PY7A1041011Licensed Transmitter

Mobile Phone T226 This is a preliminary version of the U ser's G uide 1 ContentsGetting started 3Make and receive the first call.Getting to know your phone 7Key functions, quick keys, entering letters and characters.Personalizing your phone 16Choose ring signal, theme and other settings.Calling 23Use the phonebook, call options.Setting up Mobile Internet 37Set up internet and email.Messaging 42Chat, email, text and pictures.Using Mobile Internet 50WAP browser, bookmarks. More features 54Events, alarm clock, stopwatch, timer, games.Security 58SIM card lock, phone lock.Troubleshooting 59Why doesn’t the phone work the way I want?Additional information 62Sony Ericsson Consumer web site, safe and efficient use, warranty, declaration of conformity.Icons 70What do the icons mean?Index 75 T226.book Page 1 Thursday, July 31, 2003 2:28 PM 2 Sony EricssonFirst edition (August 2003)This manual is published by Sony Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this manual.© 2003 Sony Ericsson Mobile Communications AB All rights reserved.Publication number: AE/LZT 123 1735 R2 Ple ase note: Some of the services in this manual are not supported by all networks. This also applies to the GSM International Emergency Number 112 . Please contact your network operator or service provider if you are not sure whether you can use a particular service or not. Please read the Guidelines for safe and efficient use and the Limited warranty chapters before you use your mobile phone.The marble logo is a trademark of Sony Ericsson Mobile Communications AB. Sony is a trademark of Sony Corporation and Ericsson is a trademark of Telefonaktiebolaget L M Ericsson.T9™ Text Input is a trademark or a registered trademark of Tegic Communications.T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057, United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide.Other product and company names may be the trademarks of their respective owners. Any rights not expressly granted herein are reserved. T226.book Page 2 Thursday, July 31, 2003 2:28 PM Getting started 3 Getting startedAbout this user’s guideFor ease of reference, the “Getting to know your phone” chapter gives a quick overview of the main functions of the phone, shortcuts and general information. More information and downloads are available at www.SonyEricsson.com or wap.SonyEricsson.com . Note: Throughout this manual, WAP and Web are used interchangeably to refer to internet services.Available servicesSome services and functions described in this user’s guide are network- or subscription-dependent. Because of this, some menus may not be available in your phone.This symbol indicates that a service or function is network or subscription-dependent.Please consult your network operator for more information about your subscription. The SIM cardWhen you register as a subscriber with a network operator, you get a SIM (Subscriber Identity Module) card. The SIM card contains a computer chip that keeps track of your phone number, the services included in your subscription, and your phonebook information.Tip: Check if your information is saved to the SIM card before you remove it from another phone. For example, phonebook entries may be saved in the phone memory.AssemblyBefore you can use your phone you need to: • Insert the SIM card.• Attach and charge the battery. See “SIM card and battery information” on page 4.Note: Always turn off the phone and detach the charger before you insert or remove a SIM card. T226.book Page 3 Thursday, July 31, 2003 2:28 PM 4 Getting started SIM card and battery informationIt may take up to 30 minutes before an icon appears when charging if the battery is completely discharged. 1. Insert the SIM card. Make sure the SIM card is placed under the metal clips. 2. Place the battery on the back of the phone with the connectors facing each other (label side up). 3. Place the back cover into the bottom of the phone and slide it up until it clicks into place. 4. Connect the charger to the phone at the flash symbol. The flash symbol on the charger plug must face upwards. 5. It may take up to 30 minutes before the battery charging icon appears in the display. Wait approximately 4 hours or until the icon indicates that the battery is fully charged. If you do not see the battery icon after this time, press any key or the center select key to activate the display. The display will “sleep” during charging. 6. Remove the charger by tilting the plug upwards.Note: You have to insert the SIM card and charge the battery before you can use the phone. T226.book Page 4 Thursday, July 31, 2003 2:28 PM Getting started 5 Holding the PhoneHold your mobile phone as you would any other telephone. While speaking into the mouthpiece, angle the phone up and over your shoulder.Internal AntennaYour phone is equipped with an internal antenna. For best reception, try to hold your phone so your hand does not cover the internal antenna.The antenna is located on the back of the phone above the back cover.Turning On the PhonePress and hold NO until you hear a tone. Enter your PIN (Personal Identity Number), if you have one for your SIM card.Your PIN is provided by your network operator. If you make a mistake while entering your PIN, delete the wrong number by pressing . If your PIN starts with the same digits as an emergency number, for example 911, the digits are not hidden with an * when you enter …

Text truncated - open the document above for the full version.

Mobile Phone T226 This is a preliminary version of the U ser's G uide 1 ContentsGetting started 3Make and receive the first call.Getting to know your phone 7Key functions, quick keys, entering letters and characters.Personalizing your phone 16Choose ring signal, theme and other settings.Calling 23Use the phonebook, call options.Setting up Mobile Internet 37Set up internet and email.Messaging 42Chat, email, text and pictures.Using Mobile Internet 50WAP browser, bookmarks. More features 54Events, alarm clock, stopwatch, timer, games.Security 58SIM card lock, phone lock.Troubleshooting 59Why doesn’t the phone work the way I want?Additional information 62Sony Ericsson Consumer web site, safe and efficient use, warranty, declaration of conformity.Icons 70What do the icons mean?Index 75 T226.book Page 1 Thursday, July 31, 2003 2:28 PM 2 Sony EricssonFirst edition (August 2003)This manual is published by Sony Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this manual.© 2003 Sony Ericsson Mobile Communications AB All rights reserved.Publication number: AE/LZT 123 1735 R2 Ple ase note: Some of the services in this manual are not supported by all networks. This also applies to the GSM International Emergency Number 112 . Please contact your network operator or service provider if you are not sure whether you can use a particular service or not. Please read the Guidelines for safe and efficient use and the Limited warranty chapters before you use your mobile phone.The marble logo is a trademark of Sony Ericsson Mobile Communications AB. Sony is a trademark of Sony Corporation and Ericsson is a trademark of Telefonaktiebolaget L M Ericsson.T9™ Text Input is a trademark or a registered trademark of Tegic Communications.T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057, United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide.Other product and company names may be the trademarks of their respective owners. Any rights not expressly granted herein are reserved. T226.book Page 2 Thursday, July 31, 2003 2:28 PM Getting started 3 Getting startedAbout this user’s guideFor ease of reference, the “Getting to know your phone” chapter gives a quick overview of the main functions of the phone, shortcuts and general information. More information and downloads are available at www.SonyEricsson.com or wap.SonyEricsson.com . Note: Throughout this manual, WAP and Web are used interchangeably to refer to internet services.Available servicesSome services and functions described in this user’s guide are network- or subscription-dependent. Because of this, some menus may not be available in your phone.This symbol indicates that a service or function is network or subscription-dependent.Please consult your network operator for more information about your subscription. The SIM cardWhen you register as a subscriber with a network operator, you get a SIM (Subscriber Identity Module) card. The SIM card contains a computer chip that keeps track of your phone number, the services included in your subscription, and your phonebook information.Tip: Check if your information is saved to the SIM card before you remove it from another phone. For example, phonebook entries may be saved in the phone memory.AssemblyBefore you can use your phone you need to: • Insert the SIM card.• Attach and charge the battery. See “SIM card and battery information” on page 4.Note: Always turn off the phone and detach the charger before you insert or remove a SIM card. T226.book Page 3 Thursday, July 31, 2003 2:28 PM 4 Getting started SIM card and battery informationIt may take up to 30 minutes before an icon appears when charging if the battery is completely discharged. 1. Insert the SIM card. Make sure the SIM card is placed under the metal clips. 2. Place the battery on the back of the phone with the connectors facing each other (label side up). 3. Place the back cover into the bottom of the phone and slide it up until it clicks into place. 4. Connect the charger to the phone at the flash symbol. The flash symbol on the charger plug must face upwards. 5. It may take up to 30 minutes before the battery charging icon appears in the display. Wait approximately 4 hours or until the icon indicates that the battery is fully charged. If you do not see the battery icon after this time, press any key or the center select key to activate the display. The display will “sleep” during charging. 6. Remove the charger by tilting the plug upwards.Note: You have to insert the SIM card and charge the battery before you can use the phone. T226.book Page 4 Thursday, July 31, 2003 2:28 PM Getting started 5 Holding the PhoneHold your mobile phone as you would any other telephone. While speaking into the mouthpiece, angle the phone up and over your shoulder.Internal AntennaYour phone is equipped with an internal antenna. For best reception, try to hold your phone so your hand does not cover the internal antenna.The antenna is located on the back of the phone above the back cover.Turning On the PhonePress and hold NO until you hear a tone. Enter your PIN (Personal Identity Number), if you have one for your SIM card.Your PIN is provided by your network operator. If you make a mistake while entering your PIN, delete the wrong number by pressing . If your PIN starts with the same digits as an emergency number, for example 911, the digits are not hidden with an * when you enter …

Text truncated - open the document above for the full version.

Beteckning' Reference GUG/NO3:198 Vår handläggare, namn, tfn .Attending to this mattet; name, te/ephone LD/SEM/GUG/NB Håkan Sjöberg +46 46 193559 Confidentiality Request Datum' Date 2003-06-26 Ert datum' Your dateEr beteckning. Your reference Receiver Federal Communications Commision Confidentiality Request Sony Ericsson Mobile Communications AB hereby requests that the FCC application materials Iisted below for Sony Ericsson mobile phone type AAA-1041011-BV (FCC ID: PY7A1041011) shall be treated as confidential and withheld from public inspection. Electrical Compone Technical .Block diagrams This material contains information relating to circuit function and complexity that could be of benefit to competitors. The material contains secrets and confidential information that Sony Ericsson does not customarily release to the public and which is otherwise not generally available to the public. Please contact the undersigned if there are any further questions or additional information needed in this matter. Type Approval Manager Sony Ericsson Mobile Communications AB Nya Vattentornet221 88 Lund Sweden Telephone: +46 46 193242 E-mail: [email protected] Sony Ericsson Mobile Communications AB Styrelsens säte: Lund Registered office: Lund Telefon' Te/ephone Nat 046-194000 Ini +4646194000 Momsnr .~A. rNo: SE556615665801 Organisationsnr. Reg No: 556615-6658 Telefax. Telefax Nat 046-194100 Ini +4646194100 Postadress' Mail SE-221 88 Lund Sweden Besöksadress. Office address Nya Vattentornet Lund diagramsnt listings descriptions

CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 112 (121) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 113 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 114 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 115 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 116 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 117 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 118 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 119 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 120 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 121 (121) PHOTOGRAPH OF THE EQUIPMENT

Confidential WORK DESCRIPTION 1(4) Document number Revision 1/1483-1/FCP 101 2336 Uen 151-86 Rev L Prepared by Date SEM/BGR/RDV KIM REETZ 7/10/03 Contents responsible if other than preparer Remarks Approved by This document is managed in metaDoc. Note: Any hard copy of this document is for reference only. Due to template and application dependencies the header and footer may fail to display correct data. It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. 151-86 KRH 101 93 Marking Drawing For T226 Type AAA -104 1011-BV. Label The Label used for marking is defined in the Manufacturing Specification 1301-SVF 930 2239. Placing The label shall be placed on the back of the telephone according to the Assembly Drawing (151 88 KRH 101 83) for the KRH. Print Layout Sony Ericsson llllllllllllllll llllllllllllllllllllllllll llllllllllllllll IMEI : 01020800-123456-0 lllllllllllllllllllllll lllllllllllllllllllllllllllllllllll A6103J000 FCC ID: PY7A 1041011 Can IC: 4170B -A 1041011 T2 2 6 D P Y 10 1 1 4 0 1 R XX AA A- 1 0 4 10 1 1 - B V AA AMade i n Sweden 03W18 8, 9, 10 Line 1 2 3 4 5 6 7 Confidential WORK DESCRIPTION 2(4) Document number Revision 1/1483-1/FCP 101 2336 Uen Rev L Definitions: Sony Ericsson trademark Sony Ericsson trademark shall be according to the corporate standard 190 89-EN/LZT 108 5347. IMEI number as bar code See below for definition of IMEI-number. The bar code shall only contain the digits of the IMEI number (no -). IMEI number as characters The IMEI number has format: 01AAAAAA-BBBBBB-C AAAAAA = 020800 BBBBBB = assigned serial number C = A check digit, from 0-9, calculated according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Serial number as bar code According to Ericsson corporate standard 102 01 – 109. Serial number as characters According to Ericsson group standard 0012- 101. Ericsson group factory number system according the Ericsson corporate standard 1120-101 Country approval mark 1 Consist of text: FCC ID: PY7A1041011 Within a frame with height > 1,5 mm. Country approval mark 2 Consist of text: IC: 4170B-A1041011 Line Text 1. Sony Ericsson Trademark 2. IMEI Number as Bar Code 3. IMEI Number as Characters 4. Serial Number as Bar Code 5. Serial Number as Characters 6. Country Approval mark 1 7. Country Approval mark 2. 8. Model number, Reduced DPY number, Type approval number GHY1 fields. 9. 10. Marking of Origin Build week Confidential WORK DESCRIPTION 3(4) Document number Revision 1/1483-1/FCP 101 2336 Uen Rev L Model Number The model number is T226 and shall be printed “T226” Reduced DPY Reduced DPY-Number See product listing below. Type Number The type number is AAA 1041011-BV and shall be printed “AAA-041011-BV” G – Field R-State identification of the CXC-module according to the Marking Data 1/151 86 for the KRC H-field R-state identification of the KRH according to the Marking data 1/151 86 for the KRH. Y 1 -field R-state identification of the ROA according to the Marking data 1/151 86 for the KRH. Marking of origin “Made in” statement should reflect the country of origin of the 1/KRC (i.e. Made in Malaysia). Build Week Build Week, in format year W XX, ie 03W18 is equal to build year 2003, Week 18. Print regulations The printing shall be well readable and permanent. Typeface OCR-B Type size min 1.1 mm Line spacing min 1.5 mm Trademark min 1.5 mm Approval Marks min 5.0 mm Product Listing Product Number Customer DPY 1401 Generic T226 DPY 1413 Generic Blue/Blue T226 DPY 1413/30 Cingular DPY 1413/26 T-Mobile Revision Table Revision Reason E Add revision table, Product list, Modify GHY, real IMEI number and change title F Removed the “prototype not for Sale” line G Added SVV number Confidential WORK DESCRIPTION 4(4) Document number Revision 1/1483-1/FCP 101 2336 Uen Rev L H New picture with correct IMEI format, FCC and IC number K Updated type description, DPY reduction in table and Ref CE mark doc. Removed CE mark at request of Compliance group. Dual band US only phones should not have CE mark. L To add the type number AAA designation back in as required by regulatory, to change the header to KRH not SVV.

CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 112 (121) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 113 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 114 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 115 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 116 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 117 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 118 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 119 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 120 (121) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 121 (121) PHOTOGRAPH OF THE EQUIPMENT

APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7A1041011 REPORT 1(85) Prepared (also subject responsible if other) No. SEM/CV/PF/P Dulce Altabella SEM/CB/D-03:0359/REP Approved Checked SEM/CV/PF/P Dulce Altabella DA A C:\Dulce\b.fcct226.doc E E E x x h h i i b b i i t t 1 1 1 1 Exhibit 11: SAR Test Report of Portable Cellular Phone FCC ID: PY7A1041011 model: T226 Date of test: Date of Report: May 13-30, 2003 June1st, 2003 Laboratory: SAR Testing Laboratory Sony Ericsson Mobile Communications, Inc.7001 Development Drive, P.O. Box 13969, Research Triangle Park, NC, 27709, USA Tested by: Dulce Altabella Staff Engineer, Antenna Development Group Test Responsible: Dulce Altabella Staff Engineer, Antenna Development Group Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following electromagnetic exposure tests: Specific Absorption Rate (SAR) Dielectric parameters RF power measurement On the following types of products: Wireless communications devices.A2LA certificate #1650-01 Statement of Compliance: Sony Ericsson Mobile Communications, Inc declares under its sole responsibility that portable cellular telephone FCC ID PY7A1041011 model T226 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) © Sony Ericsson Mobile Communications, Inc. 2003 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Sony Ericsson Mobile Communications encourages all feedback, both positive and negative, on this test report. APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7A1041011 REPORT 2(85) Prepared (also subject responsible if other) No. SEM/CV/PF/P Dulce Altabella SEM/CB/D-03:0359/REP Approved Checked SEM/CV/PF/P Dulce Altabella DA A C:\Dulce\b.fcct226.doc E E E x x h h i i b b i i t t 1 1 1 1 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 3 2.1 Antenna description 3 2.2 Device description 3 3. Test Equipment Used 3 3.1 Dosimetric System 3 3.2 Additional Equipment 4 4. Electrical parameters of the tissue simulating liquid 4 5. System Accuracy Verification 5 6. Test Results 6 6.1 Head Adjacent Test Results 6 6.2 Body-Worn Test Results 9 References 12 Appendix 1: SAR distribution comparison for system accuracy verification 13 Appendix 2: SAR distribution plots for Phantom Head Adjacent Use 23 Appendix 3: SAR distribution plots for Body Worn Configuration 39 Appendix 4: Probe Calibration Certificate 64 Appendix 5: Measurement Uncertainty Budget 72 Appendix 6: Photographs of the device under test 76 APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7A1041011 REPORT 3(85) Prepared (also subject responsible if other) No. SEM/CV/PF/P Dulce Altabella SEM/CB/D-03:0359/REP Approved Checked SEM/CV/PF/P Dulce Altabella DA A C:\Dulce\b.fcct226.doc E E E x x h h i i b b i i t t 1 1 1 1 1. Introduction The Sony Ericsson SAR Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone FCC ID PYA1041011 model T226. The Specific Absorption Rate (SAR) of this product was measured. The applicable RF safety guidelines and the SAR measurement specifications used for the test are described in [1]. 2. Description of the Device Under Test 2.1 Antenna description Type Internal antenna Location Inside the back cover, near the top Width 32 mm Dimensions Length 30 mm Configuration Patch antenna 2.2 Device description FCC ID Number / Device Model PY7A1041011 / T226 Serial number A6101TVF63 Mode(s) of Operation GSM 800 GSM 1900 Modulation Mode(s) TDMA TDMA Target Value for Maximum Output Power Setting 32 dBm 30 dBm Factory Tolerance Window in Power Setting +0.8/ -1.0 dB ± 1.0 dB Duty Cycle 1/8 1/8 Transmitting Frequency Rang(s) 824-849 MHz 1850-1910 MHz Production Unit or Identical Prototype (47 CFR §2..908)Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled 3. Test Equipment Used 3.1 Dosimetric System The Sony Ericsson SAR Laboratory utilizes a Dosimetric Assessment System (Dasy3™ v3.1d) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerland. The overall RSS uncertainty of the measurement system is ±10.59% (K=1) with an expanded uncertainty of ±21.17% (K=2). The measurement uncertainty budget is given in Appendix 5. The list of calibrated equipment used for the measurements is shown in the following table. APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7A1041011 REPORT 4(85) Prepared (also subject responsible if other) No. SEM/CV/PF/P Dulce Altabella SEM/CB/D-03:0359/REP Approved Checked SEM/CV/PF/P Dulce Altabella DA A C:\Dulce\b.fcct226.doc E E E x x h h i i b b i i t t 1 1 1 1 Description Serial Number Cal Due Date DASY3 DAE V1 416 11-Dec-2003 DASY3 DAE V1 417 11-Dec-2003 E-Field Probe ETDV6 1583 19-Dec-2003 E-Field Probe ETDV6 1586 20-Jun-2003 Dipole Validation Kit, DV835V2 428 14-Jan-2004 S.A.M. Phantom used for 835MHz 1031 Dipole Validation Kit, DV1800V2 217 14-Jan-2004 Dipole Validation Kit, DV1900V2 537 14-Jan-2004 S.A.M. Phantom used for 1900MHz 1030 3.2 Additional Equipment Description Serial Number Cal Due Date Signal Generator HP8648C 3537A01598 09-Sep-2003 Power Meter 437B 3125U113481 16-May-2004 Power Meter 437B 3110A05257 16-May-2004 Power Sensor - 8482H MY41090240 16-May-2004 Power Sensor - 8482H MY41090241 16-May-2004 Network Analyzer HP8752C 3410A3105 23-Aug-2003 Dielectric Probe Kit HP8507…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 SaarbrückenTelefon: +49 (0)681 598-9100Telefax: -9075 RSC11issue test report consist of 121 PagesPage 1 (121) BLUETOOTH TM is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM Recognized by the Federal Communications Commission FCC–Identification Number: 90462 TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 166/98 Independent ETSI compliance test house ETSI Accredited Bluetooth™ Test Facility (BQTF) Test report no.: 2_3287-01-01/03 FCC Part 24/22/15 AAB-1041011-BV FCC ID: PY7A1041011 IC: 4170B-A1041011 CETECOM – ICT Services GmbH Untertürkheimerstr. 6-10 66117 Saarbrücken, Germany Telephone: + 49 (0) 681 / 598-0 Fax: + 49 (0) 681 / 9075 CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 2 (121) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test report 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. 1.2Testing laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telefone: + 49 681 598 - 9100 Telefax : + 49 681 598 - 9075 E-mail: [email protected] Internet: www.cetecom-ict.de Accredited testing laboratory The Test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025. DAR registration number: TTI-P-G-166/98 Listed by: Federal Communications Commission (FCC) Identification/Registration No : 90462 Accredited Bluetooth TM Test Facility (BQTF) BLUETOOTH TM is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 3 (121) 1.3Details of applicant Name : Sony Ericsson Mobile Communication AB Street : Nya Vattentornet City : 22188 Lund Country : Sweden Telephone : +46-46-193-242 Telefax : +46-46-193-295 Contact : Mr. Bo Johansson Telephone : +46-46-193-242 e-mail: 1.4Application details Date of receipt of application : 2003-05-14 Date of receipt of test item : 2003-05-16 Date of test : 2003-05-16/19/20 1.5Test item Type of equipment : Triple Band GSM Mobile Phone (PCS 850/1800/1900 MHz) with Bluetooth ® transmitter Type designation:AAB-1041011-BV Manufacturer:Applicant Street: City: Country: Serial number:IMEI : 001003.00.064406.5 Additional informations: : Frequency:1850.2 – 1909.8 MHz and 824.2 – 848.8 MHz Type of modulation:300KGXW Number of channels :300 (PCS1900) and 125 (PCS850) Antenna:Integral antenna Power supply:3,7V DC NiMH Output power GSM 850:cond.: 32.72 dBm Peak , ERP: 23.7 dBm (Burst); EIRP: 25.8 dBm (Burst) Output power GSM 1900 :cond : 30.77 dBm Peak , ERP: 30.22 dBm (Burst); EIRP: 32.32 dBm (Burst) Type of equipment:Temperature range : -30°C - +60°C FCC – ID: PY7A1041011 IC : 4170B-A1041011 Hardware:P3 Software:R1A034 1.6Test standards: FCC Part 24, 22 FCC Part 15 CETECOM ICT Services GmbH Test report no..: 2_3287-01-01/03Issue Date: 2003-06-10Page 4 (121) 2 Technical test For Part 24/22 we use the substitution method ( TIA/EIA 603). All measurements in this report are done in GSM mode.…
