PY7PM-0280GSM/UMTS Mobile Phone with WLAN, BT, RFID

Startup guide Xperia ™ Z C6602 Sony Mobile Communications AB SE-221 88 Lund, Sweden www.sonymobile.com 1269-9485.1 Welcome Important Information Before you use your device, please read the Important Information provided in your device or in the box. Water and dust resistance >1m Ocean waterSwimming poolDiving Hot waterSand/mudOther liquid chemicals Your device has IP (Ingress Protection) ratings of IP5X, IPX5 and IPX7. This means that your device is dust protected and protected against the effects of immersion in water in depths of between 0 to 100 cm for up to 30 minutes, and is also protected against the effects of a low pressure water stream. The covers for the micro USB port, the micro SD card, the micro SIM card and the headset connector must be firmly closed in order for the device to meet the stated IP rating. More information about IP codes and important details about your device’s resistance to water can be found in the User guide for your device and on the Sony Mobile support website. www.sonymobile.com/support Assembly To insert the micro SIM card 1 2 3 4 5 To insert a memory card Do not insert a micro SIM card into the memory card slot. 1 22222 The memory card may not be included at purchase in all markets. Basics Device overview 123 4 5 6 7 8 91011 12 15 16 17 18 13 14 1. Front camera lens 2. Ear speaker 3. Ambient light sensor 4. Notification light 5. Main microphone 6. Charging dock connector 7. Memory card slot 8. Port for charger/USB cable 9. Headset connector 10. Camera lens 11. Second microphone 12. Camera light 13. NFC™ detection area 14. Strap hole 15. Speaker 16. Volume/Zoom key 17. Power key 18. Micro SIM slot Use the accessories provided with your device, or other compatible accessories, for optimal performance. Turning on the device To turn on the device Make sure that the battery is charged for at least 30 minutes before you turn on the device for the first time. 1 Press and hold down the power key until the device vibrates. 2 Wait a while for the device to start. Waking up the screen To activate the screen • Briefly press the power key . To unlock the screen • Drag up or drag down. Using the keys Back • Go back to the previous screen • Close the on-screen keypad, a dialog box, an options menu, or the Notification panel Home • Go to the Home screen Task • Tap to open a window showing your most recently used applications and a small apps bar Set up your device What is Android™? Android is your device's operating system. Since Android is developed by Google™, your device is preloaded with several Google™ services, such as Google Maps™ and Google™ web search. To use some of the services provided by Google™, you need a Google account. What is different about Android? Android™ is an open system, which means that you're not limited to using applications and services from only one provider. Google™ account With a Google™ account, you can use Gmail™ to send emails, Google Talk™ to chat with friends, and Google Play™ to download applications and games, music, movies and books. To set up a Google™ account on your device 1 From your Home screen, tap . 2 Find and tap Settings > Add account > Google. 3 Follow the registration wizard to create a Google™ account, or sign in if you already have an account. You can also sign in to or create a Google™ account from the setup guide the first time you start your device. Or you can go online and create an account at www.google.com/accounts. Basic settings The first time you start your device, a setup guide explains basic device functions and helps you enter essential settings. You can also access the setup guide later. To access the setup guide manually 1 From the Home screen, tap . 2 Tap Settings > Setup guide. Transferring contacts to your new device Transferring contacts to your new device can sometimes be complicated, but help is available. You can transfer contacts from several device brands, including iPhone, Samsung, HTC and Nokia. You need: • An Internet-connected PC running Windows® • A USB cable for your old device • A USB cable for your new Android™ device • Your old device • Your new Android™ device Get started transferring your contacts Use the PC Companion program to transfer your contacts. It's free, and the installation files are already saved on your new device. PC Companion also offers a range of other features, including help to update your device software. To install PC Companion 1 New device: Turn on your new Android™ device and connect it to a PC using a USB cable. 2 New device: Tap Install to install PC Companion on the PC. 3 Computer: If a popup window appears to notify you about available PC software, select Run Startme.exe. 4 Computer: Click Install to start the installation and then follow the instructions to complete the installation. To transfer contacts to your new device using PC Companion 1 Make sure that PC Companion is installed on your PC. 2 Open the PC Companion program on the PC, then click Contacts Setup and follow the instructions to transfer your contacts. Finding your way Home screen The Home screen of your device is the equivalent of the desktop on a computer. You can customise your Home screen with widgets, shortcuts, folders, themes, wallpaper and other items. The Home screen extends beyond the regular screen display width, so you need to flick left or right to view content in one of the screen's four extensions. The items in the bar at the bottom of the screen are always available for quick access. To go to the Home screen • Press . To browse the Home screen • Flick right or left. To change your Home screen wallpaper 1 Tap an empty area on your Home screen. 2 Tap Wallpaper and select an option. Widgets Widgets are small applications that you can use directly on your Home screen. For example, the Music player widget allows you to start playing music directly. Some widgets are resizable, so you can expand them to view more content or shrink them to save space on your Home screen. Application…

Text truncated - open the document above for the full version.

SAR Information FCC Statement Declaration of Conformity Sony C6602 UMTS HSPA Band 1 2 4 5 8 GSM GPRS/EDGE 850/900/1800/1900 Important Information United States & Canada THIS PHONE MODEL HAS BEEN CERTIFIED IN COMPLIANCE WITH THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. The Series mobile phones have been designed to comply with applicable safety requirements for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed to not exceed the limits* of exposure to radio frequency (RF) energy set by governmental authorities. These limits establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by international scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a safety margin designed to assure the safety of all individuals, regardless of age and health. The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate (SAR). Tests for SAR are conducted using standardized methods with the phone transmitting at its highest certified power level in all used frequency bands. While there may be differences between the SAR levels of various phone models, they are all designed to meet the relevant guidelines for exposure to radio waves. For more information on SAR, please refer to the safe and efficient use chapter in the User Guide. The highest SAR value as reported to the authorities for this phone model when tested for use by the ear is 1.05 W/kg*, and when worn on the body is 0.56 W/kg* for speech and 1.10 W/kg* for data calls. For body-worn operation, the phone has been tested when positioned a minimum of 15 mm from the body without any metal parts in the vicinity of the phone or when properly used with an appropriate Sony accessory and worn on the body. For devices which include “WiFi hotspot” functionality, SAR measurements for the device operating in WiFi hotspot mode were taken using a separation distance of 2 10mm. Use of third-party accessories may result in different SAR levels than those reported. **Before a phone model is available for sale to the public in the US, it must be tested and certified by the Federal Communications Commission (FCC) that it does not exceed the limit established by the government-adopted requirement for safe exposure*. The tests are performed in positions and locations (i.e., by the ear and worn on the body) as required by the FCC for each model. The FCC has granted an Equipment Authorization for this phone model with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR levels of various phones, all mobile phones granted an FCC equipment authorization meet the government requirement for safe exposure. SAR information on this phone model is on file at the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID PY7PM-0280. Additional information on SAR can be found on the Cellular Telecommunications & Internet Association (CTIA) website at http://www.phonefacts.net. * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard incorporates a margin of safety to give additional protection for the public and to account for any variations in measurements. **This paragraph is only applicable to authorities and customers in the United States. 3 Renseignements importants États-Unis et Canada CE MODÈLE DE TÉLÉPHONE A ÉTÉ CERTIFIÉ CONFORME AUX EXIGENCES GOUVERNEMENTALES RELATIVES À L'EXPOSITION AUX ONDES RADIOÉLECTRIQUES. Les téléphones mobiles de la ont été conçus pour répondre aux normes de sécurité en vigueur en matière d'exposition aux ondes radioélectriques. Votre téléphone sans fil est un émetteur et un récepteur radio. Il est conçu de manière à ne pas dépasser les limites* d'exposition à l'énergie des fréquences radio (RF) établies par les autorités gouvernementales. Ces limites fixent les niveaux maximaux d'énergie RF auxquels peut être soumis le grand public. Ces lignes directrices sont basées sur des normes qui ont été élaborées par des organisations scientifiques internationales par le biais d'évaluations périodiques et approfondies des études scientifiques. Ces normes prévoient une marge de sécurité visant à assurer la protection de tous les individus, peu importe leur âge et leur état de santé. Les lignes directrices relatives à l'exposition aux ondes radioélectriques utilisent une unité de mesure appelée « Taux d'absorption spécifique » (TAS). Les tests de TAS sont effectués selon des méthodes standardisées dans lesquelles le téléphone émet dans toutes les bandes de fréquences utilisées, à la plus forte puissance pour laquelle il a été homologué. Bien que le TAS puisse être différent d'un modèle de téléphone à un autre, tous les appareils sont conçus pour respecter les lignes directrices relatives aux ondes radioélectriques. Pour en savoir plus sur le TAS, reportez-vous au chapitre sur l'utilisation efficace et sans danger du guide de l'utilisateur. Le TAS le plus élevé relevé par les autorités pour ce modèle de téléphone est de 1.05 W/kg* lorsqu'il est testé en utilisation près de l'oreille, et de 0.556 W/kg* pour les appels vocaux et de 1.10 W/kg* pour les transmissions de données lorsqu'il est porté sur le corps. En mode d’utilisation porté sur le corps, le téléphone a été testé lorsqu’il est à au moins 15 mm du corps et à l’écart de toute pièce en métal, ou lorsqu’il est utilisé de façon 4 adéquate avec un accessoire Sony et porté sur le corps. Pour les appareils munis de la fonctionnalité « point d'accès WiFi », les mesures du TAS de l'appareil en mode WiFi ont été prises à une distance de sécurité de 10 mm. L'utilisation d'accessoires tiers peut produire des niveaux de TAS différents de ceux relevés. **Ava…

Text truncated - open the document above for the full version.

SONY Sony Mobile Communications SE-221 88 LUND· SWEDEN Confidentiality Request 2013-01-09 CGQBDA12:533 SoM/CGQBDA Afrah Sadiq +46 10 80 12250 Receiver Federal Communications Commission Subject: Request for Confidentiality FCC 10: PY7PM·0280 To Whom It May Concern: In accordance with §0.459 of CFR 47, Sony Mobile Communications AB requests confidentiality for the below listed items for our Sony mobile phone type PM-0280-BV, FCC ID: PY7PM-0280: 1. Block Diagram 2. Schematic Diagram 3. Part List 4 . Operational/Technical Descriptions These items contain detailed system and equipment description and related information about the product which Sony Mobile Communications AB considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Sony Mobile Communications AB also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Please contact the undersigned if there are any further questions or additional information needed in this matter. :r:rdS, Afrah Sadiq Staff Ve:rificalion Engineer Globa! Type Approval Sony Mobile Communications Nya ValtentOfl'let 221 88 Lund, Sweden Fax. +46 10 80 02441 l!Q!rLI:l1..Q.IlliL('.9..!.'J Sony Mobile Communications Styrelsens sate: Lund Momsnr • V.A rNa: SE55661566580 I Registered office. wnd Organisationsnr. Reg No: 556615-6658 Posfadress • Mail Besoksadless • Offics addres Teralol"l • Telepl10ne Tale/ax· Talalax SE-221 aa Lund Nya Vatlentomat Nat a I 0-80 00000 Nat 010-8002040 Swedan Lund Inl +45 10 80 00000 Int +46 10 SO 02040

Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 22 of 30 An nex B External ph ot ogra phs o f the E UT Photo documentation: Photo 1: Photo 2: Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 23 of 30 Photo 3: Photo 4: Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 24 of 30 Photo 5: Photo 6:

Company Internal MARKING DRAWING 1 (4) Prepared (also subject responsible if other) No. CGOVDPLG, Anna Englund 1267-9871 Uen Approved Checked Date Rev Reference CGOVDPLG, Anna Englund 2012-07-03 4 3 , Mobile Phone label content 1 General information MLCI=Main Label Content information 2 Printing information Content Format Line 1a (1,4/28,0) Marking of origin; “MADE IN CHINA” Text, height 1,2 mm. Line 1b (1,4/37,1) Model Name “C6602” Text, height 1,2 mm. According to model name in Chapter 1 in MLCI. Line 1c (1,4/41,5) Actual electronic serial number (IMEI) of the mobile phone, “00000000-000000-0” Text, height 1,2 mm. In the format TAC-SNR-CD. TAC and SNR derived from pos 500 in BOM. CD = check digit according to the Luhn formula (ISO/IEC 7812), GSM 02.16. Line 1d (1,4/54,0) Production week (flash), “00W01” (yy = year, ww = week) Text, height 1,2 mm. Line 1e (1,4/58,2) HW & SW identification field, if applicable; “EFF” Text, height 1,2 mm. According to Type-testing report under Product Model Specifying Document Line 2 (3,6/41,5) Line 2 in bar code, according to line 1c. As desired by supplier (e.g. only actual number). Bar code, height 2,0 mm. As desired by supplier (e.g. Code 128 symbology). Mobile Phone label part no  Not applicable Mobile Phone label content part no  1267-9873 Bar code  Print quality: according to COSMETIC GUIDELINE – Bar code labels document 1222-6072 Uen  Quiet zone: No bar codes are allowed to be closer to a label edge than 2 mm! Text If applicable, or nothing else specified, Helvetica Neue LT Std 37 Light Condensed 4.75 pt (kerning -20) is imposed. When needed, the text is adjusted to fit the label. Coordinates “(x/y)” under each line number specifies the bottom / left alignment for text, graphics and bar codes, x is measured vertically, and y horizontally from the upper left corner of the label (landscape format), both in mm. When needed, the alignment is adjusted to fit the label. Company Internal MARKING DRAWING 2 (4) Prepared (also subject responsible if other) No. CGOVDPLG, Anna Englund 1267-9871 Uen Approved Checked Date Rev Reference CGOVDPLG, Anna Englund 2012-07-03 4 3 3 Layout The conceptual picture (for Zebra 90XiII printer, or equivalent) should not be considered as specifications, but as an additional help for setting up the label. 3.1 Conceptual picture double underlined = major changes since last revision. Company Internal MARKING DRAWING 3 (4) Prepared (also subject responsible if other) No. CGOVDPLG, Anna Englund 1267-9871 Uen Approved Checked Date Rev Reference CGOVDPLG, Anna Englund 2012-07-03 4 3 Company Internal MARKING DRAWING 4 (4) Prepared (also subject responsible if other) No. CGOVDPLG, Anna Englund 1267-9871 Uen Approved Checked Date Rev Reference CGOVDPLG, Anna Englund 2012-07-03 4 3

Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 25 of 30 An nex C Inter nal p ho to gra phs o f the E UT Photo documentation: Photo 1: Photo 2: Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 26 of 30 Photo 3: Photo 4: Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 27 of 30 Photo 5: Photo 6: Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 28 of 30 Photo 7: Photo 8:

2013-01-17 Page 1 of 30 TEST REPORT 1-4254/12-72-03-A Testing Laboratory Applicant CETECOM ICT Services GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken/Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom-ict.de e-mail: [email protected] Accredited Test Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-01 Area of Testing: Radio/Satellite Communications Sony Mobile Communications AB Nya Vattentornet 22188 Lund/SWEDEN Phone: +46 46 19 30 00 Fax: +46 46 19 32 95 Contact: Håkan Sjöberg e-mail: [email protected] Phone: +46 46 19 35 59 Manufacturer Sony Mobile Communications AB Nya Vattentornet 22188 Lund/SWEDEN Test Standard/s 47 CFR Part 15 Title 47 of the Code of Federal Regulations; Chapter I Part 15 - Radio frequency devices RSS - Gen Issue 3 General Requirements and Information for the Cetification of Radiocommunication Equipment For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: GSM Mobile Phone GPRS/EGPRS 850/900/1800/1900; UMTS HSPA FDDI/II/IV/V/VIII; WLAN a/b/g/n; BT 3.1; BT LE; RFID; FM Rx; A-GPS Model name: PM-0280-BV Frequency [MHz]: GSM: 824.2 – 848.8 MHz, 1850.2 – 1909.8 MHz UMTS: 826.4 – 846.6 MHz, 1712.4 – 1752.6 MHz, 1852.4 – 1907.6 MHz Technology tested: GSM, UMTS – receiver mode Antenna: Integrated antenna Power Supply: 3.7 V DC by Li - polymer battery Temperature Range: -30°C to +60°C Test report authorised: Test performed: 2013-01-17 Stefan Bös 2013-01-17 Marco Bertolino Senior Testing Manager Testing Manager Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 2 of 30 1 Table of contents 1 Table of contents ............................................................................................................................................ 2 2 General information ....................................................................................................................................... 3 2.1 Notes and disclaimer .......................................................................................................................... 3 2.2 Application details ............................................................................................................................... 3 3 Test standard/s ............................................................................................................................................... 3 4 Test environment ............................................................................................................................................ 4 5 Test item .......................................................................................................................................................... 4 6 Test laboratories sub-contracted ................................................................................................................. 4 7 Summary of measurement results ............................................................................................................... 5 7.1 Receiver ................................................................................................................................................ 5 8 Measurement results ...................................................................................................................................... 6 8.1 RX spurious emissions conducted < 30 MHz ................................................................................... 6 8.2 RX spurious emissions radiated ........................................................................................................ 8 9 Test equipment and ancillaries used for tests .......................................................................................... 15 10 Observations ......................................................................................................................................... 16 Annex A Photographs of the test setup ...................................................................................................... 17 Annex B External photographs of the EUT ................................................................................................. 22 Annex C Internal photographs of the EUT .................................................................................................. 25 Annex D Document history .......................................................................................................................... 29 Annex E Further information ........................................................................................................................ 29 Annex F Accreditation Certificate ............................................................................................................... 30 Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 3 of 30 2 General information 2.1 Notes and disclaimer The test results of this test report relate exclusively to the test item specified in this test report. CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of CETECOM ICT Services GmbH. The testing service provided by CETECOM ICT Services GmbH has been rendered under the current "General Terms and Conditions for CETECOM ICT Services GmbH". CETECOM ICT Services GmbH will not be liable for any loss or damage resulting from false, inaccurate, inappropriate or incomplete pr…

Text truncated - open the document above for the full version.

Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 17 of 30 An nex A Pho tog raphs o f t h e test se tu p Photo documentation: Photo 1: Photo 2: Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 18 of 30 Photo 3: Photo 4: Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 19 of 30 Photo 5: Photo 6: Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 20 of 30 Photo 7: Photo 8: Test Report No.: 1-4254/12-72-03-A 2013-01-17 Page 21 of 30 Photo 9: additional measurement HDMI connection via USB-cradle to monitor
