PY7A1032042GSM 850/1800/1900 Mobile Phone

Z250a User guide 2 Congratulations on your purchase of the Sony Ericsson Z250a. For additional phone content, go towww.sonyericsson.com/fun. Register now to get free online storage and special offers at www.sonyericsson.com/myphone. For product support, go to www.sonyericsson.com/support. Instruction symbols The following instruction symbols appear in this User guide: >Use the navigation key to scroll and select. Press the navigation key up. Press the navigation key down. Press the navigation key to the left. Press the navigation key to the right. Tip Note Warning Indicates that a service or function is network- or subscription-dependent. All menus or functions may not be available in your phone. Consult your network operator for more information. 3 Prepare the phone Always turn off your phone and detach the charger before you insert or remove the SIM card. To insert the SIM card and battery 1Remove the battery cover by sliding the battery release latch down. 2Slide the SIM card into its holder with the contacts facing down. 3Insert the battery with the label side up and the connectors facing each other. 4Slide the battery cover into place and close the battery release latch . 4 Charge the battery Your phone battery is partly charged when you buy it. It takes approximately 3 hours to fully charge the battery. To charge the battery 1Connect the charger to the phone. Press a key to view the charging status on the screen. 2To remove the charger, tilt the plug upwards. It may take 30 minutes for the battery icon to appear on the screen. You can use the phone during charging. You can charge the battery for more or less than 3 hours. Interrupted charging will not damage the battery. 5 Turn the phone on To turn on the phone 1Press and hold down . 2Enter your PIN if requested. To correct mistakes, press . 3Select OK. 4Select a language. 5At first start-up, select Yes to use the setup wizard to make a phone setup. SelectNo to use the setup wizard later. To turn off the phone •Press and hold down . To use the setup wizard •From standby select Menu >Settings >General >Setup wizard >Basic setup. After you have turned the phone on and entered your PIN, the name of your operator appears on the screen. This view or screen is called standby. You can now make and receive calls. 6 SIM card The SIM (Subscriber Identity Module) card, which you get from your network operator, contains information about your subscription. Always turn off your phone and detach the charger before you insert or remove the SIM card. PIN code (SIM card lock) The PIN (Personal Identification Number) code is a SIM card lock that protects your subscription, but not the phone itself. If the card is locked, you have to enter the PIN code when you turn on your phone. Each PIN digit appears as *, unless it starts with emergency number digits, for example, 112 or 911. You can call an emergency number without entering a PIN. You can save contacts on the SIM card before removing if from your phone. Contacts may also be saved in the phone memory. See Contacts on page 17. If you enter the wrong PIN three times in a row, the following message appears: PIN blocked. To unblock, enter your PUK code provided by your network operator. To unblock your SIM card, see Locks on page 34. 7 Menu overview CallsInternetGames CameraMessagingFile manager Write new Inbox Drafts Outbox Sent messages Saved messages Call voicemail Templates Settings Camera album Pictures Ringtones Themes Bookmarks Games Applications Other OrganizerContactsSettings Online services Alarms Applications Calendar Tasks Notes Calculator Timer Stopwatch Options New contact General Sounds & alerts Display Calls Connectivity Some menus and icons described in this document may vary depending on operator, network or subscription. Some options may vary when the default settings are changed. 8 Phone overview Camera key Back key Internet keyNavigation key Volume buttons C key (Clear) On/off key Infrared port Microphone Right selection key Left selection key Charging (USB connector) Network coverage Battery status Function for right selection key Function for left selection key CallsMenu 9 Network coverage The network bars show the strength of the GSM network. Move to another location if you have network problems. No netw. coverage means you are out of range. Battery status The outside = Good network coverage = Average network coverage = The phone battery is fully charged = The phone battery is empty Icon display Camera lens 10 Icons These icons may appear in your phone. Icon Description Battery charging, appears with battery icon. You have missed a call. See Calling on page 15. The phone is set to silent. You have received a new text message. You have received a new picture message. Ongoing call. Divert calls is activated. An alarm is activated. The loudspeaker is on. The infrared port is activated. The stopwatch is activated. 11 Shortcuts From standby you can use the navigation keys to go directly to a function: •Press to start the camera. •Press to write a message. •Press to go to your contacts. To navigate the menus •From standby select Menu and press , , or . •Press to go back one step in the menu. •Press and hold down to return to standby. •Press or to move between tabs. To delete items •Press . To set the phone to silent •Press and hold down to set silent mode on or off. To view tips and tricks •From standby select Menu >Settings >General >Setup wizard >Tips and tricks. To change a standby shortcut, go to Menu >Settings >General >Shortcuts. The camera shortcut cannot be changed. 12 Messaging Your phone supports various messaging services. Text messages You need a service centre number from your network operator to be able to send text messages. To view and set the service centre number 1From standby select Menu >Messaging >Settings >Text message >Service centre. 2If there is no number, select New ServiceCentre, enter the number including the international “+” prefix and country code. Sel…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-33-02/07 2007-09-14 Page 20 of 27 9 Photographs of t he E UT Photo documentation Photo 4: CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-33-02/07 2007-09-14 Page 21 of 27 Photo 5: Photo 6: CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-33-02/07 2007-09-14 Page 22 of 27 Photo 7: Photo 8: CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-33-02/07 2007-09-14 Page 23 of 27 Photo 9: Photo 10:

Confidential MARKING DRAWINGSPECIFICATION 1 (4) Prepared (also subject responsible if other) No. SEM/BGNUDP THOMAS NILSSON 8/159 35-1/FCP 119 0191 Uen Approved Checked Date Rev Reference 2007-09-03 PA2 5 Approved according to 000 21–LXE 107 42/1 Z250a Marking Drawing Type: AAB-1032042-BV 1 General information The format of the label is based on a label SVF 930 2639. If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. All bar codes, when applicable, are according to Ericsson corporate standard 102 01–109 Uen. All bar codes shall fulfil minimum print quality C according to ANSI X3.182-1990 as stated in Ericsson corporate standard 102 01–1003 Uen. No bar codes are allowed to be closer to a label edge than 2 mm! (quiet zone). “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. The label shall be placed on the back of the telephone according to the Assembly Drawing (151 88-) for the KRH. 2 Printing information Content Format Line 1a (2,3/1,0) Sony Ericsson stylized name. Graphics, height 1,5 mm. According to 190 89–EN/LZT 108 5347 Line 1b (2,3/16,0) Model name, “Z250a” Text, height 1,2 mm. Line 1c (2,3/22,0) Product number of the DPY kit in which the phone is packed. Printed without R-state. “DPY 101 0000/000” Text, height 1,2 mm. Line 2a (4,5/1,0) Type number of the phone (KRH), “Type: AAB-1032042-BV”. Text, height 1,2 mm. Line 2b (4,5/16,0) HW & SW fields, “FG” Text, height 1,2 mm. According to the 3/151 86- document in the 1095- for the SVV. Line 3a (6,5/1,0) Country approval mark 1 “FCC ID: PY7A1032042” Text, height 1,2 mm. Line 3b (6,5/16,0) Production week (flash), “yy’W’ww” (yy = year, ww = week) Text, height 1,2 mm. Line 4 (7,8/22,0) CE approval symbol. Graphics, height 5 mm. According to 1424-SVF 930 52. Confidential MARKING DRAWINGSPECIFICATION 2 (4) Prepared (also subject responsible if other) No. SEM/BGNUDP THOMAS NILSSON 8/159 35-1/FCP 119 0191 Uen Approved Checked Date Rev Reference 2007-09-03 PA2 5 Content Format Line 5a (8,5/1,0) Country approval mark 2 “IC: 4170B-A1032042” Text, height 1,2 mm. Line 5b (8,5/16,0) Repair week, if applicable. “Ry’W’ww” (y = year, ww = week) Text, height 1,2 mm. Line 6 (10,4/22,9) The Notified body number. “0682” Text, height 2,3 mm. Line 7a (9,6/1,0) Marking of origin. The line shall be printed as stated in chapter 3 in this document. Text, height 1,2 mm. Line 7b (9,6/16,0) Location code of where the phone is flashed, if applicable, “FFF” Text, height 1,2 mm. Line 8 (13/1,0) Line 7a in bar code. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 9a (14,8/1,0) Supplier’s identification for trace- ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,2 mm. Defined by supplier. Line 9b (14,8/13,0) Actual electronic serial number (IMEI) of the phone (KRH), “00000000-000000-0” Text, height 1,2 mm. In the format TAC-SNR-CD. TAC and SNR derived from the 3/151 86- document in the 1095- for the SVV. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 10 (17,0/1,0) Line 7b in bar code (only actual number, without data identifier). Bar code, height 2,0 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. Confidential MARKING DRAWINGSPECIFICATION 3 (4) Prepared (also subject responsible if other) No. SEM/BGNUDP THOMAS NILSSON 8/159 35-1/FCP 119 0191 Uen Approved Checked Date Rev Reference 2007-09-03 PA2 5 3 Marking of Origin 3.1 Content “Made in Xxx”; “Xxx” = actual country of production of the included telephone, in English 4 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 4.1 Conceptual picture double underlined = major changes since last revision. Confidential MARKING DRAWINGSPECIFICATION 4 (4) Prepared (also subject responsible if other) No. SEM/BGNUDP THOMAS NILSSON 8/159 35-1/FCP 119 0191 Uen Approved Checked Date Rev Reference 2007-09-03 PA2 5 4.1 Label placement To find the label follow these steps: 1. Remove the cover on the rear side of the product. 2. Remove the battery. 3. The label is located under the battery. Rear side of the phone Place for battery Label placement

CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-33-02/07 2007-09-14 Page 24 of 27 Photo 11: Photo 12: CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-33-02/07 2007-09-14 Page 25 of 27 Photo 13: Photo 14: CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-33-02/07 2007-09-14 Page 26 of 27 Photo 15: Photo 16: CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-33-02/07 2007-09-14 Page 27 of 27 Photo 17:

Company Internal REPORT 1 (11) Prepared (also subject responsible if other) No. LD/SEMC/BGLIM Hamid Kami Shirazi BGLI07:390 Approved Checked Date Rev Reference LD/SEMC/BGLIMC Peter Lindeborg 070830 070829 A File Report issued by Accredited SAR Laboratory For PY7A1032042 (Z250a) Date of test: 22 nd to 28 th Aug. 2007 Laboratory: SAR Test Laboratory Sony Ericsson Mobile Communications AB Nya Vattentornet SE-221 82 LUND, Sweden Testing Engineer: Hamid Kami Shirazi [email protected] +46 46232644 Testing Approval Peter Lindeborg [email protected] +46462126180 Statement of Compliance Sony Ericsson Mobile Communications AB declares under its sole responsibility that the product Sony Ericsson Type AAB-1032042-BV; FCC ID: PY7A1032042; IC:4170B-A1032042 to which this declaration relates, is in conformity with the appropriate RF exposure standards recommendations and guidelines. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (None) This laboratory is accredited to ISO/IEC 17025 (SWEDAC accreditation no. 1847). Laboratories are accredited by the Swedish Board for Accreditation and Conformity Assessment (SWEDAC) under the terms of Swedish legislation. The accredited laboratory activities meet the requirements in SS-EN ISO/IEC 17025 (2005). This report may not be reproduced other than in full, except with the prior written approval of the issuing laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Sony Ericsson encourages all feedback, both positive and negative, on this report. © Sony Ericsson Mobile Communication AB, 2007 Company Internal REPORT 2 (11) Prepared (also subject responsible if other) No. LD/SEMC/BGLIM Hamid Kami Shirazi BGLI07:390 Approved Checked Date Rev Reference LD/SEMC/BGLIMC Peter Lindeborg 070830 070829 A File 1 Table of contents 2 INTRODUCTION..................................................................................................................................................................3 3 DEVICE UNDER TEST........................................................................................................................................................3 3.1 A NTENNA DESCRIPTION.......................................................................................................................................................3 3.2 D EVICE DESCRIPTION...........................................................................................................................................................3 4 TEST EQUIPMENT ..............................................................................................................................................................4 4.1 D OSIMETRIC SYSTEM............................................................................................................................................................4 4.2 A DDITIONAL EQUIPMENT.....................................................................................................................................................4 5 ELECTRICAL PARAMETERS ON THE TISSUE SIMULATING LIQUID ..............................................................4 6 SYSTEM ACCURACY VERIFICATION..........................................................................................................................5 7 SAR MEASUREMENT UNCERTAINTY .........................................................................................................................6 8 TEST RESULTS ....................................................................................................................................................................7 9 REFERENCES .......................................................................................................................................................................8 10 APPENDIX .............................................................................................................................................................................9 10.1 P HOTOGRAPHS OF THE DEVICE UNDER TEST....................................................................................................................9 10.2 D EVICE POSITION ON SAM TWINS PHANTOM...............................................................................................................11 10.3 A TTACHMENTS...............................................................................................................................................................12 Company Internal REPORT 3 (11) Prepared (also subject responsible if other) No. LD/SEMC/BGLIM Hamid Kami Shirazi BGLI07:390 Approved Checked Date Rev Reference LD/SEMC/BGLIMC Peter Lindeborg 070830 070829 A File 2 Introduction In this test report, compliance of the Sony Ericsson PY7A1032042 (Z250a) portable telephone with RF safety guidelines is demonstrated. The applicable RF safety guidelines and the SAR measurement specifications used for the test are described in the SAR Measurement Specifications of Wireless Handsets [1]. 3 Device under Test 3.1 Antenna Description Type Internal antenna Location Inside, rear, at the bottom Max length 40mm Dimensions Max width 15mm Configuration PIFA 3.2 Device description Device model PY7A1032042(Z250a) Serial number (EUT #) BX8000GY04#8769 Mode GSM1900 GSM850 Crest Factor 8.3 8.3 Multiple Access Scheme TDMA TDMA Ch512 Ch661 Ch810 Ch128 Ch190 Ch251 Maximum Output Power Setting (dBm) 30.0 30.0 30.0 32.5 32.5 32.5 Factory Tolerance in Power Setting ±0.5dB ±0.5dB Maximum Peak Output Power (dBm) 30.5 30.5 30.5 33.0 33.0 33.0 Data and connectivity GPRS Class: 8 ; Capability Class: B Ch512 Ch661 Ch810…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Untertürkheimer Straße 6-10 . D-66117 Saarbrücken Phone: +49 (0) 681-598-0 Fax:-9075 RSC-Laboratory 2007-09-14 Page 1 of 27 Accredited testing-laboratory DAR registration number: DAT-P-176/94-D1 Federal Motor Transport Authority (KBA) DAR registration number: KBA-P 00070-97 Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463A-1 (IC) Certification ID: DE 0001 Accreditation ID: DE 0002 Accredited Bluetooth ® Test Facility (BQTF) The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Cetecom ICT is under license Annex to Test report no. : 2-4576-33-02/07 Type identification : AAB-1032042-BV Applicant : Sony Ericsson Mobile Communications AB FCC ID : PY7A1032042 IC Certification No : 4170B-A1032042 Test standards : 47 CFR Part 15 B RSS 210 Issue 7 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-33-02/07 2007-09-14 Page 2 of 27 Table of contents 1 G e n e r a l i n f o r m a t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . 3 1.1 Notes ...................................................................................................................................................................3 1.2 Testing laboratory ...............................................................................................................................................4 1.3 Details of applicant .............................................................................................................................................4 1.4 Application details ..............................................................................................................................................4 2 T e s t s t a n d a r d / s : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 5 3 T e c h n i c a l t e s t s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 6 3.1 Details of manufacturer .......................................................................................................................................6 3.2 Test item(s) and test configuration ......................................................................................................................6 4 S u m m a r y o f M e a s u r e m e n t R e s u l t s a n d l i s t o f a l l p e r fo r m e d t e s t c a s e s . . . . . . . . . . . . . . . . . . . . . . . . . . 7 5 M e a s u r e m e n t s a n d r e s u l t s . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . 8 6 A n n e x A : F C C P a r t 1 5 S u b p a r t B . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 9 6.1 Conducted Limits ................................................................................................................................................9 Receiver spurious emission radiated (Idle mode).........................................................................................................12 7 T e s t e q u i p m e n t a n d a n c i l l a r i e s u s e d f o r t e s t s . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 1 6 8 P h o t o g r a p h s o f t h e T e s t S e t - u p . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . 1 8 9 P h o t o g r a p h s o f t h e E U T . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . 2 0 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-33-02/07 2007-09-14 Page 3 of 27 1 General infor mat ion 1 . 1 N o t e s The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. Test laboratory manager: 2007-09-14 Jakob Reschke Date Name Signature Technical responsibility for area of testing: 2007-09-14 Michael Berg Date Name Signature CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-33-02/07 2007-09-14 Page 4 of 27 1 . 2 T e s t i n g l a b o r a t o r y CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 e-mail: [email protected] Internet: http://www.cetecom-ict.de State of accreditation: Accredited by: The test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 DAR registration number: DAT-P-176/94-D1 Federal Motor Transport Authority (KBA) DAR registration number: KBA-P 00070-97 Testing location, if different from CETECOM ICT Services GmbH: Name : Street : Town : Country : Phone : Fax : 1 . 3 D e t a i l s o f a p p l i c a n t Name: Sony Ericsson Mobile Communications AB Street: Nya Vattentornet Town: 22188 Lund Country: Sweden Telephone: +46-46-19-3000 Fax: +46-46…

Text truncated - open the document above for the full version.
