P900 User Guide LettersLowercase letters are written below the arrow and uppercase letters in line with the arrow. Note Start each stroke at the dotted end. Accented lettersWrite the character as described above, then write the accent above the arrow. Other such characters, for example, ö and ü, follow the same principle. Note Start each stroke at the dotted end. NumbersNumbers are written above the arrow.Note Start each stroke at the dotted end. a b c d e f g h k l m n o p q r s t u v y z w x 1 2 i j 1 1 1 1 1 1 2 1 2 2 2 2 2 2 ,. « ? ! & @ " 01234567 89 , . * or + * / \ ( ) = 3 ContentsO VERVIEW Introduction................................................................. 8Getting to know your P900......................................... 9 P900 package...................................................................... 9 P900 overview .................................................................. 10 SIM card ........................................................................... 11Battery .............................................................................. 11Care instructions............................................................... 12First time start-up.............................................................. 13Turning your P900 on and off .......................................... 13 Importing phone book entries........................................... 13 Operational modes............................................................ 14Flip closed mode .............................................................. 15Flip open mode ................................................................. 16Flip removed..................................................................... 16Screen areas ...................................................................... 17Jog Dial ............................................................................ 18Keypad functions ............................................................. 19Indicators and status bar icons.......................................... 20Memory Stick® Duo™ .................................................... 21Connecting the accessories............................................... 23Services............................................................................. 24Applications - overview.................................................... 24General functions.............................................................. 27 Entering text..................................................................... 31P900 locks........................................................................ 35 Phone.......................................................................... 38 Call handling with the Flip closed ................................... 38Call handling with the Flip open...................................... 41Handling two or more calls.............................................. 44Call list and call log ......................................................... 45Hints and smart functions ................................................ 46Preferences....................................................................... 50 M EDIA CommuniCorder....................................................... 56 Recording video clips ...................................................... 56Taking pictures ................................................................ 58Camera settings................................................................ 59 Pictures and Image editor........................................ 60 Pictures ............................................................................ 60Image editor ..................................................................... 62 Video player .............................................................. 64 Video clips ....................................................................... 64Streaming ......................................................................... 66Preferences....................................................................... 67 Music player.............................................................. 68 4 Playing sound files............................................................ 68Managing sound files........................................................ 69 Internet....................................................................... 72 Using the browser view .................................................... 73Using the bookmark view................................................. 76 Preferences........................................................................ 78 Games......................................................................... 80 Chess................................................................................. 80Solitaire............................................................................. 80 B USINESS Messaging................................................................... 82 Folders in Messaging........................................................ 83The accounts in Messaging............................................... 84Handling text messages .................................................... 84Handling multimedia messages ........................................ 85Handling e-mails............................................................... 88More about messaging...................................................... 91 Contacts...................................................................... 94 Using Contacts with the Flip closed ................................. 94Using Contacts with the Flip open.................................... 96Creating and editing contacts............................................ 97Managing contacts............................................................ 99Making an owner card .................................................... 100Preferences..................................................…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03Page 60 (72) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03Page 61 (72) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03Page 62 (72) PHOTOGRAPH OF THE EQUIPMENT

Company Internal MARKING DRAWING 1 (4) Prepared (also subject responsible if other) No. SEMBGKTLD Arne Rahm 151 86-SVV 104 601/1 Uen Approved Checked Date Rev Reference KI/SEMBGKTL Leif Brunström 2003-10-02 D Type FAB-102 1011-BV. Smartphone P900 1. Label The label used for marking is defined in the Manufacturing Specification on the SVF 930 863. 2. Placing The label shall be placed on the back of the telephone according to the Assembly Drawing (151 88-) for the KRH. 3. Print layout Printing area 31.6 x 18.5 mm. Line nbr 1. yyyy/x RXX Rywwxx P900 xxxxxxxxxx 2. Type FAB-102 1011-BV G1G2G3HY1Y2Y3 xxxxxxxxxx 3. 4. 35196500-XXXXXX-X 5. 6. XXXXXXXXXX yyWww CDAxxxxxxx Rxx 7. IC: 4170B-FB021011 8. FCC ID: PY7FAB1021011 9. 10. 11 Line Text Text height 1. Reduced DPY-number, R-state, Repair week, Model name, Additional field (if necessary) min 1.2 mm 2. Type number, G1,G2, G3, H, Y1, Y2, Y3 field, Additional field min 1.2 mm 3. IMEI number as bar code min 3.5 mm 4. IMEI number as characters min 1.2 mm 5. Serial number as bar code min 3.5 mm 6. Serial number as characters, production week, CDA number , R-state. min 1.2 mm 7. Country approval mark 1 min 1.2 mm 8. Country approval mark 2 min 1.5 mm 9. Approval mark, angled 90° clw Min 5.0 mm 10. Sony Ericsson trademark, angled 90° clw min 2.0 mm 11. Marking of origin, angled 90° clw min 1.2 mm 2 (4) Prepared (also subject responsible if other) No. SEMBGKTLD Arne Rahm 151 86-SVV 104 601/1 Uen Approved Checked Date Rev Reference KI/SEMBGKTL Leif Brunström 2003-10-02 D 4. Print layout Prototype label Printing area 31.6 x 18.5 mm. Line nbr 1. yyyy/x Rxx Rywwxx P900 2. NOT TYPE APPROVED 3. 4. 004601-01-XXXXXX-X 5. 6. XXXXXXXXXX yyWww CDAxxxxxxx Rxx 7. 8. PROTOTYPE XXX 9. 10. 11. Line Text Text height 1. Prototype DPA-number, R-state, Repair week, Model name min 1.2 mm 2. “NOT TYPE APPROVED” min 1.2 mm 3. IMEI number as bar code. See line 4. min 3.5 mm 4. IMEI number as characters. Must consist of 004601-01-SNR-CD. Were SNR = serial number 425 000 – 429 999 CD = check digit 0-9. min 1.2 mm 5. Serial number as bar code min 3.5 mm 6. Serial number as characters, production week, CDA number, R-state. min 1.2 mm 7. Blank 8. “PROTOTYPE XXX” (EP1, FP2.1, etc) min 3.5 mm 9. Blank min 1.2 mm 10. Sony Ericsson trademark, angled 90° clw min 2.0 mm 11. Marking of origin, angled 90° clw min 1.2 mm 5. Definitions: 1. Reduced DPY- number The DPY number, according to 1095- for the produced product, without “DPY 101” e.g. if DPY 101 2541/1 is produced the printing should be “2541/1”. (6 pos) R-state The R-state for the DPY according to the 1095- for the DPY. (3 pos) Repair week The field shall be left blank unless a repair centre repairs the unit. The repair week shall then be given as Rywwxx. (R = repair, y = year, ww = week, xx = 3 (4) Prepared (also subject responsible if other) No. SEMBGKTLD Arne Rahm 151 86-SVV 104 601/1 Uen Approved Checked Date Rev Reference KI/SEMBGKTL Leif Brunström 2003-10-02 D R-state e.g. 1A). (6 pos) Model name The model name P900 Additional field (if necessary) The field shall be left blank unless otherwise stated in a separate 2/151 86-SVV according to 1095- of the actual SVV. Some fields might need two lines. 2. Ericsson Type number The type number shall be printed “Type FAB-1021011-BV” (19 pos) G1-field R-state of the CXC-phone sw according to the Type approval report 17452-SVV104601/1. G2-field R-state of the CXC-organizer sw according to the Type approval report 17452-SVV104601/1. G3-field R-state of the CXC-BT sw according to the Type approval report 17452-SVV104601/1. H-field R-state of the type approved hardware according to the Type approval report 17452-SVV104601/1. Y1-field R-state of the KRH according to the Marking drawing 1/151 86-SVV104601/1. Y2-field ROA identification according to the Marking drawing 1/151 86-SVV104601/1. Y3-field R-state of the ROA according to the Marking drawing 1/151 86-SVV104601/1. Additional field The field shall be left blank unless otherwise stated in a separate 2/151 86-SVV according to 1095- of the actual SVV. 3. IMEI number as bar code See below for definition of IMEI-number. The bar code shall only contain the digits of the IMEI number (no dash). Acc. to Ericsson corporate standard 102 01-109. Code 128. 4. IMEI number as characters The IMEI number has format: TAC-SNR-CD (17 pos) TAC = 35196500 (type approval code) (8 pos) SNR = Serial number from 000 000 to 999 999 (6 pos) CD = A check digit, from 0-9, calculated (1 pos) according to the Luhn formula (ISO/IEC 7812), GSM 02.16. 5. Serial number as bar code According to Ericsson corporate standard 102 01 - 109. Code 128 6. Serial number as characters According to Ericsson group standard (10 pos) 0012-101. Ericsson group factory number system according the Ericsson corporate standard 1120-101 Factory codes: Flextronics Linköping A61 Ericsson Beijing CB5 Sony Alsace AL Production week The production week shall be given as yyWww (yy = year, ww = week) according to the ISO 8601 standard. (5 pos) 4 (4) Prepared (also subject responsible if other) No. SEMBGKTLD Arne Rahm 151 86-SVV 104 601/1 Uen Approved Checked Date Rev Reference KI/SEMBGKTL Leif Brunström 2003-10-02 D CDA number, R-state The CDA number and the R-state according to 13132- for the produced DPY. (16 pos) 7. Country approval mark 1 Consist of text: “IC 4170B-FB021011” 8. Country approval mark 2 Consist of text: “FCC ID: PY7FAB1021011” in a frame with height > 1,5 mm 9. Approval marks According to 1424 - SVF 930 52 The notified body number 0682 according to the RTTE directive. The print height for the notified body number and approval mark CE is a regulatory requirement. 10. Sony Ericsson Trademark According to corporate standard 190 89-EN/LZT 108 5347. 11. Marking of origin The field shall be left blank unless otherwise stated in a separate 3/151 86-SVV document according to 1095- of the actual SVV.

CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03Page 64 (72) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03Page 65 (72) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03Page 66 (72) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03Page 67 (72) PHOTOGRAPH OF THE EQUIPMENT CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03Page 68 (72) PHOTOGRAPH OF THE EQUIPMENT

CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 SaarbrückenTelephon: +49 (0)681 598-0Telefax: -9075 RSC14issue test report consist of 72 PagesPage 1 (72) Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463 (IC) TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 166/98 Independent ETSI compliance test house ETSI Accredited Bluetooth™ Test Facility (BQTF) Test Report No.: 2_3371-01-02/03 FCC Part 15.247 / CANADA RSS-210 FAB-102 10 11-xx FCC ID: PY7FAB1021011 Canada IC: 4170B-F1021011 CETECOM – ICT Services GmbH Untertürkheimerstr. 6-10 66117 Saarbrücken, Germany Telephone: + 49 (0) 681 / 598-0 Fax: + 49 (0) 681 / 589-9075 BLUETOOTH is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03 Page 2 (72) Table of Contents 1 General Information 1.1 Notes 1.2 Testing Laboratory 1.3 Details of Applicant 1.4 Application Details 1.5 Test Item 1.6 Test Specifications 2 Technical Test 2.1 Summary of Test Results 2.2 Test Report CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03 Page 3 (72) 1 General Information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. Test Laboratory Manager: 2003-09-11RSC8411Berg M. DateSectionNameSignature Technical Responsibility for Area of Testing: 2003-09-11RSC8412Hausknecht D. DateSectionNameSignature CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03 Page 4 (72) 1.2 Testing Laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telephone: + 49 681 598 - 0 Telefax : + 49 681 598 - 9075 E-mail : [email protected] Internet : www.cetecom-ict.de Accredited testing laboratory The Test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025. DAR-registration number : TTI-P-G 166/98-30 Accredited Bluetooth™ Test Facility (BQTF) BLUETOOTH is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM 1.3Details of Applicant Name : Sony Ericsson Mobile Communication AB Street : Torshamnsgatan 27 City : 164 94 Kista Country : Sweden Telephone : +46 8 757 25 33 Telefax : +46 8 404 34 30 Contact : Mr. Lennart Skoglund Telephone : Tel +46 8 757 25 33, Fax +46 8 404 34 30 Email :[email protected] 1.4 Application Details Date of receipt of application : 2003-08-28 Date of receipt of test item : 2003-08-28 Date of test : 2003-08-28 to 2003-09-02 CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03 Page 5 (72) 1.5 Test Item Type of equipment : Mobile phone with Bluetooth Type designation: FAB-1021011-BV/CN Manufacturer: Applicant Street: City: Country: Serial number: 004601-01-427226-5-01 FCC – ID: PY7FAB1021011 IC : 4170B-F1021011 Hardware: Software : Additional information : Frequency: 2402 – 2480 MHz Type of modulation: 1M00FXD / 79M8FXD (FHSS) Number of channels : 79 Antenna: Print antenna Power supply: 3.7V LiIon Accumulator Output power: EIRP: 0.30 mW (worst case); conducted : 0.59 mW Field strength: max. 97.73 dBμV/m Occupied bandwidth: 817.653 kHz Transmitter spurious : 88.1 μV/m in 3m Receiver spurious. 126.6 μV/m in 3m Temperature range: -30°C - +60°C DECLARATION OF COMPLIANCE: I declare that the testing was performed or supervised by me; that the test measurements were made in accordance with the above-mentioned Industry Canada standard(s); and that the equipment identified in this application has been subjected to all the applicable test conditions specified in the Industry Canada standards and all of the requirements of the standard have been met. Signature: _______________________________________________ Date: ___2003-05-09 Michael Berg ; Test management NAME AND TITLE (Please print or type): 1.6 Test Specifications: FCC Part 15 §15.247 CANADA RSS-210 CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03 Page 6 (72) 2 Technical Test 2.1Summary of Test Results The radiated measurements are performed in vertical and horizontal plane in the frequency range from 9 kHz to 25 GHz in semi-anechoic chambers. The EUT is positioned on a non- conductive support with a height of 0.80 m above a conductive ground plane that covers the whole chamber. The receiving antennas are conform with specifications ANSI C63.2-1987 clause 15 and ANSI C63.4-1992 clause 4.1.5. These antennas can be moved over the height range between 1.0 m and 4.0 m in order to search for maximum field strength emitted from EUT. The measurement distances between EUT and receiving antennas are indicated in the test setups for the various frequency ranges. For each measurement, the EUT is rotated in all three axes until the maximum field strength is received. The wanted and unwanted emissions are received by spectrum analysers where the detector modes and resolution bandwidths over various frequency ranges are set according to requirement ANSI C63-4-1992 clause 4.2. Antennas are conform with ANSI C63.2-1996 item 15. 150 kHz - 30 MHz: Quasi Peak measurement, 9kHz Bandwidth, passive loop antenna. 30 MHz - 200 MHz: Quasi Peak measurement, 120KHz Bandwidth, biconical antenna 200MHz - 1GHz: Quasi Peak measurement, 120KHz Bandwidth, log periodic antenna 1GHz: Average, RBW 1MHz, VBW 10 MHz, waveguide horn All measurements are done in accordance with the Filing and Measurement Guidelimes for Frequency Hopping S…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03Page 57 (72) Pictures Radiated Emissions CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03Page 58 (72) Test site CETECOM ICT Services GmbH Test Report No.: 2_3371-01-02/03Issue Date: 2003-09-03Page 59 (72) conducted measurements
