PY7A3880130Mobile phone with Bluetooth, WLAN 802.11bgn, GPS/A-GPS and FM Rx

Sony Corporation

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Apr 24, 2012
Application Purpose: Original Equipment
Date of Application: Apr 24, 2012
Equipment Note: Mobile phone with Bluetooth, WLAN 802.11bgn, GPS/A-GPS and FM Rx
Frequency Range: 2412.00000000 - 2462.00000000
Company: Sony Corporation
Country: Japan

Documents & Files

Select a file to view

Users Manual

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

External Photos

No.2012WLN0309 Page68 of 73 ©Copyright. All rights reserved by TMC Beijing. ANNEX C: PHOTOGRAPHS OF THE EUT External Photo EUT Photo EUT Photo No.2012WLN0309 Page69 of 73 ©Copyright. All rights reserved by TMC Beijing. Back Label of Mobile Phone Back Label of Mobile Phone No.2012WLN0309 Page70 of 73 ©Copyright. All rights reserved by TMC Beijing. Battery Battery No.2012WLN0309 Page71 of 73 ©Copyright. All rights reserved by TMC Beijing. Travel Charger Label of Travel Charger

ID Label/Location Info

Company Internal MARKING DRAWING 1 (2) Prepared (also subject responsible if other) No. SEM/CVVGP, Leif Hedin 1256-2810 Uen Approved Checked Date Rev Reference SEM/CVVGP, Leif Hedin 2011-12-22 1 2 ST25i, Mobile Phone label, ROW, made in... 1 General information MLCI= Main Label Content Information Document 2 Printing information Content Format Line 1 (13,0/29,0) SIM-card logo Graphics height 11,0 mm. According to 1262-4725. Line 2a (15,5/4,0) Sony Ericsson stylized name. Graphics, height 1,5 mm. According to 1200-1925 Line 2b (19,5/22,0) Model Name “ST25i” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 3a (19,5/4,0) Product number of the Sales Item in which the phone is packed, if applicable. “SI XXXX-XXXX” Text, height 1,2 mm. Line 3b (10,0/22,0) Location code of where the phone is flashed, if applicable, “XXX” Text, height 1,2 mm. Line 4a (23,5/4,0) “TYPE: AAD-3880130-BV” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 4b (23,5/22,0) HW & SW identification field, if applicable; “FFGG” Text, height 1,2 mm. According to Type-testing report under Product Model Specifying Documents Line 5a (26,5/4,0) ”FCC ID: PY7A3880130” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 5b (26,5/22,0) Production week (flash), “yyWww” (yy = year, ww = week) Text, height 1,2 mm. Line 6a (29,5/4,0) “IC: 4170B-A3880130” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 6b (29,5/22,0) Repair week, if applicable. “RyyWww” (yy = year, ww = week) Text, height 1,2 mm. Mobile Phone label part no • 1253-4855 Mobile Phone label content part no • 1256-2809 Bar code • Print quality: according to COSMETIC GUIDELINE – Bar code labels document 1222-6072 Uen • Quiet zone: No bar codes are allowed to be closer to a label edge than 2 mm! Text If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. Coordinates “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. Company Internal MARKING DRAWING 2 (2) Prepared (also subject responsible if other) No. SEM/CVVGP, Leif Hedin 1256-2810 Uen Approved Checked Date Rev Reference SEM/CVVGP, Leif Hedin 2011-12-22 1 2 Line 7 (33,5/4,0) Line 7 in bar code, according to line 8a. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 8a (36,0/4,0) Supplier’s identification for trace-ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,5 mm. Defined by supplier. Line 8b (36,0/19,0) Actual electronic serial number (IMEI) of the mobile phone, “00000000-000000-0” Text, height 1,5mm. In the format TAC-SNR-CD. TAC and SNR derived from pos 500 in BOM. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 9 (38,5/4,0) Line 9 in bar code, according to line 8b. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 10a (46,0/4,0) CE approval symbol, the NB-“0682” and “Alert Symbol” in one artwork Graphics, height 5 mm. According to 1242-7470 Line 10b (46,0/34,0) WEEE trashcan without bar symbol Graphics, min. height 5mm, according to 1202-5537. Line 11 (50,5/4,0) Marking of origin; “Made in Xxx” “Xxx” = actual country of production of the included telephone, in English Text, height 1,2 mm. 3 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 3.1 Conceptual picture double underlined = major changes since last revision.

Internal Photos

No.2012WLN0309 Page72 of 73 ©Copyright. All rights reserved by TMC Beijing. Internal Photo EUT Disassembly EUT Disassembly No.2012WLN0309 Page73 of 73 ©Copyright. All rights reserved by TMC Beijing. EUT Disassembly *** END OF REPORT BODY ***

RF Exposure Info

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: ST25i To: OET Bulletin 65 Supplement C: (2001-01) and RSS-102 Issue 4 March 2010 Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 This Test Report Is Issued Under The Authority Of Chris Guy, Head of Global Approvals: (APPROVED SIGNATORY) Checked By: Richelieu Quoi (APPROVED SIGNATORY) Issue Date: 24 April 2012 Test Dates: 17 April to 21 April 2012 This report is issued in portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by RFI Global Services Ltd. is under license. Other trademarks and trade names are those of their respective owners. Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 2 of 159 RFI Global Services Ltd. This page has been left intentionally blank. Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 3 of 159 RFI Global Services Ltd. TABLE OF CONTENTS 1. Customer Information ...................................................................................................... 4 2. Equipment Under Test (EUT) ........................................................................................... 5 3. Test Specification, Methods and Procedures ................................................................ 9 4. Deviations from the Test Specification ......................................................................... 11 5. Operation and Configuration of the EUT during Testing ............................................ 12 6. Summary of Test Results ............................................................................................... 14 7. Measurements, Examinations and Derived Results .................................................... 16 8. Measurement Uncertainty .............................................................................................. 35 Appendix 1. Test Equipment Used .................................................................................... 42 Appendix 2. Measurement Methods .................................................................................. 45 Appendix 3. Measurement Methods .................................................................................. 48 Appendix 4. SAR Distribution Scans ................................................................................ 50 Appendix 5. Photographs ................................................................................................ 120 Appendix 6. Validation of System ................................................................................... 151 Appendix 7. Simulated Tissues ....................................................................................... 156 Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 4 of 159 RFI Global Services Ltd. 1. Customer Information Company Name: Sony Mobile Communications AB Address: Nya Vattentornet 22188 Lund Sweden Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 5 of 159 RFI Global Services Ltd. 2. Equipment Under Test (EUT) 2.1. Identification of Equipment Under Test (EUT) Description: Mobile Handset Brand Name: Sony Model Name or Number: ST25i Serial Number: BX902ST8TT Type Number: AAD-3880130-BV IMEI Number: 004402144882341 Hardware Version Number: AP2.1 Software Version Number: 6.0.B.1.168 Hardware Revision of GSM Module: Not Applicable Software Revision of GSM Module: Not Applicable FCC ID Number: PY7A3880130 IC Certification Number: 4170B-A3880130 Country of Manufacture: China Date of Receipt: 17 April 2012 Note(s): This sample was used to perform 2G SAR evaluation and conducted power measurements only. The sample supports simultaneous transmission with the WWAN and WLAN antenna > 5 cm apart. Wireless Personal Hotspot is also supported and was evaluated as per KDB 941225 D06 "Hot Spot SAR v01" Description: Mobile Handset Brand Name: Sony Model Name or Number: ST25i Serial Number: BX902ST8KQ Type Number: AAD-3880130-BV IMEI Number: 004402144881855 Hardware Version Number: AP2.1 Software Version Number: s_atp_kumquat_0_0_95_3 Hardware Revision of GSM Module: Not Applicable Software Revision of GSM Module: Not Applicable FCC ID Number: PY7A3880130 IC Certification Number: 4170B-A3880130 Country of Manufacture: China Date of Receipt: 20 April 2012 Note(s): This sample was used to perform WLAN SAR evaluation and conducted power measurements only. The sample supports simultaneous transmission with the WWAN and WLAN antenna > 5 cm apart. Wireless Personal Hotspot is also supported and was evaluated as per KDB 941225 D06 "Hot Spot SAR v01" Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 6 of 159 RFI Global Services Ltd. 2.2. Description of EUT The Equipment Under Test is a Mobile Phone with GSM 2G quad band, 3G dual band and Wi-Fi bands. The EUT has GPRS Class 12 / EDGE Class 33, UMTS FDD I and VIII With HSPA, WLAN 802.11 b/g/n, Bluetooth, ‘Wi-Fi Hotspot’ and ‘Wi-Fi Hotspot Auto RF Power Reduction’ mode capabilities. 2.3. Modifications Incorporated in the EUT EUT (IMEI: 004402144882341) was setup for WWAN SAR test and conducted power measurements only. EUT (IMEI: 004402144881855) was setup for WLAN SAR test and conducted power measurements only. Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 7 of 159 RFI Global Services Ltd. 2.4. Accessories The following accessories were supplied with the EUT during testing: Descr…

Text truncated - open the document above for the full version.

RF Exposure Info

Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 50 of 159 RFI Global Services Ltd. Appendix 4. SAR Distribution Scans This appendix contains SAR distribution scans which are not included in the total number of pages for this report. Scan Reference Number Title SCN/87697/001 Touch Left GSM CH190 SCN/87697/002 Touch Left GSM CH128 SCN/87697/003 Touch Left GSM CH251 SCN/87697/004 Tilt Left GSM CH190 SCN/87697/005 Touch Right GSM CH190 SCN/87697/006 Touch Right GSM CH128 SCN/87697/007 Touch Right GSM CH251 SCN/87697/008 Tilt Right GSM CH190 SCN/87697/009 Front of EUT Facing Phantom GPRS CH190 SCN/87697/010 Rear of EUT Facing Phantom GPRS CH190 SCN/87697/011 Left Hand Side of EUT Facing Phantom GPRS CH190 SCN/87697/012 Right Hand Side of EUT Facing Phantom GPRS CH190 SCN/87697/013 Bottom of EUT Facing Phantom GPRS CH190 SCN/87697/014 Rear of EUT Facing Phantom EDGE CH190 SCN/87697/015 Rear of EUT Facing Phantom GSM CH190 SCN/87697/016 Rear of EUT Facing Phantom GSM CH128 SCN/87697/017 Rear of EUT Facing Phantom GSM CH251 SCN/87697/018 Rear of EUT Facing Phantom GPRS CH128 SCN/87697/019 Rear of EUT Facing Phantom GPRS CH251 SCN/87697/020 Rear of EUT Facing Phantom with PHF GPRS CH251 SCN/87697/021 Touch Left PCS CH661 SCN/87697/022 Touch Left PCS CH512 SCN/87697/023 Touch Left PCS CH810 SCN/87697/024 Tilt Left PCS CH661 SCN/87697/025 Touch Right PCS CH661 SCN/87697/026 Tilt Right PCS CH661 SCN/87697/027 Front of EUT Facing Phantom GPRS CH661 SCN/87697/028 Front of EUT Facing Phantom GPRS CH512 SCN/87697/029 Front of EUT Facing Phantom GPRS CH810 SCN/87697/030 Rear of EUT Facing Phantom GPRS CH661 SCN/87697/031 Rear of EUT Facing Phantom GPRS CH512 SCN/87697/032 Rear of EUT Facing Phantom GPRS CH810 Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 51 of 159 RFI Global Services Ltd. SAR Distribution Scans (Continued) Scan Reference Number Title SCN/87697/033 Left Hand Side of EUT Facing Phantom GPRS CH661 SCN/87697/034 Right Hand Side of EUT Facing Phantom GPRS CH661 SCN/87697/035 Bottom of EUT Facing Phantom GPRS CH661 SCN/87697/036 Front of EUT Facing Phantom EDGE CH661 SCN/87697/037 Front of EUT Facing Phantom EDGE CH512 SCN/87697/038 Front of EUT Facing Phantom EDGE CH810 SCN/87697/039 Front of EUT Facing Phantom PCS CH661 SCN/87697/040 Front of EUT Facing Phantom 15mm GPRS CH810 SCN/87697/041 Front of EUT Facing Phantom with PHF GPRS CH810 SCN/87697/042 Touch Left WLAN 802.11b 1Mbps CH6 SCN/87697/043 Tilt Left WLAN 802.11b 1Mbps CH6 SCN/87697/044 Touch Right WLAN 802.11b 1Mbps CH6 SCN/87697/045 Tilt Right WLAN 802.11b 1Mbps CH6 SCN/87697/046 Touch Left WLAN 802.11g 6Mbps CH6 SCN/87697/047 Touch Left WLAN 802.11n 6_5Mbps CH6 SCN/87697/048 Touch Left WLAN 802.11b 1Mbps CH1 SCN/87697/049 Touch Left WLAN 802.11b 1Mbps CH11 SCN/87697/050 Front of EUT Facing Phantom WLAN 802.11b 1Mbps CH6 SCN/87697/051 Rear of EUT Facing Phantom WLAN 802.11b 1Mbps CH6 SCN/87697/052 Left Hand Side of EUT Facing Phantom WLAN 802.11b 1Mbps CH6 SCN/87697/053 Right Hand Side of EUT Facing Phantom WLAN 802.11b 1Mbps CH6 SCN/87697/054 Top of EUT Facing Phantom WLAN 802.11b 1Mbps CH6 SCN/87697/055 Rear of EUT Facing Phantom WLAN 802.11g 6Mbps CH6 SCN/87697/056 Rear of EUT Facing Phantom WLAN 802.11n 6_5Mbps CH6 SCN/87697/057 Rear of EUT Facing Phantom WLAN 802.11b 1Mbps CH1 SCN/87697/058 Rear of EUT Facing Phantom WLAN 802.11b 1Mbps CH11 SCN/87697/059 Rear of EUT Facing Phantom with PHF WLAN 802.11b 1Mbps CH1 SCN/87697/060 System Performance Check 900MHz Head 17 04 12 SCN/87697/061 System Performance Check 900MHz Body 18 04 12 SCN/87697/062 System Performance Check 900MHz Body 20 04 12 SCN/87697/063 System Performance Check 1900MHz Head 18 04 12 SCN/87697/064 System Performance Check 1900MHz Head 19 04 12 SCN/87697/065 System Performance Check 1900MHz Body 19 04 12 SCN/87697/066 System Performance Check 1900MHz Body 20 04 12 SCN/87697/067 System Performance Check 2450MHz Head 21 04 12 SCN/87697/068 System Performance Check 2450MHz Body 21 04 12 Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 52 of 159 RFI Global Services Ltd. SCN/87697/001: Touch Left GSM CH190 Date/Time: 17/04/2012 DUT: Sony Kumquat; Type: Kumquat 18; Serial: BX902ST8TT 0 dB = 0.868mW/g Communication System: GSM 850 MHz; Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium: 900 MHz HSL Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.9 mho/m; ε r = 43.3; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3814; ConvF(8.75, 8.75, 8.75); Calibrated: 22/09/2011 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn394; Calibrated: 26/01/2012 - Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1207 - Measurement SW: DASY4, V4.7 Build 55; Postprocessing SW: SEMCAD, V1.8 Build 176 Touch Left - Middle/Area Scan (81x131x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.895 mW/g Touch Left - Middle/Zoom Scan (5x5x7) 2 (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 9.14 V/m; Power Drift = 0.018 dB Peak SAR (extrapolated) = 1.08 W/kg SAR(1 g) = 0.828 mW/g; SAR(10 g) = 0.607 mW/g Maximum value of SAR (measured) = 0.868 mW/g Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 53 of 159 RFI Global Services Ltd. SCN/87697/002: Touch Left GSM CH128 Date: 17/04/2012 DUT: Sony Kumquat; Type: Kumquat 18; Serial: BX902ST8TT 0 dB = 0.741mW/g Communication System: GSM 850 MHz; Frequency: 824.2 MHz;Duty Cycle: 1:8.3 Medium: 900 MHz HSL Medium parameters used (interpolated): f = 824.2 MHz; σ = 0.892 mho/m; ε r = 43.4; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3814; ConvF(8.75, 8.75, 8.75); Calibrated: 22/09/2011 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn394; Calibrated: 26/01/2012 - Phantom: SAM 12b; Type: SAM 4.0; Seri…

Text truncated - open the document above for the full version.

RF Exposure Info

Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 120 of 159 RFI Global Services Ltd. Appendix 5. Photographs This appendix contains the following photographs: Photo Reference Number Title PHT/87696/001 Test configuration for the measurement of Specific Absorption Rate (SAR) PHT/87696/002 Touch Left PHT/87696/003 Tilt Left PHT/87696/004 Touch Right PHT/87696/005 Tilt Right PHT/87696/006 Front of EUT Facing Phantom at 10mm separation PHT/87696/007 Front of EUT Facing Phantom at 15mm separation PHT/87696/008 Rear of EUT Facing Phantom at 10mm separation PHT/87696/009 Rear of EUT Facing Phantom at 15mm separation PHT/87696/010 Left Hand Side of EUT Facing Phantom PHT/87696/011 Right Hand Side of EUT Facing Phantom PHT/87696/012 Top of EUT Facing Phantom PHT/87696/013 Bottom of EUT Facing Phantom PHT/87696/014 General setup of EUT Facing Phantom with PHF PHT/87696/015 Front view of EUT PHT/87696/016 Rear view of EUT PHT/87696/017 Left hand Side of EUT PHT/87696/018 Right hand Side of EUT PHT/87696/019 Top View of EUT PHT/87696/020 Bottom View of EUT PHT/87696/021 Internal View of EUT (WWAN Sample) PHT/87696/022 Internal View of EUT (WLAN Sample) PHT/87696/023 PHF View PHT/87696/024 Battery View PHT/87696/025 900 MHz Head Fluid Level PHT/87696/026 900 MHz Body Fluid Level PHT/87696/027 1900 MHz Head Fluid Level PHT/87696/028 1900 MHz Body Fluid Level PHT/87696/029 2450 MHz Head Fluid Level PHT/87696/030 2450 MHz Body Fluid Level Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 121 of 159 RFI Global Services Ltd. PHT/87696/01: Test configuration for the measurement of Specific Absorption Rate (SAR) Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 122 of 159 RFI Global Services Ltd. PHT/87696/02: Touch Left Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 123 of 159 RFI Global Services Ltd. PHT/87696/03: Tilt Left Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 124 of 159 RFI Global Services Ltd. PHT/87696/04: Touch Right Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 125 of 159 RFI Global Services Ltd. PHT/87696/05: Tilt Right Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 126 of 159 RFI Global Services Ltd. PHT/87696/06: Front of EUT Facing Phantom at 10mm separation Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 127 of 159 RFI Global Services Ltd. PHT/87696/07: Front of EUT Facing Phantom at 15mm separation Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 128 of 159 RFI Global Services Ltd. PHT/87696/08: Rear of EUT Facing Phantom at 10mm separation Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 129 of 159 RFI Global Services Ltd. PHT/87696/09: Rear of EUT Facing Phantom at 15mm separation Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 130 of 159 RFI Global Services Ltd. PHT/87696/010: Left Hand Side of EUT Facing Phantom Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 131 of 159 RFI Global Services Ltd. PHT/87696/011: Right Hand Side of EUT Facing Phantom Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 132 of 159 RFI Global Services Ltd. PHT/87696/012: Top of EUT Facing Phantom Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 133 of 159 RFI Global Services Ltd. PHT/87696/013: Bottom of EUT Facing Phantom Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 134 of 159 RFI Global Services Ltd. PHT/87696/014: General setup of EUT Facing Phantom with PHF Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 135 of 159 RFI Global Services Ltd. PHT/87696/015: Front view of EUT Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 136 of 159 RFI Global Services Ltd. PHT/87696/016: Rear view of EUT Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 137 of 159 RFI Global Services Ltd. PHT/87696/017: Left hand Side of EUT Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 138 of 159 RFI Global Services Ltd. PHT/87696/018: Right hand Side of EUT Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 139 of 159 RFI Global Services Ltd. PHT/87696/019: Top View of EUT Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 140 of 159 RFI Global Services Ltd. PHT/87696/020: Bottom View of EUT Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 141 of 159 RFI Global Services Ltd. PHT/87696/021: Internal View of EUT (WWAN Sample) Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 142 of 159 RFI Global Services Ltd. PHT/87696/022: Internal View of EUT (WLAN Sample) Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 143 of 159 RFI Global Services Ltd. PHT/87696/023: PHF View Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 144 of 159 RFI Global Services Ltd. PHT/87696/024: Battery View Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 145 of 159 RFI Global Services Ltd. PHT/87696/025: 900 MHz Head Fluid Level Test Report Serial No: RFI-SAR-RP87697JD01A V1.0 Version 1.0 Issue Date: 24 April 2012 Page: 146 of 159 RFI Global Services Ltd. PHT/87696/026: 900 MHz Body Fluid Level Test Report Serial No: RFI-SAR-RP87697J…

Text truncated - open the document above for the full version.

Test Report

No.2012WLN0309 Page1 of 73 ©Copyright. All rights reserved by TMC Beijing. FCC PART 15C/IC RSS-210 TEST REPORT No. 2012WLN0309 for Sony Ericsson Mobile Communications AB GSM 850/900/1800/1900 quad bands and UMTS FDD 1/8 mobile Type: AAD-3880130-BV With FCC ID: PY7A3880130 IC No.: 4170B-A3880130 Hardware Version: A Software Version: ATP R1A034 Issued Date: 2012-04-06 No. DGA-PL-114/01-02 DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 Note:The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China, 100191 Tel:+86(0)10-62304633, Fax:+86(0)10-62304793 Email:[email protected]. www.emcite.com No.2012WLN0309 Page2 of 73 ©Copyright. All rights reserved by TMC Beijing. CONTENTS CONTENTS ...................................................................................................................................... 2 1. TEST LATORATORY ......................................................................................................... 6 1.1. TESTING LOCATION .............................................................................................................. 6 1.2. TESTING ENVIRONMENT ....................................................................................................... 6 1.3. PROJECT DATA ..................................................................................................................... 6 1.4. SIGNATURE .......................................................................................................................... 6 2. CLIENT INFORMATION .................................................................................................... 7 2.1. APPLICANT INFORMATION ..................................................................................................... 7 2.2. MANUFACTURER INFORMATION ............................................................................................. 7 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT(AE) ...................... 8 3.1. ABOUT EUT ......................................................................................................................... 8 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................................... 8 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................................... 8 3.4. GENERAL DESCRIPTION ....................................................................................................... 9 4. REFERENCE DOCUMENTS ............................................................................................ 9 4.1. DOCUMENTS SUPPLIED BY APPLICANT ................................................................................... 9 4.2. REFERENCE DOCUMENTS FOR TESTING ................................................................................ 9 5. LABORATORY ENVIRONMENT .................................................................................... 10 6. SUMMARY OF TEST RESULTS ..................................................................................... 11 6.1. SUMMARY OF TEST RESULTS ............................................................................................... 11 6.2. STATEMENTS....................................................................................................................... 11 7. TEST EQUIPMENTS UTILIZED...................................................................................... 12 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 13 A.1. MEASUREMENT METHOD ....................................................................................................... 13 A.2. MAXIMUM PEAK OUTPUT POWER ........................................................................................... 14 A.2.1. ANTENNA GAIN ................................................................................................................... 14 A.2.2. MAXIMUM PEAK OUTPUT POWER ........................................................................................ 14 A.3. PEAK POWER SPECTRAL DENSITY ......................................................................................... 14 A.4. OCCUPIED 6DB BANDWIDTH .................................................................................................. 15 FIG. 1 OCCUPIED 6DB BANDWIDTH (802.11B, CH 1) ................................................................. 16 FIG. 2 OCCUPIED 6DB BANDWIDTH (802.11B, CH 6) ................................................................. 16 FIG. 3 OCCUPIED 6DB BANDWIDTH (802.11B, CH 11) ............................................................... 17 FIG. 4 OCCUPIED 6DB BANDWIDTH (802.11G, CH 1) ................................................................. 17 FIG. 5 OCCUPIED 6DB BANDWIDTH (802.11G, CH 6) ................................................................. 18 FIG. 6 OCCUPIED 6DB BANDWIDTH (802.11G, CH 11) ............................................................... 18 No.2012WLN0309 Page3 of 73 ©Copyright. All rights reserved by TMC Beijing. FIG. 7 OCCUPIED 6DB BANDWIDTH (802.11N-HT20, CH 1) ....................................................... 19 FIG. 8 OCCUPIED 6DB BANDWIDTH (802.11N-HT20, CH 6) ....................................................... 19 FIG. 9 OCCUPIED 6DB BANDWIDTH (802.11N-HT20, CH 11) ..................................................... 20 A.5. BAND EDGES COMPLIANCE .................................................................................................... 21 FIG. 10 BAND EDGES (802.11B, CH 1) ..................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Mika Kaneko(Chief Regulatory Compliance Manager)

[email protected]+81367103225Fax: +815038096297

Technical Contact

Sony Mobile Communications ABH�kan Sj�berg

[email protected]

Nya Vattentornet · Lund · Sweden

Test Firm

TMC-Telecommunication Metrology Center of M.I.I.TChongwen Song

[email protected]0086-10-62303288Fax: 0086-10-62304793

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	162.00 mW

Confidentiality

Long Term

Grant Notes

ower listed is conducted. This filing is only applicable for 850/1900 MHz PCS and unlicensed transmitter operations as specified in this filing. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. SAR compliance for body-worn operating configurations is limited to the specific configurations tested for this filing. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1,5 cm separation between the device, including its antenna, and the users body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, wireless router and simultaneous transmission use conditions are 0.28W/kg, 0.10 W/kg, 0.10 W/kg, and 1.09 W/kg, respectively.
