PY7A3880112GSM 850/900/1800/1900 GPRS / EDGE / UMTS FDD156 / HSUPA/HSDPA mobile phone with Bluetooth, WLAN 802.11bgn, GPS/A-GPS, FM Rx, ANT+ and RFID

71 Calling/Network Services SO-02C Web_TA Copying contacts registered in Google account to docomo account 1 On the "docomo (Copy to account)" tab screen, tap a Google account you want to copy. 2 Ta p [ (Overwrite)]/ [ (Add)]. You can also copy the Contacts data saved in "Phone contact" to docomo account as well as Google account. You can back up contacts to the Phonebook back up center automatically on a regular basis and restore the contacts in case of losing the FOMA terminal or erasing the contacts accidentally. For details on Phonebook backup, refer to " (sp< >) Mobile Phone User's Guide [sp- mode <Smartphone>] (in Japanese only)". You can use the following DOCOMO network services on the FOMA terminal. For details on the outline and how to use each service, see the relevant pages indicated in the following table. You cannot use the network services when you are outside of the service area or in a location without the radio wave. For details, see the "Mobile Phone User's Guide [Network Services]". For subscription and inquiry, contact "General Inquiries" on the last page of this manual. Using Phonebook backup Network Services Available Network Services Service name Monthly charge ApplicationPage Vo i ce M a il Service PaidRequiredP.72 Call Waiting Service PaidRequiredP.74 Call Forwarding Service FreeRequiredP.76 Caller ID Notification Service FreeNot required P.77 Continued on next page SO-02C_E_TA.book 71 ページ ２０１１年５月２４日 火曜日 午後２時３３分 72 Calling/Network Services SO-02C Web_TA ❖Information In this manual, the outlines of each network service are described with menu operations. The Voice Mail Service takes messages for you, as long as it answers a call with the answering message, if there is an incoming call when you are in a location without the radio wave, while the FOMA terminal is powered off, or when you cannot answer a call within the preset ring time. When the Voice Mail Service is set to "Activate" and if you do not answer an incoming call, the call is saved in "Call log" as a "Missed call" and (Missed call) appears in the status bar. The FOMA terminal does not support Voice Mail service of videophone call. Call "1412" to set "Not support". ❖Information This FOMA terminal does not have Record message function which records voice messages on internal memory. Use the Voice Mail Service. The message can be recorded up to 3 minutes for 1 message, up to 20 messages, and stored up to 72 hours. The number of Voice Mail messages appears until you have played all messages. Basic flow of the Voice Mail Service Voice Mail Service Your FOMA terminal receives a call. If you do not answer the call, it is connected to the Voice Mail service center. The caller leaves a message. The receiver is notified that the Voice Mail service center has taken the voice message. Play the voice message. If you are in a hurry and wish to leave a message without listening to the Voice Mail answering message, you can interrupt the answering message and switch to message recording mode immediately by tapping [Dialpad] [#]. Activate the Voice Mail Service. SO-02C_E_TA.book 72 ページ ２０１１年５月２４日 火曜日 午後２時３３分 73 Calling/Network Services SO-02C Web_TA Setting Voice Mail Service 1 From the Home screen, press t and tap [Settings]. 2 Tap [Call settings] X [Network service setting]. 3 Tap [Voicemail]. Select items you want to use from the following. * After operation is finished, you receive the "NTT DoCoMo VM:XX" SMS. ❖Information If you have the recorded messages stored at the Voice Mail service center, (New SMS message) and (Voice Mail message) appear on the status bar. (Voice Mail message) disappears when you delete all messages. The notification setting and notifications (message (SMS) reception) are not charged. Activate Vo i ce m ai l Tap [OK] to activate the Voice Mail Service. Set ring timeEnter the ring time (0 to 120 seconds). It changes only the ring time. Deactivate Vo i ce m ai l Tap [OK] to deactivate the Voice Mail Service. Check Voicemail setting Check the current service settings. Play messages*Tap [OK] to call the Voice Mail service center. After this step, follow the voice prompts to play the message. Voicemail setting* Tap [OK] to change the Voice Mail setting with the voice prompts. The call is connected to the Voice Mail service center. After this step, follow the voice prompts to operate. Check messages*Check if a new message is stored. After checking, the completion message appears. Notification settings Set whether to alert you of a new message with the tone or vibration. Activate Missed Call Notification When it is received while the FOMA terminal is powered off or outside of the service area, an SMS is sent to notify you of the information about the call (date, time and the caller ID) once you turn the FOMA terminal back on or move back in to the service area. Select [All calls] to notify you of all received calls. Select [Calls with Caller ID] to notify you of only the calls with the caller ID. Deactivate Missed Call Notification While starting the notification, tap this item to deactivate the notification. Check settingCheck the notification settings. SO-02C_E_TA.book 73 ページ ２０１１年５月２４日 火曜日 午後２時３３分 74 Calling/Network Services SO-02C Web_TA Playing the voice message 1 When the SMS notification "NTT DoCoMo VM:XX" appears, tap [New message] from the notification panel (P.34). A recorded message plays. 2 Follow the voice prompts to operate. When there is another incoming call while you are on a call, the in-call ring tone notifies you of the second call. You can answer the second call by putting the first call on hold. You can also put your current call on hold and place a call to another party. ❖Information Even when the call is on hold, the caller is charged for a call fee. Setting Call Waiting 1 From the Home screen, press t and tap [Settings]. 2 Tap [Call settings] X [Network service setting]. 3 Tap [Call Waiting]. You can select the following operations. Putting the current call on hold and answeri…

Text truncated - open the document above for the full version.

Sony Ericsson Confidentiality Request 2011-05-23 CVDVBA 11 :173 SEMC/CVDVBA Afrah Sadiq +46108012250 Receiver Federal Communications Commission Subject: Request for Confidentiality FCC ID: PY7A3880112 To Whom It May Concern': In accordance with §0.459 of CFR 47, Sony Ericsson Mobile Communications AB requests confidentiality for the below listed items for our mobile phone type AAD­ 3880112-BV, FCC ID: PY7A3880112: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational/Technical Descriptions These items contain detailed system and equipment description and related information about the product which Sony Ericsson Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Ericsson Mobile Communications AB also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Best Regards, 4C Afrah Sadiq Staff Ve rificatio n Engineer Global Type Approval Sony Ericsson Mobile Communications N ya Vattentornet 221 88 Lund, Sweden Fax: +46 10 80 02441 sonyerif',sson .com Sony Ericsson Mobile Communications AB Styrelsens sa te : Lund Momsnr • VA. TNo: SE556615665801 Register ed office: Lund Organisatio nsnr • Reg No: 556615-6658 Postadress • Mail Besoksadress • Office address Telefon • Telephone Telefax • Telefax SE-221 88 Lund Nya Vattentornet Nat 010- 80 00000 Nat 010-80 02040 Sweden Lund Int +46 108000000 Int +46 10 80 02040

Sony Ericsson Short Term Confidentiality Request 2011-05-26 CVDVBA11 :184 SEM/CCDALE Afrah Sadiq +46 108012250 Receiver Federal Communications Commission Subject: Request for Temporary Confidentiality FCC 10: PY7 A3880112 To Whom It May Concern: In accordance with §0.459 of CFR 47 and Public Notice OA 04-1705, Sony Ericsson Mobile Communications AB requests in addition to confidentiality request CVOVBA 11: 173 temporary confidentiality for 180 days of the below listed items for our mobile phone type AAO-3880112-BV, FCC 10: PY7A3880112: 1. User Manual 2. Test set-up 3. External and Internal photos When the announcement of the product is done, the TCB will be notified to remove the Short Term Confidentiality. Please contact the undersigned if there are any further questions or additional information needed in this matter. Best Regards, Afrah Sadiq Staff Verification Engineer Global Type Approval Sony Ericsson Mobile Communications Nya Vattentornet 221 88 Lund, Sweden Fax: +46 10 80 02441 sonyericsson.com Sony Ericsson Mobile Communications AB Styrelsens sate: Lund Momsnr. VA. T.No: SE556615665801 Registered office: Lund Organisationsnr. Reg No: 556615-6658 Postadress • Mail Besoksadress • Office address Telefon • Telephone Telefax • Telefax SE-221 88 lund Nya Vattentornet Nat 010-80 00000 Nat 010-80 02040 Sweden lund Int +46 108000000 Int +46 1 080 02040

Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 18 of 27 An ne x B E x te rna l ph ot ogra phs o f the E UT Photo documentation Photo 4: Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 19 of 27 Photo 5: Photo 6: Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 20 of 27 Photo 7:

Company Internal MARKING DRAWINGLABEL CONTENT 1 (8) Prepared (also subject responsible if other) No. Leif Hedin (23056584) 1251-0000 Approved Checked Date Rev Reference Leif Hedin (23056584) 2011-04-05 1.1 3State: Preliminary SO-02C, Mobile Phone label content, DOCOMO 1 General information Core Unit label part no 1249-5507 Bar code • Print quality: according to COSMETIC GUIDELINE – Bar code labels document 1222-6072 Uen • Quiet zone: No bar codes are allowed to be closer to a label edge than 2 mm! Text If applicable, or nothing else specified, Zebra printer Scalable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. Coordinates “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. MLCI= Main Label Content Information Document 2 Printing information Content Format Line 1 (4,0/3,0) Sony Ericsson stylized name. Graphics, height 2,0 mm. According to 1200-1925 Line 2, a (7,0/3,0) Operator logo in Japanese Graphics, height 2,0 mm. According to 1234-3760 Line 2, b (7,0/28,8) SIM-card logo Graphics height 5,5mm According to 1235-2274 document Company Internal MARKING DRAWINGLABEL CONTENT 2 (8) Prepared (also subject responsible if other) No. Leif Hedin (23056584) 1251-0000 Approved Checked Date Rev Reference Leif Hedin (23056584) 2011-04-05 1.1 3State: Preliminary Line 3, a (9,5/3,0) “Product name in Japanese Graphics, height 2,0 mm. According to 1234-3743 Line 3, b (9,5/13,0) Model Name “SO-02C” Text, height 1,5 mm. According to Chapter 1 in MLCI Line 3, c (9,5/19,0) Colour of the included telephone, in English: e.g. “< XXXXXXX >” Text, height 1,5 mm. English colour names according to Chapter 2.1 in MLCI Line 3, d (9,5/43,0) Memory card Micro SD logo Graphics height 5,5mm According to 1246-1770 document Line 4, a (11,2/3,0) Type number of the phone, “TYPE: AAD-3880112-BV”. Text, height 1,2 mm. According to Chapter 1 in MLCI Line 4, b (11,2/18,8) HW & SW identification field, if applicable; “FFGG” Text, height 1,2 mm. According to Type-testing report under Product Model Specifying Documents Line 5,a (13,0/3,0) “FCC ID: PY7A3880112” Text, height 1,2 mm. According to Chapter 1 in MLCI Line 5,b (13,0/18,8) Location code of where the phone is flashed, if applicable, “XXX” Text, height 1,2 mm Line 6, a (14,5/3,0) “IC ID: 4170B-A3880112” Text, height 1,2 mm According to Chapter 1 in MLCI Line 6,b (14,5/18,8) Repair week, if applicable. “RyyWww” (yy = year, ww = week) Text, height 1,2 mm Line 7, a (16,8/3,0) Production week (flash), “yyWww” (yy = year, ww = week) + production date in Text, height 1,5 mm. Graphics, height 1,5 Company Internal MARKING DRAWINGLABEL CONTENT 3 (8) Prepared (also subject responsible if other) No. Leif Hedin (23056584) 1251-0000 Approved Checked Date Rev Reference Leif Hedin (23056584) 2011-04-05 1.1 3State: Preliminary Japanese (eg: year+ 年+ month+月 ) : “yyWww/ 20XX 年 XX 月” mm. According to 1234-3763, 1235-6102 and 1235- 6103 Line 7, b (16,8/34,0) Product number of the Sales Item in which the phone is packed, if applicable. “SI XXXX-XXXX” Text, height 1,2 mm Line 8 (18,5/3,0) Supplier’s identification for trace-ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,2 mm. Defined by supplier Line 9 (21,4/4,0) Line 9 in bar code, according to line 8. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology) Line 10 (22,8/3,0) “製 “+ Actual electronic serial number (IMEI) of the Mobile Phone, “ 製 12345678-123456-1” Graphics, height 1,5 mm. According to 1234-3770. Text, height 1,5 mm. In the format TAC-SNR- CD. TAC and SNR derived from pos 500 in BOM. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 11 (29.0/4,0) Line 11 in bar code, according to line 10 (only actual number, without data identifier). Bar code, minimum height 6,0 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. When printing Code 128, Company Internal MARKING DRAWINGLABEL CONTENT 4 (8) Prepared (also subject responsible if other) No. Leif Hedin (23056584) 1251-0000 Approved Checked Date Rev Reference Leif Hedin (23056584) 2011-04-05 1.1 3State: Preliminary minimum width should be more than 0.125mm and should use four kinds of the width of multiplied width to the minimum width used. (x1, x2, x3, x4) White bar should use the same spec. Line 12, a (32,5/3,0) “Caution symbol” Graphics, height 3 mm. According to 1234-3774 Line 12, b (32,5/7,0) “Caution” in Japanese Graphics, height 2.8 mm. According to 1234-3790 Line 12, c (32,5/14,0) “Do not remove this label” statement in Japanese, on two rows. ”航空機内・病院内では電源を切ってください“ “このシールを剥がさないでください“ Graphics, height 1,5 mm. According to 1250-5471 Line 13 (36,0/3,0) Manufacturer name in Japanese “ ” Graphics, height 1,5 mm. According to 1248-6304, on two rows NOTE: If text doesn’t fit, adjust the height accordingly. Line 14 (38,0/10,0) Local Type Approval Number: T AD 11-0004 202 Text, height 1,2 mm Company Internal MARKING DRAWINGLABEL CONTENT 5 (8) Prepared (also subject responsible if other) No. Leif Hedin (23056584) 1251-0000 Approved Checked Date Rev Reference Leif Hedin (23056584) 2011-04-05 1.1 3State: Preliminary Line 15 (38,9/9,5) Square around T, see Line 15 Weight 1,5 x Height 2,0 mm Line 16 (39,8/12,0) Local Type Approval Number: 202XY111297724 Text, height 1,2 mm Line 17 (41,2/12,0) Local Type Approval Number: 202MW111297724 Text, height 1,2 mm Line 18 (42,0/3,0) “JATE” logo Graphics, height 5 mm. According to 1234-3837 Line 19 (42,8/10,0) Local Type Approval Number: R 202WW111297724 Text, height 1,2 mm. Line 20 (43,0/9,8) Square around R, see Line 19 Width 1,5 x Height 2,0 mm Line 21, a …

Text truncated - open the document above for the full version.

Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 21 of 27 An ne x C Inte r na l p ho to gra phs o f the E UT Photo documentation Photo 8: Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 22 of 27 Photo 9: Photo 10: Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 23 of 27 Photo 11: Photo 12: Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 24 of 27 Photo 13: Photo 14: Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 25 of 27 Photo 15: Photo 16: Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 26 of 27 Photo 17: Photo 18: Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 27 of 27 An ne x D Doc u me n t his to r y Version Applied changes Date of release 1.0 Initial release 2011-04-15 An ne x E Fur the r in for ma ti o n Glossary DUT - Device under Test EMC - Electromagnetic Compatibility EUT - Equipment under Test FCC - Federal Communication Commission FCC ID - Company Identifier at FCC HW - Hardware IC - Industry Canada Inv. No. - Inventory number N/A - not applicable S/N - Serial Number SW - Software

2011-05-26 Page 1 of 27 TEST REPORT Annex to Test Report No.: 1-2977-30-02/11-A Testing Laboratory Applicant CETECOM ICT Services GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken/Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom-ict.de e-mail: [email protected] Accredited Test Laboratory: The test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 DAkkS registration number: D-PL-12076-01-01 Area of Testing: Radio Satellite Communications Sony Ericsson Mobile Communications AB Nya Vattentornet 22188 Lund/Sweden Phone: +46 46 19 30 00 Fax: +46 46 19 32 95 Contact: Johan Wedin e-mail: [email protected] Phone: +46 70 71 95 73 6 Manufacturer Sony Ericsson Mobile Communications AB Nya Vattentornet 22188 Lund/Sweden Test Standard/s 47 CFR Part 15 ICES -003 Issue 4 Title 47 of the Code of Federal Regulations; Chapter I Part 15 – Radio frequency devices Spectrum Management amd Telecommunications Policy Interference-Causing Equipment Standard For further applied test standards please refer to section 3 of this test report. Test item Kind of test item: GSM Mobile Phone (GPRS/EGPRS) 850/ 900/1800/1900; UMTS (HSDPA/HSUPA) FDDI/V/VI; BT2.1 + EDR; A-GPS; WLAN; ANT+; RFID Model name: AAD-3880112-BV FCC ID: PY7A3880112 IC: 4170B-A3880112 Frequency: 824.2 – 848.8 MHz, 826.4 – 846.6 MHz, 1850.2 – 1909.8 MHz Power supply: 3.70 V DC by Li-ion Battery (BA750) and power supply Temperature range: -30 °C to +60 °C Test performed: Test Report authorised: 2011-05-26 Marco Bertolino 2011-05-26 Stefan Bös Annex to Test Report No.: 1-2977-30-02/11-A 2011-05-26 Page 2 of 27 1 Table of contents 1 Table of contents ............................................................................................................................................ 2 2 General Information ....................................................................................................................................... 3 2.1 Notes ..................................................................................................................................................... 3 2.2 Application details ............................................................................................................................... 3 3 Test standard/s ............................................................................................................................................... 3 4 Test Environment ........................................................................................................................................... 3 5 Test item .......................................................................................................................................................... 4 6 Test Laboratories sub-contracted ................................................................................................................ 4 7 Summary of Measurement Results .............................................................................................................. 5 7.1 Receiver ................................................................................................................................................ 5 8 Measurement Results .................................................................................................................................... 6 8.1 RX Spurious Emissions Conducted < 30 MHz ................................................................................. 6 8.2 Spurious Emissions Radiated – Receiver Mode .............................................................................. 9 9 Test equipment and ancillaries used for tests .......................................................................................... 14 Annex A Photographs of the test setup ...................................................................................................... 16 Annex B External photographs of the EUT ................................................................................................. 18 Annex C Internal photographs of the EUT .................................................................................................. 21 Annex D Document history .......................................................................................................................... 27 Annex E Further information ........................................................................................................................ 27 Annex to Test Report No.: 1-2977-30-02/11-A 2011-05-26 Page 3 of 27 2 General Information 2.1 Notes The test results of this test report relate exclusively to the test item specified in this test report. CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of CETECOM ICT Services GmbH. 2.2 Application details Date of receipt of order: 2011-04-07 Date of receipt of test item: 2011-04-07 Start of test: 2011-04-08 End of test: 2011-04-11 Person(s) present during the test: -/- 3 Test standard/s Test Standard Version Test Standard Description 47 CFR Part 15 2009-10 Title 47 of the Code of Federal Regulations; Chapter I-Federal Communications Commission subchapter A - general, Part 15-Radio frequency devices ICES-003 Issue 4 2004-04 Spectrum Management and Telecommunications Policy Interference-Causing Equipment Standard 4 Test Environment Temperature: T nom T max T min +23 °C during room temperature tests +60 °C during high temperature test -30 °C during low temperature test Relative humidity content: 40 % Air pressure: not relevant for this kind of testing Power supply: V nom V max V min 3.70 V DC by Li-ion Bat…

Text truncated - open the document above for the full version.

Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 16 of 27 An ne x A P ho tog ra phs o f t h e te s t s e tu p Photo documentation Photo 1: Photo 2: Annex to Test Report No.: 1-2977-30-02/11 2011-04-15 Page 17 of 27 Photo 3:
