Xperia ™ active Startup guide Sony Ericsson Mobile Communications AB SE-221 88 Lund, Sweden www.sonyericsson.com 1250-0557.1 To insert the SIM card and the memory card Memory card may not be included with purchase in all markets. To attach the battery cover and the back cover 1 3 2 1 2 Correctly attaching the back cover and the battery cover can keep your phone resistant to water. The phone is not resistant to water when the micro USB port cover or the headset connector cover is open, for example, when the phone is charging or when it's connected to a wired headset. Phone basics Phone overview 12354 6 7 8 10 9 111213 16 15 14 19 20 17 18 21 22 1. Light sensor 2. Notification LED 3. Ear speaker 4. Proximity sensor 1 5. Proximity sensor 2 6. Volume key/Zoom key 7. Touch screen 8. Camera key 9. Menu key 10. Strap hole 11. Home key 12. Main microphone 13. Back key 14. Second microphone 15. Camera LED light 16. Power key/Screen lock 17. Speaker 18. Camera lens 19. Micro USB port cover 20. Headset connector cover 21. Micro USB port 22. Headset connector Turning on the phone To turn on the phone It may take a while for the phone to start up. Waking up the screen To activate the screen • Briefly press the key. To unlock the screen • Drag the icon to the right across the screen. Using the keys Back • Go back to the previous screen • Close the on-screen keypad, a dialog box, an options menu, or the Notification panel Home • Go to the Home screen • Press and hold to open a window showing your most recently used applications Menu • Open a list of options available in the current screen or application Set up your phone What is Android? Android is your phone's operating system. Since it's developed by Google™, your phone is preloaded with several Google™ services, such as Google Maps™ and Google™ web search. To use some of the services provided by Google™, you need a Google account. With a Google account you can access Android Market™ – an application store providing both free and paid applications for easy download to your phone. What is different about Android? Android™ is an open system, which means that you're not limited to using applications and services from only one provider. Google™ account Use Gmail™ to send emails, Google Talk™ to chat with friends, and Android Market™ to download applications. To add an account 1 From your Home screen, tap . 2 Tap Settings > Accounts & sync > Add account. 3 Tap the account type you want to add and then follow the registration wizard. Basic settings The first time you start your phone, a setup guide explains basic phone functions and helps you enter essential settings. You can also access the setup guide later. To access the setup guide 1 From the Home screen, tap . 2 Find and tap Setup guide. Transferring contacts from your old phone When you buy a new phone, one of the first challenges is to transfer your contacts and phone numbers from your old phone. This procedure can sometimes be complicated. In this section we give you the big picture and outline solutions based on the type of your old phone. We also tell you where you can find detailed step-by-step instructions. My old phone is a non- Android™ phone Sony Ericsson Transfer the contacts from your old Sony Ericsson phone to your new phone in a few steps: 1 New phone: Connect your new phone to an Internet-connected PC using a USB cable. 2 New phone: If prompted, tap the screen to launch the installation of PC Companion on the PC. 3 PC: In PC Companion, select the option to transfer or synchronise your contacts. 4 With your old phone and its USB cable at hand, follow the instructions on the PC screen to transfer your contacts from the old phone to your new one. To view detailed step-by-step instructions, visit www.sonyericsson.com/support/contacts. Nokia Transfer the contacts from your old Nokia Symbian™ phone to your new phone in a few steps. This method only works for Nokia phones using the S60 platform. 1 New phone: Connect your new phone to an Internet-connected PC using a USB cable. 2 New phone: If prompted, tap the screen to launch the installation of PC Companion on the PC. 3 PC: In PC Companion, select the option to transfer or synchronise your contacts. 4 With your old phone and its USB cable at hand, follow the instructions on the PC screen to transfer your contacts from the old phone to your new one. To view detailed step-by-step instructions, visit www.sonyericsson.com/support/contacts. Welcome Important information Please read the Important information leaflet and the Water resistance leaflet before you use your mobile phone. Assembly To remove the back cover and the battery cover 2 1 3 Use a thumb nail so that you can lift up the back cover with more force. July 29, 2011 17:12:29 ST17i__Booklet_EN_1250-0557.1.pdf 1 of 2 iPhone™ Transfer your iPhone™ contacts to your new phone via a Google™ account: 1 Connect your iPhone to a PC and start the iTunes™ application. Click the Info tab in iTunes™ and select to sync the phone with Google™ Contacts. If you use a Mac® computer, you need to export your contacts in vCard format from the Mac® Address Book into a vCard file, and then import the vCard file into your Google™ account. 2 Once your iPhone contacts are moved to your Google™ account, you need to synchronise your new phone with your Google™ account. To view detailed step-by-step instructions, visit www.sonyericsson.com/support/contacts. Other phone Transfer the contacts from your old phone to a computer and then use Google Sync™ to transfer the contacts to your new phone. 1 Old phone: Transfer the contacts from your old phone to a computer. The most practical way to do this is by using a memory card. 2 Make a note of where you copy the contacts file. This kind of file is usually in vCard (.vcf) or a .csv format. 3 Computer: Go to www.google.com/contacts and sign in, or create a new Google™ account. Click Import and browse to the location of the contacts file, then click Open. Your contacts are…

Text truncated - open the document above for the full version.

Sony Ericsson Confidentiality Request 2011-09-23 CVDVBA 11 :498 SEMC/CVDVBA Afrah Sadiq +46 108012250 Receiver Federal Communications Commission Subject: Request for Con'FIdentiality FCC 10: PY7A3880122 To Whom It May Concern: In accordance with §0.459 of CFR 47, Sony Ericsson Mobile Communications AB requests confidentiality for the below listed items for our mobile phone type AAD­ 3880122-BV, FCC ID: PY7A3880122: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. OperationallTechnical Descriptions These items contain detailed system and equipment description and related information about the product which Sony Ericsson Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Ericsson Mobile Communications AB also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. ~. -; Afrah Sadiq Staff Verification Engineer Global Type Approval Sony Ericsson Mobile Communications Nya Vattentornet 221 88 Lund, Sweden Fa x: +46 108002441 sonye ricsson .com Sony Ericsson Mobile Communications AB Styrelsens sate: Lund Momsnr. v.A. T.No: SE55661 5665801 Registered office: Lund Organisationsnr • Reg No: 556615-6658 Postadress • Mail Besbksadress • Office address Telefon • Telephone Telefax • Telefax SE-221 88 Lund Nya Vattentornet Nat 010-8000000 Nat 010-80 02040 Sweden Lund Int +46 10 80 00000 Int +46108002040

Page 1 of 5 The test results relate only to the individual items which have been tested. This report shall not be reproduced in parts without the written approval of the testing laboratory © Copyright: All rights reserved by CETECOM Laboratory Accreditation and Listings Reg. No.: 736496 MRA US-EU 0003 Industry Canada Reg. No.: 3462D-1 Reg. No.: 3462D-2 Reg. No.: 3462D-3 Voluntary Controls for Electromagnetic Emissions Reg. No.: R-2665, R-2666 C-2914, T-1967, G-301 accredited according to DIN EN ISO/IEC 17025 CETECOM GmbH Laboratory Radio Communications & Electromagnetic Compatibility Im Teelbruch 116 • 45219 Essen • Germany Registered in Essen, Germany, Reg. No.: HRB Essen 8984 Tel.: + 49 (0) 20 54 / 95 19-954 • Fax: + 49 (0) 20 54 / 95 19-964 E-mail: [email protected] • Internet: www.cetecom.com ANNEX 2: EXTERNAL EUT PHOTOS TO TEST REPORT No.: 2-0004-11-17-1C for GSM/(E)GPRS/W-CDMA MOBILE PHONE AAD-3880122-BV + FCC-ID: PY7A3880122 IC: 4170B-A3880122 Version of template: 11.08 SONY ERICSSON MOBILE COMMUNICATIONS AB Annex 2 to Test Report 2-0004-11-17-1C, Page 2 of 5 TR2-0004-11-17-1c-A2 Table of contents 1. EXTERNAL PHOTOS OF EUT 3 Annex 2 to Test Report 2-0004-11-17-1C, Page 3 of 5 TR2-0004-11-17-1c-A2 1. External Photos of EUT Photograph 1: EUT A – front side Photograph 2: EUT A – rear side Annex 2 to Test Report 2-0004-11-17-1C, Page 4 of 5 TR2-0004-11-17-1c-A2 Photograph 3: EUT B – AC Charger Photograph 4: EUT C – USB cable Annex 2 to Test Report 2-0004-11-17-1C, Page 5 of 5 TR2-0004-11-17-1c-A2 Photograph 5: EUT D - battery Photograph 6: EUT E - Headset

Company Internal MARKING DRAWING 1 (2) Prepared (also subject responsible if other) No. SEM/CVVGP, Leif Hedin 1249-8272 Uen Approved Checked Date Rev Reference SEM/CVVGP, Leif Hedin 2011-06-14 1 2 ST17a, Mobile Phone label, a-version, made in... 1 General information MLCI= Main Label Content Information Document 2 Printing information Content Format Line 1a (4,0/2,0) Sony Ericsson stylized name. Graphics, height 1,5 mm. According to 1200-1925 Line 1b (4,0/20,0) Model Name “ST17a” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 2a (6,2/2,0) Product number of the Sales Item in which the phone is packed, if applicable. “SI XXXX-XXXX” Text, height 1,2 mm. Line 2b (6,2/20,0) Location code of where the phone is flashed, if applicable, “XXX” Text, height 1,2 mm. Line 3a (8,5/2,0) “TYPE: AAD-3880122-BV” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 3b (8,5/20,0) HW & SW identification field, if applicable; “FFGG” Text, height 1,2 mm. According to Type-testing report under Product Model Specifying Documents Line 4 (9,0/27,0) SIM-card logo Graphics height 7,0mm according to 1001-6195 Line 5a (11,5/2,0) ”FCC ID: PY7A3880122” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 5b (11,5/20,0) Production week (flash), “yyWww” (yy = year, ww = week) Text, height 1,2 mm. Line 6a (14,5/2,0) “IC: 4170B-A3880122” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 6b (14,5/20,0) Repair week, if applicable. “RyyWww” (yy = year, ww = week) Text, height 1,2 mm. Mobile Phone label part no • 1241-3099 Mobile Phone label content part no • 1249-8271 Bar code • Print quality: according to COSMETIC GUIDELINE – Bar code labels document 1222-6072 Uen • Quiet zone: No bar codes are allowed to be closer to a label edge than 2 mm! Text If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. Coordinates “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. Company Internal MARKING DRAWING 2 (2) Prepared (also subject responsible if other) No. SEM/CVVGP, Leif Hedin 1249-8272 Uen Approved Checked Date Rev Reference SEM/CVVGP, Leif Hedin 2011-06-14 1 2 Line 7 (18,0/2,0) Line 7 in bar code, according to line 8a. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 8a (20,0/2 ,0) Supplier’s identification for trace-ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,5 mm. Defined by supplier. Line 8b (20,0/17,0) Actual electronic serial number (IMEI) of the mobile phone, “00000000-000000-0” Text, height 1,5mm. In the format TAC-SNR-CD. TAC and SNR derived from pos 500 in BOM. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 9 (23,0/2 ,0) Line 9 in bar code, according to line 8b.. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 10a (29,3/2,0) CE approval symbol, the NB-“0682” and “Alert Symbol” in one artwork Graphics, height 5 mm. According to 1242-7470 Line 10b (29,3/32,0) WEEE trashcan without bar symbol Graphics, min. height 5mm, according to 1202-5537. Line 11 (32,2/2,0) Marking of origin; “Made in Xxx” “Xxx” = actual country of production of the included telephone, in English Text, height 1,2 mm. 3 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 3.1 Conceptual picture double underlined = major changes since last revision. Confidential MARKING DRAWING 1(1) Document number Revis ion 1249-8272 Uen Prepared by Date 2011-06-14 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by Note: Any hard copy of this document is for reference only. D u e to template and application dependencies the header and footer may fail to display correct data. It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Label placement To find the label follow these steps: 1 . R emove the cover on the rear side of the product. 2. Remove the battery. 3. The label is located behind the battery. Rear side of the phone Place for battery Label placement

Page 1 of 8 The test results relate only to the individual items which have been tested. This report shall not be reproduced in parts without the written approval of the testing laboratory © Copyright: All rights reserved by CETECOM Laboratory Accreditation and Listings Reg. No.: 736496 MRA US-EU 0003 Industry Canada Reg. No.: 3462D-1 Reg. No.: 3462D-2 Reg. No.: 3462D-3 Voluntary Controls for Electromagnetic Emissions Reg. No.: R-2665, R-2666 C-2914, T-1967, G-301 accredited according to DIN EN ISO/IEC 17025 CETECOM GmbH Laboratory Radio Communications & Electromagnetic Compatibility Im Teelbruch 116 • 45219 Essen • Germany Registered in Essen, Germany, Reg. No.: HRB Essen 8984 Tel.: + 49 (0) 20 54 / 95 19-954 • Fax: + 49 (0) 20 54 / 95 19-964 E-mail: [email protected] • Internet: www.cetecom.com Annex 4: Internal EUT Photos to TEST REPORT No.: 2-0004-11-17-1a for GSM/(E)GPRS/W-CDMA Mobile Phone AAD-3880122-BV FCC-ID: PY7A3880122 IC: 4170B-A3880122 According to: FCC-Regulations Part 22 & Part 24 IC-Regulations RSS-132 Issue 2 & RSS-133 Issue 5 RSS-Gen, Issue 3 Sony Ericsson Mobile Communications AB Annex 4 to Test Report 2-0004-11-17-1a , Page 2 of 8 TR2-0004-11-17-1a-A4 Table of contents 1. INTERNAL PHOTOS OF EUT ......................................................................................................................... 3 Annex 4 to Test Report 2-0004-11-17-1a , Page 3 of 8 TR2-0004-11-17-1a-A4 1. Internal photos of EUT Photograph 1: EUT opened Photograph 2: PCB rear side Annex 4 to Test Report 2-0004-11-17-1a , Page 4 of 8 TR2-0004-11-17-1a-A4 Photograph 3: PCB rear side Photograph 4: PCB rear side Annex 4 to Test Report 2-0004-11-17-1a , Page 5 of 8 TR2-0004-11-17-1a-A4 Photograph 5: PCB front side Photograph 6: PCB front side (cover removed) Annex 4 to Test Report 2-0004-11-17-1a , Page 6 of 8 TR2-0004-11-17-1a-A4 Photograph 7: PCB front side (cover removed) Photograph 8: PCB rear side Annex 4 to Test Report 2-0004-11-17-1a , Page 7 of 8 TR2-0004-11-17-1a-A4 Photograph 9: Cover internal Photograph 10: View Antenna Annex 4 to Test Report 2-0004-11-17-1a , Page 8 of 8 TR2-0004-11-17-1a-A4 Photograph 11: View Antenna Photograph 12: View Antenna electrical connector

Page 1 of 24 The test results relate only to the individual items which have been tested. This report shall not be reproduced in parts without the written approval of the testing laboratory © Copyright: All rights reserved by CETECOM Laboratory Accreditation and Listings Reg. No.: 736496 MRA US-EU 0003 Industry Canada Reg. No.: 3462D-1 Reg. No.: 3462D-2 Reg. No.: 3462D-3 Voluntary Controls for Electromagnetic Emissions Reg. No.: R-2665, R-2666 C-2914, T-1967, G-301 accredited according to DIN EN ISO/IEC 17025 CETECOM GmbH Laboratory Radio Communications & Electromagnetic Compatibility Im Teelbruch 116 • 45219 Essen • Germany Registered in Essen, Germany, Reg. No.: HRB Essen 8984 Tel.: + 49 (0) 20 54 / 95 19-954 • Fax: + 49 (0) 20 54 / 95 19-964 E-mail: [email protected] • Internet: www.cetecom.com TEST REPORT No.: 2-0004-11-17-1c for GSM/(E)GPRS/W-CDMA Mobile Phone AAD-3880122-BV FCC-ID: PY7A3880122 IC: 4170B-A3880122 According to: FCC-Regulations Part 15.107&15.207, Part 15.109 Class B IC-Regulations RSS-132 Issue 2 & RSS-133 Issue 5 RSS-Gen, Issue 3 Sony Ericsson Mobile Communications AB Test Report 2-0004-11-17-1c, Page 2 of 24 TR2-0004-11-17-1c Table of contents 1. SUMMARY OF TEST RESULTS...................................................................................................................... 3 1.1. TESTS OVERVIEW FCC Part 15 and Canada IC Standards (RSS) .............................................................. 3 2. ADMINISTRATIVE DATA ............................................................................................................................... 4 2.1. Identification of the testing laboratory ............................................................................................................. 4 2.2. Test location .................................................................................................................................................... 4 2.3. Organizational items ........................................................................................................................................ 4 2.4. Applicant’s details ........................................................................................................................................... 4 2.5. Manufacturer’s details ..................................................................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) ................................................................................................................. 5 3.1. Additional declaration and description of main EUT ...................................................................................... 5 3.2. EUT: Type, S/N etc. and short descriptions used in this test report ................................................................ 6 3.3. Auxiliary Equipment (AE): Type, S/N etc. and short descriptions .................................................................. 6 3.4. EUT set-ups ..................................................................................................................................................... 6 3.5. EUT operating modes ...................................................................................................................................... 7 3.6. Parameter Settings on mobile phone and base station CMU200 ..................................................................... 8 4. DESCRIPTION OF TEST SET-UP’S ................................................................................................................ 9 5. MEASUREMENTS ............................................................................................................................................. 10 5.1. Conducted emissions on AC-Power lines ........................................................................................................ 10 5.2. Radiated field strength emissions, 30 MHz - 1 GHz ....................................................................................... 12 5.3. Radiated emissions, above 1GHz .................................................................................................................... 15 6. MEASUREMENT UNCERTAINTIES .............................................................................................................. 20 7. INSTRUMENTS AND ANCILLARY ................................................................................................................ 21 7.1. Used equipment “CTC” ................................................................................................................................... 21 Table of annex Total pages SEPARATE DOCUMENT TR2-0004-11-17-1C_A1.PDF: DIAGRAMS OF TESTING 28 SEPARATE DOCUMENT TR2-0004-11-17-1C_A2.PDF: EXTERNAL PHOTOS OF EUT 5 SEPARATE DOCUMENT TR2-0004-11-17-1C_A3.PDF: TEST SET-UP PHOTOS 4 Test Report 2-0004-11-17-1c, Page 4 of 24 TR2-0004-11-17-1c 2. Administrative Data 2.1. Identification of the testing laboratory Company name: CETECOM GmbH Address: Im Teelbruch 116 45219 Essen - Kettwig Germany Responsible for testing laboratory: Dipl.-Ing. W. Richter Deputy: Dipl.-Ing. J. Schmitt Laboratory accreditations/Listings: DAkkS-Registration No. D-PL-12047-01-01 FCC-Registration No.: 736496, MRA US-EU 0003 IC-Registration No. 3462D-1, 3462D-2, 3462D-3 VCCI Reg. No. R-2665, R-2666, C-2914, T-1967, G-301 2.2. Test location 2.2.1. Test laboratory “CTC” Company name: see chapter 2.1. Identification of the testing laboratory 2.3. Organizational items Order No.: 2-0004-11-17 Responsible for test report and project leader: Dipl.-Ing. C. Lorenz Receipt of EUT: 2011-07-31 Date(s) of test: 2011-07-31 to 2011-08-31 Date of report: 2011-09-21 ----------------------------------------------------------------------------------------------------------------------------------------------------- Version of template: 11.05 _All.Dotm 2.4. Applicant’s details Applicant’s name: Sony Er…
