PY7A1021051Licensed Transmitter

Sony Corporation

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Aug 23, 2004
Application Purpose: Original Equipment
Date of Application: Aug 23, 2004
Equipment Note: Licensed Transmitter
Frequency Range: 2402.00000000 - 2480.00000000
Company: Sony Corporation
Country: Japan

Documents & Files

Select a file to view

Users Manual

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

Confidentiality Request Datum' DateBeteckning. Reference Vår handläggare, namn, tfn .Attending to this mattet; name, te/ephone SEM/BGGINB Håkan Sjöberg +4646193559 2004-08-17 Ert datum' Your date GUG/NO4:193 Er beteckning' Your reference Receiver Federal Communications Commission Subject: Request for Confidentiality FCC ID: PY7A1021051 Ta Wham It May Cancern: In accordance with §O.459 of CFR 47, Sony Ericsson Mobile Communications AB requests confidentiality for the below Iisted items for our mobile phone type AAB- 1021051-BV, FCC ID: PY7A1021051: 1.2.3.4. Block Diagram Schematic Diagram Part List Operational Descriptions These items contain detailed system and equipment description and related information about the product which Sony Ericsson Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Ericsson Mobile Communications AB also feels thai this information would be of benefit to ils competitors, and thai the disclosure of the information in these exhibits would give Dur competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Bo Johansson Type Approval Manager Sony Ericsson Mobile Communications AB Sony Ericsson Mobile Communications AB Momsnr .~A. 7:No: SE556615665801 Organisationsnr. Reg No: 556615-6658 Telefax. Telefax Nat 046-1941 00 Ini +4646194100 Styrelsens säte: Lund Registered office: Lund Telefon' Te/ephone Nat 046-1940 00 Int +4646194000 Postadress. Mail SE-221 88 Lund Sweden Besöksadress. Office address Nya Vattentornet Lund

External Photos

SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 42 of 53 4 Photographs Test Site: SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 43 of 53 Test Site: SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 44 of 53 Test Site: SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 45 of 53 EUT: SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 46 of 53 EUT: SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 47 of 53 EUT: SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 48 of 53 EUT: SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 49 of 53 EUT: SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 50 of 53 EUT: SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 51 of 53 EUT: SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 52 of 53 EUT: SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 53 of 53 EUT:

ID Label/Location Info

Company Internal MARKING DRAWING 1 (3) Prepared (also subject responsible if other) No. SEM/BGURDBB, Thomas Westman 151 86–SVV 107 163/1 Uen Approved Checked Date Rev Reference SEM/BGURDBB (Thomas Westman) 2004-05-19 A 5 Approved according to 000 21–LXE 107 42/1 S700i, KRH-label, SEM 1 General information The format of the label is based on a label sized 33,0 x 20,0 mm, e.g. SVF 930 863 (rounded corner top left). The label shall be fed through the printer that the bars in the bar codes are parallel to the feeding direction. If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. All bar codes, when applicable, are according to Ericsson corporate standard 102 01–109 Uen. All bar codes shall fulfil minimum print quality C according to ANSI X3.182-1990 as stated in Ericsson corporate standard 102 01–1003 Uen. No bar codes are allowed to be closer to a label edge than 2 mm! (quiet zone). “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. The label shall be placed on the back of the telephone according to the Assembly Drawing (151 88-) for the KRH. 2 Printing information Content Format Line 1a (2,5/2,0) Sony Ericsson stylized name. Graphics, height 1,4 mm. According to 190 89–EN/LZT 108 5347 Line 1b (2,5/15,0) Model name, “S700i” / ”S700c” Text, height 1,2 mm. Line 1c (2,5/19,0) Product number (without R-state) of the DPY kit in which the phone is packed, if applicable. Printed without “DPY 101”, “0000/000” Text, height 1,2 mm. Line 2a (4,0/1,0) Type number of the phone (KRH), “Type: AAB-1021051-BV”. Text, height 1,2 mm. Line 2b (4,0/15,0) ROA and R-state identification field, “GHY 1 Y 2 Y 3 ” Text, height 1,2 mm. According to the 3/151 86- document in the 1095- for the SVV. Company Internal MARKING DRAWING 2 (3) Prepared (also subject responsible if other) No. SEM/BGURDBB, Thomas Westman 151 86–SVV 107 163/1 Uen Approved Checked Date Rev Reference SEM/BGURDBB (Thomas Westman) 2004-05-19 A 5 Content Format Line 2c (4,0/23,5) Location code of where the phone is flashed, if applicable, “FFF” Text, height 1,2 mm. Line 3a (6,0/1,0) Federal Communications Commission identification number: “FCC ID: PY7A1021051” Text, height 1,2 mm. Line 3b (6,0/15,0) Industry Canada certification number: “IC: 4170B-A1021051” Text, height 1,2 mm. Line 4 (9,0/2,0) Line 5a in bar code. As desired by supplier (e.g. only actual number). Bar code, height 2,5 mm. As desired by supplier (e.g. Code 128 symbology). Line 5a (10,5/1,0) Supplier’s identification for trace- ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,2 mm. Defined by supplier. Line 5b (10,5/12,0) Electronic serial number (IMEI) of phone (KRH), “IMEI: 00000000-000000-0”. Text, height 1,2 mm. In the format TAC-SNR-CD. TAC and SNR derived from the 3/151 86- document in the 1095- for the SVV. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 6 (13,5/2,0) Line 5b in bar code (only actual number, without data identifier). Bar code, height 2,5 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. Line 7 (15,0/1,0) Repair week, if applicable. “Ry’W’ww” (y = year, ww = week) Text, height 1,2 mm. Line 8 (17,0/1,0) Production week, “yy’W’ww” (yy = year, ww = week) Text, height 1,2 mm. Line 9a (19,0/1,0) Marking of origin. The line shall be printed as stated in a separate 1/151 86- document in the 1095- for the SVV, if any. Text, height 1,2 mm. Line 9b (19,0/11,0) Additional field/lines. The field shall be left blank unless otherwise stated in a separate 2/151 86– document in the 1095- of the actual SVV. Line 9c (19,0/32,0) “CE 0682” approval symbol. Graphics, height 5 mm. According to SVF 930 182/2. Rotated 90° counter clockwise. Company Internal MARKING DRAWING 3 (3) Prepared (also subject responsible if other) No. SEM/BGURDBB, Thomas Westman 151 86–SVV 107 163/1 Uen Approved Checked Date Rev Reference SEM/BGURDBB (Thomas Westman) 2004-05-19 A 5 Layout The example picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 2.1 Example picture double underlined = major changes since last revision.

Internal Photos

Test Report

G:\2_RSC\PROJEKTE\04\3636_1 SEM AAB-1021051-BV\Ergebnisse\Task 3 FCC part 15.247\2-3636-1-3_04 FCC.doc Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463 (IC) TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 081/94-DO Independent ETSI compliance test house ETSI Accredited Bluetooth™ Test Facility (BQTF) Test report no.: 2-3636-1-3_04 FCC Part 15.247 / CANADA RSS-210 FCC ID: PY7A1021051 / IC: 4170B-A1021051 Type: AAB-1021051-BV CETECOM – ICT Services GmbH Untertürkheimerstr. 6-10 D-66117 Saarbrücken, Germany Telephone: + 49 (0) 681 / 598-0 Fax: + 49 (0) 681 / 598-9075 BLUETOOTH is a trademark owned by Bluetooth SIG, Inc. and licensed to Cetecom SRD-Testreport CETECOM ICT Services GmbH Saarbruecken, Germany Test report No.: 2-3636-1-3_04Date: 2004-06-15Page 2 of 53 Table of contents 1.ADMINISTRATIVE DATA ...................................................................................................................................... 3 1.1.A DMINISTRATIVE DATA OF THE TEST FACILITY..................................................................................................... 3 1.1.1Identification of the testing laboratory ......................................................................................................... 3 1.1.2Organizational items .................................................................................................................................... 3 1.1.3Applicant ́s details ........................................................................................................................................ 4 1.2A DMINISTRATIVE DATA OF MANUFACTURER / MEMBER........................................................................................ 4 1.3D ESCRIPTION OF THE EQUIPMENT UNDER TEST (EUT) .......................................................................................... 5 1.3.1EUT: Type, S/N etc. ...................................................................................................................................... 5 1.3.2If RF component testing only, describtion of additional used HW/SW .........................................................5 1.3.3Additional EUT information For IC Canada (appendix 2)........................................................................... 6 1.3.4EUT operating modes ................................................................................................................................... 7 1.3.5Extreme conditions testing values................................................................................................................. 7 2.TESTSTANDARD & SUMMARY LIST OF ALL PERFORMED TEST CASES .............................................. 8 3.RF MEASUREMENT TESTING ............................................................................................................................. 9 3.1D ESCRIPTION OF TEST SET-UP................................................................................................................................9 3.1.1Radiated measurements ................................................................................................................................ 9 3.1.2Conducted measurements ............................................................................................................................. 9 3.2R EFERENCED DOCUMENTS................................................................................................................................... 10 3.3 A DDITIONAL COMMENTS..................................................................................................................................... 10 3.4A NTENNA GAIN................................................................................................................................................... 10 3.5C ARRIER FREQUENCY SEPARATION §15.247(A1)................................................................................................. 11 3.6 N UMBER OF HOPPING CHANNELS §15.247(A1) .................................................................................................... 12 3.7T IME OF OCCUPANCY (DWELL TIME) §15.247(A1 III).......................................................................................... 13 3.8 P OWER SPECTRAL DENSITY (HYBRID SYSTEM IN INQUIRY MODE/PAGE SCAN) §15.247(D) ................................. 14 3.9S PECTRUM BANDWIDTH OF A FHSS SYSTEM / 20DB BANDWITH §15.247(A1)................................................... 15 3.10M AXIMUM OUTPUT POWER (CONDUCTED) § 15.247 (B) (1) ................................................................................ 17 3.11M AX. PEAK OUTPUT POWER (RADIATED) § 15.247 (B) (1)................................................................................... 19 3.12B AND-EDGE COMPLIANCE OF CONDUCTED EMISSIONS §15.247 (C) ..................................................................... 20 3.13B AND-EDGE COMPLIANCE OF RADIATED EMISSIONS §15.205 .............................................................................. 23 3.14S PURIOUS EMISSIONS - CONDUCTED (TRANSMITTER) § 15.247 (C) (1) ............................................................... 27 3.15S PURIOUS EMISSIONS - RADIATED (TRANSMITTER) § 15.247 (C) (1) .................................................................. 29 3.16S PURIOUS EMISSIONS - RADIATED (RECEIVER) § 15.109..................................................................................... 35 3.17S PURIOUS EMISSIONS - RADIATED <30 MHZ § 15.109 ........................................................................................ 37 3.17S PURIOUS EMISSIONS - RADIATED <30 MHZ § 15.109 ........................................................................................ 37 3.18C ONDUCTED EMISSIONS <30 MHZ § 15.107/207 ................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Mika Kaneko(Chief Regulatory Compliance Manager)

[email protected]+81367103225Fax: +815038096297

Technical Contact

Sony Ericsson Mobile Communications ABH�kan Sj�berg

[email protected]+46 46 193 000

Nya Vattentornet · Lund · Sweden

Test Firm

Cetecom ICT Services GmbHRalf Hoehn

[email protected]49-681-598-8455Fax: 49-681-598-8475

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	1.36 mW

Confidentiality

Long Term

Grant Notes

Power is conducted. The Bluetooth transmitter is collocated with the PCS transmitter in the device. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance.
