www.SonyEricsson.com Sony Ericsson Mobile Communications AB SE-221 88 Lund, Sweden B - Adding the headset again or to another phone B - Añadir el auricular de nuevo o añadirlo a otro teléfono B - 重新添加耳机，或将耳机添加到另一手机 B - 耳機再次加入或加入另一台手機 Make sure the headset is turned on. (See p. 16.) Asegúrese de que el auricular está encendido. (Consulte la página 16.) 确保耳机已开启。（请参见第 16 页） 務請先將耳機開機。請參考第 16 頁。 )s 5 ( Front Parte delantera 正面 正面 Call handling button Botón de gestión de llamadas 呼叫操作按钮 通話處理鈕 Decorative panel Panel decorativo 装饰面板 裝飾面板 Indicator light Indicador luminoso 指示灯 顯示燈號 Microphone Micrófono 话筒 麥克風 Microphone Micrófono 话筒 麥克風 Getting started Introducción 入门 準備開始 Chargers Cargadores 充电器 充電器 First time use: Charge approximately 8 hours before using the headset. (For battery capacity see p. 31.) Utilización por primera vez: Cárguelo aproximadamente durante 8 horas antes de utilizar el auricular. (Consulte en la p. 31 la capacidad de la batería.) 首次使用：首次使用手机前，请将电池充电约 8 小 时。（有关电池容量的信息，请参见第 31 页。） 首次使用時：使用耳機前，請先充電 8 小時左右。 （電池容量的說明，見第 31 頁。） CST-13CLA-11 Introduction Introducción 简介 簡介 Bluetooth™ Headset HBH-610 The Bluetooth™ Headset HBH-610 can be connected to any device with Bluetooth wireless technology that supports the handsfree or headset profile. This user guide focuses on usage with a Sony Ericsson mobile phone. Bluetooth™ Headset HBH-610 El auricular Bluetooth™ Headset HBH-610 puede conectarse a cualquier dispositivo que disponga de tecnología inalámbrica Bluetooth y que admita perfiles de manos libres o de auricular. Esta guía del usuario se centra en la utilización del dispositivo con un teléfono móvil de Sony Ericsson. Bluetooth™ 蓝牙耳机 HBH-610 利用蓝牙无线技术，Bluetooth™ 蓝牙耳机 HBH-610 可以与支持免提或耳机模式的任何设备连接。本用户 指南着重介绍在索尼爱立信手机上的使用方法。 Bluetooth™ 耳機 HBH-610 Bluetooth™ 耳機 HBH-610 可經 Bluetooth 藍芽無線技 術，連上任何支援免持及耳機模式的裝置。本使用手 冊特別說明如何在 Sony Ericsson 手機上使用本耳機。 Range Alcance 范围 範圍 Optimal performance Rendimiento óptimo 性能最佳 最佳的作業範圍 Limited performance Rendimiento limitado 性能受限制 可接受的作業範圍 Charging Carga 充电 充電 Battery needs charging Debe cargar la batería 电池需要充电 電池需要充電 Fully charged Completamente cargado 已充满 電已充足 Charging Carga 充电中 充電中 Para poder utilizar el auricular Bluetooth con el teléfono, debe añadirlo al teléfono: 1.Prepare el auricular según A o B (consulte la p. 12). 2.Siga las instrucciones de la guía de usuario del teléfono sobre la forma de encender y posteriormente añadir un dispositivo Bluetooth a su teléfono. La clave maestra del auricular es 0000. Después de añadir el auricular a la lista de dispositivos Bluetooth del teléfono, se conectará automáticamente al teléfono tan pronto como se encienda y dentro del alcance. 在将蓝牙耳机用于手机之前，必须将它添加到手机 上一次： 1.依照 A 或 B（参见第 12 页）将耳机准备好。 2. 按照手机用户指南中的说明，正确开启蓝牙设备， 然后将它添加到手机上。耳机的识别码是 0000。 将耳机添加到手机的蓝牙设备列表中后，耳机将在手 机开启并处于服务区后自动连接手机。 Bluetooth™ Headset HBH-610 User Guide Guía del usuario 用户指南 使用手冊 FCC statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Sony Ericsson HBH-610 First edition (May 2005) This manual is published by Sony Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this manual. All rights reserved. ©Sony Ericsson Mobile Communications AB, 2005 Publication number: LZT 108 7761/1 R1A Some of the services in this manual are not supported by all networks. This also applies to the GSM International Emergency Number 112. Contact your network operator or service provider if you are in doubt whether you can use a particular service or not. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Ericsson is under license. Back Parte posterior 背面 背面 Decrease volume Bajar volumen 降低音量 降低音量 Increase volume Subir volumen 增加音量 放大音量 Speaker Altavoz 扬声器 擴音器 Charging connector Conector de carga 充电连接器 充電接口 Ear hook Enganche para la oreja 耳挂 配戴耳鉤 User Guide symbols Símbolos de la guía del usuario 《用户指南》符号 使用手冊符號 Press and release Pulsar y soltar 按下后松开 壓放 Indicator light Indicador luminoso 指示灯 顯示燈號 Press and hold Mantener pulsado 按下并保持 按住 Steady red light Luz roja fija 持续红灯亮 持續的紅燈 Press simultaneously Pulsar simultáneamente 同时按住 同時按 Steady green light Luz verde fija 持续绿灯亮 持續的綠燈 User Guide symbols (continued) Símbolos de la guía del usuario (continuación) 《用户指南》符号（续） 使用手冊符號（續前） Green flash Flash verde 绿灯闪烁 閃綠燈 Ring signal Señal de timbre 响铃信号 鈴聲 Red flash Flash rojo 红灯闪烁 閃紅燈 Beep tone Tono de pitido 蜂鸣声 嗶聲 Adding the headset to the phone Añadir el auricular al teléfono 将耳机添加到手机上 將耳機連上手機 Before you can use your Bluetooth headset with your phone it has to be added once to the phone: 1.Prepare your headset according to A or B (see p. 12). 2.Follow the instructions from the phone user guide on how to turn on and then add a Bluetooth device to your phone. The passkey of the headset is 0000. After you have added the headset to the list of Bluetooth devices in the phone, it will automatically connect to the phone as soon as it is turned on and within range. Bluetooth（藍芽）耳機可用於手機前，需先加入手 機一次，方法如下： 1.按第 12 頁 A 或 B 步驟，將耳機準備好。(see p. 12). 2.按手機使用手冊的指令，將 Bluetooth（藍芽）裝 置開啟並加入手機。 耳機的識別碼為 0000。 將耳機加入手機的 Bluetooth（藍芽）裝置清單後， 只要耳機開機且在有效範圍內，就會自動連上手機。 The headset beeps and flashes green when successfully added El auricular emite un pitido y parpadea en color verde cuando se añade correctamente 成功连接后，耳机会发出蜂鸣声，同时绿灯闪烁 耳機加入後會發出嗶聲並閃綠燈 A - Adding the headset for the first time or after a reset A - Añadir el auricular por primera vez o después de reiniciar A - 首次添加耳机，或在重新设定后添加耳机 A - 首次或重設後加入耳機 ) s 5 ( Pu…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4012-01-02/05 Date: 2005-06-30 Page 41 of 46 4 Photographs Conducted sample: CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4012-01-02/05 Date: 2005-06-30 Page 42 of 46 radiated sample: CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4012-01-02/05 Date: 2005-06-30 Page 43 of 46 EUT is test chamber CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4012-01-02/05 Date: 2005-06-30 Page 44 of 46 EUT opened CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4012-01-02/05 Date: 2005-06-30 Page 45 of 46 CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4012-01-02/05 Date: 2005-06-30 Page 46 of 46

Company Internal MARKING DRAWING 1 (1) Prepared (also subject responsible if other) No. SEM/BNDM Bennie Rolink 151 86 - KRY 901 087 Uen Approved Checked Date Rev Reference SEM/BNDM (Christian den Herder) 2005-04-05 C BLUETOOTH HEADSET HBH-610 The marking is by means of laser writing. Change: Textfield and fontsizes are made smaller Content: Line A0: a; Styled name; ‘Sony Ericsson’ b; Commercial product ID; ‘HBH-610’ Line A1: a; Actual product number (without suffix); ‘KRY 901 087’ b; R-state of product; ‘Rrr’ c; C-tic logo with number ‘N12878’ Line A2: a; Type number; ‘Type: DDA-0001006’ b; CE0682-logo Line A3: a; FCC approval number; ‘FCC ID: PY7DDA-1006’ b; New Zealand approval number; ‘Z354’ Line A4: a; Canada approval number; ‘IC: 4170B-DDA1006’ b; Country of production; ‘Made in China’ Line A5: a; Bluetooth Device Address; ‘BDA: nnnnnnnnnnn’ b; Production date; ‘yyWww’ Format Textfield size is 16.5 x 8 mm Text font type Arial or similar, fontsize 1.0 mm Graphics; 1.3 mm height • SonyEricsson (Capital S) • HBH-610, Fonttype Arial or similar. Fontsize 1.3 mm • CE logo with number, according to SVF 930 182 Ux • C-tic logo with number, according to SVF 930 2333 Ux Marking illustration KRY 901 087 P1A Type: DDA-0001006 FCC ID: PY7DDA-1006 Z354 I C: 4 1 7 0 B-DDA1 0 0 6 M a d e i n Ch i n a B DA: 012345678902 yyWww N 12878 HBH-610 0682 Conceptual picture of the marking. Information shown might be incorrect.
