EDGE PC Card Sony Ericsson EDGE PC Cards GC82, GC83 and GC85 User Guide 2Contents Content Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Hardware Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Software Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Services Available Over the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 EDGE PC Card Hardware Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Installing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Start Using Wireless Manager. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Wireless Manager Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Wireless Manager Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Windows Log on Using GPRS/EDGE Dial-up Connection . . . . . . . . . . . . . 19 Create a Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 GPRS Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 CSD Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Modify a Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Delete a Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Using your Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Browse the Internet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Send and Receive emails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Wireless Manager Status Screen . . . . . . . . . . . . . . . . . . . . . . . . . 25 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Wireless Manager Telephony Settings Screen . . . . . . . . . . . . . . 27 Phone Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Networks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Forward Calls (Divert). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Restrict Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Wireless Manager SMS Messages Screen . . . . . . . . . . . . . . . . . . 33 SMS Manager Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Wireless Manager Phone Book Screen . . . . . . . . . . . . . . . . . . . . 37 The Phone Book Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Phone Book Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Wireless Manager Online Services Screen . . . . . . . . . . . . . . . . . 41 Contents3 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Wireless Manager Icon Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Software Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 SIM Card Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Sony Ericsson Support Web Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Guidelines for Safe and Efficient Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 License Agreement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Term . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Limitation of liability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Disputes and Governing Law . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Appendix A - Connection Parameters . . . . . . . . . . . . . . . . . . . . . 62 General Connection Parameters for CSD and GPRS . . . . . . . . . . . . . . . . 62 CSD Specific Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 TCP/IP Optimisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 Glossary . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Date June 28, 2004 Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Sony Ericsson Mobile Communications AB requests confidentiality for the following products: FCC ID Number Product Title/Model PY7FF021011 GC85/Type FAF-1021011-BV For the product stated above, we request that the following information be held confidential: • Electrical diagrams. • Component listing. • Technical description. • Operational description. • Block diagrams. No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain Sony Ericsson Mobile Communications AB trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our mobile PC Card. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please contact me at the address shown below. Sincerely, Michael Bower M2M Com Sony Ericsson Mobile Communications AB 1 Lakeside Road, Aerospace Centre Farnborough, Hampshire, GU14 6XP, UK Phone: +441252551631 E-mail: [email protected]

External Photos GC85 EUT – Top view External Photos GC85 EUT – Bottom view

Public SPECIFICATION 1 (5) Prepared (also subject responsible if other) No. GBBA/SEM/BMD/D Pete Saunders 1/151 86-KRD 102 332/1 Uen Approved Checked Date Rev Reference GBBA/SEM/BMD/D (Pam Wood) 2004-05-14 A SPECIFICATION Marking Drawing GC85 Type FAF-1021011-BV Label The label used for marking is defined in the Manufacturing Specification on the media used. Placing The label shall be placed on the back of the PC card according to the Assembly Drawing (151 88) for the KRD. Print layout Printing area 38 x 26 mm. 1 2 3 4 5 IMEI: XXXXXX-XX-XXXXXX-X 6 7 SN: XXXXXXXXXX 8 9 UPC: XXXXXXXXXXXX Lines: Line 10 Line 11 Line 12 1.0mm 0.5mm 1.0mm 0.5mm Public SPECIFICATION 2 (5) Prepared (also subject responsible if other) No. GBBA/SEM/BMD/D Pete Saunders 1/151 86-KRD 102 332/1 Uen Approved Checked Date Rev Reference GBBA/SEM/BMD/D (Pam Wood) 2004-05-14 A Definitions Line 1a Sony Ericsson trademark 1b Production Week as bar code 2a Approval marks ( 1,2 ) 2b Production Week as characters 3 Industry Canada marking and FCC approval marking 4 IMEI number as bar code 5 IMEI number as characters 6 Serial number as bar-code 7 Serial number as characters 8 UPC number as bar code 9 UPC number as characters 10 Product number, Product Variant, R-state (PRIM) Product Variant, Var: Generic=<blank>, AWS= /54, Cingular= /30 11 Type number 12a Marking of Country of Origin 12b Product Name “GC85” Sony Ericsson trademark Sony Ericsson and the Sony Ericsson trademark shall be according to the corporate standard 190 89-EN/LZT 108 5347. Height min. 3 mm. Approval marks 1. CE Marking. According to 1424 - SVF 930 52. 2. The Notified Body number. It shall be CE0682. The print size (height) for the notified body number and the corresponding approval marks shall be minimum 5 mm. This is a regulatory requirement. Local approval marks This field shall be used for local approval marks in countries where special marking is required. IMEI number as bar code See below for definition of IMEI-number. The bar code shall only contain the digits of the IMEI number (no -). Height 3.5 mm. IMEI number as characters XXXXXX-XX-XXXXXX-X The IMEI number has format: TAC1-TAC2-SNR-CD TAC1 = First six digits of the Type Public SPECIFICATION 3 (5) Prepared (also subject responsible if other) No. GBBA/SEM/BMD/D Pete Saunders 1/151 86-KRD 102 332/1 Uen Approved Checked Date Rev Reference GBBA/SEM/BMD/D (Pam Wood) 2004-05-14 A Approval code after assignment from the Notified Body. TAC2 = Last two digits of the Type Approval code after assignment from the Notified Body. SNR = A serial number “yyyyyy” from 000 000 to 999 999. CD = A Check Digit “d”, from 0-9, calculated according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Serial number as bar code According to Ericsson corporate standard 102 01 - 109. Height 3.5 mm. Serial number as characters According to Ericsson group standard 0012-101. Ericsson group factory number system according the Ericsson corporate standard 1120-101 Factory codes: Tecom (Taiwan)= S48 Elcoteq (Monterrey, Mexico)= TE6 UPC number as bar code The Sony Ericsson UPC Number, unless customer part number is required: XXXXXXXXXXXX According to AT&T PM-100-1-03. Height 3.5 mm. UPC number as characters According to AT&T PM-100-1-03. Type number The type number is FAF-1021011-BV and shall be printed “TYPE FAF-1021011-BV”. FCC approval marking FCC approval marking: consists of the text: FCC ID: PY7FF021011 Within a frame with height > 1.5 mm. Industry Canada marking Industry Canada approval marking: consists of text: IC: 4170B-FF021011 Public SPECIFICATION 4 (5) Prepared (also subject responsible if other) No. GBBA/SEM/BMD/D Pete Saunders 1/151 86-KRD 102 332/1 Uen Approved Checked Date Rev Reference GBBA/SEM/BMD/D (Pam Wood) 2004-05-14 A Production Week as bar code According to Ericsson corporate standard 102 01 - 109. Height 3.5 mm Production week The production week shall be given as yyWww (yy = year, ww = week) KRD number The KRD number for the product. R-state The R-state for the KRD according to the 1095 for the KRD. Marking of origin Marking of origin and shall be printed “Made in XXXXXX” where XXXXXX = Country of Origin. Printing regulations Fontface: OCR-B Type size: min. 1.3 mm Line spacing: min. 0.3 mm Trade mark height: min. 3 mm Approval marks height: min. 5 mm Colour: Black Margins: 1.0mm clear margin on Left & Right edges 0.5mm clear margin on Top & Bottom edges Layout: Lines 10, 11 & 12 should be Justified to the Bottom & Right label margins. Public SPECIFICATION 5 (5) Prepared (also subject responsible if other) No. GBBA/SEM/BMD/D Pete Saunders 1/151 86-KRD 102 332/1 Uen Approved Checked Date Rev Reference GBBA/SEM/BMD/D (Pam Wood) 2004-05-14 A Print layout for prototypes Line 2 is replaced with text with alternative shown below. Type size min. 5 mm. DEMO GC85 PROTOTYPE FP2 Line 3 and 4, the field shall be filled with the test IMEI numbers: XXXXXX-XX-XXXXXX-X The test IMEI number is: 004601-01- and the SNR are between 538yyy ---> 539yyy (the IMEI Check Digit “d” number must be added) Line 5 and 6 are serial numbers. Line 7 and 8 are replaced with text "NOT TYPE APPROVED". Text height min. 2 mm. Under this text the following fields should be put: • Production week, Product number, R-state. Text height min. 1.3 mm. • Text “Made in Country of Origin”. Text height min. 1.3 mm. LINES 1 2 XXXXXXXXXX 3 4 XXXXXX-XX-XXXXXX-X 5 6 XXXXXXXXXX 7 NOT TYPE APPROVED 8 yyWww KRD 102 332/1 PXX Made in XXXXXXXXX Label location

TTI-P-G 081/94-A0 Accredited according to ISO/IEC 17025 Bluetooth Qualification Test Facility (BQTF) FCC listed # 101450 IC recognized # 3925 CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2113686 Board of Directors: Dr. Harald Ansorge, Dr. Klaus Matkey, Hans Peter May V.2.16M-2002-03-12 \\stupendousman\rootappsdata\emc\projects_emc\broadcom(mobilink)\676- 2004_gc85\sar\report\sar_676_2004_fcc_900_1800_1900.doc © Copyright by CETECOM SAR Test Report No. SAR_676_2004_FCC_900_1800_1900 for the Sony Ericsson Mobile Communications AB PC – Card Radio module for GSM 900 MHz / 1800MHz / 1900MHz Model Number: FAF – 1021011-BV FCC ID: PY7 FF021011 Date of Report: 7/14/2004 Date of issue: 07/14/2004 Report Copy No.: 01 SAR Test Report No. SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Page 2 of 32 Error! Reference source not found. This report shall not be reproduced except in full without the written approval of: CETECOM Inc. Š SAR Š 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Contents 1 ASSESSMENT ...................................................................................................................4 2 ADMINISTRATIVE DATA...................................................................................................5 2.1 Identification of the Testing Laboratory Issuing the SAR Assessment Report ...............5 2.2 Identification of the Client...........................................................................................5 2.3 Identification of the Manufacturer...............................................................................5 3 EQUIPMENT UNDER INVESTIGATION (EUI)...................................................................6 3.1 Identification of the Equipment under Investigation ...................................................6 3.2 Front View of the Equipment under Investigation ......................................................7 4 SUBJECT OF INVESTIGATION ........................................................................................8 4.1 The IEEE Standard C95.1 and the FCC Exposure Criteria .......................................8 4.2 Distinction Between Exposed Population, Duration of Exposure and Frequencies...8 4.3 Distinction between Maximum Permissible Exposure and SAR Limits......................9 4.4 SAR Limit ...................................................................................................................9 5 THE FCC MEASUREMENT PROCEDURE .....................................................................10 5.1 General Requirements.............................................................................................10 5.2 Phantom Requirements ...........................................................................................10 5.3 Test Positions Body-worn and Other Configurations ...............................................10 5.4 Procedure for assessing the peak spatial-average SAR .........................................11 5.5 Determination of the largest peak spatial-average SAR ..........................................13 6 THE MEASUREMENT SYSTEM ......................................................................................14 6.1 Robot system specification ......................................................................................14 6.2 Probe and amplifier specification .............................................................................15 6.3 Phantoms.................................................................................................................15 6.4 SAR measurement procedure .................................................................................16 6.5 SARA2 Interpolation and Extrapolation schemes ....................................................16 6.6 Interpolation of 2D area scan...................................................................................17 SAR Test Report No. SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Page 3 of 32 Error! Reference source not found. This report shall not be reproduced except in full without the written approval of: CETECOM Inc. Š SAR Š 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. 6.7 Extrapolation of 3D scan..........................................................................................17 6.8 Interpolation of 3D scan and volume averaging.......................................................17 7 UNCERTAINTY ASSESSMENT.......................................................................................19 7.1 Table of Measurement Uncertainty Values of SAR Evaluations..............................20 7.2 Table of Measurement Uncertainty Values for SAR System Verification ................21 8 TEST RESULTS SUMMARY............................................................................................22 8.1 Conducted Output Power.........................................................................................22 8.2 Test Positions and Configurations ...........................................................................22 8.3 GPRS Operating Mode ............................................................................................22 8.4 1900 MHz band GPRS 2 timeslots results in PC #1................................................23 8.5 1900 MHz band GPRS 2 timeslots results in PC #2................................................24 8.6 1900 MHz band GPRS 2 timeslots results in PC #3................................................25 8.7 Validation Check Results .........................................................................................26 9 REFERENCES..................................................................................................................27 SAR Test Report No. SAR_676_2004_FCC_900_1800_1900 Da…

Text truncated - open the document above for the full version.

SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 1 of 18 Photo 1. EUT Top side FCC ID: PY7F1041011 Photo 1. EUT Top side FCC ID: PY7 FF021011 SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 2 of 18 Photo 2. EUT bottom side FCC ID: PY7F1041011 Photo 2. EUT bottom side FCC ID: PY7 FF021011 SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 3 of 18 Photo 3. PC #1 lap antenna parallel SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 4 of 18 Photo 4. PC #1 lap antenna perpendicular SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 5 of 18 Photo 5. PC #1 bystander antenna vertical SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 6 of 18 Photo 6. PC #1 bystander antenna horizontal SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 7 of 18 Photo 7. PC #1 bystander distance SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 8 of 18 Photo 8. PC #2 lap antenna parallel SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 9 of 18 Photo 9. PC #2 lap antenna perpendicular SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 10 of 18 Photo 10. PC #2 bystander antenna vertical SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 11 of 18 Photo 11. PC #2 bystander antenna horizontal SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 12 of 18 Photo 12. PC #2 bystander distance SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 13 of 18 Photo 13. PC #3 lap antenna parallel SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 14 of 18 Photo 14. PC #3 lap antenna perpendicular SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 15 of 18 Photo 15. PC #3 bystander antenna vertical SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 16 of 18 Photo 16. PC #3 bystander antenna horizontal SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 17 of 18 Photo 17. PC #3 bystander distance SAR Test Report No : SAR_676_2004_FCC_900_1800_1900 Date of Report: 07/14/2004 Appendix B Photos Page 18 of 18 Photo 18. Photo to demonstrate 15 cm Z-axis flat phantom

TTI-P-G 081/94-A0 Accredited according to ISO/IEC 17025 Bluetooth Qualification Test Facility (BQTF) FCC listed # 101450 IC recognized # 3925 CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2113686 Board of Directors: Dr. Harald Ansorge, Dr. Klaus Matkey, Hans Peter May V1.1 2003-03-01 The BLUETOOTH trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to CETECOM Inc. © Copyright by CETECOM FCC Test report Test report no.: EMC_676FCC-24_2004 FCC Part 24 / RSS 133 FCC ID: PY7FF021011 IC ID: 4170B-FF021011 CETECOM Inc. Test report no.: EMC_676FCC-24_2004 Issue date: 2004-06-29 Page 2 (55) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test report 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM Inc. does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM Inc. TEST REPORT PREPARED BY: EMC Engineer: Harpreet Sidhu 1.2 Testing laboratory CETECOM Inc. 411 Dixon Landing Road, Milpitas, CA-95035, USA Phone: +1 408 586 6200 Fax: +1 408 586 6299 E-mail: [email protected] Internet: www.cetecom.com CETECOM Inc. Test report no.: EMC_676FCC-24_2004 Issue date: 2004-06-29 Page 3 (55) 1.3 Details of applicant Name : Sony Ericsson Mobile Communications AB Street : Maplewood, Chineham Business Park City / Zip Code : Basingstoke, Hampshire RG24 8YB Country : United Kingdom Contact : Jose Aurelio Rodrigo Telephone : +44 1256774841 Tele-fax : +44 1256774280 e-mail : [email protected] 1.4 Application details Date of receipt test item : 2004-06-24 Date of test : 2004-06-24 1.5 Test item Manufacturer : Applicant Marketing Name : GC85 Model No. : FAF-1021011-BV Description : PC – Card Radio Module for GSM 900/1800/1900 FCC-ID : PY7FF021011 IC ID : 4170B-FF021011 Additional information Frequency : 1850.2MHz – 1909.8MHz for PCS 1900 Type of modulation : GMSK Number of channels : 299 for PCS 1900 Antenna : Detachable external Stub Antenna with hinge, 360°, 50Ω (unique connector) Power supply : Powered by the Laptop PC battery via PCMCIA connector Output power : 27.6dBm (575.44mW) max. EIRP measured for PCS 1900 Extreme vol. Limits : 3.0VDC to 3.6VDC (nominal: 3.6VDC) Extreme temp. Tolerance : -30°C to +50°C 1.6 Test standards FCC Part 24 / RSS133 r1 CETECOM Inc. Test report no.: EMC_676FCC-24_2004 Issue date: 2004-06-29 Page 4 (55) 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course of the tests Performed Final Verdict: (only “passed” if all single measurements are “passed”) Passed Technical responsibility for area of testing: 2004-06-29 EMC & Radio Lothar Schmidt (Manager) Date Section Name Signature Responsible for test report and project leader: 2004-06-29 EMC & Radio Harpreet Sidhu (EMC Engineer) Date Section Name Signature CETECOM Inc. Test report no.: EMC_676FCC-24_2004 Issue date: 2004-06-29 Page 5 (55) 2.2 Test report TEST REPORT Test report no.: EMC_676FCC-24_2004 CETECOM Inc. Test report no.: EMC_676FCC-24_2004 Issue date: 2004-06-29 Page 6 (55) TEST REPORT REFERENCE PARAMETER TO BE MEASURED PARAGRAPH PAGE POWER OUTPUT § 24.232(b) 7 FREQUENCY STABILITY § 2.1055 / § 24.235 13 OCCUPIED BANDWIDTH §2.1049(h)(i) 15 EMISSION BANDWIDTH §24.238(b) 19 EMISSIONS LIMITS §24.238 23 BAND EDGE COMPLIANCE §24.238(b) 39 RECEIVER RADIATED EMISSIONS § 15.209 41 CONDUCTED SPURIOUS EMISSIONS 47 CONDUCTED EMISSIONS § 15.107/207 52 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS 53 BLOCK DIAGRAMS 54 CETECOM Inc. Test report no.: EMC_676FCC-24_2004 Issue date: 2004-06-29 Page 7 (55) POWER OUTPUT § 24.232(b) Summary: During the process of testing, the EUT was controlled via Rhode & Schwarz Digital Radio Communication tester (CMD-55) to ensure max. Power transmission and proper modulation. This paragraph contains Burst Average conducted output power and EIRP measurements for the EUT. In all cases, output power is within the specified limits. Method of Measurements: The EUT was set up for the max. Output power with pseudo random data modulation. The power was measured with R&S Spectrum Analyzer ESIB 40 (peak) These measurements were done at 3 frequencies, 1850.2 MHz, 1880.0 MHz and 1909.8 MHz (bottom, middle and top of operational frequency range) CETECOM Inc. Test report no.: EMC_676FCC-24_2004 Issue date: 2004-06-29 Page 8 (55) Conducted: Limits: Power Step Nominal Peak Output Power (dBm) Tolerance (dB) 0 ≤30dBm (1W)* ± 2 *GSM Specification – ETSI EN 300 910 V8.5.0 (2000-07) Section 4.1 {GSM05.05 Version 8.5.0 Release 1999} Power Measurements: Frequency (MHz) Burst Conducted Peak Power (dBm) 1850.2 28.57 1880.0 28.59 1909.8 28.72 CETECOM Inc. Test report no.: EMC_676FCC-24_2004 Issue date: 2004-06-29 Page 9 (55) Radiated: EIRP Measurements Description: This is the test for the maximum radiated power from the EUT. Rule Part 24.232(b) specifies, "Mobile/portable stations are limited to 2 watts e.i.r.p. Peak power" and 24.232(c) specifies that "Peak transmit power must be measured over any interval of continuous transmission using instrumentation calibrated in terms of an rms-equivalent voltage." Method of Measurement: 1. In an anechoic antenna test chamber, a half-wave dipole antenna for the frequency band of interest is placed at the reference centre of the chamber. An RF Signal source f…

Text truncated - open the document above for the full version.

Test setup Photos GC85 Test setup – Radiated Emissions Test setup Photos GC85 Test setup –Conducted Measurements Test setup Photos GC85 Test setup – AC Line Conducted Emissions
