SONY Sony Mobile Communications SE-221 88 LUND· SWEDEN Confidentiality Request 2012-07-12 CGQBDA12:300 SoMC/CGQBDA Afrah Sadiq +46 108012250 Receiver Federal Communications Commission Subject: Request for Confidentiality FCC 10: PV7PM·0200 To Whom It May Concern: In accordance with §0.459 of CFR 47, Sony Mobile Communications AS requests confidentiality for the below listed items for our Sony mobile phone type PM-0200-BV, FCC ID: PY7PM-0200: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. OperationallTechnical Descriptions These items contain detailed system and equipment description and related information about the product which Sony Mobile Communications AS considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Mobile Communications AS also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Best Regards, -=dt? Afrah Sadiq Staff Verification Engineer Global Type Approval Sony Mobile Communications Nya Vattentomet 221 88 Lund. Sweden Fox. r46 10 800244 1 ~QlJi.L~ Sony Mobile Communications Styrelsens sate: Lund Momsnr. VA. T.No: SE556615665801 Registered office: Lund Orgamsauonsnr • Reg No: 556615-6658 Postadress • Mail 8esoksadress • Office address Telefon • Telephone Telefax' Telefax SE-221 88 Lund Nya Vattentornet Nat 010-8000000 Nat 010-80 02U4O Sweden Lund Int 046 1080 00000 Int +46 108002040

No.2012TAR322 Page 85 of 95 ©Copyright. All rights reserved by TMC Beijing. ANNEX C: EUT photograph Mobile Phone Mobile Phone No.2012TAR322 Page 86 of 95 ©Copyright. All rights reserved by TMC Beijing. Mobile Phone Mobile Phone No.2012TAR322 Page 87 of 95 ©Copyright. All rights reserved by TMC Beijing. Mobile Phone Mobile Phone No.2012TAR322 Page 88 of 95 ©Copyright. All rights reserved by TMC Beijing. Label of Mobile Phone Mobile Phone Disassembly

1(2) Document number Revision 1266-4718 3 Sony Mobile Communications AB Prepared by Date CGOVDPLG, Anna Englund 2012-06-27 Contents responsible if other than preparer Remarks Approved by CGOVDPLG, Anna Englund LT28h Aoba Rita, MoP-label RoW 1 General information Mobile Phone label part no • 1264-3886 Mobile Phone label content part no • Bar code 1266-4715 • Print quality: according to COSMETIC GUIDELINE – Bar code labels document 1222-6072 Uen • Quiet zone: No bar codes are allowed to be closer to a label edge than 2 mm! Text If applicable, or nothing else specified, Zebra printer Scaleable Smooth Font CG Triumvirate Bold Condensed is imposed. When needed, the text is adjusted to fit the label. Coordinates “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. MLCI= Main Label Content Information Document 2 Printing information Content Format Line 1a (2,0/20,0) SONY stylized name. Graphics, height 2,3mm, width13 mm. According to 1263-9535 Line 1b (2,0/26,0)) Model Name “LT28h” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 2 (4,0/20,0) Product number with revision of the Sales Item in which the phone is packed, if applicable. “SI XXXX-XXXX” Text, height 1,2 mm. Line 3a (6,7/2, 8) Actual electronic serial number (IMEI) of the mobile phone, “00000000-000000-0” Text, height 1,2mm. In the format TAC-SNR-CD. TAC and SNR derived from pos 500 in BOM. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 3b (6,7/20,0) Line 3a in barcode (IMEI-number) Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Line 4a (9,0/3,5) “TYPE: PM-0200-BV” Text, height 1,2 mm. According to Chapter 1 in MLCI. 2(2) Document number Revision 1266-4718 3 Sony Mobile Communications AB Prepared by Date CGOVDPLG, Anna Englund 2012-06-27 Contents responsible if other than preparer Remarks Approved by CGOVDPLG, Anna Englund Line 4b (9,0/20,1) HW & SW identification field, if applicable; “EFF” Text, height 1,2 mm. According to Type-testing report under Product Model Specifying Documents Line 4c (9,0/26,5) ”FCC ID: PY7PM-0200” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 4c (9,0/44,5) “IC: 4170B-PM0200” Text, height 1,2 mm. According to Chapter 1 in MLCI. Line 5a (13,0/40,0) Supplier’s identification for trace-ability of the telephone, as desired by supplier (e.g. “S/N: nnn....” for serial number). Text, height 1,2 mm. Defined by supplier. Line 5b (13,0/53,0) Location code of where the phone is flashed, if applicable, “XXX” Text, height 1,2 mm. Line 6 (15,2/40,0) Production week (flash), “00W01” (00 = year, 01 = week) Text, height 1,2 mm. Line 7a (16,2/4,0) CE approval symbol, the NB-“0682” and “Alert Symbol” in one artwork Graphics, height 5 mm. According to 1242-7470 Line 7b (16,2/33,5) WEEE trashcan without bar symbol Graphics, min. height 5mm, according to 1202- 5537. Line 8a (19,0/20,0) Marking of origin; “Made in Xxx” “Xxx” = actual country of production of the included telephone, in English Text, height 1,2 mm. 3 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 3.1 Conceptual picture double underlined = major changes since last revision.

No.2012TAR322 Page 89 of 95 ©Copyright. All rights reserved by TMC Beijing. Mobile Phone Disassembly Mobile Phone Disassembly No.2012TAR322 Page 90 of 95 ©Copyright. All rights reserved by TMC Beijing. Mobile Phone Disassembly Mobile Phone Disassembly No.2012TAR322 Page 91 of 95 ©Copyright. All rights reserved by TMC Beijing. Mobile Phone Disassembly Mobile Phone Disassembly No.2012TAR322 Page 92 of 95 ©Copyright. All rights reserved by TMC Beijing. Mobile Phone Disassembly Mobile Phone Disassembly No.2012TAR322 Page 93 of 95 ©Copyright. All rights reserved by TMC Beijing. Mobile Phone Disassembly Inbuilt Li-Polymer Battery

No.2012TAR348 Page 1 of 26 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2012TAR348 for Sony Mobile Communications AB GSM 850/900/1800/1900 quad bands and UMTS FDD 1/2/4/5/8 mobile phone Type: PM-0200-BV FCC ID: PY7PM-0200 IC No.: 4170B-PM0200 with Hardware Version: A Software Version: 6.1.E.0.35 Issued Date: Jul. 05 th , 2012 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0) 10-62304633-2678, Fax:+86(0)10-62304633-2504 Email:[email protected]. www.emcite.com No.2012TAR348 Page 2 of 26 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY..............................................................................................................3 1.1. TESTING LOCATION ..........................................................................................................3 1.2. TESTING ENVIRONMENT ..................................................................................................3 1.3. PROJECT DATA..................................................................................................................3 1.4. SIGNATURE ........................................................................................................................3 2. CLIENT INFORMATION..........................................................................................................4 2.1. APPLICANT INFORMATION...............................................................................................4 2.2. MANUFACTURER INFORMATION.....................................................................................4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................5 3.1. ABOUT EUT ........................................................................................................................5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ...................................5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST......................................5 3.4. GENERAL DESCRIPTION ..................................................................................................6 4. REFERENCE DOCUMENTS ..................................................................................................7 4.1. REFERENCE DOCUMENTS FOR TESTING......................................................................7 5. LABORATORY ENVIRONMENT ............................................................................................8 6. SUMMARY OF TEST RESULTS.............................................................................................9 6.1. SUMMARY OF TEST RESULTS .........................................................................................9 6.2. STATEMENTS .....................................................................................................................9 7. TEST EQUIPMENTS UTILIZED............................................................................................10 ANNEX A: EUT PHOTOGRAPH..................................................................................................11 ANNEX B: MEASUREMENT RESULTS ......................................................................................21 ANNEX C: TEST LAYOUT ...........................................................................................................26 No.2012TAR348 Page 4 of 26 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: Sony Mobile Communications (China) Co. Ltd Address /Post: Sony Mobile R&D Center, No. 16, Guangshun South Street, Chaoyang District City: Beijing Postal Code: 100102 Country: China Contact Person: Ma, Gang Telephone: +86-10-58656312 Fax: +86-10-58659049 2.2. Manufacturer Information Company Name: Sony Mobile Communications AB Address /Post: Nya Vattentornet, 22188 Lund, Sweden City: Lund Postal Code: 22188 Country: Sweden Contact Person: Nordlof, Anders Telephone: +46-10-802 3919 Fax: +46-10-800 2441 No.2012TAR348 Page 5 of 26 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description GSM 850/900/1800/1900, GPRS, EDGE, WCDMA FDD Band 1/2/4/5/8, BT EDR2.0, WLAN ( 802.11 b/g/n), FM, GPS receiver mobile phone Type PM-0200-BV FCC ID PY7PM-0200 IC No 4170B-PM0200 Frequency range GSM 850: 824.2 MHz - 848.8 MHz PCS 1900: 1850.2 MHz -1909.8 MHz WCDMA FDD Band 2:1850 MHz -1910 MHz WCDMA FDD Band 4:1710 MHz -1755 MHz WCDMA FDD Band 5:824 MHz - 849 MHz Antenna Internal Power supply Battery or charger (travel adapter / vehicle adapter ) Output power 32.67 dBm maximum ERP measured for GSM850 32.90 dBm maximum EIRP measured for PCS1900 28.66 dBm maximum EIRP measured for WCDMA FDD Band 2 28.49 dBm maximum EIRP measured for WCDMA FDD Band 4 26.83 dBm maximum ERP measured for WCDMA FDD Band 5 Extreme vol. Limits 3.5VDC to 4.1VDC (nominal: 3.7VDC) Extreme temp. Tolerance -30°C to +50°C Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN IMEI HW Version SW Version N01 CB5A1K245R 004402145746859 A 6.1.E.0.35 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN Revision AE2 USB Cable 120812AD128862E 1 AE2 Commercial name EC480 Manufacturer Sony Mobile Length o…
