PY7PM-0100Mobile phone with Bluetooth, W-LAN 802.11bgn, GPS/A-GPS and FM Rx

Sony Corporation

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jul 18, 2012
Application Purpose: Original Equipment
Date of Application: Jul 01, 2012
Equipment Note: Mobile phone with Bluetooth, W-LAN 802.11bgn, GPS/A-GPS and FM Rx
Frequency Range: 2412.00000000 - 2462.00000000
Company: Sony Corporation
Country: Japan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Startup guide Xperia ™ go Sony Mobile Communications AB SE-221 88 Lund, Sweden www.sonymobile.com ST27i/ST27a 1262-3861.1 To insert a memory card 1 Remove the back cover from the phone. 2 To remove the memory card slot cover, insert a fingernail into the gap between the memory card slot cover and the headset connector, then pull out the cover. 3 Insert the memory card into the memory card slot with the gold-coloured contacts facing up. 4 Using the edge of a SIM card or other similarly sized card, push the memory card further into the slot until you hear a locking sound. 5 Push the memory card slot cover back into position so that it is fully latched. To attach the back cover Water resistance Your phone has an IP (Ingress Protection) rating of 67. This means that your phone is dust tight and is protected against the effects of immersion in water in depths of between 0 to 100 cm. The covers for the micro USB port and the headset connector must be firmly closed in order for the phone to be water resistant. More information about IP codes and important details about your phone’s resistance to water can be found in your phone User guide, and on the Sony Mobile support website. Phone basics Phone overview 15243 6 7 8 9 10 1112 14 13 17 16 15 19 18 1. Power key 2. Ear speaker 3. Proximity sensor 1 4. Proximity sensor 2 5. Light sensor 6. Notification LED 7. Port for charger/USB cable 8. Volume/Zoom key 9. Menu key 10. Main microphone 11. Home key 12. Back key 13. Touchscreen 14. Headset connector 15. Camera LED light 16. Camera lens 17. Speaker 18. Strap hole 19. Second microphone Use the accessories provided with your phone, or other compatible accessories, for optimal performance. Turning on the phone To turn on the phone It may take a while for the phone to start up. Waking up the screen To activate the screen • Briefly press the power key . To unlock the screen • Drag to the right across the screen. Using the keys Back • Go back to the previous screen • Close the on-screen keypad, a dialog box, an options menu, or the Notification panel Home • Go to the Home screen • Press and hold to open a window showing your most recently used applications Menu • Open a list of options available in the current screen or application Set up your phone What is Android™? Android is your phone's operating system. Since it's developed by Google™, your phone is preloaded with several Google™ services, such as Google Maps™ and Google™ web search. To use some of the services provided by Google™, you need a Google account. What is different about Android? Android™ is an open system, which means that you're not limited to using applications and services from only one provider. Google™ account With a Google™ account, you can use Gmail™ to send emails, Google Talk™ to chat with friends, and Google Play™ to download applications and games, music, movies and books. To set up a Google™ account in your phone 1 From your Home screen, tap . 2 Find and tap Settings > Accounts & sync > Add account > Google. 3 Follow the registration wizard to create a Google™ account, or sign in if you already have an account. Your phone is now ready to use with Gmail™ , Google Talk™ and Google Calendar™. You can also sign in or create a Google™ account from the setup guide the first time you start your phone. Or you can go online and create an account at www.google.com/accounts. Basic settings The first time you start your phone, a setup guide explains basic phone functions and helps you enter essential settings. You can also access the setup guide later. To access the setup guide manually 1 From the Home screen, tap . 2 Find and tap Setup guide. Transferring contacts to your new phone Transferring contacts to your new phone can sometimes be complicated, but help is available. You can transfer contacts from several phone brands, including iPhone, Samsung, HTC and Nokia. You need: • An Internet-connected PC running Windows® • A USB cable for your old phone • A USB cable for your new Android™ phone • Your old phone • Your new Android™ phone If you don't have access to all of the items listed above, go to www.sonymobile.com to find out about other ways to transfer your contacts. Get started transferring your contacts Use the PC Companion program to transfer your contacts. It's free, and the installation files are already saved on your new phone. PC Companion also offers a range of other features, including help to update your phone software. To install PC Companion 1 New phone: Turn on your new Android™ phone and connect it to a PC using a USB cable. 2 New phone: Tap Install to install PC Companion on the PC. 3 Computer: If a popup window appears, select Run Startme.exe. In the new popup window that appears, click Install to start the installation and then follow the instructions to complete the installation. To transfer contacts to your new phone using PC Companion 1 Make sure that PC Companion is installed on your PC. 2 Open the PC Companion program on the PC, then click Contacts Setup and follow the instructions to transfer your contacts. Welcome Important information Please read the Important information leaflet before you use your mobile phone. Assembly To remove the back cover • Insert a thumbnail into the strap hole opening on the back cover, then use your thumb to firmly lift up the cover. To insert the SIM card Do not insert an incompatible SIM card in the SIM card slot. Doing so could permanently damage your SIM card or your phone. 1 2 May 19, 2012 11:12:18 ST27i__Booklet_EN_1262-3861.1.pdf 1 of 2 Finding your way Home screen Your phone Home screen is the equivalent of the desktop on a computer. You can customise your Home screen with widgets, shortcuts, folders, themes, wallpaper and other items. The Home screen extends beyond the regular screen display width, so you need to flick left or right to view content in one of the screen's four extensions. The items in the bar at the bottom of the screen are always available for quick acce…

Text truncated - open the document above for the full version.

Attestation Statements

SONY Sony MobIle CommunIcations SE-221 88 LUND· SWEDEN Confidential 1(1) CGQBDA12:212 A Da!c SEMCI CGQBDA Afrah Sadiq + 46 10 80 12250 2012-06-16 CC:1!c.... !s responSloie if ether :'~a1 p~c:;a~e!'" Approved by SEMCI CGQBOAHakan Sjoberg tel +46 108013559 ._ ._._--_._ ._.__._._.._ ._ ._---------- Receiver: Federal Communication Commission and Certification and Engineering Bureau Industry Canada Application: Type number: PM-0100-BV, FCC ID: PY7PM-0100, Canada IC: 4170B-PM0100 Statement on WLAN hardware Sony mobile phone ST27a (FCC 10: PY7PM-0100, IC: 4170B-PM01 00) uses the exact same WLAN hardware and software as ST27i (FCC 10: PY7PM-0090). Based on this, FCC part 15.247 and RSS - 210 Issue 7 report (report no. 2012WLN0347 _WLAN_ V3 dated 2012-05-21) issued for ST27i also applies for ST27a. Best regards, Hakan Sjoberg Acting Manager - HW Verification Global Type Approval Sony Mobile Communications (Sweden)AB Sony Mobile Communications Slyreisens sate; Lund M01l1sm' V.A T.No . SE55661S665801 Registered office: Lund OrganlsaUonsnr' Reg No: 556EJ1S-6658 Postadres$ • Mall Basoksadress • Office address Telelon • Telephone Telefax • Telefax SE-221 88 Lund Nya Vattentomet Nat 01 0-80 00000 Nat OlD-80 02040 Sweden Lund Inl +4$ 1 0 ao 00000 In! +46 10 80 02040

Cover Letter(s)

SONY Sony Mobile Communicatiolls SE-221 88 LUND· SWEDEN Confidentiality Request 2012-06-16 CGQBDA12:207 SEMC/CGQBDA Afrah Sadiq +46 10 80 12250 Receiver Federal Communications Commission Subject: Request for Confidentiality FCC 10: PY7PM-0100 To Whom It May Concern: In accordance with §0.459 of CFR 47, Sony Mobile Communications AB requests confidentiality for the below listed items for our Sony mobile phone type PM-0100-BV, FCC 10: PY7PM-0100: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational/Technical Descriptions These items contain detailed system and equipment description and related information about the product which Sony Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Mobile Communications AB also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Best Regards, ~ Afrah Sad iq Staff Verification Engineer Global Type Approval Sony Mobile '::ommunications Nya Vattento rnet 2 21 88 Lund, Sweden Fax: +46 10 80 02441 sonyericsson.com Sony Mobile Communications Styrelsens sate: Lund Momsnr· VAT.No: SE556615665801 Registered office. Lund Organisationsnr • Reg No: 556615-6658 Posladress • Mall BesOksadress • Office address Telefon • Telephone Teletax • Telefax SE-221 88 Lund Sweden Nya Valtentorne\ Lund Nat Int 010-80 00000 +46 10 80 00000 Nat Int 010-80 02040 1-4610 aD 02040

External Photos

No.2012WLN0347 Page69 of 73 ©Copyright. All rights reserved by TMC Beijing. ANNEX C: PHOTOGRAPHS OF THE EUT EUT Photo EUT Photo No.2012WLN0347 Page73 of 73 ©Copyright. All rights reserved by TMC Beijing. Travel Charger Label of Travel Charger *** END OF REPORT BODY ***

ID Label/Location Info

Company Internal MARKING DRAWING 1 (2) Prepared (also subject responsible if other) No. Flora Kang (28848956) 1262-4375 Approved Checked Date Rev Reference Flora Kang (28848956) 2012-03-29 1 2 Label Content Specification ST27a, Mobile Phone Label, Made in 1 General information Mobile Phone label part no • 1255-6377 Bar code • Standard: according to Ericsson corporate standard 102 01–109 Uen • Print quality: C, according to ANSI X3.182-1990 as stated in Ericsson corporate standard 102 01– 1003 Uen • Quiet zone: No bar codes are allowed to be closer to a label edge than 2 mm! Text If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. Coordinates “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. 2 Printing information Content Format Line 1a (2,7/1,5) SONY stylized name. Graphics, height 1,9 mm, width 10,4mm. According to 1263-9535. Line 1b (2,7/18,0) Model name, “ST27a” Text, height 1,2 mm. Line 2a (4,5/1,5) Type number of the phone, “TYPE: PM-0100-BV”. Text, height 1,2 mm. Line 2b (4,5/18,0) HW & SW identification field, if applicable; “FFGG” Text, height 1,2 mm. According to Type-testing report under Product Model Specifying Document Line 3a (6,5/1,5) “FCC ID: PY7PM-0100” Text, height 1,2 mm. Line 3b (6,5/18,0) Location code of where the phone is flashed, if applicable, “XXX” Text, height 1,2 mm. Line 4a (8,5/1,5) “IC: 4170B-PM0100” Text, height 1,2 mm. Line 4b (8,5/18,0) Production week (flash), “yy’W’ww” (yy = year, ww = week) Text, height 1,2 mm. Line 5a (10,5/1,5) Product number without revision of the Sales Item in which the phone is packed, if applicable. “SI XXXX-XXXX” Text, height 1,2 mm. Line 5b (10,5/18,0) Repair week, if applicable. “Ry’W’ww” (y = year, ww = week) Text, height 1,2 mm. Line 6 (13,5/2,0) Line 7a in bar code. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 7a (15,5/1,5) Supplier’s identification for trace-ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,2 mm. Defined by supplier. Company Internal MARKING DRAWING 2 (2) Prepared (also subject responsible if other) No. Flora Kang (28848956) 1262-4375 Approved Checked Date Rev Reference Flora Kang (28848956) 2012-03-29 1 2 Line 7b (15,5/15,0) Actual electronic serial number (IMEI) of the mobile phone, “00000000-000000-0” Text, height 1,2 mm. In the format TAC-SNR-CD. TAC and SNR derived from pos 500 in BOM. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 8 (18,0/2,0) Line 7b in bar code (only actual number, without data identifier). Bar code, height 2,0 mm. Code 128 symbology, code C subset. If uneven number of digits, code B subset shall be used for the last digit. Line 9a (23,5/1,5) CE approval symbol Graphics, height 5 mm. According to 1210-0131. Line 9b (23,5/9,0) The notified body number “0682” Text, height 5,0 mm. Line 9c (23,5/20,0) “Alert Symbol” Graphics, height 5,0 mm According to 1001-5859 Line 10a (31,5/2,0) Marking of origin; “Made in Xxx” “Xxx” = actual country of production of the included telephone, in English Text, height 1,2 mm. Line 10b (31,5/20,5) WEE trashcan without bar symbol Graphics, height 5,0 mm, According to 1202-5537. 3 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 3.1 Conceptual picture double underlined = major changes since last revision.

Internal Photos

No.2012WLN0347 Page70 of 73 ©Copyright. All rights reserved by TMC Beijing. Mobile phone Disassembly Mobile phone Disassembly No.2012WLN0347 Page71 of 73 ©Copyright. All rights reserved by TMC Beijing. Mobile phone Disassembly Mobile Phone Disassembly No.2012WLN0347 Page72 of 73 ©Copyright. All rights reserved by TMC Beijing. Mobile Phone Disassembly Mobile Phone Disassembly

RF Exposure Info

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: ST27a FCC ID: PY7PM-0100 IC ID: 4170B-PM-0100 To: OET Bulletin 65 Supplement C: (2001-01) and RSS-102 Issue 4 March 2010) Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Supersedes All Previous Versions This Test Report Is Issued Under The Authority Of Chris Guy, Head of Global Approvals: (APPROVED SIGNATORY) Checked By: Richelieu Quoi (APPROVED SIGNATORY) Issue Date: 29 June 2012 Test Dates: 26 May 2012 to 02 June 2012 This report is issued in portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by RFI Global Services Ltd. is under license. Other trademarks and trade names are those of their respective owners. Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 2 of 207 RFI Global Services Ltd. Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 3 of 207 RFI Global Services Ltd. This page has been left intentionally blank. Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 4 of 207 RFI Global Services Ltd. TABLE OF CONTENTS 1. Customer Information ..................................................................................................... 5 2. Equipment Under Test (EUT).......................................................................................... 6 3. Test Specification, Methods and Procedures ............................................................. 13 4. Deviations from the Test Specification ....................................................................... 15 5. Operation and Configuration of the EUT during Testing ........................................... 16 6. Summary of Test Results ............................................................................................. 18 7. Measurements, Examinations and Derived Results ................................................... 21 8. Measurement Uncertainty ............................................................................................ 47 Appendix 1. Test Equipment Used .................................................................................. 54 Appendix 2. Measurement Methods ................................................................................ 58 Appendix 3. SAR Distribution Scans ............................................................................... 60 Appendix 4. Photographs ............................................................................................... 164 Appendix 5. System Check ............................................................................................ 197 Appendix 6. Simulated Tissues...................................................................................... 204 Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 5 of 207 RFI Global Services Ltd. 1. Customer Information Company Name: Sony Mobile Communications AB Address: Nya Vattentornet 22188 Lund Sweden Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 6 of 207 RFI Global Services Ltd. 2. Equipment Under Test (EUT) 2.1. Identification of Equipment Under Test (EUT) Description: Mobile Handset Brand Name: Sony Model Name or Number: ST27a Serial Number: CB5A1JZ8WU Type Number: PM-0100-BV IMEI Number: 00440214-542402-8 Hardware Version Number: AP1 Software Version Number: 6.0.B.3.20 Hardware Revision of GSM Module: None Specified Software Revision of GSM Module: None Specified FCC ID Number: PY7PM-0100 IC Number: 4170B-PM-0100 Country of Manufacture: China Date of Receipt: 25 May 2012 Note(s): This sample was used to perform WWAN GSM850 and UMTS FDD V SAR evaluation measurements only. The sample supports simultaneous transmission with the WWAN and WLAN antenna < 5 cm apart. Wireless Personal Hotspot is also supported and was evaluated as per KDB 941225 D06 "Hot Spot SAR v01" Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 7 of 207 RFI Global Services Ltd. Identification of Equipment Under Test (EUT) (Continued) Description: Mobile Handset Brand Name: Sony Model Name or Number: ST27a Serial Number: CB5A1JZ8YP Type Number: PM-0100-BV IMEI Number: 00440214-501805-0 Hardware Version Number: AP1 Software Version Number: 6.0.B.3.20 Hardware Revision of GSM Module: None Specified Software Revision of GSM Module: None Specified FCC ID Number: PY7PM-0100 IC Number: 4170B-PM-0100 Country of Manufacture: China Date of Receipt: 25 May 2012 Note(s): This sample was used to perform WWAN PCS1900 and UMTS FDD II SAR evaluation measurements only. The sample supports simultaneous transmission with the WWAN and WLAN antenna < 5 cm apart. Wireless Personal Hotspot is also supported and was evaluated as per KDB 941225 D06 "Hot Spot SAR v01" In order to perform conducted power measurement this sample back cover was removed and replaced with a modified back cover to allow for this. The detail below is for the modified back cover: Serial Number (Conducted Cover): CB5A1K50Z1 IMEI Number (Conducted Cover): 00440214-542699-9 Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 8 of 207 RFI Global Services Ltd. Ide ntification of Equipment Under Test (EUT) (Continued) Description: Mobile Handset Brand Name: Sony Model Name or Number: ST27a Serial Number: CB5A1JZ8SS Type Number: PM-0100-BV IMEI Number: 00440214-501709-5 Hardware Version Number: AP1 Software Version Number: …

Text truncated - open the document above for the full version.

RF Exposure Info

Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 60 of 207 RFI Global Services Ltd. Appendix 3. SAR Distribution Scans This appendix contains SAR distribution scans which are not included in the total number of pages for this report. Scan Reference Number Title SCN/87693JD02/001 Touch Left GSM CH190 SCN/87693JD02/002 Touch Left GSM CH128 SCN/87693JD02/003 Touch Left GSM CH251 SCN/87693JD02/004 Tilt Left GSM CH190 SCN/87693JD02/005 Touch Right GSM CH190 SCN/87693JD02/006 Touch Right GSM CH128 SCN/87693JD02/007 Touch Right GSM CH251 SCN/87693JD02/008 Tilt Right GSM CH190 SCN/87693JD02/009 Front of EUT Facing Phantom GPRS CH190 SCN/87693JD02/010 Back of EUT Facing Phantom GPRS CH190 SCN/87693JD02/011 Left Hand Side of EUT Facing Phantom GPRS CH190 SCN/87693JD02/012 Right Hand Side of EUT Facing Phantom GPRS CH190 SCN/87693JD02/013 Bottom of EUT Facing Phantom GPRS CH190 SCN/87693JD02/014 Back of EUT Facing Phantom GPRS CH128 SCN/87693JD02/015 Back of EUT Facing Phantom GPRS CH251 SCN/87693JD02/016 Back of EUT Facing Phantom at 15mm GPRS CH190 SCN/87693JD02/017 Back of EUT Facing Phantom at 15mm GPRS CH128 SCN/87693JD02/018 Back of EUT Facing Phantom at 15mm GPRS CH251 SCN/87693JD02/019 Back of EUT Facing Phantom GSM CH190 SCN/87693JD02/020 Back of EUT Facing Phantom GSM CH128 SCN/87693JD02/021 Back of EUT Facing Phantom GSM CH251 SCN/87693JD02/022 Back of EUT Facing Phantom with PHF GSM CH190 SCN/87693JD02/023 Touch Left PCS CH661 SCN/87693JD02/024 Tilt Left PCS CH661 SCN/87693JD02/025 Touch Right PCS CH661 SCN/87693JD02/026 Tilt Right PCS CH661 SCN/87693JD02/027 Touch Left PCS CH512 SCN/87693JD02/028 Touch Left PCS CH810 SCN/87693JD02/029 Front of EUT Facing Phantom GPRS CH661 SCN/87693JD02/030 Back of EUT Facing Phantom GPRS CH661 SCN/87693JD02/031 Left Hand Side of EUT Facing Phantom GPRS CH661 SCN/87693JD02/032 Right Hand Side of EUT Facing Phantom GPRS CH661 SCN/87693JD02/033 Bottom of EUT Facing Phantom GPRS CH661 Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 61 of 207 RFI Global Services Ltd. SAR Distribution Scans (Continued) Scan Reference Number Title SCN/87693JD02/034 Back of EUT Facing Phantom GPRS CH512 SCN/87693JD02/035 Back of EUT Facing Phantom GPRS CH810 SCN/87693JD02/036 Back of EUT Facing Phantom at 15mm GPRS CH661 SCN/87693JD02/037 Back of EUT Facing Phantom at 15mm GPRS CH512 SCN/87693JD02/038 Back of EUT Facing Phantom at 15mm GPRS CH810 SCN/87693JD02/039 Back of EUT Facing Phantom PCS CH661 SCN/87693JD02/040 Back of EUT Facing Phantom with PHF PCS CH661 SCN/87693JD02/041 Touch Left UMTS FDD II CH9400 SCN/87693JD02/042 Touch Left UMTS FDD II CH9262 SCN/87693JD02/043 Touch Left UMTS FDD II CH9538 SCN/87693JD02/044 Tilt Left UMTS FDD II CH9400 SCN/87693JD02/045 Touch Right UMTS FDD II CH9400 SCN/87693JD02/046 Tilt Right UMTS FDD II CH9400 SCN/87693JD02/047 Front of EUT Facing Phantom UMTS FDD II CH9400 SCN/87693JD02/048 Back of EUT Facing Phantom UMTS FDD II CH9400 SCN/87693JD02/049 Left Hand Side of EUT Facing Phantom UMTS FDD II CH9400 SCN/87693JD02/050 Right Hand Side of EUT Facing Phantom UMTS FDD II CH9400 SCN/87693JD02/051 Bottom of EUT Facing Phantom UMTS FDD II CH9400 SCN/87693JD02/052 Back of EUT Facing Phantom UMTS FDD II CH9262 SCN/87693JD02/053 Back of EUT Facing Phantom UMTS FDD II CH9538 SCN/87693JD02/054 Back of EUT Facing Phantom at 15mm UMTS FDD II CH9400 SCN/87693JD02/055 Back of EUT Facing Phantom at 15mm UMTS FDD II CH9262 SCN/87693JD02/056 Back of EUT Facing Phantom at 15mm UMTS FDD II CH9538 SCN/87693JD02/057 Back of EUT Facing Phantom at 15mm with PHF UMTS FDD II CH9400 SCN/87693JD02/058 Touch Left UMTS FDD V CH4183 SCN/87693JD02/059 Touch Left UMTS FDD V CH4132 SCN/87693JD02/060 Touch Left UMTS FDD V CH4233 SCN/87693JD02/061 Tilt Left UMTS FDD V CH4183 SCN/87693JD02/062 Touch Right UMTS FDD V CH4183 SCN/87693JD02/063 Touch Right UMTS FDD V CH4132 SCN/87693JD02/064 Touch Right UMTS FDD V CH4233 SCN/87693JD02/065 Tilt Right UMTS FDD V CH4183 SCN/87693JD02/066 Front of EUT Facing Phantom UMTS FDD V CH4183 SCN/87693JD02/067 Back of EUT Facing Phantom UMTS FDD V CH4183 SCN/87693JD02/068 Left Hand Side of EUT Facing Phantom UMTS FDD V CH4183 SCN/87693JD02/069 Right Hand Side of EUT Facing Phantom UMTS FDD V CH4183 SCN/87693JD02/070 Bottom of EUT Facing Phantom UMTS FDD V CH4183 Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 62 of 207 RFI Global Services Ltd. SAR Distribution Scans (Continued) Scan Reference Number Title SCN/87693JD02/071 Back of EUT Facing Phantom UMTS FDD V CH4132 SCN/87693JD02/072 Back of EUT Facing Phantom UMTS FDD V CH4233 SCN/87693JD02/073 Back of EUT Facing Phantom at 15mm UMTS FDD V CH4183 SCN/87693JD02/074 Back of EUT Facing Phantom at 15mm UMTS FDD V CH4132 SCN/87693JD02/075 Back of EUT Facing Phantom at 15mm UMTS FDD V CH4233 SCN/87693JD02/076 Back of EUT Facing Phantom at 15mm with PHF UMTS FDD V CH4233 SCN/87693JD02/077 Touch Left WLAN 802.11b 1Mbps CH6 SCN/87693JD02/078 Tilt Left WLAN 802.11b 1Mbps CH6 SCN/87693JD02/079 Touch Right WLAN 802.11b 1Mbps CH6 SCN/87693JD02/080 Tilt Right WLAN 802.11b 1Mbps CH6 SCN/87693JD02/081 Touch Right WLAN 802.11b 1Mbps CH1 SCN/87693JD02/082 Touch Right WLAN 802.11b 1Mbps CH11 SCN/87693JD02/083 Front of EUT Facing Phantom WLAN 802.11b 1Mbps CH6 SCN/87693JD02/084 Back of EUT Facing Phantom WLAN 802.11b 1Mbps CH6 SCN/87693JD02/085 Left Hand Side of EUT Facing Phantom WLAN 802.11b 1Mbps CH6 SCN/87693JD02/086 Back of EUT Facing Phantom WLAN 802.11b 1Mbps CH1 SCN/87693JD02/087 Back of EUT Facing Phantom WLAN 802.11b 1Mbps CH11 SCN/87693JD02/088 Back of EUT Facing Phantom with PHF WLAN 802.11b 1Mbps CH11 SCN/87693JD02/089 System Performance Check 900MHz Head 26 05 12 SCN/87693JD02/090 System Performance Check 900MHz Head 28 05 12 SCN/87693JD02/091 System Performance Check 900MHz Body 28 05 12 SCN/87693JD02/092 System Performance Check 900MHz Body 29 05 12 SCN/87693…

Text truncated - open the document above for the full version.

RF Exposure Info

Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 164 of 207 RFI Global Services Ltd. Appendix 4. Photographs This appendix contains the following photographs: Photo Reference Number Title PHT/87693JD01/001 Test configuration for the measurement of Specific Absorption Rate (SAR) PHT/87693JD01/002 Touch Left PHT/87693JD01/003 Tilt Left PHT/87693JD01/004 Touch Right PHT/87693JD01/005 Tilt Right PHT/87693JD01/006 Front of EUT Facing Phantom at 10mm separation PHT/87693JD01/007 Front of EUT Facing Phantom at 15mm separation PHT/87693JD01/008 Back of EUT Facing Phantom at 10mm separation PHT/87693JD01/009 Back of EUT Facing Phantom at 15mm separation PHT/87693JD01/010 Left Hand Side of EUT Facing Phantom PHT/87693JD01/011 Right Hand Side of EUT Facing Phantom PHT/87693JD01/012 Top of EUT Facing Phantom PHT/87693JD01/013 Bottom of EUT Facing Phantom PHT/87693JD01/014 General Set up of EUT with PHF PHT/87693JD01/015 Front View of EUT PHT/87693JD01/016 Back View of EUT PHT/87693JD01/017 Left Hand Side View of EUT PHT/87693JD01/018 Right Hand Side View of EUT PHT/87693JD01/019 Top View of EUT PHT/87693JD01/020 Bottom View of EUT PHT/87693JD01/021 Internal View of WWAN Head Sample PHT/87693JD01/022 Internal View of WWAN Body Sample PHT/87693JD01/023 Internal View of WWAN Back Cover PHT/87693JD01/024 Internal View of WLAN Head Sample PHT/87693JD01/025 Internal View of WLAN Body Sample PHT/87693JD01/026 Internal View of WLAN Back Cover PHT/87693JD01/027 900 MHz Head Fluid Level PHT/87693JD01/028 900 MHz Body Fluid Level PHT/87693JD01/029 1900 MHz Head Fluid Level PHT/87693JD01/030 1900 MHz Body Fluid Level PHT/87693JD01/031 2450 MHz Head Fluid Level PHT/87693JD01/032 2450 MHz Body Fluid Level Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 165 of 207 RFI Global Services Ltd. PHT/87693JD01/001: Test configuration for the measurement of Specific Absorption Rate (SAR) Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 166 of 207 RFI Global Services Ltd. PHT/87693JD01/002: Touch Left Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 167 of 207 RFI Global Services Ltd. PHT/87693JD01/003: Tilt Left Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 168 of 207 RFI Global Services Ltd. PHT/87693JD01/004: Touch Right Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 169 of 207 RFI Global Services Ltd. PHT/87693JD01/005: Tilt Right Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 170 of 207 RFI Global Services Ltd. PHT/87693JD01/006: Front of EUT Facing Phantom at 10mm separation Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 171 of 207 RFI Global Services Ltd. PHT/87693JD01/007: Front of EUT Facing Phantom at 15mm separation Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 172 of 207 RFI Global Services Ltd. PHT/87693JD01/008: Back of EUT Facing Phantom at 10mm separation Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 173 of 207 RFI Global Services Ltd. PHT/87693JD01/009: Back of EUT Facing Phantom at 15mm separation Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 174 of 207 RFI Global Services Ltd. PHT/87693JD01/010: Left Hand Side of EUT Facing Phantom Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 175 of 207 RFI Global Services Ltd. PHT/87693JD01/011: Right Hand Side of EUT Facing Phantom Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 176 of 207 RFI Global Services Ltd. PHT/87693JD01/012: Top of EUT Facing Phantom Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 177 of 207 RFI Global Services Ltd. PHT/87693JD01/013: Bottom of EUT Facing Phantom Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 178 of 207 RFI Global Services Ltd. PHT/87693JD01/014: General Set up of EUT with PHF Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version 3.0 Issue Date: 29 June 2012 Page: 179 of 207 RFI Global Services Ltd. PHT/87693JD01/015: Front View of EUT Test Report Serial No: RFI-SAR-RP87693JD02A V3.0 Version …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Mika Kaneko(Chief Regulatory Compliance Manager)

[email protected]+81367103225Fax: +815038096297

Technical Contact

Sony Mobile Communications ABH�kan Sj�berg

[email protected]

Nya Vattentornet · Lund · Sweden

Test Firm

TMC-Telecommunication Metrology Center of M.I.I.TChongwen Song

[email protected]0086-10-62303288Fax: 0086-10-62304793

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	101.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is conducted. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. SAR compliance for body-worn operating configurations is limited to the specific configurations tested for this filing. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5 cm separation between the device, including its antenna, and the users body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, wireless router and simultaneous transmission use conditions are 0.22W/kg, 0.30 W/kg, 0.30 W/kg, and 1.43W/kg, respectively.
