PY7A3880132GSM/UMTS/HSPA Mobile Phone with WLAN, BT, RFID and ANT+

’11.10 INSTRUCTION MANUAL SO-03D Introduction Thank you for your purchase of "SO-03D". For proper use of the SO-03D, read this manual carefully before and while you use the SO-03D. Before using the terminal The SO-03D supports W-CDMA, GSM/GPRS and Wireless LAN Systems. Because the terminal operates using radio frequencies, it cannot be used inside a tunnel, underground, in a building or other locations where radio waves do not reach the terminal, in locations with weak radio wave condition, or outside of the FOMA's service area. The FOMA services may not be available on high upper floors of high-rise apartments or buildings, even if you can see no obstructions around you. On occasion, your calls may become disconnected even in areas with strong radio wave condition, even if you are not moving, or even if there are 4-antenna marks in the terminal's display. Note that because the terminal operates on radio frequencies, your calls are at risk of being intercepted by the third party. However, the W-CDMA, GSM/GPRS system automatically scrambles all calls through a private call feature. Therefore, even if third party successfully intercepts your call, they will only hear noise. The terminal operates on radio frequencies by converting voice into digital signals. If the caller moves into an area of adverse radio wave condition, the digital signal may not restored accurately, and the voice received in the call may differ slightly from the actual voice. Always keep the information you save in the terminal in a separate note. Even if the data may be lost as a result of malfunction, repair, change, or other handling of the terminal, under no condition will DOCOMO be held liable for any lost data saved in the terminal. You are recommended to save important data to microSD card. As with PCs, some user-installed applications may disrupt the stability of the terminal performance, or unexpectedly transmit information via the Internet causing improper use of your location information as well as personal information recorded on the terminal. Therefore, verify the supplier and operating conditions of the applications to be used before using them. This terminal has FOMA Plus-Area and FOMA HIGH-SPEED Area support. Descriptions in this manual are for the terminal with a DOCOMO's UIM inserted. SIM unlock This terminal supports SIM unlock. If you release SIM lock, you can use SIM by a carrier other than NTT DOCOMO. The SIM unlock service is provided at a docomo Shop. A SIM unlock charge is separately required. If you use a SIM other than by DOCOMO, available services and functions will be limited. DOCOMO is not liable to any failures or malfunctions. For details of SIM unlock, refer to NTT DOCOMO website. 1 SO-03D (with warranty and Back Cover SO17) Quick Start Guide (In Japanese only) Notes on usage Safety/Handling precautions (In Japanese only) Battery Pack SO04 AC Adapter Cable SO03 (with warranty) microSDHC card (16GB)* (Sample) (with instruction manual) * Inserted in the terminal when purchased. Stereo Headset with Microphone (Sample) (with instruction manual) For details on optional devices, see "Optional and related devices" (P.193). Accessories Supplied accessories <AC adapter><microUSB cable> 2 In addition to this manual, the operations of SO-03D are described in "Quick Start Guide" (in Japanese only) and "Instruction Manual" application of the terminal. The initial operations and settings after purchasing the terminal, screen view contents and operations of main function are explained. (In Japanese only) Similarly to this manual, operations and settings of each function are explained. To use "Instruction Manual" application, from the Home screen, tap X [Instruction Manual]. For the first time using, download and install it according to the onscreen instructions. You can use the application as an electronic book. You can also shift to actual operations by tapping the description in the contents or view reference contents. ❖Cautions For downloading or updating the application, a high packet communication charge will be applied because of a large amount data communication. For this reason, subscription of packet flat-rate service is highly recommended. * If you use Wi-Fi function to download, packet communication charges are not applied. Operations and settings of each function are explained. It can be downloaded from NTT DOCOMO website. http://www.nttdocomo.co.jp/english/support/ trouble/manual/download/index.html * The URL and contents are subject to change without prior notice. ❖Cautions Reproduction or reprint of all or part of this manual without prior permission is prohibited. Important information for SO-03D is posted in the following website. Be sure to check before using. http://www.sonyericsson.co.jp/support/ use_support/product/so-03d/ About manuals of SO-03D "Quick Start Guide" (Supplied accessories) "Instruction Manual" (Application of the terminal) "Instruction Manual" (PDF file) 3 In this manual, each key operations are described with p, x, y, t, s, m. And selection operations of the icons or function items on the touch panel are described as follows. ❖Information In this manual, the instructions are described with the default Home screen. If you set the other application to the home screen, the operations may differ from the descriptions. Display examples and illustrations used in this manual are just images for explanations and may be different from actual ones. In this manual, the easier procedure is described for the functions and settings which have multiple operating procedures. Please note that "SO-03D" is called the "the terminal" in this manual. Operation descriptions DescriptionOperation From the Home screen, press t and tap [Settings]. From the Home screen, press t (Menu) key and tap "Settings" on the screen. Tap [Settings] X [Date & time] X [Set date]. Tap "Settings" displayed on the screen, and then tap "Date & time" on the next screen and "Set date" on the following screen in …

Text truncated - open the document above for the full version.

Sony Ericsson Confidentiality Request 2012-01-16 CGOBDA12:014 SEMC/CGOBDA Afrah Sadiq +46 10 80 12250 Receiver Federal Communications Commission Subject: Request for Confidentiality FCC 10: PY7 A3880132 To Whom It May Concern: In accordance with §0.459 of CFR 47, Sony Ericsson Mobile Communications AS requests confidentiality for the below listed items for our mobile phone type AAD­ 3880132-BV, FCC 10: PY7A3880132: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. OperationallTechnical Descriptions These items contain detailed system and equipment description and related information about the product which Sony Ericsson Mobile Communications AS considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Ericsson Mobile Communications AS also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Best Regards, Afrah Sadiq Staff Verification Engineer Global Type Approval Sony Ericsson Mobile Communications Nya Vattentornet . 221 88 Lund, Sweden Fax +46 10 8002441 son yericsson .com Sony Ericsson Mobile Communications AB Styrelsens sate: Lund Momsnr · II.A TNo: SE556615665801 Postadress • Mail Besbksadress • Office address Registered office: Lund Telefon • Telephone Organisationsnr • Reg No: 556615-6658 Telefax • Telefax S E-221 88 Lund Nya Vattentornet Nat 046-1 9 40 00 Nat 046-194100 Sweden Lund In! +46 46 19 40 00 int +46 46 1 9 41 00

Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 18 of 33 An ne x B E x te rna l ph ot ogra phs o f the E UT Photo documentation Photo 3: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 19 of 33 Photo 4: Photo 5: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 20 of 33 Photo 6: Photo 7: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 21 of 33 Photo 8: Photo 9:

Company Internal MARKING DRAWINGLABEL CONTENT 1 (3) Prepared (also subject responsible if other) No. Leif Hedin (23056584) 1262-1498 Approved Checked Date Rev Reference Leif Hedin (23056584) 2011-12-12 1 5State: Released SO-03D, Hikari_DCM_JP, Mobile Phone label content 1 General information 2 Printing information Content Format Line 1a (2,0/3,5) “Do not remove this label” statement in Japanese. “ ” Graphics, height 1,2 mm. According to 1234-3822 Line 1b (2,0/32,5) Supplier’s identification for trace-ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,2 mm. Defined by supplier. Line 2 (4,0/32,5) Colour of the included telephone, in English: e.g. “< XXXXX >” Text, height 1,5 mm. English colour names according to Chapter 2.1 in MLCI Line 3 (5,5/32,5) Product number of the Sales Item in which the phone is packed, if applicable. “SI XXXX-XXXX” Text, height 1,2 mm Mobile Phone label part no  1253-4855 Mobile Phone label content part no  1262-1486 Bar code  Print quality: according to COSMETIC GUIDELINE – Bar code labels document 1222-6072 Uen  Quiet zone: No bar codes are allowed to be closer to a label edge than 2 mm! Text If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. Coordinates “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. Company Internal MARKING DRAWINGLABEL CONTENT 2 (3) Prepared (also subject responsible if other) No. Leif Hedin (23056584) 1262-1498 Approved Checked Date Rev Reference Leif Hedin (23056584) 2011-12-12 1 5State: Released Line 4a (7,0/4,5) Line 4a in bar code, according to line 5a (only actual number, without data identifier). Bar code, minimum height 4,5 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. When printing Code 128, minimum width should be more than 0.125mm and should use four kinds of the width of multiplied width to the minimum width used. (x1, x2, x3, x4) White bar should use the same spec. Line 4b (7,0/32,5) Production week (flash), “yyWww” (yy = year, ww = week) Text, height 1,2 mm. Line 4c (7,0/39,0) Location code of where the phone is flashed, if applicable, “XXX” Text, height 1,2 mm. Line 5a (10,0/3,5) “製 “+ Actual electronic serial number (IMEI) of the Mobile Phone, “製 00000000-000000-0” Graphics, height 1,4 mm. According to 1234-3770. Text, height 1,2 mm. In the format TAC-SNR-CD.TAC and SNR derived from pos 500 in BOM. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 5b (10,0/26,2) Type number of the phone, “TYPE: AAD-3880132-BV”. Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 5c (10,0/41,2) HW & SW identification field, if applicable; “FFGG” Text, height 1,2 mm. According to Type-testing report under Product Model Specifying Document Line 6a (12,3/1,0) Production date in Japanese (eg: year+ 年 + month+ 月 ) : “ 0000 年 00 月” Text, height 1,2 mm. Graphics, height 1,4 mm. According to 1234-3763, 1235-6102 and 1235-6103 Line 6b (12,3/31,5) Marking of origin. “Made in Xxx”; “Xxx” = actual country of production of the included telephone, in English Text, height 1,2 mm. Company Internal MARKING DRAWINGLABEL CONTENT 3 (3) Prepared (also subject responsible if other) No. Leif Hedin (23056584) 1262-1498 Approved Checked Date Rev Reference Leif Hedin (23056584) 2011-12-12 1 5State: Released 3 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 3.1 Conceptual picture double underlined = major changes since last revision. Confidential DESCRIPTION 1(3) Document number Revision Uae Prepared by Date Shigeru Iwasaki 2011-11-30 Contents responsible if other than preparer Remarks Approved by Phone label design Abstract This document contains information on the phone label design required for Japanese approval. Product name: AAD-3880132-BV Marketing name: SO-03D Contents 1 Drawing of phone label ........................................................................ 2 2 Label placement on phone .................................................................. 3 Confidential DESCRIPTION 2(3) Document number Revision Uae PA1 1 Drawing of phone label CE marking and FCC id Confidential DESCRIPTION 3(3) Document number Revision Uae PA1 Electronic Display for Radio Law/Tele Biz Law 2 Label placement on phone 6.0 mm

Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 22 of 33 An ne x C Inte r na l p ho to gra phs o f the E UT Photo documentation Photo 10: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 23 of 33 Photo 11: Photo 12: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 24 of 33 Photo 13: Photo 14: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 25 of 33 Photo 15: Photo 16: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 26 of 33 Photo 17: Photo 18: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 27 of 33 Photo 19: Photo 20: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 28 of 33 Photo 21: Photo 22: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 29 of 33 Photo 23: Photo 24: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 30 of 33 Photo 25: Photo 26: Annex to Test Report No.: 1-2977/11-94-02 2011-12-16 Page 31 of 33 Photo 27: Photo 28:

2012-01-18 Page 1 of 75 TEST REPORT Test report no.: 1-2977/11-94-06 Testing laboratory Applicant CETECOM ICT Services GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-01 Area of Testing: Radio/Satellite Communications Sony Ericsson Mobile Communications AB Nya Vattentornet 22188 Lund / SWEDEN Phone: +46 46 19 30 00 Fax: +46 46 19 32 95 Contact: Håkan Sjöberg e-mail: [email protected] Phone: +46 46 19 35 59 Manufacturer Sony Ericsson Mobile Communications AB Nya Vattentornet 22188 Lund / SWEDEN Test standard/s 47 CFR Part 15 Title 47 of the Code of Federal Regulations; Chapter I Part 15 - Radio frequency devices RSS - 210 Issue 8 Spectrum Management and Telecommunications - Radio Standards Specification Low-power Licence-exempt Radiocommunication Devices (All Frequency Bands): Category I Equipment For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: GSM Mobile Phone 850/900/1800/1900; GPRS/EGPRS; UMTS FDDI/FDDV/FDDVI/FDDIX/FDDXIX; HSPA; RFID; BT EDR; WLAN b/g/n; ANT+; GPS Model name: AAD-3880132-BV FCC ID: PY7A3880132 IC: 4170B-A3880132 Frequency [MHz]: ISM band 2400 MHz to 2483.5 MHz (lowest channel 2402 MHz, highest channel 2480 MHz) Technology tested: ANT+ Antenna: Integrated PCB antenna Power Supply: 3.7 V DC by Li-polymer battery Temperature Range: -20°C to +5 °C Test report authorised: Test performed: 2012-01-18 Stefan Bös 2012-01-18 Jakob Reschke Senior Testing Manager Testing Manager Test report no.: 1-2977/11-94-06 2012-01-18 Page 2 of 75 1 Table of contents 1 Table of contents ............................................................................................................................................ 2 2 General information ....................................................................................................................................... 3 2.1 Notes and disclaimer .......................................................................................................................... 3 2.2 Application details ............................................................................................................................... 3 3 Test standard/s ............................................................................................................................................... 3 4 Test environment ............................................................................................................................................ 4 5 Test item .......................................................................................................................................................... 4 6 Test laboratories sub-contracted ................................................................................................................. 4 7 Summary of measurement results ............................................................................................................... 5 8 RF measurements .......................................................................................................................................... 6 8.1 Description of test setup .................................................................................................................... 6 8.1.1 Radiated measurements............................................................................................................. 6 8.2 Additional comments .......................................................................................................................... 7 8.3 RSP100 test report cover sheet / performance test data ................................................................ 8 9 Measurement results ...................................................................................................................................... 9 9.1 Timing of the transmitter .................................................................................................................... 9 9.2 Spectrum bandwidth – 99% bandwidth ........................................................................................... 11 9.3 Maximum field strength .................................................................................................................... 14 9.4 Band edge compliance radiated ...................................................................................................... 15 9.5 TX spurious emissions radiated ...................................................................................................... 18 9.6 RX spurious emissions radiated ...................................................................................................... 29 9.7 Spurious emissions radiated < 30 MHz ........................................................................................... 33 9.8 Spurious emissions conducted < 30 MHz....................................................................................... 36 10 Test equipment and ancillaries used for tests ................................................................................... 39 11 Observations ......................................................................................................................................... 40 Annex A Photographs of the test setup ...................................................................................................... 41 Annex B External photographs of the EUT ......................................................................................…

Text truncated - open the document above for the full version.

Test report no.: 1-2977/11-94-04 2012-01-10 Page 78 of 113 An nex A Pho tog raphs o f t h e test se tu p Photo documentation: Photo 1: Photo 2: Test report no.: 1-2977/11-94-04 2012-01-10 Page 79 of 113 Photo 3: Photo 4: Test report no.: 1-2977/11-94-04 2012-01-10 Page 80 of 113 Photo 5: Photo 6: Test report no.: 1-2977/11-94-04 2012-01-10 Page 81 of 113 Photo 7: Photo 8: Test report no.: 1-2977/11-94-04 2012-01-10 Page 82 of 113 Photo 9: Photo 10:
