PY7A1042061GSM 850/1900 mobile phone

T250a User guide 2 Congratulations on your purchase of the Sony Ericsson T250a. For additional phone content, go towww.sonyericsson.com/fun. Register now to get free online storage and special offers at www.sonyericsson.com/myphone. For product support, go to www.sonyericsson.com/support. Instruction symbols The following instruction symbols appear in this User guide: >Use the navigation key to scroll and select. Press the navigation key up. Press the navigation key down. Press the navigation key to the left. Press the navigation key to the right. Note Tip Warning Indicates that a service or function is network- or subscription-dependent. All menus or functions may not be available in your phone. Consult your network operator for more information. 3 Prepare the phone To insert the SIM card and battery 1Remove the battery cover. Slide the SIM card into its holder with the contacts facing down. 2Insert the battery with the label side up and the connectors facing each other. Replace the battery cover as shown in the picture. Do not force the battery cover into place. Slide the battery cover carefully onto the phone and close it. 4 Charge the battery 1The phone battery is partly charged when you buy it. Connect the charger to the phone. It takes approximately 2.5 hours to fully charge the battery. Press a key to illuminate the screen. 2To remove the charger, tilt the plug upwards. You can use the phone during charging. You can charge the battery for more or less than 2.5 hours. Interrupted charging will not damage the battery. 2.5 h 5 Turn the phone on 1Press and hold down . 2Enter your PIN if requested. To correct mistakes, select Delete. 3Select OK. 4Select a language. 5Enter the time and date and select Save. To turn the phone off •Press and hold down . Standby After you have turned the phone on and entered your PIN, the name of your operator appears on the screen. This is called standby. You can now make and receive calls. 6 SIM and PIN SIM card The SIM (Subscriber Identity Module) card, which you get from your network operator, contains information about your subscription. Always turn off your phone and detach the charger before you insert or remove the SIM card. PIN code You may need a PIN (Personal Identification Number) to activate the services in your phone. Your PIN is supplied by your network operator. Each PIN digit appears as *, unless it starts with emergency number digits, for example, 112 or 911. You can call an emergency number without entering a PIN. You can save contacts on the SIM card before removing it from your phone. Contacts may also be saved in the phone memory. See Contacts on page 17. If you enter the wrong PIN three times in a row, PIN blocked. Enter PUK provided by your operator. appears. To unblock it, you need to enter your PUK (Personal Unblocking Key). 7 Menu overview ExtrasInternetFM radio Calendar Timer Stopwatch Calculator My files My games Homepage Bookmarks Go to URL Edit bookmark Show pictures Push access Push inbox Clear cache Internet profile CameraMessagingAlarms Take pic. Camera pics Slide show Text message Picture message Settings CallsContactsSettings Call list Time and cost Call settings View contacts Find contact Add contact My number Voicemail Delete contacts Speed dial Copy all contacts Send contacts Settings Sound & alerts Wallpaper Theme Time and date Language Select network Infrared port Advanced Phone status Some menus and icons in this document may vary depending on operator, network or subscription. 8 Phone overview Selection key Volume keys Navigation key with shortcuts. Call key Keylock Infrared port End key, On/off key Stereo handsfree and battery charger connector 9 Network coverage The network bars show the strength of the GSM network in your area. Try moving to another location if you have trouble calling and network coverage is poor. No network means you are not in range of a network. Battery status = Good network coverage = Average network coverage = The phone battery is fully charged = The phone battery is empty Battery status Network coverage 10 Screen icons These icons may appear on the screen. Icon Description Battery icon. A completely green icon means that the battery is fully charged You have missed a call Divert calls is activated The phone is set to silent The keypad is locked You have received a new text message You have received a new picture message An alarm is activated Ongoing call The loudspeaker is on The FM radio is playing The Infrared port is activated 11 Shortcuts From standby you can use the navigation keys to go directly to a function: •Press to write a text or picture message. •Press to go to the camera. •Press to play the FM radio. •Press to go to your contacts. To navigate the menus 1From standby select Menu. 2Press , , , and select amenu. To go back one step in the menu •Select Back. To return to standby •Press . To lock the keypad •Press and select Lock keys. To unlock the keypad •Press and select Unlock. To set the phone to silent •Press and hold down . To call your voicemail service •Press and hold down . 12 Calling You must turn on the phone and be within range of a network. To make a call 1From standby enter the area code and phone number. 2Press . To end a call •Press . To answer a call •Press . To reject a call •Press . To turn off the ringtone when receiving a call •Select Silent to turn off the ringtone without answering the call. To turn the loudspeaker on during a call •Select Options > Turn on speaker. To change the ear speaker volume during a call •Press or . Do not hold the phone to your ear when using the loudspeaker. This could damage your hearing. 13 To make international calls 1From standby press and hold down until a + sign appears on the screen. 2Enter the country code, area code (without the first zero) and phone number. 3Press . To view a missed call When Missed call is displayed, select Details. To call back scroll to the number and press . Call list You can view information about…

Text truncated - open the document above for the full version.

Sony Ericsson Confidentiality Request Datum -Date Beteckning - Reference 2007-07-09 BGL107:278 s EKS~MW~ KgfltTb?kn"@8ffth#e%=$mb83phone Ert datum - Your date Er beteckning a Your reference Receiver Federal Communications Commission Subject: Request for Confidentiality FCC ID: PY7A1042061 To Whom It May Concern: In accordance with 50.459 of CFR 47, Sony Ericsson Mobile Communications AB requests confidentiality for the below listed items for our mobile phone type AAA- 1042061 -BV, FCC ID: PY7A1042061: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. OperationallTechnicaI Descriptions These items contain detailed system and equipment description and related information about the product which Sony Ericsson Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Ericsson Mobile Communications AB also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Best Regards, Kent Lorentzon Development Engineer - Global Type Approvals Sony Ericsson Mobile Communications AB Sony Ericsson Mobile Communications AB Styrelsens sate: Lund Momsnr - KA.TNo: SE556615665801 Registered office: Lond Organisationsnr ' Reg No: 55661 5-6658 Postadress ' Mail Besoksadress - Office address Telefon ' Telephone Telefax ' Jelefax SE-221 88 Lund Nya Vattentornet Nat 046-1 9 40 00 Nat 046-1 9 41 00 Sweden Lund Int +46 46 19 40 00 Int +46 46 19 41 00

CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-06-02/07 2007-07-17 Page 21 of 26 8 Photographs of t he E UT Photo documentation Photo 4: CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-06-02/07 2007-07-17 Page 22 of 26 Photo 5: Photo 6: CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-06-02/07 2007-07-17 Page 23 of 26 Photo 7: Photo 8: CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-06-02/07 2007-07-17 Page 24 of 26 Photo 9: Photo 10:

Company Internal MARKING DRAWING 1 (4) Prepared (also subject responsible if other) No. SEM/BGLDB, Patrik Jonsson 151 86–SVV 107 754/1 Uen Approved Checked Date Rev Reference SEM/BGLDB (Patrik Jonsson) 2007-06-19 A 5 Approved according to 000 21–LXE 107 42/1 T250a, KRH-lbl, Type nr: AAA-1042061-BV, Made in... 1 General information The format of the label is based on a label SVF 930 2658. If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. All bar codes, when applicable, are according to Ericsson corporate standard 102 01–109 Uen. All bar codes shall fulfil minimum print quality C according to ANSI X3.182-1990 as stated in Ericsson corporate standard 102 01–1003 Uen. No bar codes are allowed to be closer to a label edge than 2 mm! (quiet zone). “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. The label shall be placed on the back of the telephone according to the Assembly Drawing (151 88-) for the KRH. 2 Printing information Content Format Line 1a (3,0/1,0) Sony Ericsson stylized name. Graphics, height 1,4 mm. According to 190 89–EN/LZT 108 5347 Line 1b (3,0/13,0) Model name, “T250a” Text, height 1,2 mm. Line 2a (5,0/1,0) Type number of the phone (KRH), “Type: AAA-1042061-BV”. Text, height 1,2 mm. Line 2b (5,0/18,0) ROA and R-state identification field, if applicable; “FG” Text, height 1,2 mm. According to the 3/151 86- document in the 1095- for the SVV, if any. Line 2c (4,5/20,5) Repair week, if applicable. “Ry’W’ww” (y = year, ww = week) Text, height 1,2 mm. Line 3a (7,0/1,0) Product number of the DPY kit in which the phone is packed. Printed without R-state. “DPY 101 0000/000” Text, height 1,2 mm. Line 3b (7,0/13,0) Production week (flash), “yy’W’ww” (yy = year, ww = week) Text, height 1,2 mm. Company Internal MARKING DRAWING 2 (4) Prepared (also subject responsible if other) No. SEM/BGLDB, Patrik Jonsson 151 86–SVV 107 754/1 Uen Approved Checked Date Rev Reference SEM/BGLDB (Patrik Jonsson) 2007-06-19 A 5 Line 3c (7,0/20,0) Location code of where the phone is flashed, if applicable, “XXX” Text, height 1,2 mm. Line 4a (9,0/1,0) Country approval mark 1 “FCC ID: PY7A1042061” Text, height 1,2 mm. Line 4b (9,0/15,0) Country approval mark 2 “IC: 4170B-A1042061” Text, height 1,2 mm. Line 5 (12,0/1,0) Line 6a in bar code. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 6a (14,0/1,0) Supplier’s identification for trace- ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,2 mm. Defined by supplier. Line 6b (14,0/13,0) Actual electronic serial number (IMEI) of the phone (KRH), “00000000-000000-0” Text, height 1,2 mm. In the format TAC-SNR-CD. TAC and SNR derived from the 3/151 86- document in the 1095- for the SVV. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 7 (17,0/1,0) Line 6b in bar code (only actual number, without data identifier). Bar code, height 2,0 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. Line 8 (20,0/1,0) Marking of origin. The line shall be printed as stated in chapter 3 in this document. Text, height 1,2 mm. Company Internal MARKING DRAWING 3 (4) Prepared (also subject responsible if other) No. SEM/BGLDB, Patrik Jonsson 151 86–SVV 107 754/1 Uen Approved Checked Date Rev Reference SEM/BGLDB (Patrik Jonsson) 2007-06-19 A 5 3 Marking of Origin 3.1 Content “Made in Xxx”; “Xxx” = actual country of production of the included telephone, in English 4 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 4.1 Conceptual picture double underlined = major changes since last revision. Company Internal MARKING DRAWING 4 (4) Prepared (also subject responsible if other) No. SEM/BGLDB, Patrik Jonsson 151 86–SVV 107 754/1 Uen Approved Checked Date Rev Reference SEM/BGLDB (Patrik Jonsson) 2007-06-19 A 5 4.1 Label placement To find the label follow these steps: 1. Remove the cover on the rear side of the product. 2. Remove the battery. 3. The label is located behind the battery. Rear side of the phone Place for battery Label placement

CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-06-02/07 2007-07-17 Page 25 of 26 Photo 11: Photo 12: CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-06-02/07 2007-07-17 Page 26 of 26 Photo 13: Photo 14:

Company Internal REPORT 1 (11) Prepared (also subject responsible if other) No. LD/SEMC/BGLIM Hamid Kami Shirazi BGLI07:274 Approved Checked Date Rev Reference LD/SEMC/BGLIMC Peter Lindeborg 070707 070707 A File Report issued by Accredited SAR Laboratory For PY7A1042061 (T250a) Date of test: 2 nd - 3 rd July 2007 Laboratory: Sony Ericsson SAR Test Laboratory Sonyericsson Mobile Communications AB Nya Vattentornet SE-221 82 LUND, Sweden Testing Engineer: Hamid Kami Shirazi [email protected] +46 46232644 Testing Approval Peter Lindeborg [email protected] +46 462126180 Statement of Compliance Sony Ericsson Mobile Communications AB declares under its sole responsibility that the product Sony Ericsson Type AAA-1042061-BV; FCC ID: PY7A1042061; IC:4170B-A1042061 to which this declaration relates, is in conformity with the appropriate RF exposure standards recommendations and guidelines. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (None) This laboratory is accredited to ISO/IEC 17025 (SWEDAC accreditation no. 1847). Laboratories are accredited by the Swedish Board for Accreditation and Conformity Assessment (SWEDAC) under the terms of Swedish legislation. The accredited laboratory activities meet the requirements in SS-EN ISO/IEC 17025 (2005). This report may not be reproduced other than in full, except with the prior written approval of the issuing laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Sony Ericsson encourages all feedback, both positive and negative, on this report. © Sony Ericsson Mobile Communication AB, 2007 Company Internal REPORT 2 (11) Prepared (also subject responsible if other) No. LD/SEMC/BGLIM Hamid Kami Shirazi BGLI07:274 Approved Checked Date Rev Reference LD/SEMC/BGLIMC Peter Lindeborg 070707 070707 A File 1 Table of contents 2 INTRODUCTION..................................................................................................................................................................3 3 DEVICE UNDER TEST........................................................................................................................................................3 3.1 A NTENNA DESCRIPTION.......................................................................................................................................................3 3.2 D EVICE DESCRIPTION...........................................................................................................................................................3 4 TEST EQUIPMENT ..............................................................................................................................................................4 4.1 D OSIMETRIC SYSTEM............................................................................................................................................................4 4.2 A DDITIONAL EQUIPMENT.....................................................................................................................................................4 5 ELECTRICAL PARAMETERS ON THE TISSUE SIMULATING LIQUID ..............................................................4 6 SYSTEM ACCURACY VERIFICATION..........................................................................................................................5 7 SAR MEASUREMENT UNCERTAINTY .........................................................................................................................5 8 TEST RESULTS ....................................................................................................................................................................7 9 REFERENCES .......................................................................................................................................................................8 10 APPENDIX .............................................................................................................................................................................9 10.1 P HOTOGRAPHS OF THE DEVICE UNDER TEST....................................................................................................................9 10.2 D EVICE POSITION ON SAM TWINS PHANTOM...............................................................................................................11 10.3 A TTACHMENTS...............................................................................................................................................................12 Company Internal REPORT 3 (11) Prepared (also subject responsible if other) No. LD/SEMC/BGLIM Hamid Kami Shirazi BGLI07:274 Approved Checked Date Rev Reference LD/SEMC/BGLIMC Peter Lindeborg 070707 070707 A File 2 Introduction In this test report, compliance of the Sony Ericsson PY7A1042061 (T250a) portable telephone with RF safety guidelines is demonstrated. The applicable RF safety guidelines and the SAR measurement specifications used for the test are described in the SAR Measurement Specifications of Wireless Handsets [1]. 3 Device under Test 3.1 Antenna Description Type Internal antenna Location Inside, Back, at the bottom Max length 32 mm Dimensions Max width 15 mm Configuration PIFA 3.2 Device description Device model PY7A1042061(T250a) Serial number TP80001760 (#7987) Mode GSM1900 GSM850 Crest Factor 8.3 8.3 Multiple Access Scheme TDMA TDMA Ch512 Ch661 Ch810 Ch128 Ch190 Ch251 Maximum Output Power Setting (dBm) 29.0 28.7 29.0 32.5 33.0 33.0 Factory Tolerance in Power Setting ±0.5dB ±0.5dB Maximum Peak Output Power (dBm) 29.5 29.2 29.5 33.0 33.5 33.5 Data and connectivity GPRS Class: 8 ; Capability Class: B Ch512 Ch6…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Untertürkheimer Straße 6-10 . D-66117 Saarbrücken Phone: +49 (0) 681-598-0 Fax:-9075 RSC-Laboratory 2007-07-17 Page 1 of 62 Accredited testing-laboratory DAR registration number: DAT-P-176/94-D1 Federal Motor Transport Authority (KBA) DAR registration number: KBA-P 00070-97 Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463A-1 (IC) Certification ID: DE 0001 Accreditation ID: DE 0002 Accredited Bluetooth ® Test Facility (BQTF) The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Cetecom ICT is under license Test report no. : 2-4576-06-02/07 Type identification : AAA-1042061-BV Applicant : Sony Ericsson Mobile Communications AB FCC ID : PY7A1042061 IC Certification No : 4170B-A1042061 Test standards : 47 CFR Part 22 47 CFR Part 24 RSS - 132 Issue 2 RSS - 133 Issue 3 CETECOM ICT Services GmbH Test report no.: 2-4576-06-02/07 2007-07-17 Page 2 of 62 Table of contents 1 G e n e r a l i n f o r m a t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . 3 1.1 Notes ...................................................................................................................................................................3 1.2 Testing laboratory ...............................................................................................................................................4 1.3 Details of applicant .............................................................................................................................................4 1.4 Application details ..............................................................................................................................................4 2 T e s t s t a n d a r d / s : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 5 3 T e c h n i c a l t e s t s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 6 3.1 Details of manufacturer .......................................................................................................................................6 3.1.1 Test item......................................................................................................................................................6 3.2 Test Setup............................................................................................................................................................7 4 S t a t e m e n t o f C o m p l i a n c e . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . 8 4.1 Summary of Measurement Results......................................................................................................................8 4.1.1 PCS 1900.....................................................................................................................................................8 4.1.2 GSM 850 .....................................................................................................................................................8 5 M e a s u r e m e n t s a n d r e s u l t s . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . 9 5.1 PART PCS 1900 .................................................................................................................................................9 5.1.1 RF Power Output.........................................................................................................................................9 5.1.2 Frequency Stability ...................................................................................................................................13 5.1.3 Radiated Emissions ...................................................................................................................................16 5.1.4 Receiver Radiated Emissions ....................................................................................................................23 5.1.5 Conducted Spurious Emissions .................................................................................................................26 5.1.6 Block Edge Compliance............................................................................................................................29 5.1.7 Occupied Bandwidth .................................................................................................................................31 5.2 PART GSM 850 ................................................................................................................................................35 5.2.1 RF Power Output.......................................................................................................................................35 5.2.2 Frequency Stability ...................................................................................................................................38 5.2.3 Radiated Emissions ...................................................................................................................................41 5.2.4 Receiver Radiated Emissions ....................................................................................................................48 5.2.5 Conducted Spurious Emissions .....................…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Untertürkheimer Straße 6-10 . D-66117 Saarbrücken Phone: +49 (0) 681-598-0 Fax:-9075 RSC-Laboratory 2007-07-17 Page 1 of 26 Accredited testing-laboratory DAR registration number: DAT-P-176/94-D1 Federal Motor Transport Authority (KBA) DAR registration number: KBA-P 00070-97 Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463A-1 (IC) Certification ID: DE 0001 Accreditation ID: DE 0002 Accredited Bluetooth ® Test Facility (BQTF) The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Cetecom ICT is under license Annex to Test report no. : 2-4576-06-02/07 Type identification : AAA-1042061-BV Applicant : Sony Ericsson Mobile Communications AB FCC ID : PY7A1042061 IC Certification No : 4170B-A1042061 Test standards : 47 CFR Part 22 47 CFR Part 24 RSS - 132 Issue 2 RSS - 133 Issue 3 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-06-02/07 2007-07-17 Page 2 of 26 Table of contents 1 G e n e r a l i n f o r m a t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . 3 1.1 Notes ...................................................................................................................................................................3 1.2 Testing laboratory ...............................................................................................................................................4 1.3 Details of applicant .............................................................................................................................................4 1.4 Application details ..............................................................................................................................................4 2 T e c h n i c a l t e s t s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 5 2.1 Details of manufacturer .......................................................................................................................................5 2.2 Test item(s) and test configuration ......................................................................................................................5 3 S u m m a r y o f M e a s u r e m e n t R e s u l t s a n d l i s t o f a l l p e r fo r m e d t e s t c a s e s . . . . . . . . . . . . . . . . . . . . . . . . . . 6 4 M e a s u r e m e n t s a n d r e s u l t s . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . 7 5 A n n e x A : F C C P a r t 1 5 S u b p a r t B . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 8 5.1 Conducted Limits ................................................................................................................................................8 5.2 Receiver spurious emission radiated (Idle mode) .............................................................................................11 6 T e s t e q u i p m e n t a n d a n c i l l a r i e s u s e d f o r t e s t s . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 1 5 7 P h o t o g r a p h s o f t h e T e s t S e t - u p . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . 1 8 8 P h o t o g r a p h s o f t h e E U T . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . 2 1 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-06-02/07 2007-07-17 Page 3 of 26 1 General infor mat ion 1 . 1 N o t e s The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. Test laboratory manager: 2007-07-17 Jakob Reschke Date Name Signature Technical responsibility for area of testing: 2007-07-17 Michael Berg Date Name Signature CETECOM…

Text truncated - open the document above for the full version.
