery charging icon appears in the display. 5. Wait approximately 4 hours or until the icon indicates that the battery is fully charged. If you do not see the battery icon after this time, press any key or the joystick to activate the display. 6. Remove the charger by tilting the plug upwards. You have to insert the SIM card and charge the battery before you can use the phone. Getting started 5 Making and receiving callsTo turn on the phone • Press and hold NO until you hear a tone. • Enter your PIN (Personal Identity Number), if you have one for your SIM card.Your PIN is provided by your network operator. If you make a mistake while entering your PIN, delete the wrong number by pressing . If you enter the wrong PIN three times in a row, the SIM card is blocked and the message PIN blocked appears. To unblock it, you need to enter your PUK (Personal Unblocking Key). Your PUK is provided by your network operator.To make and receive calls • Enter the area code and phone number, and press YES to make the call . • Press NO to end the call. • When the phone rings, press YES to answer the call. 6 Getting to know your phone Getting to know your phoneKey functions Vo l u m e key Increase or decrease the volume of the earpiece during a call. Scroll through menus, lists and text. Enter the Status menu in standby. Slide up or down twice to reject an incoming call. Slide up or down once to turn off the ring signal when receiving a call.Make and answer calls. Select a menu, submenu or an option.Press for options. 1–9, 0 Enter the digits 0–9 and letters. Press and hold to enter the international prefix +. Move through menus using shortcuts.Enter *. Shift between lower and upper case. Press the joystick up, down, left or right to move through the menus, lists and texts. Press the joystick as an alternative to . Press and hold to turn the phone on or off or to go back to standby mode. Press to end or reject a call, go back one level in the menus or leave an option unchanged. (clear) Delete numbers and letters from the display. Delete an item from a list. Press and hold to turn off the microphone during a call.Enter #. Getting to know your phone 7 Quick k…

Text truncated - open the document above for the full version.

ContentsGetting started 3Make and receive the first call.Getting to know your phone 6Key functions, quick keys, entering letters.Personalizing your phone 15Choose ring signal, theme and other settings.Calling 24Use the phone book, voice control, call options.Setting up mobile Internet 43Set up WAP and e-mail.Messaging 49Chat, e-mail, text and multimedia messages.Using mobile Internet 57WAP browser, bookmarks. Transferring and exchanging information 61Bluetooth wireless technology, synchronization. More features 67Calendar, alarm clock, stopwatch, timer, games.Security 75SIM card lock, phone lock.Troubleshooting 76Why doesn’t the phone work the way I want?Additional information 78Safe and efficient use, warranty, declaration of conformity.Icons 87What do the icons mean? Sony EricssonFirst edition (November 2001)This manual is published by Sony Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this manual.All rights reserved.© Sony Ericsson Mobile Communications AB, 2001 Publication number: EN/LZT 108 5405 R1APlease note:Some of the services in this manual are not supported by all networks. This also applies to the GSM International Emergency Number 112 . Please contact your network operator or service provider if you are in doubt whether you can use a particular service or not.Please read the Guidelines for safe and efficient use and the Limited warranty chapters before you use your mobile phone.The BLUETOOTH trademarks are owned by Bluetooth SIG, Inc.T9™ Text Input is a registered trademark of Tegic Communications.T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057, United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide. Getting started 3 Getting startedAbout this user’s guideFor ease of reference, the “Getting to know your phone” chapter gives a quick overview of the main functions of the phone, shortcuts and general information.Available servicesSome services and functions described in this user’s guide are network- or subscription-dependent. Because of this, all menus may not be available in your phone. This symbol indicates that a service or function is network- or subscription-dependent. Please consult your network operator for more information about your subscription.The SIM cardWhen you register as a subscriber with a network operator, you get a SIM (Subscriber Identity Module) card. The SIM card contains a computer chip that keeps track of your phone number, the services included in your subscription, and your phone book information, among other things. AssemblyBefore you can use your phone you need to: • insert the SIM card.• attach and charge the battery. See “SIM card and battery information” on page 4.Note: Always turn off the phone and detach the charger before you insert or remove a SIM card. 4 Getting started SIM card and battery informationIt may take up to 30 minutes before an icon appears in the display when charging. 1. Insert the SIM card. Make sure the SIM card is placed under the silvery holders. 2. Place the battery on the back of the phone and push until you hear a click. 3. Connect the charger to the phone at the flash symbol. The flash symbol on the charger plug must face upwards. 4. It may take up to 30 minutes before the battery charging icon appears in the display. 5. Wait approximately 4 hours or until the icon indicates that the battery is fully charged. If you do not see the battery icon after this time, press any key or the joystick to activate the display. 6. Remove the charger by tilting the plug upwards. You have to insert the SIM card and charge the battery before you can use the phone. 30 min. 4 h . Getting started 5 Making and receiving callsTo turn on the phone • Press and hold NO until you hear a tone. • Enter your PIN (Personal Identity Number), if you have one for your SIM card.Your PIN is provided by your network operator. If you make a mistake while entering your PIN, delete the wrong number by pressing . If you enter the wrong PIN three times in a row, the SIM card is blocked and the message PIN blocked appears. To unblock it, you need to enter your PUK (Personal Unblocking Key). Your PUK is provided by your network operator.To make and receive calls • Enter the area code and phone number, and press YES to make the call . • Press NO to end the call. • When the phone rings, press YES to answer the call. On/off My Network 12:18 6 Getting to know your phone Getting to know your phoneKey functions Vo l u m e key Increase or decrease the volume of the earpiece during a call. Scroll through menus, lists and text. Enter the Status menu in standby. Slide up or down twice to reject an incoming call. Slide up or down once to turn off the ring signal when receiving a call.Make and answer calls. Select a menu, submenu or an option.Press for options. 1–9, 0 Enter the digits 0–9 and letters. Press and hold to enter the international prefix +. Move through menus using shortcuts.Enter *. Shift between lower and upper case. Press the joystick up, down, left or right to move through the menus, lists and texts. Press the joystick as an alternative to . Press and hold to turn the phone on or off or to go back to standby mode. Press to end or reject a call, go back one level in the menus or leave an option unchanged. (clear) Delete numbers and letters from the display. Delete an item from a list. Press and hold to turn off the microphone during a call.Enter #. Gettin…

Text truncated - open the document above for the full version.

1 (1) Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other)Nr - No. LD/ECS/GUG/NV Anders NordlöfGT/NTV-01:368 Dokansv/Godk - Doc respons/ApprovedKontr – CheckedDatum – Date RevFile LD/ECS/GUG/NV01-12-07A COMPARISON 1130201-BV AND 1130202-BV The purpose of this document is to define the differences between the 1130201-BV and 1130202-BV. Differences. Marking drawing. 1130201-BV T68 FCC ID: PBY1130201 1130202-BV T68i FCC ID: PY71130202 Hardware. Mechanics: The differences between the models are that 1130202-BV will have a new front and rear cover. MS type 1130202-BV, T68i, will use a different keypad back light illumination. Antenna: Same antenna on both models. Software. There will be different version used in MS types 1130202-BV, T68i, then 1130201- BV, T68: MS typeSW ModuleMS VersionTAE version 1130201-BVCRH1069083CXC125398CXC125418_TAE 1130202-BVCRH1069083CXC125265CXC125326_TAE Summery The MS type 1130202-BV is electrically identical to 1130201-BV 2 (1) Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other)Nr - No. LD/ECS/GUG/NV Anders NordlöfGT/NTV-01:368 Dokansv/Godk - Doc respons/ApprovedKontr – CheckedDatum – Date RevFile LD/ECS/GUG/NV01-12-07A Photo comparison Appendix 1: Photos of MS type 1130201-BV (front and back). Appendix 2: Photo of MS type 1130202-BV (front and back).

Application PY7 1130202 January 22 nd , 2002 Federal Communications Commission Equipment Authorization Division, Application Processing Branch, 7435 Oakland Mills Road, Columbia, MD 21048 Subject: Request for Deferring the Grant to March 8 th 2002 To whom it may concern: On behalf of our customer Sony Ericsson Mobile Communications AB we kindly ask you to change the date of deferral of the grant to the date 8 th of March 2002. Thank you for your understanding and anticipated cooperation. We are very much looking forward to working with you on this project. Yours sincerely, Karin Silberhorn Project Engineer CETECOM GmbH Im Teelbruch 122 45219 Essen, Germany

CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 25 (33) Photographs of the equipment Photograph no.: 1 CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 26 (33) Photographs of the equipment Photograph no.: 2 CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 27 (33) Photographs of the equipment Photograph no.: 3 CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 28 (33) Photographs of the equipment Photograph no.: 4 CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 29 (33) Photographs of the equipment Photograph no.: 5

Application PY7 1130202 EXHIBIT 1: FCC ID Label & Location Info APPLICANT: FCC ID No.: Sony Ericsson Mobile Communications AB PY7 1130202 Close Up View of the Label:

CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 30 (33) Photographs of the equipment Photograph no.: 6 CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 31 (33) Photographs of the equipment Photograph no.: 7 CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 32 (33) Photographs of the equipment Photograph no.: 8 CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 33 (33) Photographs of the equipment Photograph no.: 9

Confidential REPORT 1 (16) Prepared (also subject responsible if other)No. LD/ECS/GUF/KG Ramadan Plicanic GTX/FG 01:086 ApprovedCheckedDateRevFile GUF/KG Ramadan PlicanicECSRAPL2001-12-03A H:\RR\SAR_FCC Report\T68i.doc EN SAR Test Report: T68i (PY71130202) Date of test: November 30 , 2001 Laboratory: Electromagnetic Near Field and Radio Frequency Dosimetry Laboratory Sony Ericsson Mobile Communications AB Nya Vattentornet, SE-221 83 LUND, Sweden Test Responsible: Ramadan Plicanic, M.Sc.EE Senior Staff Engineer, Terminal Antennas [email protected] +46 46 19 38 62 Statement of Compliance Sony Ericsson Mobile Communications AB declares under its sole responsibility that the that the product Ericsson Type 1130202-BV (T68i); FCC ID: PY 71130202 to which this declaration relates, is in conformity with the appropriate RF exposure standards, recommendations and guidelines. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) © Sony Ericsson Mobile Communications AB, 2001 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Sony Ericsson encourages all feedback, both positive and negative, on this test report. Confidential REPORT 2 (16) Prepared (also subject responsible if other)No. LD/ECS/GUF/KG Ramadan Plicanic GTX/FG 01:086 ApprovedCheckedDateRevFile GUF/KG Ramadan PlicanicECSRAPL2001-12-03A H:\RR\SAR_FCC Report\T68i.doc EN Table of Contents 1. Introduction3 2. Device Under Test3 2.1Antenna description3 2.2Device description3 3. Test equipment3 3.1 Dosimetric system3 3.2Additional equipment3 4. Electrical parameters of the tissue simulating liquid4 5. System accuracy verification4 6. Test results5 References6 Appendix 1: SAR distribution comparison for system accuracy verification7 Appendix 2: SAR distribution plots9 Appendix 3: Photographs of the device under test12 Appendix 4: Position of device on Generic Twin Phantom14 Appendix 5: Probe calibration parameters for ET3DV6 SN:156916 Confidential REPORT 3 (16) Prepared (also subject responsible if other)No. LD/ECS/GUF/KG Ramadan Plicanic GTX/FG 01:086 ApprovedCheckedDateRevFile GUF/KG Ramadan PlicanicECSRAPL2001-12-03A H:\RR\SAR_FCC Report\T68i.doc EN 1. Introduction In this test report, compliance of the Ericsson T68i portable telephone with RF safety guidelines is demonstrated. The applicable RF safety guidelines and the SAR measurement specifications used for the test are described in the SAR Measurement Specification of Wireless Handsets [1]. 2. Device Under Test 2.1 Antenna description Type Internal antenna Location Inside the back cover, near the top Max length22mm Dimensions Max width35mm Configuration PIFA 2.1 Device description Device model T68i Serial numberA6101T53PA Mode 1900 TDMA Multiple Access Scheme TDMA Maximum Output Power Setting 1 29.0 dBm Factory Tolerance in Power Setting ± 0.5dB Maximum Peak Output Power 2 29.5 dBm Duty Cycle1 / 8 Transmitting Frequency Range1850 – 1910 MHz Prototype or Production Unit Prototype Device Category Portable RF exposure environment[2] General population / uncontrolled 3. Test equipment 3.1 Dosimetric system SAR measurements were made using the DASY3 professional system (software version 3.1c) with a SAM twin phantom, manufactured by Schmid & Partner Engineering AG (SPEAG). The extended SAR assessment uncertainty (K = 2) is ±24% [1]. The list of calibrated equipment is given below. DescriptionSerial NumberDue Date DASY3 DAE V2 2155/02 E-field probe ETDV615695/02 Dipole Validation Kit, D1900V25105/03 1 This is the conducted power measured at the antenna port when the device is set to its highest power setting. It is measured at the middle of the transmit frequency band. Note that the output power may be different at other frequencies. 2 This equals the maximum output power setting plus the factory tolerance. Confidential REPORT 4 (16) Prepared (also subject responsible if other)No. LD/ECS/GUF/KG Ramadan Plicanic GTX/FG 01:086 ApprovedCheckedDateRevFile GUF/KG Ramadan PlicanicECSRAPL2001-12-03A H:\RR\SAR_FCC Report\T68i.doc EN 3.2 Additional equipment DescriptionSerial NumberDue Date Signal Generator ESG-D4000A INV 5629354/02 Dielectric probe kit HP 85070B INV 4430297/02 Network analyzer HP 8753CINV 4216706/02 Power meter R&S NRVDINV 48392012/01 Power sensor R&S NRV-Z5INV 233412/01 Wavetek 4106GPPINV 4629917/02 4. Electrical parameters of the tissue simulating liquid Prior to conducting SAR measurements, the relative permittivity, ε r , and the conductivity, σ, of the tissue simulating liquids were measured with the dielectric probe kit. These values are shown in the table below. The mass density, ρ, entered into the DASY3 program is also given. Recommended limits for maximum permittivity, minimum conductivity and maximum mass density are also shown. Dielectric Parameters f (MHz) Tissue type Limits / Measured ε r σ (S/m)ρ (g/cm 3 ) Measured, 11/30/01 39.2 1.41.00Head Recommended40.01.41.03 Measured, 11/30/0139.21.41.00 1900 Muscle Recommended53.31.521.04 5. System accuracy verification A system accuracy verification of the DASY3 was performed using the dipole validation kit listed in Section 3.1. The system verification test was conducted on the same day as the measurement of the DUT. Measurement made in ambient temperature 22.7 °C, liquids temperature 21.8 °C and humidity 40.2%. The obtained results are displayed in the table below. It is seen that the system is operating within its specification, as the results are within ±10% of the reference values. At 1900 MHz, reference values are provided by the manufacturer. The distributions of SAR compare well with…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Radio Satelite Communication Untertürkheimer Straße 6-10 . D-66117 SaarbrückenTelefon: +49 (0)681 598-9100Telefax: -9075 RSC11issue test report consist of 33 PagesPage 1 (33) BLUETOOTH TM is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM TTI-P-G-166/98-30 Accredited Bluetooth Test Facility (BQTF) Test report no.: 2_2746-01-01/01 FCC Part 24 1130202-BV/CN FCC-ID: PY71130202 CETECOM – ICT Services GmbH Untertürkheimerstr. 6-10 66117 Saarbrücken, Germany Telephone: + 49 (0) 681 / 598-0 Fax: + 49 (0) 681 / 9075 CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 2 (33) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test report 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. 1.2Testing laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telefone: + 49 681 598 - 9100 Telefax : + 49 681 598 - 9075 E-mail : [email protected] Internet : www.cetecom.de Accredited testing laboratory DAR-registration number : TTI-P-G-166/98-30 Accredited Bluetooth TM Test Facility (BQTF) BLUETOOTH TM is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 3 (33) 1.3Details of applicant Name : Sony Ericsson Mobile Communications AB Street : Nya Vattentornet City : S-22188 Lund Country : Sweden Telephone : +46 46 193 242 Telefax : +46 46 193 295 Contact : Mr. Bo Johansson Telephone : +46 46 193 242 1.4Application details Date of receipt of application : 03.12.2001 Date of receipt of test item : 04.12.2001 Date of test : 05.12.2001 1.5Test item Type of equipment : GSM Tri Band Mobile Phone with integrated BLUETOOTH module Type designation: Type: 1130202-BV/CN Manufacturer:Applicant Street: City: Country: Serial number:004601-01-293475-7-01 Additional informations: : Frequency:GSM 1900 :1850 – 1910 MHz and Bluetooth 2402 – 2480 MHz Type of modulation:GSM 1900 : 300KF2D Bluetooth : 1M00FXD / 79M0FXD Number of channels :GSM 1900 : 300Bluetooth : 79 Antenna:Integral antenna and socket Power supply:3.6 VDC accu Li-Polymer Output power:GSM 1900 : 29.5 dBm Peak, Bluetooth : ca. 0.54 mW Type of equipment:Temperature range : -30°C - +60°C FCC – ID:PY71130202 Hardware:R1A Software:R1A095prgCXC125265, R1A095prgCXC125326_TAE 1.6Test standards: FCC Part 24 / 15.247 CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 4 (33) Technical test The radiated measurements were performed vertical and horizontal over the whole frequency range. We start at 1 m high with vertical receiving antenna and rotate the dish continuously. During rotation we use the antenna lift system to vary the high from 1 to 4 m. So we find maximum radiation output. At this points we do manual re-measurements. After this we do the same measurements in horizontal position of the receiving antenna. This (horizontal and vertical) is made for all the three planes of the test sample. We use the maximum received results. The detector function and selection of bandwidth are according ANSI C63.2-1996 item 8.2.1 and ANSI C63.4-1992 Item 4.2. Antennas are conform with ANSI C63.2-1996 item 15. 150 kHz - 30 MHz: Quasi Peak measurement, 9kHz Bandwidth, passive loop antenna. 30 MHz - 200 MHz: Quasi Peak measurement, 120KHz Bandwidth, Biconical antenna 200MHz - 1GHz: Quasi Peak measurement, 120KHz Bandwidth, Log periodic antenna 1GHz: Average, RBW 1MHz, VBW 10 MHz, waveguide horn 2.1 Summary of test results Only spurious emission test from 30 MHz to 25 GHz were done with GSM 1900 and Bluetooth operating mode ! FINAL VERDICT : PASS Technical responsibility for area of testing : 05.12.01RSC 8411 Berg M. DateSectionNameSignature Technical responsibility for area of testing : 05.12.01RSC8412Hausknecht D. DateSectionNameSignature CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 5 (33) 2.2Testreport TEST REPORT Testreport no. : 2_2746-01-01/01 CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 6 (33) TEST REPORT REFERENCE LIST OF MEASUREMENTS PARAMETER TO BE MEASURED ParagraphPAGE EMISSIONS LIMITS §24.2387 TEST SITE23 PHOTOGRAPHS OF THE EQUIPMENT25 CETECOM ICT Services GmbH Test report nr.:2_2746-01-01/01Issue date:05.12.2001Page 7 (33) REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see test equipment listing) 17 - 24 EMISSIONS LIMITS §24.238 Measurement Procedure: The following steps outline the procedure used to measure the radiated emissions from the mobile station. The site is constructed in accordance with ANSI C63.4 – 1992 requirements and is recognised by the FCC to be in compliance for a 3 and a10 meter site. The spectrum was scanned from 30 MHz to the 10th harmonic of the highest frequency generated within the equipment, which is the transmitted carrier that can be as high as 1910 MHz. This was rounded up to 20 GHz. The resolution bandwidth is set as outlined in Part 24.238. The spectrum was scanned with the mobile station transmitting at carrier frequencies that pertain to low, mid and high channels of the USPCS band. The final open field emission test procedure is as follows: a) The test item was placed on a 0. 8 meter high non-conductive stand at a 3 meter test distance from the receive antenna. b) The anten…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Radio Satelite Communication Untertürkheimer Straße 6-10 . D-66117 SaarbrückenTelefon: +49 (0)681 598-9100Telefax: -9075 RSC11issue test report consist of 55 PagesPage 1 (55) Test report no.: 2-2519-B/01 FCC Part 24 1130201-BV FCC ID : PBY1130201-BV Accredited Testing Laboratory DAR-Registration number: TTI-P-G 166/98-20 CETECOM ICT Services GmbH Test report nr.:2-2519-B/01Issue date:25.05.2001Page 2 (55) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test report 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. 1.2Testing laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telefone: + 49 681 598 - 9100 Telefax : + 49 681 598 - 9075 E-mail: [email protected] Internet: www.cetecom.de Accredited testing laboratory DAR-registration number : TTI-P-G 166/98-00 CETECOM ICT Services GmbH Test report nr.:2-2519-B/01Issue date:25.05.2001Page 3 (55) 1.3Details of applicant Name :Ericsson Mobile Communications AB Street :Nya Vattentornet City :S-22183 Lund Country :Sweden Telephone:+46-46-19 3000 Telefax :+46-46-19 3295 Contact :Mr. Bo Johansson Telephone:+46-46-19 3000 1.4Application details Date of receipt of application : 14.05.01 Date of receipt of test item : 17.05.01 Date of test : 17.-06.06.01 1.5Test item Type of equipment :GSM 900/1800/1900 Mobile Phone with integrated Bluetooth Module Type designation:113020101-BV Manufacturer:Applicant Street: City: Country: Serial number:243 099999-00-123456-0-00 Additional informations:: Frequency:1850 – 1910 MHz Type of modulation:300KF2D Number of channels :300 Antenna:Integral antenna and socket Power supply:3.6 VDC accu Li-Polymer Output power:28.8 dBm Peak / ERP : 27.3 dBm (Burst); EIRP: 29.3 dBm (Burst) Type of equipment:Temperature range : -30°C - +60°C FCC – ID:PBY1130201 Hardware:PA1 Software:R1A023prgCXC125265 / R1A023 prgCXC125326_TAE 1.6Test standards: FCC Part 24 …
