PY7A1022011Licensed Transmitter

Sony Corporation

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: May 05, 2005
Application Purpose: Original Equipment
Date of Application: May 05, 2005
Equipment Note: Licensed Transmitter
Frequency Range: 1850.20000000 - 1909.80000000
Company: Sony Corporation
Country: Japan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 Contents Getting Started . . . . . . . . . . . . . . . . . . 4 Assemble the phone, SIM card, battery, make a call. Getting to Know Your Phone . . . . . . . 9 Phone overview, use the menus, enter letters, activity menu, file manager, Memory Stick Duo. Calling . . . . . . . . . . . . . . . . . . . . . . . . 18 Calls, contacts, voice control, call options. Messaging . . . . . . . . . . . . . . . . . . . . . 34 Text messaging, picture messaging, voice messaging, email, My friends. Imaging . . . . . . . . . . . . . . . . . . . . . . . 43 Camera, video recorder, pictures, PhotoDJ™. Entertainment . . . . . . . . . . . . . . . . . . 48 Media player, radio, PlayNow™, ringtones, MusicDJ™, VideoDJ™, sound recorder, themes, games. Connectivity . . . . . . . . . . . . . . . . . . . . 58 Internet and email settings, synchronizing, Bluetooth, infrared, USB cable, update service. More Features . . . . . . . . . . . . . . . . . . 68 Time and date, alarm clock, calendar, tasks, Java™ applications, SIM card lock, etc. Troubleshooting . . . . . . . . . . . . . . . . . 76 Why doesn’t the phone work the way I want? Additional Information . . . . . . . . . . . . 81 Sony Ericsson Consumer Web site, safe and efficient use, warranty, declaration of conformity. Icons . . . . . . . . . . . . . . . . . . . . . . . . . . 89 Icon descriptions. Index . . . . . . . . . . . . . . . . . . . . . . . . . 91 PPreflighted byreflighted byPreflighted by ( )( )( ) 2 Sony Ericsson GSM 900/1800/1900 First edition (February 2005) This user guide is published by Sony Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this user guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this user guide. All rights reserved. © Sony Ericsson Mobile Communications AB, 2005 Publication number: AE/LZT 108 7528 R1A Please note: Some of the services in this user guide are not supported by all networks. This also applies to the GSM International Emergency Number 112. Please contact your network operator or service provider if you are in doubt whether you can use a particular service or not. Please read the Guidelines for safe and efficient useand the Limited warranty chapters before you use your mobile phone. Your mobile phone has the capability to download, store and forward additional content, e.g. ringtones. The use of such content may be restricted or prohibited by rights of third parties, including but not limited to restriction under applicable copyright laws. You, and not Sony Ericsson, are entirely responsible for additional content that you download to or forward from your mobile phone. Prior to your use of any additional content, please verify that your intended use is properly licensed or is otherwise authorized. Sony Ericsson does not guarantee the accuracy, integrity or quality of any additional content or any other third party content. Under no circumstances will Sony Ericsson be liable in any way for your improper use of additional content or other third party content. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Ericsson is under license. Memory Stick™ and Memory Stick Duo™ are trademarks or registered trademarks of Sony Corporation. QuickShare™, PlayNow™, MusicDJ™ and VideoDJ™ are trademarks or registered trademarks of Sony Ericsson Mobile Communications AB. Microsoft, Windows and PowerPoint are either registered trademarks or trademarks of Microsoft Corporation in the U.S and other countries. Mac OS is a trademark of Apple Computer, Inc., registered in the U.S. and other countries. PPreflighted byreflighted byPreflighted by ( )( )( ) 3 T9™ Text Input is a trademark or a registered trademark of Tegic Communications. T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057, United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide. Java and all Java based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. End-user license agreement for Sun™ Java™ J2ME™. 1Restrictions: Software is confidential copyrighted information of Sun and title to all copies is retained by Sun and/or its licensors. Customer shall not modify, decompile, disassemble, decrypt, extract, or otherwise reverse engineer Software. Software may not be leased, assigned, or sublicensed, in whole or in part. 2Export Regulations: Software, including technical data, is subject to U.S. export control laws, including the U.S. Export Administration Act and its associated regulations, and may be subject to export or import regulations in other countries. Customer agrees to comply strictly with all such regulations and acknowledges that it has the responsibility to obtain licenses to export, re-export, or import Software. Software may not be downloaded, or otherwise exported or re-exported (i) into, or to a national or resident of, Cuba, Iraq, Iran, North Korea, Libya, Sudan, Syria (as such listing may be revised from time to time) or any country to which the U.S. has embargoed goods; or (ii) to anyone on the U.S. Treasury Department’s list of Specially Designated Nations or the U.S. Commerce Department’s Table of Denial Orders. 3Restricted Rights: Use, duplication or disclosure by the United States government is subject to the restrictions as set forth in the Rights in Technical Data and Computer Software Clauses in DFARS 252.227-7013(c) (1) (ii) and FAR 52.227-19(c) (2) as applicable. Part of the software in this product…

Text truncated - open the document above for the full version.

External Photos

CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-3934-01-01/05 Date: 2005-04-14 Page 1 of 39 \\ut55\2_PROJEKTE\05\3934_1\Task1(MCP)\Annex.doc Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463 (IC) TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 081/94-D0 Independent ETSI compliance test house ETSI Accredited Bluetooth ® Test Facility (BQTF) Annex to Test report no. : 2-3934-01-01/05 Applicant : Sony Ericsson Mobiele Communication AB Type : AAB-1022011-BV Test Standard : FCC Part 15 / RSS210 FCC ID : PY7A1022011 Certification No. IC : 4170B-A1022011 CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-3934-01-01/05 Date: 2005-04-14 Page 2 of 39 Table of contents 1 GENERAL INFORMATION ......................................................................................................................................... 3 1.1. ADMINISTRATIVE DATA OF THE TEST FACILITY........................................................................................................... 3 1.1.1 Identification of the testing laboratory ............................................................................................................... 3 1.2. NOTES......................................................................................................................................................................... 3 1.3 DETAILS OF APPLICANT............................................................................................................................................... 4 1.4 APPLICATION DETAILS................................................................................................................................................ 4 1.5 TEST ITEM................................................................................................................................................................... 5 1.6 TEST SETUP................................................................................................................................................................. 6 1.7 TEST SPECIFICATIONS.................................................................................................................................................. 6 2 STATEMENT OF COMPLIANCE ................................................................................................................................ 7 2.1 SUMMARY OF MEASUREMENT RESULTS...................................................................................................................... 7 2.1.1 CFR 47 Part 15 Radio frequency devices ........................................................................................................... 7 3 MEASUREMENTS AND RESULTS ............................................................................................................................. 8 4 ANNEX A: FCC PART 15 SUBPART B........................................................................................................................ 9 4.1 Conducted Limits .................................................................................................................................................... 9 5 ANNEX B PHOTOGRAPS OF TEST SITE ................................................................................................................ 20 6 ANNEX C: EXTERNAL PHOTOGRAPS OF THE EQUIPMENT.......................................................................... 25 7 ANNEX D: INTERNAL PHOTOGRAPS OF THE EQUIPMENT........................................................................... 27 CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-3934-01-01/05 Date: 2005-04-14 Page 3 of 39 1 General information 1.1. Administrative data of the test facility 1.1.1 Identification of the testing laboratory Company name: Cetecom ICT Services GmbH Address: Untertürkheimerstr. 6-10 D-66117 Saarbruecken Germany Laboratory accreditation: DAR-Registration No. TTI-P-G081/94-D0 Bluetooth Qualification Test Facility (BQTF) Federal Communications Commission (FCC) Identification/Registration No : 90462 Responsible for testing laboratory: Gillmann D. / Hausknecht D. Phone: +49 681 598 0 Fax: +49 681 598 9075 email: [email protected] 1.2. Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. ............................................... / ............................................... Responsible for testing laboratory (Gillmann D. / Hausknecht D.) ................................................ / ............................................... . Responsible for test report (Gillmann D. / Hausknecht D.) CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-3934-01-01/05 Date: 2005-04-14 Page 4 of 39 1.3 Details of Applicant Name : Sony Ericsson Mobiele Communication AB Address : Nya Vattentornet City : 22188 Lund Country : Sweden Phone : + 46 46 193242 Fax : + 46 46 193295 Contact : Mr. Bo.G. Joh…

Text truncated - open the document above for the full version.

ID Label/Location Info

Company Internal MARKING DRAWING 1 (3) Prepared (also subject responsible if other) No. SEM/BGURDBB, Niklas Lövberg 151 86–SVV 107 196/2 Uen Approved Checked Date Rev Reference SEM/BGURDBB (Niklas Lövberg) 2005-03-15 B 3 Approved according to 000 21–LXE 107 42/1 K750i, KRH-label, TYPE: AAB-1022011-BV 1 General information The format of the label is based on a label SVF 930 1371. If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. All bar codes, when applicable, are according to Ericsson corporate standard 102 01–109 Uen. All bar codes shall fulfil minimum print quality C according to ANSI X3.182-1990 as stated in Ericsson corporate standard 102 01–1003 Uen. No bar codes are allowed to be closer to a label edge than 2 mm! (quiet zone). “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. The label shall be placed on the back of the telephone according to the Assembly Drawing (151 88-) for the KRH. 2 Printing information Content Format Line 1 (3,5/1,0) Line 2 in bar code. As desired by supplier (e.g. only actual number). Bar code, height 2,5 mm. As desired by supplier (e.g. Code 128 symbology). Line 2 (5,2/1,0) Supplier’s identification for trace- ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,2 mm. Defined by supplier. Line 3 (9,6/12,8) Actual electronic serial number (IMEI) of the phone (KRH), “00000000-000000-0” Text, height 2,0 mm. In the format TAC-SNR-CD. TAC and SNR derived from the 3/151 86- document in the 1095- for the SVV. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 4a (11,5/12,8) Repair week, if applicable. “Ry’W’ww” (y = year, ww = week) Text, height 1,2 mm. Company Internal MARKING DRAWING 2 (3) Prepared (also subject responsible if other) No. SEM/BGURDBB, Niklas Lövberg 151 86–SVV 107 196/2 Uen Approved Checked Date Rev Reference SEM/BGURDBB (Niklas Lövberg) 2005-03-15 B 3 Content Format Line 4b (11,5/18,0) Location code of where the phone is flashed, if applicable, “XXX” Text, height 1,2 mm. Line 5 (13,5/12,8) Production week (flash), “yy’W’ww” (yy = year, ww = week) Text, height 1,2 mm. Line 6a (15,1/11,3) Product number of the DPY kit in which the phone is packed, if applicable. Printed without “DPY 101” and R-state, “0000/000” Text, height 1,2 mm. Line 6b (15,1/20,5) CE approval symbol. Graphics, height 5 mm. According to 1424-SVF 930 52. Line 6c (15,1/27,4) The Notified body number. “0682” Text, height 1,2 mm. Line 7a (16,8/0,5) Country approval mark 2 “IC: 4170B-A1022011” Text, height 1,2 mm. Line 7b (16,8/15,8) Country approval mark 1 “FCC ID: PY7A1022011” Text, height 1,2 mm. Line 8a (18,4/0,5) Type number of the phone (KRH), “Type: AAB-1022011-BV”. Text, height 1,2 mm. Line 8b (18,4/15,3) ROA and R-state identification field, “GHY 1 Y 2 Y 3 ” Text, height 1,2 mm. According to the 3/151 86- document in the 1095- for the SVV. Line 8c (18,4/19,9) Sony Ericsson stylized name. Graphics, height 1,4 mm. According to 190 89–EN/LZT 108 5347 Line 9a (20,6/0,5) Line 3 in bar code (only actual number, without data identifier). Bar code, height 2,0 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. Line 9b (20,6/26,5) Model name, “K750i” Text, height 1,2 mm. Company Internal MARKING DRAWING 3 (3) Prepared (also subject responsible if other) No. SEM/BGURDBB, Niklas Lövberg 151 86–SVV 107 196/2 Uen Approved Checked Date Rev Reference SEM/BGURDBB (Niklas Lövberg) 2005-03-15 B 3 3 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 3.1 Conceptual picture double underlined = major changes since last revision.

Internal Photos

Text truncated - open the document above for the full version.

RF Exposure Info

Company Internal REPORT 1 (12) Prepared (also subject responsible if other) No. LD/SEMC/BGGI/NM Hamid Kami Shirazi BGGIN05:097 Approved Checked Date Rev Reference LD/SEMC/BGGI/NM Ramadan Plicanic 050426 050425 A File Report issued by Accredited SAR Laboratory for PY7A1022011 Date of test: 14-15-17, April, 2005 Laboratory: Sony Ericsson SAR Test Laboratory Sonyericsson Mobile Communications AB Nya Vattentornet SE-221 82 LUND, Sweden Testing Engineer: Hamid Kami Shirazi [email protected] +4646232644 Testing Approval Ramadan Plicanic [email protected] +46 46 193 862 Statement of Compliance Sony Ericsson Mobile Communications AB declares under its sole responsibility that the product Sony Ericsson Type AAB-1022011-BV; FCC ID:PY7A1022011;IC:4170B-A1022011 to which this declaration relates, is in conformity with the appropriate RF exposure standards recommendations and guidelines. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (None) This laboratory is accredited to ISO/IEC 17025 (SWEDAC accreditation no. 1847). Laboratories are accredited by the Swedish Board for Accreditation and Conformity Assessment (SWEDAC) under the terms of Swedish legislation. The accredited laboratory activities meet the requirements in SS-EN ISO/IEC 17025 (2000). This report may not be reproduced other than in full, except with the prior written approval of the issuing laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Sony Ericsson encourages all feedback, both positive and negative, on this report. © Sony Ericsson Mobile Communication AB, 2005 Company Internal REPORT 2 (12) Prepared (also subject responsible if other) No. LD/SEMC/BGGI/NM Hamid Kami Shirazi BGGIN05:097 Approved Checked Date Rev Reference LD/SEMC/BGGI/NM Ramadan Plicanic 050426 050425 File 1 Table of contents 2 INTRODUCTION..................................................................................................................................................................3 3 DEVICE UNDER TEST........................................................................................................................................................3 3.1 A NTENNA DESCRIPTION.......................................................................................................................................................3 3.2 D EVICE DESCRIPTION...........................................................................................................................................................3 4 TEST EQUIPMENT ..............................................................................................................................................................4 4.1 D OSIMETRIC SYSTEM............................................................................................................................................................4 4.2 A DDITIONAL EQUIPMENT.....................................................................................................................................................4 5 ELECTRICAL PARAMETERS ON THE TISSUE SIMULATING LIQUID ..............................................................5 6 SYSTEM ACCURACY VERIFICATION..........................................................................................................................5 7 SAR MEASUREMENT UNCERTAINTY .........................................................................................................................6 8 TEST RESULTS ....................................................................................................................................................................7 9 REFERENCES .......................................................................................................................................................................8 10 APPENDIX .............................................................................................................................................................................9 10.1 P HOTOGRAPHS OF THE DEVICE UNDER TEST..................................................................................................................10 10.2 D EVICE POSITION ON SAM TWINS PHANTOM...............................................................................................................11 Company Internal REPORT 3 (12) Prepared (also subject responsible if other) No. LD/SEMC/BGGI/NM Hamid Kami Shirazi BGGIN05:097 Approved Checked Date Rev Reference LD/SEMC/BGGI/NM Ramadan Plicanic 050426 050425 File 2 Introduction In this test report, compliance of the Sony Ericsson PY7A1022011 portable telephone with RF safety guidelines is demonstrated. The applicable RF safety guidelines and the SAR measurement specifications used for the test are described in the SAR Measurement Specifications of Wireless Handsets [1]. 3 Device Under Test 3.1 Antenna Description Type Build in Location Up on the back side Max length 32mm Dimensions Max width 20mm Configuration PIFA 3.2 Device description Device model PY7A1022011 Serial number 692287-5 Mode GSM1900 Multiple Access Scheme TDMA Maximum Output Power Setting 30.0dBm Factory Tolerance in Power Setting ±0.5dBm Maximum Peak Output Power for GPRS 28.5±0.5dBm Crest Factor 8 Transmitting Frequency Range(MHz) 1850.2 – 1909.8 Prototype or Production Unit Preproduction Device Category Portable RF exposure environment General population / uncontrolled Company Internal REPORT 4 (12) Prepared (also subject responsible if other) No. LD/SEMC/BGGI/NM Hamid Kami Shirazi BGGIN05:097 Approved Checked Date Rev Reference LD/SEMC/BGGI/NM Ramadan Plicanic 050426 050425 File…

Text truncated - open the document above for the full version.

Test Report

CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-3934-01-01/05 Date: 2005-04-14 Page 1 of 46 Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463 (IC) TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 081/94-D0 Independent ETSI compliance test house ETSI Accredited Bluetooth ® Test Facility (BQTF) Test report no. : 2-3934-01-01/05 Applicant : Sony Ericsson Mobile Communications AB Type : AAB-1022011-BV Test Standard : FCC Part 24 RSS 133 FCC ID : PY7A1022011 Certification No. IC : 4170B-A1022011 CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-3934-01-01/05 Date: 2005-04-14 Page 2 of 46 Table of contents 1 GENERAL INFORMATION ................................................................................................................................... 3 1.1. ADMINISTRATIVE DATA OF THE TEST FACILITY..................................................................................................... 3 1.1.1 Identification of the testing laboratory ......................................................................................................... 3 1.2. NOTES................................................................................................................................................................... 3 1.3 DETAILS OF APPLICANT......................................................................................................................................... 4 1.4 APPLICATION DETAILS...................................................................................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Kazuyuki Hori(Senior EMC/RF Compliance Manager)

[email protected]+815031416220Fax: +815037506540

Technical Contact

Sony Ericsson Mobile Communications ABH�kan Sj�berg

[email protected]

Nya Vattentornet · Lund · Sweden

Test Firm

Cetecom ICT Services GmbHRalf Hoehn

[email protected]49-681-598-8455Fax: 49-681-598-8475

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	24E	1.85 GHz - 1.91 GHz	891.00 mW	300KGXW	0.0452000000 ppm

Confidentiality

Long Term

Grant Notes

Power Output is EIRP. This device contains GSM 900 and 1800 MHz functions that are not operational in U.S. Territories. SAR compliance for body-worn operating configurations is limited to the specific configuration tested for this filing. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5 cm separation between the device and the users body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR value is: Head: 0.96W/kg (Bluetooth active) Body: 0.97W/kg (GPRS active)
