PY7A5880014Mobile phone with Bluetooth and GPS

Introduction Thank you for purchasing the URBANO AFFARE. Before using your cell phone, be sure to read the cell phone Basic Manual (this PDF manual) to ensure correct usage. After you have finished reading this manual, store this PDF manual and the printed manuals in safe places so you can retrieve them whenever you need them.Manuals for the cell phoneThere are three manuals for the cell phone: the Basic Manual, printed Instruction Manual (Japanese) and full Instruction Manual (Japanese). For learning the basics: Read the cell phone Basic Manual (this manual) or printed cell phone Instruction Manual (Japanese). For learning details of each function: The full Instruction Manual (Japanese) gives detailed instructions on using each function and can be downloaded from the au homepage: http://www.au.kddi.com/torisetsu/index.html To ensure proper usage of the cell phone, be sure to read the Safety Precautions " " in the Instruction Manual.The keyword searchable au Online Manual is also available on the au homepage: http://www.au.kddi.com/manual/index.html To access from EZweb (free of packet communication charge): R au Customer Support OK (Online Manual) Scan this QR code to access the au Online Manual. • 1 Illustrations and Screenshots in This Manual Illustrations and Screenshots in This Manual Note on Illustrations The illustrations in this manual may look different from the actual cell phone in shape, color and typeface. The key illustrations are also simplified as shown below. Key Illustration Key Illustration cjs % & R L C N F 123456789*0# m ( Note on Screenshots The screenshots in this manual are simplified and may look different from the actual cell phone screens. 2 Notes on Cell Phone Use Notes on Cell Phone Use Cell Phone EtiquetteThe cell phone always emits weak radio waves when power is on.Use the cell phone in an enjoyable and safe manner without forgetting to be considerate of others around you. Use of cell phones is not allowed in some places.Do not use the cell phone while you are driving. Doing so is both dangerous and prohibited by law.Using a cell phone in an aircraft is prohibited by law. Set Airplane Mode to ON and turn the cell phone power off.Radio waves from cell phones may interfere with medical electrical equipment.Some people close to you in crowded places such as packed trains may be using a cardiac pacemaker. Turn the cell phone off in such places.Abide by the rules of hospitals and other medical institutions where it is forbidden to use or carry cell phones.Be considerate of where you use the cell phone and how loudly you talk.Do not make calls in theaters, museums, libraries, and other similar places. Turn power off or turn on manner mode not to disturb others around you by ring tones.Do not use the cell phone on a street where you might interrupt the flow of pedestrians.Move to areas where you will not inconvenience others on trains or in hotel lobbies.Refrain from talking in a loud voice. •• •• •••• Obtain the permission of other people before you take their photos with the cell phone's camera.Do not record information with the cell phone's camera in bookstores and other locations where taking photos is not permitted. Do Not Use the Cell Phone While Driving!Turn off your cell phone or put it in Drive Mode while driving. Do not use the cell phone while driving a car/motorcycle or riding a bicycle. It may result in a traffic accident. Using a cell phone while driving is prohibited by law. Using a cell phone while riding a bicycle may also be punishable by law. Prohibited! Looking at a cell phone displayTalking on a cell phone while holding it Drive ModeIn Drive Mode, a Japanese message meaning "I am driving right now. Please leave your name and message after the beep." is played when a call is received, and asks the caller to leave a message on the answer memo. When the standby screen is displayed, press , use to select Drive , and then press (Set). •• • • 3 Notes on Cell Phone Use Disaster Message Board Service When a large scale disaster occurs, you can register your safety information from EZweb. The registered information can be referred from anywhere in Japan from EZweb or Internet. When a large scale disaster occurs, from an au phone, you can register your safety information (i.e. your condition and comments) to the (Disaster Message Board) created on the EZweb.After registration of your safety information, e-mail is sent to your family or acquaintances you have previously designated to notify that your safety information has been uploaded to the (Disaster Message Board).You can inquire for safety information of a person by entering his/her phone number from EZweb or Internet.** To inquire from other carriers' cell phone, a PHS or PC, access "http://dengon.ezweb.ne.jp/". Access R au one Top (Disaster Message Board)http://dengon.ezweb.ne.jp/ ••• Registered information is stored until the service set up for the disaster ends.The maximum available number of registrations is 10 per phone number. When the number of registrations exceeds 10, the oldest one is overwritten.The demonstration of this service can be referred to anytime by pressing au Customer Support OK (Disaster Message Board (Demo Version)).To view the Disaster Message Board in English, select English from the top menu of the Disaster Message Board. •••• Registering safety information Registering safety information Inquiring for safety information Inquiring for safety information 4 Contents Contents IntroductionIllustrations and Screenshots in This Manual 1 Notes on Cell Phone Use 2 Cell Phone Etiquette ..................................................... 2 Do Not Use the Cell Phone While Driving! ................... 2Disaster Message Board Service ................................. 3 Contents 4Getting Ready 6 Checking the Contents of the Box ................................ 6Names of Parts ............................................................. 7 Charging the Battery Pack......................…

Text truncated - open the document above for the full version.

Sony Ericsson Confidentiality Request 2011-10-11 CVDVBA11 :522 SEMC/CVDVBA Afrah Sadiq +46 10 8012250 Receiver Federal Communications Commission Subject: Request for Confidentiality FCC 10: PY7 A5880014 To Whom It May Concern: In accordance with §0.459 of CFR 47, Sony Ericsson Mobile Communications AS requests confidentiality for the below listed items for our mobile phone type AAH­ 5880014-BV, FCC ID: PY7A5880014: 1. Block Diagram 2. Schematic Diagram 3. Part List 4 . OperationallTechnical Descriptions These items contain detailed system and equipment description and related information about the product which Sony Ericsson Mobile Communications AS considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Ericsson Mobile Communications AS also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Best Regards, Afrah Sadiq Staff Verifi cation Engineer Glob al Type Approval Sony Ericsson Mobile Communications Nya Vattentornet 221 88 Lund, Sweden Fax: +46 10 8002441 sonyericsson .com Sony Ericsson Mobile Communicat ions AS Styrelsens sate: Lund Momsnr· II.A. T No: SE556615665801 Registered office: L und Organisationsnr • Reg No: 556615-6658 P ost adress • Mail Besbksadress • Office address Telefon • Telephone Telefax • Telefax SE-221 88 Lund Nya Vatt ent orn et Nat 0 10-80 00000 Nat 010-80 02040 Sweden Lund I nt +46 10 80 00000 Int +46 10 80 02040

Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 18 of 29 An ne x B E x te rna l ph ot ogra phs o f the E UT Photo documentation Photo 3: Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 19 of 29 Photo 4: Photo 5: Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 20 of 29 Photo 6: Photo 7: Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 21 of 29 Photo 8: Photo 9:

Confidential MARKING DRAWING 1(5) Document number Revision 1/151 86-FCP 119 1168 Uen A Prepared by Date SEM/CVOAHBB SHINGO OTSUKA 2011-07-15 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CVOAAPP (ATSUSHI TAKAGI) Note: Any hard copy of this document is for reference only. Due to template and application dependencies the header and footer may fail to display correct data. It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. AAH-5880014-BV CDMA SOY05 Marking Drawing(Label Details) 1. General Information This is KDDI’s OEM product. The label is based on the requirement of KDDI and it has been approved. 2. Printing Information Content Format Line 1a Symbol of insertion direction for microSD and micro SD Graphic, height : 2.8 mm Line 1b Please be careful with inserting direction Text, height : 1.0 mm Line 1c Symbol of insertion direction for auIC card And IC card Graphic, height : 2.8 mm Line 2a Operator's name (Logo: au by KDDI) Graphic, height : 2.5 mm Line 2b Official name (CDMA SOY05) Text, height : 1.4 mm Line 3 Sony Ericsson stylized name Graphic, height : 2.0 mm Line 4a Operator’s product code Text, height : 1.5 mm Line 4b SOY05XXX (Operator's product code) Text, height : 1.5 mm Line 5a Type number: AAH-5880014-BV Text, height : 1.2 mm Line 5b HW&SW identification field: AAAA Text, height : 1.2 mm Line 6 The name of distribution company: KDDI Inc and Okinawa Cellular Telephone Company Text, height : 1.2 mm Line 7a Manufacture : Applicant Text, height : 1.2 mm Line 7b&10 Sony Ericsson Mobile Communications AB (The name of manufacture) Text, height : 1.2 mm Line 8 JATE number: AD11-XXXXXXX Text, height : 1.0 mm Line 9 Telecommunications mark Graphic, height : 1.0 mm Line 11 TELEC number (for CDMA): 001XZAA1327 Text, height : 1.0 mm Line 12 TELEC number (for MC-CDMA): 001ZYAA1123 Text, height : 1.0 mm Line 13 TELEC number (for T-CDMA): 001NXAA1188 Text, height : 1.0 mm Line 14 Radio Law certification number mark Graphic, height : 1.0 mm Line 15 Bluetooth figure mark (Bluetooth logo) Graphic, height : 3.0 mm Confidential MARKING DRAWING 2(5) Document number Revision 1/151 86-FCP 119 1168 Uen A Line 16 TELEC number (for T-CDMA MC): 001XUAA1015 Text, height : 1.0 mm Line 17 TELEC symbol Graphic, height : 5.2 mm Line 18 TELEC number (for Bluetooth): 001WWDA1537 Text, height : 1.0 mm Line 19 FCC ID: PY7A5880014 Text, height : 1.0 mm Line 20 ARIB mark Graphic, height : 2.25 mm Line 21 IC ID: 4170B-A5880011 Text, height : 1.0 mm Line 22a Date of manufacture Text, height : 1.5 mm Line 22b 20XX/XX (Year/Month: Date of manufacture) Text, height : 1.5 mm Line 23 Line 22 in bar code for Manufacturing number for KDDI Bar code height : 2.5 mm Line 24a Number of manufacture Text, height : 1.5 mm Line 24b Manufacturing number for KDDI (SSOXXXXXXXX) Text, height : 1.5 mm Line 25 Line 24 in bar code for IMEI number Bar code height : 2.5 mm Line 26 IMEI number (IMEI XXXXXXXXXXXXXXX) Text, height : 1.5 mm Line 27a Recycling Li-ion symbol Graphic, height : 6.8 mm Line 27b CE approved symbol Graphic, height : 5.0 mm Line 27c Trash can mark Graphic, height : 5.0 mm Line 28a Caution symbol Graphic, height : 1.2 mm Line 28b Caution message. "Please turn off power in an airplane and in a hospital Text, height : 1.2 mm Line 29 Caution message. "Please do not peel off this sticker" Text, height : 1.2 mm Line 30 Marking of Origin: Made in Japan Text, height : 1.0 mm Confidential MARKING DRAWING 3(5) Document number Revision 1/151 86-FCP 119 1168 Uen A 3. Layout Confidential MARKING DRAWING 4(5) Document number Revision 1/151 86-FCP 119 1168 Uen A 4. Dimensions Confidential MARKING DRAWING 5(5) Document number Revision 1/151 86-FCP 119 1168 Uen A Label placement To find the label follow these steps: 1. Remove the cover on the rear side of the product. 2. Remove the battery. 3. The label is located behind the battery. Rear side of the phone Place for battery Label placement

Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 22 of 29 An ne x C Inte r na l p ho to gra phs o f the E UT Photo documentation Photo 10: Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 23 of 29 Photo 11: Photo 12: Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 24 of 29 Photo 13: Photo 14: Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 25 of 29 Photo 15: Photo 16: Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 26 of 29 Photo 17: Photo 18: Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 27 of 29 Photo 19: Photo 20: Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 28 of 29 Photo 21: Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 29 of 29 An ne x D Doc u me n t his to r y Version Applied changes Date of release 1.0 Initial release 2011-10-04 An ne x E Fur the r in for ma ti o n Glossary AVG - Average DUT - Device under test EMC - Electromagnetic Compatibility EN - European Standard EUT - Equipment under test ETSI - European Telecommunications Standard Institute FCC - Federal Communication Commission FCC ID - Company Identifier at FCC HW - Hardware IC - Industry Canada Inv. No. - Inventory number N/A - Not applicable PP - Positive peak QP - Quasi peak S/N - Serial number SW - Software

2011-10-05 Page 1 of 29 TEST REPORT Annex to Test Report No.: 1-2977-59-03/11 Testing Laboratory Applicant CETECOM ICT Services GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken/Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom-ict.de e-mail: [email protected] Accredited Test Laboratory: The test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 DAkks registration number: D-PL-12076-01-01 Area of Testing: Radio Satellite Communications Sony Ericsson Mobile Communications AB Nya Vattentornet 22188 Lund/SWEDEN Phone: +46 46 19 30 00 Fax: +46 46 19 32 95 Contact: Håkan Sjöberg e-mail: [email protected] Phone: +46 46 19 35 59 Manufacturer Sony Ericsson Mobile Communications AB Nya Vattentornet 22188 Lund/SWEDEN Test Standard/s 47 CFR Part 15 Title 47 of the Code of Federal Regulations; Chapter I Part 15 - Radio frequency devices ICES-003 Issue 4 Spectrum Management and Telecommunications Policy Interference-Causing Equipment Standard For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: Mobile Phone GSM 900,1800,1900; CDMA 2000 Band0/3/6; BT EDR; RFID; GPS Model name: AAH-5880014-BV FCC ID: PY7A5880014 IC: 4170B-A5880014 Frequency : GSM:1850.2 – 1909.8 MHz CDMA2000: 826.4 – 848.6 MHz Power supply: 3.70 V DC by Li-Ion Battery Temperature range: -30 °C to 60 °C Test performed: Test Report authorised: p. o. 2011-10-05 Jakob Reschke 2011-10-05 Marco Bertolino Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 2 of 29 1 Table of contents 1 Table of contents ............................................................................................................................................ 2 2 General Information ....................................................................................................................................... 3 2.1 Notes ..................................................................................................................................................... 3 2.2 Application details ............................................................................................................................... 3 3 Test standard/s ............................................................................................................................................... 3 4 Test Environment ........................................................................................................................................... 3 5 Test item .......................................................................................................................................................... 4 6 Test Laboratories sub-contracted ................................................................................................................ 4 7 Summary of Measurement Results .............................................................................................................. 5 7.1 Receiver ................................................................................................................................................ 5 8 Measurement Results .................................................................................................................................... 6 8.1 RX Spurious Emissions Conducted < 30 MHz ................................................................................. 6 8.2 Spurious Emissions Radiated – Receiver Mode .............................................................................. 9 9 Test equipment and ancillaries used for tests .......................................................................................... 14 Annex A Photographs of the test setup ...................................................................................................... 16 Annex B External photographs of the EUT ................................................................................................. 18 Annex C Internal photographs of the EUT .................................................................................................. 22 Annex D Document history .......................................................................................................................... 29 Annex E Further information ........................................................................................................................ 29 Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 3 of 29 2 General Information 2.1 Notes The test results of this test report relate exclusively to the test item specified in this test report. CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of CETECOM ICT Services GmbH. 2.2 Application details Date of receipt of order: 2011-07-04 Date of receipt of test item: 2011-09-05 Start of test: 2011-09-05 End of test: 2011-09-30 Person(s) present during the test: -/- 3 Test standard/s Test Standard Date Test Standard Description 47 CFR Part 15 2010-10 Title 47 of the Code of Federal Regulations; Chapter I Part 15 - Radio frequency devices ICES-003 Issue 4 2004-04 Spectrum Management and Telecommunications Policy Interference-Causing Equipment Standard 4 Test Environment Temperature: T nom T max T min +25 °C during room temperature tests +60 °C during high temperature tests -30 °C during low temperature tests Relative humidity: 48 % Air pressure: not relevant for this kind of testing Power supply: V nom V max V min 3.70 V DC by Li-Ion Battery 4.40 V 3.30 V Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 4 of 29 5 Test item Kind of test item : Mobile Phone GSM 900,…

Text truncated - open the document above for the full version.

Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 16 of 29 An ne x A P ho tog ra phs o f t h e te s t s e tu p Photo documentation Photo 1: Annex to Test Report No.: 1-2977-59-03/11 2011-10-05 Page 17 of 29 Photo 2:
