PY7A3880069GSM 850/900/1800/1900 GPRS / EDGE / UMTS FDD1&8 / HSPA mobile phone with Bluetooth, WLAN 802.11bg, GPS/A-GPS, FM receiver

X10 mini User guide Important information Please read the Important information leaflet before you use your mobile phone. Some of the services and features described in this User guide are not supported in all countries/regions or by all networks and/or service providers in all areas. Without limitation, this applies to the GSM International Emergency Number 112. Please contact your network operator or service provider to determine availability of any specific service or feature and whether additional access or usage fees apply. Experience more. Discover how. Need help? Get more, do more. Miss nothing. Visit www.sonyericsson.com/xperiax10mini to learn more about your phone. User guide in the phone An extended User guide is available in your phone. The extended User guide and more information is also available at www.sonyericsson.com/support. To access the User guide in your phone 1 From the Home screen, drag upwards. 2 Find and tap User guide . 2 Getting started To insert the SIM card and the memory card 1 2 1 Remove the cover. 2 Slide the SIM card with the gold-coloured contacts facing down and memory card with the gold-coloured contacts facing up. To attach the cover 1 2 • Attach the cover to the back of the phone. 3 To turn on the phone 1 Press and hold down the key on the top of the phone. 2 Enter your SIM card PIN, if requested, and select OK. 3 At first startup, follow the instructions in Setup guide. Your PIN is supplied by your network operator. If you want to correct a mistake made while entering your SIM card PIN, press . To turn off the phone 1 Press and hold until the options menu opens. 2 In the options menu, tap Power off. 3 Tap OK. To activate the screen • Press one of the hardware keys on the front of the phone. The screen is also activated when you receive a call. To lock the screen • Press . Starting your phone for the first time The first time you start your phone, a setup guide lets you enter essential phone settings, import contacts, and set up your email and online services accounts. You can also access the setup guide later from the phone settings. To set the language 1 Scroll through the available languages list. 2 Tap the language you want to use in your phone. The language is marked. 3 Tap Save. 4 Internet and messaging settings In order to send messages and use the Internet you will need a 2G/3G mobile data connection. For most mobile phone networks and operators, settings for messaging and the Internet will be preinstalled on the phone or downloaded to your phone the first time you turn on the phone with a SIM card inserted. If not, you can go to www.sonyericsson.com/support from your computer to download the settings to your phone. To import contacts from the SIM card 1 From the setup guide, tap Import contacts. 2 When you are asked to confirm if you want to import the contacts from the SIM card to the phone, tap Yes. By using Sony Ericsson Sync you can synchronise contacts, bookmarks and calendar events between your phone and your Sony Ericsson account. This way you can transfer information from your old phone to the Sony Ericsson account, and then transfer it to your new phone. You can set up a Sony Ericsson account from the Sony Ericsson Sync application in your phone, or by going to www.sonyericsson.com/user from your computer. To set the time and date 1 From the setup guide, tap Time & date. 2 Unmark the Automatic checkbox, if it is marked. 3 Tap Set date or Set time. 4 Tap or to adjust the date or hour and minute. 5 Tap Set. While setting time, you can shift between 12-hour and 24-hour format. If you want to use AM and PM, you have to unmark Use 24-hour format. 5 To create a new Google™ account in your phone 1 From the setup guide, tap Google account. 2 Tap Next. 3 Tap Create. 4 Enter your personal information and desired Google™ username. Tap Next. 5 Enter and confirm your password. Tap Next. 6 Select a security question and enter a personal answer that only you know. You can also enter a secondary email address to which your Google™ account information could be sent in case you forget the information. Tap Next. 7 To agree to the Google™ Terms of service, tap I agree, Next. 8 Enter the security word displayed as an image. Tap Next. 9 Mark the checkboxes to allow the additional Google™ services, or leave them blank if you do not agree to use these services. Tap Next. 10 Tap Finish setup. Your new Google™ account has now been created and set up to be used with the Google™ services in your phone. To set up an existing Google™ account in your phone 1 From the setup guide, tap Google account. 2 Tap Next. 3 Tap Sign in. 4 Enter your Google™ username and password. Tap Sign in to continue. 5 Mark the checkboxes to allow the additional Google™ services, or leave them blank if you do not agree to use these services. Tap Next. 6 6 Tap Finish setup. Your Google™ account has now been set up in your phone. In most cases, your Google™ username is the first part of your Google™ email address. To set up an email account 1 From the setup guide, tap Email. 2 Tap Email address, enter your email address and tap Next. 3 Enter your password and tap Done. 4 Tap Continue. 5 If the phone cannot download your email account settings automatically, enter the account settings manually. If you need to enter the settings manually, contact your email service provider for the correct email account settings. For example, you need to know if the account type is POP3 or IMAP. Sony Ericsson Timescape™ settings Sony Ericsson Timescape™ collects all the communication events at one place and keeps you updated with messages, missed calls from your contacts and friends in Facebook™ and Twitter™. To set up a Facebook™ account 1 From the setup guide, tap Facebook. 2 Tap Username, enter your username and tap Next. 3 Enter your password and tap Done. To set up a Twitter™ account 1 From the setup guide, tap Twitter. 2 Tap Username, enter your username and tap Next. 7 3 Enter your password and tap Do…

Text truncated - open the document above for the full version.

Sony Ericsson Confidentiality Request 2010-03-26 CVVA10:098 SEMC/CVVALG Afrah Sadiq +46 1080 12250 Receiver Federal Communications Commission Subject: Request for Confidentiality FCC ID: PY7A3880069 To Whom It May Concern: In accordance with §0.459 of CFR 47, Sony Ericsson Mobile Communications AS requests confidentiality for the below listed items for our mobile phone type AAD­ 3880069-BV, FCC 10: PY7A3880069: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational/Technical Descriptions These items contain detailed system and equipment description and related information about the product which Sony Ericsson Mobile Communications AS considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Ericsson Mobile Communications AS also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Best Regards, Afrah Sadiq Development Engineer - Global Type Approval Sony Ericsson Mobile Communications AB Sony Ericsson Mobile Communications AS Styrelsens sate: Lund Mornsnr' II.A. T.No: SE556615665801 Registered office: Lund Organisationsnr' Reg No: 556615-6658 Postadress • Mail Besbksadress • Office address Telefon • Telephone Telefax • Telefax SE-221 88 Lund Nya Vattentornet Nat 010-80 00000 Nat 010-80 02040 Sweden Lund Int +46 10 80 00000 Int +46 10 80 02040

CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 20 of 36 9 Photographs of t he E UT Photo documentation: External photos Photo 1: Photo 2: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 21 of 36 Photo 3: Photo 4: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 22 of 36 Photo 5: Photo 6:

1 (3) Company Internal MARKING DRAWING Prepared (also subject responsible if other) No. SEM/CVVGP, Anna Englund 1234-2226 Uen Approved Checked Date Rev Reference SEM/CVVGP, Anna Englund 2010-02-11 1 18 E10i, Mobile Phone label content, Made in... 1 General information Mobile Phone label part no • 1227-6777 Mobile Phone label content part no • 1234-2225 Bar code • Print quality: according to COSMETIC GUIDELINE – Bar code labels document 1222-6072 Uen • Quiet zone: No bar codes are allowed to be closer to a label edge than 2 mm! Text If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. Coordinates “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. MLCI= Main Label Content Information Document 2 Printing information Content Format Line 1 (3,0/2,0) Line 1 in bar code, according to line 2a. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 2 a (4,0/2,0) Supplier’s identification for trace-ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,2 mm. Defined by supplier. Line 2 b (4,0/16,0) Actual electronic serial number (IMEI) of the Mobile Phone, “00000000-000000-0” Text, height 1,2 mm. In the format TAC-SNR-CD. TAC and SNR derived from pos 500 in BOM. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 3 (6,5/2,0) Line 3 in bar code, according to line 2b (only actual number, without data identifier). Bar code, height 2,0 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. Line 4a (7,8/2,0) Sony Ericsson stylized name. Graphics, height 1,4 mm. According to 1200-1925 Line 4b (7,80/18,0) Model Name “E10i” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 5a (9,2/2,0) Product number of the Sales Item in which the phone is packed, if applicable. “SI XXXX-XXXX” Text, height 1,2 mm. Line 5b (9,2/15,0) Location code of where the phone is flashed, if applicable, “XXX” Text, height 1,2 mm. Company Internal MARKING DRAWING 2 (3) Prepared (also subject responsible if other) No. SEM/CVVGP, Anna Englund 1234-2226 Uen Approved Checked Date Rev Reference SEM/CVVGP, Anna Englund 2010-02-11 1 18 Line 5c (9,2/16,5) Production week (flash), “yy’W’ww” (yy = year, ww = week) Text, height 1,2 mm. Line 5d (9,2/22,2) Repair week, if applicable. “Ry’W’ww” (y = year, ww = week) Text, height 1,2 mm. Line 6a (10,8/2,0) Typenumbe r: “AAD-3880069-BV” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 6b (10,8/17,5) HW & SW identification field, if applicable; “FFGG” Text, height 1,2 mm. According to Type-testing report under Product Model Specifying Documents Line 7 (13,1/2,0) FCC ID : ” PY7A3880069” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 8 (13,8/2,0) “IC:4170B-A3880069” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 9 (15,0/2,0) Marking of origin. “Made in Xxx”; “Xxx” = actual country of production of the included telephone, in English Text, height 1,2 mm. Line 10 (16,0/19,2) WEEE trashcan without bar symbol Graphics, min. height 5mm, according to 1202-5537. Line 11a (20,1/4,3) CE approval symbol Graphics, height 5 mm. According to 1210-0131. Line 11b (20,1/12,0) The notified body number “0682” Text, height 1,2 mm. Line 11c (20,1/13,9) “Alert Symbol” Graphics, height 5 mm According to 1001-5859 3 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 3.1 Conceptual picture double underlined = major changes since last revision. Company Internal MARKING DRAWING 1 (3) Prepared (also subject responsible if other) No. SEM/CVVGP, Anna Englund 1234-2226 Uen Approved Checked Date Rev Reference SEM/CVVGP, Anna Englund 2010-02-11 1 6 Label placement To find the label follow these steps: 1. Remove the cover on the rear side of the product. 2. Remove the battery. 3. The label is located behind the battery. Rear side of the phone Place for battery Label placement

CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 23 of 36 Photo documentation: Internal photos Photo 1: Photo 2: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 24 of 36 Photo 3: Photo 4: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 25 of 36 Photo 5: Photo 6: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 26 of 36 Photo 7: Photo 8: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 27 of 36 Photo 9: Photo 10: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 28 of 36 Photo 11: Photo 12: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 29 of 36 Photo 13: Photo 14: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 30 of 36 Photo 15: Photo 16: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 31 of 36 Photo 17: Photo 18: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 32 of 36 Photo 19: Photo 20: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 33 of 36 Photo 21: Photo 22: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 34 of 36 Photo 23: Photo 24: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 35 of 36 Photo 25: Photo 26: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 36 of 36 Photo 27:

CETECOM ICT Services GmbH Untertürkheimer Straße 6-10 . D-66117 Saarbrücken Phone: +49 (0) 681-598-0 Fax: -9075 RSC-Laboratory 2010-03-01 Page 1 of 36 Accredited testing-laboratory DAR registration number: DGA-PL-176/94-D1 Federal Motor Transport Authority (KBA) DAR registration number: KBA-P 00070-97 Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3462C-1 (IC) Certification ID: DE 0001 Accreditation ID: DE 0002 Accredited Bluetooth ® Test Facility (BQTF) The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Cetecom ICT is under license Annex to Test report no. : 1-1954-10-02/10 Type identification : AAD-3880069-BV Applicant : Sony Ericsson Mobile Communications AB FCC ID : PY7A3880069 IC Certification No : 4170B-A3880069 Test standards : 47 CFR Part 15 RSS - 210 Issue 7 ICES-003 Issue 4 CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 2 of 36 Table of contents 1 G e n e r a l i n f o r m a t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . 3 1.1 Notes ...................................................................................................................................................................3 1.2 Testing laboratory ...............................................................................................................................................4 1.3 Details of applicant .............................................................................................................................................4 1.4 Application details ..............................................................................................................................................4 2 T e s t s t a n d a r d / s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 5 3 T e c h n i c a l t e s t s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 6 3.1 Details of manufacturer .......................................................................................................................................6 3.2 Test item..............................................................................................................................................................6 4 S u m m a r y o f M e a s u r e m e n t R e s u l t s a n d l i s t o f a l l p e r fo r m e d t e s t c a s e s . . . . . . . . . . . . . . . . . . . . . . . . . . 7 5 M e a s u r e m e n t s a n d r e s u l t s . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . 8 6 A n n e x A : F C C P a r t 1 5 S u b p a r t B . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 9 6.1 Conducted Limits ................................................................................................................................................9 6.2 Unwanted emissions..........................................................................................................................................10 7 T e s t e q u i p m e n t a n d a n c i l l a r i e s u s e d f o r t e s t s . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 1 5 8 P h o t o g r a p h s o f t h e T e s t S e t - u p . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . 1 7 9 P h o t o g r a p h s o f t h e E U T . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . 2 0 CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 3 of 36 1 General infor mat ion 1 . 1 N o t e s The test results of this test report relate exclusively to the test item specified in 3.1.1. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. Test laboratory manager: 2010-03-01 Marco Bertolino Date Name Signature Technical responsibility for area of testing: 2010-03-01 Stefan Bös Date Name Signature CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 4 of 36 1 . 2 T e s t i n g l a b o r a t o r y Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 e-mail: [email protected] Internet: http://www.cetecom-ict.de State of accreditation: Accredited by: The test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 DAR registration number: DGA-PL-176/94-D1 Federal Motor Transport Authority (KBA) DAR registration number: KBA-P 00070-97 Testing location, if different from CETECOM ICT Services GmbH: Name : Street : Town : Country : Phone : Fax : 1 . 3 D e t a i l s o f a p p l i c a n t Name: Sony Ericsson Mobile Communications AB Street: Nya Vattentornet Town: 22188 Lund Country: Sweden Telephone: +46-46-19…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 17 of 36 8 Photographs of t he Test Set- up Photo documentation: Photo 1: Photo 2: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 18 of 36 Photo 3: Photo 4: CETECOM ICT Services GmbH Annex to Test report no.: 1-1954-10-02/10 2010-03-01 Page 19 of 36 Photo 5:
