Important Information United States & Canada THIS PHONE MODEL HAS BEEN CERTIFIED IN COMPLIANCE WITH THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. The Series mobile phones have been designed to comply with applicable safety requirements for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed to not exceed the limits* of exposure to radio frequency (RF) energy set by governmental authorities. These limits establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by international scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a safety margin designed to assure the safety of all individuals, regardless of age and health. The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate (SAR). Tests for SAR are conducted using standardized methods with the phone transmitting at its highest certified power level in all used frequency bands. While there may be differences between the SAR levels of various phone models, they are all designed to meet the relevant guidelines for exposure to radio waves. For more information on SAR, please refer to the safe and efficient use chapter in the User Guide. The highest SAR value as reported to the authorities for this phone model when tested for use by the ear is W/kg*, and when worn on the body is W/kg* for speech and W/kg* for data calls. Body worn measurements are made while the phone is in use and worn on the body with a Sony Ericsson accessory supplied with or designated for use with this phone. It is therefore recommended that only Ericsson and Sony Ericsson original accessories be used in conjunction with Sony Ericsson phones. **Before a phone model is available for sale to the public in the US, it must be tested and certified by the Federal Communications Commission (FCC) that it does not exceed the limit established by the government-adopted requirement for safe exposure*. The tests are performed in positions and locations (i.e., by the ear and worn on the body) as required by the FCC for each model. The FCC has granted an Equipment Authorization for this phone model with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR levels of various phones, all mobile phones granted an FCC equipment authorization meet the government requirement for safe exposure. SAR information on this phone model is on file at the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID Additional information on SAR can be found on the Cellular Telecommunications & Internet Association (CTIA) website at http://www.phonefacts.net. * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard incorporates a margin of safety to give additional protection for the public and to account for any variations in measurements. **This paragraph is only applicable to authorities and customers in the United States. This is an Internet version of this publication. © Print only for private use. W960i 0.95 1.09 1.16 PY7F3022017. Renseignements importants États-Unis et Canada CE MODÈLE DE TÉLÉPHONE A ÉTÉ CERTIFIÉ CONFORME AUX EXIGENCES GOUVERNEMENTALES RELATIVES À L'EXPOSITION AUX ONDES RADIOÉLECTRIQUES. Les téléphones mobiles ont été conçus pour répondre aux normes de sécurité en vigueur en matière d'exposition aux ondes radioélectriques. Votre téléphone sans fil est un émetteur et un récepteur radio. Il est conçu de manière à ne pas dépasser les limites* d'exposition aux signaux radiofréquences (RF) établies par les autorités gouvernementales. Ces limites fixent les niveaux maximaux d'énergie radiofréquence auxquels peut être soumis le grand public. Ces lignes directrices sont basées sur des normes qui ont été élaborées par des organisations scientifiques internationales par le biais d'évaluations périodiques et approfondies des études scientifiques. Ces normes prévoient une marge de sécurité visant à assurer la protection de toutes les personnes, quels que soient leur âge et leur état de santé. Les lignes directrices relatives à l'exposition aux ondes radioélectriques utilisent une unité de mesure appelée "Débit d'absorption spécifique" (SAR). Les tests de SAR sont effectués selon des méthodes standardisées dans lesquelles le téléphone émet dans toutes les bandes de fréquences utilisées, à la plus forte puissance pour laquelle il a été homologué. Bien que le débit d'absorption spécifique puisse être différent d'un modèle de téléphone à un autre, tous les appareils sont conçus pour respecter les lignes directrices relatives aux ondes radioélectriques. Pour en savoir plus sur le débit d'absorption spécifique, reportez-vous au chapitre sur l'utilisation efficace et sans danger de ce présent guide. Le débit d'absorption spécifique le plus élevé relevé par les autorités pour ce modèle de téléphone est de W/kg* lorsqu'il est testé en utilisation près de l'oreille, et de W/kg* (pour les appels vocaux) et de W/kg* (pour les appels de données) lorsqu'il est porté sur le corps. Lors des mesures de port sur le corps, le téléphone était maintenu par un accessoire Sony Ericsson fourni avec ce téléphone ou conçu pour être utilisé avec l'appareil. Il est par conséquent recommandé de n'utiliser que les accessoires authentiques Ericsson et Sony Ericsson avec les téléphones Sony Ericsson. **Avant qu'un modèle de téléphone ne soit offert au public aux États-Unis, la FCC (Federal Communications Commission) doit le tester et certifier qu'il respecte les limites fixées dans les exigences gouvernementales d'exposition sans danger*. Pour chaque modèle, les tests sont effectués en position et aux endroits d'usage (c'est- à-dire près de l'oreille et porté…

Text truncated - open the document above for the full version.

Document number BGLI07:337 Prepared by Date BGGINK Lennart Skoglund 2007-08-20 Contents responsible if other than preparer Remarks Approved by Reference POWER OF ATTORNEY To whom it may concern: The following organisation is granted authority to act on Sony Ericsson Mobile Communications AB’s behalf, to file technical reports, measurements and forms for Sony Ericsson Mobile Communication mobile phone FAD-3022017-BV with the FCC ID: PY7F3022017 as it applies for a new equipment grant. CETECOM GmbH We certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. Further, no party as defined in 47CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Sincerely Lennart Skoglund

Confidentiality Request 2007-08-20 BGLI07:335 SEM/BGLIK Lennart Skoglund +46 8 7572533 Receiver Federal Communications Commission Subject: Request for Confidentiality FCC ID: PY7F3022017 To Whom It May Concern: In accordance with §0.459 of CFR 47, Sony Ericsson Mobile Communications AB requests confidentiality for the below listed items for our Mobile Phone type FAD-3022017-BV, FCC ID: PY7F3022017: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational/Technical Descriptions These items contain detailed system and equipment description and related information about the product which Sony Ericsson Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Ericsson Mobile Communications AB also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Best Regards, ______________________ Lennart Skoglund Type Approval and verification Sony Ericsson Mobile Communications AB

CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-24-02/07 2007-08-14 Page 17 of 27 7 Photographs of the EUT Photo No.: 01 Photo No.: 02 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-24-02/07 2007-08-14 Page 18 of 27 Photo No.: 03 Photo No.: 04 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-24-02/07 2007-08-14 Page 19 of 27 Photo No.: 05 Photo No.: 06 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-24-02/07 2007-08-14 Page 20 of 27 Photo No.: 07 Photo No.: 08

Company Internal MARKING DRAWING 1 (3) Prepared (also subject responsible if other) No. SEM/BGODD Mats Hörlin 151 86-SVV 107 665/3 Uen Approved Checked Date Rev Reference SEM/BGODD (Mats Hörlin) 2007-09-06 A 14 W960i, KRH-label, TYPE: FAD-3022017-BV, Made in... WEEE-logo 1 General information The format of the label is based on a label SVF 930 1450 (35,0 x 45,0 mm). If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. All bar codes, when applicable, are according to Ericsson corporate standard 102 01–109 Uen. All bar codes shall fulfil minimum print quality C according to ANSI X3.182-1990 as stated in Ericsson corporate standard 102 01–1003 Uen. No bar codes are allowed to be closer to a label edge than 2 mm! (quiet zone). “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. The label shall be placed on the back of the telephone according to the Assembly Drawing (151 88-) for the KRH. 2 Printing information Content Format Line 1 (8,0/2,0) Simcard symbol Graphics, height 14 mm. According to 1424-SVF 930 2622/1. Line 2 (12,5/2,0) Sony Ericsson stylized name. Graphics, height 2,0 mm. According to 190 89–EN/LZT 108 5347 Line 3a (14,5/2,0) Model name, “W960i” Text, height 1,2 mm. Line 3b (14,5/8,0) Product number of the DPY kit in which the phone is packed. Printed without “R-state”, “DPY 101 0000/000” Text, height 1,2 mm. Line 4a (16,5/2,0) Country approval mark 1 “FCC ID: PY7F3022017” Text, height 1,2 mm. Line 4b (16,5/19,5) Country approval mark 2 “IC:4170B-F3022017” Text, height 1,2 mm. Line 5a (18,5/2,0) Type number of the phone (KRH), “Type: FAD-3022017-BV”. Text, height 1,2 mm. Line 5b (18,5/19,5) ROA and R-state identification field, “G 1 G 2 G 3 HY 1 Y 2 Y 3” Text, height 1,2 mm. “G”,“H”and “Y”-field According to the Type approval report 174 52-SVV 107 636/1. This document will be found in the 1095- for this SVV. Company Internal MARKING DRAWING 2 (3) Prepared (also subject responsible if other) No. SEM/BGODD Mats Hörlin 151 86-SVV 107 665/3 Uen Approved Checked Date Rev Reference SEM/BGODD (Mats Hörlin) 2007-09-06 A 14 Content Format Line 6 (21,5/2,0) Line 7 in bar code. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 7 (23,0/2,0) Supplier’s identification for trace- ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” For serial number). Text, height 1,2 mm. Defined by supplier. Line 8 (26,0/2,0) Line 9 in bar code (only actual number, without data identifier). Bar code, height 4,0 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. Line 9a (27,5/2,0) Actual electronic serial number (IMEI) of the phone (KRH), “00000000-000000-0” Text, height 1,2 mm. In the format TAC-SNR-CD. TAC and SNR derived from the 1301- FAD 109 0117/1 document in the 1095- for the SVV. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 9b (27,5/27) Repair week, if applicable. “Ry’W’ww” (y = year, ww = week) Text, height 1,2 mm. Line 10a (30,5/2,0) Production week (flash), “yy’W’ww” (yy = year, ww = week) Text, height 1,2 mm. Line 10b (30,5/10,0) Location code of where the phone is flashed, if applicable, “FFF” Text, height 1,2 mm. Line 11 (32,5/2,0) Marking of origin. The line shall be printed as stated in chapter 3 in this document. Text, height 1,2 mm. Line 12a (44,0/2,0) CE approval symbol. Graphics, height 5 mm. According to 1424-SVF 930 182/2. Line 12b (44,0/17,0) Alert sign Graphics, height 5 mm. According to 1424-SVF 930 2517. Line 12c (44,0/27,0) WEEE-logo Graphics, height 5 mm. According to 1424-SVF 930 1444/3. Company Internal MARKING DRAWING 3 (3) Prepared (also subject responsible if other) No. SEM/BGODD Mats Hörlin 151 86-SVV 107 665/3 Uen Approved Checked Date Rev Reference SEM/BGODD (Mats Hörlin) 2007-09-06 A 14 3 Marking of Origin 3.1 Content “Made in Xxx”; “Xxx” = actual country of production of the included telephone, in English 4 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 4.1 Conceptual picture double underlined = major changes since last revision. Position of label The view below is taken from the back side of the mobile telephone. The label is located below the battery lid. SVV 107 665/P1 KRH-label, prototype

CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-24-02/07 2007-08-14 Page 21 of 27 Photo No.: 09 Photo No.: 10 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-24-02/07 2007-08-14 Page 22 of 27 Photo No.: 11 Photo No.: 12 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-24-02/07 2007-08-14 Page 23 of 27 Photo No.: 13 Photo No.: 14 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-24-02/07 2007-08-14 Page 24 of 27 Photo No.: 15 Photo No.: 16 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-24-02/07 2007-08-14 Page 25 of 27 Photo No.: 17 Photo No.: 18 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-24-02/07 2007-08-14 Page 26 of 27 Photo No.: 19 Photo No.: 20 CETECOM ICT Services GmbH Annex to Test report no.: 2-4576-24-02/07 2007-08-14 Page 27 of 27 Photo No.: 21

1 (34) EAB-07:038956 Uen, Rev A, 2007-08-16 Laboratories are accredited by the Swedish Board for Accreditation and Conformity Assessment (SWEDAC) under the terms of Swedish legislation. The accredited laboratory activities meet the requirements in SS-EN ISO/IEC 17025:2005. This report shall not be reproduced except in full, without written approval of the laboratory. Report issued by an Accredited Laboratory Rapport utfärdad av ett ackrediterat laboratorium This laboratory is accredited to SS-EN ISO/IEC 17025 (SWEDAC accreditation no. 1761). SAR Test Report, FCC ID: PY7F3022017 Document number: EAB-07:038956 Uen Rev A Date of report: 2007-08-16 Testing laboratory: Ericsson EMF Research Laboratory Ericsson AB SE-164 80 Stockholm Sweden Company/Client: Lars Melin Sony Ericsson Mobile Communications AB Box 64 SE-164 94 Stockholm Sweden Tests performed by: Johan Danestig Date of tests: August 7 – 8 2007 Manufacturer and market name(s) of device: Sony Ericsson Mobile Communications AB, W960i Testing has been performed in accordance with: IEEE Std 1528, IEC 62209-1, FCC OET Bulletin 65 Supplement C Test results: The tested device complies with the requirements in respect of all parameters subject to the test. Additional information: Signature: Test engineer _______________________ Johan Danestig Research Engineer [email protected] Tel: +46 8 508 765 41 Quality manager _______________________ Christer Törnevik Director, EMF Health and Safety [email protected] Tel: +46 8 7641235 © Telefonaktiebolaget LM Ericsson AB 2 (34) EAB-07:038956 Uen, Rev A, 2007-08-16 Table of Contents Table of Contents ....................................................................................................................................... 2 1 Summary of SAR Test Report ............................................................................................................ 3 1.1 Equipment under test (EUT).....................................................................................................3 1.2 Results...................................................................................................................................... 3 2 General information ............................................................................................................................ 4 3 Equipment under test.......................................................................................................................... 4 4 Test equipment ................................................................................................................................... 6 4.1 Dosimetric system .................................................................................................................... 6 4.2 Additional equipment ................................................................................................................ 6 5 Electrical parameters of the tissue simulating liquids.........................................................................7 6 SAR system performance check ........................................................................................................ 8 7 Uncertainty evaluation of SAR measurement system DASY4 according to IEC 62209-1 [1] and IEEE 1528 [2]...................................................................................................................................... 9 8 Test results ....................................................................................................................................... 10 8.1 Results for the GSM1900 mode (head) ................................................................................. 11 8.2 Results for the GSM1900 mode (body).................................................................................. 11 8.3 Results for the GPRS(2Tx)1900 mode (body) ....................................................................... 12 8.4 Results for the GPRS(1Tx)1900 mode (body) ....................................................................... 12 8.5 Results for the WLAN 802.11b mode (head) ......................................................................... 13 8.6 Results for the WLAN 802.11b mode (body) ......................................................................... 13 8.7 Multi-mode maximum SAR..................................................................................................... 14 9 Conclusion ........................................................................................................................................ 15 10 References ....................................................................................................................................... 15 11 Revision History................................................................................................................................ 15 APPENDIX A: Photographs of the EUT ................................................................................................... 16 APPENDIX B: Photographs of the EUT when positioned for SAR measurements ................................. 17 APPENDIX C: SAR distribution plots for the system performance checks.............................................. 19 APPENDIX D: SAR distribution plots ....................................................................................................... 23 APPENDIX E: Probe calibration parameters for ES3DV3, S/N: 3113 ..................................................... 34 3 (34) EAB-07:038956 Uen, Rev A, 2007-08-16 1 Summary of SAR Test Report 1 1.1 Equipment under test (EUT) Serial Number CB5A0EPJ5A (Used for GSM/GPRS testing) CB5A0EKY2B (Used for WLAN testing) Type Number FAD-3022017-BV Device ID FCC ID: PY7F3022017 IC: 4170B-F3022017 Accessories used in testing Handsfree HPM-70, Bluetooth handsfree HBH-DS200 Battery BST-33 Hardware status Pre-production EP2.1 Notes - Frequency Band [MHz] 850 900 1800 1900 2100 2450 Modes GS…
