PY7PM-0720Smart Phone

Important Information Before you use your device, please read the Important Information provided in your device regarding warranty, safety and handling information. Assembly To insert the micro SIM card Your phone requires a micro SIM card. For more information, contact your network operator. To insert a memory card Basics Overview 13 6 7 8 10 9 12 5 24 11 15 17 14 13 16 18 1. Proximity sensor/ Light sensor 2. Charging light/ Notification light 3. Ear speaker 4. Front camera lens 5. Micro SIM and memory card slot cover 6. Power key 7. Volume/Zoom key 8. Camera key 9. Strap hole 10. Speaker 11. Illumination bar 12. Main microphone 13. Main camera lens 14. Camera light 15. Headset jack 16. Second microphone 17. Port for charger/USB cable 18. NFC™ detection area Turning on the device Make sure that the battery is charged for at least 30 minutes before you turn on the device for the first time. To turn on the device 1 Press and hold down the power key until the device vibrates. 2 Wait a while for the device to start. Waking up the screen To activate the screen • Briefly press the power key . Setting up your device Setup guide The first time you start your device, a setup guide opens to help you configure basic settings, sign in to some accounts (for example, your Google™ account), and personalise your device. You can also manually access the setup guide at a later stage. To access the setup guide manually 1 From the Home screen, tap . 2 Tap > Setup guide. Settings menu View and change settings for your device from the Settings menu. To access your device settings 1 From your Home screen, tap . 2 Find and tap . Transferring your contacts Xperia™ Transfer and Contacts Setup are applications within the PC Companion and the Sony™ Bridge for Mac computer programs that help you to collect contacts from your old device and transfer them to your new device. These applications support several device brands, including iPhone, Samsung, HTC, BlackBerry, LG, Motorola and Nokia. You need: • An Internet-connected computer. • A USB cable for your old device. • A USB cable for your new Android™ device. • Your old device. • Your new Android™ device. To transfer contacts to your new device 1 Connect your device to a computer. In the window that appears, choose to install PC Companion or Bridge for Mac if you have not already installed these applications. 2 After successful installation, open the PC Companion application or the Sony™ Bridge for Mac application, then click Xperia™ Transfer or Contacts Setup and follow the relevant instructions to transfer your contacts. Finding your way Using the buttons Back • Go back to the previous screen. • Close the on-screen keypad, a dialog box, an options menu, or the Notification panel. Home • Go to the Home screen. • Press and hold to open a window showing your most recently used applications. Menu • Open a list of options available in the current screen or application. Application screen • Open the Application screen. Basic applications and settings Make phone calls by dialling the number manually or by using the smart dial function. Use the Messaging application to send and receive text and multimedia messages. Go to Google Play™ to download free and paid applications for your device. Optimise the device settings to suit your own requirements. Status and notifications To open or close the Notification panel Support on the web Visit www.sonymobile.com/support to access a range of support options for your device, including downloads, troubleshooting tips and a User guide. Legal information Sony D2303/D2305/D2306 Publication number: xxxx-xxxx.1 This Startup guide is published by Sony Mobile Communications AB or its local affiliated company, without any warranty. Improvements and changes to this Startup guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this Startup guide. All illustrations are for illustration only and may not accurately depict the actual device. See regulatory information such as the CE mark in the label tray of the device. All product and company names mentioned herein are the trademarks or registered trademarks of their respective owners. All other trademarks are property of their respective owners. Any rights not expressly granted herein are reserved. Visit www.sonymobile.com/us/legal/ for more information. Product compliance: This product has been manufactured by or on behalf of Sony Mobile Communications, Mobilvägen, SE-221 88 Lund, Sweden. Inquiries related to product compliance based on national legislation shall be addressed to Sony Mobile Quality Officer, Sony Mobile Communications AB, Mobilvägen, SE-221 88 Lund, Sweden. For any service or guarantee matters, please refer to the contact details provided in the separate service or guarantee documents. ©Sony Mobile Communications AB, 2013. All rights reserved. FCC Caution: Your device can only connect to an FCC approved access point when using 5 GHz WLAN for indoor and outdoor operation. This is because operation in the 5.15 GHz to 5.25 GHz frequency band is only permitted for indoor use. To view the CE mark and the FCC ID 1 2 1 Make sure your device is turned off. 2 Detach the cover for the micro SIM card slot. 3 Using a fingernail, remove the two label trays in the order shown in the illustration. 4 The FCC ID is displayed on the back of the first tray. The CE mark is displayed on the front of the second tray. Startup guide M2 D2303/D2305/D2306

American English Hearing Aid Compatibility Your phone is designed for Hearing Aid Compatibility (HAC) and can be used with hearing aids. This feature has not been tested in combination with WLAN. Hearing Aid Settings You can choose the setting in the phone to match the setting in your hearing aid before making or receiving calls. To select a phone setting for HAC 1 From the Home screen, tap . 2 Find and tap Settings > Call settings. 3 Mark the Hearing aids checkbox to turn on hearing aid compatibility. Hearing Aid Compatibility Information This phone has been tested and rated for use with hearing aids for some of the wireless technologies it uses. However, there may be some newer wireless technologies used in this phone that have not been tested yet for use with hearing aids. It is important to try the different features of this phone thoroughly and in different locations, using your hearing aid or cochlear implant, to determine if you hear any interfering noise. Consult your service provider or the manufacturer of this phone for information on hearing aid compatibility. If you have questions about return or exchange policies, consult your service provider or phone retailer. Hearing Aid Compatibility Rating This model handset was designed to comply with the requirements set forth in Section 20.19 of the Federal Communication Commission's (FCC) rules governing hearing aid compatibility (HAC), for the reduction of RF interference and magnetic coupling (T-coil) to hearing aids. The Microphone (M) rating and T-coil (T) rating is defined and labeled on the handset box. Devices meeting HAC compliance must have a minimum M3 and/or T3 rating or above as defined by the FCC in accordance with the latest ANSI Standard C63.19. The (M) rating refers to lower RF emission levels of the handset. The (T) rating refers to the magnetic coupling between the handset and the T-coil compatible hearing aid. Some hearing aids are also provided an (M) rating, and are more immune than others to interference. To determine the (M) rating of your hearing aid, please contact your hearing health professional. More information about digital wireless devices and hearing aid compatibility can be found at May 30, 2012 13:36:44 Important information Información importante www.sonymobile.com Sony Mobile Communications AB SE-221 88 Lund, Sweden http://blogs.sonymobile.com/about-us/sustainability/ accessibility/overview/hearing-aid-compatibility/. 1239-4751.5 October 24, 2013 14:55:51 Leaflet NAM HAC Leaflet AE XL FR A7 1239-4751.5.pdf 1 of 2 Español Latinoamericano Compatibilidad de aparatos auditivos Su teléfono está diseñado para la compatibilidad de aparatos auditivos (HAC, por su sigla en inglés) y se puede usar con aparatos auditivos. Esta función no se ha probado en combinación con WLAN. Ajustes de los aparatos auditivos Puede elegir que el ajuste del teléfono coincida con el ajuste de su aparato auditivo antes de realizar o recibir llamadas. Seleccionar una configuración de teléfono para HAC 1 Desde Home screen, toque suavemente . 2 Busque y toque suavemente Configuración > Config. de llamada. 3 Marque la casilla de verificación Hearing aids para activar la compatibilidad de aparatos auditivos. INFORMACIÓN SOBRE COMPATIBILIDAD CON EQUIPOS DE ASISTENCIA AUDITIVA Este teléfono ha sido probado y clasificado para su uso con equipos de asistencia auditiva para ciertas tecnologías de servicio móvil que usa. Sin embargo, pueden existir ciertas tecnologías nuevas de servicio móvil usadas en este teléfono que no han sido probadas aún para su uso con equipos de asistencia auditiva. Es importante probar minuciosamente y en diferentes sitios las distintas funciones de este teléfono, usando su equipo Français Compatibilité avec les appareils auditifs Votre téléphone est conçu pour la compatibilité avec les appareils auditifs (HAC) et peut être utilisé avec des appareils auditifs. Cette fonction n'a pas été testée avec les réseaux WLAN. Paramètres de l'appareil auditif Sur votre téléphone, vous pouvez choisir le même paramètre que celui de l'appareil auditif avant de passer ou de recevoir des appels. Pour sélectionner un paramètre de téléphone pour la HAC 1 Dans l'Home screen, tapez sur . 2 Tapez sur Paramètres > Paramètres d'appel. 3 Cochez la case Hearing aids pour activer la compatibilité avec les appareils auditifs. Informations relatives à la compatibilité avec les appareils auditifs Ce téléphone a été testé et classé pour offrir une compatibilité entre certaines des technologies sans fil qu'il utilise et les appareils auditifs. Cependant, il peut faire appel à des technologies sans fil plus récentes qui n'ont pas encore été testées avec les appareils auditifs. Il est donc important que vous essayiez les diverses fonctions de ce téléphone, de manière exhaustive et dans différents endroits, avec votre appareil auditif ou votre implant cochléaire pour déterminer si vous entendez des parasites. Pour plus d'informations sur la compatibilité de asistencia auditiva o implante coclear, para determinar si usted escucha algún ruido de interferencia. Consulte con su proveedor de servicio o el fabricante de este teléfono para información sobre compatibilidad con equipos de asistencia auditiva. Si tiene preguntas sobre las políticas de devolución o cambios, consulte con su proveedor de servicio o centro de venta de teléfonos. Clasificación de compatibilidad de los aparatos auditivos Este modelo de teléfono fue diseñado para cumplir los requisitos establecidos en la Sección 20.19 de las normas de la Federal Communication Commission (FCC) que rigen la compatibilidad de los aparatos auditivos (HAC, por sus siglas en inglés), para la reducción de la interferencia RF y el acoplamiento magnético (T-coil) con los aparatos auditivos. La clasificación de Micrófono (M) y la clasificación de T-coil (T) está definida y marcada en la caja del teléfono. Los dispositivos que cumplen los requisitos de HAC deben tener una clasificación mínima de M3 y/o T3 …
