PY7PM-0742GSM/UMTS/LTE/CDMA Mobile Phone with WLAN, BT, RFID and Ant+

SAR Information FCC Statement Declaration of Conformity Sony D6 708 UMTS HSPA Band 1 2 5 8 GSM GPRS/EDGE 850/900/1800/1900 CDMA BC0 BC1 LTE Band 2 3 4 7 13 Important Information United States & Canada THIS PHONE MODEL HAS BEEN CERTIFIED IN COMPLI ANCE WITH THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. The D6708 Series mobile phones have been designed to comply with applicable safety requirements for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed to not exceed the limits* of exposure to radio frequency (RF) energy set by governmental authorities. These limits establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by international scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a safety margin designed to assure the safety of all individuals, regardless of age and health. The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate (SAR). Tests for SAR are conducted using standardized methods with the phone transmitting at its highest certified power level in all used frequency bands. While there may be differences between the SAR levels of various phone models, they are all designed to meet the relevant guidelines for exposure to radio waves. For more information on SAR, please refer to the Important Information chapter in the User Guide. The highest SAR value as reported to the authorities for this phone model when tested for use by the ear is 0.653 W/kg*, and when worn on the body is 1.194 W/kg*. For body-worn operation, the phone has been tested when positioned a minimum of 15 mm from the body without any metal parts in the vicinity of the phone or when properly used with an appropriate accessory and worn on the body. For devices which include “WiFi hotspot” functionality, SAR measurements for the device operating in WiFi hotspot mode were taken using a separation distance of 10 mm. Use of third-party 2 accessories may result in different SAR levels than those reported. **Before a phone model is available for sale to the public in the US, it must be tested and certified by the Federal Communications Commission (FCC) that it does not exceed the limit established by the government-adopted requirement for safe exposure*. The tests are performed in positions and locations (i.e., by the ear and worn on the body) as required by the FCC for each model. The FCC has granted an Equipment Authorization for this phone model with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR levels of various phones, all mobile phones granted an FCC equipment authorization meet the government requirement for safe exposure. SAR information on this phone model is on file at the FCC and can be found under the Display Grant section of http://transition.fcc.gov/oet/ea/fccid after searching on FCC ID PY7PM-0742. Additional information on SAR can be found on the Mobile Manufacturers Forum EMF website at http://www.emfexplained.info/. * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard incorporates a margin of safety to give additional protection for the public and to account for any variations in measurements. **This paragraph is only applicable to authorities and customers in the United States. 3 Renseignements importants États-Unis et Canada CE MODÈLE DE TÉLÉPHONE A ÉTÉ CERTIFIÉ CONFOR ME AUX EXIGENCES GOUVERNEMENTALES RELATIVES À L'EXPOSITION AUX ONDES RADIOÉLECTRIQUES. Les téléphones mobiles de la D6708 ont été conçus pour répondre aux normes de sécurité en vigueur en matière d'exposition aux ondes radioélectriques. Votre téléphone sans fil est un émetteur et un récepteur radio. Il est conçu de manière à ne pas dépasser les limites* d'exposition à l'énergie des fréquences radio (RF) établies par les autorités gouvernementales. Ces limites fixent les niveaux maximaux d'énergie RF auxquels peut être soumis le grand public. Ces lignes directrices sont basées sur des normes qui ont été élaborées par des organisations scientifiques internationales par le biais d'évaluations périodiques et approfondies des études scientifiques. Ces normes prévoient une marge de sécurité visant à assurer la protection de tous les individus, peu importe leur âge et leur état de santé. Les lignes directrices relatives à l'exposition aux ondes radioélectriques utilisent une unité de mesure appelée « Taux d'absorption spécifique » (TAS). Les tests de TAS sont effectués selon des méthodes standardisées dans lesquelles le téléphone émet dans toutes les bandes de fréquences utilisées, à la plus forte puissance pour laquelle il a été homologué. Bien que le TAS puisse être différent d'un modèle de téléphone à un autre, tous les appareils sont conçus pour respecter les lignes directrices relatives aux ondes radioélectriques. Pour en savoir plus sur le DAS, reportez-vous au chapitre sur les renseignements importants du guide de l'utilisateur. Le DAS le plus élevé relevé par les autorités pour ce modèle de téléphone est de 0.653 W/kg* lorsqu'il est testé en utilisation près de l'oreille, et de 1.194 W/kg* lorsqu'il est porté sur le corps. En mode d’utilisation porté sur le corps, le téléphone a été testé lorsqu’il est à au moins 15 mm du corps et à l’écart de toute pièce en métal, ou lorsqu’il est utilisé de façon adéquate 4 avec un accessoire et porté sur le corps. Pour les appareils munis de la fonctionnalité « point d'accès WiFi », les mesures du DAS de l'appareil en mode WiFi ont été prises à une distance de sécurité de 10 mm. L'utilisation d'accessoires tiers peut produire des niveaux de DAS différents de ceux relevés. **Avant qu'un modèle de téléphone ne soit mis en vente auprès du public aux États-Unis, la Commission …

Text truncated - open the document above for the full version.

Get to Know Your Phone SONY ® X P ERIA® Z 3v D6708 Welcome to Verizon Wireless. You’re now part of a growing movement that’s about speed, signal and strength. This guide will show you how to set up and use your phone, access special features, and find help. Insert the SIM Card NOTE: If not already inserted, follow the instructions below to insert your 4G LTE SIM card. To insert the SIM card: 1. Open the SIM card slot cover. 2. Using a fingernail, pull out the SIM card holder. 3. Carefully insert the 4G LTE SIM card into the SIM card holder with the Verizon logo facing down. 4. Push the SIM card holder back into place. 5. Close the SIM card slot cover. Setting Up Your Phone 1 2 3 4 5 Charge the Phone Before turning on your phone, charge it fully 1. Connect the USB cable to the charger. 2. Insert the other end of the USB cable into the charger port on the left side of the phone. 3. Plug the charger into a compatible electrical outlet. WARNING! Please use only an approved charging accessory to charge your phone. Improper handling of the charging port, as well as the use of an incompatible charger, may cause damage to your device and void the warranty. Optional: Insert the microSD Card If you have a microSD card, slide the microSD card into the microSD card slot To insert the microSD card: 1. Open the microSD card slot cover. 2. Carefully slide the microSD card into the microSD slot with the gold contacts facing up. 3. Close the microSD slot cover. (To remove the microSD card, carefully push the card inward to release it from the slot.) NOTE: The microSD card is sold separately. Front Camera MicroSD slot Volume/ Zoom key Microphone Camera key Speaker NOTE: Devices and software are constantly evolving—the screen images and icons you see here are for reference only. Proximity/ Light sensor Speaker/ Charging/ Notification light Powey/Lock Button Second Microphone Nano SIM slot NFC Detection Area Charger/ USB Port Headset Jack Wireless charge Detection Area Using Your Phone Turning Your Phone On/Off It’s important to fully charge the battery before turning on your phone. To turn on your phone: • Press and hold the Power/Lock button on the right side of your phone. To turn off your phone: 1. Press and hold the Power/Lock button until the Device options screen appears. 2. Tap Power off OK. Home Screen Setup Wizard Follow the onscreen instructions to quickly set up your phone and email accounts. Locking and Unlocking Your Phone Prevent accidental key presses by locking your phone. To lock your phone: • Press the Power/Lock button. To unlock your phone: • Press the Power/Lock button to wake the display and then drag your finger across the screen in any direction. Using the Touch Screen Use touch gestures to move around the screen, open menus, select items, zoom in or out on web pages, and more. Swipe—Swipe by quickly sliding your finger in any direction. Drag—Drag by touching an item and sliding it to a new position. Double-Tap—Tap two times rapidly to zoom in or out on a web page or picture. ©2014 Verizon Wireless. All Rights Reserved. Multi Touch—Pinch or spread your thumb and index finger to zoom in or out. Making a Call 1. Tap the phone icon on the Home screen. 2. Enter the number you want to call. 3. Ta p Send to place the call. Receiving a Call Tap Answer and slide to the right to answer an incoming call. Setting Up Voice Mail 1. Tap the phone icon on the Home screen. 2. Dial *86 and tap Send. 3. When you hear a greeting, tap # to interrupt. 4. Follow the setup tutorial. Checking Voice Mail From your phone, dial *86 and press Send. From other phones, enter your wireless number. 1. When you hear a greeting, tap # to interrupt. 2. Follow the prompts. NOTE: Voice mailboxes not set up within 45 days will be canceled. Your voice mailbox is not password protected until you create a password by following the setup tutorial. Sending a Text 1. From the Home screen, tap Apps Messaging. 2. Tap the Add icon to create a new conversation. 3. Enter the contact information and your message text. 4. You can also tap onscreen icon to add an attachment. 5. Ta p Send. Taking Photos 1. From the Home screen, tap Apps Camera. 2. Use the phone’s screen as a viewfinder to set up your shot. 3. Pinch the screen to zoom out or pinch open to zoom in. 4. You can tap onscreen icons to choose various camera options and settings. 5. You can also tap the screen to move the focus to a desired area of interest. 6. Tap the Camera icon (the shutter will sound). The picture is automatically stored in your selected storage location. Setting Up Email 1. From the Home screen, tap Apps Email. 2. Enter your email address in the “Email address” field. 3. Enter your password in the Password field and tap Next. 4. At the “Account setup” screen, name the account and enter a screen name to identify yourself on this account. 5. Tap Next to save the new account. Play Store From the Home screen: Tap the Google Play Store icon. Viewing Apps To view your apps, from the Home screen, tap the Apps icon. Installing Apps Thousands of apps are available to download from the Google Play™ Store. From the Home screen, tap the Play Store icon. Uninstalling Apps 1. From the Home screen, tap the Apps icon. 2. Swipe in from the left edge of the screen and choose Uninstall. 3. Tap the red X of the app you want to uninstall. Isis Mobile Wallet™ Now you can pay with your phone. Isis® lets you pay for purchases and often save on them too. Learn more at verizonwireless.com/isis. Improving Accessibility Adjust accessibility settings to assist users who have impaired vision or hearing, or reduced dexterity. 1. From the Home screen, tap Apps Settings Accessibility. 2. Tap a category and set the desired options to improve accessibility. Using TalkBack TalkBack provides screen reading to assist people with impaired vision. 1. From the Home screen, tap Apps Settings Accessibility. 2. Tap TalkBack. Then tap the TalkBack switch to turn it on. 3. Tap Settings at the top of…

Text truncated - open the document above for the full version.

Sony Mobile Communications Confidential WORK DESCRIPTION 1(1) Document number Revision 97/1483-LXE 108 828 Uen B Prepared by Date SEM/CGQTAOA TOSHIKO KITAHARA 2014-07-10 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQTAOA (MIGUEL DELORME) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 2014-05-20 TO WHOM IT MAY CONCERN FCC ID: PY7PM-0742 Sony mobile phone with the FCC ID: PY7PM-0742 uses the same WLAN hardware and software as the Sony mobile phone with the FCC ID: PY7PM-0740. Based on this fact, conducted measurements in FCC part 15.247/407 reports (report no 1-6965/13-04-14-A dated 2014-01-22, report no 1-6965/13-04-16-B dated 2014- 01-23 and report no 1-6965/13-04-18-A dated 2014-01-22) and the DFS client report (report no 1-6965/13-04-19-A dated 2014-01-22) issued for FCC ID: PY7PM-0740 also apply for FCC ID: PY7PM-0742. If you have any questions, please feel free to contact us at the address shown below Sincerely, Mika Kaneko Senior Architect – Global Type Approval Sony Mobile Communications Inc. Tel: +81 3 5782 5706 Konan, Minato-ku, 108-0075, Tokyo, Japan [email protected]

Sony Mobile Communications Confidential WORK DESCRIPTION 1(1) Document number Revision 95/1483-LXE 108 828 Uen B Prepared by Date SEM/CGQTAOA TOSHIKO KITAHARA 2014-07-10 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQTAOA (MIGUEL DELORME) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 2014-05-20 TO WHOM IT MAY CONCERN FCC ID: PY7PM-0742 Sony mobile phone with the FCC ID: PY7PM-0742 uses the same Bluetooth Low Energy hardware and software as the Sony mobile phone with the FCC ID: PY7PM-0740. Based on this fact, conducted measurements in FCC part 15.247 report (report no 1- 6965/13-04-11-A dated 2014-01-22) issued for FCC ID: PY7PM-0740 also apply for FCC ID: PY7PM-0742. If you have any questions, please feel free to contact us at the address shown below Sincerely, Mika Kaneko Senior Architect – Global Type Approval Sony Mobile Communications Inc. Tel: +81 3 5782 5706 Konan, Minato-ku, 108-0075, Tokyo, Japan [email protected]

Sony Mobile Communications Confidential WORK DESCRIPTION 1(1) Document number Revision 91/1483-LXE 108 828 Uen B Prepared by Date SEM/CGQTAOA TOSHIKO KITAHARA 2014-07-10 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQTAOA (MIGUEL DELORME) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 2014/05/20 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID PY7PM-0742 For the product stated above, we request permanent confidentiality for exhibits which contain Operational Description, Block Diagram, Schematics, Parts Lists or Tune Up Information. The above exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Mika Kaneko Senior Architect – Global Type Approval Sony Mobile Communications Inc. Tel: +81 3 5782 5706 Konan, Minato-ku, 108-0075, Tokyo, Japan [email protected]

Sony Mobile Communications Confidential WORK DESCRIPTION 1(1) Document number Revision 90/1483-LXE 108 828 Uen B Prepared by Date SEM/CGQTAOA TOSHIKO KITAHARA 2014-07-10 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQTAOA (MIGUEL DELORME) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use. Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 2014/05/20 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests short term confidentiality for the following product: FCC ID PY7PM-0742 For the product stated above, we request that the following information be held confidential: 1. External and Internal Photographs 2. Test Setup Photos 3. User Manual We request this confidentiality on the basis of ensuring that business sensitive information remains confidential for 180 days or the date of the marketing, whichever is earlier. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Mika Kaneko Senior Architect – Global Type Approval Sony Mobile Communications Inc. Tel: +81 3 5782 5706 Konan, Minato-ku, 108-0075, Tokyo, Japan [email protected]

Test report no.: 1-6965/13-20-01_AnnexA 2014-06-17 Page 1 of 6 Annex A This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Marco Bertolino Testing Manager Test report no.: 1-6965/13-20-01_AnnexA 2014-06-17 Page 2 of 6 External ph ot os o f t he EU T Photo 1: Photo 2: Test report no.: 1-6965/13-20-01_AnnexA 2014-06-17 Page 3 of 6 Photo 3: Photo 4: Test report no.: 1-6965/13-20-01_AnnexA 2014-06-17 Page 4 of 6 Photo 5: Photo 6: Test report no.: 1-6965/13-20-01_AnnexA 2014-06-17 Page 5 of 6 Photo 7: Test report no.: 1-6965/13-20-01_AnnexA 2014-06-17 Page 6 of 6 Docu men t his to r y Version Applied changes Date of release Initial release 2014-06-17

Sony Mobile Communications Confidential WORK DESCRIPTION 1(1) Document number Revision 81/1483-LXE 108 828 Uen A Prepared by Date SEM/CGQTAOA TOSHIKO KITAHARA 2014-05-14 Contents responsible if other than preparer Remarks This document is managed in metaDoc. Approved by SEM/CGQTAOA (TOSHIKO KITAHARA) It is the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use.

Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 1 of 15 Annex B This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Marco Bertolino Testing Manager Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 2 of 15 Inter nal p ho tos of the E UT Photo 1: Photo 2: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 3 of 15 Photo 3: Photo 4: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 4 of 15 Photo 5: Photo 6: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 5 of 15 Photo 7: Photo 8: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 6 of 15 Photo 9: Photo 10: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 7 of 15 Photo 11: Photo 12: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 8 of 15 Photo 13: Photo 14: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 9 of 15 Photo 15: Photo 16: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 10 of 15 Photo 17: Photo 18: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 11 of 15 Photo 19: Photo 20: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 12 of 15 Photo 21: Photo 22: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 13 of 15 Photo 23: Photo 24: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 14 of 15 Photo 25: Photo 26: Test report no.: 1-6965/13-20-01_AnnexB 2014-06-17 Page 15 of 15 Docu men t his to r y Version Applied changes Date of release Initial release 2014-06-17

Page 1 of 124 Annex D Appendix to Test Report No.: 1-6965/13-20-02-C Testing Laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 – 10 66117 Saarbrücken/Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom.com e-mail: [email protected] Accredited Test Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-01 Appendix with Calibration data, Phantom certificate and system check information 2014-07-02 Annex D to Test report no.: 1-6965/13-20-02-C Page 2 of 124 1 Table of contents 1 Table of contents ....................................................................................................................................... 2 2 Calibration report “Probe ET3DV6” ......................................................................................................... 3 3 Calibration report “Probe ES3DV3” ...................................................................................................... 14 4 Calibration report “Probe ES3DV3” ...................................................................................................... 25 5 Calibration report “Probe EX3DV4” ...................................................................................................... 36 6 Calibration report “750 MHz System validation dipole” ...................................................................... 47 7 Calibration report “835 MHz System validation dipole” ...................................................................... 55 8 Calibration report “1750 MHz System validation dipole” .................................................................... 65 9 Calibration report “1900 MHz System validation dipole” .................................................................... 75 10 Calibration report “2450 MHz System validation dipole” ............................................................ 85 11 Calibration report “2600 MHz System validation dipole” ............................................................ 94 12 Calibration report “5GHz System check dipole” ........................................................................ 102 13 Calibration certificate of Data Acquisition Unit (DAE) ............................................................... 115 14 Calibration certificate of Data Acquisition Unit (DAE) ............................................................... 116 15 Calibration certificate of Data Acquisition Unit (DAE) ............................................................... 117 16 Certificate of “SAM Twin Phantom V4.0/V4.0C’’ ........................................................................ 118 17 Application Note System Performance Check ............................................................................ 119 17.1 Purpose of system performance check ............................................................................... 119 17.2 System Performance check procedure ................................................................................ 119 17.3 Uncertainty Budget ................................................................................................................. 120 17.4 Power set-up for validation .................................................................................................... 123 17.5 Laboratory reflection .............................................................................................................. 124 17.6 Additional system checks ...................................................................................................... 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 3 of 124 2 Calibration report “Probe ET3DV6” Annex D to Test report no.: 1-6965/13-20-02-C Page 4 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 5 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 6 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 7 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 8 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 9 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 10 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 11 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 12 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 13 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 14 of 124 3 Calibration report “Probe ES3DV3” Annex D to Test report no.: 1-6965/13-20-02-C Page 15 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 16 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 17 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 18 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 19 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 20 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 21 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 22 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 23 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 24 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 25 of 124 4 Calibration report “Probe ES3DV3” Annex D to Test report no.: 1-6965/13-20-02-C Page 26 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 27 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 28 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 29 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 30 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 31 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 32 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 33 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 34 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 35 of 124 Annex D to Test report no.: 1-6965/13-20-02-C Page 36…

Text truncated - open the document above for the full version.

Page 1 of 170 TEST REPORT Test Report No.: 1-6965/13-20-02-D Testing Laboratory Applicant CETECOM ICT Services GmbH Untertürkheimer Straße 6 – 10 66117 Saarbrücken/Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom.com e-mail: [email protected] Accredited Test Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-01 Sony Mobile Communications Inc. Nya Vattentornet 22188 Lund/SWEDEN Phone: +46 46 19 30 00 Contact: Mikael Nilsson e-mail: [email protected] Phone: +46 7 03 22 75 03 Fax: -/- Manufacturer Sony Mobile Communications Inc. 1-8-15 Kohnan, Minato-ku, Tokyo, 108-0075 Japan Test Standard/s IEEE 1528-2003 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR)in the Human Head from Wireless Communications Devices: Measurement Techniques RSS-102 Issue 4 Radio Frequency Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: Smart Phone Device type: portable device S/N serial number: CB5A1Z1Y8L / CB5A1Z1Y6X / CB5A1Z1Y51 / CB5A1Z1Y50/ CB5A1Z1Y0Y / CB5A1Z1Y49 / CB5A1Z1Y7G / CB5A1Z1Y2Y FCC-ID: PY7PM-0742 IMEI-Number: 00440245 2668 589 / 004402452668456 / 004402452668373 / 004402452668365 / 004402452668324 / 004402452668803 Hardware status: AP1.0 Software status: 23.0.E0.81 Frequency: see technical details Antenna: integrated antenna Battery option: Integrated Li-polymer battery 3.7V Accessories: --- Test sample status: identical prototype Exposure category: general population / uncontrolled environment This test report is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test Report authorised: Test performed: Thomas Vogler Oleksandr Hnatovskiy Professional Specialist Test report no.: 1-6965/13-20-02-D Page 2 of 170 1 Table of contents 1 Table of contents ....................................................................................................................................... 2 2 General information .................................................................................................................................. 4 2.1 Notes and disclaimer ..................................................................................................................... 4 2.2 Application details ......................................................................................................................... 4 2.3 Statement of compliance ............................................................................................................... 4 2.4 Technical details............................................................................................................................. 5 2.5 Transmitter and Antenna Operating Configurations .................................................................. 6 3 Test standards/ procedures references .................................................................................................. 7 3.1 RF exposure limits ...................................................................................................…

Text truncated - open the document above for the full version.
