PY7PM-0260850/900/1800/1900 GPRS / EDGE / UMTS FDD1&2&5 / HSPA mobile phone with Bluetooth, WLAN 802.11bgn, GPS/A-GPS and HAC support

Startup guide Xperia ™ E C1505/C1504 Sony Mobile Communications AB SE-221 88 Lund, Sweden www.sonymobile.com 1263-5886.1 Welcome Important information Please read the Important information leaflet before you use your mobile phone. Assembly To remove the battery cover To insert a memory card To insert the SIM card Do not insert an incompatible SIM card in the SIM card slot. Doing so could permanently damage your SIM card or your phone. To insert the battery To attach the battery cover To remove the bottom cover To attach the bottom cover 1 2 Phone basics Phone overview 2 11 78910 4 5 6 13 12 17 15 14 16 13 1. Proximity sensor 2. Ear speaker 3. Notification light 4. Volume/Zoom key 5. Power key 6. Camera key 7. Menu key 8. Microphone 9. Home key 10. Back key 11. Touchscreen 12. Camera lens 13. Second microphone 14. Headset jack (CTIA standard) 15. Port for charger/USB cable 16. Strap hole 17. Speaker Use the accessories provided with your phone, or other compatible accessories, for optimal performance. Turning on the phone To turn on the phone 1 Press and hold down the power key on the right side of the phone until the phone vibrates. 2 Wait a while for the phone to start. Waking up the screen To activate the screen • Briefly press the power key . To unlock the screen • Drag to the right across the screen. Using the keys Back • Go back to the previous screen • Close the on-screen keypad, a dialog box, an options menu, or the Notification panel Home • Go to the Home screen • Press and hold to open a window showing your most recently used applications Menu • Open a list of options available in the current screen or application Set up your phone What is Android™? Android is your phone's operating system. Since it's developed by Google™, your phone is preloaded with several Google™ services, such as Google Maps™ and Google™ web search. To use some of the services provided by Google™, you need a Google account. What is different about Android? Android™ is an open system, which means that you're not limited to using applications and services from only one provider. Google™ account With a Google™ account, you can use Gmail™ to send emails, Google Talk™ to chat with friends, and Google Play™ to download applications and games, music, movies and books. To set up a Google™ account in your phone 1 From your Home screen, tap . 2 Find and tap Settings > Accounts & sync > Add account > Google. 3 Follow the registration wizard to create a Google™ account, or sign in if you already have an account. Your phone is now ready to use with Gmail™ , Google Talk™ and Google Calendar™. You can also sign in or create a Google™ account from the setup guide the first time you start your phone. Or you can go online and create an account at www.google.com/accounts. Basic settings The first time you start your phone, a setup guide explains basic phone functions and helps you enter essential settings. You can also access the setup guide later. To access the setup guide manually 1 From the Home screen, tap . 2 Find and tap Setup guide. Transferring contacts to your new phone Transferring contacts to your new phone can sometimes be complicated, but help is available. You can transfer contacts from several phone brands, including iPhone, Samsung, HTC and Nokia. You need: • An Internet-connected PC running Windows® • A USB cable for your old phone • A USB cable for your new Android™ phone • Your old phone • Your new Android™ phone If you don't have access to all of the items listed above, go to www.sonymobile.com to find out about other ways to transfer your contacts. Get started transferring your contacts Use the PC Companion program to transfer your contacts. It's free, and the installation files are already saved on your new phone. PC Companion also offers a range of other features, including help to update your phone software. To install PC Companion 1 New phone: Turn on your new Android™ phone and connect it to a PC using a USB cable. 2 New phone: Tap Install to install PC Companion on the PC. 3 Computer: If a popup window appears, select Run Startme.exe. In the new popup window that appears, click Install to start the installation and then follow the instructions to complete the installation. To transfer contacts to your new phone using PC Companion 1 Make sure that PC Companion is installed on your PC. 2 Open the PC Companion program on the PC, then click Contacts Setup and follow the instructions to transfer your contacts. Finding your way Home screen Your phone Home screen is the equivalent of the desktop on a computer. You can customise your Home screen with widgets, shortcuts, folders, themes, wallpaper and other items. The Home screen extends beyond the regular screen display width, so you need to flick left or right to view content in one of the screen's four extensions. The items in the bar at the bottom of the screen are always available for quick access. To go to the Home screen • Press . To browse the Home screen • Flick right or left. To change your Home screen wallpaper 1 From your Home screen, press . 2 Tap Wallpaper, then select a wallpaper. Widgets Widgets are small applications that you can use directly on your Home screen. For example, the Music player widget allows you to start playing music directly. Some widgets are resizable, so you can expand them to view more content or shrink them to save space on your Home screen. Application screen The Application screen, which you open from your Home screen, contains the applications that come installed with your phone as well as the applications you download. The Application screen extends beyond the regular screen width, so you need to flick left and right to view all content. To open the Application screen • From your Home screen, tap . To open an application • From your Home screen or the Application screen, tap the application. Applications An application is a phone program that helps you perform a task. For example, there are applications to make calls…

Text truncated - open the document above for the full version.

SAR Information FCC Statement Declaration of Conformity Sony C1504 UMTS HSPA Band 1 2 5 GSM GPRS/EDGE 850/900/1800/1900 Important Information U nited States & Canada THIS PHONE MODEL HAS BEEN CERTIFIED IN COMPLIANCE WITH THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. The Series mobile phones have been designed to comply with applicable safety requirements for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed to not exceed the limits* of exposure to radio frequency (RF) energy set by governmental authorities. These limits establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by international scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a safety margin designed to assure the safety of all individuals, regardless of age and health. The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate (SAR). Tests for SAR are conducted using standardized methods with the phone transmitting at its highest certified power level in all used frequency bands. While there may be differences between the SAR levels of various phone models, they are all designed to meet the relevant guidelines for exposure to radio waves. For more information on SAR, please refer to the safe and efficient use chapter in the User Guide. The highest SAR value as reported to the authorities for this phone model when tested for use by the ear is 1.15 W/kg*, and when worn on the body is 0.79 W/kg* for speech and 1.37 W/kg* for data calls. For body-worn operation, the phone has been tested when positioned a minimum of 15 mm from the body without any metal parts in the vicinity of the phone or when properly used with an appropriate Sony accessory and worn on the body. For devices which include “WiFi hotspot” functionality, SAR measurements for the device operating in WiFi hotspot mode were taken using a separation distance of 2 10mm. Use of third-party accessories may result in different SAR levels than those reported. **Before a phone model is available for sale to the public in the US, it must be tested and certified by the Federal Communications Commission (FCC) that it does not exceed the limit established by the government-adopted requirement for safe exposure*. The tests are performed in positions and locations (i.e., by the ear and worn on the body) as required by the FCC for each model. The FCC has granted an Equipment Authorization for this phone model with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR levels of various phones, all mobile phones granted an FCC equipment authorization meet the government requirement for safe exposure. SAR information on this phone model is on file at the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID PY7PM-0260. Additional information on SAR can be found on the Cellular Telecommunications & Internet Association (CTIA) website at http://www.phonefacts.net. * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard incorporates a margin of safety to give additional protection for the public and to account for any variations in measurements. **This paragraph is only applicable to authorities and customers in the United States. 3 Renseignements importants É tats-Unis et Canada CE MODÈLE DE TÉLÉPHONE A ÉTÉ CERTIFIÉ CONFORME AUX EXIGENCES GOUVERNEMENTALES RELATIVES À L'EXPOSITION AUX ONDES RADIOÉLECTRIQUES. Les téléphones mobiles de la ont été conçus pour répondre aux normes de sécurité en vigueur en matière d'exposition aux ondes radioélectriques. Votre téléphone sans fil est un émetteur et un récepteur radio. Il est conçu de manière à ne pas dépasser les limites* d'exposition à l'énergie des fréquences radio (RF) établies par les autorités gouvernementales. Ces limites fixent les niveaux maximaux d'énergie RF auxquels peut être soumis le grand public. Ces lignes directrices sont basées sur des normes qui ont été élaborées par des organisations scientifiques internationales par le biais d'évaluations périodiques et approfondies des études scientifiques. Ces normes prévoient une marge de sécurité visant à assurer la protection de tous les individus, peu importe leur âge et leur état de santé. Les lignes directrices relatives à l'exposition aux ondes radioélectriques utilisent une unité de mesure appelée « Taux d'absorption spécifique » (TAS). Les tests de TAS sont effectués selon des méthodes standardisées dans lesquelles le téléphone émet dans toutes les bandes de fréquences utilisées, à la plus forte puissance pour laquelle il a été homologué. Bien que le TAS puisse être différent d'un modèle de téléphone à un autre, tous les appareils sont conçus pour respecter les lignes directrices relatives aux ondes radioélectriques. Pour en savoir plus sur le TAS, reportez-vous au chapitre sur l'utilisation efficace et sans danger du guide de l'utilisateur. Le TAS le plus élevé relevé par les autorités pour ce modèle de téléphone est de 1.15 W/kg* lorsqu'il est testé en utilisation près de l'oreille, et de 0.79 W/kg* pour les appels vocaux et de 1.37 W/kg* pour les transmissions de données lorsqu'il est porté sur le corps. En mode d’utilisation porté sur le corps, le téléphone a été testé lorsqu’il est à au moins 15 mm du corps et à l’écart de toute pièce en métal, ou lorsqu’il est utilisé de façon 4 adéquate avec un accessoire Sony et porté sur le corps. Pour les appareils munis de la fonctionnalité « point d'accès WiFi », les mesures du TAS de l'appareil en mode WiFi ont été prises à une distance de sécurité de 10 mm. L'utilisation d'accessoires tiers peut produire des niveaux de TAS différents de ceux relevés. **Avant …

Text truncated - open the document above for the full version.

American English Hearing Aid Compatibility Your phone is designed for Hearing Aid Compatibility (HAC) and can be used with hearing aids. This feature has not been tested in combination with WLAN. Hearing Aid Settings You can choose the setting in the phone to match the setting in your hearing aid before making or receiving calls. To select a phone setting for HAC 1 From the Home screen, tap . 2 Find and tap Settings > Call settings. 3 Mark the Hearing aids checkbox to turn on hearing aid compatibility. Hearing Aid Compatibility Information This phone has been tested and rated for use with hearing aids for some of the wireless technologies it uses. However, there may be some newer wireless technologies used in this phone that have not been tested yet for use with hearing aids. It is important to try the different features of this phone thoroughly and in different locations, using your hearing aid or cochlear implant, to determine if you hear any interfering noise. Consult your service provider or the manufacturer of this phone for information on hearing aid compatibility. If you have questions about return or exchange policies, consult your service provider or phone retailer. Hearing Aid Compatibility Rating This model handset was designed to comply with the requirements set forth in Section 20.19 of the Federal Communication Commission's (FCC) rules governing hearing aid compatibility (HAC), for the reduction of RF interference and magnetic coupling (T-coil) to hearing aids. The Microphone (M) rating and T-coil (T) rating is defined and labeled on the handset box. Devices meeting HAC compliance must have a minimum M3 and/or T3 rating or above as defined by the FCC in accordance with the latest ANSI Standard C63.19. The (M) rating refers to lower RF emission levels of the handset. The (T) rating refers to the magnetic coupling between the handset and the T-coil compatible hearing aid. Some hearing aids are also provided an (M) rating, and are more immune than others to interference. To determine the (M) rating of your hearing aid, please contact your hearing health professional. More information about digital wireless devices and hearing aid compatibility can be found at www.sonyericsson-snc.com. May 30, 2012 13:36:44 HAC-leaflet--Generic-ae,xl,fr_1239-4751.4.pdf 1 of 2 Important information Información importante www.sonymobile.com Sony Mobile Communications AB SE-221 88 Lund, Sweden 1239-4751.4 Español Latinoamericano Compatibilidad de aparatos auditivos Su teléfono está diseñado para la compatibilidad de aparatos auditivos (HAC, por su sigla en inglés) y se puede usar con aparatos auditivos. Esta función no se ha probado en combinación con WLAN. Ajustes de los aparatos auditivos Puede elegir que el ajuste del teléfono coincida con el ajuste de su aparato auditivo antes de realizar o recibir llamadas. Seleccionar una configuración de teléfono para HAC 1 Desde Home screen, toque suavemente . 2 Busque y toque suavemente Configuración > Config. de llamada. 3 Marque la casilla de verificación Hearing aids para activar la compatibilidad de aparatos auditivos. INFORMACIÓN SOBRE COMPATIBILIDAD CON EQUIPOS DE ASISTENCIA AUDITIVA Este teléfono ha sido probado y clasificado para su uso con equipos de asistencia auditiva para ciertas tecnologías de servicio móvil que usa. Sin embargo, pueden existir ciertas tecnologías nuevas de servicio móvil usadas en este teléfono que no han sido probadas aún para su uso con equipos de asistencia auditiva. Es importante probar minuciosamente y en diferentes sitios las distintas funciones de este teléfono, usando su equipo Français Compatibilité avec les appareils auditifs Votre téléphone est conçu pour la compatibilité avec les appareils auditifs (HAC) et peut être utilisé avec des appareils auditifs. Cette fonction n'a pas été testée avec les réseaux WLAN. Paramètres de l'appareil auditif Sur votre téléphone, vous pouvez choisir le même paramètre que celui de l'appareil auditif avant de passer ou de recevoir des appels. Pour sélectionner un paramètre de téléphone pour la HAC 1 Dans l'Home screen, tapez sur . 2 Tapez sur Paramètres > Paramètres d'appel. 3 Cochez la case Hearing aids pour activer la compatibilité avec les appareils auditifs. Informations relatives à la compatibilité avec les appareils auditifs Ce téléphone a été testé et classé pour offrir une compatibilité entre certaines des technologies sans fil qu'il utilise et les appareils auditifs. Cependant, il peut faire appel à des technologies sans fil plus récentes qui n'ont pas encore été testées avec les appareils auditifs. Il est donc important que vous essayiez les diverses fonctions de ce téléphone, de manière exhaustive et dans différents endroits, avec votre appareil auditif ou votre implant cochléaire pour déterminer si vous entendez des parasites. Pour plus d'informations sur la compatibilité de asistencia auditiva o implante coclear, para determinar si usted escucha algún ruido de interferencia. Consulte con su proveedor de servicio o el fabricante de este teléfono para información sobre compatibilidad con equipos de asistencia auditiva. Si tiene preguntas sobre las políticas de devolución o cambios, consulte con su proveedor de servicio o centro de venta de teléfonos. Clasificación de compatibilidad de los aparatos auditivos Este modelo de teléfono fue diseñado para cumplir los requisitos establecidos en la Sección 20.19 de las normas de la Federal Communication Commission (FCC) que rigen la compatibilidad de los aparatos auditivos (HAC, por sus siglas en inglés), para la reducción de la interferencia RF y el acoplamiento magnético (T-coil) con los aparatos auditivos. La clasificación de Micrófono (M) y la clasificación de T-coil (T) está definida y marcada en la caja del teléfono. Los dispositivos que cumplen los requisitos de HAC deben tener una clasificación mínima de M3 y/o T3 o superior definida por la FCC de acuerdo con la última norma ANSI C63.19. La clasificación (M) se refiere a l…

Text truncated - open the document above for the full version.

Sony Mobile Communications Prepared by SOMC/CGQBADS Håkan Sjöberg Contents responsible if other than preparer Approved by SOMC/CGQBADS Håkan Sjöberg Variation Attestation Sony Mobile Communications AB, herby declares the C1504, FCC ID: PY7PM variant of the C1604, FCC ID: PY7PM • The difference between the single SIM slot and C1604 have insert. • PCB/trace layouts, product form factor and antenna between the two versions remains identical • No changes have been made MHz, WCDMA The device contains functions that are not operational in U.S Territor frequency bands operational in the U.S Territories are GSM 850MHz, PCS 1900MHz. This application relates to these b Yours sincerely Håkan Sjöberg Manager - HW Verification Global Type Approval Sony Mobile Communications AB Company Internal Document number CGQBDA12:466 Date 2012-12-07 Remarks Receiver Whom it may concern Variation Attestation Sony Mobile Communications AB, herby declares the C1504, FCC ID: PY7PM variant of the C1604, FCC ID: PY7PM-0261. The difference between the C1604 and C1504 is only in SIM slot design. single SIM slot and C1604 has Dual SIM slot. C1504 doesn’t insert switch key and have insert. PCB/trace layouts, product form factor and antenna between the two versions remains No changes have been made to affect the GSM 850 MHz, WCDMA 1900 MHz, Bluetooth, WLAN or HAC The device contains functions that are not operational in U.S Territor frequency bands operational in the U.S Territories are GSM 850MHz, PCS 1900MHz. This application relates to these bands and additionally Bluetooth, Yours sincerely Håkan Sjöberg HW Verification Approval Sony Mobile Communications AB 1(1) Revision B Sony Mobile Communications AB, herby declares the C1504, FCC ID: PY7PM-0260, as a is only in SIM slot design. C1504 has doesn’t insert switch key and C1604 PCB/trace layouts, product form factor and antenna between the two versions remains GSM 1900 MHz, WCDMA 850 The device contains functions that are not operational in U.S Territories. The only cellular frequency bands operational in the U.S Territories are GSM 850MHz, PCS 1900MHz. This , WLAN and HAC.

Sony Mobile Communications Prepared by SEM/CGQB Håkan Sjöberg Contents responsible if other than preparer Approved by SEM/CGQB Håkan Sjöberg Telecommunication Certification Body UL Pavilion A Ashwood Park Ashwood Way Basingstoke Hampshire RG23 8BG England To whom it may concern Sony Mobile Communications AB measurements, as listed on Page Sporton International Inc), is as expected and Yours sincerely Håkan Sjöberg Manager - Global Type Approval Sony Mobile Communications Tel: +46 10 801 35 59 Mobilvägen 10, SE-221 88 Lund, Sweden [email protected] Confidential LETTER Document number CGQBDA12:470 Date 2012-12-17 Remarks Telecommunication Certification Body FCC ID: PY7PM-0261 Sony Mobile Communications AB, herby declares that the HSDPA Conducted Average Power on Page 34 of exhibit SAR test report (report no FA290405 issued by is as expected and that the transmitter was functioning correctly. 221 88 Lund, Sweden [email protected] 1(1) Revision B PA Conducted Average Power SAR test report (report no FA290405 issued by the transmitter was functioning correctly.

Sony Mobile Communications Prepared by SEM/CGQB Håkan Sjöberg Contents responsible if other than preparer Approved by SEM/CGQB Håkan Sjöberg Telecommunication Certification Body UL Pavilion A Ashwood Park Ashwood Way Basingstoke Hampshire RG23 8BG England To whom it may concern This is to certify that Sony Mobile Communications AB Telecommunication Certification Body on our behalf phone C1504, FCC ID: PY7PM We certify that we are not subject to a denial of Federal pursuant to Section 5301 of the Anti conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for th Yours sincerely Håkan Sjöberg Manager - Global Type Approval Sony Mobile Communications Tel: +46 10 801 35 59 Mobilvägen 10, SE-221 88 Lund, Sweden [email protected] Confidential LETTER Document number CGQBDA12:478 Date 2012-12-04 Remarks Telecommunication Certification Body To whom it may concern This is to certify that Sony Mobile Communications AB authorizes UL Telecommunication Certification Body on our behalf for the FCC application of PY7PM-0260 We certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes.. Global Type Approval Sony Mobile Communications 221 88 Lund, Sweden [email protected] 1(1) Revision A UL to act as for the FCC application of our mobile benefits, that include FCC benefits, Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for

Sony Mobile Communications Prepared by SEM/CGQB Håkan Sjöberg Contents responsible if other than preparer Approved by SEM/CGQB Håkan Sjöberg Telecommunication Certification Body UL Pavilion A Ashwood Park Ashwood Way Basingstoke Hampshire RG23 8BG England Subject: Certification Application FCC ID: PY7PM-026 It is requested that the following information is to be held confidential on behalf of Sony Mobile Communications AB pursuant to FCC Rules Parts 0.457 and 0.459: • Block Diagrams • Schematics • Parts List • Tune Up Information • Operation Description These items contain detailed about the product which Sony Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is Mobile Communications AB also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Yours sincerely Håkan Sjöberg Global Type Approval Sony Mobile Communications Tel: +46 10 801 35 59 Mobilvägen 10, SE-221 88 Lund, Sweden [email protected] Confidential LETTER Document number CGQBDA12:480 Date 2012-12-04 Remarks Telecommunication Certification Body Subject: Certification Application 0260 that the following information is to be held confidential on behalf of Sony Mobile Communications AB pursuant to FCC Rules Parts 0.457 and 0.459: Block Diagrams Tune Up Information Operation Description These items contain detailed system and equipment description and related information about the product which Sony Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Mobile Communications AB also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. Sony Mobile Communications 221 88 Lund, Sweden [email protected] 1(1) Revision A that the following information is to be held confidential on behalf of Sony Mobile Communications AB pursuant to FCC Rules Parts 0.457 and 0.459: system and equipment description and related information about the product which Sony Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general a basis from which future technological products will evolve, Sony Mobile Communications AB also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our Please contact the undersigned if there are any further questions or additional information

Sony Mobile Communications Prepared by SEM/CGQB Håkan Sjöberg Contents responsible if other than preparer Approved by SEM/CGQB Håkan Sjöberg Telecommunication Certification Body UL Pavilion A Ashwood Park Ashwood Way Basingstoke Hampshire RG23 8BG England Subject: Short term confidentiality request Applies to FCC ID: PY7PM In accordance with §0.459 of CFR 47 and Public Notice DA 04 Communications AB requests in addition to confidentiality request temporary confidentiality C1504, FCC ID: PY7PM • User manual • Test setup photos • External photos • Internal photos These items contain proprietary information related to the design of the product which has not yet been released to the market. The public disclosure of this information prior to public launch may be harmful to Sony Mobile Communications competitors. A period up to 2013 market launch, If the launch date is re again to cancel this restrict Please contact the undersigned if there are any further questions or additional information needed in this matter. Yours sincerely Håkan Sjöberg Global Type Approval Sony Mobile Communications Tel: +46 10 801 35 59 Mobilvägen 10, SE-221 88 Lund, Sweden [email protected] Confidential LETTER Document number CGQBDA12:481 Date 2012-12-19 Remarks Telecommunication Certification Body Short term confidentiality request PY7PM-0260 In accordance with §0.459 of CFR 47 and Public Notice DA 04-1705, Sony Mobile Communications AB requests in addition to confidentiality request temporary confidentiality until 2013-02-15 of the below listed items for our mobile pho , FCC ID: PY7PM-0260: photos photos nternal photos These items contain proprietary information related to the design of the product which has not yet been released to the market. The public disclosure of this information prior to public launch may be harmful to Sony Mobile Communications AB and provide unjust benefits to its competitors. A period up to 2013-02-15 is requested to protect this information before formal market launch, If the launch date is re-scheduled to be earlier than 2013 ain to cancel this restriction. Please contact the undersigned if there are any further questions or additional information n this matter. Sony Mobile Communications 21 88 Lund, Sweden [email protected] 1(1) Revision B 1705, Sony Mobile Communications AB requests in addition to confidentiality request CGQBDA12:480 of the below listed items for our mobile phone These items contain proprietary information related to the design of the product which has not yet been released to the market. The public disclosure of this information prior to public AB and provide unjust benefits to its 15 is requested to protect this information before formal scheduled to be earlier than 2013-02-15 we will inform Please contact the undersigned if there are any further questions or additional information

Sony Mobile Communications Prepared by SEM/CGQB Håkan Sjöberg Contents responsible if other than preparer Approved by SEM/CGQB Håkan Sjöberg Telecommunication Certification Body UL Pavilion A Ashwood Park Ashwood Way Basingstoke Hampshire RG23 8BG England To whom it may concern The C1504, FCC ID: PY7PM supporting the following Frequency bands: • GSM 850MHz Voice and (E)GPRS Data • GSM 900MHz Voice and (E)GPRS Data • GSM 1800MHz Voice and (E)GPRS Data • GSM 1900MHz Voice and (E)GPRS Data • UMTS FDD I 2100MHz Voice and Data • UMTS FDD II 1900MHz Voice and Data • UMTS FDD V 850MHz Voice and Data • WLAN 2412 – 2462MHz • Bluetooth 2402 – 2480MHz The device contains functions that are not operational in U.S Territories. bands operational in the U.S Territories are GSM 850MHz and UMTS FDD II 1900MHz WLAN and HAC Yours sincerely Håkan Sjöberg Manager - Global Type Approval Sony Mobile Communications Tel: +46 10 801 35 59 Mobilvägen 10, SE- 221 88 Lund, Sweden [email protected] Confidential LETTER …

Text truncated - open the document above for the full version.
