PY7AF031021Licensed Transmitter

Sony Corporation

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Dec 12, 2004
Application Purpose: Original Equipment
Date of Application: Dec 12, 2004
Equipment Note: Licensed Transmitter
Frequency Range: 824.20000000 - 848.80000000
Company: Sony Corporation
Country: Japan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 Contents ContentsGetting started . . . . . . . . . . . . . . . . . . 4Assemble the phone, SIM card, battery, make a call.Getting to know your phone . . . . . . . . 8Phone overview, use the menus, enter letters, quick keys, Memory Stick Duo™, file manager.Calling . . . . . . . . . . . . . . . . . . . . . . . . 18Calls, phonebook, voice control, call options.Messaging . . . . . . . . . . . . . . . . . . . . . 35Text messaging, picture messaging, email, My Friends, messaging glossary.Imaging . . . . . . . . . . . . . . . . . . . . . . . 49Camera, video recorder, pictures, screen saver.Entertainment . . . . . . . . . . . . . . . . . . 56Media player, sounds, themes, games. Connectivity . . . . . . . . . . . . . . . . . . . . 60Internet and email settings, synchronizing, Bluetooth™ wireless technology, infrared.More features . . . . . . . . . . . . . . . . . . . 69Time and date, alarm clock, calendar, tasks, SIM card lock, etc.Troubleshooting . . . . . . . . . . . . . . . . . 77Why doesn’t the phone work the way I want?Additional information . . . . . . . . . . . . 80Sony Ericsson web site, technical assistance, safe and efficient use, warranty, declaration of conformity.Icons . . . . . . . . . . . . . . . . . . . . . . . . . . 88Icon descriptionsIndex . . . . . . . . . . . . . . . . . . . . . . . . . 91 S710a_UG_R1A.book Page 1 Thursday, September 30, 2004 10:24 AM 2 Sony EricssonGSM 850/1800/1900First edition (November 2004)This manual is published by Sony Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this manual.All rights reserved.© Sony Ericsson Mobile Communications AB, 2004 Publication number: AE/LZT 123 7896 R1APlease note: Some of the services in this manual are not supported by all networks. This also applies to the GSM International Emergency Number 112, 911, 060 . Please contact your service provider if you are in doubt whether you can use a particular service or not.Please read the Guidelines for safe and efficient use and the Limited warranty chapters before you use your mobile phone.Your mobile phone has the capab ility to download, store and forward additional content, e.g. ringtones. The use of such content may be restricted or prohibited by rights of third parties, including but not limited to restriction under applicable copyright laws. You, and not Sony Ericsson, are entirely responsible for additional content that you download to or forward from your mobile phone. Prior to your use of any additional content, please verify that your intended use is properly licensed or is otherwise authorized. Sony Ericsson does not guarantee the accuracy, integrity or quality of any additional content or any other third party content. Under no circumstances will Sony Ericsson be liable in any way for your improper use of additional content or other third party content. PlayNow™ is a trademark or a registered trademark of Sony Ericsson Mobile Communications AB.MusicDJ™ is a trademark or a registered trademark of Sony Ericsson Mobile Communications AB.MagicGate™, Memory Stick™, Memory Stick Duo™ and Memory Stick PRO Duo™ are trademarks or registered trademarks of Sony Corporation.The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Ericsson is under license.Microsoft and PowerPoint are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. S710a_UG_R1A.book Page 2 Thursday, September 30, 2004 10:24 AM 3 T9™ Text Input is a trademark or a registered trademark of Tegic Communications.T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057, United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide.Java and all Java based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.End-user license agreement for Sun™ Java™ J2ME™.1 Restrictions: Software is confidential copyrighted information of Sun and title to all copies is retained by Sun and/or its licensors. Customer shall not modify, decompile, disassemble, decrypt, extract, or otherwise reverse engineer Software. Software may not be leased, assigned, or sublicensed, in whole or in part. 2 Export Regulations: Software, including technical data, is subject to U.S. export control laws, including the U.S. Export Administration Act and its associated regulations, and may be subject to export or import regulations in other countries. Customer agrees to comply strictly with all such regulations and acknowledges that it has the responsibility to obtain licenses to export, re-export, or import Software. Software may not be downloaded, or otherwise exported or re-exported (i) into, or to a national or resident of, Cuba, Iraq, Iran, North Korea, Libya, Sudan, Syria (as such listing may be revised from time to time) or any country/region to which the U.S. has embargoed goods; or (ii) to anyone on the U.S. Treasury Department's list of Specially Designated Nations or the U.S. Commerce Department's Table of Denial Orders. 3 Restricted Rights: Use, duplication or disclosure by the United States government is subject to the restrictions as set forth in the Rights in Technical Data and Computer Software Clauses in DFARS 252.227-7013(c) (1) (ii) and FAR 52.227-19(c) (2) as applicable. Part of the software in this product is copyright © SyncML initiative Ltd. (1999-2002). All rights reserved.Othe…

Text truncated - open the document above for the full version.

Attestation Statements

Confidentiality Request Datum' Date 2004-11-09 Beteckning' Reference GUG/NO4:253 Vår handläggare, namn, tfn .Attending to this matter; name, te/ephone SEM/BGGINB Håkan Sjöberg +4646193559 Ert datum. Your date Er beteckning. Your reference Receiver Federal Communications Commission Subject: Request for Confidentiality FCC ID: PY7AFO31021 To Whom It May Cancern: In accordance with §O.459 of CFR 47, Sony Ericsson Mobile Communications AB requests confidentiality for the below Iisted items for our mobile phone type AAF- 1031021-BV, FCC ID: PY7AFO31021: 1.2. 3. 4. 5. Block Diagram Schematic Diagram Part List Operational Descriptions Mounting Drawing These items contain detailed system and equipment description and related information about the product which Sony Ericsson Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Ericsson Mobile Communications AB also feels thai this information would be of benefit to ils competitors, and thai the disclosure of the information in these exhibits would give Dur competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Type Approval Manager Sony Ericsson Mobile Communications AB Sony Ericsson Mobile Communications AB Styrelsens säte: Lund Registered office: Lund Telefon. Te/ephone Nat 046-194000 Int +4646194000 Momsnr. \'(A. 7:No: SE556615665801 Organisationsnr. Reg No: 556615-6658 Telefax. Telefax Nat 046-1941 00 Ini +4646194100 Postadress. Mail SE-221 88 Lund Sweden Besöksadress. Office address Nya Vattentornet Lund

External Photos

CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 Saarbrücken Telefon: +49 (0)681 598-0 Telefax: - 9075 Annex to test report No.: 2-3767-01-02/04 This test report consists of 20 pages Page 1 (20) Recognized by the Federal Communications Commission Anechoic Chamber Registration No.: 90462 (FCC) Anechoic Chamber Registration No.: 3463 (IC) TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 081/94-D0 Independent ETSI compliance test house ETSI Annex to Test Report No.: 2-3767-01-02/04 Applicant: Sony Ericsson Mobile Com. AB Type: AAF-1031021-BV Test Standards: FCC Part 22, 24 RSS132, 133 FCC ID: PY7AF031021 IC: 4170B-AF031021 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 2 (20) ANNEX A: TEST SETUP PHOTOS ANNEX B: EXTERNAL PHOTOS ANNEX C: INTERNAL PHOTOS CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 3 (20) Annex A: Test Setup Photos Test site CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 4 (20) Test site CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 5 (20) Test site CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 6 (20) ANNEX B: EXTERNAL PHOTOS Photograph No.: 1 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 7 (20) Photograph No.: 2 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 8 (20) Photograph No.: 3 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 9 (20) Photograph No.: 4 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 10 (20) Photograph No.: 5 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 11 (20) ANNEX B: INTERNAL PHOTOS Photograph No.: 6 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 12 (20) Photograph No.: 7 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 13 (20) Photograph No.: 8 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 14 (20) Photograph No.: 9 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 15 (20) Photograph No.: 10 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 16 (20) Photograph No.: 11 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 17 (20) Photograph No.: 12 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 18 (20) Photograph No.: 13 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 19 (20) Photograph No.: 14 CETECOM ICT Services GmbH Annex to test report No.: 2-3767-01-02/04 Page 20 (20) Photograph No.: 15

ID Label/Location Info

Confidential KRH MARKING DRAWING S710a 1(3) Prepared Date Rev Doc no. RT/SEM/CA/KA Christer Andersson 2004-11-03 E 151 86-KRH 101 219 Uen Approved Checked File CA/KA C. Andersson 919-472-7351 Type AAF-1031021-BV (S710a). Print layout for KRH label (SVF 930 863). Printing area 31.6 x 18.5 mm. Line no. 1. YYYY/ZZ RXX Rywwxx Model: S710a 2. Type number: AAF-1031021-BV G H Y 3. 4. XXXXXXXX-YYYYYY-Z 5. 6. XXXXXXXXXX yyWww 7. CAN: 4170B-AF031021 8. FCC ID: PY7AF031021 9. 10. 11. 12. Line Text Text height 1. DPY-number, R-state, Repair code, Model name min 1.2 mm 2. “NOT TYPE APPROVED” min 1.2 mm 3. IMEI number as bar code. See line 4. min 2.5 mm 4. IMEI number as characters. Must consist of TAC-SNR-CD. See doc. 1/151 86-KRH 101 219 Uen for actual TAC and SNR to be used. min 1.2 mm 5. Serial number as bar code min 2.5 mm 6. Serial number as characters, production week min 1.2 mm 7. Consists of text: ”CAN: 4170B-AF031021” min 1.2 mm 8. Consists of text: ”FCC ID: PYAF031021” within a frame with height >1.5 mm. min 1.5 mm 9. UPC code Scaled to fit 10. “CE 0682” Approval Mark, angled 90° clockwise min 5.0 mm 11. Sony Ericsson trademark, angled 90° clockwise min 1.4 mm 12. Marking of origin, angled 90° clockwise min 1.2 mm Confidential KRH MARKING DRAWING S710a 2(3) Prepared Date Rev Doc no. RT/SEM/CA/KA Christer Andersson 2004-11-03 E 151 86-KRH 101 219 Uen Approved Checked File CA/KA C. Andersson 919-472-7351 Definitions: 1. Reduced DPY-number The DPY number, according to 1095- for the produced product, without “DPY 101” e.g. if DPY 101 1448/12 is produced the printing should be “1448/12”. (7pos) R-state The R-state for the DPY according to the actual 1095- for the DPY. (3 pos) Repair code Six character code to identify repair data, this code will not be used by the manufacturing unit. This code is only used after completed repair and re-labeling. (6 pos) Model name Print: “Model: S710a” 2. Sony Ericsson Type number Print: “Type number: AAF-1031021-BV” G H Y fields R-state identification of the CXC module, the KRH and the ROA. Refer to 1/15186-KRH 101 219 for actual letter to be printed. (5 pos) 3. IMEI number as bar code See below for definition of IMEI-number. The bar code shall only contain the digits of the IMEI number (no dash). According to Ericsson corporate standard 102 01-109. Code 128. Refer to 1/151 86-KRH 101 219 for TAC and SNR. 4. IMEI number as characters The IMEI number has format: TAC-SNR-CD (17 pos) TAC = Type approval code (8 pos) SNR = Serial number from 000 000 to 999 999 (6 pos) CD = A check digit, from 0-9, calculated (1 pos) according to the Luhn formula (ISO/IEC 7812), GSM 02.16. 5. Serial number as bar code According to Ericsson corporate standard 102 01 - 109. Code 128 Confidential KRH MARKING DRAWING S710a 3(3) Prepared Date Rev Doc no. RT/SEM/CA/KA Christer Andersson 2004-11-03 E 151 86-KRH 101 219 Uen Approved Checked File CA/KA C. Andersson 919-472-7351 6. Serial number as characters According to Ericsson group standard 0012-101. Ericsson group factory number system according the Ericsson corporate standard 1120-101. Factory codes: Sony Alsace AL (10 pos) Production week The production week shall be given as yyWww (yy = year, ww = week) according to the ISO 8601 standard. (5 pos) 7. Country Approval 1 Print: CAN: 4170B-AF031021 8. Country Approval 2 Print: FCC ID: PYAF031021 9. UPC code UPC barcode, only for the DPY kits that are listed in Table 1 below; Table 1 Customer DPY number UPC code Cingular DPY 101 1448/12 00 095673 02334 Printed in standard UPC-A format, scaled to fit the label. 10. Approval Mark (CE marking) According to 1424-SVF 930 52 11. Sony Ericsson Trademark According to corporate standard 190 89-EN/LZT 108 5347. 12. Marking of Origin Print: Made in Japan

Internal Photos

RF Exposure Info

APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7AF031021 REPORT 1(104) Prepared (also subject responsible if other) No. SEM/CV/PF/P Gerard Hayes REP 2004 004 S710A 01 Approved Checked SEM/CV/PF/P Gerard Hayes B X:\SAR Chamber\FCC reports\S710A\Final Reports\FCCS710A.doc E E E x x h h i i b b i i t t 1 1 1 1 Exhibit 11: SAR Test Report of Portable Cellular Phone FCC ID: PY7AF031021 Model : S710a Date of test: Date of Report: August 15- August 27, 2004 and December 2-3, 2004 December 6, 2004 Laboratory: SAR Testing Laboratory Sony Ericsson Mobile Communications, Inc. 7001 Development Drive, P.O. Box 13969, Research Triangle Park, NC, 27709, USA Tested by: Rodney Dixon Technician III, Product Verification Group Test Responsible: Gerard Hayes Consulting Engineer, Antenna/RF Development Group Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following electromagnetic exposure tests: Specific Absorption Rate (SAR) Dielectric parameters RF power measurement On the following types of products: Wireless communications devices. A2LA certificate #1650-01 Statement of Compliance: Sony Ericsson Mobile Communications, Inc declares under its sole responsibility that portable cellular telephone FCC ID PY7AF031021 model S710A to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) © Sony Ericsson Mobile Communications, Inc. 2004 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Sony Ericsson Mobile Communications encourages all feedback, both positive and negative, on this test report. APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7AF031021 REPORT 2(104) Prepared (also subject responsible if other) No. SEM/CV/PF/P Gerard Hayes REP 2004 004 S710A 01 Approved Checked SEM/CV/PF/P Gerard Hayes B X:\SAR Chamber\FCC reports\S710A\Final Reports\FCCS710A.doc E E E x x h h i i b b i i t t 1 1 1 1 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 3 2.1 Antenna description 3 2.2 Device description 3 3. Test Equipment Used 4 3.1 Dosimetric System 4 3.2 Additional Equipment 4 4. Electrical parameters of the tissue simulating liquid 5 5. System Accuracy Verification 6 6. Test Results 7 6.1 Head Adjacent Test Results 7 6.2 Body-Worn Test Results 12 References 14 Appendix 1: SAR distribution comparison for system accuracy verification 16 Appendix 2: SAR distribution plots for Phantom Head Adjacent Use 28 Appendix 3: SAR distribution plots for Body Worn Configuration 61 Appendix 4: Probe Calibration Certificate 78 Appendix 5: Measurement Uncertainty Budget 86 Appendix 6: Photographs of the device under test 96 APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7AF031021 REPORT 3(104) Prepared (also subject responsible if other) No. SEM/CV/PF/P Gerard Hayes REP 2004 004 S710A 01 Approved Checked SEM/CV/PF/P Gerard Hayes B X:\SAR Chamber\FCC reports\S710A\Final Reports\FCCS710A.doc E E E x x h h i i b b i i t t 1 1 1 1 1. Introduction The Sony Ericsson SAR Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone FCC ID PY7AF031021 model S710A. The Specific Absorption Rate (SAR) of this product was measured. The applicable RF safety guidelines and the SAR measurement specifications used for the test are described in [1]. 2. Description of the Device Under Test 2.1 Antenna description Type Internal antenna Location Inside back cover, above the camera Width 34mm Length 16mm Dimensions Height 6mm Configuration Bent Monopole – Type Antenna 2.2 Device description FCC ID Number / Device Model PY7AF031021 / S710A Serial number BF7EP20328 BF7EP20308 BF7EP20308 Mode(s) of Operation GSM 800 GSM 1900 Modulation Mode(s) TDMA TDMA f low 32.0 ± 0.8dBm f low 30.2 ± 0.8dBm f mid 32.0 ± 0.5dBm f mid 30.0 ± 0.5dBm Target Value and Factory Tolerance Window for Maximum Output Power Setting f high 32.0 ± 0.8dBm f high 30.0 ± 0.8dBm Calibration Frequency (f low , f mid , f high ) f mid f mid Duty Cycle 1/8 GSM 2/8 EGPRS (Data) 1/8 GSM 2/8 EGPRS (Data) Transmitting Frequency Rang(s) 824-849 MHz 1850-1910 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PY7AF031021 REPORT 4(104) Prepared (also subject responsible if other) No. SEM/CV/PF/P Gerard Hayes REP 2004 004 S710A 01 Approved Checked SEM/CV/PF/P Gerard Hayes B X:\SAR Chamber\FCC reports\S710A\Final Reports\FCCS710A.doc E E E x x h h i i b b i i t t 1 1 1 1 3. Test Equipment Used 3.1 Dosimetric System The Sony Ericsson SAR Laboratory utilizes Dosimetric Assessment Systems (Dasy3™ v3.1d for body-worn measurements and Dasy4™ for adjacent to head measurements) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerland. The overall RSS uncertainty of the measurement system is ±11.33% (K=1) with an expanded uncertainty of ±22.67% (K=2) for Dasy3™ v3.1d and ±10.14% (K=1) with an expanded uncertainty of ±20.27% (K=2) for Dasy4™. The measurement uncertainty budget is given in Appendix 5 for both systems. The list of calibrated equipment used for the measurements is shown in the following table. Description Serial Number Cal Due Date DASY3 DAE V1 345 25-Nov-2004 DASY3 DAE V1 392 24-Nov-2005 DASY3 DAE V1 417 10-Dec-2004 DASY3 DAE V1 431 26-Nov-2004 E-Field Probe ETD…

Text truncated - open the document above for the full version.

Test Report

CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 Saarbrücken Telefon: +49 (0)681 598-0 Telefax: - 9075 Test report No.: 2-3767-01-02/04 This test report consists of 91 pages Page 1 (91) Recognized by the Federal Communications Commission Anechoic Chamber Registration No.: 90462 (FCC) Anechoic Chamber Registration No.: 3463 (IC) TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 081/94-D0 Independent ETSI compliance test house ETSI Test Report No.: 2-3767-01-02/04 Applicant: Sony Ericsson Mobile Com. AB Type: AAF-1031021-BV Test Standards: FCC Part 22, 24 RSS132, 133 FCC ID: PY7AF031021 IC: 4170B-AF031021 CETECOM ICT Services GmbH Test report No.: 2-3767-01-02/04 Date: 2004-10-19 Page 2 (91) Table of Contents 1 GENERAL INFORMATION.................................................................................................................3 1.1 N OTES.................................................................................................................................................... 3 1.2 T ESTING LABORATORY......................................................................................................................... 3 1.3 D ETAILS OF APPLICANT......................................................................................................................... 4 1.4 A PPLICATION DETAILS.......................................................................................................................... 4 1.5 T EST ITEM.............................................................................................................................................. 5 1.6 T EST STANDARDS.................................................................................................................................. 6 2 STATEMENT OF COMPLIANCE .......................................................................................................7 2.1 S UMMARY OF MEASUREMENT RESULTS............................................................................................... 7 2.1.1 PCS1900 .......................................................................................................................................7 2.1.2 GSM 850 .......................................................................................................................................7 3 MEASUREMENTS AND RESULTS ....................................................................................................8 3.1 PART PCS 1900.................................................................................................................................... 8 3.1.1 RF Power Output ..........................................................................................................................8 3.1.2 Frequency Stability .....................................................................................................................12 3.1.3 Radiated Emissions.....................................................................................................................15 3.1.4 Receiver Radiated Emissions......................................................................................................24 3.1.5 Conducted Spurious Emissions...................................................................................................28 3.1.6 Block Edge Compliance..............................................................................................................32 3.1.7 Occupied Bandwidth...................................................................................................................37 3.2 PART GSM 850 .................................................................................................................................. 50 3.2.1 RF Power Output ........................................................................................................................50 3.2.2 Frequency Stability .....................................................................................................................53 3.2.3 Radiated Emissions.....................................................................................................................56 3.2.4 Receiver Radiated Emissions......................................................................................................64 3.2.5 Conducted Spurious Emissions...................................................................................................68 3.2.6 Block Edge Compliance..............................................................................................................72 3.2.7 Occupied Bandwidth...................................................................................................................77 4 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS .....................................................90 ANNEX A: TEST SETUP PHOTOS ANNEX B: EXTERNAL PHOTOS ANNEX C: INTERNAL PHOTOS CETECOM ICT Services GmbH Test report No.: 2-3767-01-02/04 Date: 2004-10-19 Page 3 (91) 1 GENERAL INFORMATION 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. 1.2 Testing Laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telephone: + 49 681 598 - 9100 Telefax: + 49 681 598 - 9075 E-mail: [email protected] Internet: www.cetecom-ict.de Accredited testing laboratory The test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025. DAR registr…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Kazuyuki Hori(Senior EMC/RF Compliance Manager)

[email protected]+815031416220Fax: +815037506540

Test Firm

Cetecom ICT Services GmbHRalf Hoehn

[email protected]49-681-598-8455Fax: 49-681-598-8475

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	22H	824.2 MHz - 848.8 MHz	1.096 W	300KGXW	0.06 ppm

Confidentiality

Long Term

Grant Notes

Output power is ERP for Part 22 and EIRP for Part 24. This device contains 1800 MHz GSM functions that are not operational in U.S.Territories. This filing is only applicable for 850 MHz and 1900 MHz PCS operations. SAR compliance for body-worn operating configurations is limited to the specific configuration tested for this filing. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5 cm separation between the device, including its antenna whether extended or retracted, and the users body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values with GSM and Bluetooth activated simultaneously are: GSM 1900:Head: 0.757W/kg; Body-worn: 0.53W/kg GSM 850: Head: 0.877W/kg; Body-worn: 0.578W/kg
