Important Information Before you use your device, please read the Important Information provided in your device regarding warranty, safety and handling information. Protecting your device from water and dust Your device has IP (Ingress Protection) ratings of IP55 and IP58. These ratings mean that your device is dust resistant and is protected against low pressure water stream as well as against the effects of submersion for 30 minutes in fresh (non-saline) water up to 1.5 metres deep. Always firmly attach all covers to ensure the water and dust resistance of the device. If liquid is detected inside the device, for example, underneath one of the covers, your warranty will be void. Before using your device in water and in dusty conditions, refer to the relevant section of the User guide for your device for more detailed information. An online User guide as well as a downloadable version is available at www.sonymobile.com/support. Overview 6 1235 7 8 4 9 10 1112 13 14 15 16 1. Front camera lens 2. Speaker/Charging light/Notification light 3. Second microphone 4. Proximity/Light sensor 5. Headset jack 6. Power key 7. Volume/Zoom key 8. Camera key 9. Speaker 10. Microphone 11. Main camera lens 12. Camera light 13. Charger/USB port cover 14. NFC™ detection area 15. Charging dock connector 16. Cover for micro SIM/ memory card slot Assembly Make sure you insert the micro SIM card into the SIM card holder before inserting the card into the device. Also, don’t confuse the SIM card slot with the memory card slot. To insert the micro SIM card If you insert the SIM card while the device is powered on, the device restarts automatically. 1 Detach the cover for the micro SIM card holder. 2 Using a fingernail or other similar object, drag out the SIM card holder. 3 Place the micro SIM card in the SIM card holder, then reinsert the holder. 4 Re-attach the cover. Make sure you reinsert the SIM card holder in the correct orientation. When you drag the holder out to insert the micro SIM card, do not turn it around. To insert the memory card 1 Remove the memory card slot cover. 2 Insert the memory card into the memory card slot with the gold coloured contacts facing down, then reattach the memory card slot cover. Basics Turning on the device Make sure that the battery is charged for at least 30 minutes before you turn on the device for the first time. To turn on the device Make sure that the battery is charged for at least 30 minutes before you turn on the device for the first time. 1 Press and hold down the power key until the device vibrates. 2 Wait a while for the device to start. Waking up the screen To activate the screen • Briefly press the power key . • If Tap to wake up mode is enabled, double-tap the screen. To enable Tap to wake up mode, go to the Home screen, then tap > Settings > Display > Tap to wake up. Setting up your device Basic settings The first time you start your device, a setup guide explains basic device functions and helps you enter essential settings. You can also access the setup guide later. To access the setup guide manually 1 From the Home screen, tap . 2 Tap Settings > Setup guide. Accessing settings View and change settings for your device from the Settings menu. The Settings menu is accessible from both the Notification panel and the Application screen. To access your device settings 1 From your Home screen, tap . 2 Find and tap Settings. Transferring your contacts Xperia™ Transfer and Contacts Setup are applications within the PC Companion and the Sony Bridge for Mac computer programs that help you to collect contacts from your old device and transfer them to your new device. These applications support several device brands, including iPhone, Samsung, HTC, BlackBerry, LG, Motorola and Nokia. You need: • An Internet-connected computer. • A USB cable for your old device. • A USB cable for your new Android™ device. • Your old device. • Your new Android™ device. To transfer contacts to your new device 1 Search and download PC Companion (on a PC) or Bridge for Mac (on a Mac computer) from www.sonymobile.com if the application is not already installed. 2 After successful installation, open the PC Companion application or the Sony Bridge for Mac application, then click Xperia™ Transfer or Contacts Setup and follow the relevant instructions to transfer your contacts. Finding your way Using the keys Back navigation key • Go back to the previous screen within an application or close the application. Home navigation key • Exit an application and go back to the Home screen. Task navigation key • Open the recently used applications window and the small apps bar. Application screen • Open the Application screen. Basic applications and settings Make phone calls by dialling the number manually or by using the smart dial function. Use the Messaging application to send and receive text and multimedia messages. Go to Google Play™ to download free and paid applications for your device. Optimise the device settings to suit your own requirements. Status and notifications To open or close the Notification panel Drag down two fingers instead of one to open the Quick settings panel instead. Support on the web Visit www.sonymobile.com/support to access a range of support options for your device, including downloads, troubleshooting tips and a User guide. Legal information Sony D6563 Publication number: 1274-4575.1 This Startup guide is published by Sony Mobile Communications AB or its local affiliated company, without any warranty. Improvements and changes to this Startup guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this Startup guide. All illustrations are for illustration only and may not accurately depict the actual device. See regulatory information such as the CE mark in the re…
