PY7PM-0050GSM/GPRS/EDGE/UMTS/HSPA/LTE mobile phone with Bluetooth, Bluetooth LE, WLAN 802.11abgn, GPS/A-GPS, RFID and FM Rx

Start Guide Preface Thank you for purchasing "XPERIA VL SOL21" (simply called "the SOL21" or "this product" from here on). Before using your terminal, read "Start Guide" (this manual) and " (Full Instruction Manual)" (Japanese) to ensure safe use and handling. About manuals "Start Guide" (this manual) Basic operations of major functions of the SOL21 are described. For detailed descriptions on various functions, refer to the "Manual SOL21" application installed on the SOL21 or " (Full Instruction Manual)" (Japanese) available on the au homepage. http://www.au.kddi.com/torisetsu/index.html Company names, system name and product names generally referred to in this manual are trademarks or registered trademarks of respective companies. The TM,® marks may be omitted in this manual. "Manual SOL21" application The SOL21 provides you with preinstalled "Manual SOL21" application for detailed descriptions. You can activate some functions from the instructions. From the Home screen, []X[Manual SOL21] When you activate for the first time, follow the onscreen instructions to download and install application. For Those Requiring an English Instruction Manual You can download the English version of manuals from the au website (available from approximately one month after the product is released). Download URL: http://www.au.kddi.com/torisetsu/index. html Safety precautions Before you start using the SOL21, make sure to read the "Cautions on using SOL21" to ensure correct use. Before you assume that the product is malfunctioning, check for possible remedies in the following au Customer Support site of au homepage: http://www.kddi.com/customer/service/au/trouble/kosho/ index.html Electronic certificate and certification number for this product To refer to details (including certification numbers) on authorization and compliance mark particular to the this product, perform the following operation. To check authorization and compliance mark 1From the Home screen, tX[Settings]X[About phone]X[Legal information]X[Certificates] This product has acquired the certification of conformity with technical regulations for the specified radio station based on the Radio Law, and the "Technical Conformity Mark " is checked on the product as a certificate. Please refer to the Regulatory in the SOL21 for certification. If the screws of the product are removed and modifications are made to the internal components, the certification of conformity with technical regulations will become invalid. Never use the product without the valid certification. Doing so violates the Radio Law. When using the product Communication is not possible even inside the service area in places where the signal does not reach (e.g. tunnels and basements). Also, communication is sometimes not possible in poor reception areas. Communication is sometimes interrupted if you move into a poor reception areas during communications. A feature of digital communications used on the product is that consistent, high communications quality continues to be maintained even under the weak signal down to a limit. Accordingly, communication is sometimes interrupted if this limit is reached and exceeded during communications. Since this product uses radio waves, the possibility of communication intercepts by third parties cannot be eliminated. (Though CDMA/GSM system has highly secure confidential communication features.) This product is compatible with the international roaming service. Each network service described in this manual varies depending on the area and service content. For details, refer to the "Manual SOL21" application installed on the SOL21 or " (Full Instruction Manual)" (Japanese) available on the au homepage. Since this product is a radio station under the Radio Law, you may be asked to temporarily submit the product for inspection in accordance with the Radio Law. When the au IC-Card is inserted in your cell phone, the product number of the cell phone is automatically sent to KDDI CORPORATION for maintenance and monitoring operational status of your cell phone. Take care not to inconvenience people around you when you use the product in a public place. When the product is used by a child, parents or guardians should thoroughly read the "Start Guide" (this manual) and teach the child how to use it. Use of the product is not allowed in the following places! Do not use a cell phone while driving a car or riding a motorbike or bicycle. It may cause a traffic accident. Use of a cell phone while driving a car or motorbike is prohibited by law. Use of a cell phone while riding a bicycle may be punishable by some regulations. Do not use this product while you are aboard an airplane. Use of electric devices transmitting radio waves in airplane is prohibited by law. Some airline companies, however, allow their passengers to use cell phones. For details, contact the airline company you use. Notes for overseas usage If you do not make E-mail (@ezweb.ne.jp) initial settings in Japan, you cannot perform data communication overseas. Even if you do not use E-mail (@ezweb.ne.jp), make sure to set E-mail (@ezweb.ne.jp) before leaving Japan. For detail on E-mail (@ezweb.ne.jp) initial settings, refer to "Setting Guide" available on au homepage. Regarding notations used in this document In this manual, keys are represented by simplified illustrations such as x, y, t. Operations of tapping menu items/icons/buttons on the screen etc. are indicated as [(name of the item etc.)]. Screen illustrations shown in this manual may look different from the actual screens. In some cases, minor details or a part of a screen may be omitted. In this manual, "microSD™ memory card" and "microSDHC™ memory card" are abbreviated as "microSD memory card" or "microSD". "The Company" as appears on the product refers to the following companies: Sold by: KDDI CORPORATION, OKINAWA CELLULAR TELEPHONE COMPANY Manufactured by: Sony Mobile Communication Japan, Inc. Using au (au Disaster Countermeas…

Text truncated - open the document above for the full version.

SONY Sony Mobile Communications SE-221 88 LUND SWEDEN Confidential 1(1) Document number RevisIon CGQBDA12:3$6 A Prepared by Date SoMI CGQBDA Afrah Sadiq + 46 10 80 12250 2012-09-13 Contents responsible if other than pre parer Remarks Approved by SoMI CCQBClA Hilkan Sjoberg tel +46 10 80 13559 Receiver: Federal Communication Commission and Certification and Engineering Bureau Industry Canada Application: Type number: PM-0050-BV, FCC 10: PY7PM-0050, Canada IC: N/A Statement on WLAN hardware Sony mobile phone COMA SOL21 (FCC 10: PY7PM-0050) uses the exact same WLAN hardware and software as SO-01 E (FCC 10: PY7PM-0070). Based on this, FCC part 15.247 report (report no.1-4254_12-47-06 dated 2012-09-12, 1-4254_12-47-08-A dated 2012-09-12, 1-4254_12-47-13-A dated 2012-09-12 and 1-4254_12-47-10-A dated 2012-09-12) issued for SO-01E also applies for COMA SOL21. Best regards, Hakan Sjoberg Manager - HW Verification Global Type Approval Sony Mobile Communications (Sweden)AB Sony Mobile Communications Styrelsens sate. Lund Momsnr. VA T.NQ: SE55661566580 I Regrstef!"d offir;s; Lund OrganisatiOllsnr. Reg No: 556615-6858 Postadress • Ma:! Besoksadress • Offir;e address Teleion • Telephone ele/ax • Talofax SE-221 88 Lund Nya Vattentornet Nat 010-80 00000 Nat OlD·80 0204f.l Sweden Lund Inl +46 10 80 00000 lilt • .:1610 00 020 In

SONY Sony Mobile Communications SE-221 88 LUND· SWEDEN Confidentiality Request 2012-09-13 CGQBDA 12:379 SoM/CGQBDA Afrah Sadiq +46 10 80 12250 Receiver Federal Communications Commission Subject: Request for Confidentiality FCC ID: PY7PM-0050 To Whom It May Concern : In accordance with §0.459 of CFR 47, Sony Mobile Communications AB requests confidentiality for the below listed items for our Sony mobile phone type PM-0050-BV, FCC ID: PY7PM-0050: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational/Technical Descriptions These items contain detailed system and equipment description and related information about the product which Sony Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Mobile Communications AB also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. ~ Afrah Sadiq Starf Verificaiici1 Engineer Global Type Approval Sony Mobile Communications Nya Vattentornet 221 88 Lund. Sweden Fax: +46 10 80 02441 ~g'1Y!ll.QJill!t.(;Q.m Sony Mobile Communications Styrelsens SlIte: Lund Momsnr • II.A T.Na: SE556615665801 Regis/ered office: Lund Organlsationsnr· Reg No. 556615-6658 Postadress • Mall Besciksadress • Office aodress Teleton • TelephOne Telefax • Telefax SE-221 88 Lund Nya Vattentomet Nat 010-80 00000 Nat 01 0-80 02040 Sweden Lund tnt +46-10 80 00000 Int -+461 Deo 02040 SONY Sony Mobile Communications SE-221 88 LUND· SWEDEN Short Term Confidentiality Request 2012-09-13 CGQBOA 12:383 SoMCI CGQBOA Afrah Sadiq +46108012250 Receiver Federal Communications Commission Subject: Request for Temporary Confidentiality FCC 10: PY7PM-0050 To Whom It May Concern: In accordance with §0.459 of CFR 47 and Public Notice OA 04-1705, Sony Mobile Communications AS requests in addition to confidentiality request CGQBOA 12:379 temporary confidentiality for 180 days of the below listed items for our mobile phone type PM-0050-BV, FCC 10: PY7PM-0050: 1. User Manual 2 . Test set-up 3. External and Internal photos When the announcement of the product is done, the TCB will be notified to remove the Short Term Confidentiality. Please contact the undersigned if there are any further questions or additional information needed in this matter. ~ Afrah Sadiq Staff Verification Engineer Global Type Approval SOllY Mo b ile Co mmunicatio ns Nya Vattenlomel 221 88 Lund. Sweden Fax: +46 10 80 02441 SOlWl11ohiie,com Sony Mobile Communications Slyrelsen sate: Lund Momsnr· VA. T.No: SE556615665B01 Registered office: Lund Organisationsnr. Reg No: 556615-665B Postadress • Mall Besbksadress • Office address TBlefon • Telephone Telefax • Telefax SE·221 BB Lund Nya Vattentornet Nat 01 0-80 00000 Nat 010-80 02040 Sweden Lund In! +46 10 80 ooooa Inl +46 10 80 02040

Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 21 of 34 An nex B External ph ot ogra phs o f the E UT Photo documentation: Photo 1: Photo 2: Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 22 of 34 Photo 3: Photo 4: Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 23 of 34 Photo 5:

1(5) Document number Revision 1268-0947 2 Sony Mobile Communications AB Pre pared by Date CGOVDPLG, Anna Englund 2012-07-06 Contents responsible if other than preparer Remarks Approved by CGOVDPLG, Anna Englund CDMA SOL21 Mobile Phone label 1 General information Core Unit label part no 1262-0653 Bar code xPrint quality: according to COSMETIC GUIDELINE – Bar code labels document 1222-6072 Uen xQuiet zone: No bar codes are allowed to be closer to a label edge than 2 mm! Text If applicable, or nothing else specified, Zebra printer Scalable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. Coordinates “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. MLCI= Main Label Content Information Document 2 Printing information Content Format Line 1 (3,0/36,0) Model Name “CDMA SOL21” Text, height 1,2 mm. According to Chapter 1 in MLCI Line 2 (8,0/23,5) logo Graphics, height 6,5 mm, width 11,4 mm According to 1267-8979. Line 3a (9,0/3,0) Two card-slot aw in Japanese Graphics, height 8 mm. According to 1267-8982 Line 3b (9,0/36,0) ARIB STD-T71-logo Graphics height 6,0mm According to 1267-8998 Line 4a (12,0/3,0) Sentence in Japanese: “ ā Graphics, height 1,2 mm. According to 1248-3733 2(5) Document number Revision 1268-0947 2 Sony Mobile Communications AB Pre pared by Date CGOVDPLG, Anna Englund 2012-07-06 Contents responsible if other than preparer Remarks Approved by CGOVDPLG, Anna Englund Line 4b (12,0/10,0) Colour info of the included phone “SOL21XXX” Text, height 1,2 mm. “SOL21XXX” “XXX” = different for each phone unit color. “Pink”, use “MPA” “White”, use “MWA” “Black”, use “MKA” “Blue”, use “MLA” Line 5a (14,5/3,0) Type number of the phone, “TYPE: PM-0050-BV”. Text, height 1,2 mm. According to Chapter 1 in MLCI Line 5b (14,5/16,0) HW & SW identification field, if applicable; “EFF” Text, height 1,2 mm. According to Type-testing report under Product Model Specifying Documents Line 5c (14,5/210) “FCC ID: PY7PM-0050” Text, height 1,2 mm. According to Chapter 1 in MLCI Line 5d (14,5/35,0) Production date in Japanese (eg: year / month : 201X/XX Text, height 1,5 mm. Graphics, height 1,5 mm. According to 1234-3763 Line 6a (15,2/3,0) Product number of the Sales Item in which the phone is packed, if applicable. “SI XXXX-XXXX” Text, height 1,2 mm Line 6b (15,2/16,0) Production week (flash), “yyWww” (yy = year, ww = week) Text, height 1,2 mm. Line 7a (19,0/3,2) “Caution symbol” Graphics, height 2.5 mm. According to 1234-3774 Line 7b (19,0/6,0) “Caution” in Japanese Graphics, height 2.0 mm. According to 1234-3790 Line 8 (20,2/10,0) “Do not remove this label” statement in Japanese, on two rows. ” ⥶ⓨᯏౝ䯂∛㒮ౝ䬶䬾㔚Ḯ䭡ಾ䬲䬵䬞䬯䬤䬓 “ “ 䬢䬽䭾䯃䮲䭡೸䬛䬤䬹䬓䬶䬞䬯䬤䬓 “ Graphics, height 1,5 mm. According to 1250-5471 Line 9 (25,2/4,0) Line 9 in bar code, according to line 10 (ie IMEI number, only actual number, without data identifier). Bar code, height 4,0 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. 3(5) Document number Revision 1268-0947 2 Sony Mobile Communications AB Pre pared by Date CGOVDPLG, Anna Englund 2012-07-06 Contents responsible if other than preparer Remarks Approved by CGOVDPLG, Anna Englund Line 10 (15,2/38,5) Actual electronic serial number (IMEI) of the Mobile Phone, “IMEI: 00000000-000000-0” Text, height 1,2 mm. In the format TAC-SNR-CD. TAC and SNR derived from pos 500 in BOM. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 11 (29,0/4,0) Line 11 in bar code, according to line 12. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 12 (31,0/4,0) Supplier’s identification for trace-ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1.2 mm. Defined by supplier Line 13a (36,5/3,0) “CE approval symbol, The notified body number 0682 and Alert Symbol” Graphics, height 5 mm. According to 1242-7470 Line 13b (36,5/33,5) WEE trashcan without bar symbol Graphics, min. height 5mm, according to 1202-5537 Line 13c (36,5/39,0) “Li-ion 00 Symbol” Graphics, min. height 5mm, according to 1235-2267 Line 14 (40,2/36,0) Local Type Approval Number: T ADXX-XXXXXXX Text, height 1,2 mm Line 15 (41,0/35,7) Square around T, see Line 14 Width 1,5 x Height 2,0 mm Line 16 (42,0/4,0) Text within the frame; “2.4 FH1/XX8/DS4/OF4” Three bars under the text, each bar is 1 mm high and 3 mm long Bluetooth value with frame measurements; 13x 4,4 mm Text height 1,2 mm Line 17 (42,6/36,0) Local Type Approval Number: R XXX- XXXXXX Text, height 1,2 mm. Line 18 (42,4/36,0) Square around R, see Line 17 Width 1,5 x Height 2,0 mm 4(5) Document number Revision 1268-0947 2 Sony Mobile Communications AB Pre pared by Date CGOVDPLG, Anna Englund 2012-07-06 Contents responsible if other than preparer Remarks Approved by CGOVDPLG, Anna Englund Line 19 (44,0/28,0) “JATE” logo Graphics, height 5 mm. According to 1234-3837 Line 20 (47,0/2,0) Sentence in Japanese, 2 rows; Graphics height 3,5 acc to aw 1267-8983 Line 21 (51,5/2,0) 5,2 Ghz WLAN text, two rows Graphics height 3,5 acc to aw 1267-8977 Line 22 (52,0/35,0) Marking of origin. “Made in Xxx”; “Xxx” = actual country of production of the included telephone, in English Text, height 1,2 mm. Line 23 (60,2/11,7) Line 23 in bar code, according to line 24 (ie IMEI number, only actual number, without data identifier). Bar code, height 10,0 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. Line 25 (68,0/11,7) Actual electronic serial number (IMEI) of the Mobile Phone, “IMEI: 00000000-000000-0” Text, height 2,5 mm. In the format TAC-SNR-CD. TAC and SNR derived fro…

Text truncated - open the document above for the full version.

Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 24 of 34 An nex C Inter nal p ho to gra phs o f the E UT Photo documentation: Photo 1: Photo 2: Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 25 of 34 Photo 3: Photo 4: Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 26 of 34 Photo 5: Photo 6: Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 27 of 34 Photo 7: Photo 8: Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 28 of 34 Photo 9: Photo 10: Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 29 of 34 Photo 11: Photo 12: Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 30 of 34 Photo 13: Photo 14: Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 31 of 34 Photo 15: Photo 16: Test Report No.: 1-4254/12-46-03-B 2012-09-12 Page 32 of 34 Photo 17: Photo 18:

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: CDMA SOL21 To: OET Bulletin 65 Supplement C: (2001-01) FCC ID: PY7PM-0050 Test Report Serial No: RFI-SAR-RP87207JD02A V3.0 Version 3.0 Supersedes All Previous Versions This Test Report Is Issued Under The Authority Of Chris Guy, Head of Global Approvals: (APPROVED SIGNATORY) Checked By: Richelieu Quoi (APPROVED SIGNATORY) Issue Date: 12 September 2012 Test Dates: 23 July 2012 to 04 September 2012 This report is issued in portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by RFI Global Services Ltd. is under license. Other trademarks and trade names are those of their respective owners. Test Report Serial No: RFI-SAR-RP87207JD02A V3.0 Version 3.0 Issue Date: 12 September 2012 Page: 2 of 234 RFI Global Services Ltd. This page has been left intentionally blank. Test Report Serial No: RFI-SAR-RP87207JD02A V3.0 Version 3.0 Issue Date: 12 September 2012 Page: 3 of 234 RFI Global Services Ltd. TABLE OF CONTENTS 1. Customer Information ..................................................................................................... 4 2. Equipment Under Test (EUT).......................................................................................... 5 3. Test Specification, Methods and Procedures ............................................................. 15 4. Deviations from the Test Specification ....................................................................... 17 5. Operation and Configuration of the EUT during Testing ........................................... 18 6. Summary of Test Results ............................................................................................. 21 7. Measurements, Examinations and Derived Results ................................................... 25 8. Measurement Uncertainty ............................................................................................ 53 Appendix 1. Test Equipment Used .................................................................................. 60 Appendix 2. Measurement Methods ................................................................................ 64 Appendix 3. SAR Distribution Scans ............................................................................... 66 Appendix 4. Photographs ............................................................................................... 187 Appendix 5. System Check ............................................................................................ 221 Appendix 6. Simulated Tissues...................................................................................... 231 Appendix 7. DASY4 System Details ............................................................................... 232 Test Report Serial No: RFI-SAR-RP87207JD02A V3.0 Version 3.0 Issue Date: 12 September 2012 Page: 4 of 234 RFI Global Services Ltd. 1. Customer Information Company Name: Sony Mobile Communications AB Address: Nya Vattentornet 22188 Lund Sweden Test Report Serial No: RFI-SAR-RP87207JD02A V3.0 Version 3.0 Issue Date: 12 September 2012 Page: 5 of 234 RFI Global Services Ltd. 2. Equipment Under Test (EUT) 2.1. Identification of Equipment Under Test (EUT) Description: Mobile Handset Brand Name: Sony Model Name or Number: CDMA SOL21 Serial Number: CB5A1K9RSP IMEI Number: 00440245-036251-6 Hardware Version Number: AP1 Software Version Number: 9.0.B.0.59 Hardware Revision of GSM Module: None Specified Software Revision of GSM Module: None Specified FCC ID Number: PY7PM-0050 Country of Manufacture: China Date of Receipt: 18th July 2012 Note(s): This sample was used to perform WWAN SAR testing on bands PCS1900, UMTS FDD 2 only. The sample supports simultaneous transmission with the WWAN and WLAN antenna > 5 cm apart. Wireless Personal Hotspot is also supported and was evaluated as per KDB 941225 D06 "Hot Spot SAR v01" Description: Mobile Handset Brand Name: Sony Model Name or Number: CDMA SOL21 Serial Number: CB5A1K9RQ5 IMEI Number: 00440245-036265-6 Hardware Version Number: AP1 Software Version Number: 9.0.B.0.59 Hardware Revision of GSM Module: None Specified Software Revision of GSM Module: None Specified FCC ID Number: PY7PM-0050 Country of Manufacture: China Date of Receipt: 18th July 2012 Note(s): This sample was used to perform WWAN SAR testing on bands GSM850, UMTS FDD 5 only. The sample supports simultaneous transmission with the WWAN and WLAN antenna > 5 cm apart. Wireless Personal Hotspot is also supported and was evaluated as per KDB 941225 D06 "Hot Spot SAR v01" Test Report Serial No: RFI-SAR-RP87207JD02A V3.0 Version 3.0 Issue Date: 12 September 2012 Page: 6 of 234 RFI Global Services Ltd. Identification of Equipment Under Test (EUT) (Continued): Description: Mobile Handset Brand Name: Sony Model Name or Number: CDMA SOL21 Serial Number: CB5A1K9RTZ IMEI Number: 00440245-036255-7 Hardware Version Number: AP1 Software Version Number: s_atp_tsubasa_1_0_8_0_e Hardware Revision of GSM Module: None Specified Software Revision of GSM Module: None Specified FCC ID Number: PY7PM-0050 Country of Manufacture: China Date of Receipt: 18th July 2012 Note(s): This sample was used to perform WLAN SAR testing only. The sample supports simultaneous transmission with the WWAN and WLAN antenna > 5 cm apart. Wireless Personal Hotspot is also supported and was evaluated as per KDB 941225 D06 "Hot Spot SAR v01" Description: Mobile Handset Brand Name: Sony Model Name or Number: CDMA SOL21 Serial Number: CB5A1KA6AS IMEI Number: 00440245-037256-4 Hardware …

Text truncated - open the document above for the full version.

2012-09-12 Page 1 of 98 TEST REPORT Test report no.: 1-4254/12-47-10-A Testing laboratory Applicant CETECOM ICT Services GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-01 Area of Testing: Radio/Satellite Communications Sony Mobile Communications AB Nya Vattentornet 22188 Lund / SWEDEN Phone: +46 46 19 30 00 Fax: +46 46 19 32 95 Contact: Håkan Sjöberg e-mail: [email protected] Phone: +46 46 19 35 59 Manufacturer Sony Mobile Communications AB Nya Vattentornet 22188 Lund / SWEDEN Test standard/s 47 CFR Part 15 Title 47 of the Code of Federal Regulations; Chapter I Part 15 - Radio frequency devices For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: GSM Mobile Phone GPRS/EGPRS 850/900/1800/1900; UMTS HSPA FDDI/V/VI/XIX; LTE FDD 1/19/21; WLAN a/b/g/n; BT 3.1; RFID; FM Rx; A-GPS Model name: PM-0070-BV FCC ID: PY7PM-0070 IC: -/- Frequency: ISM band 5725 MHz to 5850 MHz (lowest channel 149 – 5745 MHz, highest channel 165 – 5825 MHz Technology tested: WLAN (OFDM a, n HT20 & n HT40) Antenna: Integrated antenna Power Supply: 3.7 V DC by Li - polymer battery Temperature Range: -20°C to +55 °C Test report authorised: Test performed: 2012-09-12 Stefan Bös 2012-09-12 Marco Bertolino Senior Testing Manager Testing Manager Test report no.: 1-4254/12-47-10-A 2012-09-12 Page 2 of 98 1 Table of contents 1 Table of contents ............................................................................................................................................ 2 2 General information ....................................................................................................................................... 3 2.1 Notes and disclaimer .......................................................................................................................... 3 2.2 Application details ............................................................................................................................... 3 3 Test standard/s ............................................................................................................................................... 3 3.1 Measurement guidance ....................................................................................................................... 3 4 Test environment ............................................................................................................................................ 4 5 Test item .......................................................................................................................................................... 4 6 Test laboratories sub-contracted ................................................................................................................. 4 7 Summary of measurement results ............................................................................................................... 5 8 RF measurements .......................................................................................................................................... 6 8.1 Description of test setup .................................................................................................................... 6 8.1.1 Radiated measurements............................................................................................................. 6 8.1.2 Conducted measurements.......................................................................................................... 7 8.2 Additional comments .......................................................................................................................... 7 9 Measurement results ...................................................................................................................................... 8 9.1 Output power verification (conducted) ............................................................................................. 8 9.2 Antenna gain ........................................................................................................................................ 9 9.3 Maximum output power .................................................................................................................... 12 9.4 Power spectral density ..................................................................................................................... 18 9.5 Spectrum bandwidth – 6 dB / 75 % power bandwidth (EBW) ....................................................... 24 9.6 Spectrum bandwidth – 20 dB / 99 % power bandwidth ................................................................. 29 9.7 Band edge compliance conducted .................................................................................................. 34 9.8 Band edge compliance radiated ...................................................................................................... 34 9.9 TX spurious emissions conducted .................................................................................................. 35 9.10 TX spurious emissions radiated .................................................................................................. 54 9.11 RX spurious emissions radiated .................................................................................................. 71 9.12 TX spurious emissions radiated < 30 MHz .................................................................................. 75 9.13 TX spurious emissions conducted < 30 MHz ...............…

Text truncated - open the document above for the full version.

Test report no.: 1-4254/12-47-06-A 2012-09-12 Page 79 of 95 Annex A Photographs of the test setup Photo documentation: Photo 1: Photo 2: Test report no.: 1-4254/12-47-06-A 2012-09-12 Page 80 of 95 Photo 3: Photo 4: Test report no.: 1-4254/12-47-06-A 2012-09-12 Page 81 of 95 Photo 5: Photo 6: Test report no.: 1-4254/12-47-06-A 2012-09-12 Page 82 of 95 Photo 7: Photo 8:

Test report no.: 1-4254/12-47-10-A 2012-09-12 Page 82 of 98 Annex A Photographs of the test setup Photo do…
