PPreflighted byreflighted byPreflighted by ( )( )( ) PPreflighted byreflighted byPreflighted by ( )( )( ) 1 Contents Getting started . . . . . . . . . . . . . . . . . . 4 Assemble the phone, SIM card, battery, make a call, replace covers. Getting to know your phone . . . . . . . . 9 Phone overview, use the menus, enter letters, activity menu, and file manager. Calling . . . . . . . . . . . . . . . . . . . . . . . . 18 Calls, contacts, voice control, call options. Messaging . . . . . . . . . . . . . . . . . . . . . 34 Text messaging, picture messaging, voice messaging, email, My friends. Imaging . . . . . . . . . . . . . . . . . . . . . . . 43 Camera, video recorder, pictures, PhotoDJ™. Entertainment . . . . . . . . . . . . . . . . . . 48 Media player, PlayNow™, ringtones, MusicDJ™, VideoDJ™, sound recorder, themes, games. Connectivity . . . . . . . . . . . . . . . . . . . . 56 Internet and email settings, synchronizing, Bluetooth, infrared, and optional USB cable. More features . . . . . . . . . . . . . . . . . . . 65 Time and date, alarm clock, calendar, tasks, Java™ applications, SIM card lock, etc. Troubleshooting . . . . . . . . . . . . . . . . . 73 Why doesn’t the phone work the way I want? Important information . . . . . . . . . . . . 77 Sony Ericsson Consumer Web site, safe and efficient use, warranty, declaration of conformity. Icons . . . . . . . . . . . . . . . . . . . . . . . . . . 86 Icon descriptions. Index . . . . . . . . . . . . . . . . . . . . . . . . . 88 PPreflighted byreflighted byPreflighted by ( )( )( ) 2 Sony Ericsson GSM 900/1800/1900 This user guide is published by Sony Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this user guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this user guide. All rights reserved. ©Sony Ericsson Mobile Communications AB, 2005 Publication number: EN/LZT 108 8066 R1A Please note: Some of the services in this user guide are not supported by all networks. This also applies to the GSM International Emergency Number 112. Please contact your network operator or service provider if you are in doubt whether you can use a particular service or not. Please read the Guidelines for safe and efficient useand the Limited warranty chapters before you use your mobile phone. Your mobile phone has the capability to download, store and forward additional content, e.g. ringtones. The use of such content may be restricted or prohibited by rights of third parties, including but not limited to restriction under applicable copyright laws. You, and not Sony Ericsson, are entirely responsible for additional content that you download to or forward from your mobile phone. Prior to your use of any additional content, please verify that your intended use is properly licensed or is otherwise authorized. Sony Ericsson does not guarantee the accuracy, integrity or quality of any additional content or any other third party content. Under no circumstances will Sony Ericsson be liable in any way for your improper use of additional content or other third party content. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Ericsson is under license. QuickShare™, PlayNow™, MusicDJ™, VideoDJ™ and Style-Up™ are trademarks or registered trademarks of Sony Ericsson Mobile Communications AB. Microsoft, Windows and PowerPoint are either registered trademarks or trademarks of Microsoft Corporation in the U.S and other countries. Mac OS is a trademark of Apple Computer, Inc., registered in the U.S. and other countries. T9™ Text Input is a trademark or a registered trademark of Tegic Communications. T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, PPreflighted byreflighted byPreflighted by ( )( )( ) 3 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057, United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide. Java and all Java based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. End-user license agreement for Sun™ Java™ J2ME™. 1Restrictions: Software is confidential copyrighted information of Sun and title to all copies is retained by Sun and/or its licensors. Customer shall not modify, decompile, disassemble, decrypt, extract, or otherwise reverse engineer Software. Software may not be leased, assigned, or sublicensed, in whole or in part. 2Export Regulations: Software, including technical data, is subject to U.S. export control laws, including the U.S. Export Administration Act and its associated regulations, and may be subject to export or import regulations in other countries. Customer agrees to comply strictly with all such regulations and acknowledges that it has the responsibility to obtain licenses to export, re-export, or import Software. Software may not be downloaded, or otherwise exported or re-exported (i) into, or to a national or resident of, Cuba, Iraq, Iran, North Korea, Libya, Sudan, Syria (as such listing may be revised from time to time) or any country to which the U.S. has embargoed goods; or (ii) to anyone on the U.S. Treasury Department’s list of Specially Designated Nations or the U.S. Commerce Department’s Table of Denial Orders. 3Restricted Rights: Use, duplication or disclosure by the United States government is subject to the restrictions as set forth in the Rights in Technical Data and Computer Software Clauses in DFARS 252.227-7013(c) (1) (ii) and FAR 52.227-19(c) (2) as applicable. Part of the software in this product is copyright © …

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4071-01-02/05 Date: 2005-08-19 Page 1 of 37 \\ut55\2_PROJEKTE\05\4071_1\Task2(MCP)\Annex to 2-4071-01-02_05.doc Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463 (IC) TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number DAT-P-176/94-D1 Independent ETSI compliance test house ETSI Accredited Bluetooth ® Test Facility (BQTF) Annex to Test report no. : 2-4071-01-02/05 Applicant : Sony Ericsson Mobile Communications AB Test Standard : FCC Part 15 / RSS210 CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4071-01-02/05 Date: 2005-08-19 Page 2 of 37 Table of contents 1.1. ADMINISTRATIVE DATA OF THE TEST FACILITY........................................................................................................... 3 1.1.1 Identification of the testing laboratory ............................................................................................................... 3 1.2. NOTES......................................................................................................................................................................... 3 1.3 DETAILS OF APPLICANT............................................................................................................................................... 4 1.4 APPLICATION DETAILS................................................................................................................................................ 4 1.5 TEST SET-UP(S) ........................................................................................................................................................... 5 1.7 TEST SPECIFICATIONS.................................................................................................................................................. 5 2 STATEMENT OF COMPLIANCE ................................................................................................................................ 6 2.1 SUMMARY OF MEASUREMENT RESULTS...................................................................................................................... 6 2.1.1 CFR 47 Part 15 Radio frequency devices ........................................................................................................... 6 3 MEASUREMENTS AND RESULTS ............................................................................................................................. 7 4 ANNEX A: FCC PART 15 SUBPART B........................................................................................................................ 8 4.1 Conducted Limits .................................................................................................................................................... 8 5 ANNEX B PHOTOGRAPHS OF TEST SITE............................................................................................................. 15 6 ANNEX C: EXTERNAL PHOTOGRAPHS OF THE EQUIPMENT....................................................................... 20 7 ANNEX D: INTERNAL PHOTOGRAPHS OF THE EQUIPMENT........................................................................ 28 CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4071-01-02/05 Date: 2005-08-19 Page 3 of 37 1 GENERAL INFORMATION 1.1. Administrative data of the test facility 1.1.1 Identification of the testing laboratory Company name: Cetecom ICT Services GmbH Address: Untertürkheimerstr. 6-10 D-66117 Saarbruecken Germany Laboratory accreditation: DAR-Registration No. DAT-P-176/94-D1 Bluetooth Qualification Test Facility (BQTF) Federal Communications Commission (FCC) Identification/Registration No : 90462 Responsible for testing laboratory: Dirk Hausknecht Phone: +49 681 598 0 Fax: +49 681 598 9075 email: [email protected] 1.2. Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. .......................................... Responsible for testing laboratory (Gillmann D.) ..................................................................................... Responsible for testing laboratory (Dirk Hausknecht) CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4071-01-02/05 Date: 2005-08-19 Page 4 of 37 1.3 Details of Applicant Name : Sony Ericsson Mobile Communications AB Address : Torshamnsgatan 27 City : S-164 94 Kista Country : Sweden Phone : +46 8 508 77 056 Fax : +46 8 404 3430 Contact : Mr. Kenth Skoglund Phone : +46 8 508 77 056 Fax : +46 8 404 3430 e-mail : [email protected] 1.4 Application Details Date of receipt of application : 2005-08-17 Date of receipt of test item : 2005-08-17 Date(s) of test : 2005-08-18 to 2005-08-19 Date of report : 2005-08-19 CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4071-01-02/05 Date: 2005-08-19 Page 5 of 37 1.5 T…

Text truncated - open the document above for the full version.

Company Internal MARKING DRAWING 1 (3) Prepared (also subject responsible if other) No. SEM/BGUDBB, Niklas Lövberg 151 86–SVV 107 376/1 Uen Approved Checked Date Rev Reference SEM/BGUDBB (Niklas Lövberg) 2005-07-06 P1A 2 Approved according to 000 21–LXE 107 42/1 Z520i, KRH-label, TYPE: AAC-1052011-BV, Made in... 1 General information The format of the label is based on a label SVF 930 1447 (44,0 x 16,5 mm). If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. All bar codes, when applicable, are according to Ericsson corporate standard 102 01–109 Uen. All bar codes shall fulfil minimum print quality C according to ANSI X3.182-1990 as stated in Ericsson corporate standard 102 01–1003 Uen. No bar codes are allowed to be closer to a label edge than 2 mm! (quiet zone). “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. The label shall be placed on the back of the telephone according to the Assembly Drawing (151 88-) for the KRH. 2 Printing information Content Format Line 1a (2,3/1,0) Sony Ericsson stylized name. Graphics, height 1,3 mm. According to 190 89–EN/LZT 108 5347 Line 1b (2,1/12,0) Model name, “Z520i” Text, height 1,2 mm. Line 1c (2,1/16,0) Product number of the DPY kit in which the phone is packed. Printed without “DPY 101” and R-state, “0000/000” Text, height 1,2 mm. Line 2a (3,9/1,0) Type number of the phone (KRH), “Type: AAC-1052011-BV”. Text, height 1,2 mm. Line 2b (3,9/17,0) ROA and R-state identification field, “GHY 1 Y 2 Y 3 ” Text, height 1,2 mm. According to the 3/151 86- document in the 1095- for the SVV. Company Internal MARKING DRAWING 2 (3) Prepared (also subject responsible if other) No. SEM/BGUDBB, Niklas Lövberg 151 86–SVV 107 376/1 Uen Approved Checked Date Rev Reference SEM/BGUDBB (Niklas Lövberg) 2005-07-06 P1A 2 Content Format Line 3a (5,8/1,0) Country approval mark 1 “FCC ID: PY7AC052011” Text, height 1,2 mm. Line 3b (5,8/15,0) Production week (flash), “yy’W’ww” (yy = year, ww = week) Text, height 1,2 mm. Line 3c (5,8/22,0) CE approval symbol. Graphics, height 5 mm. According to 1424-SVF 930 52. Line 3d (5,8/28,9) The Notified body number. “0682” Text, height 2,0 mm. Line 4a (7,6/1,0) Country approval mark 2 “IC: 4170B-AC052011” Text, height 1,2 mm. Line 4b (7,6/15,0) Marking of origin. The line shall be printed as stated in chapter 3 in this document. Text, height 1,2 mm. Line 5 (9,9/1,0) Line 6a in bar code. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 6a (11,2/1,0) Supplier’s identification for trace- ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,2 mm. Defined by supplier. Line 6b (11,2/13,0) Actual electronic serial number (IMEI) of the phone (KRH), “00000000-000000-0” Text, height 1,2 mm. In the format TAC-SNR-CD. TAC and SNR derived from the 3/151 86- document in the 1095- for the SVV. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 7 (12,8/28,5) Location code of where the phone is flashed, if applicable, “FFF” Text, height 1,2 mm. Line 8a (15,5/1,0) Line 6b in bar code (only actual number, without data identifier). Bar code, height 4,0 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. Line 8b (15,5/27,0) Repair week, if applicable. “Ry’W’ww” (y = year, ww = week) Text, height 1,2 mm. Company Internal MARKING DRAWING 3 (3) Prepared (also subject responsible if other) No. SEM/BGUDBB, Niklas Lövberg 151 86–SVV 107 376/1 Uen Approved Checked Date Rev Reference SEM/BGUDBB (Niklas Lövberg) 2005-07-06 P1A 2 3 Marking of Origin 3.1 Content “Made in Xxx”; “Xxx” = actual country of production of the included telephone, in English 4 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 4.1 Conceptual picture double underlined = major changes since last revision.

CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4071-01-02/05 Date: 2005-08-19 Page 1 of 37 \\ut55\2_PROJEKTE\05\4071_1\Task2(MCP)\Annex to 2-4071-01-02_05.doc Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463 (IC) TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number DAT-P-176/94-D1 Independent ETSI compliance test house ETSI Accredited Bluetooth ® Test Facility (BQTF) Annex to Test report no. : 2-4071-01-02/05 Applicant : Sony Ericsson Mobile Communications AB Test Standard : FCC Part 15 / RSS210 CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4071-01-02/05 Date: 2005-08-19 Page 2 of 37 Table of contents 1.1. ADMINISTRATIVE DATA OF THE TEST FACILITY........................................................................................................... 3 1.1.1 Identification of the testing laboratory ............................................................................................................... 3 1.2. NOTES......................................................................................................................................................................... 3 1.3 DETAILS OF APPLICANT............................................................................................................................................... 4 1.4 APPLICATION DETAILS................................................................................................................................................ 4 1.5 TEST SET-UP(S) ........................................................................................................................................................... 5 1.7 TEST SPECIFICATIONS.................................................................................................................................................. 5 2 STATEMENT OF COMPLIANCE ................................................................................................................................ 6 2.1 SUMMARY OF MEASUREMENT RESULTS...................................................................................................................... 6 2.1.1 CFR 47 Part 15 Radio frequency devices ........................................................................................................... 6 3 MEASUREMENTS AND RESULTS ............................................................................................................................. 7 4 ANNEX A: FCC PART 15 SUBPART B........................................................................................................................ 8 4.1 Conducted Limits .................................................................................................................................................... 8 5 ANNEX B PHOTOGRAPHS OF TEST SITE............................................................................................................. 15 6 ANNEX C: EXTERNAL PHOTOGRAPHS OF THE EQUIPMENT....................................................................... 20 7 ANNEX D: INTERNAL PHOTOGRAPHS OF THE EQUIPMENT........................................................................ 28 CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4071-01-02/05 Date: 2005-08-19 Page 3 of 37 1 GENERAL INFORMATION 1.1. Administrative data of the test facility 1.1.1 Identification of the testing laboratory Company name: Cetecom ICT Services GmbH Address: Untertürkheimerstr. 6-10 D-66117 Saarbruecken Germany Laboratory accreditation: DAR-Registration No. DAT-P-176/94-D1 Bluetooth Qualification Test Facility (BQTF) Federal Communications Commission (FCC) Identification/Registration No : 90462 Responsible for testing laboratory: Dirk Hausknecht Phone: +49 681 598 0 Fax: +49 681 598 9075 email: [email protected] 1.2. Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. .......................................... Responsible for testing laboratory (Gillmann D.) ..................................................................................... Responsible for testing laboratory (Dirk Hausknecht) CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4071-01-02/05 Date: 2005-08-19 Page 4 of 37 1.3 Details of Applicant Name : Sony Ericsson Mobile Communications AB Address : Torshamnsgatan 27 City : S-164 94 Kista Country : Sweden Phone : +46 8 508 77 056 Fax : +46 8 404 3430 Contact : Mr. Kenth Skoglund Phone : +46 8 508 77 056 Fax : +46 8 404 3430 e-mail : [email protected] 1.4 Application Details Date of receipt of application : 2005-08-17 Date of receipt of test item : 2005-08-17 Date(s) of test : 2005-08-18 to 2005-08-19 Date of report : 2005-08-19 CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4071-01-02/05 Date: 2005-08-19 Page 5 of 37 1.5 T…

Text truncated - open the document above for the full version.

APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7AC052011 REPORT 2(74) Prepared (also subject responsible if other) No. SEM/CV/PF/P Gerard Hayes and Rodney Dixon REP 2005 006 Z520i 02 Approved Checked SEM/CV/PF/P Gerard Hayes A X:\SAR Chamber\FCC reports\Z520I\Final Reports\FCCZ520I.doc E E E x x h h i i b b i i t t 1 1 1 1 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 3 2.1 Antenna description 3 2.2 Device description 3 3. Test Equipment Used 4 3.1 Dosimetric System 4 3.2 Additional Equipment 4 4. Electrical parameters of the tissue simulating liquid 5 5. System Accuracy Verification 6 6. Test Results 7 6.1 Head Adjacent Test Results 7 6.2 Body-Worn Test Results 10 References 12 Appendix 1: SAR distribution comparison for system accuracy verification 13 Appendix 2: SAR distribution plots for Phantom Head Adjacent Use 18 Appendix 3: SAR distribution plots for Body Worn Configuration 39 Appendix 4: Probe Calibration Certificate 52 Appendix 5: Measurement Uncertainty Budget 57 Appendix 6: Photographs of the device under test 67 APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7AC052011 REPORT 3(74) Prepared (also subject responsible if other) No. SEM/CV/PF/P Gerard Hayes and Rodney Dixon REP 2005 006 Z520i 02 Approved Checked SEM/CV/PF/P Gerard Hayes A X:\SAR Chamber\FCC reports\Z520I\Final Reports\FCCZ520I.doc E E E x x h h i i b b i i t t 1 1 1 1 1. Introduction The Sony Ericsson SAR Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone FCC ID PY7AC052011 model Z520i. The Specific Absorption Rate (SAR) of this product was measured. The applicable RF safety guidelines and the SAR measurement specifications used for the test are described in [1]. 2. Description of the Device Under Test 2.1 Antenna description Type PIFA- Type Antenna Location External plastic loop, near the hinge Width 40 mm Length 30 mm Dimensions Height 8mm 2.2 Device description FCC ID Number / Device Model PY7AC052011 / Z520i Serial number BD3022UQJL BD3022SBPV Mode(s) of Operation GSM 800 GSM 1900 Modulation Mode(s) TDMA TDMA f low 32.2 dBm +0.4/-1.2 dB f low 30.0 dBm +0.5/-1.5 dB f mid 31.7 dBm +0.4/-0.7 dB f mid 30.0 dBm +0.5/-1.5 dB Target Value and Factory Tolerance Window for Maximum Output Power Setting GSM Mode: 1/8 Duty Cycle f high 31.7 dBm +0.3/-0.7 dB f high 30.0 dBm +0.5/-1.5 dB f low 32.2 dBm max. f low Same as GSM 1:8 f mid 31.6 dBm max. f mid Same as GSM 1:8 GPRS Mode: 2/8 Duty Cycle Target Maximum Output Power Setting (adjusted from GSM mode) f high 31.2 dBm ± 0.3 dB f high Same as GSM 1:8 Calibration Frequency (f low , f mid , f high ) f high f mid Transmitting Frequency Rang(s) 824-849 MHz 1850-1910 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7AC052011 REPORT 4(74) Prepared (also subject responsible if other) No. SEM/CV/PF/P Gerard Hayes and Rodney Dixon REP 2005 006 Z520i 02 Approved Checked SEM/CV/PF/P Gerard Hayes A X:\SAR Chamber\FCC reports\Z520I\Final Reports\FCCZ520I.doc E E E x x h h i i b b i i t t 1 1 1 1 3. Test Equipment Used 3.1 Dosimetric System The Sony Ericsson SAR Laboratory utilizes Dosimetric Assessment Systems (Dasy3™ v3.1d for body-worn measurements and Dasy4™ for adjacent to head measurements) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerland. The overall RSS uncertainty of the measurement system is ±10.77% (K=1) with an expanded uncertainty of ±21.55% (K=2) for Dasy3™ v3.1d and ±9.49% (K=1) with an expanded uncertainty of ±18.74% (K=2) for Dasy4™. The measurement uncertainty budget is given in Appendix 5 for both systems. The list of calibrated equipment used for the measurements is shown in the following table. Description Serial Number Cal Due Date DASY3 DAE V1 345 12-Nov-2005 DASY3 DAE V1 417 11-Nov-2005 E-Field Probe ETDV6 1586 26-May-2006 E-Field Probe ETDV6 1587 26-May-2006 Dipole Validation Kit, DV835V2 438 24-May-2006 Dipole Validation Kit, DV900V2 035 24-May-2006 Dipole Validation Kit, DV1800V2 238 11-May-2006 Dipole Validation Kit, DV1900V2 536 19-May-2006 S.A.M. Phantom used for 835MHz (Head) 1251 S.A.M. Phantom used for 835MHz (Body) 1031 S.A.M. Phantom used for 900MHz (Head and Body) 1251 S.A.M. Phantom used for 1800MHz (Head and Body) 1335 S.A.M. Phantom used for 1900MHz (Head) 1335 S.A.M. Phantom used for 1900MHz (Body) 1020 3.2 Additional Equipment Description Serial Number Cal Due Date Signal Generator HP8648C 3537A01598 August 30, 2006 Power Meter 437B 3125U16382 December 8, 2005 Power Meter 437B 3125U13729 January 6, 2006 Power Sensor - 8482H MY41090240 April 29, 2006 Power Sensor - 8482H MY41090239 April 29, 2006 Dielectric Probe Kit HP85070B US33020390 July 4, 2006 Digital Thermometer 61220-601 And Probe (61220-604) 350078 November 5, 2005 Digital Hygrometer/ Thermometer 21242911 November 3, 2005 HP RF Amplifier 8347A 3307A1069 May 4, 2006 APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7AC052011 REPORT 5(74) Prepared (also subject responsible if other) No. SEM/CV/PF/P Gerard Hayes and Rodney Dixon REP 2005 006 Z520i 02 Approved Checked SEM/CV/PF/P Gerard Hayes A X:\SAR Chamber\FCC reports\Z520I\Final Reports\FCCZ520I.doc E E E x x h h i i b b i i t t 1 1 1 1 4. Electrical parameters of the tissue simulating liquid Prior to conducting SAR measurements, the relative permittivity, ε r , and the conductivity, σ, of the tissue simulating liquids were measured with the dielectric probe kit. These values, along with the temperature of the simulated tissue are shown in the table below. A mass density of ρ=1g/cm3 was entered into the system in all the cases. It can be seen that the measured parameters are within tolerance of the recommended limits [1]. During the tests, the ambient temperature of the laboratory was in the range 22.2-24.1°…

Text truncated - open the document above for the full version.

APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7AC052011 REPORT 18(74) Prepared (also subject responsible if other) No. SEM/CV/PF/P Gerard Hayes and Rodney Dixon REP 2005 006 Z520i 02 Approved Checked SEM/CV/PF/P Gerard Hayes A X:\SAR Chamber\FCC reports\Z520I\Final Reports\FCCZ520I.doc E E E x x h h i i b b i i t t 1 1 1 1 Appendix 2 SAR distribution plots for Phantom Head Adjacent Use APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7AC052011 REPORT 19(74) Prepared (also subject responsible if other) No. SEM/CV/PF/P Gerard Hayes and Rodney Dixon REP 2005 006 Z520i 02 Approved Checked SEM/CV/PF/P Gerard Hayes A X:\SAR Chamber\FCC reports\Z520I\Final Reports\FCCZ520I.doc E E E x x h h i i b b i i t t 1 1 1 1 800 GSM Band: SAR Distribution and Extrapolation of Maximum SAR Model: Z520i SN: BD3022UQJL with Standard Battery: BST-37 Right Side, Cheek/Touch Position. Date/Time: 8/13/2005 4:22:12 PMDate/Time: 8/13/2005 4:27:45 PM File Name: 13Aug05_Z520i_GSM850_UQJL_RC01.da4 DUT: Model: Z520i Program Notes: Battery BST-37 Humidity: 49.7% Ambient Temp: 23 Simulant Temp: 23.9 Communication System: GSM 850; Frequency: 849 MHz; Duty Cycle: 1:8.3 Medium: Head 835/900 MHz Medium parameters used (interpolated): f = 849 MHz; s = 0.901 mho/m; e r = 40.7; ? = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ET3DV6 - SN1586; ConvF(6.58, 6.58, 6.58); Calibrated: 5/26/2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn417; Calibrated: 11/11/2004 - Phantom: SAM with CRP (Low Band Head); Type: SAM; Serial: 1251 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing …
